Schaub Lorenz SLUS335S2 User manual
NO FROST COMBI REFRIGERATOR
Freezer - Fridge
User manual
КОМБИ - ХОЛОДИЛЬНИК NO FROST
Морозильная и холодильная камера
Руководство по эксплуатации
SLUS335S2
EN
2
Index
BEFORE USING THE APPLIANCE .................................4
General warnings...................................................................... 4
Old and out-of-order fridges...................................................... 6
Safety warnings ........................................................................ 7
Installing and operating your fridge freezer .............................. 7
Before using your fridge freezer ............................................... 9
Information on No-Frost technology ......................................... 9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 10
USAGE INFORMATION .................................................. 12
Temperature settings ............................................................... 12
Warnings about temperature adjustments ............................... 12
Accessoires ............................................................................. 13
Ice tray ................................................................................. 13
EN
3
CLEANING AND MAINTENANCE .................................. 14
Defrosting ................................................................................ 15
Replacing the light bulb ........................................................... 15
Replacing LED lighting ............................................................ 15
ARRANGING FOOD IN THE APPLIANCE ..................... 16
Refrigerator compartment ........................................................ 16
Freezer compartment .............................................................. 17
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION ........................................................................ 22
Repositioning the door ............................................................. 22
BEFORE CALLING YOUR AFTER SALES SERVICE ... 23
TIPS FOR SAVING ENERGY .......................................... 26
EN
4
BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of
the appliance, it must be xed in accordance with the
instructions.
• If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for
a few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- staff kitchen areas in shops, ofces and other working
environments.
BEFORE USING THE APPLIANCE
- farm houses and by clients in hotels, motels and
other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
EN
5
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
EN
6
BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock
before discarding it, because children may get trapped
inside it and may cause an accident.
• Old fridges and freezers contain isolation material and
refrigerant with CFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
Disposal of your old appliance
This symbol on the product or package implies that the product
should not be treated as domestic waste. Instead, it should
be delivered to applicable waste collection places recycling
electrical and electronic equipment. You will contribute to
avoid potential negative results regarding environment and
human health, which will arise due to wrong waste procedure
for the product by ensuring that this product is annihilated
properly. Recycling materials will help natural resources be
preserved. For more detailed information regarding recycling
of this product, please contact local municipality, domestic
waste annihilation service or the shop you have purchased
the product.
Please ask your municipal authority about the disposal of the
WEEE reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before
installing and using your appliance. We are not
responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
• This appliance is produced to be used in homes and it
can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be
responsible for losses incurred.
• This appliance is produced to be used in houses and it is
only suitable for cooling / storing food. It is not suitable for
commercial or common use and/or for storing substances
BEFORE USING THE APPLIANCE
except for food. Our company is not responsible for losses
to be incurred in the contrary case.
Safety warnings
• Do not connect your fridge freezer to the mains electricity
supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow
children to play with the appliance or let them hang off the
door.
• Never touch the power cord/plug with wet hands as this
could cause a short circuit or electric shock.
• Do not place glass bottles or beverage cans in the icemaking compartment as they can burst as the contents
freeze.
• Do not place explosive or ammable material in your fridge
freezer. Place drinks with high alcohol content vertically in
the fridge compartment and make sure that their tops are
tightly closed.
• When removing ice from the ice-making compartment, do
not touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat icecream or ice cubes immediately after you have taken them
out of the ice-making compartment.
• Do not cover the body or top of fridge freezer with lace.
This affects the performance of your fridge freezer.
• Secure any accessories in the fridge freezer during
transportation to prevent damage to the accessories.
EN
7
Installing and operating your fridge freezer
Before starting to use your fridge freezer, you should pay
attention to the following points:
EN
8
BEFORE USING THE APPLIANCE
• The operating voltage for your fridge freezer is 220-240 V
at 50Hz.
• The plug must be accessible after installation.
• Your fridge freezer may have a smell when it is operated
for the rst time. This is normal and the smell will fade
away when your fridge freezer starts to cool.
• Before connecting your fridge freezer, ensure that the
information on the data plate (voltage and connected load)
matches that of the mains electricity supply. If in doubt,
consult a qualied electrician.
• Insert the plug into a socket with an efcient ground
connection. If the socket has no ground contact or the
plug does not match, we recommend that you consult a
qualied electrician for assistance.
• The appliance must be connected with a properly installed
fused socket. Power supply (AC) and voltage at the
operating point must match with the details on the name
plate of the appliance (name plate is located on the inside
left of the appliance).
• We do not accept responsibility for any damages that
occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to
direct sunlight.
• Your fridge freezer should never be used outdoors or
exposed to rain.
• Your appliance should be at least 50 cm away from stoves,
gas ovens and heater cores, and at least 5 cm away from
electrical ovens.
• When your fridge freezer is placed next to a deep freezer,
there should be at least 2 cm between them to prevent
humidity forming on the outer surface.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly, especially the interior,
before use (see Cleaning and Maintenance).
• The installation procedure into the kitchen unit is given
in the installation manual. This product is intended to be
used in proper kitchen units only.
• Use the adjustable front legs to make sure your appliance
is level and stable. You can adjust the legs by turning them
BEFORE USING THE APPLIANCE
in either direction. This should be done before placing food
in the fridge freezer.
• Before using your fridge freezer, wipe all parts with
a solution of warm water and a teaspoon of sodium
bicarbonate, then rinse with clean water and dry.
Place all parts in the fridge after cleaning.
• Install the plastic distance guide (the part with black vanes
at the rear) by turning it 90° (as shown in the gure) to
prevent the condenser from touching the wall.
• The fridge freezer should be placed against a wall with a
free space not exceeding 75 mm.
Before using your fridge freezer
• When using your fridge for the rst time, or after
transportation, keep it in an upright position for at least 3
hours before plugging into the mains. This allows efcient
operation and prevents damage to the compressor.
• Your fridge may have a smell when it is operated for the
rst time. This is normal and the smell will fade away when
your fridge starts to cool.
EN
9
Information on No-Frost technology
No-frost refrigerators differ from other static refrigerators in
their operating principle.
In normal fridges, the humidity entering the fridge due to
opening the door and the humidity inherent in the food causes
freezing in the freezer department. To defrost the frost and ice
in the freezer compartment, you are periodically required to
turn off the fridge, place the food that needs to be kept frozen
in a separately cooled container and remove the ice gathered
in the freezer department.
The situation is completely different in no-frost fridges. Dry
and cold air is blown into the fridge and freezer compartments
homogeneously and evenly from several points via a blower
fan. Cold air dispersed homogeneously and evenly between
the shelves cools all of your food equally and uniformly, thus
preventing humidity and freezing.
Therefore your no-frost fridge allows you ease of use, in
addition to its huge capacity and stylish appearance.
EN
10
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
A
2
3
4
5
11
12
10
9
8
6
B
7
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
A) Fridge compartment
B) Freezer compartment
1) Thermostat knob
2) Fridge shelves
3) Crisper cover
4) Crispers
5) Upper freezer baskets
6) Bottom freezer basket
7) Levelling feet
8) Freezer glass shelves
9) Bottle shelf
10) Door shelves
11) Ice tray
12) Egg holder
EN
11
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
EN
12
USAGE INFORMATION
Temperature settings
Cooling compartment
The thermostat ensures that the temperature settings in the cooling and
freezing compartments of your refrigerator
are controlled automatically. It may be used
to set to any value ranging from 1 to 6. As
you turn the thermostat setting knob from 1
to 6, the amount of cooling increases.
Cooling compartment thermostat knob:
5 - 6 : For more cooling.
3 - 5 : For normal use.
1 - 3 : For less cooling.
Warnings about temperature adjustments
• It is not recommended that you operate your fridge in environments
colder than 10°C in terms of its efciency.
• The thermostat should be set according to the frequency of door
openings and the quantity of food kept inside the fridge.
• When you rst switch on the appliance, you should ideally try to run
it without any food in for 24 hours and not open the door. If you need
to use it straight away, try not to put a large quantity of food inside.
• A 5 minute delay function is included to prevent damage to the
compressor of your fridge, when you unplug it and then plug it in
again to operate it, or when an energy breakdown occurs. Your fridge
will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals
stated in the standards, according to the climate class stated in the
information label. It is not recommended that your fridge is operated
in the environments which are out of the stated temperature intervals.
This will reduce the cooling
efciency of the fridge.
• This appliance is designed
for use at an ambient
temperature within the
16°C - 43°C range.
Climate
Class
T Between 16 and 43 (°C)
ST Between 16 and 38 (°C)
N Between 16 and 32 (°C)
SN Between 10 and 32 (°C)
Ambient Temperature oC
Thermostat knob
THE VARIOUS FUNCTION AND POSSIBILITIES
Accessoires
Ice tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely turned into ice, you can twist the tray
as shown below to remove the ice cubes.
Visual and text descriptions on the accessories section may
vary according which model you have.
EN
13
EN
14
CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before
cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and
other electrical components.
• The refrigerator should be cleaned periodically using a
solution of bicarbonate of soda and lukewarm water.
• Clean the accessories separately with
soap and water Do not clean them in the
dishwasher.
• Do not use abrasive products, detergents or soaps. After
washing, rinse with clean water and dry carefully. When
you have nished cleaning, reconnect the plugto the mains
supply with dry hands.
• Clean the condenser with a broom at least twice a year.
This will help you to save on energy costs and increase
productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
CLEANING AND MAINTENANCE
Defrosting
• Your refrigerator performs automatic defrosting. The water
formed as a result of defrosting passes through the water
collection spout, ows into the vaporisation container
behind your refrigerator and evaporates there.
• Make sure you have disconnected the plug of your
refrigerator before cleaning the vaporisation container.
• Remove the vaporisation container from its position by
removing the screws as indicated. Clean it with soapy
water at specic time intervals. This will prevent odours
from forming.
Replacing the light bulb
To replace the bulb in the freezer and fridge compartments;
1- Unplug your fridge.
2- Using a screwdriver, carefully remove the light cover from
the top panel. (A)
3- Replace with a 15 watt bulb. (B)
4- Reinstall the light cover.
5- Wait for 5 minutes before re-plugging the fridge in and
restore the thermostat to its original position.
EN
15
Evaporating
tray
B
1
A
3
2
Replacing LED lighting
If your refrigerator has LED lighting contact the help desk as
this should be changed by authorized personnel only.
EN
16
ARRANGING FOOD IN THE APPLIANCE
Refrigerator compartment
• To reduce humidity and the consequent increase in frost, never
place liquids in unsealed containers in the refrigerator. Frost tends to
concentrate in the coldest parts of the evaporating liquid and in time
will more frequent defrosting will be required.
• Never place warm food in the refrigerator. Warm food should be
allowed to cool at room temperature and should be arranged to
ensure adequate air circulation in the refrigerator compartment.
• Nothing should touch the back wall of the appliance as it will cause
frost and packaging to stick to it. Do not open the refrigerator door too
frequently.
• Arrange meat and cleaned sh (wrapped in packages or sheets of
plastic) which you intend to use in 1-2 days, in the bottom section of
the refrigerator compartment (that is above the crisper) as this is the
coldest section and will ensure the best storage conditions.
• Store fruit and vegetable items loose in the crisper containers.
Some recommendations have been specied below for the placement
and storage of your food in the cooling compartment.
Food
Vegetables and
fruits
Meat and sh 2 - 3 Days
Fresh cheese 3 - 4 Days In special door shelf
Butter and
margarine
Bottled products
milk and yoghurt
Eggs 1 month In the egg shelf
Cooked food All shelves
Maximum Storing
time
1 week Vegetable bin
1 week In special door shelf
Until the expiry date
recommended by
the producer
Where to place in the
fridge department
Wrapped in plastic foil or
bags or in a meat container
(on the glass shelf)
In special door shelf
ARRANGING FOOD IN THE APPLIANCE
Freezer compartment
• For maximum capacity for the freezer compartment, use glass
shelves for upper and middle section. For the bottom section, use the
lower basket.
• Place the food you would like to freeze initially in the upper shelf of
the deep freeze section in such a way that it does not exceed the
declared freezing capacity of your refrigerator. You may place your
food next to the other frozen food once it has frozen (for at least 24
hours).
• It is recommended to keep the thermostat set at level 5.
• It is recommended that the food to be frozen is kept separate from the
already frozen food.
• Foods should be frozen in single portion sized containers.
• Never refreeze frozen food after it has thawed. It may be hazardous
to your health and could lead to food poisoning.
• Never place warm food in the freezer compartment, as it will disturb
the frozen food.
• When buying frozen food, make sure that it was frozen under
appropriate conditions and the packaging is not damaged.
• When storing frozen food, the instructions shown on the packaging
should always be followed carefully and if no information is provided
food should consumed as soon as possible.
• Frozen food should be transported in appropriate containers and
placed in the freezer as soon as possible. Do not use door shelves
for freezing.
• If a frozen food package shows signs of humidity and abnormal
swelling it is probable that it has been previously stored at an
unsuitable temperature and that the contents have deteriorated. Do
not buy such food.
• Storage time for frozen food may differ according to the ambient
temperature, frequency of door openings, thermostat adjustments,
type of food and the time elapsed between buying the food and placing
the food in the freezer. Always follow instructions on the packaging
and do not exceed the storage period.
• During extended power outages, please do not open the door of the
deep freeze compartment. Your refrigerator will preserve your frozen
food in the ambient environmental temperature of 25°C for about 13
hours. This preservation time period decreases with higher ambient
EN
17
Loading...
