Schneider Electric SSLM1A13M7 Data Sheet
Product data sheet
Characteristics
SSLM1A13M7
solid state relay - DIN rail mount - input 90-280 V
AC, output 12-280 V AC, 3A
Main
Range of product Zelio Relay
Product or component type Solid state relay
Device short name SSLM
Phase 1 phase
Complementary
Mounting support Symmetrical DIN rail
Line Rated Current 3 A
Output voltage 12...280 V AC
[Uc] control circuit voltage 90...280 V AC
Contacts type and configuration 1 NO
Tightening torque 0.6...0.8 N.m
Connections - terminals Screw terminals : 1 x 0.2...1 x 5.26 mm² (AWG 24...AWG 10)
Switching voltage 90 V AC turn-on
Load current 0.1...3 A
Voltage drop <= 1.65 V on-state
Leakage current <= 5 mA off-state
Overvoltage category III
Width 0.3 in (7.5 mm)
Height 3.15 in (80 mm)
Depth 2.48 in (63 mm)
Product weight 0.07 lb(US) (0.03 kg)
Environment
Dielectric strength 4000 V for input/output
Aug 23, 2019
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Pollution degree 2
Product certifications UL
Marking UL
Ambient air temperature for operation 32...158 °F (0...70 °C)
EAC
CSA
CSA
EAC
CE
Ordering and shipping details
Category 21127 - ZELIO ICE CUBE RELAYS
Discount Schedule CP2
GTIN 00785901084907
Nbr. of units in pkg. 12
Package weight(Lbs) 7.0000000000000007E-2
Returnability N
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 1522 - Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Product environmental profile Available
Product end of life instructions Available
California proposition 65 WARNING: This product can expose you to chemicals including:
- - - - - - - Substance 1 Nickel compounds, which is known to the State of California to cause cancer, and
- - - - - - - Substance 2 Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
- - - - - - - More information For more information go to www.p65warnings.ca.gov
reproductive harm.
