3000 ANSI LUMENS z WIRED NETWORKING PROJECTOR
PLC-XU300/XU300A
XGA Ultraportable Multimedia Projector
COMPLETE EASY AUTO SET UP FUNCTION, SMART AUTO INPUT
SEARCH AND AUTO VERTICAL KEYSTONE CORRECTION
PLC-XU300/XU300A provides "Auto Set Up Function" that corrects
keystone shaped distortion by searching for an input signal and detecting
projector incline, therefore reducing set up time. PLC-XU300/XU300A
automatically compensates for keystone picture distortion. Auto Keystone
Correction, Auto Input Search and Auto PC Adjustment make it a really
smart projector.
NETWORKING CAPABILITY
Bright 3000Im, the PLC-XU300/XU300A are equipped with SANYO’s
exclusive PJ-Net Master Network Interface software for wired networking, a
common feature among SANYO’s extensive line of commercial projectors.
Networking allows the monitoring of projector functions and operation from a
long distance via a web browser for up 15,000 Sanyo projectors. Emails can
be sent automatically to report operating status.
COMPACT DESIGN AND LIGHTWEIGHT FOR PORTABILITY
The compact design (12.8"x3.3”x9.1”) and lightweight body (5.7lbs.) let you
make presentations almost anywhere.
POWER-OFF AND GO
No need to wait for the projector to cool down. Once the lamp is shut off you
can disconnect the power cord right after your presentation.
BLACK BOARD / COLOR BOARD MODE
What could be more right for education? A black board mode. The PLCXU300/XU300A are compatible with four colored (red, blue, green and
yellow) projection surfaces via the ‘Color Board Mode’. It adjusts the color to
make images look as true as on an ordinary white screen.
LAMP REPLACEMENT ON TOP CABINET
There is access to the lamp from the top of the projector which means you
can replace the lamp on a ceiling-mounted unit without taking down the
projector.
CLOSED CAPTION
PLC-XU300/XU300A are Closed Caption compatible.
Resolution XGA (1,024 x 768)
Brightness (typical) 3000
Uniformity 85%
Panel System 0.63” TFT Polyx3
Number of Pixels 2,359.296 (786,432 x3)
Contrast Ratio (Full on / off) 500:1
Image Size 40"-300"
Aspect Ratio 4:3
Projection Lamp (s) 225W UHP
Scanning Frequency H:15-100kHZ V:50-100Hz
Dot Clock 140MHz
Fan Noise 29dBA / 34dBA (Normal / Eco)
Voltage 100-240V
BTU Rating 1,024 / 809 (Normal / Eco)
Power Consumption 330W / 237W (Normal / Eco)
Input signal compatibility
Color System NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N
Projection Lens (inch) F1.65 – 1.76 f=0.88" - 1.06"
Throw Ratio 1.72 - 2.07
Throw Distance (feet) 4.6' - 41.7'
Zoom / Focus Manual
Zoom Ratio 1:1.2
Up / Down Ratio 9:1
Digital Keystone Correction V +/- 30° (Auto Keystone)
Projection System Diachronic mirror & X prism system w/PBS
Digital Zoom 16x - 1/4x
Speaker Output 1W
Weight (lbs.) 5.7lbs.
Dimensions (inch) W,H,D 12.8"x3.3”x9.1”
Lamp Life *
(hours Normal / Eco)
Replacement Lamp 610 343 2069
Replacement Remote 645 099 3213
Input
Output
Control Dsub-9 x 1 (Control port)
Others RJ-45 x 1 (Wired LAN)
Included Accessories
Optional Accessories POA-CACOMPVGA (Component-Dsub 15 conversion Cable)
User Maintenance Clean air filters, replace lamp assembly
Warranty
Because its products are subject to continu ous improvement, SANYO reserves the right to modify product design and
specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a general e st imate.
The brightness of a lamp usually decreases over t ime and use.
Rear Back Panel
Specifications
UXGA / WXGA / SXGA+ / SXGA / XGA / SVGA / VGA /
MAC, 480i / 480p / 575i / 575p / 720p / 1080i
Up to 4000h / 5000h (Normal / Eco)
PC1
PC2
VIDEO
Dsub-15 x 1 (RGB, Component, RGB)
Mini jack x 1 (Audio input, stereo)
Dsub-15 x 1 (in common)
Mini jack x 1 (Audio input, stereo)
Mini DIN 4-pin x 1 (S-Video)
RCA x 1 (Composite Video)
RCA x 2 (Audio input, R/ L-mono)
Dsub-15 x 1 (in common)
Mini jack x 1 (Audio out, stereo variable)
Quick reference guide, CD-ROM read me note, UL cable
card, PIN code label, Computer cable, Power cord, Remote
control, AAA Battery x 2, User's manual (CD ROM), Network
PJ-Net Manager software (CD ROM), Soft carrying case,
Strap for Lens cap
Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
