1.0 Introduction

This manual describes the functional, mechanical and interface specifications for the following Seagate

Barracuda® ES Serial ATA model drives:

ST3750640NS ST3500630NS ST3400620NS ST3320620NS ST3250620NS

ST3750840NS ST3500830NS ST3400820NS ST3320820NS ST3250820NS

These drives provide the following key features:

• 7,200 RPM spindle speed.

• High instantaneous (burst) data-transfer rates (up to 300 Mbytes per second).

• Perpendicular recording technology provides the drives with increased areal density.

• State-of-the-art cache and on-the-fly error-correction algorithms.

• Native Command Queueing with command ordering to increase performance in demanding applications.

• Full-track multiple-sector transfer capability without local processor intervention.

• Quiet operation.

• SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.

• Support for S.M.A.R.T. drive monitoring and reporting.

• Supports latching SATA cables and connectors.

Barracuda ES Serial ATA Product Manual, Rev. B 1

1.1 About the Serial ATA interface

The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The prim ary
advantages include:

• Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jump­ers or other configuration options.

• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.

• Scalability to higher performance levels.

In addition, Serial ATA makes the transition from parallel A TA easy by providing legacy software support. Serial
ATA was designed to allow you to install a Serial ATA host adapter and Serial ATA disc drive in your current
system and expect all of your existing applications to work as normal.

The Serial ATA interface connects each disc drive in a point-to-point configuration with the Serial ATA host
adapter. There is no master/slave relationship with Serial ATA devices like there is with parallel ATA. If two
drives are attached on one Serial ATA host adapter, the host operating system views the two devices as if they
were both “masters” on two separate ports. This essentially means both drives behave as if they are Device 0
(master) devices.

Note. The host adapter may, optionally, emulate a master/slave environment to host software where two

devices on separate Serial ATA ports are represented to host software as a Device 0 (master) and
Device 1 (slave) accessed at the same set of host bus addresses. A host adapter that emulates a
master/slave environment manages two sets of shadow registers. This is not a typical Serial ATA
environment.

The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide
backward compatibility with existing host systems and software. The Command and Control Block registers,
PIO and DMA data transfers, resets, and interrupts are all emulated.

The Serial ATA host adapter contains a set of register s that shadow the content s of the traditional de vice regis­ters, referred to as the Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For addi­tional information about how Serial ATA emulates parallel ATA, refer to the “S erial ATA: High Speed Serialized
AT Attachment” specification. The specification can be downloaded from www .serialata.org.

2 Barracuda ES Serial ATA Product Manual, Rev. B

2.0 Drive specifications

Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal
power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the
following drive models:

ST3750640NS ST3500630NS ST3400620NS ST3320620NS ST3250620NS
ST3750840NS ST3500830NS ST3400820NS ST3320820NS ST3250820NS

2.1 Specification summary tables

The specifications listed in the following tables are for quick refere nce. For details on specification measure­ment or definition, see the appropriate section of this manual.

Barracuda ES Serial ATA Product Manual, Rev. B 3

Table 1: Drive specifications summary for 750 Gbyte models

Drive specification ST3750640NS ST3750840NS

Formatted Gbytes (512 bytes/sector)* 750
Guaranteed sectors 1,465,149,168
Heads 8 8
Discs 4 4
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density, KBPI (kbits/in max) 926
Track density, KTPI (ktracks/in avg.) 145
Areal density, (Gbits/in2 avg) 128.2
Spindle speed (RPM) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate OD (Mbytes/sec max) 78
I/O data-transfer rate (Mbytes/sec max) 300
ATA data-transfer modes supported PIO modes 0–4

Cache buffer 16 Mbytes 8 Mbytes
Height (mm max) 26.1 mm (1.028 inches)
Width (mm max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (mm max) 146.99 mm (5.787 inches)
Weight (max) 720 grams
Average latency 4.16 msec
Power-on to ready (sec max) 15 sec
Standby to ready (sec max) 15 sec
Track-to-track seek time (msec typical) <0.8 read; <1.0 write
Average seek, read (msec typical) <8.5
Average seek, write (msec typical) <10.0
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%

Ambient temperature 5° to 55°C (operating)

Temperature gradient (°C per hour max) 20°C (operating)

Relative humidity 5% to 90% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 37.7 (operating)

Altitude, operating –60.96 m to 3,048 m

Altitude, nonoperating
(below mean sea level, max)

Operational Shock (max at 2 msec) 63 Gs
Non-Operational Shock (max at 2 msec) 300 Gs

Multiword DMA modes 0–2
Ultra DMA modes 0–6

12V ± 10%

–40° to 70°C (nonoperating)

30°C (nonoperating)

5% to 95% (nonoperating)

37.7 (nonoperating)

(–200 ft. to 10,000+ ft.)
–60.96 m to 12,192 m

(–200 ft. to 40,000+ ft.)

4 Barracuda ES Serial ATA Product Manual, Rev. B

Drive specification ST3750640NS ST3750840NS

Vibration, operating 5–22 Hz: 0.25 Gs, Limited displacement

Vibration, nonoperating 5–22 Hz: 0.25 Gs, Limited displacement

Drive acoustics, sound power (bels)
Idle** 2.7 (typical)

Performance seek 3.2 (typical)

Nonrecoverable read errors 1 sector per 10
Annualized Failure Rate (AFR) 0.73%
Warranty 5 years on distribution units.

Contact start-stop cycles
(25°C, 50% rel. humidity)

Supports Hotplug operation per Serial ATA Revision 2.5
specification

22–350 Hz: 0.50 Gs
350–500 Hz: 0.25 Gs

22–350 Hz: 5.0 Gs
350–500 Hz: 1.0 Gs

3.0 (max)

3.9 (max)

15

bits read

To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be asked
to provide the drive serial number, model number (or part number) and
country of purchase. The system will display the warranty information for
your drive.

50,000

Yes

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

**During periods of drive idle, some offline a ctivity may occur according to the S.M.A.R.T. specification, which may incr ease acoustic and

power to operational levels.

Barracuda ES Serial ATA Product Manual, Rev. B 5

Table 2: Drive specifications summary for 500 Gbyte models

Drive specification ST3500630NS ST3500830NS

Formatted Gbytes (512 bytes/sector)* 500
Guaranteed sectors 976,773,168
Heads 6
Discs 3
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density, KBPI (kbits/in max) 813
Track density, KTPI (ktracks/in avg.) 145
Areal density, (Gbits/in2 avg) 114.4
Spindle speed (RPM) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate OD (Mbytes/sec max) 72
I/O data-transfer rate (Mbytes/sec max) 300
ATA data-transfer modes supported PIO modes 0–4

Cache buffer 16 Mbytes 8 Mbytes
Height (mm max) 26.1 mm (1.028 inches)
Width (mm max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (mm max) 146.99 mm (5.787 inches)
Weight (max) 635 grams
Average latency (msec) 4.16
Power-on to ready (sec max) 15 sec
Standby to ready (sec max) 15 sec
Track-to-track seek time (msec typical) <0.8 (read), <1.0 (write)
Average seek, read (msec typical) <8.5
Average seek, write (msec typical) <10.0
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%

Ambient temperature 5° to 55°C (operating)

Temperature gradient (°C per hour max) 20°C (operating)

Relative humidity 5% to 90% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 37.7 (operating)

Altitude, operating –60.96 m to 3,048 m

Altitude, nonoperating
(below mean sea level, max)

Operational Shock (max at 2 msec) 63 Gs
Non-Operational Shock (max at 2 msec) 300 Gs

Multiword DMA modes 0–2
Ultra DMA modes 0–6

12V ± 10%

–40° to 70°C (nonoperating)

30°C (nonoperating)

5% to 95% (nonoperating)

37.7 (nonoperating)

(–200 ft. to 10,000+ ft.)
–60.96 m to 12,192 m

(–200 ft. to 40,000+ ft.)

6 Barracuda ES Serial ATA Product Manual, Rev. B

Drive specification ST3500630NS ST3500830NS

Vibration, operating 5–22 Hz: 0.25 Gs, Limited displacement

Vibration, nonoperating 5–22 Hz: 0.25 Gs, Limited displacement

Drive acoustics, sound power (bels)
Idle** 2.5 (typical)

Performance seek 3.2 (typical)

Nonrecoverable read errors 1 sector per 10
Annualized Failure Rate (AFR) 0.73%
Warranty 5 years on distribution units.

Contact start-stop cycles
(25°C, 50% rel. humidity)

Supports Hotplug operation per SATA II
specification

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

**During periods of drive idle, some offline a ctivity may occur according to the S.M.A.R.T. specification, which may incr ease acoustic and

power to operational levels.

22–350 Hz: 0.50 Gs
350–500 Hz: 0.25 Gs

22–350 Hz: 5.0 Gs
350–500 Hz: 1.0 Gs

2.8 (max)

3.5 (max)

15

bits read

To determine the warra nty for a specific drive, use a web browser to access
the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be asked to
provide the drive serial number, model number (or part number) and country
of purchase. The system will display the warranty information for your drive.

50,000

Yes

Barracuda ES Serial ATA Product Manual, Rev. B 7

Table 3: Drive specifications summary for 400 Gbyte models

Drive specification ST3400620NS ST3400820NS

Formatted Gbytes (512 bytes/sector)* 400
Guaranteed sectors 781,422,768
Heads 5
Discs 3
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density, KBPI (kbits/in max) 781
Track density, KTPI (ktracks/in avg.) 145
Areal density, (Gbits/in2 avg) 128.2
Spindle speed (RPM) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate OD (Mbytes/sec max) 72
I/O data-transfer rate (Mbytes/sec max) 300
ATA data-transfer modes supported PIO modes 0–4

Cache buffer 16 Mbytes 8 Mbytes
Height (mm max) 26.1 mm (1.028 inches)
Width (mm max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (mm max) 146.99 mm (5.787 inches)
Weight (max) 635 grams
Average latency (msec) 4.16
Power-on to ready (sec max) 15 sec
Standby to ready (sec max) 15 sec
Track-to-track seek time (msec typical) <0.8 (read), <1.0 (write)
Average seek, read (msec typical) <8.5
Average seek, write (msec typical) <10.0
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%

Ambient temperature 5° to 55°C (operating)

Temperature gradient (°C per hour max) 20°C (operating)

Relative humidity 5% to 90% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 37.7 (operating)

Altitude, operating –60.96 m to 3,048 m

Altitude, nonoperating
(below mean sea level, max)

Operational Shock (max at 2 msec) 63 Gs
Non-Operational Shock (max at 2 msec) 300 Gs

Multiword DMA modes 0–2
Ultra DMA modes 0–6

12V ± 10%

–40° to 70°C (nonoperating)

30°C (nonoperating)

5% to 95% (nonoperating)

37.7 (nonoperating)

(–200 ft. to 10,000+ ft.)
–60.96 m to 12,192 m

(–200 ft. to 40,000+ ft.)

8 Barracuda ES Serial ATA Product Manual, Rev. B

Drive specification ST3400620NS ST3400820NS

Vibration, operating 5–22 Hz: 0.25 Gs, Limited displacement

Vibration, nonoperating 5–22 Hz: 0.25 Gs, Limited displacement

Drive acoustics, sound power (bels)
Idle** 2.5 (typical)

Performance seek 3.2 (typical)

Nonrecoverable read errors 1 sector per 10
Annualized Failure Rate (AFR) 0.73%
Warranty 5 years on distribution units.

Contact start-stop cycles
(25°C, 50% rel. humidity)

Supports Hotplug operation per SATA II
specification

22–350 Hz: 0.50 Gs
350–500 Hz: 0.25 Gs

22–350 Hz: 5.0 Gs
350–500 Hz: 1.0 Gs

2.8 (max)

3.5 (max)

15

bits read

To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. Y ou will be asked
to provide the drive serial number, model number (or part number) and
country of purchase. The system will display the warranty information for
your drive.

50,000

Yes

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

**During periods of drive idle, some offline a ctivity may occur according to the S.M.A.R.T. specification, which may incr ease acoustic and

power to operational levels.

Barracuda ES Serial ATA Product Manual, Rev. B 9

Table 4: Drive specifications summary for 320 Gbyte models

Drive specification ST3320620NS ST3320820NS

Formatted Gbytes (512 bytes/sector)* 320
Guaranteed sectors 625,142,448
Heads 4
Discs 2
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density, KBPI (kbits/in max) 781
Track density, KTPI (ktracks/in avg.) 145
Areal density, (Gbits/in2 avg) 114.4
Spindle speed (RPM) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate OD (Mbytes/sec max) 72
I/O data-transfer rate (Mbytes/sec max) 300
ATA data-transfer modes supported PIO modes 0–4

Cache buffer 16 Mbytes 8 Mbytes
Height (mm max) 26.1 mm (1.028 inches)
Width (mm max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (mm max) 146.99 mm (5.787 inches)
Weight (max) 635 grams
Average latency (msec) 4.16
Power-on to ready (sec max) 15 sec
Standby to ready (sec max) 15 sec
Track-to-track seek time (msec typical) <0.8 (read), <1.0 (write)
Average seek, read (msec typical) <8.5
Average seek, write (msec typical) <10.0
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%

Ambient temperature 5° to 55°C (operating)

Temperature gradient (°C per hour max) 20°C (operating)

Relative humidity 5% to 90% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 37.7 (operating)

Altitude, operating –60.96 m to 3,048 m

Altitude, nonoperating
(below mean sea level, max)

Operational Shock (max at 2 msec) 63 Gs
Non-Operational Shock (max at 2 msec) 350 Gs

Multiword DMA modes 0–2
Ultra DMA modes 0–6

12V ± 10%

–40° to 70°C (nonoperating)

30°C (nonoperating)

5% to 95% (nonoperating)

37.7 (nonoperating)

(–200 ft. to 10,000+ ft.)
–60.96 m to 12,192 m

(–200 ft. to 40,000+ ft.)

10 Barracuda ES Serial ATA Product Manual, Rev. B

Drive specification ST3320620NS ST3320820NS

Vibration, operating 5–22 Hz: 0.25 Gs, Limited displacement

Vibration, nonoperating 5–22 Hz: 0.25 Gs, Limited displacement

Drive acoustics, sound power (bels)
Idle** 2.5 (typical)

Performance seek 3.2 (typical)

Nonrecoverable read errors 1 sector per 10
Annualized Failure Rate (AFR) 0.73%
Warranty 5 years on distribution units.

Contact start-stop cycles
(25°C, 50% rel. humidity)

Supports Hotplug operation per SATA II
specification

22–350 Hz: 0.50 Gs
350–500 Hz: 0.25 Gs

22–350 Hz: 5.0 Gs
350–500 Hz: 1.0 Gs

2.8 (max)

3.5 (max)

15

bits read

To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. Y ou will be asked
to provide the drive serial number, model number (or part number) and
country of purchase. The system will display the warranty information for
your drive.

50,000

Yes

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

**During periods of drive idle, some offline a ctivity may occur according to the S.M.A.R.T. specification, which may incr ease acoustic and

power to operational levels.

Barracuda ES Serial ATA Product Manual, Rev. B 11

Table 5: Drive specifications summary for 250 Gbyte models

Drive specification ST3250620NS ST3250820NS

Formatted Gbytes (512 bytes/sector)* 250
Guaranteed sectors 488,397,168
Heads 3
Discs 2
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density, KBPI (kbits/in max) 813
Track density, KTPI (ktracks/in avg.) 145
Areal density, (Gbits/in2 avg) 114.4
Spindle speed (RPM) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate OD (Mbytes/sec max) 72
I/O data-transfer rate (Mbytes/sec max) 300
ATA data-transfer modes supported PIO modes 0–4

Cache buffer 16 Mbytes 8 Mbytes
Height (mm max) 26.1 mm (1.028 inches)
Width (mm max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (mm max) 146.99 mm (5.787 inches)
Weight (max) 580 grams (1.28 lb.)
Average latency (msec) 4.16
Power-on to ready (sec max) 11 sec
Standby to ready (sec max) 15 sec
Track-to-track seek time (msec typical) <0.8 (read), <1.0 (write)
Average seek, read (msec typical) <8.5
Average seek, write (msec typical) <10.0
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%

Ambient temperature 5° to 55°C (operating)

Temperature gradient (°C per hour max) 20°C (operating)

Relative humidity 5% to 90% (operating)

Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 37.7 (operating)

Altitude, operating –60.96 m to 3,048 m

Altitude, nonoperating
(below mean sea level, max)

Operational Shock (max at 2 msec) 63 Gs
Non-Operational Shock (max at 2 msec) 350 Gs

Multiword DMA modes 0–2
Ultra DMA modes 0–6

12V ± 10%

–40° to 70°C (nonoperating)

30°C (nonoperating)

5% to 95% (nonoperating)

37.7 (nonoperating)

(–200 ft. to 10,000+ ft.)
–60.96 m to 12,192 m

(–200 ft. to 40,000+ ft.)

12 Barracuda ES Serial ATA Product Manual, Rev. B

Drive specification ST3250620NS ST3250820NS

Vibration, operating 5–22 Hz: 0.25 Gs, Limited displacement

Vibration, nonoperating 5–22 Hz: 0.25 Gs, Limited displacement

Drive acoustics, sound power (bels)
Idle** 2.5 (typical)

Performance seek 3.2 (typical)

Nonrecoverable read errors 1 sector per 10
Annualized Failure Rate (AFR) 0.73%
Warranty 5 years on distribution units.

Contact start-stop cycles
(25°C, 50% rel. humidity)

Supports Hotplug operation per SATA II
specification

22–350 Hz: 0.50 Gs
350–500 Hz: 0.25 Gs

22–350 Hz: 5.0 Gs
350–500 Hz: 1.0 Gs

2.8 (max)

3.5 (max)

15

bits read

To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Y our Warranty” link. You will be asked
to provide the drive serial number, model number (or part number) and
country of purchase. The system will display the warranty information for
your drive.

50,000

Yes

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

**During periods of drive idle, some offline a ctivity may occur according to the S.M.A.R.T. specification, which may incr ease acoustic and

power to operational levels.

Barracuda ES Serial ATA Product Manual, Rev. B 13

2.2 Formatted capacity

Model

ST3750640NS 750 Gbytes 1,465,149,168 512
ST3750840NS 750 Gbytes 1,465,149,168 512
ST3500630NS 500 Gbytes 976,773,168 512
ST3500830NS 500 Gbytes 976,773,168 512
ST3400620NS 400 Gbytes 781,422,768 512
ST3400820NS 400 Gbytes 781,422,768 512
ST3320620NS 320 Gbytes 625,142,448 512
ST3320820NS 320 Gbytes 625,142,448 512
ST3250620NS 250 Gbytes 488,397,168 512
ST3250820NS 250 Gbytes 488,397,168 512

*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment

and formatting.

Formatted
capacity*

Guaranteed
sectors

Bytes per sector

2.2.1 LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1,
where n is the number of guaranteed sectors as defined above.

See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48­bit addressing support of drives with capacities over 137 Gbytes.

2.3 Default logical geometry

Cylinders Read/write heads Sectors per track

16,383 16 63

LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1,
where n is the number of guaranteed sectors as defined above.

14 Barracuda ES Serial ATA Product Manual, Rev. B

2.4 Recording and interface technology

750GB 500GB 400GB 320GB 250GB

Interface Serial ATA (SATA)
Recording method Perpendicular
Recording density , KBPI (kbits/inch max) 926 813 781 813
Track density, KTPI (ktracks/inch avg) 145
Areal density (Gbits/inch2 avg) 128.2 114.4
Spindle speed (RPM) (± 0.2%) 7,200
Internal data transfer rate (Mbits/sec max) 1,030
Sustained data transfer rate (Mbytes/sec max) 78 72
I/O data-transfer rate (Mbytes/sec max) 300 (Ultra DMA mode 5)

2.5 Physical characteristics

Maximum height 26.1 mm (1.028 inches)
Maximum width 101.6 mm (4.000 +/- 0.010 inches)
Maximum length 146.99 mm (5.787 inches)
Max weight

ST3750640NS and ST3750840NS 720 grams (1.59 lbs)
ST3500630NS, ST3500830NS, ST3400620NS,

ST3400820NS, ST3320620NS and ST3320820NS

ST3250620NS and ST3250820NS 580 grams (1.28 lbs)
Cache buffer
ST3750640NS

ST3500630NS
ST3400620NS
ST3320620NS
ST3250620NS

ST3750840NS
ST3500830NS
ST3400820NS
ST3320820NS
ST3250820NS

635 grams (1.4 lbs)

16 Mbytes (16,384 kbytes)

8 Mbytes (8,192 kbytes)

Barracuda ES Serial ATA Product Manual, Rev. B 15

2.6 Seek time

Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using
drive diagnostics. The specifications in the table below are defined as follows:

• Track-to-track seek time is an average of all possible single-track seeks in both directions.

• Average seek time is a true s tatistical random average of at le ast 5,000 measurements of seeks between
random tracks, less overhead.

*Typical seek times (msec) Read Write

Track-to-track <0.8 <1.0
Average <8.5 <10.0
Average latency: 4.16 4.16

*Measured in performance mode.
Note. These drives are designed to consistently meet the seek times represented in this manual. Physical

seeks, regardless of mode (such as track-to-track and average), are expected to meet the noted
values. However, due to the manner in which these drives are formatted, benchmark tests that
include command overhead or measure logical seeks may produce results that vary from these
specifications.

2.7 Start/stop times

Power-on to Ready (sec) 15 (max)
Standby to Ready (sec) 15 (max)
Ready to spindle stop (sec) 10 (max)

2.8 Power specifications

The drive receives DC power (+5V or +12V) through a na tive SATA po wer connector. See Figure 4 on page 28.

2.8.1 Power consumption

Power requirements for the drives are listed in the t able on p ag e 9. Typical power measurements are based on
an average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient
temperature.

• Spinup power

Spinup power is measured from the time of power-on to the time that the drive spindle reaches op erating
speed.

• Seek mode

During seek mode, the read/write actuator arm moves toward a specific position on the disc surface and
does not execute a read or write operation. Servo electronics are active. Seek mode power represents the
worst-case power consumption, using only random seeks with read or write latency time. This mode is not
typical and is provided for worst-case information.

• Read/write power and current

Read/write power is measured with the heads on track, based on a 16-sector write followed by a 32-msec
delay, then a 16-sector read followed by a 32-msec delay.

16 Barracuda ES Serial ATA Product Manual, Rev. B

• Operating power and current

Operating power is measured using 40 percent r andom seeks, 40 percent r ead/write mode (1 write for each
10 reads) and 20 percent drive idle mode.

• Idle mode power

Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in
a random track location.

• Standby mode

During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/
write electronics are in power-down mode.

Table 6: DC power requirements

Power dissipation (4-disc values shown) Avg (watts 25 ° C) Avg 5V typ amps Avg 12V typ amps

Spinup — — 2.8 0 (peak)
Idle* 9.30 0.611 0.520
Idle* (with offline activity) 10.40 0.719 0.567
Operating (40% r/w, 40% seek, 20% inop.) 13.00 0.772 0.762
Seeking (random, 20% idle) 12.60 0.613 0.795
Standby 0.80 0.106 0.023
Sleep 0.80 0.106 0.023

*During periods of drive idle, some offline activity may occur according to the S.M.A.R. T. specification, which may increase acoustic and

power to operational levels.

2.8.1.1 Typical current profiles

Figure 1. Typical 5V startup and operation cu rre nt profile

Barracuda ES Serial ATA Product Manual, Rev. B 17

Figure 2. Typical 12V startup and operation current profile

2.8.2 Conducted noise

Input noise ripple is measured at the host system powe r supply across an equivalent 80-ohm resistive load on
the +12 volt line or an equivalent 15-ohm resistive load on the +5 volt line.

• Using 12-volt power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave
injected noise at up to 10 MHz.

• Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave
injected noise at up to 10 MHz.

Note. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write

current.

2.8.3 Voltage tolerance

Voltage tolerance (including noise):
5V ± 5%

12V ± 10%

2.8.4 Power-management modes

The drive provides programmable power management to pr ovide greater energy efficiency. In most systems,
you can control power management through the system setup program. The drive features the following
power-management modes:

Power modes Heads Spindle Buffer

Active Tracking Rotating Enabled
Idle Tracking Rotating Enabled
Standby Parked Stopped Enabled
Sleep Parked Stopped Disabled

• Active mode

The drive is in Active mode during the read/write and seek operations.

18 Barracuda ES Serial ATA Product Manual, Rev. B

• Idle mode

The buffer remains enabled, and the drive accepts all commands and returns to Active mode any time disc
access is necessary.

• Standby mode
The drive enters Standby mode when the host sends a Standby Immediate command. If the host has set

the standby timer, the drive can also enter Standby mode automatically after the drive has been inactive for
a specifiable length of time. The standby timer delay is established using a Standby or Idle command. In
Standby mode, the drive buffer is enabled, the heads are parked and the spindle is at rest. The drive
accepts all commands and returns to Active mode any time disc access is necessary.

•Sleep mode

The drive enters Sleep mode after receiving a Sleep command from the host. In Sleep mode, the drive
buffer is disabled, the heads are parked and the spindle is at rest. The drive leaves Sleep mode after it
receives a Hard Reset or Soft Reset from the host. After receiving a reset, the drive exits Sleep mode and
enters Standby mode with all current translation parameters intact.

• Idle and Standby timers

Each time the drive performs an Active function (read, write or seek), the standby timer is reinitializ ed and
begins counting down from its specified delay times to zero. If the standby timer reaches zero before any
drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the
drive accepts all commands and returns to Active mode when disc access is necessary.

Barracuda ES Serial ATA Product Manual, Rev. B 19

2.9 Environmental specifications

2.9.1 Ambient temperature

Ambient temperature is defined as the temperature of the environment immediately surrounding the drive.
Actual drive case temperature should not exceed 69°C (156°F) within the operating ambient conditions.

Above 1,000 feet (305 meters), the maximum temperature is derated linearly to 112°F (44°C) at 10,000 feet
(3,048 meters).

Operating: 5° to 55°C (41° to 131°F)
Nonoperating: –40° to 70°C (–40° to 158°F)

2.9.2 Temperature gradient

Operating: 20°C per hour (68°F per hour max), without condensation
Nonoperating: 30°C per hour (86°F per hour max)

2.9.3 Humidity

2.9.3.1 Relative humidity

Operating: 5% to 90% noncondensing (30% per hour max)
Nonoperating: 5% to 95% noncondensing (30% per hour max)

2.9.3.2 Wet bulb temperature

Operating: 37.7°C (99.9°F max)
Nonoperating: 37.7°C (99.9°F max)

2.9.4 Altitude

Operating: –60.96 m to 3,048 m (–200 ft. to 10,000+ ft.)
Nonoperating: –60.96 m to 12,192 m (–200 ft. to 40,000+ ft.)

2.9.5 Shock

All shock specifications assume that the drive is mounted securely with the input shock applied at the drive
mounting screws. Shock may be applied in the X, Y or Z axis.

2.9.5.1 Operating shock

These drives comply with the performance levels specified in this document when subjected to a maximum
operating shock of 63 Gs based on half-sine shock pulses of 2 msec. Shocks should not be repeated more
than two times per second.

2.9.5.2 Nonoperating shock

The nonoperating shock level that the drive can experienc e without incurring physical damage or degradation
in performance when subsequently put into operation is 300 Gs for 750, 500 and 400 GB models) and 350 Gs
(for 250 GB models) based on a nonrepetitive half-sine shock pulse of 2 msec duration.

20 Barracuda ES Serial ATA Product Manual, Rev. B

2.9.6 Vibration

All vibration specifications assume that the drive is mounted securely with the input vibration applied at the
drive mounting screws. Vibration may be applied in the X, Y or Z axis.

2.9.6.1 Operating vibration

The maximum vibration levels that the drive may experience while meeting the performance standards speci­fied in this document are specified below.

5–22 Hz 0.25 Gs (Limited displacement)
22–350 Hz 0.50 Gs
350–500 Hz 0.25 Gs

2.9.6.2 Nonoperating vibration

The maximum nonoperating vibration levels that the drive may experience without incurring physical damage
or degradation in performance when subsequently put into operatio n are specified below.

5–22 Hz 0.25 Gs (limited displacement)
22–350 Hz 5.0 Gs
350–500 Hz 1.0 Gs

Barracuda ES Serial ATA Product Manual, Rev. B 21

2.10 Acoustics

Drive acoustics are measured as ov erall A-weighted acoustic sound power levels (no pure tones). All mea­surements are consistent with ISO document 7779. Sound power measurements are taken under essentially
free-field conditions over a reflecting plane. For all tests, the drive is oriented with the cover facing upward.

Note. For seek mode tests, the drive is placed in seek mod e only. The number of seeks per second is defined

by the following equation:

(Number of seeks per second = 0.4 / (average latency + average access time)

Table 7: Fluid Dynamic Bearing (FDB) motor acoustics

Idle* Performance seek

ST3750640NS, ST3750840NS 2.7 bels (typ)

3.0 bels (max)

ST3500630NS, ST3500830NS 2.5 bels (typ)

2.8 bels (max)

ST3400620NS, ST3400820NS
ST3320620NS, ST3320820NS

ST3250620NS, ST3250820NS 2.5 bels (typ)

*During periods of drive idle, some offline activity may occur according to the S.M.A.R. T. specification, which may increase acoustic and

power to operational levels.

2.5 bels (typ)

2.8 bels (max)

2.8 bels (max)

3.2 bels (typ)

3.9 bels (max)

3.2 bels (typ)

3.5 bels (max)

3.2 bels (typ)

3.5 bels (max)

3.2 bels (typ)

3.5 bels (max)

2.11 Electromagnetic immunity

When properly installed in a representative host syst em, the drive operates without errors or degradation in
performance when subjected to the radio frequency (RF) environments defined in the follo wing table:

Table 8: Radio frequency environments

Test Description Performance level Reference standard

Electrostatic
discharge

Radiated RF
immunity

Electrical fast
transient

Surge immunity ± 1 kV differential, ± 2 kV common, AC mains B EN 61000-4-5: 95

Contact, HCP, VCP: ± 4 kV; Air: ± 8 kV B EN 61000-4-2: 95

80 to 1,000 MHz, 3 V/m,
80% AM with 1 kHz sine
900 MHz, 3 V/m, 50% pulse modulation @ 200 Hz

± 1 kV on AC mains, ± 0.5 kV on external I/O B EN 61000-4-4: 95

A EN 61000-4-3: 96

ENV 50204: 95

Conducted RF
immunity

Voltage dips,
interrupts

150 kHz to 80 MHz, 3 Vrms, 80% AM with 1 kHz sine A EN 61000-4-6: 97

0% open, 5 seconds
0% short, 5 seconds
40%, 0.10 seconds
70%, 0.01 seconds

C
C
C
B

EN 61000-4-11: 94

22 Barracuda ES Serial ATA Product Manual, Rev. B

2.12 Reliability

2.12.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF)

The product shall achieve an Annualized Failure Rate (AFR) of 0.73% (MTBF of 1.2 million hours) when oper­ated in an environment that ensur es the HDA cas e temper atures do not exceed 4 0°C. Operation at case tem­peratures outside the specifications in Section 2.9 may increase the product AFR (decreas e MTBF). AFR and
MTBF are population statistics that are not relevant to individual units.

AFR and MTBF specifications are based on the following assumptions for business critical storage system
environments:

• 8,760 power-on-hours per year.

• 250 average motor start/stop cycles per year.

• Operations at nominal voltages.

• Systems will provide adequate cooling to ensure the case temperatures do not exceed 40°C. Temperatures

outside the specifications in

Nonrecoverable read errors 1 per 1015 bits read, max
Annualized Failure Rate (AFR) 0.73% (nominal power, 40°C ambient temperature)
Contact start-stop cycles 50,000 cycles

Warranty 5 years on distribution units.

Preventive maintenance None required.

Section 2.9 will increase the product AFR and decrease MTBF.

(at nominal voltage and temperature, with 60 cycles per hour and a 50% duty cycle)

To determine the warranty for a specific drive, use a web browser to access the fol­lowing web page:

www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be asked to provide

the drive serial number, model number (or part number) and country of purchase.
The system will display the warranty information for your drive.

2.13 Agency certification

2.13.1 Safety certification

The drives are recognized in accordance with UL 1950 and CSA C22.2 (950) and meet all applicable sections
of IEC950 and EN 60950 as tested by TUV North America.

2.13.2 Electromagnetic compatibility

Hard drives that display the CE mark comply with the European Union (EU) requirements specified in the Elec­tromagnetic Compatibility Directive (89/336/EEC). Testing is performed to the levels specified by the product
standards for Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and
the immunity levels are defined by EN 55024.

Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous
paragraph. Drives are tested in representative end-us er systems. Although CE-marked Seagate drives comply
with the directives when used in the test systems, we cannot guarantee that all systems will comply with the
directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O
cable (if necessary) and terminators on all unused I/O ports. Computer manufacturers and system integrators
should confirm EMC compliance and provide CE marking for their products.

Korean RRL

Barracuda ES Serial ATA Product Manual, Rev. B 23

If these drives have the Korea Ministry of Information and Communication (MIC) logo, they comply with para­graph 1 of Article 11 of the Electr omagnetic Compatibility control Regulation and meet the Electromagnetic
Compatibility (EMC) Framework requirements of the Radio Research Laboratory (RRL) Ministry of Information
and Communication Republic of Korea.

These drives have been tested and comply with the Electromagnetic Interferen ce/Ele ctromagn etic Susceptibil ­ity (EMI/EMS) for Class B products. Drives are tested in a representative, end-user system by a Korean-recog­nized lab.

• Barracuda ES

• Certificate number: STX-L3510 (B)

Australian C-Tick (N176)

If these models have the C-Tick marking, they comply with the Australia/New Zealand Standard AS/NZS3548
1995 and meet the Electromagnetic Compatibility (EMC) Framework req uireme nts of the Australian Communi
cation Authority (ACA).

2.13.3 FCC verification

These drives are intended to be contained solely with in a pe rsonal com puter or simila r enclosur e ( not attached
as an external device). As such, each drive is considered to be a subassembly even when it is individually mar
keted to the customer. As a subassembly, no Federal Communications Commission verification or certification
of the device is required.

Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total
assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B
computing device, pursuant to Subpart
likely to result in interference to radio and television reception.

J, Part 15 of the FCC rules. Operation with noncertified assemblies is

-

-

Radio and television interference. This equipment generates and uses radio frequency energy and if not
installed and used in strict accordanc e with the manufacturer’s instructions, may cause interference to radio
and television reception.

This equipment is designed to provide reasonable protection against such interference in a residential installa­tion. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause interference to radio or television, which can be determined by turning the equipment on and off,
you are encouraged to try one or more of the following corrective measures:

• Reorient the receiving antenna.

• Move the device to one side or the other of the radio or TV.

• Move the device farther away from the radio or TV.

• Plug the computer into a different outlet so that the receiver and computer are on different branch outlets.
If necessary, you should consult your dealer or an experienced radio/television technician for additional sug-

gestions. You ma y find helpful the following booklet prepared by the Federal Communications Commission:
How to Identify and Resolve Radio-Television Interference Problems. This booklet is available from the Super
intendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication num­ber 004-000-00345-4.

2.14 Environmental protection

Seagate designs its products to meet environmental protection requirements worldwide, including regulations
restricting certain chemical substances.

-

24 Barracuda ES Serial ATA Product Manual, Rev. B

2.14.1 European Union Restriction of Hazardous Substances (RoHS)

The European Union Restriction of Hazardous Substances (RoHS) Directive restricts the presence of chemical
substances, including Lead (Pb), in electronic products ef fective July 2006. Alth ough am endments to the Euro
pean Union’s Restriction of Hazardous Substances (RoHS) Directive have not b een finalized, to the best of our
knowledge the disc drives documented in this publication will comply with the final RoHS Directive require
ments.

A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep­resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our
supplier contracts require compliance with our che mical substance restrictions, and our suppliers document
their compliance with our requirements by providing material conten t declarations for all p arts and materials for
the disc drives documented in this publication. Current supplier declarations include disclosure of the inclusion
of any RoHS-regulated substance in such parts or materials.

Seagate also has internal systems in place to ensure on going compliance with the RoHS Directive and all laws
and regulations which restrict chemical content in electronic products. These systems include standard operat
ing procedures that ensure that restricted substances are not utilized in our manufacturing operations, labora­tory analytical validation testing, and an internal auditing process to ensure that all standard operating
procedures are complied with.

-

-

-

2.15 Corrosive environment

Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to
light industrial environments containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM
B845. However, this accelerated testing cannot duplicate every potential application environment. Users
should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive
chemicals as electronic drive component reliability can be affected by the installation environment. The silver,
copper, nickel and gold films used in Seagate product s are especially sensitive to the presence of sulfide, chlo
ride, and nitrate contaminants . Sulfur is found to be the most damaging. In addition, electronic components
should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or
exposed to an ambient relative humidity greater than 95%. Materials used in cabinet fabrication, such as vulca
nized rubber, that can outgas corrosive compounds should be minimized or eliminated. The useful life of any
electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives.

-

-

Barracuda ES Serial ATA Product Manual, Rev. B 25

26 Barracuda ES Serial ATA Product Manual, Rev. B

3.0 Configuring and mounting the drive

This section contains the specifications and instructions for configuring and mounting the drive.

3.1 Handling and static-discharge precautions

After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic dis­charge (ESD) hazards. Observe the following standard handling and static-discharge precautions:

Caution:

• Before handling the drive, put on a grounded wrist str ap , or ground yourself frequently by touching the metal

chassis of a computer that is plugged into a grounded outlet. Wea r a grounded wrist strap throughout the entire
installation procedure.

• Handle the drive by its edges or frame only.

• The drive is extremely fragile—handle it with care. Do not press down on the drive top cover.

• Always rest the drive on a padded, antistatic surface until you mount it in the computer.

• Do not touch the co nnector pins or the printed circuit board.

• Do not remove the factory-installed labels from the dr ive or cover them with additional labels. Removal voids

the warranty. Some factory-installed labels contain information needed to service the drive. Other labels are
used to seal out dirt and contamination.

Barracuda ES Serial ATA Product Manual, Rev. B 27

3.2 Configuring the drive

Each drive on the Serial ATA interface connects point-to-point with the Serial ATA host adapter. There is no
master/slave relationship because each drive is considered a master in a point-to-point relationship. If two
drives are attached on one Serial ATA host adapter, the host operating system views the two devices as if they
were both “masters” on two separate ports. Both drives behave as if they are Device 0 (master) devices.

Serial ATA drives are designed for easy installation. It is usually not necessary to set any jumpers on the drive
for proper operation; however, if you connect the drive and receive a “drive not detecte d” error, yo ur SATA­equipped motherboard or host adapter may use a chipset that does not suppor t SATA speed autonegotiation. If
you have a motherboard or host adapter that does not support autonegotiation:

• Install a jumper as shown in Figure 3 below to limit the data transfer rate to 1.5 Gbits per second (and leave
the drive connected to the SATA-equipped motherboard or host adapter that doesn’t support autonegoti ation)
or

• Install a SATA host adapter that supports autonegotiation, leave the drive jumper block set to “Normal
operation” (see Figure
the drive to a 1.5 Gbits/sec transfer rate.

3.0 Gbits per second operation

Limit data transfer rate to

1.5 Gbits per second

3 below), and connect the drive to that adapter. This option has the benefit of not limiting

Jumper block

SATA interface connector

Figure 3. Serial ATA connectors

SATA power connector

3.3 Serial ATA cables and connectors

The Serial ATA interface cable consists of four conductors in two differential pairs, plus three ground connec­tions. The cable size may be 30 to 26 AWG with a maximum length of one meter (39.37 inches). See Table 9
for connector pin definitions. Either end of the SATA signal cable can be attached to the drive or host.

For direct backplane connection, the drive connectors are inserted directly into the host receptacle. The drive
and the host receptacle incorporate features that enable the direct connection to be hot pluggable and blind
mateable.

For installations which require cables, you can connect the drive as illustrated in Figure 4.

Signal connector

Power connector

Signal cable

Power cable

Figure 4. Attaching SATA cabling

Each cable is keyed to ensure correct orientation. Barracuda ES Serial ATA drives support latching SATA con­nectors.

28 Barracuda ES Serial ATA Product Manual, Rev. B

3.4 Drive mounting

You can mount the drive in any orientation using four screws in the side-mounting ho les or four screws in the
bottom-mounting holes. See Figure
tions when mounting the drive:

• Allow a minimum clearance of 0.030 inches (0.76 mm) around the entire perimeter of the drive for cooling.

• Use only 6-32 UNC mounting screws.

• The screws should be inserted no more than 0.150 inch (3.81 mm) into the bottom or side mounting holes.

• Do not overtighten the mounting screws (maximum torque: 6 inch-lb).

5.787 (146.9898) max.

1.122

+ .020

(28.499

+ .508)

[1]

1.638

(41.605)

[1]

4.000

(101.6)

5 for drive mounting dimensions. Follow these important mounting precau-

Recommended

[1]

[1]

4.000

(101.60)

case temperature
measurement location

.250 + .015

(6.35 + .381)

(3x both sides)

.138

(3.505)

.814

2.00

(50.80)

(20.676)

CLof conn. Datum B

CLof drive

[1]

2 x 3.750

(2 x 95.25)

1.028 max

(26.111 max)

2 x 1.625

(2 x 41.28)

2 x 1.750

(2 x 44.45)

[1]

Notes:

Dimensions are shown in inches (mm).
[1] Dimensions per SFF-8301 specification

[1]

[1]

4.000

(101.6)

[1]

Recommended
case temperature
measurement location

Figure 5. Mounting dimensions—top, side and end v ie w

Barracuda ES Serial ATA Product Manual, Rev. B 29

30 Barracuda ES Serial ATA Product Manual, Rev. B

4.0 Serial ATA (SATA) interface

These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA
programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6.

For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT
Attachment” specification.

4.1 Hot-Plug compatibility

Barracuda ES Serial ATA drives incorporate connectors which enable you to hot plug these drives in accor­dance with the Serial ATA II: Extension to Serial ATA 1.0a specification. This specification can be downloaded
from www.serialata.org.

Barracuda ES Serial ATA Product Manual, Rev. B 31

4.2 Serial ATA device plug connector pin definitions

Table 9 summarizes the signals on the Serial ATA interface and power connectors.

Table 9: Serial ATA connector pin definitions

Segment Pin Function Definition

S1 Ground 2nd mate
S2 A+ Differential signal pair A from Phy
S3 A­S4 Ground 2nd mate
S5 B- Differential signal pair B from Phy
S6 B+

Signal

S7 Ground 2nd mate

Key and spacing separate signal and power segments

P1 V
P2 V
P3 V

33

33

33

3.3V power

3.3V power

3.3V power, pre-charge, 2nd mate
P4 Ground 1st mate
P5 Ground 2nd mate
P6 Ground 2nd mate

Power

P7 V
P8 V
P9 V

5

5

5

5V power, pre-charge, 2nd mate
5V power

5V power
P10 Ground 2nd mate
P11 Ground or LED signal If grounded , drive does not use deferred spin
P12 Ground 1st mate.
P13 V
P14 V
P15 V

12

12

12

12V power, pre-charge, 2nd mate

12V power

12V power

Notes:

1. All pins are in a single row, with a 1.27 mm (0.050”) pitch.

2. The comments on the mating sequence apply to the case of backplane blindmate connector only. In this
case, the mating sequences are:

• the ground pins P4 and P12.

• the pre-charge power pins and the other ground pins.

• the signal pins and the rest of the power pins.

3. There are three power pins for each voltage. One pin from each voltage is used for pre-charge when
installed in a blind-mate backplane configuration.

4. All used voltage pins (Vx) must be terminated.

32 Barracuda ES Serial ATA Product Manual, Rev. B

4.3 Supported ATA commands

The following table lists Serial ATA standard commands that the drive supports. For a detailed description of
the ATA commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification.
“S.M.A.R.T. commands” on page 40.for deta ils and subcommands used in the S.M.A.R.T. implementation.

Table 10: Supported ATA commands

Command name Command code (in hex)

See

Check Power Mode 98H or E5
Device Configuration Freeze Lock B1H / C1
Device Configuration Identify B1H / C2
Device Configuration Restore B1H / C0
Device Configuration Set B1H / C3
Device Reset 08
Download Microcode 92
Execute Device Diagnostics 90
Flush Cache E7
Flush Cache Extended EA
Format Track 50
Identify Device EC

H
H
H

H

H

H

H

Idle 97H or E3
Idle Immediate 95H or E1
Initialize Device Parameters 91
Read Buffer E4
Read DMA C8
Read DMA Extended 25
Read DMA Without Retries C9
Read Log Ext 2F
Read Multiple C4
Read Multiple Extended 29
Read Native Max Address F8
Read Native Max Address Extended 27
Read Sectors 20
Read Sectors Extended 24
Read Sectors Without Retries 21
Read Verify Sectors 40
Read Verify Sectors Extended 42
Read Verify Sectors Without Retries 41
Recalibrate 10
Security Disable Password F6
Security Erase Prepare F3

H

H
H

H

H

H

H
H
H
H
H
H
H
H
H
H
H
H
H

H
H
H
H
H

H

H

Barracuda ES Serial ATA Product Manual, Rev. B 33

Command name Command code (in hex)

Security Erase Unit F4
Security Freeze F5
Security Set Password F1
Security Unlock F2
Seek 70
Set Features EF
Set Max Address F9

H
H
H
H
H

H

H

Note: Individual Set Max Address
commands are identified by the value
placed in the Set Max Features regis­ter as defined to the right.

Set Max Address Extended 37
Set Multiple Mode C6

H

H

Sleep 99H or E6
S.M.A.R.T. Disable Operations B0H / D9
S.M.A.R.T. Enable/Disable Autosave B0H / D2
S.M.A.R.T. Enable Operations B0H / D8
S.M.A.R.T. Execute Offline B0H / D4
S.M.A.R.T. Read Attribute Thresholds B0H / D1
S.M.A.R.T. Read Data B0H / D0
S.M.A.R.T. Read Log Sector B0H / D5
S.M.A.R.T. Return Status B0H / DA
S.M.A.R.T. Save Attribute Valu e s B0H / D3
S.M.A.R.T. Write Log Sector B0H / D6
Standby 96H or E2
Standby Immediate 94H or E0
Write Buffer E8
Write DMA CA
Write DMA Extended 35
Write DMA FUA Extended CD
Write DMA Without Retries CB
Write Log Extended 3F
Write Multiple C5
Write Multiple Extended 39
Write Multiple FUA Extended CE
Write Sectors 30
Write Sectors Without Retries 31
Write Sectors Extended 34

H

H

H

H
H

H

H

H

H
H
H
H

Address:

Password:

Unlock:

Freeze Lock:

H
H
H
H
H
H
H
H
H
H
H

H

H

Lock:

00
01
02
03
04

H
H
H
H
H

34 Barracuda ES Serial ATA Product Manual, Rev. B

4.3.1 Identify Devic e comma n d

The Identify Device command (command code ECH) transfers information about the drive to the host following
power up. The data is organized as a sing le 512-byt e bloc k of data, whos e contents are sh own in

Table 10 on
page 33. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or
vary with the state of the drive. See Section 2.0 on page 3 for default parameter settings.

The following commands contain drive-specific features that may not be included in the Serial ATA specifica­tion.

Word Description Value

0

Configuration information:

• Bit 15: 0 = ATA; 1 = ATAPI

• Bit 7: removable media

0C5A

• Bit 6: removable controller

• Bit 0: reserved
1 Number of logical cylinders 16,383
2 ATA-reserved 0000
3 Number of logical heads 16
4 Retired 0000
5 Retired 0000
6 Number of logical sectors per logical track: 63 003F
7–9 Retired 0000
10–19 Serial number: (20 ASCII characters, 0000H = none) ASCII
20 Retired 0000
21 Retired 0400
22 Obsolete 0000
23–26 Firmware revision (8 ASCII character string, padded with blanks to end

x.xx

of string)

27–46 Drive model number: (40 ASCII characters, padded with blanks to end

of string)

H

H

H
H
H
H

H
H
H

47 (Bits 7–0) Maximum sectors per interrupt on Read multiple and Write

multiple (16)
48 Reserved 0000
49 Standard Standby timer, IORDY supported and may be disabled 2F00
50 ATA-reserved 0000
51 PIO data-transfer cycle timing mode 0200
52 Retired 0200
53 Words 54–58, 64–70 and 88 are valid 0007
54 Number of current logical cylinders xxxx
55 Number of current logical heads xxxx
56 Number of current logical sectors per logical track xxxx
57–58 Current capacity in sectors xxxx
59 Number of sectors transferred during a Read Multiple or Write Multiple

command

8010

xxxx

H

H
H
H
H
H

H
H
H
H
H
H

Barracuda ES Serial ATA Product Manual, Rev. B 35

Word Description Value

60–61 Total number of user-addressable LBA sectors available

0FFFFFFFh*
(see Section 2.2 for related information)
*Note: The maximum value allowed in this field is: 0FFFFFFFh

(268,435,455 sectors, 137 Gbytes). Drives with capacities over 137
Gbytes will have 0FFFFFFFh in this field and the actual number of
user-addressable LBAs specified in words 100-103. This is required
for drives that support the 48-bit addressing feature.

62 Retired 0000
63 Multiword DMA active and modes supported (see note following this

xx07
table)

64 Advanced PIO modes supported (modes 3 and 4 supported) 0003
65 Minimum multiword DMA transfer cycle time per word (120 nsec) 0078
66 Recommended multiword DMA transfer cycle time per word (120

0078
nsec)

67 Minimum PIO cycle time without IORDY flow control (240 nsec) 00F0
68 Minimum PIO cycle time with IORDY flow control (120 nsec) 0078
69–74 ATA-reserved 0000
75 Queue depth 0000
76 Serial ATA capabilities xxxx
77 Reserved for future Serial ATA definition xxxx
78 Serial ATA features supported xxxx
79 Serial ATA features enabled xxxx
80 Major version number 003E
81 Minor version number 0000
82 Command sets supported 364B
83 Command sets supported 7C03
84 Command sets support extension 4003
85 Command sets enabled 30xx
86 Command sets enabled 0001
87 Command sets enable extension 4000
88 Ultra DMA support and current mode (see note following this table) xx3F
89 Security erase time 0000
90 Enhanced security erase time 0000
92 Master password revision code FFFE
93 Hardware reset value (see description following this table) xxxx
95–99 ATA-reserved 0000
100–

103

Total number of user-addressable LBA sectors available (see Section

2.2 for related information). These words are required for drives that
support the 48-bit addressing feature. Maximum value:
0000FFFFFFFFFFFFh.

750 GB models = 1,465,149,168

500 GB models = 976,773,168

400 GB models = 781,422,768

320 GB models = 625,142,448

250 GB models = 488,397,168

H

H

H
H
H

H
H
H

H
H
H
H
H

H

H

H
H

H

H

H

H

H

H

H

H

H

H

104–
127

ATA-reserved 0000

H

36 Barracuda ES Serial ATA Product Manual, Rev. B

Word Description Value

128 Security status 0001
129–

Seagate-reserved xxxx

159
160–

ATA-reserved 0000

254
255 Integrity word xxA5

H

H

H

H

Note. Advanced Power Management (APM) is supported. APM is disabled by defau lt but you may enable APM

using the SATA set features commands. Use the time settings stated below:
Enable Idle 1 Options:
Word 0x53 set to 0x7D09

Word 0xE3 set to 0x1388 // 5 seconds
Word 0xE4 set to 0x2710 // 10 seconds
Word 0xE5 set to 0x0015 // 21 seconds
Word 0xE6 set to 0x0025 // 37 seconds
Word 0x5B set to 0xFEFE

Barracuda ES Serial ATA Product Manual, Rev. B 37

Note. See the bit descriptions below for words 63, 88, and 93 of the Identify Drive data.

Description (if bit is set to 1)

Bit Word 63

0 Multiword DMA mode 0 is supported.
1 Multiword DMA mode 1 is supported.
2 Multiword DMA mode 2 is supported.
8 Multiword DMA mode 0 is currently active.
9 Multiword DMA mode 1 is currently active.
10 Multiword DMA mode 2 is currently active.

Bit Word 88

0 Ultra DMA mode 0 is supported.
1 Ultra DMA mode 1 is supported.
2 Ultra DMA mode 2 is supported.
3 Ultra DMA mode 3 is supported.
4 Ultra DMA mode 4 is supported.
5 Ultra DMA mode 5 is supported.
6 Ultra DMA mode 6 is supported.
8 Ultra DMA mode 0 is currently active.
9 Ultra DMA mode 1 is currently active.
10 Ultra DMA mode 2 is currently active.
11 Ultra DMA mode 3 is currently active.
12 Ultra DMA mode 4 is currently active.
13 Ultra DMA mode 5 is currently active.
14 Ultra DMA mode 6 is currently active.

38 Barracuda ES Serial ATA Product Manual, Rev. B

4.3.2 Set Features command

This command controls the implementation of various featur es that the drive su pports. When the drive receives
this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an inter
rupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.
Power-on default has the read look-ahead and write caching features enabled. The acceptable values for the
Features register are defined as follows:

Table 11: Set Features command values

-

02
03

10
55
82
90
AA
F1

Enable write cache (default).

H

Set transfer mode (based on value in Sector Count register).

H

Sector Count register values:
00HSet PIO mode to default (PIO mode 2).
01HSet PIO mode to default and disable IORDY (PIO mode 2).
08HPIO mode 0
09HPIO mode 1
0AHPIO mode 2
0BHPIO mode 3
0CHPIO mode 4 (default)
20HMultiword DMA mode 0
21HMultiword DMA mode 1
22HMultiword DMA mode 2
40HUltra DMA mode 0
41HUltra DMA mode 1
42HUltra DMA mode 2
43HUltra DMA mode 3
44HUltra DMA mode 4
45HUltra DMA mode 5
46HUltra DMA mode 6
Enable use of SATA features

H

Disable read look-ahead (read cache) feature.

H

Disable write cache

H

Disable use of SATA features

H

Enable read look-ahead (read cache) feature (default).

H

Report full capacity available

H

Note. At power-on, or after a hardware or software reset, the default values of the features are as indi-

cated above.

Barracuda ES Serial ATA Product Manual, Rev. B 39

4.3.3 S.M.A.R.T. commands

S.M.A.R.T. provides near-term failure prediction for disc drives. When S.M.A.R.T. is enabled, the drive moni­tors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines
that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable.
S.M.A.R.T. predictability is limited to the attributes the drive can monitor. For more information on S.M.A.R.T.
commands and implementation, see the Draft ATA-5 Standard.

SeaTools diagnostic software activates a built-in drive self-test (DST S.M.A.R.T. command for D4H) that elimi­nates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at:
http://seatools.seagate.com.

This drive is shipped with S.M.A.R.T . featur es disabled . You must have a recent BIOS or sof tware pa ckage that
supports S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the
drive uses.

Table 12: S.M.A.R.T. commands

Code in features register S.M.A.R.T. command

D0
D2
D3
D4
D5
D6
D8
D9
DA

H
H
H
H
H
H
H
H

H

S.M.A.R.T. Read Data
S.M.A.R.T. Enable/Disable Attribute Autosave
S.M.A.R.T. Save Attribute Values
S.M.A.R.T. Execute Off-line Immediate (runs DST)
S.M.A.R.T. Read Log Sector
S.M.A.R.T. Write Log Sector
S.M.A.R.T. Enable Operations
S.M.A.R.T. Disable Operations
S.M.A.R.T. Return Status

Note. If an appropriate code is not written to the Features Register, the command is aborted and 0x 04

(abort) is written to the Error register.

40 Barracuda ES Serial ATA Product Manual, Rev. B

5.0 Seagate Technology support services

Online services

Internet

www.seagate.com for informat ion about Seagate products and services. Worldwide support is available 24

hours daily by e-mail for your questions.

Presales Support: www.seagate.com/support/email/email_presales.html or [e-mail]
Technical Support: www.seagate.com/support/email/email_disc_support.html or [e-mail]

mySeagate

my.seagate.com is the industry’s first Web portal designed specifically for OEMs and distributors. It provides
self-service access to critical applicat ions, personalized conten t and the tools that allow our partners to man
age their Seagate account functions. Submit pricing requests, orders and returns through a single, password­protected Web interface—anytime, anywhere in the world.

spp.seagate.com

spp.seagate.com supports Seagate resellers with product information, program benefits and sales tools. You
may register for customized communications that are not availab le on the web. These commu nications cont ain
product launch, EOL, pricing, promotions and other channel-related information. To learn more about the ben
efits or to register, go to spp.seagate.com, any time, from anywhere in th e wor ld.

Seagate Service Centers

-

-

Presales Support

Our Presales Support staff can help you determine which Seagate products are best suited for your specific
application or computer system, as well as product availability and compatibility.

Technical Support

Seagate technical support is available to assist you online at support.seagate.com or through one of our c all
centers. Have your system configuration information and your “ST” model number available.

SeaTDD™ ([phone]) is a telecommunications device for the deaf (TDD). You can send questions or
comments 24 hours daily and exchange messages with a technical support specialist during normal business
hours for the call center in your region.

Barracuda ES Serial ATA Product Manual, Rev. B 41

Customer Service Operations

Warranty Service

Seagate offers worldwide customer support for Seagate drives. Seagate distributors, OEMs and other direct
customers should contact their Seagate Customer Service Operations (CSO) representative for warranty­related issues. Resellers or end users of drive products should contact their place of purchase or one of the
Seagate CSO warranty centers for assistance. Have your drive’s “ST” model number and serial number avail
able.

Data Recovery Services

Seagate offers data recovery services for all formats and all brands of storage media. Our Data Recovery Ser­vices labs are currently located in North America. To speak with a case management representative, call
1-800-475-0143. Additional information, including an online request form and data loss prevention resources,
is available at

Authorized Service Centers

In some locations outside the US, you can contact an Authorized Service Center for service.

www.datarecovery.seagate.com.

-

42 Barracuda ES Serial ATA Product Manual, Rev. B

USA/Canada/Latin America support services

Seagate Service Centers

Presales Support

Call center Toll-free Direct dial FAX

Americas 1-877-271-3285

1

[phone]

1

[phone]

Technical Support

Call center Toll-free Direct dial FAX

Americas 1-800-SEAGATE

2

[phone]

2

[phone]

Customer Service Operations

Warranty Service

Call center Toll-free Direct dial FAX / E-mail

USA, Canada, Mexico and 1-800-468-3472
Latin America

Brazil
Jabil Industrial Do Brasil — [phone] [phone]
LTDA

4

Data Recovery Services

Call center Toll-free Direct dial FAX

USA, Canada, 1-800-475-01435 [phone]-475-0158
and Mexico [phone]

3

— [phone]

[e-mail]

1

Hours of operation are 8:00 A.M. to 7:00 P.M., Monday through Friday (Central time).

2

Hours of operation are 8:00 A.M. to 8:00 P.M., Monday through Friday (Central time).

3

Hours of operation are 8:00 A.M. to 5:00 P.M., Monday through Friday (Central time).

Caution: 4Authorized Service Center

5

Hours of operation are 8:00 A.M. to 8:00 P.M., Monday through Friday, and 9:00 A.M. to 5:00 P.M., Saturday (Eastern time).

Barracuda ES Serial ATA Product Manual, Rev. B 43

European support services

For presales and technical support in Europe, dial the Seagate Service Center toll-free number for your spe­cific location. If your location is not listed here, dial our presales and technical support call center at +1-405­324-4714 from 8:00
The presales and technical support call center is located in Oklahoma City, USA.

For European warranty service, dial the toll-free number for your specific location. If your location is not listed
here, dial our European CSO warranty center at [phone] from 8:30
time) Monday through Friday. The CSO warranty center is located in Amsterdam, The Netherlands.

A.M. to 1 1:45 A.M. an d 1:00 P.M. to 5:00 P.M. (Centr al Eu rope tim e) Monday thr ou gh Friday.

A.M. to 5:00 P.M. (Central Europe

Seagate Service Centers

Toll-free support numbers

Call center Presales and Technical Support Warranty Service

Austria — 00 800-47324289
Belgium 00 800-47324283 (00 800-4SEAGATE) 00 800-47324289
Denmark 00 800-47324283 00 800-47324289
France 00 800-47324283 00 800-47324289
Germany 00 800-47324283 00 800-47324289
Ireland 00 800-47324283 00 800-47324289
Italy 00 800-47324283 00 800-47324289
Netherlands 00 800-47324283 00 800-47324289
Norway 00 800-47324283 00 800-47324289
Poland 00 80 0- 311 12 38 00 800-311 12 38
Spain 00 800-47324283 00 800-47324289
Sweden 00 800-47324283 00 800-47324289
Switzerland 00 800-47324283 00 800-47324289
Turkey 00 800-31 92 91 40 00 800-31 92 91 40
United Kingdom 00 800-47324283 00 800-47324289

FAX services—All Europe (toll call)

Technical Support [phone]
Warranty Service [phone]

Africa/Middle East support services

For presales and technical support in Africa and the Middle East, dial our presales and technical support call
center at [phone] from 8:00
day through Friday. The presales and technical support call center is located in Oklahoma City, USA.

For warranty service in Africa and the Middle East, dial our European CSO warranty center at +31-20-316­7222 from 8:30

3513. The CSO warranty center is located in Amsterdam, The Netherlands.

A.M. to 5:00 P.M. (Central Europe time) Monday through Friday, or send a FAX to +31-20-653-

A.M. to 11:45 A.M. and 1:00 P.M. to 5:00 P.M. (Central Eu rope time ) Mon-

44 Barracuda ES Serial ATA Product Manual, Rev. B

Asia/Pacific support services

For Asia/Pacific presales and technical support, dial the toll-free number for your specific location. The Asia/
Pacific toll-free numbers are available from 6:00

A.M. to 10:45 A.M. and 12:00 P.M. to 6:00 P.M. (Australian East-

ern time) Monday through Friday, except as noted. If your location is not listed here, direct dial one of our tech­nical support locations.

Warranty service is available from 9:00 A.M. to 5:00 P.M., Monday th rough Friday. Warranty service for Australia
is available from 10:00

A.M. to 7:00 P.M., April through October, and from 11:00 A.M. to 8:00 P.M. November

through March (Australian Eastern time) Monday through Friday.

Seagate Service Centers

Call center Toll-free Direct dial FAX

Australia 1800-14-7201 — —
China (Mandarin)
Hong Kong 800-90-0474 — —
Hong Kong (Cantonese)

2, 4

India
Indonesia 001-803-1-003-2165 — —

3, 4

Japan

3, 4

Korea
Malaysia 1-800-80-2335 — —
New Zealand 0800-443988 — —
Singapore 800-1101-150 — [phone]
Taiwan (Mandarin)
Thailand 001-800-11-0032165 — —

1, 4

1, 4

800-810-9668 [phone] —

1, 4

001-800-0830-1730 — —
1-800-180-1104 — —

0034 800 400 554 — —
007 98 8521 7635 — —

00-800-0830-1730 — —

Customer Service Operations

Warranty Service

Call center Toll-free Direct dial FAX

Asia/Pacific — [phone] [phone]
Australia 1800-12-9277 — —

4

India

1

Hours of operation are 8:30 A.M. to 5:30 P.M., Monday through Friday (Australian Western time).

2

Hours of operation are 9:00 A.M. to 6:00 P.M., Monday through Saturday.

3

Hours of operation are 9:30 A.M. to 6:30 P.M., Monday through Friday.

4

Authorized Service Center

— [phone] [phone]

Barracuda ES Serial ATA Product Manual, Rev. B 45

46 Barracuda ES Serial ATA Product Manual, Rev. B

Index

A

ACA 24
acceleration 21
acoustics 22
Active 18
Active mode 18
actuator arm 16
Agency certification 23
altitude 20
Ambient temperature 20
ambient temperature 16
Annualized Failure Rate (AFR) 23
areal density 1, 15
ATA commands 33

Australia/New Zealand Standard AS/NZS3548 1995

24

Australian Communication Authority (ACA) 24
Australian C-Tick 24
Average latency 16
Average seek time 16

B

BPI 15
buffer 15

C

cables and connectors 28
cache 15
capacity 14
case temperature 20
CE mark 23
certification 23
Check Power Mode 33
Class B computing device 24
compatibility 23
Conducted noise 18
Conducted RF immunity 22
Configuring the drive 27
connectors 28
Corrosive environment 25
CSA C22.2 (950) 23
cycles 23
Cylinders 14

D

data-transfer rates 1
DC power 16
Default logical geometry 14
density 15
Device Configuration Freeze Lock 33

Device Configuration Identify 33
Device Configuration Restore 33
Device Configuration Set 33
Device Reset 33
dimensions 29
disc surface 16
dissipation 17
Download Microcode 33

E

Electrical fast transient 22
Electromagnetic compatibility 23
Electromagnetic Compatibility (EMC) 24
Electromagnetic Compatibility control Regulation 24

Electromagnetic Compatibility Directive (89/336/EEC)

23

Electromagnetic immunity 22
Electrostatic discharge 22
electrostatic discharge (ESD) 27
EN 55022, Class B 23
EN 55024 23
EN 60950 23
Environmental specifications 20
error-correction algorithms 1
errors 23
ESD 27
EU 23
European Union (EU) requirements 23
Execute Device Diagnostics 33

F

FCC verification 24
features 1
Federal Communications Commission 24
Flush Cache 33
Flush Cache Extended 33
Format Track 33
Formatted capacity 14

G

geometry 14
Gs 21
guaranteed sectors 14

H

Handling precautions 27
heads 14
height 15
humidity 20

I

I/O data-transfer rate 15
Identify Device 33

Barracuda ES Serial ATA Product Manual, Rev. B 47

Identify Device command 35
Idle 18, 33
Idle Immediate 33
Idle mode 17, 19
IEC950 23
Information Technology Equipment (ITE) 23
Initialize Device Parameters 33
Input noise ripple 18
input voltage 16
interface 15, 31
internal data-transfer rate OD 15
is 16
ISO document 7779 22
ITE 23

Power consumption 16
power consumption 16
power dissipation 17
Power modes 18
Power specifications 16
Power-management modes 18
Power-on to Ready 16
precautions 27
printed circuit board 27
programmable power management 18

Q

quick reference 3

K

Korea Ministry of Information and Communication

(MIC)

24

Korean RRL 23

L

latency 16
latency time 16
LBA mode 14
length 15
logical geometry 14

M

maintenance 23
master/slave 2
maximum temperature 20
MIC 24
mounting 29
mounting screws 20
mounting the drive 27

N

noise 18
nominal power 16
Nonoperating shock 20
Nonoperating vibration 21
Nonrecoverable read errors 23

O

operating 17
Operating power 17
Operating shock 20
Operating vibration 21

P

Physical characteristics 15
point-to-point 2, 28

R

Radiated RF immunity 22
Radio and television interference 24
radio frequency (RF) 22
random seeks 16, 17
Read Buffer 33
Read DMA 33
Read DMA Extended 33
Read DMA without Retries 33
read errors 23
Read Log Ext 33
Read Multiple 33
Read Multiple Extended 33
Read Native Max Address 33
Read Native Max Address Extended 33
Read Sectors 33
Read Sectors Extended 33
Read Sectors Without Retries 33
Read Verify Sectors 33
Read Verify Sectors Extended 33
Read Verify Sectors Without Retries 33
read/write actuator arm 16
Read/write heads 14
Read/write power 16
Recalibrate 33
recording density 15
recording method 15
Recording technology 15
relative humidity 20
Reliability 23
RF 22
RMS read/write current 18
RoHS 25
RRL 23

S

S.M.A.R.T. Disable Operations 34
S.M.A.R.T. Enable Operations 34
S.M.A.R.T. Enable/Disable Autosave 34
S.M.A.R.T. Execute Offline 34

48 Barracuda ES Serial ATA Product Manual, Rev. B

S.M.A.R.T. implementation 33
S.M.A.R.T. Read Attribute Thresholds 34
S.M.A.R.T. Read Data 34
S.M.A.R.T. Read Log Sector 34
S.M.A.R.T. Return Status 34
S.M.A.R.T. Save Attribute Values 34
S.M.A.R.T. Write Log sector 34
Safety certification 23
SATA 31
screws 20
sectors 14
Sectors per track 14
Security Disable Password 33
Security Erase Prepare 33
Security Erase Unit 34
Security Freeze 34
Security Set Password 34
Security Unlock 34
Seek 34
seek mode 16
Seek mode power 16
Seek time 16
Seeking 17
Serial ATA (SATA) interface 31
serial ATA ports 2
Servo electronics 16
servo electronics 17
Set Features 34
Set Max Address 34
Set Max Address Extended 34
Set Multiple Mode 34
Shock 20
single-track seeks 16
Sleep 17, 18, 34
Sleep mode 19
sound 22
Specification summary table 3
spindle speed 15
Spinup 17
Spinup power 16
Standby 17, 18, 34
Standby Immediate 34
Standby mode 17, 19
standby timer 19
Standby to Ready 16
Start/stop times 16
start-stop cycles 23
static-discharge 27
support services 41
Surge immunity 22

timer 19
timers 19
track density 15
Track-to-track 16
Track-to-track seek time 16
TUV North America 23

U

UL 1950 23

V

Vibration 21
voltage 16
Voltage dips, interrupts 22
Voltage tolerance 18

W

weight 15
wet bulb temperature 20
width 15
Write Buffer 34
Write DMA 34
Write DMA Extended 34
Write DMA FUA Extended 34
Write DMA Without Retries 34
Write Log Extended 34
Write Multiple 34
Write Multiple Extended 34
Write Multiple FUA Extended 34
Write Sectors 34
Write Sectors Extended 34
Write Sectors Without Retries 34

T

technical support services 41
temperature 16, 20
temperature gradient 20

Barracuda ES Serial ATA Product Manual, Rev. B 49

50 Barracuda ES Serial ATA Product Manual, Rev. B

Seagate Technology LLC

920 Disc Drive, Scotts Valley, California 95066-4544, USA

Publication Number: 100424667, Rev. B, Printed in U.S.A.
