Sanyo LC75854W Specifications

Overview

The LC75854E and LC75854W are 1/4 duty LCD display
drivers that can directly drive up to 164 segments and can
control up to four general-purpose output ports. These
products also incorporate a key scan circuit that accepts
input from up to 30 keys to reduce printed circuit board
wiring.

Features

• Key input function for up to 30 keys (A key scan is
performed only when a key is pressed.)

• 1/4 duty - 1/2 bias and 1/4 duty - 1/3 bias drive schemes
can be controlled from serial data (up to 164 segments).

• Sleep mode and all segments off functions that are
controlled from serial data

• Segment output port/general-purpose output port
function switching that is controlled from serial data

• Serial data I/O supports CCB format communication
with the system controller.

• Direct display of display data without the use of a
decoder provides high generality.

• Provision of an on-chip voltage-detection type reset
circuit prevents incorrect displays.

• RC oscillator circuit

Package Dimensions

unit: mm

3159-QFP64E

Ordering number : ENN5066B

O3099TH (OT)/N3095HA (OT)/52295TH (OT) No. 5066-1/25

LC75854E, 75854W

SANYO Electric Co.,Ltd. Semiconductor Company

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN

1/4 Duty LCD Display Drivers

with Key Input Function

CMOS IC

Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft’s
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.

SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.

unit: mm

3190-SQFP64

10.0

12.0

1.25

0.5

1.25

1.25 0.5 1.250.18

12.0

116

17

32

33

48

49

64

10.0

0.5

1.7max

0.5

0.1

0.15

SANYO: SQFP64

[LC75854W]

• CCB is a trademark of SANYO ELECTRIC CO., LTD.

• CCB is SANYO’s original bus format and all the bus
addresses are controlled by SANYO.

[LC75854E]

SANYO: QFP64E

17.2

14.0

0.8

0.35

15.6

1.6

14.0

17.2

1.0

0.8

1.0

1.0

48

49

64

1

1.6

1.0

33

32

17

16

0.8

0.15

0.1

3.0max

2.7

Specifications

Absolute Maximum Ratings at Ta = 25°C, VSS= 0 V

Allowable Operating Ranges at Ta = –40 to +85°C, VSS= 0 V

No. 5066-2/25

LC75854E, 75854W

Parameter Symbol Conditions Ratings Unit

Maximum supply voltage V

DD

max V

DD

–0.3 to +7.0 V

Input voltage

V

IN

1 CE, CL, DI –0.3 to +7.0 V

V

IN

2 OSC, KI1 to KI5, TEST, VDD1, VDD2 –0.3 to VDD+ 0.3 V

Output voltage

V

OUT

1 DO –0.3 to +7.0 V

V

OUT

2 OSC, S1 to S41, COM1 to COM4, KS1 to KS6, P1 to P4 –0.3 to VDD+ 0.3 V

I

OUT

1 S1 to S41 300 µA

Output current

I

OUT

2 COM1 to COM4 3 mA

I

OUT

3 KS1 to KS6 1 mA

I

OUT

4 P1 to P4 5 mA
Allowable power dissipation Pd max Ta = 85°C 200 mW
Operating temperature Topr –40 to +85 °C
Storage temperature Tstg –55 to +125 °C

Parameter Symbol Conditions

Ratings

Unit

min typ max

Supply voltage V

DD

V

DD

4.5 6.0 V

Input voltage

V

DD

1VDD1 2/3 V

DD

V

DD

V

V

DD

2VDD2 1/3 V

DD

V

DD

V

Input high level voltage

V

IH

1 CE, CL, DI 0.8 V

DD

6.0 V

V

IH

2 KI1 to KI5 0.6 V

DD

V

DD

V

Input low level voltage V

IL

CE, CL, DI, KI1 to KI5 0 0.2 V

DD

V

Recommended external

R

OSC

OSC 62 kΩ

resistance
Recommended external

C

OSC

OSC 680 pF

capacitance
Guaranteed oscillation range f

OSC

OSC 25 50 100 kHz

Data setup time t

ds

CL, DI: Figure 2 160 ns

Data hold time t

dh

CL, DI: Figure 2 160 ns

CE wait time t

cp

CE, CL: Figure 2 160 ns

CE setup time t

cs

CE, CL: Figure 2 160 ns

CE hold time t

ch

CE, CL: Figure 2 160 ns

High level clock pulse width t

øH

CL: Figure 2 160 ns

Low level clock pulse width t

øL

CL: Figure 2 160 ns

Rise time t

r

CE, CL, DI: Figure 2 160 ns

Fall time t

f

CE, CL, DI: Figure 2 160 ns

DO output delay time t

dc

DO, RPU= 4.7 kΩ, CL= 10 pF*1: Figure 2 1.5 µs

DO rise time t

dr

DO, RPU= 4.7 kΩ, CL= 10 pF*1: Figure 2 1.5 µs

Note: *1. Since DO is an open-drain output, these values depend on the resistance of the pull-up resistor RPUand the load capacitance CL.

Electrical Characteristics for the Allowable Operating Ranges

No. 5066-3/25

LC75854E, 75854W

Parameter Symbol Conditions

Ratings

Unit

min typ max

Hysteresis V

H

CE, CL, DI 0.1 V

DD

V

Power-down detection voltage V

DET

2.7 3.0 3.3 V

Input high level current I

IH

CE, CL, DI: VI= 6.0 V 5.0 µA

Input low level current I

IL

CE, CL, DI: VI= 0 V –5.0 µA

Input floating voltage V

IF

KI1 to KI5 0.05 V

DD

V

Pull-down resistance R

PD

KI1 to KI5: VDD= 5.0 V 50 100 250 kΩ

Output off leakage current I

OFFH

DO: VO= 6.0 V 6.0 µA

V

OH

1 KS1 to KS6: IO= –500 µA VDD– 1.2 VDD– 0.5 VDD– 0.2 V

Output high level voltage

V

OH

2 P1 to P4: IO= –1 mA VDD– 1.0 V

V

OH

3 S1 to S41: IO= –20 µA VDD– 1.0 V

V

OH

4 COM1 to COM4: IO= –100 µA VDD– 1.0 V

V

OL

1 KS1 to KS6: IO= 25 µA 0.2 0.5 1.5 V

V

OL

2 P1 to P4: IO= 1 mA 1.0 V

Output low level voltage V

OL

3 S1 to S41: IO= 20 µA 1.0 V

V

OL

4 COM1 to COM4: IO= 100 µA 1.0 V

V

OL

5 DO: IO= 1 mA 0.1 0.5 V

V

MID

1 COM1 to COM4: 1/2 bias, IO= ±100 µA

1/2 V

DD

– 1/2 VDD+

V

1.0 1.0

V

MID

2 S1 to S41: 1/3 bias, IO= ±20 µA

2/3 V

DD

– 2/3 VDD+

V

1.0 1.0

Output middle level voltage

*2

V

MID

3 S1 to S41: 1/3 bias, IO= ±20 µA

1/3 V

DD

– 1/3 VDD+

V

1.0 1.0

V

MID

4 COM1 to COM4: 1/3 bias, IO= ±100 µA

2/3 V

DD

– 2/3 VDD+

V

1.0 1.0

V

MID

5 COM1 to COM4: 1/3 bias, IO= ±100 µA

1/3 V

DD

– 1/3 VDD+

V

1.0 1.0

Oscillator frequency f

OSC

OSC: R = 62 kΩ, C = 680 pF 40 50 60 kHz

I

DD

1 Sleep mode 100 µA

Current drain I

DD

2VDD= 6.0 V, output open, 1/2 bias, f

OSC

= 50 kHz 250 500 µA

I

DD

3VDD= 6.0 V, output open, 1/3 bias, f

OSC

= 50 kHz 200 400 µA

Note: *2. Excluding the bias voltage generation divider resistor built into VDD1 and VDD2. (See Figure 1.)

Figure 1

To the common segment driver

Excluding these resistors.

1. When CL is stopped at the low level

No. 5066-4/25

LC75854E, 75854W

2. When CL is stopped at the high level

Figure 2

Block Diagram

No. 5066-5/25

LC75854E, 75854W

Pin Assignment

Pin Functions

No. 5066-6/25

LC75854E, 75854W

Pin Pin No. Function Active I/O

Handling

when unused

S1/P1 to S4/P4

S5 to S39

COM1
COM2
COM3
COM4

KS1/S40,
KS2/S41,

KS3 to KS6

KI1 to KI5

OSC

CE

CL

DI

DO

TEST

V

DD

1

V

DD

2

V

DD

V

SS

1 to 4

5 to 39

40
41
42
43

44
45

46 to 49

50 to 54

60

62
63
64
61

55

57

58

56
59

Segment outputs for displaying the display data transferred by serial data
input.

The S1/P1 to S4/P4 pins can be used as general-purpose output ports
under serial data control.

Common driver outputs
The frame frequency f

O

is given by: fO= (f

OSC

/512) Hz.

Key scan outputs
Although normal key scan timing lines require diodes to be inserted in the
timing lines to prevent shorts, since these outputs are unbalanced CMOS
transistor outputs, these outputs will not be damaged by shorting when
these outputs are used to form a key matrix. The KS1/S40 and KS2/S41
pins can be used as segment outputs when so specified by the control data.

Key scan inputs
These pins have built-in pull-down resistors.

Oscillator connection
An oscillator circuit is formed by connecting an external resistor and
capacitor at this pin.

Serial data interface connections to the controller. Note that DO, being an
open-drain output, requires a pull-up resistor.

CE: Chip enable
CL: Synchronization clock
DI: Transfer data
DO: Output data

This pin must be connected to ground.

Used for applying the LCD drive 2/3 bias voltage externally. Must be
connected to V

DD

2 when a 1/2 bias drive scheme is used.

Used for applying the LCD drive 1/3 bias voltage externally. Must be
connected to V

DD

1 when a 1/2 bias drive scheme is used.

Power supply connection. Provide a voltage of between 4.5 and 6.0 V.
Power supply connection. Connect to ground.

—

—

—

H

—

H

—
—
—

—

—

—
—

O

O

O

I

I/O

I
I
I

O

I

I

I

—
—

Open

Open

Open

GND

V

DD

GND

Open

—

Open

Open

—
—

Serial Data Input

1. When CL is stopped at the low level

No. 5066-7/25

LC75854E, 75854W

Note: DD: Direction data

Display data

Display data

Display data

Display data

Control data

Fixed data

Fixed data

Fixed data

Note: DD: Direction data

• CCB address......42H

• D1 to D164........Display data

• S0, S1................Sleep control data

• K0, K1...............Key scan output/segment output selection data

• P0, P1................Segment output port/general-purpose output port selection data

• SC......................Segment on/off control data

• DR.....................1/2 bias or 1/3 bias drive selection data

No. 5066-8/25

LC75854E, 75854W

2. When CL is stopped at the high level

Display data

Display data

Display data

Display data

Control data

Fixed data

Fixed data

Fixed data

Control Data Functions

1. S0, S1: Sleep control data
These control data bits switch between normal mode and sleep mode and set the states of the KS1 to KS6 key scan
outputs during key scan standby.

Note: This assumes that the KS1/S40 and KS2/S41 output pins are selected for key scan output.

2. K0, K1: Key scan output/segment output selection data
These control data bits switch the functions of the KS1/S40 and KS2/S41 output pins between key scan output and
segment output.

✕: don’t care

3. P0, P1: Segment output port/general-purpose output port selection data
These control data bits switch the functions of the S1/P1 to S4/P4 output pins between the segment output port and
the general-purpose output port.

The table below lists the correspondence between the display data and the output pins when these pins are selected to
be general-purpose output ports.

For example, if the S4/P4 output pin is selected to be a general-purpose output port, the S4/P4 output pin will output
a high level when the display data D13 is 1.

4. SC: Segment on/off control data
This control data bit controls the on/off state of the segments.

However, note that when the segments are turned off by setting SC to 1, the segments are turned off by outputting
segment off waveforms from the segment output pins.

No. 5066-9/25

LC75854E, 75854W

Control data

Mode OSC oscillator

Segment outputs

Output pin states during key scan standby

S0 S1

Common outputs

KS1 KS2 KS3 KS4 KS5 KS6
0 0 Normal Operating Operating H H H H H H
0 1 Sleep Stopped L L L L L L H
1 0 Sleep Stopped L L L L L H H
1 1 Sleep Stopped L H H H H H H

Control data Output pin state

Maximum number of input keys

K0 K1 KS1/S40 KS2/S41

0 0 KS1 KS2 30
0 1 S40 KS2 25
1 ✕ S40 S41 20

Control data Output pin state

P0 P1 S1/P1 S2/P2 S3/P3 S4/P4

0 0 S1 S2 S3 S4
0 1 P1 P2 S3 S4
1 0 P1 P2 P3 S4
1 1 P1 P2 P3 P4

Output pin Corresponding display data

S1/P1 D1
S2/P2 D5
S3/P3 D9
S4/P4 D13

SC Display state

0On
1 Off

5. DR: 1/2 bias or 1/3 bias drive selection data
This control data bit switches between LCD 1/2 bias or 1/3 bias drive.

Display Data and Output Pin Correspondence

For example, the table below lists the segment output states for the S11 output pin.

No. 5066-10/25

LC75854E, 75854W

DR Drive scheme

0 1/3 bias drive
1 1/2 bias drive

Output pin COM1 COM2 COM3 COM4
S1/P1 D1 D2 D3 D4
S2/P2 D5 D6 D7 D8
S3/P3 D9 D10 D11 D12
S4/P4 D13 D14 D15 D16
S5 D17 D18 D19 D20
S6 D21 D22 D23 D24
S7 D25 D26 D27 D28
S8 D29 D30 D31 D32
S9 D33 D34 D35 D36
S10 D37 D38 D39 D40
S11 D41 D42 D43 D44
S12 D45 D46 D47 D48
S13 D49 D50 D51 D52
S14 D53 D54 D55 D56
S15 D57 D58 D59 D60
S16 D61 D62 D63 D64
S17 D65 D66 D67 D68
S18 D69 D70 D71 D72
S19 D73 D74 D75 D76
S20 D77 D78 D79 D80

Output pin COM1 COM2 COM3 COM4
S21 D81 D82 D83 D84
S22 D85 D86 D87 D88
S23 D89 D90 D91 D92
S24 D93 D94 D95 D96
S25 D97 D98 D99 D100
S26 D101 D102 D103 D104
S27 D105 D106 D107 D108
S28 D109 D110 D111 D112
S29 D113 D114 D115 D116
S30 D117 D118 D119 D120
S31 D121 D122 D123 D124
S32 D125 D126 D127 D128
S33 D129 D130 D131 D132
S34 D133 D134 D135 D136
S35 D137 D138 D139 D140
S36 D141 D142 D143 D144
S37 D145 D146 D147 D148
S38 D149 D150 D151 D152
S39 D153 D154 D155 D156
KS1/S40 D157 D158 D159 D160
KS2/S41 D161 D162 D163 D164

Display data Output pin state

D41 D42 D43 D44 S11

0 0 0 0 The LCD segments for COM1, COM2, COM3 and COM4 are off.
0 0 0 1 The LCD segment for COM4 is on.
0 0 1 0 The LCD segment for COM3 is on.
0 0 1 1 The LCD segments for COM3 and COM4 are on.
0 1 0 0 The LCD segment for COM2 is on.
0 1 0 1 The LCD segments for COM2 and COM4 are on.
0 1 1 0 The LCD segments for COM2 and COM3 are on.
0 1 1 1 The LCD segments for COM2, COM3 and COM4 are on.
1 0 0 0 The LCD segment for COM1 is on.
1 0 0 1 The LCD segments for COM1 and COM4 are on.
1 0 1 0 The LCD segments for COM1 and COM3 are on.
1 0 1 1 The LCD segments for COM1, COM3 and COM4 are on.
1 1 0 0 The LCD segments for COM1 and COM2 are on.
1 1 0 1 The LCD segments for COM1, COM2 and COM4 are on.
1 1 1 0 The LCD segments for COM1, COM2 and COM3 are on.
1 1 1 1 The LCD segments for COM1, COM2, COM3 and COM4 are on.

Serial Data Output

1. When CL is stopped at the low level

2. When CL is stopped at the high level

• CCB address...............43H

• KD1 to KD30.............Key data

• SA...............................Sleep acknowledge data

Note: If a key data read operation is executed when DO is high, the read key data (KD1 to KD30) and sleep

acknowledge data (SA) will be invalid.

Output Data

1. KD1 to KD30: Key data
When a key matrix of up to 30 keys is formed from the KS1 to KS6 output pins and the KI1 to KI5 input pins and
one of those keys is pressed, the key output data corresponding to that key will be set to 1. The table shows the
relationship between those pins and the key data bits.

When the KS1/S40 and KS2/S41 output pins are selected to be segment outputs by control data bits K0 and K1 and a
key matrix of up to 20 keys is formed using the KS3 to KS6 output pins and the KI1 to KI5 input pins, the KD1 to
KD10 key data bits will be set to 0.

2. SA: Sleep acknowledge data
This output data bit is set to the state when the key was pressed. Also, while DO will be low in this case, if serial data
is input and the mode is set (to normal or sleep mode) during this period, that mode will be set. SA will be 1 in sleep
mode and 0 in normal mode.

No. 5066-11/25

LC75854E, 75854W

KI1 KI2 KI3 KI4 KI5
KS1/S40 KD1 KD2 KD3 KD4 KD5
KS2/S41 KD6 KD7 KD8 KD9 KD10

KS3 KD11 KD12 KD13 KD14 KD15
KS4 KD16 KD17 KD18 KD19 KD20
KS5 KD21 KD22 KD23 KD24 KD25
KS6 KD26 KD27 KD28 KD29 KD30

Output data

Output data

Sleep Mode Functions

Sleep mode is set up by setting S0 or S1 in the control data to 1. The segment outputs will all go low and the common
outputs will also go low, and the oscillator on the OSC pin will stop (it will be started by a key press). This reduces
power dissipation. This mode is cleared by sending control data with both S0 and S1 set to 0. However, note that the
S1/P1 to S4/P4 outputs can be used as general-purpose output ports according to the state of the P0 and P1 control data
bits, even in sleep mode. (See the control data description for details.)

Key Scan Operation Functions

1. Key scan timing
The key scan period is 384 T (s). To reliably determine the on/off state of the keys, the LC75854E/W scans the keys
twice and determines that a key has been pressed when the key data agrees. It outputs a key data read request (a low
level on DO) 800 T (s) after starting a key scan. If the key data does not agree and a key was pressed at that point, it
scans the keys again. Thus the LC75854E/W cannot detect a key press shorter than 800 T (s).

Note: *3. In sleep mode the high/low state of these pins is determined by the S0 and S1 bits in the control data. Key scan output signals are not output

from pins that are set low.

2. In normal mode

• The pins KS1 to KS6 are set high

• When a key is pressed a key scan is started and the keys are scanned until all keys are released. Multiple key

presses are recognized by determining whether multiple key data bits are set.

• If a key is pressed for longer than 800 T (s) (where T = ) the LC75854E/W outputs a key data read request (a

low level on DO) to the controller. The controller acknowledges this request and reads the key data. However, if
CE is high during a serial data transfer, DO will be set high.

• After the controller reads the key data, the key data read request is cleared (DO is set high) and the LC75854E/W

performs another key scan. Also note that DO, being an open-drain output, requires a pull-up resistor (between 1
and 10 kΩ).

1

f

OSC

No. 5066-12/25

LC75854E, 75854W

3. In sleep mode

• The pins KS1 to KS6 are set to high or low by the S0 and S1 bits in the control data. (See the control data

description for details.)

• If a key on one of the lines corresponding to a KS1 to KS6 pin which is set high is pressed, the oscillator on the

OSC pin is started and a key scan is performed. Keys are scanned until all keys are released. Multiple key presses
are recognized by determining whether multiple key data bits are set.

• If a key is pressed for longer than 800 T (s) (where T = ) the LC75854E/W outputs a key data read request (a

low level on DO) to the controller. The controller acknowledges this request and reads the key data. However, if
CE is high during a serial data transfer, DO will be set high.

• After the controller reads the key data, the key data read request is cleared (DO is set high) and the LC75854E/W

performs another key scan. However, this does not clear sleep mode. Also note that DO, being an open-drain
output, requires a pull-up resistor (between 1 and 10 kΩ).

• Sleep mode key scan example

Example: S0 = 0, S1 = 1 (sleep with only KS6 high)

Note *4. These diodes are required to reliable recognize multiple key presses on the KS6 line when sleep mode state with only KS6 high, as in the

above example. That is, these diodes prevent incorrect operations due to sneak currents in the KS6 key scan output signal when keys on
the KS1 to KS5 lines are pressed at the same time.

1

f

OSC

No. 5066-13/25

LC75854E, 75854W

Key input 1

Key input 2

Key scan

Serial data transfer

Serial data transfer

Serial data transferKey address (43H) Key address Key address

Key data read request

Key data read request Key data read request

Key data read Key data read

Key data read

When any one of these keys is pressed, the
oscillator on the OSC pin is started and the keys
are scanned.

Multiple Key Presses

Although the LC75854E/W is capable of key scanning without inserting diodes for dual key presses, triple key presses
on the KI1 to KI5 input pin lines, or multiple key presses on the KS1 to KS6 output pin lines, multiple presses other than
these cases may result in keys that were not pressed recognized as having been pressed. Therefore, a diode must be
inserted in series with each key. Applications that do not recognize multiple key presses of three or more keys should
check the key data for three or more 1 bits and ignore such data.

No. 5066-14/25

LC75854E, 75854W

Key input
(KS6 line)

Key scan

Serial data transfer

Key address (43H)

Key address

Key data read request

Key data read

Key data read request

Key data read

Serial data transfer

Serial data transfer

1/4 Duty, 1/2 Bias Drive Technique

No. 5066-15/25

LC75854E, 75854W

COM1

COM2

COM3

COM4

LCD driver output when all LCD segments
corresponding to COM1, COM2, COM3 and COM4
are turned off.

LCD driver output when only LCD segments
corresponding to COM1 are on

LCD driver output when only LCD segments
corresponding to COM2 are on.

LCD driver output when LCD segments
corresponding to COM1 and COM2 are on.

LCD driver output when only LCD segments
corresponding to COM3 are on.

LCD driver output when LCD segments
corresponding to COM1 and COM3 are on.

LCD driver output when LCD segments
corresponding to COM2 and COM3 are on.

LCD driver output when LCD segments
corresponding to COM1, COM2 and COM3 are on.

LCD driver output when only LCD segments
corresponding to COM4 are on.

LCD driver output when LCD segments
corresponding to COM2 and COM4 are on.

LCD driver output when all LCD segments
corresponding to COM1, COM2, COM3 and COM4
are on.

1/4 Duty, 1/2 Bias Waveforms

1/4 Duty, 1/3 Bias Drive Technique

No. 5066-16/25

LC75854E, 75854W

COM1

COM2

COM3

COM4

LCD driver output when all LCD segments
corresponding to COM1, COM2, COM3 and COM4
are turned off.

LCD driver output when only LCD segments
corresponding to COM1 are on

LCD driver output when only LCD segments
corresponding to COM2 are on.

LCD driver output when LCD segments
corresponding to COM1 and COM2 are on.

LCD driver output when only LCD segments
corresponding to COM3 are on.

LCD driver output when LCD segments
corresponding to COM1 and COM3 are on.

LCD driver output when LCD segments
corresponding to COM2 and COM3 are on.

LCD driver output when LCD segments
corresponding to COM1, COM2 and COM3 are on.

LCD driver output when only LCD segments
corresponding to COM4 are on.

LCD driver output when LCD segments
corresponding to COM2 and COM4 are on.

LCD driver output when all LCD segments
corresponding to COM1, COM2, COM3 and COM4
are on.

1/4 Duty, 1/3 Bias Waveforms

Voltage Detection Type Reset Circuit (VDET)

This circuit generates an output signal and resets the system when power is first applied and when the voltage drops, i.e.,
when the power supply voltage is less than or equal to the power down detection voltage VDET, which is 3.0 V, typical.
To assure that this function operates reliably, a capacitor must be added to the power supply line so that the power
supply voltage VDDrise time when power is first applied and the power supply voltage VDDfall time when the voltage
drops are both at least 1 ms. (See Figure 3.)

System Reset

1. Reset method
If at least 1 ms is assured as the supply voltage VDDrise time when power is applied, a system reset will be applied
by the VDET output signal when the supply voltage is brought up. If at least 1 ms is assured as the supply voltage
VDDfall time when power drops, a system reset will be applied in the same manner by the VDET output signal when
the supply voltage is lowered. Note that the reset is cleared at the point when all the serial data (the display data D1
to D164 and the control data) has been transferred, i.e., on the fall of the CE signal on the transfer of the last
direction data, after all the direction data has been transferred. (See Figure 3.)

Figure 3

2. LC75854E/W internal block states during the reset period

• CLOCK GENERATOR

Reset is applied and the base clock is stopped. However the OSC pin state (normal or sleep mode) is determined
after the S0 and S1 control data bits are transferred.

• COMMON DRIVER, SEGMENT DRIVER & LATCH

Reset is applied and the display is turned off. However, display data can be input to the latch circuit in this state.

• KEY SCAN

Reset is applied, the circuit is set to the initial state, and at the same time the key scan operation is disabled.

• KEY BUFFER

Reset is applied and all the key data is set to low.

• CCB INTERFACE, CONTROL REGISTER, SHIFT REGISTER

Since serial data transfer is possible, these circuits are not reset.

No. 5066-17/25

LC75854E, 75854W

Internal data

Undefined

Defined

System reset period

Display and control data transfer

Power supply voltage VDDrise time: t1 ≥ 1 ms
Power supply voltage V

DD

fall time: t2 ≥ 1 ms

3. Output pin states during the reset period

✕: Don’t care
Note: * 5. These output pins are forcibly set to the segment output function and held low.

* 6. When power is first applied, these output pins are undefined until the S0 and S1 control data bits have been transferred.
* 7. Since this output pin is an open-drain output, a pull-up resistor of between 1 and 10 kΩ is required. This pin remains high during the reset

period even if a key data read operation is performed.

No. 5066-18/25

LC75854E, 75854W

Output pin State during reset

S1/P1 to S4/P4 L

*5

S5 to S39 L
COM1 to COM4 L
KS1/S40, KS2/S41 L

*5

KS3 to KS5 ✕

*6

KS6 H
DO H

*7

Blocks that are reset

Sample Application Circuit 1

Note: *8.Add a capacitor to the power supply line so that the power supply voltage VDDrise time when power is applied and the power supply voltage V

DD

fall time when power drops are both at least 1 ms, as the LC75854E/W is reset by the VDET.

*9.The DO pin, being an open-drain output, requires a pull-up resistor. Select a resistance (between 1 to 10 kΩ) appropriate for the capacitance of the

external wiring so that signal waveforms are not degraded.

No. 5066-19/25

LC75854E, 75854W

COM1
COM2
COM3
COM4

P1/S1
P2/S2
P3/S3
P4/S4

S5

(P1)
(P2)
(P3)
(P4)

(general-purpose
output ports)
Used with the
backlight controller
or other circuit.

S39

K

I

1

K

I

2

K

I

3

K

I

4

K

I

5

S
4
0

/
K
S
1

S
4
1

/
K
S
2

K
S
3

K
S
4

K
S

5

K
S
6

(S40)
(S41)

VDD1
VDD2

V

SS

TEST

V

DD

OSC

+5V

*8

From the controller
To the controller

To the controller
power supply

Key matrix
(up to 30 keys)

C

C ≥ 0.047 µF

CE
CL
DI
DO

*9

LCD panel (up to 164 segments)

1/2 bias (for use with normal panels)

Sample Application Circuit 2

No. 5066-20/25

LC75854E, 75854W

COM1
COM2
COM3
COM4

P1/S1
P2/S2
P3/S3
P4/S4

S5

(P1)
(P2)
(P3)
(P4)

(general-purpose
output ports)
Used with the
backlight controller
or other circuit.

S39

K

I

1

K

I

2

K

I

3

K

I

4

K

I

5

S
4
0

/
K
S
1

S
4
1

/
K
S
2

K
S
3

K
S
4

K
S
5

K
S
6

(S40)
(S41)

VDD1
VDD2

V

SS

TEST

V

DD

OSC

+5V

RRR

*8

From the controller
To the controller

To the controller
power supply

Key matrix
(up to 30 keys)

C

C ≥ 0.047 µF
10kΩ ≥ R ≥ 1 kΩ

CE
CL
DI
DO

*9

LCD panel (up to 164 segments)

Note: *8.Add a capacitor to the power supply line so that the power supply voltage VDDrise time when power is applied and the power supply voltage V

DD

fall time when power drops are both at least 1 ms, as the LC75854E/W is reset by the VDET.

*9.The DO pin, being an open-drain output, requires a pull-up resistor. Select a resistance (between 1 to 10 kΩ) appropriate for the capacitance of the

external wiring so that signal waveforms are not degraded.

1/2 bias (for use with large panels)

Sample Application Circuit 3

Note: *8.Add a capacitor to the power supply line so that the power supply voltage VDDrise time when power is applied and the power supply voltage V

DD

fall time when power drops are both at least 1 ms, as the LC75854E/W is reset by the VDET.

*9.The DO pin, being an open-drain output, requires a pull-up resistor. Select a resistance (between 1 to 10 kΩ) appropriate for the capacitance of the

external wiring so that signal waveforms are not degraded.

No. 5066-21/25

LC75854E, 75854W

COM1
COM2
COM3
COM4

P1/S1

P2/S2

P3/S3

P4/S4

S5

(P1)
(P2)
(P3)
(P4)

(general-purpose
output ports)
Used with the
backlight controller
or other circuit.

S39

K

I

1

K

I

2

K

I

3

K

I
4

K

I

5

S
4
0

/
K
S
1

S

4
1

/
K
S

2

K
S

3

K
S
4

K
S
5

K
S
6

(S40)
(S41)

VDD1
VDD2

V

SS

TEST

V

DD

OSC

+5V

*8

From the controller
To the controller

To the controller
power supply

Key matrix
(up to 30 keys)

C

C ≥ 0.047 µF

CE
CL
DI
DO

*9

LCD panel (up to 164 segments)

C

1/3 bias (for use with normal panels)

Sample Application Circuit 4

Note: *8.Add a capacitor to the power supply line so that the power supply voltage VDDrise time when power is applied and the power supply voltage V

DD

fall time when power drops are both at least 1 ms, as the LC75854E/W is reset by the VDET.

*9.The DO pin, being an open-drain output, requires a pull-up resistor. Select a resistance (between 1 to 10 kΩ) appropriate for the capacitance of the

external wiring so that signal waveforms are not degraded.

Notes on transferring display data from the controller

The display data (D1 to D164) is transferred to the LC75854E/W in four operations. All of the display data should be
transferred within 30 ms to maintain the quality of the displayed image.

Notes on the controller key data read techniques

1. Timer based key data acquisition

No. 5066-22/25

LC75854E, 75854W

Key data read

processing

COM1
COM2
COM3
COM4

P1/S1
P2/S2
P3/S3
P4/S4

S5

(P1)
(P2)
(P3)
(P4)

(general-purpose
output ports)
Used with the
backlight controller
or other circuit.

S39

K

I

1

K

I

2

K

I

3

K

I
4

K

I

5

S
4
0

/
K
S
1

S

4
1

/
K
S

2

K
S

3

K
S
4

K
S
5

K
S
6

(S40)
(S41)

VDD1
VDD2

V

SS

TEST

V

DD

OSC

+5V

RRR

*8

From the controller
To the controller

To the controller
power supply

Key matrix
(up to 30 keys)

C

C ≥ 0.047 µF
10kΩ ≥ R ≥ 1 kΩ

CE
CL
DI
DO

*9

LCD panel (up to 164 segments)

C

R

1/3 bias (for use with large panels)

• Timing chart

t3: Key scan execution time when the key data agreed for two key scans. (800 T (s))
t4: Key scan execution time when the key data did not agree for two key scans and the key scan was executed again. (1600 T (s))

T =

t5: Key address (43H) transfer time
t6: Key data read time

• Explanation
In this technique, the controller uses a timer to determine key on/off states and read the key data. The controller
must check the DO state when CE is low every t7 period without fail. If DO is low, the controller recognizes that a
key has been pressed and executes the key data read operation.
The period t7 in this technique must satisfy the following condition.

t7 > (t5 + t6 + t4)

If a key data read operation is executed when DO is high, the read key data (KD1 to KD30) and sleep acknowledge
data (SA) will be invalid.

2. Interrupt based key data acquisition

• Flowchart

1

f

OSC

No. 5066-23/25

LC75854E, 75854W

Key input

Key scan

Key data read request

Key data read

Controller determination

(key on)

Controller determination

(key on)

Controller determination

(key off)

Controller determination

(key on)

Controller determination

(key off)

Key data read

processing

Wait for at

least t8

Key address

• Timing chart

t3: Key scan execution time when the key data agreed for two key scans. (800 T (s))
t4: Key scan execution time when the key data did not agree for two key scans and the key scan was executed again. (1600 T (s))

T =

t5: Key address (43H) transfer time
t6: Key data read time

• Explanation
In this technique, the controller uses interrupts to determine key on/off states and read the key data. The controller
must check the DO state when CE is low. If DO is low, the controller recognizes that a key has been pressed and
executes the key data read operation. After that the next key on/off determination is performed after the time t8 has
elapsed by checking the DO state when CE is low and reading the key data. The period t8 in this technique must
satisfy the following condition.

t8 > t4

If a key data read operation is executed when DO is high, the read key data (KD1 to KD30) and sleep acknowledge
data (SA) will be invalid.

1

f

OSC

No. 5066-24/25

LC75854E, 75854W

Key input

Key scan

Key data read request

Key data read

Controller

determination

(key on)

Controller

determination

(key off)

Controller

determination

(key on)

Controller

determination

(key on)

Controller

determination

(key on)

Controller

determination

(key off)

Key address

PS No. 5066-25/25

LC75854E, 75854W

This catalog provides information as of October, 1999. Specifications and information herein are subject
to change without notice.

Specifications of any and all SANYO products described or contained herein stipulate the performance,
characteristics, and functions of the described products in the independent state, and are not guarantees
of the performance, characteristics, and functions of the described products as mounted in the customer’s
products or equipment. To verify symptoms and states that cannot be evaluated in an independent device,
the customer should always evaluate and test devices mounted in the customer’s products or equipment.

SANYO Electric Co., Ltd. strives to supply high-quality high-reliability products. However, any and all
semiconductor products fail with some probability. It is possible that these probabilistic failures could
give rise to accidents or events that could endanger human lives, that could give rise to smoke or fire,
or that could cause damage to other property. When designing equipment, adopt safety measures so
that these kinds of accidents or events cannot occur. Such measures include but are not limited to protective
circuits and error prevention circuits for safe design, redundant design, and structural design.

In the event that any or all SANYO products (including technical data, services) described or contained
herein are controlled under any of applicable local export control laws and regulations, such products must
not be exported without obtaining the export license from the authorities concerned in accordance with the
above law.

No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, or any information storage or retrieval system,
or otherwise, without the prior written permission of SANYO Electric Co., Ltd.

Any and all information described or contained herein are subject to change without notice due to
product/technology improvement, etc. When designing equipment, refer to the “Delivery Specification”
for the SANYO product that you intend to use.

Information (including circuit diagrams and circuit parameters) herein is for example only; it is not
guaranteed for volume production. SANYO believes information herein is accurate and reliable, but
no guarantees are made or implied regarding its use or any infringements of intellectual property rights
or other rights of third parties.
