Schaub Lorenz IPH-2609 User Manual

iPhone / iPad / iPod
Docking Station

IPH-2609

For instruction manual in another language, check online at

http://manuel-utilisateur.logisav.fr

USER MANUAL

Please read and keep these instructions

- 1 -

IMPORTANT SAFETY INSTRUCTIONS

Please read carefully and keep for future reference

To reduce the risk of fire or electric shock, do not expose this
product to water, rain or moisture. To prevent the risk of
electric shock, do not remove the cover or back of this
product. In case of product failure, only qualified personnel
can repair. There are no user-serviceable parts inside.

CAUTION !
Dangerous tension inside the product ! Do not open. Risk of
electric shock ! No parts can be repaired by the end-user. Only
qualified personnel can repair and maintain this product.

If the electric cord is damaged, it must be replaced by the manufacturer
or qualified after-sales personnel in order to avoid any danger.

The product must be installed in accordance with local laws.

Damaged batteries must be properly disposed. In order to protect the
environment, please dispose the batteries properly, in accordance with
local laws (information is available at your reseller).

Where to install the product

- Place the product on a straight, rigid and stable place. Do not
place the product on a carpet.

- Do not place the product on top of another that may cause
overheating (for example, a receiver or amplifier).

- Do not place anything underneath the product (for example, CDs
or magazines).

- 2 -

Proper ventilation

- Place the product in a sufficiently–aerated place to avoid
overheating. Allow at least 10cm spacing at the back and top of
the product, and 5cm spacing on both sides to prevent
overheating.

- Do not place items such as newspapers, tablecloth, curtains, in
front of the ventilating openings.

Do not expose the product to high temperatures, moisture, water
and dust.

- The apparatus shall not be exposed to dripping or splashing. No
object filled with liquids, such as vases, shall be placed on the
apparatus.

- Do not place other items close to this product that may damage it
(for example, objects containing water or lightened candles).

- No naked flame sources, such as lighted candles, should be
placed on the apparatus.

Electric supply

- Please unplug the product in case of prolonged non-use.

- If the supply cable is damaged, it must be replaced by the
manufacturer or qualified after-sales personnel to avoid any
danger.

- This product must be connected to an electrical supply 230V ~
50Hz.

- The plug must be accessible after installation.

- 3 -

This product is compliant with directives 2006/95/CE

(abrogating the directive 73/23/CEE modified by the
directive 93/68/CEE) and 2004/108/CE (abrogating
the directive 89/336CEE).

- This logo set on the product means that the

recycling of this apparatus comes within the
framework of the directive 2002/96/EC of
January 27, 2003 concerning the waste on
electrical and electronic equipment (WEEE).

- The presence of dangerous substances in the electrical and
electronic equipments can have potential consequences on the
environment and human health in the cycle of reprocessing this
product.

- Therefore, at the end of its lifetime, this product shall not be
disposed with other non-recycled waste.

- As the end user, your role is of prime importance in the cycles of
re-using, recycling, and other forms of valorization of this electrical
and electronic equipment. Local authorities and resellers have set
special procedures for the purpose of collecting and recycling this
product.

- You have the obligation to use the selective waste collection
systems put in place by your local authorities.

- 4 -

CONTENT

IMPORTANT SAFETY INSTRUCTIONS .................................................. 1

CONTENT ................................................................................................. 4

PANELS .................................................................................................... 5

REMOTE CONTROL ................................................................................ 7

CONNECTION .......................................................................................... 9

BASIC OPERATION ............................................................................... 10

TROUBLE SHOOTING ........................................................................... 17

SPECIFICATION ..................................................................................... 19

- 5 -

PANELS

1. Control button

2. iPod socket

3. SD card socket

4. USB connector

- 6 -

1. The SET key triggers the following actions in the following order.
TIME (time setting)→SL00(sleeping time setting)→ALM (alarm
clock setting)→VOUT(Video out mode)→RST(Reset)

2. Key for “Pause” or “Play” and Power Standby (Press and hold
button for 2 seconds)

3. Selection of input channels. Sequence:

iPod → SD → USB → AUX/FM

4. Volume down

5. Volume up

6. Previous track/ tuner station

7. Next track/ tuner station
