ModiconTM3 Bus Coupler

EIO0000003635 08/2020

Modicon TM3 Bus Coupler

Hardware Guide

08/2020

EIO0000003635.03

www.schneider-electric.com

The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein. This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications. It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof. Neither Schneider Electric nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.

You agree not to reproduce, other than for your own personal, noncommercial use, all or part of this document on any medium whatsoever without permission of Schneider Electric, given in writing. You also agree not to establish any hypertext links to this document or its content. Schneider Electric does not grant any right or license for the personal and noncommercial use of the document or its content, except for a non-exclusive license to consult it on an "as is" basis, at your own risk. All other rights are reserved.

All pertinent state, regional, and local safety regulations must be observed when installing and using this product. For reasons of safety and to help ensure compliance with documented system data, only the manufacturer should perform repairs to components.

When devices are used for applications with technical safety requirements, the relevant instructions must be followed.

Failure to use Schneider Electric software or approved software with our hardware products may result in injury, harm, or improper operating results.

Failure to observe this information can result in injury or equipment damage.

2 EIO0000003635 08/2020

Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About the Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 1 General Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

TM3 Bus Couplers General Description . . . . . . . . . . . . . . . . . . . . . . .

Maximum Hardware Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . .

TM3 General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TM2 General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 2 TM3 Bus Coupler Installation . . . . . . . . . . . . . . . . . . . . . 33

2.1 TM3 Bus Coupler General Rules for Implementing. . . . . . . . . . . . . . .

Environmental Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Certifications and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 TM3 Bus Coupler Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation and Maintenance Requirements . . . . . . . . . . . . . . . . . . . .

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top Hat Section Rail (DIN rail) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Assembling a Module to a Modicon TM3 Bus Coupler . . . . . . . . . . . .

Disassembling a Module from a Modicon TM3 Bus Coupler. . . . . . . .

Direct Mounting on a Panel Surface . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 TM3 Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring Best Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Power Supply Characteristics and Wiring . . . . . . . . . . . . . . . . . . .

Grounding the TM3 System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 3 TM3 Ethernet Bus Coupler . . . . . . . . . . . . . . . . . . . . . . . 65

TM3 Ethernet Bus Coupler Presentation . . . . . . . . . . . . . . . . . . . . . . .

TM3 Ethernet Bus Coupler Characteristics . . . . . . . . . . . . . . . . . . . . .

Rotary Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Ethernet Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting the Modicon TM3 Bus Coupler to a PC . . . . . . . . . . . . . .

Chapter 4 TM3 Modbus Serial Line Bus Coupler . . . . . . . . . . . . . . 77

TM3 Modbus Serial Line Bus Coupler Presentation . . . . . . . . . . . . . .

TM3 Modbus Serial Line Bus Coupler Characteristics . . . . . . . . . . . .

Rotary Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Serial Line Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting the TM3 Modbus Serial Line Bus Coupler to a PC. . . . . .

14 15 18 27 30

34 35 38 39 40 43 46 50 52 53 54 55 60 63

66 68 69 73 75

78 80 81 85 87

EIO0000003635 08/2020 3

Chapter 5 TM3 CANopen Bus Coupler. . . . . . . . . . . . . . . . . . . . . . . 89

TM3 CANopen Bus Coupler Presentation . . . . . . . . . . . . . . . . . . . . . .

TM3 CANopen Bus Coupler Characteristics . . . . . . . . . . . . . . . . . . . .

Rotary Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CANopen Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting the TM3 CANopen Bus Coupler to a PC . . . . . . . . . . . . .

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

90 93 94 98

100 103 107

4 EIO0000003635 08/2020

Safety Information

Important Information

NOTICE

Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, service, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

EIO0000003635 08/2020 5

PLEASE NOTE

Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by Schneider Electric for any consequences arising out of the use of this material.

A qualified person is one who has skills and knowledge related to the construction and operation of electrical equipment and its installation, and has received safety training to recognize and avoid the hazards involved.

QUALIFICATION OF PERSONNEL

Only appropriately trained persons who are familiar with and understand the contents of this manual and all other pertinent product documentation are authorized to work on and with this product.

The qualified person must be able to detect possible hazards that may arise from parameterization, modifying parameter values and generally from mechanical, electrical, or electronic equipment. The qualified person must be familiar with the standards, provisions, and regulations for the prevention of industrial accidents, which they must observe when designing and implementing the system.

INTENDED USE

The products described or affected by this document, together with software, accessories, and options, are bus couplers, intended for industrial use according to the instructions, directions, examples, and safety information contained in the present document and other supporting documentation.

The product may only be used in compliance with all applicable safety regulations and directives, the specified requirements, and the technical data.

Prior to using the product, you must perform a risk assessment in view of the planned application. Based on the results, the appropriate safety-related measures must be implemented.

Since the product is used as a component in an overall machine or process, you must ensure the safety of persons by means of the design of this overall system.

Operate the product only with the specified cables and accessories. Use only genuine accessories and spare parts.

Any use other than the use explicitly permitted is prohibited and can result in unanticipated hazards.

6 EIO0000003635 08/2020

About the Book

At a Glance

Document Scope

This guide describes the hardware implementation of Modicon TM3 Bus Couplers. It provides the description, characteristics, wiring diagrams, and installation details for Modicon TM3 Bus Couplers.

Validity Note

This document has been updated for the release of EcoStruxureTM Machine Expert V1.2.4.

The technical characteristics of the devices described in the present document also appear online. To access the information online, go to the Schneider Electric home page

https://www.se.com/ww/en/download/

The characteristics that are described in the present document should be the same as those characteristics that appear online. In line with our policy of constant improvement, we may revise content over time to improve clarity and accuracy. If you see a difference between the document and online information, use the online information as your reference.

For product compliance and environmental information (RoHS, REACH, PEP, EOLI, etc.), go to

www.schneider-electric.com/green-premium

General Overview

EIO0000003635 08/2020

General Overview

Chapter 1

General Overview

What Is in This Chapter?

This chapter contains the following topics:

TM3 Bus Couplers General Description 14

Maximum Hardware Configuration 15

TM3 General Description 18

TM2 General Description 27

Accessories 30

Topic Page

EIO0000003635 08/2020 13

General Overview

TM3 Bus Couplers General Description

Introduction

The Modicon TM3 bus couplers are devices designed to manage EtherNet/IP, Modbus TCP, Modbus serial line or CANopen communications, depending on the reference, in association with TM2/TM3 I/O expansion modules in a distributed architecture.

Software configuration is accomplished with:

 The EcoStruxure Machine Expert software (refer to the Modicon TM3 Bus Coupler -

Programming Guide).

 The EcoStruxure Machine Expert - Basic software (refer to the Modicon TM3 Bus Coupler

(EcoStruxure Machine Expert - Basic) - Programming Guide).

 The Configuration software tool (see

Modicon TM3 Bus Couplers

The following table shows the TM3 bus couplers, with ports and terminal types:

Reference Port Communication type Terminal type

TM3BCEIP

(see page 65)

TM3BCSL

(see page 77)

TM3BCCO

(see page 89)

2 isolated switched Ethernet ports

1 USB port USB 2.0 USB mini-B

2 isolated RS-485 ports (daisy-chained)

1 USB port USB 2.0 USB mini-B

2 isolated CANopen ports (daisy-chained)

1 USB port USB 2.0 USB mini-B

Modicon TM3 Bus Coupler IO Configurator

EtherNet/IP Modbus TCP

Serial Line Modbus

CANopen RJ45

RJ45

EIO0000003635 08/2020

Maximum Hardware Configuration

Distributed Configuration Principle

The following illustration defines an example of a distributed configuration using a TM3BCEIP with a controller:

General Overview

1 Communication expansion module 2 Controller 3 TM3 bus coupler 4 TM3 expansion modules 5 TM3 transmitter and receiver

EIO0000003635 08/2020 15

General Overview

TM3 Bus Coupler Distributed Configuration Architecture

Optimized distributed configuration and flexibility are provided by the association of:

 Controller  TM3 bus coupler  TM3 expansion modules  TM2 expansion modules

The following illustration is an example of an association:

NOTE: Do not mount a TM2 module before any TM3 module as indicated in the following illustration:

EIO0000003635 08/2020

Maximum Number of Modules

Each TM3 bus coupler supports up to:

Module type Maximum number of modules

TM2 7

TM2 - TM3 7

TM3 7 without transmitter and receiver.

NOTE: EcoStruxure Machine Expert and EcoStruxure Machine Expert - Basic software validate the configuration to the extent possible. However, although EcoStruxure Machine Expert may allow certain configurations, the maximum configuration populated by high energy consuming modules, coupled with the maximum distance allowable between the TM3 transmitter and receiver modules, may present bus communication issues in some environments. If this occurs, you will need to analyze the energy consumption of the modules chosen for your configuration, minimize the cable distance required by your application, and otherwise consider optimizing your choices.

General Overview

14 with transmitter and receiver.

EIO0000003635 08/2020 17

General Overview

TM3 General Description

Introduction

The range of TM3 expansion modules includes:

 Digital modules, classified as follows:

 Input modules  Output modules  Mixed input/output modules

 Analog modules, classified as follows:

 Input modules  Output modules  Mixed input/output modules

 Expert modules  Transmitter and receiver modules  Safety modules

TM3 Digital Input Modules

The following table shows the TM3 digital input expansion modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Digital I/O Modules Configuration section.

(see page 18)

(see page 22)

(see page 25)

(see page 19)

(see page 21)

(see page 23)

(see page 24)

(see page 25)

Reference Channels Channel Type Voltage

Current

TM3DI8A 8 Regular inputs 120 Vac

7.5 mA

TM3DI8 8 Regular inputs 24 Vdc

7mA

TM3DI8G 8 Regular inputs 24 Vdc

7mA

TM3DI16 16 Regular inputs 24 Vdc

7mA

TM3DI16G 16 Regular inputs 24 Vdc

7mA

TM3DI16K 16 Regular inputs 24 Vdc

5mA

TM3DI32K 32 Regular inputs 24 Vdc

5mA

Terminal Type / Pitch

Removable screw terminal block /

5.08 mm

Removable screw terminal block /

5.08 mm

Removable spring terminal block /

5.08 mm

Removable screw terminal block /

3.81 mm

Removable spring terminal block /

3.81 mm

HE10 (MIL 20) connector

EIO0000003635 08/2020

TM3 Digital Output Modules

The following table shows the TM3 digital output modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Digital I/O Modules Configuration section.

General Overview

Reference Channels Channel Type Voltage

Current

TM3DQ8R 8 Relay outputs 24 Vdc / 240 Vac

7 A maximum per common line / 2 A maximum per output

TM3DQ8RG 8 Relay outputs 24 Vdc / 240 Vac

TM3DQ8T 8 Regular transistor

outputs (source)

TM3DQ8TG 8 Regular transistor

outputs (source)

TM3DQ8U 8 Regular transistor

outputs (sink)

TM3DQ8UG 8 Regular transistor

outputs (sink)

TM3DQ16R 16 Relay outputs 24 Vdc / 240 Vac

TM3DQ16RG 16 Relay outputs 24 Vdc / 240 Vac

TM3DQ16T 16 Regular transistor

outputs (source)

7 A maximum per common line / 2 A maximum per output

24 Vdc 4 A maximum per common line/0.5 A maximum per output

8 A maximum per common line / 2 A maximum per output

24 Vdc 4 A maximum per common line / 0.5 A maximum per output

Terminal Type / Pitch

Removable screw terminal block / 5.08 mm

Removable spring terminal block / 5.08 mm

Removable screw terminal block / 5.08 mm

Removable spring terminal block / 5.08 mm

Removable screw terminal block / 5.08 mm

Removable spring terminal block / 5.08 mm

Removable screw terminal block / 3.81 mm

Removable spring terminal block / 3.81 mm

Removable screw terminal block / 3.81 mm

EIO0000003635 08/2020 19

General Overview

Reference Channels Channel Type Voltage

Current

TM3DQ16TG 16 Regular transistor

outputs (source)

24 Vdc 4 A maximum per common line / 0.5 A maximum per output

TM3DQ16U 16 Regular transistor

outputs (sink)

24 Vdc 2 A maximum per common line / 0.3 A maximum per output

TM3DQ16UG 16 Regular transistor

outputs (sink)

24 Vdc 2 A maximum per common line / 0.3 A maximum per output

TM3DQ16TK 16 Regular transistor

outputs (source)

24 Vdc 2 A maximum per common line / 0.1 A maximum per output

TM3DQ16UK 16 Regular transistor

outputs (sink)

24 Vdc 2 A maximum per common line / 0.1 A maximum per output

TM3DQ32TK 32 Regular transistor

outputs (source)

24 Vdc 2 A maximum per common line / 0.1 A maximum per output

TM3DQ32UK 32 Regular transistor

outputs (sink)

24 Vdc 2 A maximum per common line / 0.1 A maximum per output

Terminal Type / Pitch

Removable spring terminal block / 3.81 mm

Removable screw terminal block / 3.81 mm

Removable spring terminal block / 3.81 mm

HE10 (MIL 20) connector

EIO0000003635 08/2020

TM3 Digital Mixed Input/Output Modules

This following table shows the TM3 mixed I/O modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Digital I/O Modules Configuration section.

General Overview

Reference Channels Channel Type Voltage

Current

TM3DM8R 4 Regular inputs 24 Vdc

7mA

4 Relay outputs 24 Vdc / 240 Vac

7 A maximum per common line / 2 A maximum per output

TM3DM8RG 4 Regular inputs 24 Vdc

7mA

4 Relay outputs 24 Vdc / 240 Vac

7 A maximum per common line / 2 A maximum per output

TM3DM24R 16 Regular inputs 24 Vdc

7mA

8 Relay outputs 24 Vdc / 240 Vac

7 A maximum per common line / 2 A maximum per output

TM3DM24RG 16 Regular inputs 24 Vdc

7mA

8 Relay outputs 24 Vdc / 240 Vac

7 A maximum per common line / 2 A maximum per output

Terminal Type / Pitch

Removable screw terminal block / 5.08 mm

Removable spring terminal block /5.08 mm

Removable screw terminal block / 3.81 mm

Removable spring terminal block / 3.81 mm

EIO0000003635 08/2020 21

General Overview

TM3 Analog Input Modules

The following table shows the TM3 analog input expansion modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Analog Input Modules Configuration section.

Reference Resolution Channels Channel

Type

TM3AI2H 16 bit, or

15 bit + sign

TM3AI2HG 16 bit, or

15 bit + sign

TM3AI4 12 bit, or

11 bit + sign

TM3AI4G 12 bit, or

11 bit + sign

TM3AI8 12 bit, or

11 bit + sign

TM3AI8G 12 bit, or

11 bit + sign

TM3TI4 16 bit, or

15 bit + sign

2 inputs 0...10 Vdc

4 inputs 0...10 Vdc

8 inputs 0...10 Vdc

4 inputs 0...10 Vdc

Mode Terminal Type / Pitch

Removable screw

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

0...20 mA extended

4...20 mA extended

-10…+10 Vdc

0...20 mA

4...20 mA

0...20 mA extended

4...20 mA extended

-10…+10 Vdc

0...20 mA

4...20 mA Thermocouple PT100/1000 NI100/1000

terminal block /

5.08 mm

Removable spring terminal block /

5.08 mm

Removable screw terminal block /

3.81 mm

Removable spring terminal blocks /

3.81 mm

Removable screw terminal block /

3.81 mm

Removable spring terminal blocks /

3.81 mm

Removable screw terminal block /

3.81 mm

EIO0000003635 08/2020

General Overview

Reference Resolution Channels Channel

Type

TM3TI4G 16 bit, or

15 bit + sign

TM3TI4D 16 bit, or

15 bit + sign

TM3TI4DG 16 bit, or

15 bit + sign

TM3TI8T 16 bit, or

15 bit + sign

TM3TI8TG 16 bit, or

15 bit + sign

4 inputs 0...10 Vdc

4 inputs Thermocouple Removable screw

4 inputs Thermocouple Removable spring

8 inputs Thermocouple

TM3 Analog Output Modules

The following table shows the TM3 analog output modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Analog Output Modules Configuration section.

Mode Terminal Type / Pitch

Removable spring

-10…+10 Vdc

0...20 mA

4...20 mA Thermocouple PT100/1000 NI100/1000

NTC/PTC

terminal blocks /

3.81 mm

terminal block /

3.81 mm

terminal blocks /

3.81 mm

Removable screw terminal block /

3.81 mm

Removable spring terminal blocks /

3.81 mm

Reference Resolution Channels Channel

Type

TM3AQ2 12 bit, or

11 bit + sign

TM3AQ2G 12 bit, or

11 bit + sign

TM3AQ4 12 bit, or

11 bit + sign

EIO0000003635 08/2020 23

2 outputs 0...10 Vdc

4 outputs 0...10 Vdc

Mode Terminal Type / Pitch

Removable screw

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

-10…+10 Vdc

0...20 mA

4...20 mA

terminal block /

5.08 mm

Removable spring terminal block /

5.08 mm

Removable screw terminal block /

5.08 mm

General Overview

Reference Resolution Channels Channel

Type

TM3AQ4G 12 bit, or

11 bit + sign

4 outputs 0...10 Vdc

TM3 Analog Mixed Input/Output Modules

This following table shows the TM3 analog mixed I/O modules, with corresponding channel type, nominal voltage/current, and terminal type. For information on configuration of these modules, refer to the TM3 Analog Mixed I/O Modules Configuration section.

Reference Resolution Channels Channel

Type

TM3AM6 12 bit, or

11 bit + sign

TM3AM6G 12 bit, or

11 bit + sign

TM3TM3 16 bit, or

15 bit + sign

12 bit, or 11 bit + sign

TM3TM3G 16 bit, or

15 bit + sign

12 bit, or 11 bit + sign

4 inputs 0...10 Vdc

2 outputs

4 inputs 0...10 Vdc

2 outputs

2 inputs 0...10 Vdc

1 output 0...10 Vdc

2 inputs 0...10 Vdc

1 output 0...10 Vdc

Mode Terminal Type / Pitch

Removable spring

-10…+10 Vdc

0...20 mA

4...20 mA

Mode Terminal Type / Pitch

-10...+10 Vdc

0...20 mA

4...20 mA

-10...+10 Vdc

0...20 mA

4...20 mA

-10...+10 Vdc

0...20 mA

4...20 mA Thermocouple PT100/1000 NI100/1000

-10...+10 Vdc

0...20 mA

4...20 mA

-10...+10 Vdc

0...20 mA

4...20 mA Thermocouple PT100/1000 NI100/1000

-10...+10 Vdc

0...20 mA

4...20 mA

terminal block /

5.08 mm

Removable screw terminal block /

3.81 mm

Removable spring terminal block /

3.81 mm

Removable screw terminal block /

5.08 mm

Removable spring terminal block /

5.08 mm

EIO0000003635 08/2020

TM3 Expert Modules

The following table shows the TM3 expert expansion modules, with corresponding terminal type. For information on configuration of these modules, refer to the TM3 Expert I/O Modules Configuration section.

Reference Description Terminal Type / Pitch

TM3XTYS4 TeSys module 4 front connectors RJ-45

TM3 Transmitter and Receiver Modules

The following table shows the TM3 transmitter and receiver expansion modules, with corresponding terminal type. For information on configuration of these modules, refer to the TM3 Transmitter and Receiver I/O Modules Configuration section.

Reference Description Terminal Type / Pitch

TM3XTRA1 Data transmitter module for remote I/O 1 front connector RJ-45

TM3XREC1 Data receiver module for remote I/O 1 front connector RJ-45

General Overview

1 removable power supply connector / 5.08 mm

1 screw for functional ground connection

1 removable power supply connector / 5.08 mm

TM3 Safety Modules

This table contains the TM3 safety modules, with the corresponding channel type, nominal voltage/current, and terminal type:

Reference Function

TM2 General Description

Introduction

The range of TM2 expansion modules includes:

 Digital expansion modules  Analog expansion modules

Digital Expansion Modules Features

The following table shows the digital expansion modules features:

Module reference Channels Channel type Voltage/current Reference page

Input Modules

TM2DAI8DT 8 Inputs 120 Vac

TM2DDI8DT 8 Inputs 24 Vdc

TM2DDI16DT 16 Inputs 24 Vdc

TM2DDI16DK 16 Inputs 24 Vdc

TM2DDI32DK 32 Inputs 24 Vdc

Output Modules

TM2DRA8RT 8 Outputs

TM2DRA16RT 16 Outputs

TM2DD08UT 8 Outputs

TM2DD08TT 8 Outputs

TM2DDO16UK 16 Outputs

TM2DDO16TK 16 Outputs

TM2DDO32UK 32 Outputs

Relay

Transistor sink

Transistor source

Transistor sink

Transistor source

Transistor sink

7.5 mA

7 mA

5 mA

30 Vdc/230 Vac 2 A max

24 Vdc

0.3 A max per output

24 Vdc

0.5 A max per output

24 Vdc

0.1 A max per output

24 Vdc

0.4 A max per output

24 Vdc

0.1 A max per output

General Overview

TM2DAI8DT

TM2DDI8DT

TM2DDI16DT

TM2DDI16DK

TM2DDI32DK

TM2DRA8RT

TM2DRA16RT

TM2DDO8UT

TM2DDO8TT

TM2DDO16UK

TM2DDO16TK

TM2DDO32UK

EIO0000003635 08/2020 27

General Overview

Module reference Channels Channel type Voltage/current Reference page

TM2DDO32TK 32 Outputs

Mixed Modules

TM2DMM8DRT 4

TM2DMM24DRF 16

Analog Expansion Modules Features

The following table shows the analog expansion modules features:

Module reference Channels Channel type Voltage/current Reference page

Input Modules

TM2AMI2HT 2 High-level inputs 0...10 Vdc

TM2AMI2LT 2 Low-level inputs Thermocouple

TM2AMI4LT 4 Inputs 0...10 Vdc

TM2AMI8HT 8 Inputs 0...20 mA

TM2ARI8HT 8 Inputs NTC / PTC TM2ARI8HT

TM2ARI8LRJ 8 Inputs PT100/1000 TM2ARI8LRJ

TM2ARI8LT 8 Inputs PT100/1000 TM2ARI8LT

Output Modules

TM2AMO1HT 1 Outputs 0...10 Vdc

TM2AVO2HT 2 Outputs +/- 10 Vdc TM2AVO2HT

Transistor source

Inputs Outputs Relay

24 Vdc

0.4 A max per output

24 Vdc/7 mA 30 Vdc/230VAC 2 A max

4...20 mA

type J,K,T

0...20 mA PT100/1000 Ni100/1000

0...10 Vdc

4...20 mA

TM2DDO32TK

TM2DMM8DRT

TM2DMM24DRF

TM2AMI2HT

TM2AMI2LT

TM2AMI4LT

TM2AMI8HT

(see Modicon TM2, Modules Configuration, Programming Guide)

TM2AMO1HT

EIO0000003635 08/2020

Module reference Channels Channel type Voltage/current Reference page

Mixed Modules

TM2AMM3HT 2

Inputs

Outputs

0...10 Vdc

4...20 mA

0...10 Vdc

TM2AMM3HT

4...20 mA

TM2AMM6HT 4

Inputs

Outputs

0...10 Vdc

4...20 mA

0...10 Vdc

TM2AMM6HT

4...20 mA

TM2ALM3LT 2

Low-level inputs

Outputs

Thermo J,K,T, PT100

0...10 Vdc

TM2ALM3LT

4...20 mA

General Overview

EIO0000003635 08/2020 29

General Overview

Accessories

Overview

This section describes the accessories and cables.

Accessories

Reference Description Use Quantity

NSYTRAAB35 End brackets Helps secure the TM3 bus coupler and their

TMAM2 Mounting Kit Mounts the TM3 bus coupler directly to a flat,

VW3A8306RC Modbus line

terminator

VW3CANA71 CANopen adaptor CANopen adaptor for converting SUB-D to RJ45. –

TCSCAR013M120 CANopen line

terminator (RJ45)

expansion modules on a top hat section rail (DIN rail).

vertical panel.

Terminate the end of RS-485 line. 2

Terminate the end of CAN bus. 2

Cables

Reference Description Details Length

TCSXCNAMUM3P Terminal port/USB

port cordset

BMXXCAUSBH018 Terminal port/USB

port cordset

From the USB mini-B port on the bus coupler to USB port on the PC terminal.

NOTE: Grounded and shielded, this USB

cable is suitable for long-duration connections.

VW3A8306R•• Modbus serial line

cable

XBTZ998• Modbus serial line

cable

XBTZ938 Modbus serial line

cable

XBTZ9008 Modbus serial line

cable

TSXCSA••• Modbus cable for

RS485

Cable equipped with 2 RJ45 connectors for Ethernet network, Modbus serial line, XBTGT terminal.

Cable equipped with 2 RJ45 connectors for XBT terminal.

Cable equipped with 1 RJ45 connector and 1 SUB-D 25 for XBT terminal.

Cable equipped with 1 RJ45 connector and 1 SUB-D 9 for XBT terminal.

Cable equipped with 4 twisted shielded wires. 100, 200 or 500 m

3m (10 ft)

1.8 m (5.9 ft)

0.3, 1 or 3 m (0.98, 3.28 or 9.84 ft)

2.5 or 10 m (8.2 or 32.81 ft)

2.5 m (8.2 ft)

328.08, 656.16 or

1.640.42 ft

EIO0000003635 08/2020

Reference Description Details Length

VW3A8306D•• Modbus serial line

cable

TWDXCAFJ010 Modbus serial line

cable

490NTW000•• Ethernet shielded

cable for DTE connections

490NTW000••U Standard cable, equipped with RJ45

TCSECE3M3M••S4 Cable for harsh environment, equipped with

TCSECU3M3M••S4 Cable for harsh environment, equipped with

TSXCANCA••• CANopen cable CANopen standard cable.

TSXCANCB••• CANopen standard cable.

Cable equipped with 1 RJ45 connector and 1 free end.

Standard cable, equipped with RJ45 connectors at each end for DTE. CE compliant.

connectors at each end for DTE. UL compliant.

RJ45 connectors at each end. CE compliant.

RJ45 connectors at each end. UL compliant.

CE compliant

3m (9.84 ft)

1m (3.28 ft)

2, 5, 12, 40, or 80 m (6.56, 16.4, 39.37,

131.23 or 262.47 ft)

2, 5, 12, 40, or 80 m (6.56, 16.4, 39.37,

131.23, or 262.47 ft)

1, 2, 3, 5, or 10 m (3.28, 6.56, 9.84, 16.4,

32.81 ft)

1, 2, 3, 5, or 10 m (3.28, 6.56, 9.84, 16.4,

32.81 ft)

50, 100 or 300 m (164.04, 328.08 or

984.25 ft)

CE and UL compliant.

TSXCANCD••• CANopen cable for harsh environment.

CE compliant.

TCSCCN4F3M••T CANopen

preassembled

VW3M3805R••• 1 or 3 m

cordsets

CANopen standard cable equiped with 1 RJ45 connector and 1 SUB-D 9 connector.

0.5, 1 or 3 m (1.64, 3.28 or 9.84 ft)

3.28 or 9.84 ft)

VW3CANCARR•• CANopen standard cable, equipped with RJ45

connectors at each end.

0.3 or 1 m (0.984 or 3.28 ft)

General Overview

EIO0000003635 08/2020 31

General Overview

EIO0000003635 08/2020

Modicon TM3 Bus Coupler

TM3 Bus Coupler Installation

EIO0000003635 08/2020

TM3 Bus Coupler Installation

Chapter 2

TM3 Bus Coupler Installation

What Is in This Chapter?

This chapter contains the following sections:

Section Topic Page

2.1 TM3 Bus Coupler General Rules for Implementing 34

2.2 TM3 Bus Coupler Installation 39

2.3 TM3 Electrical Requirements 54

EIO0000003635 08/2020 33

TM3 Bus Coupler Installation

TM3 Bus Coupler General Rules for Implementing

Section 2.1

TM3 Bus Coupler General Rules for Implementing

What Is in This Section?

This section contains the following topics:

Environmental Characteristics 35

Certifications and Standards 38

Topic Page

EIO0000003635 08/2020

Environmental Characteristics

Enclosure Requirements

Modicon TM3 Bus Coupler components are designed as Zone B, Class A industrial equipment according to IEC/CISPR Publication 11. If they are used in environments other than those described in these standards, or in environments that do not meet the specifications in this manual the ability to meet electromagnetic compatibility requirements in the presence of conducted and/or radiated interference may be reduced.

All Modicon TM3 Bus Coupler components meet UL requirement for open equipment as defined by UL 61010-1 and UL 61010-2-201. You must install them in an enclosure that conforms to UL 61010-1 and UL 61010-2-201 and designed for the specific environmental conditions and to minimize the possibility of unintended contact with hazardous voltages. The enclosure must have protection against the spread of fire and adequate rigidity to conform to UL 61010-1 and UL 610102-201. Use metal enclosures to improve the electromagnetic immunity of your Modicon TM3 Bus Coupler components. Use enclosures with a keyed locking mechanism to minimize unauthorized access.

TM3 Bus Coupler Installation

EIO0000003635 08/2020 35

TM3 Bus Coupler Installation

Environmental Characteristics

This equipment meets CE requirements as indicated in the table below. This equipment is intended for use in a Pollution Degree 2 industrial environment. This equipment is intended for indoor use only.

UNINTENDED EQUIPMENT OPERATION

Do not exceed any of the rated values specified in the environmental and electrical characteristics tables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

The following table shows the general environmental characteristics:

WARNING

Characteristic Minimum

Specification

Standard compliance IEC/EN 61131-2

IEC/EN 61010-1, 2-201

Ambient operating temperature – Horizontal

– Vertical installation –10...50 °C (14...122 °F)

Storage temperature – –25...70 °C (- 13...158 °F)

Relative humidity – Transport and

Degree of pollution IEC/EN 60664-1 2

Pollution degree IEC/UL 61010-1 Pollution degree 2, overvoltage category 2

Degree of protection IEC/EN 61131-2 IP20

Corrosion immunity – Atmosphere free from corrosive gases

Operating altitude – 0...2000 m (0...6560 ft)

Storage altitude – 0...3000 m (0...9843 ft)

Vibration resistance IEC/EN 61131-2 Panel mounting or

Mechanical shock resistance –

Tested Range

–

–10...60 °C (14...140 °F)

installation

10...95 % (non-condensing)

storage

Operation 10...95 % (non-condensing)

3.5 mm (0.13 in) fixed amplitude mounted on a top hat section rail (DIN rail)

147 m/s

or 482.28 ft/s2 (15 gn) for a duration of 11 ms

from 5...8.4 Hz

9.8 m/s

acceleration from 8.4...150 Hz

(32.15 ft/s2) (1 gn) fixed

NOTE: The tested ranges may indicate values beyond that of the IEC Standard. However, our internal standards

define what is necessary for industrial environments. In all cases, we uphold the minimum specification if indicated.

EIO0000003635 08/2020

Electromagnetic Susceptibility

The expansion module components and the TM3 bus coupler meet electromagnetic susceptibility specifications as indicated in the following table:

Characteristic Minimum Specification Tested Range

Electrostatic discharge IEC/EN 61000-4-2 8 kV (air discharge)

4 kV (contact discharge)

Radiated electromagnetic field IEC/EN 61000-4-3 10 V/m (80...1000 MHz)

Magnetic field IEC/EN 61000-4-8 30 A/m 50 Hz, 60 Hz

Fast transients burst IEC/EN 61000-4-4 DC Power lines 2 kV

Surge immunity IEC/EN 61000-4-5

IEC/EN 61131-2

Induced electromagnetic field IEC/EN 61000-4-6 10 Vrms (0.15...80 MHz)

Conducted emission IEC/EN 61000-6-4 AC/DC power line:

Radiated emission IEC/EN 61000-6-4 30...230 MHz: 40 dBμV/m QP

1 Common Mode 2 Differential Mode

3 V/m (1.4...2 GHz) 3 V/m (2...2.7 GHz) 3 V/m (2.7...6 GHz)

Controls and signals 1 kV

–

DC Power lines 1 kV 0.5 kV

Controls and signals 1 kV –

Communication line 1 kV –

 10...150 kHz: 120...69 dBμV/m QP  150...1500 kHz: 79...63 dBμV/m QP  1.5...30 MHz: 63 dBμV/m QP

230...1000 MHz: 47 dBμV/m QP

TM3 Bus Coupler Installation

NOTE: The tested ranges may indicate values beyond that of the IEC Standard. However, our internal standards

define what is necessary for industrial environments. In all cases, we uphold the minimum specification if indicated.

EIO0000003635 08/2020 37

TM3 Bus Coupler Installation

Certifications and Standards

Introduction

The TM3 bus coupler is designed to conform to the main national and international standards concerning electronic industrial control devices:

 EN 61131-2  UL/CSA 61010-1  UL/CSA 61010-2-201

The TM3 bus couplers have obtained the following conformity marks:

 CE  cULus  Marine Certification EU RO

For product compliance and environmental information (RoHS, REACH, PEP, EOLI, etc.), go to

www.schneider-electric.com/green-premium

EIO0000003635 08/2020

TM3 Bus Coupler Installation

Section 2.2

TM3 Bus Coupler Installation

What Is in This Section?

This section contains the following topics:

Installation and Maintenance Requirements 40

Installation Guidelines 43

Top Hat Section Rail (DIN rail) 46

Assembling a Module to a Modicon TM3 Bus Coupler 50

Disassembling a Module from a Modicon TM3 Bus Coupler 52

Direct Mounting on a Panel Surface 53

TM3 Bus Coupler Installation

Topic Page

EIO0000003635 08/2020 39

TM3 Bus Coupler Installation

Installation and Maintenance Requirements

Before Starting

Read and understand this chapter before beginning the installation of your system.

The use and application of the information contained herein require expertise in the design and programming of automated control systems. Only you, the user, machine builder or integrator, can be aware of all the conditions and factors present during installation and setup, operation, and maintenance of the machine or process, and can therefore determine the automation and associated equipment and the related safeties and interlocks which can be effectively and properly used. When selecting automation and control equipment, and any other related equipment or software, for a particular application, you must also consider any applicable local, regional or national standards and/or regulations.

Pay particular attention in conforming to any safety information, different electrical requirements, and normative standards that would apply to your machine or process in the use of this equipment.

Disconnecting Power

All options and modules should be assembled and installed before installing the control system on a mounting rail, onto a mounting plate or in a panel. Remove the control system from its mounting rail, mounting plate or panel before disassembling the equipment.

HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH

 Disconnect all power from all equipment including connected devices prior to removing any

covers or doors, or installing or removing any accessories, hardware, cables, or wires except under the specific conditions specified in the appropriate hardware guide for this equipment.

 Always use a properly rated voltage sensing device to confirm the power is off where and when

indicated.

 Replace and secure all covers, accessories, hardware, cables, and wires and confirm that a

proper ground connection exists before applying power to the unit.

 Use only the specified voltage when operating this equipment and any associated products.

Failure to follow these instructions will result in death or serious injury.

DANGER

EIO0000003635 08/2020

Programming Considerations

UNINTENDED EQUIPMENT OPERATION

 Only use software approved by Schneider Electric for use with this equipment.  Update your application program every time you change the physical hardware configuration.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Operating Environment

In addition to the Environmental Characteristics, refer to Product Related Information in the beginning of the present document for important information regarding installation in hazardous locations for this specific equipment.

UNINTENDED EQUIPMENT OPERATION

Install and operate this equipment according to the conditions described in the Environmental Characteristics.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

TM3 Bus Coupler Installation

WARNING

EIO0000003635 08/2020 41

TM3 Bus Coupler Installation

Installation Considerations

UNINTENDED EQUIPMENT OPERATION

 Use appropriate safety interlocks where personnel and/or equipment hazards exist.  Install and operate this equipment in an enclosure appropriately rated for its intended

environment and secured by a keyed or tooled locking mechanism.

 Use the sensor and actuator power supplies only for supplying power to the sensors or

actuators connected to the module.

 Power line and output circuits must be wired and fused in compliance with local and national

regulatory requirements for the rated current and voltage of the particular equipment.

 Do not use this equipment in safety-critical machine functions unless the equipment is

otherwise designated as functional safety equipment and conforming to applicable regulations and standards.

 Do not disassemble, repair, or modify this equipment.  Do not connect any wiring to reserved, unused connections, or to connections designated as

No Connection (N.C.).

Failure to follow these instructions can result in death, serious injury, or equipment damage.

NOTE: JDYX2 or JDYX8 fuse types are UL-recognized and CSA approved.

WARNING

EIO0000003635 08/2020

Installation Guidelines

Introduction

The TM3 bus coupler is connected to a controller using a fieldbus communication cable.

The TM3 bus coupler can be installed on a top hat section rail (DIN rail).

Correct Mounting Position

Whenever possible, the TM3 bus coupler should be mounted horizontally on a vertical plane as shown in the illustrations below:

TM3 Bus Coupler Installation

Acceptable Mounting Position

Whenever possible, the TM3 bus coupler can also be mounted vertically with a temperature derating on a vertical plane as shown below:

NOTE: Expansion modules must be mounted above the TM3 bus coupler.

EIO0000003635 08/2020 43

TM3 Bus Coupler Installation

Incorrect Mounting Position

The TM3 bus coupler should only be positioned as shown in Correct Mounting Position

(see page 43)

. The following illustrations show the incorrect mounting positions:

EIO0000003635 08/2020

Minimum Clearances

UNINTENDED EQUIPMENT OPERATION

 Place devices dissipating the most heat at the top of the cabinet and ensure adequate

ventilation.

 Avoid placing this equipment next to or above devices that might cause overheating.  Install the equipment in a location providing the minimum clearances from all adjacent

structures and equipment as directed in this document.

 Install all equipment in accordance with the specifications in the related documentation.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

The TM3 bus coupler has been designed as an IP20 product and must be installed in an enclosure. Clearances must be respected when installing the product.

There are 3 types of clearances between:

 The TM3 bus coupler and all sides of the cabinet (including the panel door).  The TM3 bus coupler terminal blocks and the wiring ducts. This distance reduces

electromagnetic interference between the controller and the wiring ducts.

 The TM3 bus coupler and other heat generating devices installed in the same cabinet.

The following illustration shows the minimum clearances that apply to all TM3 bus coupler references:

TM3 Bus Coupler Installation

WARNING

EIO0000003635 08/2020 45

TM3 Bus Coupler Installation

Top Hat Section Rail (DIN rail)

Dimensions of Top Hat Section Rail DIN Rail

You can mount the TM3 bus coupler and its expansions on a 35 mm (1.38 in.) top hat section rail (DIN rail). The DIN rail can be attached to a smooth mounting surface or suspended from a EIA rack or mounted in a NEMA cabinet.

Symmetric Top Hat Section Rails (DIN Rail)

The following illustration and table indicate the references of the top hat section rails (DIN rail) for the wall-mounting range:

Reference Type Rail Length (B)

NSYSDR50A A 450 mm (17.71 in.)

NSYSDR60A A 550 mm (21.65 in.)

NSYSDR80A A 750 mm (29.52 in.)

NSYSDR100A A 950 mm (37.40 in.)

EIO0000003635 08/2020

TM3 Bus Coupler Installation

The following illustration and table indicate the references of the symmetric top hat section rails (DIN rail) for the metal enclosure range:

Reference Type Rail Length (B-12 mm)

NSYSDR60 A 588 mm (23.15 in.)

NSYSDR80 A 788 mm (31.02 in.)

NSYSDR100 A 988 mm (38.89 in.)

NSYSDR120 A 1188 mm (46.77 in.)

The following illustration and table indicate the references of the symmetric top hat section rails (DIN rail) of 2000 mm (78.74 in.):

Reference Type Rail Length

NSYSDR200

NSYSDR200D

A 2000 mm (78.74 in.)

1 Unperforated galvanized steel 2 Perforated galvanized steel

EIO0000003635 08/2020 47

TM3 Bus Coupler Installation

Double-Profile Top Hat Section Rails (DIN rail)

The following illustration and table indicate the references of the double-profile top hat section rails (DIN rails) for the wall-mounting range:

Reference Type Rail Length (B)

NSYDPR25 W 250 mm (9.84 in.)

NSYDPR35 W 350 mm (13.77 in.)

NSYDPR45 W 450 mm (17.71 in.)

NSYDPR55 W 550 mm (21.65 in.)

NSYDPR65 W 650 mm (25.60 in.)

NSYDPR75 W 750 mm (29.52 in.)

EIO0000003635 08/2020

TM3 Bus Coupler Installation

The following illustration and table indicate the references of the double-profile top hat section rails (DIN rail) for the floor-standing range:

Reference Type Rail Length (B)

NSYDPR60 F 588 mm (23.15 in.)

NSYDPR80 F 788 mm (31.02 in.)

NSYDPR100 F 988 mm (38.89 in.)

NSYDPR120 F 1188 mm (46.77 in.)

EIO0000003635 08/2020 49

TM3 Bus Coupler Installation

Assembling a Module to a Modicon TM3 Bus Coupler

Introduction

This section describes how to assemble an expansion module to a TM3 bus coupler.

DANGER

HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH

 Disconnect all power from all equipment including connected devices prior to removing any

covers or doors, or installing or removing any accessories, hardware, cables, or wires except under the specific conditions specified in the appropriate hardware guide for this equipment.

 Always use a properly rated voltage sensing device to confirm the power is off where and when

indicated.

 Replace and secure all covers, accessories, hardware, cables, and wires and confirm that a

proper ground connection exists before applying power to the unit.

 Use only the specified voltage when operating this equipment and any associated products.

Failure to follow these instructions will result in death or serious injury.

After connecting new modules to the TM3 bus coupler, update your application program before placing the system back in service. If you do not update your application program to reflect the addition of new modules, I/O located on the expansion bus may no longer operate correctly.

WARNING

UNINTENDED EQUIPMENT OPERATION

 Only use software approved by Schneider Electric for use with this equipment.  Update your application program every time you change the physical hardware configuration.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

EIO0000003635 08/2020

Assembling a Module to a Modicon TM3 Bus Coupler

The following procedure shows how to assemble a TM3 bus coupler and a module:

Step Action

1 Remove all power and dismount any existing I/O assembly from its DIN mounting.

2 Remove the expansion connector sticker from the TM3 bus coupler.

3 Verify that the mounting clip on the new module is in the upper position.

4 Align the internal bus connector on the left side of the module with the internal bus connector on the

right side of the TM3 bus coupler.

5 Press the new module towards the TM3 bus coupler until it is securely in place.

6 Push down the mounting clip on the top of the new module to lock it to the TM3 bus coupler.

TM3 Bus Coupler Installation

EIO0000003635 08/2020 51

TM3 Bus Coupler Installation

Disassembling a Module from a Modicon TM3 Bus Coupler

Introduction

This section describes how to disassemble an expansion module from a TM3 bus coupler.

DANGER

HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH

 Disconnect all power from all equipment including connected devices prior to removing any

covers or doors, or installing or removing any accessories, hardware, cables, or wires except under the specific conditions specified in the appropriate hardware guide for this equipment.

 Always use a properly rated voltage sensing device to confirm the power is off where and when

indicated.

 Replace and secure all covers, accessories, hardware, cables, and wires and confirm that a

proper ground connection exists before applying power to the unit.

 Use only the specified voltage when operating this equipment and any associated products.

Failure to follow these instructions will result in death or serious injury.

Disassembling a Module from a Modicon TM3 Bus Coupler

The following procedure describes how to disassemble a module from a TM3 bus coupler:

Step Action

1 Remove all power from the control system.

2 Dismount the assembled TM3 bus coupler and modules from the mounting rail.

3 Push up the mounting clip from the bottom of the module to disengage it from the TM3 bus

coupler.

4 Pull apart module from the TM3 bus coupler.

EIO0000003635 08/2020

Direct Mounting on a Panel Surface

Overview

This section shows how to install TM3 bus coupler using the Panel Mounting Kit. This section also provides mounting hole layout.

Installing the Panel Mount Kit

The following procedure shows how to install a mounting strip:

Step Action

1 Insert the mounting strip TMAM2 into the slot at the top of the module.

TM3 Bus Coupler Installation

Mounting Hole Layout

The following diagram shows the mounting holes for TM3 bus coupler:

EIO0000003635 08/2020 53

TM3 Bus Coupler Installation

TM3 Electrical Requirements

Section 2.3

TM3 Electrical Requirements

What Is in This Section?

This section contains the following topics:

Wiring Best Practices 55

DC Power Supply Characteristics and Wiring 60

Grounding the TM3 System 63

Topic Page

EIO0000003635 08/2020

Wiring Best Practices

Overview

This section describes the wiring guidelines and associated best practices to be respected when using the system.

HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH

 Disconnect all power from all equipment including connected devices prior to removing any

covers or doors, or installing or removing any accessories, hardware, cables, or wires except under the specific conditions specified in the appropriate hardware guide for this equipment.

 Always use a properly rated voltage sensing device to confirm the power is off where and when

indicated.

 Replace and secure all covers, accessories, hardware, cables, and wires and confirm that a

proper ground connection exists before applying power to the unit.

 Use only the specified voltage when operating this equipment and any associated products.

Failure to follow these instructions will result in death or serious injury.

LOSS OF CONTROL

 The designer of any control scheme must consider the potential failure modes of control paths

 Separate or redundant control paths must be provided for critical control functions.  System control paths may include communication links. Consideration must be given to the

implications of unanticipated transmission delays or failures of the link.

 Observe all accident prevention regulations and local safety guidelines.  Each implementation of this equipment must be individually and thoroughly tested for proper

operation before being placed into service.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

TM3 Bus Coupler Installation

DANGER

WARNING

EIO0000003635 08/2020 55

TM3 Bus Coupler Installation

Functional Ground (FE) on the DIN Rail

The DIN Rail for your system is common with the functional ground (FE) plane and must be mounted on a conductive backplane.

UNINTENDED EQUIPMENT OPERATION

Connect the DIN rail to the functional ground (FE) of your installation.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Protective Ground (PE) on the Backplane

The protective ground (PE) is connected to the conductive backplane by a heavy-duty wire, usually a braided copper cable with the maximum allowable cable section.

Wiring Guidelines

The following rules must be applied when wiring a system:

 I/O and communication wiring must be kept separate from the power wiring. Route these 2 types

of wiring in separate cable ducting.

 Verify that the operating conditions and environment are within the specification values.  Use proper wire sizes to meet voltage and current requirements.  Use copper conductors.  Use twisted-pair, shielded cables for analog, and/or fast I/O.  Use twisted-pair, shielded cables for networks, and field bus.

WARNING

UNINTENDED EQUIPMENT OPERATION

 Use shielded cables for all fast I/O, analog I/O, and communication signals.

 Ground cable shields for all fast I/O, analog I/O, and communication signals at a single point  Route communications and I/O cables separately from power cables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Multipoint grounding is permissible (and in some cases inevitable) if connections are made to an equipotential ground plane dimensioned to help avoid cable shield damage in the event of power system short-circuit currents.

NOTE: Surface temperatures may exceed 60 °C (140 °F). To conform to IEC 61010 standards, route primary wiring (wires connected to power mains) separately and apart from secondary wiring (extra low voltage wiring coming from intervening power sources). If that is not possible, double insulation is required such as conduit or cable gains.

EIO0000003635 08/2020

All connectors must be connected to Protective Extra Low Voltage (PELV) according to UL 610102-201 or IEC 60950 or Class 2 of NEC.

Rules for Removable Screw Terminal Block

The following tables show the cable types and wire sizes for a 5.08 pitch removable screw terminal block (I/Os and power supply):

The use of 75 °C (167 °F) wires with copper conductors is required.

FIRE HAZARD

Use only the correct wire sizes for the maximum current capacity of the power supplies.

Failure to follow these instructions will result in death or serious injury.

TM3 Bus Coupler Installation

DANGER

Protecting Outputs from Inductive Load Damage

Depending on the load, a protection circuit may be needed for the outputs on the controllers and certain modules. Inductive loads using DC voltages may create voltage reflections resulting in overshoot that will damage or shorten the life of output devices.

CAUTION

OUTPUT CIRCUIT DAMAGE DUE TO INDUCTIVE LOADS

Use an appropriate external protective circuit or device to reduce the risk of inductive direct current load damage.

Failure to follow these instructions can result in injury or equipment damage.

EIO0000003635 08/2020 57

TM3 Bus Coupler Installation

If your controller or module contains relay outputs, these types of outputs can support up to 240 Vac. Inductive damage to these types of outputs can result in welded contacts and loss of control. Each inductive load must include a protection device such as a peak limiter, RC circuit or flyback diode. Capacitive loads are not supported by these relays.

RELAY OUTPUTS WELDED CLOSED

 Always protect relay outputs from inductive alternating current load damage using an

appropriate external protective circuit or device.

 Do not connect relay outputs to capacitive loads.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

AC-driven contactor coils are, under certain circumstances, inductive loads that generate pronounced high-frequency interference and electrical transients when the contactor coil is deenergized. This interference may cause the logic controller to detect an I/O bus error.

CONSEQUENTIAL LOSS OF CONTROL

Install an RC surge suppressor or similar means, such as an interposing relay, on each TM3 expansion module relay output when connecting to AC-driven contactors or other forms of inductive loads.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

WARNING

Protective circuit A: this protection circuit can be used for both AC and DC load power circuits.

 C represents a value from 0.1 to 1 μF.  R represents a resistor of approximately the same resistance value as the load.

EIO0000003635 08/2020

TM3 Bus Coupler Installation

Protective circuit B: this protection circuit can be used for DC load power circuits.

Use a diode with the following ratings:

 Reverse withstand voltage: power voltage of the load circuit x 10.  Forward current: more than the load current.

Protective circuit C: this protection circuit can be used for both AC and DC load power circuits.

 In applications where the inductive load is switched on and off frequently and/or rapidly, ensure

that the continuous energy rating (J) of the varistor exceeds the peak load energy by 20 % or more.

EIO0000003635 08/2020 59

TM3 Bus Coupler Installation

DC Power Supply Characteristics and Wiring

Overview

This section provides the characteristics and the wiring diagrams of the DC power supply.

DC Power Supply Voltage Range

DANGER

FIRE HAZARD

Use only the correct wire sizes for the maximum current capacity of the power supplies.

Failure to follow these instructions will result in death or serious injury.

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not exceed any of the rated values specified in the environmental and electrical characteristics tables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

EIO0000003635 08/2020

DC Power Supply Requirements

The TM3 bus coupler and the associated expansion modules require power supplies with a nominal voltage of 24 Vdc. The 24 Vdc power supplies must be rated Protective Extra Low Voltage (PELV) according to UL 61010-2-201 or IEC 60950 or Class 2 of NEC. These power supplies are isolated between the electrical input and output circuits of the power supply.

POTENTIAL OF OVERHEATING AND FIRE

 Do not connect the equipment directly to line voltage.

 Use only isolating PELV power supplies and circuits to supply power to the equipment

Failure to follow these instructions can result in death, serious injury, or equipment damage.

For compliance to UL (Underwriters Laboratories) requirements, the power supply must also conform to the various criteria of NEC Class 2, and be inherently current limited to a maximum power output availability of less than 100 VA (approximately 4 A at nominal voltage), or not inherently limited but with an additional protection device such as a circuit breaker or fuse meeting the requirements of clause 9.4 Limited-energy circuit of UL 61010-1. In all cases, the current limit should never exceed that of the electric characteristics and wiring diagrams for the equipment described in the present documentation. In all cases, the power supply must be grounded, and you must separate Class 2 circuits from other circuits. If the indicated rating of the electrical characteristics or wiring diagrams are greater than the specified current limit, multiple Class 2 power supplies may be used.

WARNING

TM3 Bus Coupler Installation

Modicon TM3 Bus Coupler DC Characteristics

The following table shows the DC power supply characteristics required for the TM3 bus coupler:

Characteristic Value

Rated voltage 24 Vdc

Power supply voltage range 20.4...28.8 Vdc

Power interruption time 1 ms at 24 Vdc

Maximum inrush current 50 A

Input current max. 800 mA

Power consumption 14.4 W max. 19.2 W

Isolation between DC power supply and internal bus Not isolated

between DC power supply and grounding Not isolated

EIO0000003635 08/2020 61

TM3 Bus Coupler Installation

Power interruption

The TM3 bus coupler must be supplied by an external 24 V power supply equipment. During power interruptions, the TM3 bus coupler, associated to the suitable power supply, is able to continue normal operation for a minimum of 10 ms as specified by IEC standards.

When planning the management of the power supplied to the controller, you must consider the power interruption duration due to the fast cycle time of the controller.

There could potentially be many scans of the logic and consequential updates to the I/O image table during the power interruption, while there is no external power supplied to the inputs, the outputs or both depending on the power system architecture and power interruption circumstances.

UNINTENDED EQUIPMENT OPERATION

 Individually monitor each source of power used in the controller system including input power

supplies, output power supplies and the power supply to the controller to allow appropriate system shutdown during power system interruptions.

 The inputs monitoring each of the power supply sources must be unfiltered inputs.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

DC Power Supply Wiring Diagram

The following illustration shows the power supply terminal block:

WARNING

* Type T fuse

For more information, refer to the 5.08 pitch Rules for Removable Screw Terminal block

(see page 57)

EIO0000003635 08/2020

Grounding the TM3 System

Overview

Due to the effects of electromagnetic interference, cables carrying fast I/O, analog I/O, and the fieldbus communication signals must be shielded.

UNINTENDED EQUIPMENT OPERATION

 Use shielded cables for all fast I/O, analog I/O, and communication signals.

 Ground cable shields for all fast I/O, analog I/O, and communication signals at a single point  Route communications and I/O cables separately from power cables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

The use of shielded cables requires compliance with the following wiring rules:

 For protective earth ground connections (PE), metal conduit or ducting can be used for part of

the shielding length, provided there is no break in the continuity of the ground connections. For functional ground (FE), the shielding is intended to attenuate electromagnetic interference and the shielding must be continuous for the length of the cable. If the purpose is both functional and protective, as is often the case for communication cables, the cable must have continuous shielding.

 Wherever possible, keep cables carrying one type of signal separate from the cables carrying

other types of signals or power.

WARNING

TM3 Bus Coupler Installation

Protective Earth Ground (PE) on the Backplane

The protective earth ground (PE) is connected to the conductive backplane by a heavy-duty wire, usually a braided copper cable with the maximum allowable cable section.

EIO0000003635 08/2020 63

TM3 Bus Coupler Installation

Shielded Cables Connections

Cables carrying fast I/O, analog I/O, and the fieldbus communication signals must be shielded. The shielding must be securely connected to ground. Fast I/O and analog I/O shields may be connected either to the functional ground (FE) or to the protective earth ground (PE) of your TM3 expansion module. The fieldbus communication cable shields must be connected to the protective earth ground (PE) with a connecting clamp secured to the conductive backplane of your installation.

ACCIDENTAL DISCONNECTION FROM PROTECTIVE GROUND (PE)

 Do not use the TM2XMTGB Grounding Bar to provide a protective earth ground (PE).  Use the TM2XMTGB Grounding Bar only to provide a functional ground (FE).

Failure to follow these instructions can result in death, serious injury, or equipment damage.

WARNING

EIO0000003635 08/2020

Modicon TM3 Bus Coupler

TM3 Ethernet Bus Coupler

EIO0000003635 08/2020

TM3 Ethernet Bus Coupler

Chapter 3

TM3 Ethernet Bus Coupler

What Is in This Chapter?

This chapter contains the following topics:

TM3 Ethernet Bus Coupler Presentation 66

TM3 Ethernet Bus Coupler Characteristics 68

Rotary Switch 69

Ethernet Port 73

Connecting the Modicon TM3 Bus Coupler to a PC 75

Topic Page

EIO0000003635 08/2020 65

TM3 Ethernet Bus Coupler

TM3 Ethernet Bus Coupler Presentation

Overview

The TM3 bus coupler is a device designed to manage EtherNet/IP or Modbus TCP communication when using TM2/TM3 expansion modules in a distributed architecture.

The main elements of the TM3 bus coupler are:

1 Rotary switches 2 Expansion connector for TM2/TM3 expansion modules 3 Two (2) isolated switched Ethernet ports 4 USB mini-B configuration port 5 24 Vdc power supply 6 Clip-on lock for 35 mm ( 7 Status LEDs

Main Characteristics

Characteristic Value

Rated power supply 24 Vdc

Weight 100 g (3.53 oz)

Rotary switch 2

Ethernet 2 (isolated switched Ethernet ports:10 Mbps / 100 Mbps)

Power supply connection type Removable screw terminal block

1.38 in.

) top hat section rail (DIN rail)

EIO0000003635 08/2020

Status LEDs

The following graphic shows the LEDs of TM3 bus coupler:

The following table describes the status LEDs:

LED Color Status Description

PWR Green On Power is applied.

MS Green/Red Flashing Device is performing a self-test.

NS Green/Red Off IP address is not configured.

I/O Green Solid Device is communicating with the expansion modules.

TM3 Ethernet Bus Coupler

Off Power is removed. All LED indicators are off.

Green Solid Device is running.

Flashing Device detected an invalid configuration or is not configured.

Red Solid Device detected an error that is, under most circumstances, unrecoverable.

Flashing Device detected an error that is, under most circumstances, recoverable.

For example:

 Rotary switch position changed during operational mode.  Error detected during firmware update.

Flashing Device is performing a self-test.

Green Solid At least one CIP connection is established, and an exclusive owner

connection has not timed out.

Flashing The IP address is configured, but CIP connections are not established and

an exclusive owner connection has not timed out.

Red Solid Device detected that the IP address is already in use.

Flashing An IP address is configured, and an exclusive owner connection for which

this device is the target has timed out.

Flashing The physical configuration matches the software configuration, but no

communication exists between the bus coupler and the expansion modules.

Red Solid The physical configuration is inconsistent with the software configuration.

Flashing At least one TM2 or TM3 expansion module did not respond to the bus

coupler for three consecutive cycles.

NOTE: With the exception of the PWR LED, each LED is ON for a few seconds, then OFF during the boot sequence. The LED behavior rules apply when the boot is completed successfully.

EIO0000003635 08/2020 67

TM3 Ethernet Bus Coupler

TM3 Ethernet Bus Coupler Characteristics

Introduction

This section provides a general description of the characteristics of the TM3 Ethernet bus coupler.

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not exceed any of the rated values specified in the environmental and electrical characteristics tables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Dimensions

The following graphic shows the external dimensions for the Modicon TM3 Bus Coupler:

General Characteristics

The following table shows the characteristics of TM3 Ethernet Bus Coupler:

Characteristics Value

Connector insertion/removal durability Over 100 times

Supplied power available for connected inputs and outputs modules Current draw on 5 Vdc and 24 Vdc internal bus 600 mA max.

EIO0000003635 08/2020

Rotary Switch

Overview

The two rotary switches located on the front panel of the TM3 Ethernet Bus Coupler are used to set an IP address.

The default values on the rotary switches are:

 0 for TENSx  AUTO for ONESy

TM3 Ethernet Bus Coupler

NOTE: You can also set the IP address using the web server. The web server configured IP address is only taken into account when the rotary switch is in the AUTO position. If you use EcoStruxure Machine Expert - Basic, refer to the Modicon TM3 Bus Coupler (EcoStruxure Machine Expert - Basic) - Programming Guide. If you use EcoStruxure Machine Expert, refer to the Modicon TM3 Bus Coupler - Programming Guide.

EIO0000003635 08/2020 69

TM3 Ethernet Bus Coupler

Setting an IP Address

Set the rotary switches before:

 Applying power to the module.  Downloading the application.

NOTE: Any modification of the rotary switch position is taken into account after power up.

This table describes the configuration of the rotary switches:

Position of the rotary switches Description

Tens Ones

0...15 0...9 Allows you to configure the device name. Use both switches to

Any AUTO The default IP address (10.10.x.x) is used. The last two fields in

Any BOOTP Uses the MAC address to request the IP parameters.

select a numeric value from 0...159. For example, if TENS x = 08 and ONES y = 6, the device name is TM3BCEIP_086.

NOTE: Device names TM3BCEIP_091...TM3BECIP_159 are

reserved.

the default IP address are composed of the last two hexadecimal bytes of the MAC address of the port. You can change the network configuration with the embedded web server.

NOTE: A MAC address is always written in hexadecimal format

and an IP address in decimal format. Convert the MAC address to decimal format. For example, if the MAC address is

00.80.F4.01.80.F2, the default IP address is 10.10.128.242.

If you use EcoStruxure Machine Expert - Basic, refer to the Modicon TM3 Bus Coupler (EcoStruxure Machine Expert Basic) - Programming Guide. If you use EcoStruxure Machine Expert, refer to the Modicon TM3 Bus Coupler - Programming Guide.

EIO0000003635 08/2020

TM3 Ethernet Bus Coupler

Carefully manage the IP addresses because each device on the network requires a unique address. Having multiple devices with the same IP address can cause unintended operation of your network and associated equipment.

WARNING

UNINTENDED EQUIPMENT OPERATION

 Verify that there is only one master controller configured on the network or remote link.  Verify that all devices have unique addresses.  Obtain your IP address from your system administrator.  Confirm that the IP address of the device is unique before placing the system into service.  Do not assign the same IP address to any other equipment on the network.  Update the IP address after cloning any application that includes Ethernet communications to

a unique address.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

NOTE: This device comes pre configured with an IP address of 10.10.xxx.xxx. Change this default address before using the device on the network. It is good practice to ensure that your system administrator maintains a record of all assigned IP addresses on the network and subnetwork, and to inform the system administrator of all configuration changes performed.

EIO0000003635 08/2020 71

TM3 Ethernet Bus Coupler

Applying the IP Address

The device reads the position of the rotary switches at power up.

If your device does not communicate, verify that the position of the rotary switches is correct. If you change the position of the rotary switches when in operation mode, the MS flashes red. You must do a power cycle to apply the new address.

EIO0000003635 08/2020

Ethernet Port

Overview

The TM3BCEIP is equipped with two isolated switched Ethernet ports (CN1, CN2) enabling easy daisy-chain configuration.

Characteristics

This table describes the Ethernet characteristics:

Characteristic Description

Function Modbus TCP, EtherNet/IP

Connector type RJ45

Auto negotiation From 10 Mbps half duplex to 100 Mbps full duplex

Cable type Shielded

Automatic cross-over detection Yes

Topology Ring type

Pin Assignment

This graphic shows the RJ45 Ethernet connector pin assignment:

TM3 Ethernet Bus Coupler

This table describes the RJ45 Ethernet connector pins:

Pin N° Signal

1TD+

2TD-

3RD+

6RD-

EIO0000003635 08/2020 73

TM3 Ethernet Bus Coupler

NOTE: The TM3 Ethernet Bus Coupler supports the MDI/MDIX auto-crossover cable function. It is not necessary to use special Ethernet crossover cables to connect devices directly to this port (connections without an Ethernet hub or switch).

NOTE: Ethernet cable disconnection is detected every second. In case of disconnection of a short duration (< 1 second), the network status may not indicate the disconnection.

Status LED

This graphic shows RJ45 connectors status LED:

This table describes the Ethernet status LEDs:

Label Description LED

Color Status Description

1 Ethernet activity Green Off No activity

Flashing Transmitting or receiving data

2 Ethernet link Green/Orange Off No link

Orange on Link at 10 Mbit/s

Green on Link at 100 Mbit/s

EIO0000003635 08/2020

Connecting the Modicon TM3 Bus Coupler to a PC

Overview

You can connect the TM3 bus coupler to a PC through the following ports:

 USB  Ethernet

USB Mini-B Port Connection

USB-B port is dedicated for firmware update, configuration download and web server access.

TCSXCNAMUM3P: This USB cable is suitable for short duration connections such as quick

updates or retrieving data values.

NOTE: You can only connect one TM3 bus coupler or any other device associated with EcoStruxure Machine Expert and its component to the PC at any one time.

Using a typical USB cable, this connection is suitable for short duration connections to perform maintenance and inspect data values. It is not suitable for long-term connections such as commissioning or monitoring without the use of specially adapted cables to help minimize electromagnetic interference.

WARNING

UNINTENDED EQUIPMENT OPERATION OR INOPERABLE EQUIPMENT

 You must use a shielded USB cable such as a BMX XCAUSBH0•• secured to the functional

ground (FE) of the system for any long-term connection.

 Do not connect more than one controller or bus coupler at a time using USB connections.  Do not use the USB port(s), if so equipped, unless the location is known to be non-hazardous.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

TM3 Ethernet Bus Coupler

The communication cable should be connected to the PC first to minimize the possibility of electrostatic discharge affecting the TM3 bus coupler.

Grounded and shielded, this USB cable is suitable for long-term connections.

The following illustration shows the USB connection to a PC:

EIO0000003635 08/2020 75

TM3 Ethernet Bus Coupler

To connect the USB cable to your TM3 bus coupler, follow the steps below:

Step Action

1 1a If making a long-term connection using the cable BMXXCAUSBH045, or other cable with a

ground shield connection, be sure to securely connect the shield connector to the functional ground (FE) or protective ground (PE) of your system before connecting the cable to your controller and your PC.

1b If making a short-term connection using the cable TCSXCNAMUM3P or other non-grounded

USB cable, proceed to step 2.

2 Connect your USB cable to the PC.

3 Connect the Mini connector of your USB cable to the TM3 bus coupler USB connector.

Ethernet Port Connection

To connect the TM3 bus coupler to a PC using the Ethernet ports:

To connect the TM3 bus coupler to the PC, do the following:

Step Action

1 Connect the Ethernet cable to the PC.

2 Connect the Ethernet cable to one of the Ethernet ports on the TM3 bus coupler.

EIO0000003635 08/2020

Modicon TM3 Bus Coupler

TM3 Modbus Serial Line Bus Coupler

EIO0000003635 08/2020

TM3 Modbus Serial Line Bus Coupler

Chapter 4

TM3 Modbus Serial Line Bus Coupler

What Is in This Chapter?

This chapter contains the following topics:

TM3 Modbus Serial Line Bus Coupler Presentation 78

TM3 Modbus Serial Line Bus Coupler Characteristics 80

Rotary Switch 81

Serial Line Port 85

Connecting the TM3 Modbus Serial Line Bus Coupler to a PC 87

Topic Page

EIO0000003635 08/2020 77

TM3 Modbus Serial Line Bus Coupler

TM3 Modbus Serial Line Bus Coupler Presentation

Overview

The TM3 Modbus Serial Line bus coupler is a device designed to manage Serial Line communication when using TM2/TM3 expansion modules in a distributed architecture.

The main elements of the TM3 Modbus Serial Line bus coupler are:

1 Rotary switches 2 Expansion connector for TM2/TM3 expansion modules 3 Two (2) isolated RJ45 (RS-485) ports (daisy-chained) 4 USB mini-B configuration port 5 24 Vdc power supply 6 Clip-on lock for 35 mm ( 7 Status LEDs

Main Characteristics

Characteristic Value

Rated power supply 24 Vdc

Weight 100 g (3.53 oz)

Rotary switch 2

Serial line 2 isolated RJ45 (RS-485) ports (daisy-chained)

Power supply connection type Removable screw terminal block

1.38 in.

) top hat section rail (DIN rail)

EIO0000003635 08/2020

Status LEDs

The following graphic shows the LEDs of TM3 Modbus Serial Line bus coupler:

The following table describes the status LEDs:

LED Color Status Description

PWR Green On Power is applied.

COM Green Flashing Data sending and receiving.

ERR Red Flashing Device has detected an error that is, under most circumstances,

I/O Green Flashing Device has received and applied the expansion modules

TM3 Modbus Serial Line Bus Coupler

Off Power is removed. All LED indicators are off.

Off No data exchanged.

Red Flashing Device is receiving an incorrect data frame.

recoverable. For example:

 Rotary switch position changed during operational mode. Return

to the initial position to reset the LED behavior.

 Error detected during firmware update.  Communication and configuration errors.

Off No error detected.

configuration.

Solid Device is communicating with the expansion modules.

Green Red

Flashing Solid

Solid Solid

Solid Flashing

Off No configuration. Device is not communicating with the expansion

The physical configuration is inconsistent with the software configuration. No data exchange (status and I/O) is occurring.

The physical configuration is inconsistent with the software configuration. I/O data is not applied.

At least one TM2 or TM3 expansion module did not respond to the bus coupler for 10 consecutive cycles.

modules.

NOTE: With the exception of the PWR LED, each LED is ON for a few seconds, then OFF during boot sequence. The LED behavior rules apply when the boot is completed successfully.

EIO0000003635 08/2020 79

TM3 Modbus Serial Line Bus Coupler

TM3 Modbus Serial Line Bus Coupler Characteristics

Introduction

This section provides a general description of the characteristics of the TM3 Modbus Serial Line bus coupler.

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not exceed any of the rated values specified in the environmental and electrical characteristics tables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Dimensions

The following graphic shows the external dimensions for the TM3 Modbus Serial Line bus coupler:

General Characteristics

The following table shows the characteristics of TM3 Modbus Serial Line bus coupler:

Characteristics Value

Connector insertion/removal durability Over 100 times

Supplied power available for connected inputs and outputs modules Current draw on 5 Vdc and 24 Vdc internal bus 600 mA max.

EIO0000003635 08/2020

Rotary Switch

Overview

The two rotary switches located on the front panel of the TM3 Modbus Serial Line bus coupler are used to set the serial line baud rate and to set the serial line address.

Default values on the rotary switches are:

 0 for TENS  0 for ONES

TM3 Modbus Serial Line Bus Coupler

(TENS) Set the baud rate/represents the tens numbered 0 to 120. (ONES) Authorize to set the baud rate when set to not used position/represents the numbers 0 to 9.

Setting the Baud rate

The TM3 Modbus Serial Line bus coupler detects a new baud rate selection by the rotary switches only during power up. The baud rate is written to non-volatile memory.

Set the ONES rotary switch to any of the unnumbered positions (not used) to set a particular baud rate with the TENS rotary switch.

NOTE: Any modification of the rotary switch position during operational mode is not taken into account. The ERR LED flashes red. See status LEDs

(see page 79)

table.

NOTE: Baud rate can also be set and verified via the web server. If you use EcoStruxure Machine Expert - Basic, refer to the Modicon TM3 Bus Coupler (EcoStruxure Machine Expert - Basic) -

Programming Guide. If you use EcoStruxure Machine Expert, refer to the Modicon TM3 Bus

Coupler - Programming Guide.

EIO0000003635 08/2020 81

TM3 Modbus Serial Line Bus Coupler

To set the baud rate, follow the steps below:

Step Action Comment

1 Remove power to the bus coupler. The bus coupler detects the changes only at the next

2 With a 2 mm or 2,5 mm slotted (flathead)

screwdriver, set the ONES rotary switch to any of the unnumbered positions (not used).

NOTE: Rotary switch is designed to be

torqued normally by hand. Axial force must be inferior to 2 N.

3 With a 2 mm or 2,5 mm slotted (flathead), set

the TENS rotary switch to the position that corresponds to your selected baud rate.

4 Apply power to the bus coupler. The bus coupler reads the rotary switch settings only

5 Wait for the COM and the ERR LEDs to flash

3 times, then remain solid.

6 Remove power to the bus coupler and set the

serial line address using the rotary switches, as described below in Setting the Serial Line address

(see page 83)

power up cycle.

Setting the rotary switch to any of these unnumbered positions prepares the bus coupler to accept a new baud rate.

Use the baud rate selection table below to determine the position of the rotary switch.

during power up.

The bus coupler has written the new baud rate setting to memory.

The baud rate has been established for the bus coupler. It must be followed by the address setting to operate.

Baud Rate Selection Table

The following table shows the rotary switch positions and the baud rate:

Position TENS rotary switch baud rate

0 19200 bps (default)

1 1200 bps

2 2400 bps

3 4800 bps

4 9600 bps

5 19200 bps

6 38400 bps

7 57600 bps

8 115200 bps

9...12 Not used

NOTE: Setting the TENS rotary s witch be tween 9 a nd 12 and unnumbered part generates an error detected at the next power up.

EIO0000003635 08/2020

Baud Rate Setting Example

The following figure shows an example when the serial line baud rate is configured to 19200 bps.

(TENS) Set to 5 to configure the serial line baud rate to 19200 bps. (ONES) Set to the not used position to authorize the baud rate setting.

Setting the Serial Line Address

The TM3 Modbus Serial Line bus coupler address (from 1 to 127, decimal) is configured using the two serial line address settings rotary switches.

TM3 Modbus Serial Line Bus Coupler

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not use an address outside of the specified range (from 1 to 127).

Failure to follow these instructions can result in death, serious injury, or equipment damage.

To reset the bus coupler, remove power and provide a correct address before reapplying power to the bus coupler.

Set the serial line address using the TENS rotary switch to represent the hundreds and tens digits and the ONES rotary switch to represent the units digits.

EIO0000003635 08/2020 83

TM3 Modbus Serial Line Bus Coupler

Carefully manage the addresses because each device on the network requires a unique address. Having multiple devices with the same address can cause unintended operation of your network and associated equipment.

UNINTENDED EQUIPMENT OPERATION

 Do not connect the serial line cable and apply power to the TM3 Modbus Serial Line Bus

Coupler on a serial line that is operational (other devices connected in an ongoing control scheme) unless you first set the appropriate, unique address for the Bus Coupler.

 Assure that unique Modbus addresses are assigned to the TM3 Modbus Serial Line Bus

Coupler, and that those addresses are also unique from all other devices connected to the serial line.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Serial Line Address Setting Example

The following figure shows an example when the serial line address is set to 115:

WARNING

(TENS) Represents the tens numbered 0 to 120, set to 110. (ONES) Represents the numbers 0 to 9, set to 5.

EIO0000003635 08/2020

Serial Line Port

Overview

The TM3 Modbus Serial Line bus coupler is equipped with two isolated RJ45 ports (CN1, CN2) enabling easy daisy-chain configuration, as shown in following graphic:

TM3 Modbus Serial Line Bus Coupler

* You can connect a maximum of 32 Modbus devices. The last device must be terminated by terminating

resistor.

Characteristics

This table describes the serial line characteristics:

Characteristic Description

Function Serial line, Modbus, TIA-485

Connector type RJ45

Cable type Shielded

Topology Bus Type

EIO0000003635 08/2020 85

TM3 Modbus Serial Line Bus Coupler

Pin Assignment

This graphic shows the RJ45 (RS-485) connector pin assignment:

This table describes the RJ45 (RS-485) connector pins:

Pin N° Signal Description

1 N.C. No Connection

2 N.C. No Connection

3 N.C. No Connection

4 D1 Transmit/receive data Low

5 D0 Transmit/receive data High

6 N.C. No Connection

7 N.C. No Connection

8 C Common

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not connect wires to unused terminals and/or terminals indicated as “No Connection (N.C.)”.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

EIO0000003635 08/2020

TM3 Modbus Serial Line Bus Coupler

Connecting the TM3 Modbus Serial Line Bus Coupler to a PC

Overview

You can connect the TM3 Modbus Serial Line bus coupler to a PC through the USB port.

USB Mini-B Port Connection

USB-B port is dedicated for firmware update, configuration download and web server access.

TCSXCNAMUM3P: This USB cable is suitable for short duration connections such as quick

updates or retrieving data values.

NOTE: You can only connect one TM3 bus coupler or any other device associated with EcoStruxure Machine Expert and its component to the PC at any one time.

WARNING

UNINTENDED EQUIPMENT OPERATION OR INOPERABLE EQUIPMENT

 You must use a shielded USB cable such as a BMX XCAUSBH0•• secured to the functional

ground (FE) of the system for any long-term connection.

 Do not connect more than one controller or bus coupler at a time using USB connections.  Do not use the USB port(s), if so equipped, unless the location is known to be non-hazardous.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

The communication cable should be connected to the PC first to minimize the possibility of electrostatic discharge affecting the TM3 Modbus Serial Line bus coupler.

The following illustration shows the USB connection to a PC:

EIO0000003635 08/2020 87

TM3 Modbus Serial Line Bus Coupler

To connect the USB cable to your TM3 Modbus Serial Line bus coupler, follow the steps below:

Step Action

1 1a If making a long-term connection using the cable BMXXCAUSBH018, or other cable with a

1b If making a short-term connection using the cable TCSXCNAMUM3P or other non-grounded

USB cable, proceed to step 2.

2 Connect your USB cable to the PC.

3 Connect the Mini connector of your USB cable to the TM3 Modbus Serial Line bus coupler USB

connector.

EIO0000003635 08/2020

Modicon TM3 Bus Coupler

TM3 CANopen Bus Coupler

EIO0000003635 08/2020

TM3 CANopen Bus Coupler

Chapter 5

TM3 CANopen Bus Coupler

What Is in This Chapter?

This chapter contains the following topics:

TM3 CANopen Bus Coupler Presentation 90

TM3 CANopen Bus Coupler Characteristics 93

Rotary Switch 94

CANopen Port 98

Connecting the TM3 CANopen Bus Coupler to a PC 100

Topic Page

EIO0000003635 08/2020 89

TM3 CANopen Bus Coupler

TM3 CANopen Bus Coupler Presentation

Overview

The TM3 CANopen bus coupler is a device designed to manage CANopen communication when using TM2/TM3 I/O expansion modules in a distributed architecture.

The main elements of the TM3 CANopen bus coupler are:

1 Rotary switches 2 Expansion connector for TM2/TM3 I/O expansion modules 3 Two (2) isolated RJ45 CANopen ports (daisy-chained) 4 USB mini-B configuration port 5 24 Vdc power supply 6 Clip-on lock for 35 mm ( 7 Status LEDs

Main Characteristics

Characteristic Value

Nominal supply voltage 24 Vdc

Weight 100 g (3.53 oz)

Rotary switch 2

CANopen port 2 isolated RJ45 ports for CANopen (daisy-chained).

Power supply connection type Removable screw terminal block

1.38 in.

) top hat section rail (DIN rail)

EIO0000003635 08/2020

Status LEDs

The following graphic shows the LEDs of TM3 CANopen bus coupler:

The following table describes the status LEDs:

LED Color Status Description

PWR Green On Power is applied.

RUN Green On Device status is operational.

ERR Red On Bus off.

TM3 CANopen Bus Coupler

Off Power is removed. All LED indicators are off.

Flickering In conjunction with a flickering ERR LED, automatic

search for the bus communication speed.

Flashing Device status is pre-operational.

Single flash Device status is stopped.

Triple flash Firmware upgrade

Flickering In conjunction with a flickering RUN LED, automatic

search for the bus communication speed.

Flashing Invalid CANopen stack configuration

Single flash An internal error counter in the CAN controller has

reached or exceeded the error frame limit threshold (error frame).

Double flash Error control event detected. Detection of a guard

event (NMT-Slave or NMT-master) or a heartbeat event (Heartbeat consumer).

Triple flash Synchronization error detected: message not received

from sync producer within the defined period.

Quadruple flash Event-timer error detected: An expected PDO has not

been received before the event-timer elapsed

Off No error detected.

EIO0000003635 08/2020 91

TM3 CANopen Bus Coupler

LED Color Status Description

I/O Green Flashing Device has received and applied the expansion

Red Single flash Expansion module configuration transfer timeout

Green Red

This timing diagram shows the different LEDs flashing behaviors:

modules configuration.

On Device is communicating with the expansion modules.

Flashing On

On On

On Flashing

Off No configuration. Device is not communicating with the

The physical configuration is inconsistent with the software configuration. No data exchange (status and I/O) is occurring

The physical configuration is inconsistent with the software configuration. I/O data is not applied.

At least one TM2 or TM3 expansion module did not respond to the bus coupler for 10 consecutive cycles.

expansion modules.

NOTE: With the exception of the PWR LED, each LED is ON for a few seconds, then OFF during the boot sequence. The LED behavior rules apply when the boot is completed successfully.

EIO0000003635 08/2020

TM3 CANopen Bus Coupler Characteristics

Introduction

This section provides a general description of the characteristics of the TM3 CANopen bus coupler.

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not exceed any of the rated values specified in the environmental and electrical characteristics tables.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

Dimensions

The following graphic shows the external dimensions for the TM3 CANopen bus coupler:

TM3 CANopen Bus Coupler

General Characteristics

The following table shows the characteristics of TM3 CANopen bus coupler:

Characteristics Value

Connector insertion/removal durability Over 100 times

Supplied power available for connected inputs and outputs modules Current draw on 5 Vdc and 24 Vdc internal bus 600 mA max.

EIO0000003635 08/2020 93

TM3 CANopen Bus Coupler

Rotary Switch

Overview

The two rotary switches located on the front panel of the TM3 CANopen bus coupler are used to set the CANopen bit rate and CANopen NodeID.

Default values on the rotary switches are:

 0 for TENS  0 for ONES

(TENS) Set the bit rate/represents the tens numbered 0 to 120. (ONES) Authorize to set the bit rate when set to not used position/represents the numbers 0 to 9.

Setting the Bit Rate

The TM3 CANopen bus coupler detects a new bit rate selection by the rotary switches only during power up. The bit rate is written to non-volatile memory.

Set the ONES rotary switch to any of the unnumbered positions (not used) to set a particular bit rate with the TENS rotary switch.

NOTE: Any modification of the rotary switch position during operational mode is not taken into account. The ERR LED flashes red. See status LEDs

Bit rate can also be set and verified via the web server. For more information, refer to the Modicon TM3 Bus Coupler Programming Guide.

(see page 91)

table.

EIO0000003635 08/2020

To set the bit rate, follow the steps below:

Step Action Comment

1 Remove power to the bus coupler. The bus coupler detects the changes only at

2 With a 2 mm or 2,5 mm slotted (flathead)

screwdriver, set the ONES rotary switch to any of the unnumbered positions (not used).

NOTE: Rotary switch is designed to be torqued

normally by hand. Axial force must be inferior to 2 N.

3 With a 2 mm or 2,5 mm slotted (flathead), set the

TENS rotary switch to the position that corresponds to your selected bit rate.

4 Apply power to the bus coupler. The bus coupler reads the rotary switch

5 Wait for the RUN and the ERR LEDs to flash

3 times, then remain solid.

6 Remove power to the bus coupler and set the

CANopen address using the rotary switches, as described below in Setting the CANopen address

(see page 96)

Bit-rate Selection Table

The following table shows the rotary switch positions and the bit rate:

TM3 CANopen Bus Coupler

the next power up cycle.

Setting the rotary switch to any of these unnumbered positions prepares the bus coupler to accept a new bit rate.

Use the bit rate selection table below to determine the position of the rotary switch.

settings only during power up.

The bus coupler has written the new bit rate setting to memory.

The bit rate has been established for the bus coupler. It must be followed by the address setting to operate.

Position TENS rotary switch Bit rate

0 Not used

1 20 kbits/s

2 50 kbits/s

3125kbits/s

4250kbits/s

5500kbits/s

6800kbits/s

71Mbits/s

8 Automatic bit-rate detection

9250kbits/s

(default value)

10...12 Not used

NOTE: Setting the TENS rotary switch between 10 and 12 and unnumbered part will generate an error detected at the next power on.

EIO0000003635 08/2020 95

TM3 CANopen Bus Coupler

CANopen Bit Rate Setting Example

The following figure shows an example when the bit rate is configured to 500 kbits/s:

(TENS) Set to 5 to configure the bit rate to 500 kbits/s. (ONES) Set to the not used position to authorize the bit rate setting.

Setting the CANopen Address

The TM3 CANopen bus coupler address (from 1 to 127, decimal) is configured using the two CANopen address settings rotary switches.

WARNING

UNINTENDED EQUIPMENT OPERATION

Do not use an address outside of the specified range (from 1 to 127).

Failure to follow these instructions can result in death, serious injury, or equipment damage.

To reset the CANopen bus coupler, remove power and provide a correct address before reapplying power to the bus coupler.

Set the CANopen address using the TENS rotary switch to represent the hundreds and tens digit and the ONES rotary switch to represent the units digit.

EIO0000003635 08/2020

UNINTENDED EQUIPMENT OPERATION

 Do not connect the CANopen cable and apply power to the TM3 CANopen Bus Coupler on

network that is operational (other devices connected in an ongoing control scheme) unless you first set the appropriate, unique address for the Bus Coupler.

 Assure that unique CANopen addresses are assigned to the TM3 CANopen Bus Coupler, and

that those addresses are also unique from all other devices connected to the network.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

CANopen Address Setting Example

The following figure shows an example when the CANopen address is set to 115:

TM3 CANopen Bus Coupler

WARNING

(TENS) Represents the tens, numbered 0 to 120, set to 110. (ONES) Represents the numbers 0 to 9, set to 5.

EIO0000003635 08/2020 97

TM3 CANopen Bus Coupler

CANopen Port

Overview

The TM3 CANopen bus coupler is equipped with two isolated RJ45 ports (CN1, CN2) enabling easy daisy-chain configuration, as shown in following graphic:

* You can connect a maximum of 64 CANopen devices, master inclusive, without use of a repeater. Both

ends of the CAN bus must be terminated by terminating resistor.

Characteristics

This table describes the CANopen characteristics:

Characteristic Description

Function CANopen

Connector type RJ45

Cable type Shielded

Topology Bus type

EIO0000003635 08/2020

Pin Assignment

This graphic shows the RJ45 CANopen connector pin assignment:

This table describes the RJ45 CANopen connector pins:

Pin N° Signal Description

1 CAN_H CAN_H bus line (High)

2 CAN_L CAN_L bus line (Low)

3 CAN_GND CAN 0 Vdc

4 N.C. No Connection

5 N.C. No Connection

6 N.C. No Connection

7 N.C. No Connection

8 N.C. No Connection

For more detailed information, refer to the CANopen Hardware Setup Manual.

TM3 CANopen Bus Coupler

EIO0000003635 08/2020 99

TM3 CANopen Bus Coupler

Connecting the TM3 CANopen Bus Coupler to a PC

Overview

You can connect the TM3 CANopen bus coupler to a PC through the USB port.

USB Mini-B Port Connection

USB-B port is dedicated for firmware update, configuration download and web server access.

TCSXCNAMUM3P: This USB cable is suitable for short duration connections such as quick

updates or retrieving data values.

NOTE: You can only connect one TM3 bus coupler or any other device associated with EcoStruxure Machine Expert and its component to the PC at any one time.

WARNING

UNINTENDED EQUIPMENT OPERATION OR INOPERABLE EQUIPMENT

 You must use a shielded USB cable such as a BMX XCAUSBH0•• secured to the functional

ground (FE) of the system for any long-term connection.

 Do not connect more than one controller or bus coupler at a time using USB connections.  Do not use the USB port(s), if so equipped, unless the location is known to be non-hazardous.

Failure to follow these instructions can result in death, serious injury, or equipment damage.

100

The communication cable should be connected to the PC first to minimize the possibility of electrostatic discharge affecting the TM3 CANopen bus coupler.

The following illustration shows the USB connection to a PC:

EIO0000003635 08/2020

Schneider Electric TM3 Hardware Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

ModiconTM3 Bus Coupler

Table of Contents

Safety Information

About the Book

General Overview

TM3 Bus Couplers General Description

Maximum Hardware Configuration

TM3 General Description

TM2 General Description

Accessories

TM3 Bus Coupler Installation

TM3 Bus Coupler General Rules for Implementing

Environmental Characteristics

Certifications and Standards

TM3 Bus Coupler Installation

Installation and Maintenance Requirements

Installation Guidelines

Top Hat Section Rail (DIN rail)

Assembling a Module to a Modicon TM3 Bus Coupler

Disassembling a Module from a Modicon TM3 Bus Coupler

Direct Mounting on a Panel Surface

TM3 Electrical Requirements

Wiring Best Practices

DC Power Supply Characteristics and Wiring

Grounding the TM3 System

TM3 Ethernet Bus Coupler

TM3 Ethernet Bus Coupler Presentation

TM3 Ethernet Bus Coupler Characteristics

Rotary Switch

Ethernet Port

Connecting the Modicon TM3 Bus Coupler to a PC

TM3 Modbus Serial Line Bus Coupler

TM3 Modbus Serial Line Bus Coupler Presentation

TM3 Modbus Serial Line Bus Coupler Characteristics

Rotary Switch

Serial Line Port

Connecting the TM3 Modbus Serial Line Bus Coupler to a PC

TM3 CANopen Bus Coupler

TM3 CANopen Bus Coupler Presentation

TM3 CANopen Bus Coupler Characteristics

Rotary Switch

CANopen Port

Connecting the TM3 CANopen Bus Coupler to a PC
