Sartorius Basic Series Installation And Operating Instructions Manual
Sartorius
Basic Series
Electronic Analytical and Precision Balances
Installation and Operating Instructions
2
B 120S
3
B 310P, B 310S
4
B 410, B 610, B 3100P,
B 3100S, B 4100, B 6100
5
1
Weighing pan
2
Protective ring (only for B 120S)
3
Shield plate (only for B 120S)
4
Round draft shield lid (only B 310P and B 310S)
5
Glass draft shield cylinder (only B 310P and B 310S)
6
Base plate shield cylinder (only B 310P and B 310S)
7
Pan adapter (only B 310P and B 310S)
8
Power receptacle
9
Level indicator (only B 120S, B 310P, B 310S, B 3100P and B 3100S)
10
Leveling foot (only B 120S, B 310P, B 310S, B 3100P and B 3100S)
11
PRINT key (functions only if the balance has a built-in interface)
12
Menu access switch
13
Tare control
14
CAL key for calibration
15
ON/OFF key
16
Weight display
17
Manufacturer’s label
6
Sartorius
Basic Series
With this Sartorius Balance, you have acquired a high-quality electronic precision weighing instrument that will help ease your daily
workload.
Please read these installation and operating instructions carefully before operating your new balance.
Pursuant to the German Directive for the Implementation of
Regulations for Prevention of Accidents "Elektrische Anlagen
und Betriebsmittel (VBG4)" [Electrical Installations and Equipment] of April, 1986, it is hereby certified that the equipment
delivered, "Electronic Analytical or Precision Balance of the
Basic Series," is manufactured and tested in compliance with
the following DIN/VDE regulations
DIN IEC 348/VDE0411
Safety requirements for electronic measuring apparatus
DIN IEC 380/VDE 0806
Safety of electrically energized Office machines
DIN IEC 601/VDE 0750
Safety of medical electrical equipment
and with Article 10 of the Low-Voltage Directive 73/23/EEC
issued on February 19, 1973, by the European Community.
When you use electrical equipment in installations and under
ambient conditions requiring higher safety Standards, you must
comply with the provisions as specified in the applicable regulations for installation in your country.
7
Contents
Page
Equipment Supplied 8
Installation Instructions 9
How to Start Up the
B 120 S
10
How to Start Up the
B 310P and B 310S
11
How to Start Up the
B 410, B 610,
12
B 3100P, B 3100S, B 4100, and B 6100
Operation 13
Calibration 15
Balance Operating Program 16
Troubleshooting Guide 19
Accessories 20
Specifications 22
8
Equipment Supplied
B 120S
B 310P, B 310S
B 410, B 610, B 3100P,
B 3100S, B 4100, B 6100
-
Balance
-
AC adapter
-
Dust cover
-
Weighing pan
-
Protective ring
-
Shield plate
-
Balance
-
AC adapter
-
Dust cover
-
Pan adapter
-
Base plate of the
round draft shield
-
Weighing pan
-
Glass draft shield cylinder
-
Round draft shield lid
-
Balance
-
AC adapter
-
Dust cover
-
Weighing pan
Do not miss out on the benefits of our warranty. Please complete the warranty registration card, indicating
the date of installation, and return the card to your Sartorius dealer.
