Parts List
File No.
INDOOR UNIT
Air Conditioner
Model No. Prod.Code Volt-Phase-Hertz
UH2672R 1 854 028 40 208-230-1-60
UH2672R
Made in Japan
REFERENCE No.PL 833302
38
36
UH2672R
INDOORUNIT
33
7
36
50
21
39
34
22
51
41
14
53
20
37
49
23
15
10
29
15
41
14
40
27
25
16
24
48
40
3
47
13
4
17
8
9
31
11
30
54
12
35
18
6
44
28
1
46
52
26
35
32
52
28
42
45
2
46
28
5
5
19
43
5
52
28
52
-2-
ATTENTION !
To ensure correct parts supply,please let us know followings,
when you make service parts order:
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Model No.
Key
No.
1 638 020 1167 Moter Cover Ass'y 1 854-9-9536-04347
2 638 018 7263 Mounting Plate 1 854-2-2361-49800
* 3 623 192 1411 Drain Pan Ass'y 1 854-0-2301-507H2
4 638 020 1150 Insulation 1 854-2-1408-77700
5 623 192 1404 Angle flange 3 854-2-2306-262H2
* 6 623 160 1535 Thermistor Ass'y PBC-41E-S36 1 854-0-5259-54300
7 623 000 0735 Eyelet 2 3-9041-01500
8 623 015 3431 Plug 1 733-2-3313-12000
* 9 623 192 1442 Switch Ass'y 1 854-0-5152-03900
* 10 623 192 1435 Fan Motor Ass'y KFG4X-71B6P 1 854-0-5202-32000
11 638 018 7362 Drain Hose 1 854-2-4297-14600
12 623 160 1320 Insulation Special 1 854-2-2411-22310
13 623 160 1344 Insulation Special 1 854-2-2411-22210
* 14 623 160 5380 Fan Ass'y 2 854-0-2501-22830
15 638 015 1486 Cushion Rubber 2 854-2-2534-17500
16 623 192 1428 Cover, Drain Pan 1 854-2-2343-163H2
* 17 623 192 1473 Drain Pump Ass'y PJV-1429AU 1 854-0-5264-04600
* 18 623 165 1653 Heat Exch Ass'y 1 854-0-4119-99000
19 623 192 1466 Cabinet Ass'y 1 854-9-9536-05295
* 20 623 192 1572 Circuit Board Ass'y CR-TH2672 1 854-9-9536-05306
* 21 623 160 1382 Thermistor Ass'y KTEC-35-S85 1 854-0-5259-53500
* 22 638 016 3441 Terminal Base UKT50-3+15S-2J(A 1 1FJ-4-J3A0-06800
23 623 192 1459 Top Cover Ass'y 1 854-9-9536-05305
24 623 160 1399 Elec. Wiring Diagram 1 854-2-5268-94000
* 25 623 192 1503 Transformer Ass'y ATR-IIK244B 1 854-0-5263-20400
26 623 192 1497 Mounting Plate,Evaporator 1 854-2-2303-312H2
* 27 638 003 6653 Fixed Capacitor UPMDD-440V/5.0MF 1 4-2239-56165
28 638 018 7188 Hook Plate 4 854-2-1130-24201
29 638 018 7621 Support Motor Ass'y 1 854-0-2511-24801
30 623 054 6073 Insulation Tube 1 852-2-4514-28600
31 623 077 2205 Clip 1 854-2-2315-10301
32 623 192 1480 Mounting Plate,Evaporator 1 854-2-2303-313H2
33 623 038 3425 Bushing 1 851-2-5370-00900
34 623 192 1510 Mounting Plate 1 854-2-5309-18302
35 623 160 5397 Insulation, Evaporator 2 854-2-2404-30910
36 638 018 7409 Mounting Plate 2 854-2-5309-14200
37 638 018 7416 Mounting Plate 1 854-2-5309-14300
38 623 160 1443 Elec Component Box 1 854-2-5306-15900
39 638 018 7423 Support Terminal 1 854-2-5316-16401
40 623 160 1450 Blower Casing 2 854-2-2506-19210
41 623 160 1474 Blower Casing 2 854-2-2506-19310
42 638 018 7102 Side Panel Ass'y 1 854-0-1102-39200
43 638 018 7614 Side Panel Ass'y 1 854-0-1102-39300
44 623 160 1481 Joint Drain 1 854-2-2334-18610
45 638 018 7843 Mounting Panel 1 854-2-1127-19000
46 638 018 7171 Mounting Plate 2 854-2-1129-95100
47 638 018 7805 Plate Partition Blower 1 854-2-2505-19100
48 638 018 7683 Support Fan Motor 1 854-2-2516-30000
49 638 018 7386 Cover,Elec.Component Box 1 854-2-5304-50300
50 623 192 1527 Insulation 1 854-2-1408-85100
NOTE: Metal and plastic parts will be supplied basically
Part No. Description Q'ty Reference No.
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
- 3 -
UH2672R
INDOOR UNIT
ATTENTION !
To ensure correct parts supply,please let us know followings,
when you make service parts order:
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Model No.
Key
No.
51 623 120 9908 Wire Ass'y 1 851-0-5292-70200
52 623 160 1504 Insulation 4 854-2-1408-77510
* 53 623 191 6783 Fuse MT3 5A 2 1FJ-4-S3A0-03900
* 54 623 160 1313 Thermistor Ass'y PBC-41E-S36 1 854-0-5259-54200
NOTE: Metal and plastic parts will be supplied basically
Part No. Description Q'ty Reference No.
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
UH2672R
INDOOR UNIT
For Parts or Service Contact
SANYO HVAC SERVICE CENTER
SANYO Fisher Service Company
1165 Allgood Road, Suite 22, Marietta, GA 30062 U.S.A.
300 Applewood Crescent, Concord, Ontario, L4K 5C7, CANADA
- 4 -
2/06 Printed in Japan
