Page 1
Spec-00288
SPECIFICATIONS
Bulletin: A12
F
763.422.2211
763.422.2600
MILD STEEL
Wall-Mount EnclosurEs
typE 12 EnclosurEs
CONTINUOUS HINGE WITH CLAMPS, TYPE 12
INDUSTRY STANDARDS
UL 508A Listed; Type 12, 13; File No. E61997
cUL Listed per CSA C22.2 No. 94; Type 12, 13; File No. E61997
NEMA /EEMAC Type 12 and 13
CSA, File No. 42186: Type 12
IEC 60529, IP65
APPLICATION
For applications requiring a bright white interior to increase control
visibility, this enclosure includes a padlocking hasp and staple for
security and screw-down clamps for secure closure.
WALLMOUNT ENCLOSURES Type 12 enclosures
• 16 or 14 gauge steel
• Seams continuously welded and ground smooth
• External welded-on mounting brackets for easy installation
• Formed external return flanges around all sides of enclosure
opening
• Screw-down door clamps
• Removable heavy-gauge continuous hinge pin
• Hasp and staple for padlocking
• Data pocket is high-impact thermoplastic
• Collar studs for mounting optional panels
• Bonding provision on door
• Removable door with continuous hinge
• Oil-resistant gasket
FINISH
White inside with ANSI 61 gray finish outside.
ACCESSORIES
See also Accessories.
Drip Shield Kit for Type 12 Enclosures
Electric Heater
Fast-Operating Clamp Assembly
Compact Cooling Fans
Steel and Stainless Steel Window Kits
See also the Popular Cooling and Accessories tables forllowing the
Standard Product table.
MODIFICATION AND CUSTOMIZATION
Hoffman excels at modifying and customizing products to your
specifications. Contact your local Hoffman sales office or distributor
for complete information.
Standard Product
Catalog Number
A122406LP 12.00 x 24.00 x 6.00
A161206LP 16.00 x 12.00 x 6.00
A161606LP 16.00 x 16.00 x 6.00
A162006LP 16.00 x 20.00 x 6.00
A201206LP 20.00 x 12.00 x 6.00
A201606LP 20.00 x 16.00 x 6.00
A202006LP 20.00 x 20.00 x 6.00
A202406LP 20.00 x 24.00 x 6.00
A241206LP 24.00 x 12.00 x 6.00
A241606LP 24.00 x 16.00 x 6.00
A242006LP 24.00 x 20.00 x 6.00
A242406LP 24.00 x 24.00 x 6.00
A301606LP 30.00 x 16.00 x 6.00
A302006LP 30.00 x 20.00 x 6.00
A302406LP 30.00 x 24.00 x 6.00
A362406LP 36.00 x 24.00 x 6.00
A363006LP 36.00 x 30.00 x 6.00
A122408LP 12.00 x 24.00 x 8.00
A161208LP 16.00 x 12.00 x 8.00
A161608LP 16.00 x 16.00 x 8.00
AxBxC in./mm Body Gauge Panel
305 x 610 x 152
406 x 305 x 152
406 x 406 x 152
406 x 508 x 152
508 x 305 x 152
508 x 406 x 152
508 x 508 x 152
508 x 610 x 152
610 x 305 x 152
610 x 406 x 152
610 x 508 x 152
610 x 610 x 152
762 x 406 x 152
762 x 508 x 152
762 x 610 x 152
914 x 610 x 152
914 x 762 x 152
305 x 610 x 203
406 x 305 x 203
406 x 406 x 203
Conductive
Panel
16 A12P24 A12P24G 9.00 x 21.00
16 A16P12 A16P12G 13.00 x 9.00
16 A16P16 A16P16G 13.00 x 13.00
16 A20P16 A20P16G 17.00 x 13.00
16 A20P12 A20P12G 17.00 x 9.00
16 A20P16 A20P16G 17.00 x 13.00
16 A20P20 A20P20G 17.00 x 17.00
16 A24P20 A24P20G 21.00 x 17.00
16 A12P24 A12P24G 9.00 x 21.00
16 A24P16 A24P16G 21.00 x 13.00
16 A24P20 A24P20G 21.00 x 17.00
16 A24P24 A24P24G 21.00 x 21.00
14 A30P16 A30P16G 27.00 x 13.00
14 A30P20 A30P20G 27.00 x 17.00
14 A30P24 A30P24G 27.00 x 21.00
14 A36P24 A36P24G 33.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
16 A12P24 A12P24G 9.00 x 21.00
16 A16P12 A16P12G 13.00 x 9.00
16 A16P16 A16P16G 13.00 x 13.00
Panel Size
D x E
in./mm
229 x 533
330 x 229
330 x 330
432 x 330
432 x 229
432 x 330
432 x 432
533 x 432
229 x 533
533 x 330
533 x 432
533 x 533
686 x 330
686 x 432
686 x 533
838 x 533
838 x 686
229 x 533
330 x 229
330 x 330
F
in./mm
3.00
76
1.25
32
3.00
76
3.00
76
1.25
32
3.00
76
3.00
76
3.00
76
1.25
32
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
1.25
32
3.00
76
Number
of Clamps
Data
Pocket
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Large
2 Large
2 Large
2 Small
2 Small
2 Small
EQUIPMENT PROTECTIONSUBJECT TO CHA NGE WITHOUT NOTICEMILD STEEL1
Spec-00288 F
Page 2
WALLMOUNT ENCLOSURES Type 12 enclosures
Catalog Number
A162008LP 16.00 x 20.00 x 8.00
A201208LP 20.00 x 12.00 x 8.00
A201608LP 20.00 x 16.00 x 8.00
A202008LP 20.00 x 20.00 x 8.00
A202408LP 20.00 x 24.00 x 8.00
A241208LP 24.00 x 12.00 x 8.00
A241608LP 24.00 x 16.00 x 8.00
A242008LP 24.00 x 20.00 x 8.00
A242408LP 24.00 x 24.00 x 8.00
A243008LP 24.00 x 30.00 x 8.00
A302008LP 30.00 x 20.00 x 8.00
A302408LP 30.00 x 24.00 x 8.00
A303008LP 30.00 x 30.00 x 8.00
A303608LP 30.00 x 36.00 x 8.00
A362408LP 36.00 x 24.00 x 8.00
A363008LP 36.00 x 30.00 x 8.00
A363608LP 36.00 x 36.00 x 8.00
A422408LP 42.00 x 24.00 x 8.00
A423008LP 42.00 x 30.00 x 8.00
A423608LP 42.00 x 36.00 x 8.00
A482408LP 48.00 x 24.00 x 8.00
A483008LP 48.00 x 30.00 x 8.00
A483608LP 48.00 x 36.00 x 8.00
A603608LP 60.00 x 36.00 x 8.00
A161210LP 16.00 x 12.00 x 10.00
A201610LP 20.00 x 16.00 x 10.00
A202010LP 20.00 x 20.00 x 10.00
A241210LP 24.00 x 12.00 x 10.00
A242010LP 24.00 x 20.00 x 10.00
A242410LP 24.00 x 24.00 x 10.00
A302010LP 30.00 x 20.00 x 10.00
A302410LP 30.00 x 24.00 x 10.00
A362410LP
A363010LP 36.00 x 30.00 x 10.00
A423010LP 42.00 x 30.00 x 10.00
A423610LP 42.00 x 36.00 x 10.00
A483010LP 48.00 x 30.00 x 10.00
A483610LP 48.00 x 36.00 x 10.00
A603610LP 60.00 x 36.00 x 10.00
AxBxC in./mm Body Gauge Panel
406 x 508 x 203
508 x 305 x 203
508 x 406 x 203
508 x 508 x 203
508 x 610 x 203
610 x 305 x 203
610 x 406 x 203
610 x 508 x 203
610 x 610 x 203
610 x 762 x 203
762 x 508 x 203
762 x 610 x 203
762 x 762 x 203
762 x 914 x 203
914 x 610 x 203
914 x 762 x 203
914 x 914 x 203
1067 x 610 x 203
1067 x 762 x 203
1067 x 914 x 203
1219 x 610 x 203
1219 x 762 x 203
1219 x 914 x 203
1524 x 914 x 203
406 x 305 x 254
508 x 406 x 254
508 x 508 x 254
610 x 305 x 254
610 x 508 x 254
610 x 610 x 254
762 x 508 x 254
762 x 610 x 254
36.00 x 24.00 x 10.00
914 x 610 x 254
914 x 762 x 254
1067 x 762 x 254
1067 x 914 x 254
1219 x 762 x 254
1219 x 914 x 254
1524 x 914 x 254
Conductive
Panel
16 A20P16 A20P16G 17.00 x 13.00
16 A20P12 A20P12G 17.00 x 9.00
16 A20P16 A20P16G 17.00 x 13.00
16 A20P20 A20P20G 17.00 x 17.00
16 A24P20 A24P20G 21.00 x 17.00
16 A12P24 A12P24G 9.00 x 21.00
16 A24P16 A24P16G 21.00 x 13.00
14 A24P20 A24P20G 21.00 x 17.00
16 A24P24 A24P24G 21.00 x 21.00
14 A30P24G A30P24G 27.00 x 21.00
14 A30P20 A30P20G 27.00 x 17.00
14 A30P24 A30P24G 27.00 x 21.00
14 A30P30 A30P30G 27.00 x 27.00
14 A36P30 A36P30G 33.00 x 27.00
14 A36P24 A36P24G 33.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
14 A36P36 A36P36G 33.00 x 33.00
14 A42P24 A42P24G 39.00 x 21.00
14 A42P30 A42P30G 39.00 x 27.00
14 A42P36 A42P36G 39.00 x 33.00
14 A48P24 A48P24G 45.00 x 21.00
14 A48P30 A48P30G 45.00 x 27.00
14 A48P36 A48P36G 45.00 x 33.00
14 A60P36 A60P36G 57.00 x 33.00
14 A16P12 A16P12G 13.00 x 9.00
14 A20P16 A20P16G 17.00 x 13.00
14 A20P20 A20P20G 17.00 x 17.00
14 A12P24 A12P24G 9.00 x 21.00
14 A24P20 A24P20G 21.00 x 17.00
14 A24P24G A24P24G 21.00 x 21.00
14 A30P20 A30P20G 27.00 x 17.00
14 A30P24 A30P24G 27.00 x 21.00
14 A36P24 A36P24G 33.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
14 A42P30 A42P30G 39.00 x 27.00
14 A42P36 A42P36G 39.00 x 33.00
14 A48P30 A48P30G 45.00 x 27.00
14 A48P36 A48P36G 45.00 x 33.00
14 A60P36 A60P36G 57.00 x 33.00
Panel Size
D x E
in./mm
432 x 330
432 x 229
432 x 330
432 x 432
533 x 432
229 x 533
533 x 330
533 x 432
533 x 533
686 x 533
686 x 432
686 x 533
686 x 686
838 x 686
838 x 533
838 x 686
838 x 838
991 x 533
991 x 686
991 x 838
1143 x 533
1143 x 686
1143 x 838
1448 x 838
330 x 229
432 x 330
432 x 432
229 x 533
533 x 432
533 x 533
686 x 432
686 x 533
838 x 533
838 x 686
991 x 686
991 x 838
1143 x 686
1143 x 838
1448 x 838
F
in./mm
3.00
76
1.25
32
3.00
76
3.00
76
3.00
76
1.25
32
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
1.25
32
3.00
76
3.00
76
1.25
32
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
Number
of Clamps
Data
Pocket
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Large
2 Large
2 Large
2 Large
2 Large
2 Large
2 Large
2 Small
2 Large
3 Large
3 Small
3 Large
3 Large
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Small
2 Large
2 Large
2 Large
2 Small
2 Large
3 Small
3 Large
3 Large
EQUIPMENT PROTECTION MILD STEEL 2
Spec-00288 F
Page 3
WALLMOUNT ENCLOSURES Type 12 enclosures
Catalog Number
A201612LP 20.00 x 16.00 x 12.00
A242012LP 24.00 x 20.00 x 12.00
A242412LP 24.00 x 24.00 x 12.00
A302412LP 30.00 x 24.00 x 12.00
A303012LP 30.00 x 30.00 x 12.00
A362412LP 36.00 x 24.00 x 12.00
A363012LP 36.00 x 30.00 x 12.00
A363612LP 36.00 x 36.00 x 12.00
A423012LP 42.00 x 30.00 x 12.00
A423612LP 42.00 x 36.00 x 12.00
A483612LP 48.00 x 36.00 x 12.00
A603612LP 60.00 x 36.00 x 12.00
A723612LP 72.00 x 36.00 x 12.00
A242016LP 24.00 x 20.00 x 16.00
A242416LP 24.00 x 24.00 x 16.00
A302416LP 30.00 x 24.00 x 16.00
A363016LP 36.00 x 30.00 x 16.00
A423616LP 42.00 x 36.00 x 16.00
A483616LP 48.00 x 36.00 x 16.00
A603616LP 60.00 x 36.00 x 16.00
A302420LP 30.00 x 24.00 x 20.00
A363020LP 36.00 x 30.00 x 20.00
A483620LP 48.00 x 36.00 x 20.00
A603620LP 60.00 x 36.00 x 20.00
A302424LP 30.00 x 24.00 x 24.00
AxBxC in./mm Body Gauge Panel
508 x 406 x 305
610 x 508 x 305
610 x 610 x 305
762 x 610 x 305
762 x 762 x 305
914 x 610 x 305
914 x 762 x 305
914 x 914 x 305
1067 x 762 x 305
1067 x 914 x 305
1219 x 914 x 305
1524 x 914 x 305
1829 x 914 x 305
610 x 508 x 406
610 x 610 x 406
762 x 610 x 406
914 x 762 x 406
1067 x 914 x 406
1219 x 914 x 406
1524 x 914 x 406
762 x 610 x 508
914 x 762 x 508
1219 x 914 x 508
1524 x 914 x 508
762 x 610 x 610
14 A20P16 A20P16G 17.00 x 13.00
14 A24P20 A24P20G 21.00 x 17.00
14 A24P24 A24P24G 21.00 x 21.00
14 A30P24 A30P24G 27.00 x 21.00
14 A30P30 A30P30G 27.00 x 27.00
14 A36P24 A36P24G 33.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
14 A36P36 A36P36G 33.00 x 33.00
14 A42P30 A42P30G 39.00 x 27.00
14 A42P36 A42P36G 39.00 x 33.00
14 A48P36 A48P36G 45.00 x 33.00
14 A60P36 A60P36G 57.00 x 33.00
14 A72P36 A72P36G 69.00 x 33.00
14 A24P20 A24P20G 21.00 x 17.00
14 A24P24 A24P24G 21.00 x 21.00
14 A30P24 A30P24G 27.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
14 A42P36 A42P36G 39.00 x 33.00
14 A48P36 A48P36G 45.00 x 33.00
14 A60P36 A60P36G 57.00 x 33.00
14 A30P24 A30P24G 27.00 x 21.00
14 A36P30 A36P30G 33.00 x 27.00
14 A48P36 A48P36G 45.00 x 33.00
14 A60P36 A60P36G 57.00 x 33.00
14 A30P24 A30P24G 27.00 x 21.00
Conductive
Panel
Purchase panels separately. Optional stainless steel, conductive, composite and aluminum panels are available for most sizes.
Small Data Pocket is 6.00 in. x 6.00 in. Large Data Pocket is 12.00 in. x 12.00 in.
Panel Size
D x E
in./mm
432 x 330
533 x 432
533 x 533
686 x 533
686 x 686
838 x 533
838 x 686
838 x 838
991 x 686
991 x 838
1143 x 838
1448 x 838
1753 x 838
533 x 432
533 x 533
686 x 533
838 x 686
991 x 838
1143 x 838
1448 x 838
686 x 533
838 x 686
1143 x 838
1448 x 838
686 x 533
F
in./mm
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
3.00
76
Number
of Clamps
Data
Pocket
2 Small
2 Small
2 Small
2 Large
2 Large
2 Large
2 Large
2 Large
2 Small
2 Large
3 Large
3 Large
3 Large
2 Small
2 Small
2 Large
2 Large
2 Large
3 Large
3 Large
2 Large
2 Large
3 Large
3 Large
2 Large
EQUIPMENT PROTECTIONSUBJECT TO CHA NGE WITHOUT NOTICEMILD STEEL3
Spec-00288 F
Page 4
WALLMOUNT ENCLOSURES Type 12 enclosures
Popular Cooling Products
Enclosure Depth (C Dimension) Filter Fans*
6 in. (152 mm) SF0416414
8 in. (203 mm) SF0516414
10 in. (254 mm) SF0916414
12 in. (305 mm) SF1016414
16 in. (406 mm) SF1316414
20 in. (508 mm) SF1316414
24 in. (610 mm) SF1316414
*Important: Visit tools.hoffmanonline.com/attachments to access our Cooling Selection Tool to determine the appropriate cooling solution for your application.
Popular Accessories
Enclosure Width (B Dimension)
12 in. (305 mm) LEDPUCK AS050 APWK53NF
16 in. (406 mm) LEDA2M35 AS050 APWK53NF
20 in. (508 mm) LED24V15 AS050 APWK53NF
24 in. (610 mm) LED24V15 AS050 APWK53NF
30 in. (762 mm) LED24V15 AS050 APWK53NF
36 in. (914 mm) LED24V15 AS050 APWK53NF
EQUIPMENT PROTECTION MILD STEEL 4
Spec-00288 F
Light Hole Seals
Window Kits
Loading...
