Typical Characteristics
1.4
1.2
1.0
0.8
0 1020304050607080
Charge : 500mA×16Hrs.
at 20˚C/68˚F
(2 It)
(1 It)
Cell Voltage (V)
Discharge Time (Mins)
1.4
1.2
1.0
0.8
0 2 4 6 8 10121416
Charge : 500mA×16Hrs.
at 20˚C/68˚F
(4 It)(8 It)
Cell Voltage (V)
Discharge Time (Mins)
100
80
60
40
-20-100 102030405060˚C
-4 14 32 50 68 86 104 122 140˚F
Available Capacity (%)
Operating Temperature
90
70
50
Charge Characteristics
Discharge Characteristics
Condition Charge : 500mA×16Hrs.
Discharge : 1000mA
(End Volt 1.0V)
Dimensions
of
Bare Cell
D
d
H
±0.4
58.4
H
D
d
±0.016
2.299
±0.3
32.3
±0.012
1.272
10.0 mm
0.394 inch
Cell Type KR-5000DEL
Specifications
Nominal Capacity 5000mAh
Nominal Voltage 1.2V
Charging Current
Charging Time
Charge
Ambient
Temperature
Discharge -20°C to +60°C [ -4°F to 140°F]
Storage -30°C to +50°C [ -22°F to 122°F]
Internal Impedance (Av.)
mm
(at 50% discharge)
inch
Weight 150g/5.28oz
mm
inch
Dimensions(D)×(H)
(with tube)
Standard 500mA
Fast 7500mA
Standard 14 to 16Hrs.
Fast about 1Hr.
Standard 0°C to +45°C [+32°F to 113°F]
Fast 0°C to +45°C [+32°F to 113°F]
33.2
1.31
3.5m
Ω
(at 1000Hz)
0
59.5
×
-0.9 -1.5
0
2.34
×
-0.04 -0.06
0
0
mm
inch
Charge
1.6
1.5
1.4
Cell Voltage (V)
1.3
Charge
1.6
1.5
1.4
Cell Voltage (V)
1.3
Charge : 500mA
0˚C/32˚F
20˚C/68˚F
45˚C/113˚F
0246810121416
Charge Time (Hrs.)
Temperature :
20˚C/68˚F
1.5 It
0.1 It
0 20 40 60 80 100 120 140 160
Charge Input (%)
Discharge
Discharge
(at high rate)
(at high rate)
Discharge
(at low rate)
1.4
1.2
1.0
Cell Voltage (V)
0.8
0246810121416
Discharge Time (Hrs.)
Charge : 500mA×16Hrs.
(0.1 It)(0.2 It)(0.5 It)
at 20˚C/68˚F
Temperature
(Charge & Discharge)
