Sanyo LCD-47XR8DA User Manual

INSTRUCTION MANUAL

LCD TV

LCD-47XR8DA

Before connecting, operating or adjusting this product, please read the manual completely. Please keep this manual for future reference.

Table of Contents

Important Safety Precautions..........................................................................................................................1

Important Notice............................................................................................................................................3

Preparations....................................................................................................................................................4

Identification of Controls ................................................................................................................................6

Connections....................................................................................................................................................9

Basic Operations...........................................................................................................................................13

Memorizing the Channels .............................................................................................................................15

Channel and Program Selection....................................................................................................................19

Picture Adjustment .......................................................................................................................................20

Sound Adjustment.........................................................................................................................................21

System Setup ................................................................................................................................................23

Rating and Lock Setup ..................................................................................................................................24

Timer Setup..................................................................................................................................................26

EPG Operation.............................................................................................................................................28

Teletext & Subtitle

Screen setup for D-SUB (PC) Mode ............................................................................................................30

Hotel Mode Setup ........................................................................................................................................31

Troubleshooting............................................................................................................................................32

Specifications ................................................................................................................................................34

........................................................................................................................................29

Important Safety Precautions

Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please read the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your new TV product, please read the following precautions carefully before using the product.

1. Read these instructions---All operating instructions must be read and understood before the product is operated.

2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.

3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.

4. Follow all instructions---All operating instructions must be followed.

5.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not

recommended by the manufacturer. Use of improper attachments can result in accidents.

6. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system.

7.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Note: where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

8.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result in a risk of fire or electric shock.

9.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltages are present in the product, and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid on the product.

10. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

11.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified service person to perform repairs. a. When the power cord or plug is damaged. b. When a liquid is spilled on the product or when objects have fallen into the product. c. When the product has been exposed to rain or water. d. When the product does not operate properly as described in the operating instructions. Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not described in the instructions can cause damage, which often requires extensive adjustment work by a qualified technician. e. If the product has been dropped or the cabinet has been damaged in any way. f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in the product indicates that the product needs servicing.

12. Replacement parts---In case the product needs replacement parts, make sure that the service person replaces parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.

13. Safety checks---Upon completion of service or repair work, request the service technician to perform safety checks to ensure that the product is in proper operating condition.

14. Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to ask a authorized service personnel to carry out setup. This is a safety feature.

Important Safety Precautions (Continued)

15. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. When mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.

16.Careful move---When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor surfaces can cause the product to fall from the trolley. Never attempt to move the TV unless the AC power cord has been disconnected.

17. Lightning---Unplug this apparatus during lightning storms or when unused for long periods of time. For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

18. Do not use this apparatus near water---for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like. Do not use immediately after moving from a low temperature to high temperature environment, as this causes condensation, which may result in fire, electric shock, or other hazards.

19. Clean only with dry cloth---Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

20. Ventilation---Do not block any ventilation openings. Install in accordance with the manufacturer instructions. The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.

21.Heat sources---Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

22.Panel protection---The display panel used in this product is made of glass. Therefore, it can break when the product is dropped or impacted upon by other objects. Be careful not to be injured by broken glass pieces in case the display panel breaks.

23.Pixel defect---The display panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.

Warning: For continued safety, apparatus with class I construction shall be connected to a mains socket outlet with a protective earthing connection.

Important Notice

About Temperature

About After-Image

Do not use in hot and cold rooms (locations)

! When the unit is used in rooms (locations) with low temperature, the picture may

leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

! Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location

exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the to malfunction.

screen

! Storage temperature: 0°C to +50°C ! Working temperature: 5°C to +40°C

The extended use of fixed image program material can cause a permanent on the screen.

This background image is viewable on normal programs in the form of a stationary fixed image. This type of irreversible screen deterioration can be limited by observing the following steps:

A. Reduce the brightness/contrast setting to a minimum viewing level.

B. Do not display the fixed image for extended periods of time.

C. Turn the power off when not in actual use.

after-image

Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays.

! Do not allow a still picture to be displayed for an extended period, as this can cause a

permanent after-image to remain on the screen.

Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

Cleaning and Maintenance

CAUTIONS:

! The permanent after-image on the screen resulting from fixed image use is not an

operating defect and as such is not covered by the warranty.

! This product is not designed to display fixed images for extended periods of time.

To clean this unit, wipe with a soft, dry cloth.

If the surfaces are extremely dirty, use a soft cloth dipped in a soap and water solution or a weak detergent solution.

Use eyeglass cleaner to remove stubborn dirt from the screen.

Never use alcohol, paint thinner or benzine to clean this unit.

Before using a chemically treated cloth, read the instructions that came with the

cloth carefully.

Preparations

Using the Remote Control

<Use the remote control by pointing it towards the remote sensor window of the

set. Objects between the remote control and sensor window may prevent proper operation.

Cautions regarding use of remote control

<Do not expose the remote control to shock. In addition, do not expose the remote

control to liquids, and do not place in an area with high humidity.

<Do not install or place the remote control under direct sunlight. The heat may cause deformation

of the unit.

<The remote control may not work properly if the remote sensor window of the main unit is under direct sunlight or strong

lighting. In such a case, change the angle of the lighting or the TV set, or operate the remote control closer to the remote sensor window.

Installing the Batteries

If the remote control fails to operate the TV functions, replace the batteries in the remote control.

Open the battery cover.

Insert two size-AAA batteries.

<(Place the batteries with their terminals corresponding to the (+)

and (–) indications in the battery compartment.)

Replace the cover and slide in reverse until the lock snaps.

Precaution on battery use

Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.

<Place batteries with their terminals corresponding to the (+) and (–) indications.

<Different types of batteries have different characteristics. Do not mix batteries of different types.

<Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old

batteries to leak chemicals.

<Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a rash. If chemical

leakage is found, wipe with a cloth.

<If the remote control is not used for an extended period of time, remove the batteries from the remote control.

<The batteries (battery pack of batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.

Preparations (continued)

Antenna Connection

INSTALL the unit in a room where direct light will not fall upon the screen. Total darkness or a reflection on the picture screen may cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.

Optimum reception of colour requires a good signal and will generally mean that an outdoor antenna must be used. The exact type and position of the antenna will depend upon your particular area.

TV REAR

Note

=It is recommended that the 75-ohm coaxial cable be used to eliminate interference and noise which may occur due to radio wave

conditions.

=The antenna cable should not be bundled with the power cord.

75-ohm coaxial cable (round cable)

Power Connection

Insert the AC plug into a conveniently located AC outlet.

Note

=This product should be operated only from the type of power source indicated on the marking label. =Always unplug the AC cord from power outlet when not using for a long period of time.

Identification of Controls

Main Unit (front view/side view)

菜单节目源

音量

频道

音量

频道

CH+

5 6

CH- VOL- VOL+ MENU SOURCE

1. Power Indicator

2. Remote Sensor

3. CH+/-

Press these two buttons to directly change the TV channel. In OSD menu, press these buttons to choose the OSD items.

4.VOL+/-

Press the VOL+ or VOL- button to directly increase or decrease the sound volume level;

In OSD menu, press these buttons to adjust the value or setting of each item.

5. MENU

Press this button to access Menu main page.

6. SOURCE

To access input source select menu.

7. POWER

Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.

Note

Functions of CH+/-, VOL+/-, MENU, SOURCE and POWER are also provided to the remote control. This

operation manual provides a description based on operating functions with the remote control.

Identification of Controls (Continued)

Main Unit (rear view)

1 2

1. HDMI 1 / 2 interface To connect with those equipments with HDMI or DVI interface, for example, Set-top box or DVD player. (A

HDMI-to-DVI adapter cable is required when you are connecting a DVI-equipped device to this TV.)

2. D-SUB input

Connect to the D-SUB/AUDIO output jack on your computer.

3. COMPONENT 1/2 inputs Connect to the audio and component output jacks of a DVD player or Set-Top Box.

4. Headphone jack Connect to your headphones.

5. AV inputs (Video, Audio L, R) Receive video/audio signal from external sources such as VCR or DVD player.

6. AV outputs(Video, Audio L, R) Connect to your VCR to record programs.

7. RS232 interface For service use . The user cannot operate the unit through this terminal.

8. Antenna input

Connect to your cable system or outdoor antenna.

9. S/PDIF digital audio out terminal(coaxial) Connect to the digital audio input of a digital audio component.

10. Power Switch

Identification of Controls (Continued)

Remote Control Unit

POWER: Switches the TV power on or Standby.

TV/Radio: Switches between TV and Radio mode. (DTV only)

EPG: Displays the Electronic Program Guide (DTV only).

14 15

FAV.LIST: Displays the favorite channel list.

FAV+/ FAV–: Selects the favorite channel.

0 – 9 number buttons: Press to enter channel numbers or

input password.

ZOOM: Selects the screen size.

MENU: Displays the main menu screen.

5/6/3/4/OK: Press the arrows to navigate through the

menus or adjust an item. Press OK to confirm a selection or enter a sub-menu.

MUTE: Mutes the sound.

INFO: Displays the information banner.

VOL+/–: Increases or decreases the volume.

13 23

24 25

26 27

28 29

30 31

STEREO: Selects bilingual, stereo or mono ( ATV only ), or

audio track(DTV only).

FREEZE: To freeze current picture.

SLEEP: Sets the sleep timer.

RECALL: Returns to the previous channel.

EXIT: Exits the menu screen.

SOURCE: Displays input source menu.

LIST: Displays the channel list.

CH / : Changes channel up and down.

P.MODE: Selects picture mode.

Below is teletext control buttons:

Colored buttons (RED/GREEN/YELLOW/BLUE): Direct

access to the colored items or corresponding pages. (Teletext)

TTX: Used to enter or exit teletext mode. (Teletext)

Subtitle: Displays the subtitle (DTV only), or the teletext

subpage (ATV only).

Size: Press this button several times to display the upper, then

the lower part of the screen and then return to the normal size teletext page. (Teletext)

Index: Press this button to view the main index page.(Teletext)

Reveal: To reveal or hide the concealed information. (Teletext)

Hold: To stop or resume sub-page acquisition. (Teletext)

Update:

(Teletext)

Mix:

transparent background while viewing the TV program simultaneously

Press the button to view the updated teletext page.

Press the button to display the Teletext on the screen with

. (Teletext)

S.MODE: Selects sound mode.

Connections

Cautions before connecting

Carefully check the terminals for position and type before making any connections.

The illustration of the external equipment may be different depending on your model.

Loose connectors can result in image or color problems. Make sure that all connectors are securely inserted into their terminals.

Refer to the operating manual of the external device as well.

When connecting an external device, turn the power off to avoid any issues.

Connecting digital coaxial audio

TV REAR

HIFi System

For a full Home Theater sound experience, you must connect your Hi-Fi or Audio processor to the S/PDIF OUT(Coaxial) terminal on the TV rear.

Note

The S/PDIF OUT terminal only can output digital TV program’s audio.

Audio Processor

Coaxial cable

S/PDIF IN

(Coaxial)

Connections (Continued)

Connecting a Camcorder

TV REAR

Camcorder

Cables are often color-coded to connectors. Connect red to red, white to white, etc.

AV cable

How to connect:

Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and camcorder.

To playback Camcorder

1. Turn on your TV, then press SOURCE button. The Input Source menu opens.

2. Press 5or6to select AV, then press OK to confirm.

3. Turn on your camcorder and set it to output mode. (For details, refer to your camcorder user manual.)

4. Insert the tape into the camcorder and press Play button.

“PlayStation”

Note

The operations of the camcorder may be different and is dependant on your model. Please read the user manual of your camcorder to confirm operation.

Connecting an HDMI device

TV REAR

Device with HDMI output

HDMI cable

How to connect a device using HDMI Connection:

Connect the HDMI cable between the HDMI1or HDMI2 interface on the unit and HDMI output on the device.

To play from the device using HDMI:

1. Turn on your TV, then press SOURCE button. The Input Source menu opens.

2. Press 5or6to select HDMI1/HDMI2 correspondingly, then press OK to confirm.

3. Turn on your device and set it to the correct mode. See the device’s user guide for more information.

Note

If the external device has DVI output only, use a DVI to HDMI adapter cable to connect to the HDMI terminal. Connect the audio cable to the D-SUB AUDIO IN jack on the TV rear.

+ 25 hidden pages
