Entris® II Advanced Line
Product Datasheet
Benefits
Simplifies balance leveling—with built-in real-time
level support
-
Increases reliability of weighing results—using integrated
protection systems
-
Controlled access to balance settings—with user
management
-
Gapless documentation—thanks to CalAuditTrail
-
Product Information
No matter what you are weighing, the new Entris® II balance
is always the right choice. Offering unrivalled value and
backed by almost 150 years of German engineering
expertise, the Entris® II comes in two product lines, so you
can find the balance that meets your specific weighing
needs.
Our Entris® II Advanced line gives additional value to the
Entris II portfolio, with over 38 models offering benefits such
as real-time level support, integrated protection systems,
Cal Audit Trail, a graphic touch display and 13 built-in application programs.
Technical Specifications
General Technical Data
Ambient Conditions Value
Installation site For indoor use only, max. height above sea level 3000 m
Temperature Environment (metrological data)*
Environment
Storage and transport
Relative humidity** At temperatures up to 31° C, non-condensing, then linear decrease
from max. 80% at 31° C to max. 50% at 40° C
No heat from heating systems or direct sunlight
No electromagnetic fields
Power Supply Device Value
Input voltage
Power consumption, max 4 W
Only by Sartorius power supply unit YEPS01-15V0W with interchangeable country-specific plug-in AC adaptors
+10 – +30° C
+5 – +40° C
-10 – +60° C
15 – 80%
15 V
DC
(±10%)
Interfaces
Specifications of the RS232 Interface
Type of interface Serial interface
Interface operation Full duplex
Level RS232
Connection D-sub connector, 9-pin
Maximum cable length 10 m
Pin assignment
Specifications for the USB-C Interface
Communication USB UTL
Connectable devices Sartorius printers, Sartorius second display, FTDI cable or USB memory stick
Specifications for the PC-USB Interface
Communication USB Device
Connectable devices PC
Pin 1: Not assigned
Pin 2: Data output (TxD)
Pin 3: Data input (RxD)
Pin 4: Not assigned
Pin 5: Internal ground
Pin 6: Not assigned
Pin 7: Clear to Send (CTS)
Pin 8: Request to Send (RTS)
Pin 9: Universal key
Power Supply Unit Value
Type: Sartorius power supply unit YEPS01-15V0W
Primary Voltage
Frequency
Current consumption, maximum
Secondary Voltage
Current, maximum
Short-circuit protection Electronic
Protection class according to IEC 60950-1 II
Pollution level according to IEC 61010-1 2
Overvoltage category according to IEC 60664-1 II
Other data: See label on the power supply unit
Electromagnetic Compatibility
Interference resistance: Suitable for use in industrial areas
Transient emissions Class B
Suitable for use in residential areas and areas that are connected to
a low voltage network that also supplies residential buildings
Materials
Housing Polybutylene terephthalate (PBT)
Control module Glass
Draft shield Glass | polybutylene terephthalate (PBT)
Weighing pan Stainless steel
Warm-up Time Value
Device, approx 2 h
* For conformity-assessed (verified) balances in accordance with EU requirements, refer to the information on the balance.
** For conformity-assessed (verified) balances in accordance with EU requirements, the legal regulations apply.
100 – 240 V
50 - 60 Hz
0.2 A
(±5%)
15 V
DC
0.53 A
(±10%)
AC
Calibration
Internal calibration isoCAL (models with marking i-1x)
External calibration
Selectable Weight Units*
Gram, kilogram, carat, pound, ounce, troy ounce, Hong Kong tael, Singapore tael, Taiwan tael, grain, pennyweights,
milligram, parts per pound, China tael, mommes, Austrian carat, tola, baht, mesghal and Newton
Display
Intuitive graphic touch technology
Built-in Applications
Weighing | Dosing
Counting
-
Percentage weighing
-
Mixing | Net total
-
Components | Totalizing
-
-
Languages
English, German, France, Italian, Spanish, Portuguese, Russian, Polish, Chinese, Japanese, Korean, Turkish, Hungarian
Protection
Chemical resistant housing parts
Glass parts of the draft shield are coated to
-
reduce electrostatic influences
-
Anti-theft Lock
Kensington lock and lockdown capability for cable or chain
* The availability of units depends on national legislation and is therefore country-specific.
Animal weighing
Calculation | Free factor
-
Density determination
-
Underfloor weighing feature
-
for bigger samples
-
Display foil (available as assessory)
Dust cover for balances (also available as accessory)
-
-
Statistics
Peakhold
-
Checkweighing
-
Mass unit conversion
-
Pipette smart test
-
-
2 3Entris® II Advanced Line
Models with Internal Adjustment Feature
Model BCA Unit 324i-1x 1224i-1x 1124i-1x 164i-1x
1
1203i-1x 1623i-1x 1423i-1x 1323i-1x
1
223i-1x 16202i-1x 14202i-1x 1 3202i-1x 12202i-1x 11202i-1x 1822i-1x 112201i-1x 110201i-1x 18201i-1x 15201i-1x 12201i-1x
Readability | Scale interval (d) mg 0.1 0.1 0.1 0.1 1 1 1 1 1 10 10 10 10 10 10 100 100 100 100 100
Maximum capacity (Max) g 320 220 120 60 1,200 620 420 320 220 6,200 4,200 3,200 2,200 1,200 820 12,200 10,200 8,200 5,200 2,200
Weighing system EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC
Repeatability
At 5% load, typical value ± mg 0.08 0.08 0.08 0.08 0.5 0.5 0.5 0.5 0.5 5 5 5 5 5 5 50 50 50 50 50
At approx. maximum load, typical value ± mg 0.1 0.1 0.1 0.1 1 1 1 1 1 10 10 10 10 10 10 100 100 100 50 50
Linearity deviation
Limits ± mg 0.3 0.2 0.2 0.2 2 2 2 2 2 20 20 20 20 20 20 100 100 100 100 100
Typical value ± mg 0.06 0.06 0.06 0.06 0.6 0.6 0.6 0.6 0.6 6 6 6 6 6 6 60 60 60 60 60
Sensitivity drift between +10° C and +30° C ± ppm/K 1 1 1 1 1.5 2 2 2 2 2 2 2 2 2 2 4 4 4 2 2
Tare maximum capacity (subtractive) <100% of maximum capacity <100% of maximum capacity
isoCAL (only for i-1x models):
Temperature change K 1.5 1.5 1.5 1.5 1.5 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Time interval h 4 4 4 4 4 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
For models with approval:
Accuracy class I I I I I II II II II II II II II II II II II II II II
1
Type BC-AA BC-AB BC-AB BC-AB BC-AC BC-AD BC-AD BC-AD BC-AD BC-AE BC-AE BC-AE BC-AE BC-AE BC-AE BC-AG BC-AG BC-AG BC-AE BC-AE
Verification scale interval (e) mg 1 1 1 1 10 10 10 10 10 100 100 100 100 100 100 1,000 1,000 1,000 100 100
Minimum load (Min) mg 10 10 10 10 100 20 20 20 20 500 500 500 500 500 500 5,000 5,000 5,000 5,000 5,000
Minimum initial weighing according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum initial weighing g 0.082 0.082 0.082 0.082 0.82 0.82 0.82 0.82 0.82 8.2 8.2 8.2 8.2 8.2 8.2 82 82 82 82 82
Typical minimum initial weighing g 0.16 0.16 0.16 0.16 1 1 1 1 1 10 10 10 10 10 10 100 100 100 100 100
Typical measurement time s ≤2.0 ≤2.0 ≤2.0 ≤2.0 ≤1.5 ≤1.5 ≤1.5 ≤1.5 ≤1.5 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0
Typical stabilization time s ≤1.5 ≤1.5 ≤1.5 ≤1.5 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9
Recommended calibration weight
External calibrated test weight g 200 200 100 50 1,000 500 200 200 200 5,000 2,000 2,000 2,000 1,000 500 10,000 10,000 5,000 5,000 2,000
Accuracy class in accordance with
E2 E2 E2 E2 E2 F1 F1 F1 F1 F1 F1 F1 F1 F1 F2 F2 F2 F2 F2 F2
OIML R111-1
Weighing pan size mm Ø 90 Ø 90 Ø 90 Ø 90 Ø 120 Ø 120 Ø 120 Ø 120 Ø 120 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182
Weighing chamber height* mm 240 240 240 240 240 240 240 240 240 - - - - - - - - - - Net weight, approx. kg 6.20 6.20 6.20 6.20 6.30 6.30 6.30 6.30 6.30 6.20 6.20 6.20 6.20 6.20 6.20 6.20 6.20 6.20 6.20 6.20
Gross weight, approx. kg 8.00 8.00 8.00 8.00 8.10 8.10 8.10 8.10 8.10 7.00 7.00 7.00 7.00 7.00 7.00 7.00 7.00 7.00 7.00 7.00
* upper edge of the weighing pan to the lower edge of the upper draft shield panel
1 Country-specific marking in model:
x = S: Standard balances without country-specific additions
x = SAR: Standard balances with country-specific additions for Argentina
x = SJP: Standard balances with country-specific additions for Japan
x = SKR: Standard balances with country-specific additions for South Korea
x = CCN: Balances with approval for China
x = CEU: Conformity-assessed balances with EU type examination
certificate without country-specific additions
x = CFR: Conformity-assessed balances with EU type examination
certificate only for France
x = OBR: Balances with approval for Brazil
x = OIN: Balances with approval for India
x = OJP: Balances with approval for Japan
x = ORU: Balances with approval for Russia
4 5Entris® II Advanced Line
Models without Internal Adjustment Feature, without Approval
Model BCA Unit 224-1x 1124-1x
1
64-1x
1
623-1x 1423-1x 1323-1x 1223-1x
1
6202-1x 14202-1x 1 3202-1x 12202-1x
1
1202-1x
1
822-1x
1
12201-1x 110201-1x 18201-1x
1
5201-1x
1
2201-1x
1
Readability | Scale interval (d) mg 0.1 0.1 0.1 1 1 1 1 10 10 10 10 10 10 100 100 100 100 100
Maximum capacity (Max) g 220 120 60 620 420 320 220 6,200 4,200 3,200 2,200 1,200 820 12,200 10,200 8,200 5,200 2,200
Weighing system EMC EMC EMC EMC EMC EMC EMC EMC EMC EMC Strain gauge Strain gauge Strain gauge EMC EMC Strain gauge Strain gauge Strain gauge
Repeatability
At 5% load, typical value ± mg 0.08 0.08 0.08 0.5 0.5 0.5 0.5 5 5 5 5 5 5 50 50 50 50 50
At approx. maximum load, typical value ± mg 0.1 0.1 0.1 1 1 1 1 10 10 10 10 10 10 100 100 100 100 100
Linearity deviation
Limits ± mg 0.2 0.2 0.2 2 2 2 2 20 20 20 20 20 20 100 100 300 300 300
Typical value ± mg 0.06 0.06 0.06 0.6 0.6 0.6 0.6 6 6 6 6 6 6 60 60 100 100 100
Sensitivity drift between +10° C and +30° C ± ppm/K 1 1 1 2 2 2 2 2 2 2 3.5 3.5 3.5 4 4 7 7 7
Tare maximum capacity (subtractive) <100% of maximum capacity <100% of maximum capacity
isoCAL (only for i-1x models):
Temperature change K – – – – – – – – – – – – – – – – – –
Time interval h – – – – – – – – – – – – – – – – – –
For models with approval:
Accuracy class – – – – – – – – – – – – – – – – – –
Type – – – – – – – – – – – – – – – – – –
Verification scale interval (e) mg – – – – – – – – – – – – – – – – – –
Minimum load (Min) mg – – – – – – – – – – – – – – – – – –
Minimum initial weighing according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum initial weighing g 0.082 0.082 0.082 0.82 0.82 0.82 0.82 8.2 8.2 8.2 8.2 8.2 8.2 82 82 82 82 82
Typical minimum initial weighing g 0.16 0.16 0.16 1 1 1 1 10 10 10 10 10 10 100 100 100 100 100
Typical measurement time s ≤2.0 ≤2.0 ≤2.0 ≤1.5 ≤1.5 ≤1.5 ≤1.5 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0
Typical stabilization time s ≤1.5 ≤1.5 ≤1.5 ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9 ≤0.9
≤0.9 ≤0.9 ≤0.9 ≤0.9
Recommended calibration weight
External calibrated test weight g 200 100 50 500 200 200 200 5,000 2,000 2,000 2,000 1,000 500 10,000 10,000 5,000 5,000 2,000
Accuracy class in accordance with
E2 E2 E2 F1 F1 F1 F1 F1 F1 F1 F1 F1 F2 F2 F2 F2 F2 F2
OIML R111-1
Weighing pan size mm Ø 90 Ø 90 Ø 90 Ø 120 Ø 120 Ø 120 Ø 120 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182 182 x 182
Weighing chamber height* mm 240 240 240 240 240 240 240 - - - - - - - - - - Net weight, approx. kg 5.90 5.90 5.90 5.90 5.90 5.90 5.90 4.60 4.60 4.60 4.30 4.30 4.30 4.60 4.60 4.30 4.30 4.30
Gross weight, approx. kg 7.7 0 7. 70 7.70 7. 70 7.70 7.70 7. 70 5.10 5.10 5.10 5.10 5.10 5.10 5.10 5.10 5.10 5.10 5.10
* upper edge of the weighing pan to the lower edge of the upper draft shield panel
1 Country-specific marking in model:
x = S: Standard balances without country-specific additions
x = SAR: Standard balances with country-specific additions for Argentina
x = SJP: Standard balances with country-specific additions for Japan
x = SKR: Standard balances with country-specific additions for South Korea
6 7Entris® II Advanced Line
Technical Drawings
Models with a readability of 0.1 mg
All dimensions are given in millimeters
usable height: 240 mm
12 ±1
±2
345
Models with a readability of 1 mg
All dimensions are given in millimeters
usable height: 240 mm
12
±2
345
Models with a readability of ≥ 10 mg
All dimensions are given in millimeters
±2
254
±2
317
±5
94
+2
19
253
317 ±2
±2
20
+2
253 ±2
317 ±2
20
+2
219 ±1
182 ±1
182 ±1
±1
90
219 ±1
188 ±1
219
120
188 ±1
8 9Entris® II Advanced Line
Accessories
These tables contain an excerpt of the accessories that can be ordered. For information on other products, contact Sartorius.
Balance Accessories
Item Quantity Order number
Display protection film (set of 5) 1 YDC10
Dust cover for balances with an analytical draft shield 1 6960BC01
Dust cover for balances with rectangular weighing pan 1 YDC30
In-use cover (set of 5) 1 YIC01
Density determination set for solids and liquids for balances with a readability of 0.1 mg |1 mg 1 YDK03
“Kensington Lock” anti-theft device 1 YKL01
Pedal button | foot switch 1 YFS03
Second display | remote display 1 YSD01
Below-balance weighing (not for models in legal metrology)
Hook M5 1 69EA0039
Weighing table
Made from wood with natural stone 1 YWT09
Made from natural stone, with vibration dampening 1 YWT03
Wall console made from natural stone 1 YWT04
Converter cable 5 V
DC
> 15 V
DC
1 YCC-5V-15V
External Calibration and Adjustment Weights
BCA model Weight Accuracy class Order number
324 | 224 200 g E2 YCW522-AC-02
124 100 g E2 YCW512-AC-02
64 50 g E2 YCW452-AC-02
1203 1,000 g E2 YCW612-AC-02
623 500 g F1 YCW553-AC-02
423 | 323 | 223 200 g F1 YCW523-AC-02
6202 5,000 g F1 YCW653-AC-02
4202 | 3202 | 2202 2,000 g F1 YCW623-AC-02
1202 1,000 g F1 YCW613-AC-02
822 500 g F2 YCW554-AC-02
12201 |10201 10,000 g F2 YCW714-AC-02
8201 | 5201 5,000 g F2 YCW654-AC-02
2201 2,000 g F2 YCW624-AC-02
Printer and Accessories for Data Communication
Item Quantity Order number
Thermal printer (USB-B) 1 YDP40
Thermal transfer printer (USB-B, RS232) 1 YDP30
Dot matrix printer (RS232)* 1 YDP20-0CE
Data cable USB-C > USB-B (>YDP30, YDP40) 1.5 m YCC-USB-C-B
Data cable USB-C > USB-A (>PC) 1.5 m YCC-USB-C-A
Data cable RS232 (9-pin) > USB-A (>PC) 1.5 m YCC-D09M-USB-A
Data cable RS232 (9-pin) male > RS232 (9-pin) male (> YDP30) 1.5 m YCC-D09MM
Data cable RS232 (9-pin) male > RS232 (9-pin) female (>YDP20-0CE, YSD01) 1.5 m YCC-D09MF
Y-adapter RS232 (9-pin) male > 2x RS232 (9-pin) female 1.5 m YCC-D09M-2D09F
*additional power supply e.g. YEPS01-PS4 or YEPS01-PS5 is required
10 11Entris® II Advanced Line
Sales and Service
Contacts
For further contacts, visit
www.sartorius.com
Germany
Sartorius Lab Instruments
GmbH & Co. KG
Otto-Brenner-Strasse 20
37079 Goettingen
Phone +49 551 308 0
Specifications subject to change without notice.
Copyright Sartorius Lab Instruments GmbH & Co. KG.
Printed in the EU or US on paper bleached without chlorine.
Version 1: 05 | 2020
USA
Sartorius Corporation
565 Johnson Avenue
Bohemia, NY 11716
Phone +1 631 254 4249
Toll-free +1 800 635 2906
Loading...
