Page 1

DVD Recorder/ VCR LINE-IN RECORDING

(No Tuner)

Owner's Manual

Manual del Propietario

FWZV475F

To obtain a more detailed Electronic Copy of this Manual or much further contents, go to

Para obtener una Copia Electrónica más detallada de este Manual o mucho otras

contenido, visite

http://www.sanyo-av.com/

Need help? Please Call Toll Free 1 866 212 0436 or visit our Web Site above:

Necesita ayuda?

Sitio Web en:

sanyo-av.com

Llame por favor sin costo al 1 866 212 0436 ó visite nuestro

Page 2

SAFETY INFORMATION

The model and serial numbers of this unit may be found on the cabinet. You should record and retain those numbers for future reference.

Model No.: Serial No.:

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS

FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note and rating are located on the rear or bottom of the cabinet.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The symbol for CLASS ll (Double Insulation)

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning

storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

FCC WARNING

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

Disconnect the mains plug to shut off when find trouble or not in use. The mains plug shall remain readily operable.

2 EN2 EN

Page 3

SAFETY INFORMATION

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. WARNING: Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine, fire,

LASER SAFETY

This apparatus is classified as a CLASS 1 LASER PRODUCT. This apparatus employs a laser. Only a qualified service person should remove the cover or attempt to service this apparatus, due to possible eye injury.

CAUTION: Use of controls or adjustments or performance of procedures other than those specified

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling unit can cause serious injury or even death.

Never use a gas duster on this unit. The gas trapped inside of this unit may cause ignition and explosion.

To Avoid the Hazards of Electrical Shock and Fire

•

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.

•

Donotputyourngersorobjectsintotheunit.

or the like.

herein may result in hazardous radiation exposure.

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording Playback Editing

Location and Handling

•

Donotinstalltheunitindirectsunlight,nearstrongmagneticelds,orinaplacesubjecttodustorstrongvibration.

•

Avoid a place with drastic temperature changes.

•

Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit. Depending on your external devices, noise or disturbance of the picture and/or sound may be generated if the unit is placed too close to them. In this case, please ensure enough space between the external devices and the unit.

•

Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.

•

Be sure to remove the disc and unplug the AC power cord from the outlet before carrying the unit.

Dew Condensation Warning

•

Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few hours until its inside gets dry.

− Theunitismovedfromacoldplacetoawarmplace.

− Underconditionsofhighhumidity.

− Afterheatingacoldroom.

Note about Recycling

•

This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

•

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

•

For product recycling information, please visit - sanyo-av.com

Notice for Progressive Scan Output

•

Consumersshouldnotethatnotallhighdenitiontelevisionsetsarefullycompatiblewiththisproductandmay

cause artifacts to be displayed in the picture. In case of picture problems with 525(480) progressive scan output,

itisrecommendedthattheuserswitchtheconnectiontothe‘standarddenition’output.Iftherearequestions

regarding your TV set compatibility with this 525p(480p) DVD player, please contact our customer service center.

Others Español

3EN 3EN

Page 4

SAFETY INFORMATION

Supplied Accessories

remote control (NC184UH) with batteries (AA, 1.5V x 2)

RCA audio/video cables

owner's manual

quick guide

Cleaning the disc lens

•

If this unit still does not perform properly although you refer to the relevant sections and to “TROUBLESHOOTING” in this owner's manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

Disc handling

•

Handlethediscssothatngerprintsanddustdonot

adhere to the surfaces of the discs.

•

Always store the disc in its protective case when it is not used.

Auto head cleaning

•

Automatically cleans video heads as you insert or remove a cassette, so you can see a clear picture.

•

Playback picture may become blurred or interrupted while the TV program reception is clear. Dirt accumulated on the video heads after a long period of use or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in your unit may need to be cleaned.

1. Please visit your local Audio/Video store and purchase a good quality VHS video head cleaner.

2. If a video head cleaner does not solve the problem, please consult your dealer or an Authorized Service Center.

Note

•

Remember to read the instructions along with the video head cleaner before use.

•

Clean video heads only when problems occur.

Maintenance

Servicing

•

Please refer to relevant topics on “TROUBLESHOOTING” on pages 84-87 before returning the product.

•

If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable parts inside. Turn the unit to the standby mode, unplug the power plug and please call our help line mentioned on the front page to locate an Authorized Service Center.

Cleaning the cabinet

•

Wipe the front panel and other exterior surfaces of the unit with a soft cloth.

•

Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the unit. Such chemicals may discolor the surface or damage the unit.

Cleaning discs

•

When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to out. Do not wipe in a circular motion.

•

Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analog records.

IR signal check

If the remote control does not work properly, you can test if the remote control sends out the infrared signal with a digital camera (including built-in camera of cellular phone). It will help to define the cause of malfunction.

With a digital camera (including built-in camera of cellular phone):

Direct a digital camera to remote control, press and hold a button on remote control. If infrared light appears through digital camera, the remote control is working.

4 EN4 EN

Page 5

Trademark Information

SAFETY INFORMATION

Introduction

Connections Basic Setup Function Setup VCR Functions

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Dolby Digital Stereo Creator

“Dolby create stereo DVD-Videos with stunning Dolby Digital sound tracks at home. The technology, when utilized instead of PCM recording, also saves recordable disc space, allowing for higher video resolution or extended recording time on each DVD. DVDs mastered using Dolby Digital Stereo Creator will play back on all DVDVideo players.” Note: This is true when the players are compatible with

Digital Stereo Creator enables consumers to

actual recordable DVD discs.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

is a trademark of DVD Format/Logo Licensing

Corporation.

Recording Playback Editing

SANYO is a registered trademark of SANYO Electric Co., Ltd. and is used by Funai Electric Co., Ltd. and Funai Corporation, Inc. under license from SANYO Electric Co., Ltd.

Any liability related to SANYO products, including design and quality, is the sole responsibility of Funai Electric Co., Ltd. and Funai Corporation, Inc.

Please contact Funai Corporation, Inc. for any questions or claims related to SANYO products: 1 866 212 0436 sanyo-av.com

Others Español

5EN 5EN

Page 6

Introduction

SAFETY INFORMATION...........................2

FEATURES ......................................8

Symbols Used in this Owner’s Manual............9

FUNCTIONAL OVERVIEW ........................10

Front Panel ...................................10

Rear Panel ...................................11

Remote Control ...............................12

Front Panel Display............................14

Connections

CONNECTION ..................................15

Connecting to an External Tuner ................15

TV Connection Overview .......................15

Connecting to a TV with

an HDMI™ Compatible Port ....................16

Connecting to a TV with

Component Video Input jacks ...................17

Connecting to a TV with an S-Video Input Jack....17

Connecting to a TV with

Audio / Video Input Jacks ......................18

Connecting to a TV without

Audio / Video Input Jacks ......................18

Digital Audio Connection.......................19

Basic Setup

BEFORE YOU START ............................20

Finding the Viewing Channel on Your TV.........20

Guide to On-Screen Display / Menu .............21

Main Menu ...................................23

Switching DVD / VCR Mode ....................24

How to Insert a Disc / Cassette Tape .............24

INITIAL SETTING................................25

SETTING THE CLOCK............................26

Recording

INFORMATION ON DVD RECORDING .............27

BEFORE RECORDING............................28

Setting for Auto Chapter .......................28

Recording Audio Select (XP)....................28

Setting Aspect Ratio for Video Mode Recording ...28

BASIC RECORDING &

ONE-TOUCH TIMER RECORDING .................29

TIMER RECORDING .............................31

Hints for Timer Recording ......................34

SATELLITE LINK ................................35

SETTINGS FOR AN EXTERNAL DEVICE............37

Connection to an External Device ...............37

Setting for the Video Input .....................37

Recording from an External Device ..............38

BI-DIRECTIONAL DUBBING.......................39

SETTING A DISC TO PROTECT ...................41

PLAYING THE DISCS ON OTHER DVD PLAYERS ....42

Finalizing a Disc...............................42

Auto Finalizing ................................43

6 EN6 EN

Page 7

CONTENTS

Introduction

Connections Basic Setup Function Setup VCR Functions

Playback

INFORMATION ON PLAYBACK ...................44

BASIC PLAYBACK...............................46

Direct Playback ...............................46

Playback from the Title List .....................47

Playing Back an Audio CD and

a CD-RW / -R with JPEG Files ...................48

Using the Title / Disc Menu .....................49

Pause........................................49

SPECIAL PLAYBACK.............................50

Resume Playback .............................50

Fast Forward / Fast Reverse Playback ............50

Skipping TV Commercials During Playback .......50

Rapid Playback................................50

Step by Step Playback .........................51

Slow Forward / Slow Reverse Playback ..........51

Zoom........................................51

Marker Setting ................................52

Repeat Playback ..............................52

Random Playback .............................53

Slide Show ...................................53

Program Playback .............................53

SEARCH .......................................54

Title / Chapter Search ..........................54

Track Search..................................54

Time Search ..................................55

SELECTING THE FORMAT OF AUDIO AND VIDEO ..56

Switching Subtitles ............................56

Switching Audio Soundtrack....................56

Switching Camera Angles ......................57

Reducing Block Noise..........................57

Editing

INFORMATION ON DISC EDITING.................58

Guide to a Title List............................58

Editing Discs..................................58

FORMATTING A DISC ...........................59

Choosing the Recording Format of a Brand-New

DVD-RW .....................................59

Reformatting a Disc Manually...................60

CREATING/DELETING PLAYLIST..................61

Adding Titles to a Playlist ......................61

Erasing All Playlist.............................62

DELETING TITLES ...............................63

EDITING DISCS .................................64

Deleting a Part of a Title........................64

Putting Names on Titles........................66

Setting Chapter Marks .........................67

Setting or Clearing All Chapter Marks at Once ....68

Dividing a Title................................69

Combining Titles ..............................70

Setting or Releasing the Title Protection..........71

Function Setup

LIST OF SETTINGS ..............................72

SETUPS........................................74

Playback .....................................74

Display ......................................77

Video ........................................78

HDMI ........................................79

Reset All .....................................80

VCR Functions

VCR FUNCTIONS ...............................81

Information on VCR Functions ..................81

Playback .....................................81

Recording ....................................81

One-touch Timer Recording (OTR)...............82

Index Search .................................82

Time Search ..................................83

Other Operations..............................83

Recording Playback Editing

Others

TROUBLESHOOTING ............................84

LANGUAGE CODE ..............................88

GLOSSARY.....................................89

SPECIFICATIONS................................90

Español

ESPAÑOL ......................................91

Limited Warranty

Limited Warranty .......................Back Cover

Others Español

7EN 7EN

Page 8

FEATURES

This unit not only plays back DVD, CD and VCR but also offers features for you to record on DVD and edit them after that. The following features are offered with this unit.

Recording

This unit is compatible with recording on DVD-RW which is recordable repeatedly and DVD-R which accept the additional recordings until the disc becomes full but not overwritable. You can choose either one for your convenience. Also, this unit allows you to record to the cassette tape.

DVD

Up to 12 program recording:

You can program the unit to record up to 12 programs within a one-month period. Daily or weekly program recordings are also available.

One-touch timer recording (OTR): You can easily set a recording time as you prefer. Every time [REC] is pressed during recording, the recording time will be increased by 30 minutes up to 8 hours. The recording automatically stops when the recording time you set is reached or the disc is full.

Dubbing mode:

You can copy a DVD to a cassette tape or copy a cassette tape to a DVD. This function will be possible only if the DVD or a cassette tape is not copy protected.

You cannot record on a cassette tape when its eraseprotection tab is removed.

Left channel stereo recording: This unit can record the sound of the left channel monaural input as left and right channels automatically.

Automatic chapter mark setting: Chapter marks will be put on recordings as you set before attempting to record.

Automatic title menu making: The unit creates title menu automatically when finalizing discs for video mode recording.

Automatic playlist making: The unit creates a playlist automatically after recording VR mode DVD-RW.

Automatic title finalizing: For video mode DVD-RW/-R recording, you can finalize discs automatically after finishing all timer recordings or at the end of the disc space if you set this in the main menu.

VCR

DVD

Playback

DVD

Theater surround sound in your home:

When connecting the unit to an amplifier or a decoder which is compatible with Dolby Digital, you can experience the theater surround sound from discs with surround sound system.

Quick search for what you want to watch: You can easily find the part you want to watch using the search function. Search for a desired point on a disc by title, chapter or time.

Playing back JPEG files: You can enjoy JPEG files which are recorded on CD-RW/-R.

VCR

Quick search for what you want to watch:

You can easily find the part you want to watch using the index search/time search functions. An index mark will be assigned at the beginning of each recording you make. For time search function, you can go to a specific point on a cassette tape by entering the exact amount of time you wish to skip.

Editing

DVD

Deleting titles:

You can delete titles which you do not need anymore.

Putting names on titles:

You can put your favorite names on titles.

Setting / clearing chapter marks:

You can set / clear chapter marks on titles.

Dividing or combining titles (VR mode DVD-RW only):

You can divide or combine a playlist title. Deleting parts of titles (VR mode DVD-RW only):

You can delete a specific part of a title.

Compatibility

DVD

Available for playing back discs on a regular DVD player:

Recorded discs can be played back on regular DVD players, including computer DVD drives compatible with DVD-video playback. For DVD-RW/-R, you need to finalize the recorded discs to play back on other DVD players.

8 EN8 EN

Others

DVD

Progressive scan system

Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution than that of traditional television signals.

HDMI (High-Definition Multimedia Interface)

You can enjoy clearer audio/video output when connecting this unit to a display device with an HDMI-compatible port.

VCR

Page 9

FEATURES

Symbols Used in this Owner’s Manual

To specify for what disc type each function is, we put the following symbols at the beginning of each item to operate.

* DVD-RW recorded in the non compatible recording

format is not recordable.

* DVD-R recorded in VR mode is not recordable on this

unit.

Introduction

Connections Basic Setup Function Setup VCR Functions

Symbol

For Recording, Playing Back, and Editing

For Recording and Playing Back

For Playback only

If you do not find any of the symbols listed above under the function heading, the operation is applicable to all media.

Description

Description refers to DVD-RW (VR mode)

Description refers to DVD-RW (Video mode)

Description refers to DVD-R (Video mode)

Description refers to VHS tapes Use only cassettes marked VHS ( )

Description refers to DVD-video

Description refers to audio CD

Description refers to CD-RW/-R with JPEG files

Recording Playback Editing

9EN 9EN

Others Español

Page 10

FUNCTIONAL OVERVIEW

1 2* 3

Front Panel

(*) The unit can also be turned on by pressing these buttons or inserting a cassette tape.

1. Cassette compartment (VCR)

Insert a cassette tape here.

2. A button (DVD)*

Press to open or close the disc tray.

3. Disc tray (DVD)

Place a disc when it is open.

4. AUDIO input jacks (L2) (DVD/VCR)

Use to connect external device with an RCA audio

cable.

5. VIDEO input jack (L2) (DVD/VCR)

Use to connect external device with an RCA video

cable.

6. S-VIDEO input jack (L2) (DVD/VCR)

Use to connect the S-video output of external device

with an S-video cable.

7. I REC button (DVD)

•

Press once to start a recording.

•

Press repeatedly to start the one-touch timer recording.

8. B button (DVD)*

Press to start or resume playback.

9. C button (DVD)

•

Press to stop playback or recording.

•

Press to stop the proceeding timer recording in DVD.

10. DVD indicator

Lights up when the DVD output mode is selected.

11. SOURCE button (DVD/VCR)

Press to select the component you wish to operate.

12. VCR indicator

Lights up when the VCR output mode is selected.

13. D.DUBBING button (DVD/VCR)

Press to start VCR to DVD (DVD to VCR) duplication

which you set in the main menu.

14. TRACKING L / K buttons (VCR)

•

Press to adjust the tracking during playback or in slow motion of the cassette tape.

•

While playback is in still mode, you can adjust the picture blurred vertically.

15. Display (DVD/VCR)

Refer to “Front Panel Display” on page 14.

16. Infrared sensor window (DVD/VCR)

Receive signals from your remote control so that you

can control the unit from a distance.

17. I REC button (VCR)

Press once to start a recording. Press repeatedly to

start the one-touch timer recording.

18. B button (VCR)

Press to start playback.

19. C A button (VCR)

•

Press to remove the cassette tape from the cassette compartment.

•

Press to stop cassette tape playback or recording.

•

Press to stop the proceeding timer recording in VCR.

20. D button (VCR)

Press to rapidly advance the cassette tape or view the

picture rapidly in forward during playback (forward search).

21. E button (VCR)

Press to rewind the cassette tape or to view the

picture rapidly in reverse during playback (rewind search).

y button (DVD/VCR)

22.

Press to turn On the unit or to turn the unit to the

standby mode. (To completely shut down the unit, you must unplug the AC power cord.)

23. POWER-ON indicator (DVD/VCR)

Red LED lights up when power is on.

6 5 422 21 13 11 1012 9 8* 720 19 18 17 1516 1423

10 EN10 EN

Page 11

1 2

Rear Panel

FUNCTIONAL OVERVIEW

Introduction

Connections Basic Setup Function Setup VCR Functions

37910 8 6 453

1. AC Power Cord

•

Connect to a standard AC outlet to supply power to this unit.

•

Unplug this cord from the AC outlet to completely shut down the unit.

2. HDMI OUT jack

Use an HDMI cable to connect to a display with an

HDMI compatible port.

3. AUDIO OUT jacks

Use to connect a TV monitor, AV receiver or other

device with an RCA audio cable.

4. VIDEO OUT jack

Use to connect a TV monitor, AV receiver or other

device with an RCA video cable.

5. VIDEO IN jack (L1)

Use to connect external device with an RCA video

cable.

6. AUDIO IN jacks (L1)

Use to connect external device with an RCA audio

cable.

7. S-VIDEO IN jack (L1)

Use to connect the S-video output of external device

with an S-video cable.

8. COMPONENT VIDEO OUT jacks

Use to connect a TV monitor with component video

inputs with a component video cable.

9. S-VIDEO OUT jack

Use to connect the S-video input of a TV monitor, AV

receiver or other device with an S-video cable.

10. COAXIAL DIGITAL AUDIO OUT jack

Use to connect an AV receiver, Dolby Digital decoder

or other device with a digital audio coaxial input jack with a digital audio coaxial cable.

Note

•

Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

•

This unit does not have the RF modulator.

Caution when using S-video, component or HDMI connection for VCR:

•

Only the playback video/audio are available with these connections.

Recording Playback Editing

Others Español

11EN 11EN

Page 12

Remote Control

FUNCTIONAL OVERVIEW

Installing the Batteries in the Remote Control

Install the batteries (AA 1.5V × 2) matching the polarity indicated inside battery compartment of the remote control.

Open the cover.

Insert batteries.

Make sure to match + and - on the batteries to the marks indicated in the battery compartment.

Close the cover.

Using a Remote Control

Keep in mind the following when using the remote control:

•

Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.

•

Remote operation may become unreliable if strong

sunlightoruorescentlightisshiningontheinfrared

sensor window of the unit.

•

Remote control for different devices can interfere with each other. Avoid using remote control for other device located close to the unit.

•

Replace the batteries when you notice a fall off in the operating range of the remote control.

•

The maximum operable ranges from the unit are as follows. – Line of sight: approx. 23 feet (7m) – Either side of the center: approx. 16 feet (5m) within 30° – Above: approx. 16 feet (5m) within 15° – Below: approx. 10 feet (3m) within 30°

16 feet (5m)

30˚

23 feet (7m)

16 feet (5m)

30˚

Note

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

•

Lithium or ni-cad and ni-mh rechargeable batteries are not recommended to use for remote control.

•

Do not mix different types of batteries such as alkaline and standard (carbon-zinc).

•

Do not mix new and old batteries together.

•

Do not use different kinds of batteries together. Although they may look similar, different batteries may have different voltages.

•

Make sure that the + and - ends of each battery match the indications in the battery compartment.

•

Remove batteries from battery compartment that is not going to be used for a month or more.

•

When disposing of used batteries, please comply with governmental regulations or environmental public instruction’s rules that apply in your country or area.

•

Do not recharge, short-circuit, heat, burn or disassemble batteries.

12 EN12 EN

10 12

19 3 4

8 9

11 13

Instructions continue on the next page.

26 28

30 32

Page 13

FUNCTIONAL OVERVIEW

Introduction

1. y button (DVD/VCR)

•

Press to turn On the unit or to turn the unit to the standby mode. (To completely shut down the unit, you must unplug the AC power cord.)

2. Number/Character buttons (DVD/VCR)

•

Presstoselectatitle/chapter/track/leondisplay.

•

Press to enter values for the settings in the main menu.

•

Press to enter title names.

•

Press to start the index/time search in VCR mode.

3. DISPLAY button (DVD/VCR)

•

Press to display the display menu on or off.

4. DISC MENU button (DVD)

•

Press to display the disc menu.

•

To change original and playlist on the TV screen.

5. OK button (DVD/VCR)

•

Presstoconrmorselectmenuitems.

6. SETUP button (DVD/VCR)

•

Press to display the main menu.

•

During DVD playback, press and hold for more than 3 seconds to switch the progressive scanning mode to the interlace mode.

7. VCR button

•

Press to select the VCR output mode.

8. H button (DVD)

•

During playback, press to return to the beginning of

thecurrentchapter,trackorle.

•

When playback is in pause, press repeatedly to reverse the playback step by step.

•

During playback, press twice in quick succession to skip to the previous chapter or track.

9. E button (DVD/VCR)

DVD mode:

•

During playback, press to fast reverse playback.

•

When playback is paused, press to slow reverse playback.

VCR mode:

•

During playback, press to rewind the cassette tape or to view the picture rapidly in reverse.

•

Press to fast reverse the cassette tape in stop mode.

10. CM SKIP button (DVD)

•

During playback, press to skip 30 seconds.

11. F button (DVD/VCR)

•

Press to pause playback or recording.

12. D.DUBBING button (DVD/VCR)

•

Press to start VCR to DVD (DVD to VCR) duplication which you set in the main menu.

13. REC MODE button (DVD/VCR)

•

Press repeatedly to switch the recording mode.

14. INPUT SELECT button (DVD/VCR)

•

Press to select the appropriate input.

15. A button (DVD/VCR)

DVD mode:

•

Press to open or close the disc tray.

VCR mode:

•

Press to remove the cassette tape from the cassette compartment.

16. TRACKING K / L buttons (VCR)

•

Press to adjust the tracking during playback or in slow motion of the cassette tape.

•

While playback is in still mode, you can adjust the picture blurred vertically.

17. HDMI button (DVD)

•

Press to set the HDMI connector’s video signal output mode.

18. CLEAR button (DVD/VCR)

DVD mode:

•

Press to clear the password once entered or to cancel the programming for CD or to clear the selected marker number, etc.

VCR mode:

•

Press to reset the tape counter.

19. AUDIO button (DVD/VCR)

DVD mode:

•

Press to display the audio menu during playback.

VCR mode:

•

During playback of a Hi-Fi videotape, press to change the audio out setting.

20. TIMER button (DVD/VCR)

•

Press to display the timer programming list.

21. TOP MENU button (DVD)

•

Press to display the title list.

22. Cursor K / L / 0 / 1 buttons (DVD/VCR)

•

Press to select items or settings.

23. RETURN button (DVD/VCR)

•

Press to return to the previously displayed menu screen.

24. DVD button

•

Press to select the DVD output mode.

25. B button (DVD/VCR)

•

Press to start playback or resume playback.

26. G button (DVD)

•

During playback, press to skip to the next chapter,

trackorle.

•

When playback is in pause, press repeatedly to forward the playback step by step.

27. C button (DVD/VCR)

•

Press to stop playback or recording.

DVD mode:

•

Press to exit from the title list.

28. D button (DVD/VCR)

DVD mode:

•

During playback, press to fast forward playback.

•

When playback is paused, press to slow forward playback.

VCR mode:

•

During playback, press to rapidly advance the cassette tape or view the picture rapidly in forward.

•

When playback is paused, press to view the cassette tape in slow motion.

•

Press to fast forward the cassette tape in stop mode.

29. RAPID PLAY button (DVD)

•

During playback, press to play back in a slightly faster/slower mode with keeping the audio quality.

30. SEARCH button (VCR)

•

Press to call up the index or time search menu.

31. TIMER SET button (DVD/VCR)

•

Press to set the unit in the timer standby mode. In the timer standby mode, press to cancel the mode and to turn the unit on.

32. REC button (DVD/VCR)

•

Press once to start a recording.

•

Press repeatedly to start the one-touch timer recording.

Note

•

If you turn this unit to the standby mode, [A] on the remote control is not available. Be sure to use [A] or [C A] on the unit.

Connections Basic Setup Function Setup VCR Functions

Recording Playback Editing

Others Español

13EN 13EN

Page 14

Front Panel Display

VCR

DVD

FUNCTIONAL OVERVIEW

: Appears in the afternoon

with the clock display.

2. Title / track / file and chapter mark

: Appears when indicating a

title / track / file number.

: Appears when indicating a

chapter number.

3. Current status of the unit

: Appears when playback is in

pause or in step by step playback.

: Appears when playing back a

disc or a cassette tape.

: Appears during slow forward

/ reverse playback.

: Appears when the timer

programming or OTR has been set or is proceeding.

: Flashes when all timer

recordings have been finished.

: Appears during recording

process.

: Flashes when a recording is

in pause.

BS CS DR CD

: Appears when this unit is in

DVD output mode and a disc is in the unit.

: Appears during duplication

process.

: Appears when this unit is in

VCR output mode and a cassette tape is in the unit.

: Appears during duplication

process.

: Appears when this unit is in

VCR output mode.

: Appears when the timer

recording is proceeding in VCR.

: Appears when VCR is in the

timer recording standby mode.

: Flashes when a program

cannot be performed for some reason.

VCR

HDDDB

DVD

: Appears when this unit is in

DVD output mode.

: Appears when the timer

recording is proceeding in DVD.

: Appears when DVD is in the

timer recording standby mode.

: Flashes when a program

cannot be performed for some reason.

: Appears during VCR to DVD

duplication process.

: Appears during DVD to VCR

duplication process.

4. Displays the following

•

Elapsed playback time

•

Current title / chapter / track /

lenumber

•

Recording time / remaining time

•

Clock

•

Selected external input position

•

Remaining time for one-touch timer recording

•

Selected HDMI output mode

•

VCR tape counter

Display Message

14 EN14 EN

Appears when the disc tray is opening.

DVD

Appears when the disc tray is closing.

DVD

Appears when a disc is loaded on the disc tray.

DVD

Appears when data is being recorded on a disc.

DVD

Appears when HDMI output mode (480p) is selected.

DVD

Appears when HDMI output mode (720p) is selected.

DVD

Appears when HDMI output mode (1080i) is selected.

DVD

Appears when HDMI output mode (1080p) is selected.

DVD

Page 15

CONNECTION

Read this first:

1) Disconnect the AC power cords of the devices from the AC outlet.

2) Make the connection as illustrated below.

3) After making all the connections, connect the AC power cords of the devices.

•

Connect this unit directly to the TV. If the RCA audio/video cables are connected to a VCR, pictures may be distorted due to the copy protection system.

Connecting to an External Tuner

RCA video cable

RCA audio cable

AUDIO IN

VIDEO IN

RF coaxial

cable

ANT. IN

VIDEO OUTAUDIO OUT

external tuner

RF coaxial

ANT. INANT.OUT

cable

satellite dish

RCA audio cable

RCA video cable

rear of this unit

cable TV

company

Introduction

Connections

Basic Setup Function Setup VCR Functions

Recording Playback Editing

Note

•

Required cables and connecting methods differ depending on the external tuner. For more information, please contact your external tuner provider.

With this setup:

•

You can record any unscrambled channel by selecting the channel on the external tuner. When using the external tuner connect the unscrambled cable signal to the external tuner and then send the output cable signal from the unit to the Cable Box. Be sure that the external tuner is turned on.

•

You cannot record one channel while watching another channel.

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

•

RCA video cable x 1

Please purchase the rest of the necessary cables at your local store.

TV Connection Overview

Refer to

page

If your device has only an ANT. IN jack

ANT. IN

Higher

Quality

If Your TV has

HDMI IN

COMPONENT VIDEO IN

page

Others Español

Standard

Quality

S-VIDEO IN

AUDIO IN

page

VIDEO IN

page

15EN 15EN

Page 16

CONNECTION

Connecting to a TV with an HDMI™ Compatible Port

•

HDMI outputs the video / audio signals without converting to analog signals.

•

No audio connection is required.

HDMI cable

HDMI OUT

rear of this unit

Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the connector are matched.

HDMI IN

Cables not included.

Please purchase the necessary cables at your local store.

HDMI Mode and Actual Output Signals

Press [HDMI] to select the HDMI output mode. The output mode changes as follows every time [HDMI] is pressed.

Front Panel Display Video Output Signal

480 Progressive

Press [HDMI]

720 Progressive

Press [HDMI]

1080 interlaced

Press [HDMI]

1080 Progressive

Press [HDMI]

•

The HDMI mode that is not supported by display device will be skipped.

To play back the digital video images of a DVD via an HDMI connection, it is necessary that both the player and the display device (or an AV amplifier) support a copyright protection system called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your display device (or AV amplifier) for more information.

Note for HDMI Connection

•

Because HDMI is an evolving technology, it is possible that some devices with an HDMI input may not operate properly with this unit.

•

When using an HDCP-incompatible display device, the image will not be viewed properly.

•

Among the devices that support HDMI, some devices can control other devices via the HDMI connector; however, this unit cannot be controlled by another device via the HDMI connector.

•

When this unit’s HDMI connector is connected to a DVI-D compatible monitor (HDCP compatible) with an HDMI-DVI converter cable, the signals are output in digital RGB.

•

When the power failure occurs or when you unplug the unit, some problems in the HDMI setting might occur. Please check and set the HDMI setting again.

16 EN16 EN

Page 17

CONNECTION

RCA audio cable

Connecting to a TV with Component Video Input jacks

AUDIO IN

RCA audio cable

Introduction

Connections

RCA component video cable

(Green)

(Blue)

(Red)

(Blue)

(Red)

rear of this unit

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

Please purchase the rest of the necessary cables at your local store.

Connecting to a TV with an S-Video Input Jack

COMPONENT

VIDEO IN

/CB

/CR

Basic Setup Function Setup VCR Functions

Recording Playback Editing

S-video cable

rear of this unit

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

Please purchase the rest of the necessary cables at your local store.

AUDIO IN

S-VIDEO IN

Others Español

17EN 17EN

Page 18

CONNECTION

Connecting to a TV with Audio / Video Input Jacks

AUDIO IN

RCA audio cable

RCA video cable

rear of this unit

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

•

RCA video cable x 1

Please purchase the rest of the necessary cables at your local store.

Connecting to a TV without Audio / Video Input Jacks

VIDEO IN

VHF / UHF

antenna

cable TV

company

rear of this unit

external tuner

ANT. INANT.OUT

RCA audio cable

AUDIO OUTVIDEO OUT

RCA video cable

RF coaxial cable

No Antenna (RF) Output!

If your TV only has an Antenna input (no A/ V inputs), you will need a RF modulator (NOT INCLUDED) to connect this player.

RF modulator

CHANNEL

VIDEO IN

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

•

RCA video cable x 1

Please purchase the rest of the necessary cables at your local store.

AUDIO IN

ANT. IN

TO TV

ANT. IN

AUDIO IN TO TVANT. IN

RF modulator

VIDEO IN

RCA audio cable

CHANNEL

Set channel 3 or 4

ANT. IN

RCA video cable

RF coaxial cable

Set channel 3 or 4

Note

•

RF modulator is not supplied with this unit. You need to purchase it at your local store.

•

The quality of picture may become poor if this unit is connected to an RF modulator.

18 EN18 EN

Page 19

Digital Audio Connection

Coaxial Cable Connection

Dolby Digital decoder

CONNECTION

rear of this unit

Introduction

Connections

COAXIAL

digital audio

coaxial input jack

digital audio

coaxial cable

HDMI Audio Connection

AV receiver / amplifier with an HDMI input jack

HDMI IN

HDMI

cable

HDMI OUT

To set up “HDMI Audio” refer to pages 73 and 79.

To set up “Dolby Digital” refer to pages 72 and 76.

Audio format (disc) HDMI Digital Output

Dolby Digital

LPCM

Dolby Digital Setting of this unit

PCM

Stream

PCM

Stream

2channel PCM

Dolby Digital

2channel PCM

Dolby Digital

Actual Output

Cables not included.

Please purchase the necessary cables at your local store.

Basic Setup Function Setup VCR Functions

rear of this unit

Recording Playback Editing

Note

•

The audio source on a disc in a Dolby Dig1ital multi channel surround format cannot be recorded as digital sound by an MD or DAT deck.

•

By connecting this unit to a Dolby Digital decoder, you can enjoy high-quality Dolby Digital multi channel surround sound as movie theaters.

•

Playing back a DVD using incorrect settings may generate noise distortion and may also damage the speakers.

2 Channel Analog Audio Connection

RCA audio cable

stereo system

rear of this unit

AUDIO IN

analog audio input jacks

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

Others Español

19EN 19EN

Page 20

BEFORE YOU START

After you have completed all the connections, you must find the viewing channel (external input channel) on your TV.

Finding the Viewing Channel on Your TV

After you have made all the necessary

connections, press [y] to turn on the

unit.

Turn on your TV.

•

If connected to your VCR make sure it is switched off or in standby mode before proceeding.

Press “2” on the TV’s remote control,

then press channel down button repeatedly until you see “Initial Setup” menu.

Initial Setup

OSD Language

English Français Español

Input Mode Names for Common TV Brands (Example)

Admiral AUX Panasonic TV/VIDEO

Curtis Mathis

Funai AUX CHANNEL Samsung TV/VIDEO GE INPUT, TV/VCR,

Hitachi INPUT, AUX Sharp 00 JVC VIDEO, VIDEO 1,

Kenwood AUX Toshiba TV/GAME

LXI-Series 00 Zenith 00

LINE1, LINE2, 00, 90, 91, 92, 93

00, 90, 91, 92, 93

VIDEO 2, VIDEO 3

RCA INPUT, TV/VCR,

00, 90, 91, 92, 93

Sanyo VIDEO

Sony VIDEO1, VIDEO2,

VIDEO3

Select the language for Setup display.

This is the correct viewing channel (external input channel) for the recorder.

•

For some TVs, there may be a button on the TV’s remote control that accesses the external input channel. It may be labeled “SOURCE”, “AV” or “SELECT”. In such case, press it repeatedly. Refer to your TV’s user manual for details.

•

If more than 10 minutes have passed since you have turned on the unit, you may see the screen saver instead of “Initial Setup” menu.

Screen saver:

Proceed to step 2 in “INITIAL SETTING”

on page 25.

Note

•

Video input selection varies for different brand’s models of TVs.

•

Consult your TV manufacturer if none of the above are successful.

20 EN20 EN

Page 21

BEFORE YOU START

This unit uses the following on-screen displays and menus to guide you to the easy operations. The on-screen displays give you the information on the loaded disc or the disc/file in playback or the HDMI status, etc. The menus allow you to change the various kinds of settings for playing back, recording or editing to suit your preference.

Introduction

Guide to On-Screen Display / Menu

The on-screen display changes in the following order as you press [DISPLAY].

OFF

Disc Information/Menu (only in DVD mode)

VCR Information (only in VCR mode)

Title Name Information (only in DVD mode)

(only when DVD-RW/DVD-R is in playback)

File Name Information (only in CD mode)

(only when a CD with JPEG files is in playback)

HDMI Information

(only for the images output through the HDMI output)

VR ORG

-RW

L1 (Rear)

SP 1:53

* This is an example screen only for explanation.

Displayed items vary depending on the disc you inserted.

1. Indicates a disc type and format mode.

2. Indicates a type of titles for VR mode DVD-RW.

3. Indicates the selected external input channel.

4. Indicates a recording mode and possible recording

time left.

5. Indicates an operation status.

6. Each icon means:

: Search

: Audio

: Subtitle

: Angle

: Repeat

: Marker

: Noise Reduction

: Zoom

7. Indicates the current title number/total number of

titles, the current chapter number/total number of chapters, and time lapse of the current title playback/ total duration of the title.

Connections

Basic Setup

Recording Playback Editing

Function Setup VCR Functions

Others Español

21EN 21EN

Page 22

BEFORE YOU START

VCR Information

VCR mode

12:00AM

0:00:00 HIFISP

4 53

* This is an example screen only for explanation.

Displayed items vary depending on the cassette tape you inserted.

* During stop mode or pause, VCR information is not

available with HDMI connection.

1. Indicates current video status.

2. Indicates the current time.

3. Indicates a recording or playing back mode.

4. Indicates a tape counter.

5. Audio status of the current cassette tape.

Note

•

VCR information does not appear on the screen when the unit is connected by an HDMI, component or S-video cable, except during the playback.

HDMI Information

Video Info. : 480p / YCbCr Audio Info. : Bitstream

1. Indicates the resolution of the HDMI output image.

2. Indicates the HDMI video format.

3. Indicates the HDMI audio format.

•

“- - -” will be displayed, when it does not have any information.

Title Name Information

File Name Information

Title/File Name Information

Title Name

My Title

File Name

My File

22 EN22 EN

Page 23

Main Menu

BEFORE YOU START

Introduction

Press [SETUP] to display the main menu. Then use [K / L] to select a menu and press [OK] to display the

menu. These menus provide entries to all main functions of the unit.

Setup

General Setting

Timer Programming

Title List

DVD Menu

DISC Playback Mode

General Setting Menu

General Setting

1 2

Playback Display

Video

Recording Clock

HDMI

Reset All

Parental Lock Disc Audio Disc Menu Language Audio Language Subtitle Language Angle Icon Still Mode

1. General Setting:

To go to general setting menu.

2. Timer Programming:

To program a timer recording.

3. Title List:

To call up the title list.

4. DVD Menu:

To set up the DVD setting.

5. DISC Playback Mode:

To set up the disc playback setting.

•

“DISC Playback Mode” is available only when an

audioCD,aCD-RW/-RwithJPEGlesisinsertedinto

the unit.

1. Playback:

To set up the unit to play back discs as you prefer.

2. Display:

To set up the OSD screen as you prefer.

3. Video:

To set up the video setting.

4. Recording:

To set up the unit to record to discs as you prefer.

5. Clock:

To set up the clock of the unit as you need.

6. HDMI:

To set up the HDMI connection setting.

7. Reset All:

To reset the setting to the factory default.

Connections

Basic Setup

Recording Playback Editing

DVD Menu / DISC Playback Mode

DVD Menu

Format

Finalize Disc Protect OFF ON

Delete All Playlists

DISC Playback Mode

Random Play

Program Play

DISC Playback Mode


17 25 28

Random Play Slide Show

1. Format: (DVD-RW only) Allows you to format the disc.

2. Finalize:

Allows you to finalize a disc containing recorded titles.

3. Disc Protect: (VR mode DVD-RW only) Allows you to protect a disc from accidental editing or

recording.

4. Delete All Playlists: (VR mode DVD-RW only)

5. Random Play:

Allows you to activate the random playback feature.

6. Program Play: (audio CD only) Allows you to activate the program playback feature.

7. Photo: (JPEG files only) Allows you to make setting for JPEG playback.

8. Slide Show: (JPEG files only) Allows you to select the display time of the slide show

mode.

23EN 23EN

Function Setup VCR Functions

Others Español

Page 24

BEFORE YOU START

Switching DVD / VCR Mode

Because this product is a combination of a VCR and a DVD recorder, you must select first which component you wish to operate.

DVD mode

Press [SOURCE] on the front panel or press [DVD] on the remote control.

(Verify that the DVD indicator is lit.)

DVD indicator

SOURCE button

VCR indicator

VCR mode

Press [SOURCE] on the front panel or press [VCR] on the remote control.

(Verify that the VCR indicator is lit.)

VCR button

DVD button

Note

•

You cannot switch to another mode while in the timer-standby mode.

•

Playback will stop when you change the output mode.

How to Insert a Disc / Cassette Tape

How to Insert a Disc How to Insert a Cassette Tape

1) Press [DVD].

2) Press [A] to open the disc tray.

3) Place the disc on the disc tray with its label side facing up.

Align the disc to the disc tray guide.

4) Press [A] to close the disc tray.

It may take a while to load the disc.

To eject the disc:

Press [A] to open the disc tray, then remove the disc before turning the unit to the standby mode.

1) Press [VCR].

2) Insert a cassette tape as illustrated below.

4 HEAD HI-FI STEREO

•

Insertfromtheapsiderstwiththewindowside

Cassette compartment

facing up.

To eject the cassette tape:

Press [C A] on the front panel or press [A] on the remote control.

Note

•

If you turn this unit to the standby mode, [A] on the remote control is not available. Be sure to use [A ] or [C A] on the unit.

24 EN24 EN

Page 25

INITIAL SETTING

You need to follow these steps when you turn on this unit for the first time.

Follow the procedure in “Finding the

Viewing Channel on Your TV” on

page 20 to display “Initial Setup” menu.

Use [K / L] to select your desired

language, then press [OK].

Initial Setup

OSD Language

English Français Español

Introduction

Connections

Basic Setup

Select the language for Setup display.

Proceed to step 4 in

“SETTING THE CLOCK” on page 26.

Recording Playback Editing

Function Setup VCR Functions

Others Español

25EN 25EN

Page 26

SETTING THE CLOCK

Set the clock before you try the timer programming. Follow these steps below.

Press [SETUP] and use [K / L] to select

“General Setting”, then press [OK].

“General Setting” menu will appear.

Use [K / L] to select “Clock”, then

press [OK].

“Clock Setting” menu will appear.

Use [K / L] to select calendar or time,

then press [OK].

Clock Setting

JAN / 29 / 2015 ( THU )

Note

•

Your setting will be cancelled if you press [SETUP] before pressing [OK] at step 4.

•

Your clock setting will be lost if either there is a power failure or this unit has been unplugged for more than 30 seconds when you set the clock manually.

•

For setting the day, year, hour, and minute, [the Number buttons] can also be used.

•

You can set the built-in calendar from the year 2012 up to 2062.

12 : 00 AM

Use [{ / B] to select an item to set, and

use [K / L] to select the contents to suit

your preference, then press [OK] when you finish setting all the contents.

Clock Setting

JAN / 29 / 2015 ( THU )

Your setting will be activated. The clock start counting when you press [OK].

Press [SETUP] to exit.

12 : 00 AM

26 EN26 EN

Page 27

INFORMATION ON DVD RECORDING

Before you make a recording, read the following information.

Recordable Discs

This unit can record to DVD-RW and DVD-R. DVD-R can only be recorded to once. DVD-RW can be

recorded to and erased many times.

Logos

8cm/12cm, single-sided, single layer disc Approx. max. recording time (SLP mode):

DVD-RW DVD-R

•

Following discs are recommended for good recording

360 minutes (4.7GB) (for 12cm) 108 minutes (1.4GB) (for 8cm)

quality and are proven to be compatible with this unit. However, depending on the media condition the unit may not read the disc properly.

Verbatim DVD-R 8x, DVD-RW 2x JVC DVD-RW 4x Maxell DVD-R 8x/16x Performance of any other discs are not guaranteed.

Attributes

Note

•

This unit cannot record to CD-RW or CD-R.

•

Allhighdenitionpictureswillbedownconvertedtothe standarddenitionpictureswhentheyarerecordedon

this unit.

•

DVD-RW/-R and CD-RW/-R recorded on a personal computer or a DVD or CD recorder may not be played back if the disc is damaged or dirty or if there is condensation on the player’s lens.

•

If you record a disc using a personal computer, even if it is recorded in a compatible format it may not be played back because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

•

Since the recording is made by the VBR (variable bit rate) method, depending on the picture you are recording, the actual remaining time for recording may be a little shorter than the remaining time displayed on the TV screen.

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

Unrecordable Discs

•

DVD-RW recorded in the non compatible recording format is not recordable.

•

DVD-R recorded in VR mode is not recordable on this unit.

•

DVD+RW/+R is not recordable on this unit.

Recording Mode

You can select a recording mode among 5 options, and the recording time will depend on the recording mode you select as follows.

Disc size

8cm Disc

12cm Disc

•

The recording time is only an estimate. The actual

Recording

mode

XP (1Hr)

SP (2Hr)

LP (4Hr)

EP (6Hr)

SLP (8Hr)

XP (1Hr)

SP (2Hr)

LP (4Hr)

EP (6Hr)

SLP (8Hr)

recording time may differ.

•

The audio and video quality gets poorer as the recording time becomes longer.

•

Each time [REC MODE] is pressed, recording mode and its allowed recording time will be displayed.

Recording

time

18 min

36 min

72 min

108 min

144 min

60 min

120 min

240 min

360 min

480 min

Video/sound

quality

(good)

(poor)

(good)

(poor)

Restrictions on Recording

You cannot record copy-protected program using this unit. Copy-protected video signal is included in DVD-videos, some satellite broadcasts, some pay-per-view stations and some “premium” stations.

If copy-protected material is detected, recording will pause or stop automatically and an error message appears on the screen.

“Copy-once only” video can only be recorded to CPRM compatible DVD-RW formatted in VR mode.

What is “CPRM”?

CPRM is a copy protection system with scramble system regarding the recording of “copy-once” broadcast programs. CPRM stands for Content Protection for Recordable Media.

This unit is CPRM compatible, which means that you can record copy-once broadcast programs, but you cannot make another copy of those recordings. CPRM recordings can only be made on CPRM compatible DVD-RW formatted in VR mode, and CPRM recordings can only be played back on DVD players that are specifically compatible with CPRM.

Making discs playable in other DVD players (Finalize)

For DVD-RW/-R, it is necessary to finalize the disc after recording, in order to play back the disc on other DVD players. (Refer to pages 42 - 43.)

When video mode discs are finalized, a title menu is created.

You cannot finalize discs in other DVD recorders.

Playback Editing

Others Español

27EN 27EN

Page 28

BEFORE RECORDING

Setting for Auto Chapter

You can set a specified time for chapter marks.

1) Press [SETUP] and use [K / L] to select “General Setting”, then press [OK].

“General Setting” menu will appear.

2) Use [K / L] to select “Recording”, then press [OK].

“Recording” menu will appear.

3) Use [K / L] to select “Auto Chapter”, then press [OK].

4) Use [K / L] to select a desired time option, then press [OK].

Auto Chapter

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

5) Press [SETUP] to exit.

Note

•

The interval for auto chapter may be up to two minutes different from the time option you set.

•

A blank chapter may be created depending on the remaining time of the disc.

Recording Audio Select (XP)

Note

•

“PCM” stands for Pulse Code Modulation. It changes analog sound to digital sound without compressing audio data.

•

When the recording mode is set at other than XP, the unit records “Dolby Digital” audio automatically even if you selected “PCM”.

Setting Aspect Ratio for Video Mode Recording

You can set aspect ratio for video mode recording.

1) Follow step 1 to 2 on “Recording Audio Select(XP)”.

2) Use [K / L] to select “Aspect Ratio (Video mode)”, then press [OK].

3) Use [K / L] to select your desired setting, then press [OK].

Aspect Ratio (Video mode)

Auto 4 : 3 16 : 9

Auto (default) : It will be recorded with whichever the

4:3 : Recorded in the aspect ratio of 4:3. 16:9 : Recorded in the aspect ratio of 16:9.

4) Press [SETUP] to exit.

ratio that the program you started to record are broadcasted with.

You can enjoy high quality sound recording. This function works only when the recording mode is set at XP.

1) Press [SETUP] and use [K / L] to select “General Setting”, then press [OK].

2) Use [K / L] to select “Recording”, then press

[OK].

“Recording” menu will appear.

3) Use [K / L] to select “Recording Audio Select

(XP)”, then press [OK].

4) Use [K / L] to select “PCM” or “Dolby Digital”,

then press [OK].

Recording Audio Select (XP)

PCM Dolby Digital

PCM: Records PCM audio for the best

quality sound.

Dolby Digital: Records Dolby Digital audio for good

quality sound.

5) Press [SETUP] to exit.

28 EN28 EN

Note

•

For DVD-RW VR mode, the image will be recorded in whichever the ratio that the program you record are broadcasted with, regardless of the “Aspect Ratio (Video mode)” setting.

Page 29

BASIC RECORDING & ONE-TOUCH TIMER RECORDING

Follow the steps to record TV programs from an external tuner.

This unit has no tuner system so it cannot receive TV broadcasts without an external tuner or such devices.

Press [DVD] first.

Insert a recordable disc (refer to

page 24 on how to insert a disc).

* Make sure the disc is compatible with this unit.

(Refer to page 27 for the list of compatible discs.)

It may take a while to load the disc.

•

When inserting a brand-new DVD-RW, the unit automatically starts to format.

Press [REC MODE] repeatedly to select

a recording mode.

Refer to “Recording Mode” on page 27.

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

SP 0:58

Press [INPUT SELECT] to select the

appropriate external input position (L1/

L2) to which your external tuner is connected. Then select the desired channel to record on the external tuner.

Playback Editing

Others Español

29EN 29EN

Page 30

BASIC RECORDING & ONE-TOUCH TIMER RECORDING

Press [REC] to start recording.

“I” will be displayed for 4 seconds.

Press [F] to pause recording. Press [F]] or [REC] again to restart recording.

SP 2:00

To set one-touch timer recording (OTR)...

This is a simple way to set the recording time in blocks of 30 minutes. Press [REC] repeatedly until the desired recording time (30 minutes to 8 hours) appears on the TV screen. One-touch timer recording will start.

0:30

(normal recording)

1:00

Press [C] to stop recording.

The recorded title will appear in the title list. (Refer to “Guide to a Title List” on page 58.)

Writing to Disc 90%

•

This operation may take a while to be completed.

8:00

To change the recording length during the one-touch timer recording: Press [REC] repeatedly until the desired length appears.

To cancel the one-touch timer recording within the specified time: Press [C].

7:30

Note

•

When you press [REC], recording starts immediately and continues until the disc is full or you stop recording.

•

When the unit clock has not been set, the space for a date and time of title names will be blank.

•

You cannot change the recording mode during the recording pause mode.

•

You can change a channel (external input) to be recorded during the recording pause mode.

Note for one-touch timer recording

•

The remaining recording time will be displayed on the front panel display during one-touch timer recording. Press [DISPLAY] to see it on the TV screen.

•

Unlike the timer recording, you can perform the following operations during one-touch timer recording.

- Turning the power to standby to stop one-touch timer recording.

- Using [REC] or [C] on the remote control.

•

You cannot use the pause function during one-touch timer recording.

•

If DVD one-touch timer recording is completed during VCR playback or recording, the DVD will be in stop mode and the VCR keeps the current mode.

•

Whenone-touchtimerrecordingisnishedandthepoweristurnedtostandby,theunitwillswitchtothetimer-standby

mode automatically if a timer recording has been programmed. Press [TIMER SET] to cancel the timer-standby mode to use the unit continuously.

30 EN30 EN

Page 31

TIMER RECORDING

You can program the unit to record up to 12 programs within a month in advance. Daily or weekly program recordings are also available.

Before recording, make sure

•

Set the clock before setting a timer programming. Insert a recordable disc with enough recordable space

or a cassette tape with an erase-protection tab.

Guide to Timer Programming Display

Timer Programming

JAN/30/15 12:00 AM L1 SP

Date Start End L1/L2 JAN/30 12:00AM 1:00AM L1 New Program

THU JAN/29 11:00AMSP (1:00)

Introduction

Connections Basic Setup Function Setup VCR Functions

1/1

1 Title of a timer program (Contains date, time, selected

external input position, recording mode of the program)

2 Current date and time 3 Recording mode, and length of the recording 4 Timer program list 5 Total number of pages and current page (2 pages

Recording

maximum)

6 Recording media (“

” (DVD) or “ ” (VCR))

Press [TIMER].

Playback Editing

Use [K / L] to select “New Program”,

then press [OK].

Timer Programming

Date Start End L1/L2 New Program

•

Note

•

If you have not set the clock yet:

Entry screen for the clock setting will appear instead of the timer programming list at step 1. Continue with the step 4 in “SETTING THE CLOCK” on page 26 before setting a timer programming.

•

Use [0 / 1] to move the cursor to the left and the right in the entry screen for the timer programming.

•

If a basic recording or one-touch timer recording is in progress on one component (e.g., VCR) and the timer recording set for the other component (e.g., DVD) is about to begin, the unit automatically switches to the programmed channel for timer recording 2 minutes before the programmed starting time, and the recording in progress (for VCR) will be cancelled UNLESS their recording channels are the same. If their recording channels are the same, the timer recording will start without canceling the recording currently in progress. In this case, the recording of the same channel will be made on both DVD and VCR.

•

You cannot make a program whose recording time exceeds 12 hours.

•

Cancel the timer-standby mode by pressing [TIMER SET] before operation for either DVD or VCR. Whennishedoperating,press[TIMER SET] to resume the timer-standby mode.

•

In the timer-standby mode, you can turn on the power and use the component (VCR or DVD) which is not currently timer-programmed.

If there are 6 or more programs, use

[H / G] to change pages.

Use [K / L] to enter the date, then

press [ B].

Date

JAN/30

L1/L2

JAN/01

Daily

MON-SAT

MON-FRI

SAT

FRI

SUN

JAN/31

THU JAN/29 11:00AM

Start

- - : - -

REC To Mode

DVD SP

End

- - : - -

SP 2:00

When pressing [L] at the current date, the date will change as follows.

e.g.) January 1st

Others Español

31EN 31EN

Page 32

TIMER RECORDING

Use [K / L / 0 / 1] or [the Number

buttons] to enter the start and end time,

then press [ B].

Date

JAN/30

L1/L2

•

You cannot make a program which recording time exceeds 12 hours.

Start End

12 : 00AM

REC To Mode

DVD SP

SP 2:00

- - : - -

Use [K / L] to select the appropriate

external input position (L1 / L2) to

which your external tuner is connected, then press [ B].

Date

JAN/30

L1/L2

Start End

12 : 00AM

REC To Mode

DVD SP

SP 1:00

1 : 00AM

Use [K / L] to select the recording

media (“DVD” or “VCR”), then press

[ B].

e.g.) recording to DVD

Date

JAN/30

L1/L2

Start

12 : 00AM

REC To Mode

1 : 00AM

DVD SP

SP 1:00

End

Use [K / L] to select a recording mode.

Date

JAN/30

L1/L2

Start End

DVD

1 : 00AM

SP 1:00

12 : 00AM

REC To Mode

Refer to “Recording Mode” on page 27.

•

When recording to DVD, you can check the remaining recordable space of the disc when you select the recording mode.

Date

JAN/30

L1/L2

Start End

DVD

1 : 00AM

SP 1:00

12 : 00AM

REC To Mode

Press [OK] when all items are entered.

After displaying an instructive message for 10 seconds, timer program list will appear.

Press TIMER SET to Timer Standby mode.

Ensure the external source is tuned to

the correct channel.

When Timer set on DVD or VCR,

it is not available in the standby mode.

Press TIMER SET to cancel the Standby mode.

Timer Programming

JAN/30/15 12:00 AM L1 SP

Date Start End L1/L2 JAN/30 12:00AM 1:00AM L1

THU JAN/29 11:00AMSP (1:00)

Your program setting is now stored.

•

To set another program, repeat steps 2 to 8.

•

To exit, press [TIMER] or [SETUP].

•

When 2 or more programs are overlapped, “Timer program overlapped” appears, and the overlapped program will be displayed in blue.

•

To correct the timer program refer to “Checking, canceling or correcting the timer programming information” on page 33.

Press [TIMER SET] to set a timer

programming.

will appear on the front panel display, while this

unit waits to make the recording.

CS DR CD

HDD

DVD

“VCR” will appear on the front panel display if VCR timer recording have been set.

Auto recording mode select (DVD only)...

When “Auto” is selected as a recording mode, the unit calculates how much time is available on the disc and selects the best recording mode available automatically to complete recording the program.

Date

JAN/30

L1/L2

•

“Auto” is only available for one program in the timer

Start End

DVD

1 : 00AM

Auto1:00

12 : 00AM

REC To Mode

Auto

program list.

•

The recording may be cut short when the available recording space of the disc is too limited.

32 EN32 EN

Page 33

TIMER RECORDING

Introduction

To stop the timer recording in progress

1) Press [C] on the remote control.

2) Confirmation message will appear. Select “Yes”,

then press [OK].

•

To stop the timer recording immediately, press [ C ] on the unit.

Checking, canceling or correcting the timer programming information

1) Press [TIMER SET].

2) Press [TIMER].

3) Check the information.

Timer Programming

JAN/30/15 12:00 AM L1 SP

Date Start End L1/L2 JAN/30 12:00AM 1:00AM L1 New Program

4a) To delete the timer program:

1 Use [K / L] to select the program you want to

delete, then press [OK].

2 Use [K / L] to select “Delete”, then press [OK].

Confirmation window will appear.

3 Use [K / L] to select “Yes”, then press [OK].

4b) To correct the timer program:

1 Use [K / L] to select the program you want to

correct, then press [OK].

2 Use [K / L] to select “Program Change”, then

press [OK].

3 Correct the timer program by using

[K / L / { / B], then press [OK].

5) Press [TIMER] to exit.

6) Press [TIMER SET] to return to the timer standby

mode.

THU JAN/29 11:00AMSP (1:00)

If the timer program did not complete correctly, the error number appears in the timer programming list.

Timer Programming

Date Start End L1/L2

E41 JAN/30 12:00AM 1:00AM L1

New Program

Each error number means:

E1-22 E37-39

E23-24 Unrecordable disc E25-28 Copy prohibited program E29 Disc protected E30 Disc full E31-32 Already 99 titles recorded E33 Already 999 chapters recorded E34 No space for Control information E35 PCA full * E36 Already finalized video format disc E40

E41 Power failed E42 No disc when recording

•

Recording error other than below

Some portion has not been recorded because of program overlapping. Recording did not start at the start time.

A program with the error number is grayed in the timer programming list.

•

Timer program with an error number will be cleared once the entry screen for the program is displayed.

*1 PCA is a disc's space reserved for recording test.

FRI JAN/30 11:00AM

1/1

Connections Basic Setup Function Setup VCR Functions

Recording

Playback Editing

Note

•

Press [TIMER] to check the timer recording in progress.

When the timer recording is proceeding, that program will be highlighted with red. In this case, you cannot select any other program.

Others Español

33EN 33EN

Page 34

TIMER RECORDING

PROG. B

PROG. A

PROG. B

actual recording

PROG. A

PROG. C PROG. B

PROG. C

PROG. A

PROG. B

actual recording

The first 2 minutes (at the longest) will be cut off (when recording to DVD only).

When the starting time is the same:

A program set previously (PROG. A) has priority.

When the starting time and the ending time for each programs are different:

A program that has earlier start time (PROG.C) has priority.

PROG. A

PROG. B

actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. BPROG. A

When the end time of the programming currently being recorded and the start time of the subsequent program are same:

The beginning of the PROG. B may be cut off.

Hints for Timer Recording

•

If there is a power failure or this unit has been unplugged for more than 30 seconds, the clock setting and all timer programming will be lost.

•

If a disc is not inserted, "DVD" on the front panel display

ashesandtimerrecordingcannotbeperformed.In

some cases, start time as the unit attempts to record. Please insert a recordable disc.

•

If a cassette tape with a erase-protection tab is not in the cassette compartment or there is no cassette tape in the cassette compartment, “VCR” on the front

paneldisplayashesandtimerrecordingcannotbe

performed. Please insert a recordable cassette tape.

•

If a cassette tape ends during the timer recording, the unit will automatically stop, eject the cassette tape, and turn itself to the standby mode. To continue recording, insert a recordable tape.

•

When all the timer recordings are completed, ashes.Press[TIMER SET] to release the unit from the timer standby mode.

•

If both DVD and VCR are timer programmed, you cannot use any functions for either unit during timer standby or timer recording. If you want to use functions other than recording under such condition, cancel timer recording by pressing [TIMER SET] during timer standby or stop recording by pressing [C ] / [C A] on the front panel of the unit during timer recording.

•

To cancel the timer standby mode, press [TIMER SET].

will appear momentarily around the

•

When the starting and the ending time are the same, “Exceeds 12 hours” appears and the program setting will not be accepted.

•

When the disc or cassette tape becomes full during the recording, the unit turns itself to the standby mode.

•

If the starting time is earlier and the ending time is later than the current time, the recording will start right after you press [TIMER SET] at step 9 on page 32.

•

The timer recording cannot be performed in DVD and VCR at the same time. If you set 2 programmings with the same channel and time in both devices, the program

whichissetrstwillhavethepriority.

•

“Press TIMER SET for timer recording” will appear on the TV screen 5 minutes before the programmed starting time.

The Priority of Overlapped Settings

•

Timerprogramwhichhastheearlierstarttimewillbeplacedrstinthetimerprogramlist,andbegivenpriorityover

the programs with the later start time when timer programs overlap.

•

Whentimerprogramsoverlap,therst2minutes(atthelongest)ofthelaterrecordingwillbecutoff.

•

When2ormoretimerprogramshavethesamestarttime,theprogramsetrstwillbegivenpriority.

•

A timer recording of lower priority will be cancelled or start from the middle.

•

Check the overlapped timer programmings and change the priority if necessary.

Note for DVD recording

•

When the recording time of 2 programs are overlapped or the end time of a program and the start time of another

programisthesame,therst2minutes(atthelongest)of

the subsequent program will be cut off.

•

If the cut-off portion comes up to 3 minute or more, this program will be displayed with error number E40 in the timer programming list.

34 EN34 EN

Page 35

SATELLITE LINK

You can set the unit to start recording whenever it detects the video signal from the external tuner.

Preparing for the satellite link timer recording: Preparation on the tuner

•

Satellite link accepts only the connection from L1 (rear) with the external tuner. (The connection from L2 cannot read any signals from the external tuner.)

•

The external tuner should be equipped with some kind of timer function. Using timer function of the tuner, set it to output audio/video signals when it comes to the time you want to start recording, and stop output audio/ video signals when it comes to the time you want to

nishrecording.Refertothetuner’smanualonhowto

set the timer.

•

Make sure to set the satellite link standby mode when

younishsetting.

Press [SETUP].

Use [K / L] to select “Timer

Programming”, then press [OK].

Use [K / L] to select “Satellite Link”,

then press [OK].

Timer Programming

Timer Programming Satellite Link

Use [K / L] to select the time, media

and recording mode, then press [OK].

Satellite Link

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

Playback Editing

DVD

Start Mode

VCR

5:00PM DVD SP

To Standby Mode

Use [K / L] to set the desired starting

time, then press [ B].

•

The hour can be selected from 1 to 12 with AM or PM.

•

Repeat procedures in step 5 to set the desired minutes.

•

If you wish to go back to the left, press [{].

Use [K / L] to select a recording media

(“DVD” or “VCR”), then press [ B].

Use [K / L] to select the recording

mode.

Refer to page 27 for details.

Others Español

Instructions continue on the next page.

35EN 35EN

Page 36

Press [OK].

The first 2 minutes (at the longest) will be cut off.

“To Standby Mode” is highlighted.

Press [OK] again.

Satellite Link

DVD

Start Mode

VCR

5:00PM DVD SP

To Standby Mode

In a second, the unit will be turned off automatically as it goes into the satellite link standby mode.

To cancel the satellite link function while in the satellite link standby mode:

Press [TIMER SET] to turn on the unit. To cancel the satellite link function while the

satellite link recording is in progress:

Press [C] on the front panel to stop the disc recording.

Press [C A] on the front panel to stop the cassette tape recording.

SATELLITE LINK

Notes

•

If the signal of external input breaks up over 5 seconds, satellite link function will be cancelled.

•

If you have not set the clock, “Clock Setting” menu will appear at step 4. Follow to step 4 in “SETTING THE CLOCK” on page 26.

•

You cannot set the ending time for the satellite link timer recording on this unit.

•

Recording picture will be distorted if the copy protection signal is being detected during satellite link timer recording.

•

You can record the satellite link by using S-video input jacks on the rear panel. Refer to page 17 for more information.

•

When a regular timer recording and the satellite link timer recording are overlapped, those recordings are recorded as illustrated below.

•

Press [TIMER] during the satellite link timer recording to check the satellite link timer recording in progress.

example 1

timer recording

satellite link

actual recording

The first 2 minutes (at the longest) will be cut off.

timer recording

satellite link

actual recording

example 2

timer recording

satellite link

actual recording

example 3

36 EN36 EN

Page 37

SETTINGS FOR AN EXTERNAL DEVICE

Connection to an External Device

Connect the external device properly to the unit by using input jacks either L2 (Front) or L1 (Rear). When connecting an external device of monaural output to this unit, use AUDIO L jack of L2 (Front) or L1 (Rear). Use S-video or the RCA audio/video cables for this connection.

AUDIO OUT

VIDEO

S-VIDEO

OUT

VIDEO

OUT

AUDIO OUT L R

external device

(camcorder, VCR etc.)

S-VIDEO

OUT

L R

Introduction

Connections Basic Setup Function Setup VCR Functions

RCA

S-video

cable

video cable

RCA audio cable

to L2 IN

front of this unit rear of this unit

Supplied cables used in this connection are as follows:

•

RCA audio cable (L/R) x 1

•

RCA video cable x 1

Please purchase the rest of the necessary cables at your local store.

to L1 IN

Setting for the Video Input

RCA

S-video cable

video cable

RCA audio cable

Use [K / L] to select “Select Video”, then

press [OK].

Recording

Playback Editing

Press [SETUP] and use [K / L] to select

“General Setting”, then press [OK].

“General Setting” menu will appear.

Use [K / L] to select “Video”, then

press [OK].

Submenu will appear.

Use [K / L] to select desired external

input, then press [OK].

Select Video

L1 (Rear) L2 (Front)

Use [K / L] to select the input jack

type to connect, then press [OK].

If you want to use VIDEO IN jack, select “Video In”.

If you want to use S-VIDEO IN jack, select “S-Video In”.

L1 (Rear)

Video In S-Video In

Press [SETUP] to exit.

Others Español

37EN 37EN

Page 38

SETTINGS FOR AN EXTERNAL DEVICE

Recording from an External Device

Before recording from an external device, refer to the instructions for the connection on page 37.

Recording to a DVD

Press [DVD]. Insert a recordable disc (refer to

page 24 on how to insert a disc).

It takes a while to load the disc.

Recording to a Cassette Tape

Press [VCR]. Insert the cassette tape with an erase-

protection tab intact.

Select the appropriate external input

channel (L1 or L2) by pressing [INPUT

SELECT].

•

If the external device is connected to the rear of this unit, select L1.

•

If the external device is connected to the front of this unit, select L2.

•

You can also select L1 or L2 channel by using [the Number buttons]. e.g.) For L1, press [0], [0], [1].

Press [REC MODE] repeatedly to select

a recording mode.

Refer to “Recording Mode” on page 27 for DVD or “Recording” on page 81 for VCR.

Press [I REC] on the unit to start

recording.

Start playback on the external device

to record from.

For disc:

Press [C ] on the unit to stop recording. For cassette tape:

Press [C A] on the unit to stop recording.

This operation may take a while to be completed.

38 EN38 EN

Page 39

BI-DIRECTIONAL DUBBING

Introduction

You can copy contents in a DVD to a cassette tape or do vice versa. This function is available only when the contents are not copy-protected. (Before you start, refer to page 27 for the list of compatible discs.)

Preparing for dubbing (cassette tape to DVD):

•

Insert a cassette tape to be dubbed.

•

Insert a recordable DVD.

•

Make sure there is enough space on the DVD.

Preparing for dubbing (DVD to cassette tape):

•

Insert a disc to be dubbed.

•

Insert a cassette tape with an erase-protection tab in tact.

•

Make sure there is enough recordable length on the tape.

Press [SETUP] and use [K / L] to select

“General Setting”, then press [OK].

“General Setting” menu will appear.

Use [K / L] to select “Recording”, then

press [OK].

“Recording” menu will appear.

Use [K / L] to select “Dubbing Mode”,

then press [OK].

Selection menu will appear.

Connections Basic Setup Function Setup VCR Functions

Recording

Playback Editing

Note for dubbing

•

Dubbing direction setting in “Dubbing Mode” menu is always reset to “VCR DVD” whenever you turn the power to the standby mode.

•

You cannot change the output mode during VCR to DVD or DVD to VCR duplication.

Note for recording to a tape:

Make sure

- the cassette tape’s erase-protection tab is intact.

- the cassette tape is long enough.

Note for recording to a disc:

Make sure

- the disc is compatible (refer to page 27).

Others Español

Instructions continue on the next page.

39EN 39EN

Page 40

BI-DIRECTIONAL DUBBING

VCR to DVD DVD to VCR

Use [K / L] to select “VCR DVD”, then

press [OK].

Dubbing Mode

VCR DVD DVD VCR

Press [SETUP] to exit.

Press [DVD], then press [REC MODE]

repeatedly to select the desired

recording mode.

Press [VCR], then press [ B] to find the

point where you wish to start dubbing.

Press [F] when you come to the

desired start point.

Press [D.DUBBING].

VCR to DVD duplication will start.

Press [C] to stop the dubbing.

Use [K / L] to select “DVD VCR”, then

press [OK].

Dubbing Mode

VCR DVD DVD VCR

Press [SETUP] to exit.

Press [VCR], then press [REC MODE]

repeatedly to select the desired

recording mode.

Rewind or fast forward the tape to the point where you want to start recording.

Press [DVD], then press [ B] to find the

point where you wish to start dubbing.

Press [F] when you come to the

desired start point.

Press [D.DUBBING].

DVD to VCR duplication will start.

Press [C] to stop the dubbing.

Note for DVD to VCR duplication

•

ThisfunctionisavailableforaudioCD,butnotwithJPEGles.

•

The recording mode for VCR cannot be displayed at step 5 when using HDMI / Component / S-Video connection. To display the VCR recording mode on the screen, the unit must be connected by the VIDEO OUT jack and the TV’s input select should be set to the appropriate external input channel.

Note for VCR to DVD duplication

•

After starting VCR to DVD duplication, the picture may be distorted because of the auto tracking function. This is not a malfunction. Be advised to play back the tape until the picture is stabilized, then set the starting point which you wish to start recording, and start VCR to DVD duplication.

•

This unit will automatically stop the duplication if playback with no image is detected for more than 3 minutes during VCR to DVD duplication.

•

Playback sound mode of the dubbed contents is determined by the playback sound mode of the VCR at the point of dubbing.

40 EN40 EN

Page 41

SETTING A DISC TO PROTECT

To prevent accidental recording, editing or erasing the titles, you can protect them from “DVD Menu”.

Press [SETUP].

Use [K / L] to select “DVD Menu”,

then press [OK].

Use [K / L] to select “Disc Protect OFF

ON”, then press [OK].

DVD Menu

Format Make Edits Compatible Disc Protect OFF ON Delete All Playlist

Use [K / L] to select “Yes”, then press

[OK].

Protect this disc?

Yes

A disc will be protected.

This operation may take a

while to be completed.

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

Playback Editing

Note

To cancel the disc protect:

•

When you insert a disc protected with this unit,

“Disc Protect ON OFF” will appear instead of “OFF

ON” at step 3.

DVD Menu

Format Make Edits Compatible

Disc Protect ON OFF

Delete All Playlist

To release the protection for the disc, select “Disc

Protect ON procedures.

OFF” at step 3, then follow rest of the

Others Español

41EN 41EN

Page 42

PLAYING THE DISCS ON OTHER DVD PLAYERS

Finalizing a Disc

You will need to finalize DVD-RW or DVD-R to play them back on other DVD players.

Finalizing may take several minutes up to an hour. A shorter recording period on the disc will require a longer

time period for finalization. Do not unplug the power cord during finalization.

Press [SETUP].

Use [K / L] to select “DVD Menu”,

then press [OK].

“DVD Menu” menu will appear.

Use [K / L] to select “Finalize”, then

press [OK].

Use [K / L] to select “Yes”, then press

[OK].

Finalize disc?

Yes

Finalizing will start.

Finalizing 90%

Note

•

OnceyouhavenalizedaDVD-R,youcannoteditor

record anything on that disc.

•

EvenifyouhavenalizedaDVD-RWrecordedinVR

mode, you can edit, record or delete a title.

•

WhenyouinsertaDVD-RWnalizedwiththisunit,

“Undo Finalize” will appear instead of “Finalize”.

DVD Menu

Format Undo Finalize

Disc Protect ON OFF

Delete All Playlist

To cancel finalizing...

(DVD-RW only)

•

Tocancelnalizingatstep4,press[C], select “Yes”

with [K / L], then press [OK]. Finalizing is cancelled and the unit will be in stop mode.

Do you want to cancel ?

Yes

Finalizing 5%

•

If appears when pressing [C], you cannot cancel

nalizingbecausethenalizinghasbeeninprogress.

•

When selecting “No” and press [OK] or [RETURN] ,

nalizingwillbecontinued.

•

YoucannotcancelnalizingtheDVD-Ronceithas

started.

This operation may take a while to be completed.

Finalizing is completed.

To release the finalizing for the disc, select “Undo

Finalize” at step 3.

* DO NOT turn the power off or to the standby mode

during finalization, this will result in malfunction.

42 EN42 EN

Page 43

PLAYING THE DISCS ON OTHER DVD PLAYERS

Auto Finalizing

You can finalize discs automatically using this function. You can use this function to finalize discs after finishing timer recordings and at the end of the disc space.

Press [SETUP] and use [K / L] to select

“General Setting”, then press [OK].

“General Setting” menu will appear.

Use [K / L] to select “Recording”, then

press [OK].

“Recording” menu will appear.

Use [K / L] to select “Auto Finalize”,

then press [OK].

Introduction

Connections Basic Setup Function Setup VCR Functions

Use [K / L] to select “Disc Full” or

“End of Timer Rec”, then press [OK].

Auto Finalize

Disc Full End of Timer Rec

Use [K / L] to select “ON”, then press

[OK].

e.g.) “Disc Full”

Disc Full

ON OFF

Your setting will be activated.

Press [SETUP] to exit.

Recording

Playback Editing

Note

•

Thisfunctionisnotavailableafternishingdailyor

weekly program recording.

Others Español

43EN 43EN

Page 44

INFORMATION ON PLAYBACK

is a trademark of DVD Format/Logo Licensing Corporation.

Before you play back DVD, read the following information.

Playable Discs and Files

This unit is compatible to play back the following discs. To play back a DVD, make sure that it meets the

requirements for region codes and color systems as described below. You can play back discs that have the following logos will play back on the unit. Other disc types are not guaranteed to play back.

LogosPlayable discs

DVD-video

DVD-RW (VR or Video mode)

DVD-R (Video mode)

CD-DA (audio CD)

CD-RW

CD-R

Playable files

JPEG CD-RW/-R

Media

Unplayable Discs

The following discs will not play back on this unit.

•

CD-ROM

•

DVD-RAM

•

DVD-ROM

•

Unnalizeddisc

•

DVD or CD contains Windows Media™ Audio/DivX®/

•

Compact Disc-Interactive (CD-I)

•

Video Single Disc (VSD)

•

DVD-audio

•

Video CD (VCD)

MP3les

•

Blu-ray Disc™

•

Super Video CD

•

HD DVD

On the following disc, the sound may not be heard.

•

Super audio CD - Only the sound on the CD layer can be heard. The sound on the high-density super audio CD layer cannot be heard.

Color Systems

DVD is recorded in different color systems throughout the world. The most common color system is NTSC (which is used primarily in the United States and Canada). This unit uses NTSC, so DVD you play back must be recorded in the NTSC system. You cannot play back DVD recorded in other color systems.

Region Codes

This unit has been designed to play back DVD with region 1. DVD must be labeled for ALL regions or for region 1 in order to play back on the unit. You cannot play back DVD that are labeled for other regions. Look for the symbols on the right on your DVD. If these region symbols do not appear on your DVD, you cannot play back the DVD in this unit.

The number inside the globe refers to region of the world. A DVD labeled for a specific region can only play back on

the unit with the same region code.

44 EN44 EN

Instructions continue on the next page.

Page 45

INFORMATION ON PLAYBACK

Hint for DVD Playback

The contents of DVD are generally divided into titles. Titles may be further subdivided into chapters.

DVD

title 1 title 2

chapter 1 chapter 2 chapter 1 chapter 2 chapter 3

audio CD

track 1 track 2 track 3 track 4 track 5

JPEG

folder 1 folder 2

file 1 file 2 file 3 file 4 file 5

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Editing

Others Español

45EN 45EN

Page 46

Direct Playback

BASIC PLAYBACK

Press [DVD] first.

Insert a playable disc (refer to page 24

on how to insert a disc).

* Make sure the disc is compatible with this unit.

(Refer to page 44 for the list of compatible discs.)

It may take a while to load the disc.

Press [ B] to start playback.

If you are playing back a DVD-video, a menu may appear.

Refer to “Using the Title / Disc Menu” on page 49.

Align the disc to the disc tray guide.

Press [C] once to stop playback

temporarily.

•

Refer to “Resume Playback” on page 50.

Note

•

Some discs may start playback automatically.

•

Playback will stop when you change the output mode.

46 EN46 EN

Page 47

Playback from the Title List

BASIC PLAYBACK

Press [DVD] first.

Insert a playable disc (refer to page 24

on how to insert a disc).

* Make sure the disc is compatible with this unit.

(Refer to page 44 for the list of compatible discs.)

•

To exit the title list, press [C].

•

To resume the title list, press [TOP MENU].

Press [TOP MENU].

Title list will appear. Press [DISC MENU] to switch Original/Playlist if

necessary.

•

To exit the title list, press [C].

•

To resume the title list, press [TOP MENU].

Introduction

Connections Basic Setup Function Setup VCR Functions

It may take a while to load the disc.

Recording

Use [K / L/ 0 / 1] to select a desired

title, then press [OK].

e.g.) VR mode DVD-RW original

Title List

ORG

JAN/30/15 12:00AM L1 LP 12:00AM (2:30:00) JAN/30/15 L1 LP

•

4 5 6

Press [G] to display the next page, and press [H] to display the previous page.

2 3

1 / 6

Use [K / L] to select “Play From Start”,

then press [OK].

Play From Start

Edit

Title Delete

Add To Playlist

Playback will start.

Press [C] once to stop playback

temporarily.

•

Refer to “Resume Playback” on page 50.

Playback

Editing

Others Español

Note

•

Some discs may start playback automatically.

•

You can also start playback by pressing [ B] instead of [OK] at step 3.

47EN 47EN

Page 48

BASIC PLAYBACK

Playing Back an Audio CD and a CD-RW / -R with JPEG Files

Press [DVD] first.

Insert a playable disc (refer to page 24

on how to insert a disc).

* Make sure the disc is compatible with this unit.

(Refer to page 44 for the list of compatible discs.)

It may take a while to load the disc.

When an audio CD is inserted, track list will appear. When a CD-RW/-R with JPEG files is inserted, file

list will appear. When you insert a CD-RW/-R mixed with JPEG

files, the playback media selection screen will be displayed.

For JPEG, select “Photo”.

•

Toexitthetrack/lelist,press[C].

•

Toresumethetrack/lelist,press[TOP

MENU].

Use [K / L] to select a desired folder or

track/file, then press [OK].

e.g.) File list

File List

DISC NAME

Folder 1 Folder 2

Note

•

Files whose extension is other than “. jpg / . jpeg (JPEG)” will not be listed.

•

Someunplayablefoldersorlesmaybelistedduetothe

recording status.

•

High-resolutionJPEGlestakelongertobedisplayed.

•

ProgressiveJPEGles(JPEGlessavedinprogressive

format) cannot be played back on this unit.

1/ 2

When selecting track/file:

Playback will start.

When selecting the folder (Not available for audio CD):

The files in the folder will appear. Use [K / L] to select the file or folder you want to play

back, then press [OK].

•

Press [ B], [OK] or [ B] to move to any lower hierarchies.

•

Press [s ] or [RETURN] to move back to the previous hierarchy.

Hints for audio CD tracks and JPEG files:

•

Folders are shown by .

•

Audio CD tracks are shown by .

•

JPEGlesareshownby .

•

The system can recognize up to 255 folders, up to 99

tracks/999les.

•

Lettersofale/foldernameoverowingthegiven

space will be displayed as “...”. Unrecognizable characters will be replaced with asterisks.

•

Iftherearenolesinthefolder,“NoFiles”willbe

displayed.

It is recommended that files to be played back in this unit are recorded under the following specifications:

<JPEG>

•

Upper limit : 6,300 x 5,100 dots.

•

Lower limit : 32 x 32 dots.

•

File size of image maximum : 12 MB.

48 EN48 EN

Page 49

BASIC PLAYBACK

Introduction

Playing Back an Audio CD and a CD-RW / -R with JPEG Files (cont’d)

Notes on JPEG:

•

After track is displayed for 5 seconds or 10 seconds (set in “Slide Show” on page 53) the display moves to the next track.

During JPEG playback, press [ B] or [{ ] to rotate a

picture 90 degrees clockwise or counterclockwise respectively.

(Not available when the display menu appears.)

Using the Title / Disc Menu

DVD may contain a title list, which describes the contents of the disc or a disc menu, which guides you through the available functions in the disc.

1) Insert a playable disc (refer to page 24 on how

* Make sure the disc is compatible with this unit.

2) Press [TOP MENU] or [DISC MENU] to call up the

3) Use [K / L / { / B] to make a selection, and then

4) Press [C] to exit.

Press [DVD] first.

to insert a disc).

(Refer to

page 44

for the list of compatible discs.)

It may take a while to load the disc.

title list or disc menu.

press [OK] to enable your selection.

Note

•

You can select a numbered menu with [the Number buttons] also.

•

Menus vary among discs. Refer to the information accompanying the disc for details.

•

[TOP MENU] or [DISC MENU] will not always be active with all DVD.

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Pause

1) During playback, press [F].

Playback will be paused and sound will be muted.

2) Press [ B] to return to the normal playback.

Note

•

On DVD, set “Still Mode” to “Field” in “Playback” menu if pictures in the pause mode are blurred. (Refer to page 76.)

Editing

Others Español

49EN 49EN

Page 50

SPECIAL PLAYBACK

Resume Playback

You can play back from where you stopped playing back the disc last.

1) During playback, press [C].

The resume message will appear.

Resume ON

2) Press [ B].

In a few seconds, playback will resume from the point

at which it last stopped. You can resume playback at the same point even if you turn the unit to the standby mode.

To cancel the resume playback and start playing back

the disc from the beginning, press [C] again while the playback is stopped.

Note

•

ForJPEGles,playbackwillresumefromthebeginning oftheleatwhichplaybackwasstopped.

Skipping TV Commercials During Playback

You can skip TV commercials to enjoy the recorded programs without interrupting.

During playback, press [CM SKIP].

Normal playback will start at 30 seconds ahead from the point you press [CM SKIP].

Every time you press [CM SKIP], the searching point will be extended by 30 seconds ahead.

You can press [CM SKIP] up to 6 times (180 seconds).

e.g.) Press [CM SKIP] once.

CM Skip 30 sec.

(forwarding 30 seconds)

Playback will return to the normal playback.

Fast Forward / Fast Reverse Playback

1) During playback, press [ D] or [E ].

Every time you press [ D] or [E ], approximate

speed will be changed as follows.

Fast forward or fast reverse playback across titles (for

DVD) is not possible.

normal

20x

speed

playback

2x 20x5x 40x40x

For audio CD, approximate speed is fixed at 8x with

sound (indicated with

/ ).

2) Press [ B] to return to the normal playback.

Note

•

Forward/reverse speed will be indicated with icons as

follows. forward (approx. speed) 2x: 20x: 40x: reverse (approx. speed) 5x: 20x: 40x:

Rapid Playback

Rapid playback function is available only during playback.

This function is available only on discs recorded in the Dolby Digital format, and plays back in a slightly faster/ slower speed while keeping the sound quality just as normal playback.

1) During playback, press [RAPID PLAY].

x 0.8 :

Press [RAPID PLAY] once during playback. Plays back approximately at 0.8 times of normal playback.

x 1.3 :

Press [RAPID PLAY] twice during playback. Plays back approximately at 1.3 times of normal playback.

x 1 :

Press [RAPID PLAY] 3 times to play back in normal speed. No effects.

2) Press [ B] to return to the normal playback.

Note

•

Audio (language) setting cannot be changed while using this mode.

•

This feature may not work at some point in a disc.

•

Audio is PCM during rapid playback mode except when using digital audio connection.

•

When using digital audio connection (COAXIAL), the LPCM sound (2 channel) will be output.

50 EN50 EN

Page 51

SPECIAL PLAYBACK

Introduction

Step by Step Playback

1) During playback, press [F].

Playback will be paused and sound will be muted.

2) Press [G] repeatedly.

Playback will advance one frame (or step) at a time

when you press [G] with the sound muted.

To play back step by step backward: Press [H] repeatedly. Every time you press the button, the playback will go

backward by one frame.

•

Press and hold [H] / [G] to reverse/ advance continuously.

3) Press [ B] to return to the normal playback.

Slow Forward / Slow Reverse Playback

1) During playback, press [F]. Then press [ D] or [E ].

Every time you press [ D] or [E ], approximate

speed will be changed as follows. (The sound will remain muted.)

1/8x

2) Press [ B] to return to the normal playback.

pause

1/16x 1/8x1/16x 1/3x1/4x

Zoom

1) During playback, press [DISPLAY] to bring up the display menu.

2) Use [{ / B] to select menu.

e.g.) DVD-video

1/ 5 1/ 5

3) Use [K / L] to select a desired zoom factor to zoom, then press [OK].

1/ 5 1/ 5

Zoom menu will appear. There are four options (x1.0, x1.2, x1.5 and x2.0), these are displayed

excluding the current zoom rate.

Zoom area will be displayed.

4) Use [K / L / { / B] to select a desired zoom position, then press [OK].

to display the selection

0:01:00 / 1:23:45

DVD

Video

0:01:00 / 1:23:45

DVD

× 1.2 × 1.5 × 2.0

Video

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Editing

Note

•

Forward/reverse speed will be indicated with icons as

follows. forward (approx. speed) 1/16x: 1/8x: 1/3x: reverse (approx. speed) 1/16x: 1/8x: 1/4x:

Zoom playback will start.

Note

•

When selecting a smaller factor than the current one, the zoom area will not be displayed.

•

To exit the zoom menu, press [RETURN] repeatedly at step 3.

•

To cancel the zoom function, select “x1.0” using [K / L], then press [OK].

•

You cannot slide the zoomed picture on some JPEG

les.

Others Español

51EN 51EN

Page 52

SPECIAL PLAYBACK

Marker Setting

This feature allows you to assign a specific point on a disc to be called back later.

1) During playback, press [DISPLAY] to bring up the display menu.

If the display menu is already shown, skip to step 2.

2) Use [{ / B] to select

to display the marker

list.

e.g.) DVD-video

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

3) Use [K / L] to select a desired marker number. When it reaches the desired point, press [OK].

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

---

Video

The title (track) number and the time will be displayed.

4) To return to the marker later:

Use [K / L] to select the desired marker number,

then press [OK].

Note

•

To clear a marker, select the marker number to be cleared, then press [CLEAR].

•

All markers will be erased when you operate these

operations listed below. – Opening the disc tray – Turning the unit to standby / off – Record on a recordable disc

•

You can mark up to 6 points.

Repeat Playback

Available repeat function may vary depending on the discs.

1) During playback press [DISPLAY] to bring up the display menu, then proceed to step 2) or press [REPEAT] then proceed to step 3).

If the display menu is already shown, skip to step 2.

2) Use [{ / B] to select

to display the selection

menu.

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

3) Use [K / L] to select a desired repeat type, then press [OK].

The selected repeat playback will start. e.g.) DVD-video

OFF Title Chapter A – B

e.g.) audio CD

OFF Track All A – B

e.g.) JPEG files

OFF Track All Group

Title: The current title will be played back

repeatedly.

Chapter: The current chapter will be played back

repeatedly.

All: The current disc will be played back

repeatedly.

A-B: Desired section can be played back

repeatedly.

1) Use [K / L] to select “A-B”, then press

[OK].

2) Press [OK] at the desired starting point A.

3) Press [OK] at the desired ending point B.

Track: The current track or file will be played back

repeatedly.

Group: The current folder will be played back

repeatedly.

Note

•

Point B for the repeat A-B playback should be set within the same title or track as point A.

•

To cancel the repeat playback, select “OFF” at step 3. The repeat setting will also be cancelled when you stop playback.

•

You cannot select “Group” during the random playback.

•

During the A-B repeat, if you reaches the point A with any reverse playback, the reverse playback will be cancelled and the A-B repeat playback resumes from point A.

52 EN52 EN

Page 53

SPECIAL PLAYBACK

Introduction

Random Playback

You can play back a disc randomly instead of playing back in the original order.

1) Press [SETUP].

2) Use [K / L] to select “DISC Playback Mode”, then press [OK].

“DISC Playback Mode” menu will appear. For JPEG, use [K / L] to select “Photo”, then press

[OK].

3) Use [K / L] to select “Random Play”, then press [OK].

Random playback will start.

Note

•

To cancel random playback, press [C] twice during random playback. “OFF” appears on the TV screen.

Slide Show

You can select the display time between 5 seconds and 10 seconds.

1) Follow steps 1 and 2 in “Random Playback” on

this page.

2) Use [K / L] to select “Slide Show”, then press

[OK].

3) Use [K / L] to select the display time, then press

[OK].

4) Press [SETUP] to exit.

Note

•

Large-sizeJPEGlestakeafewmomentstobe

displayed.

Program Playback

You can program the disc to play back in your desired order.

1) Press [SETUP].

2) Use [K / L] to select “DISC Playback Mode”, then press [OK].

“DISC Playback Mode” menu will appear.

3) Use [K / L] to select “Program Play”, then press [OK].

4) Use [K / L] to select a desired track, then press [OK] or [ B].

DISC Playback Mode

Program Play

-- -- -- -- -- -- -- -- --

-- -- -- -- -- -- -- -- -- --

0:00:00Total

Repeat this step until you program all the desired

tracks.

5) Press [ B].

DISC Playback Mode

Program Play

04 10 06 -- -- -- -- -- --

-- -- -- -- -- -- -- -- -- --

0:31:07Total

Program playback will start.

Note

•

To erase tracks you selected, press [CLEAR] at step 4.

•

You can make program settings up to 50 tracks.

•

To cancel program playback, press [C] twice during program playback. “OFF” appears on the TV screen.

•

You may also select a desired track using [the Number buttons] at step 4.

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Editing

Others Español

53EN 53EN

Page 54

SEARCH

Title / Chapter Search

Using [H] / [G]

1) During playback, press [G] to skip the current title or chapter and move to the next.

The title or chapter will move forward by one at a

time.

•

If there is no chapter in one title, the current title will be skipped.

To go back to the beginning of the current title or

chapter, press [H].

Press it repeatedly to go to the previous title or

chapter. The title or chapter will move backward one at a time.

Using [DISPLAY]

1) During playback, press [DISPLAY] to bring up the

display menu.

2) Use [{ / B] to select

e.g.) DVD-video

1/ 5 1/ 5

, then press [OK].

0:01:00 / 1:23:45

DVD

Video

Track Search

Using [H] / [G]

1) During playback, press [G] to skip the current track/file and move to the next.

The track/file will move forward one at a time.

To go back to the beginning of the current track/file, press [H]. Press it repeatedly to go to the previous track/file. The track/file will move backward one at a time. For JPEG files, press it once to go to the previous file.

Using [DISPLAY]

1) During playback, press [DISPLAY] to bring up the display menu.

If the display menu is already shown, skip to step 2.

2) Use [{ / B] to select

e.g.) audio CD

1/ 5CD0:00:15 / 0:05:00

, then press [OK].

The number next to will be highlighted.

3) Title: Use [K / L] or [the Number buttons] to enter a desired title number to search, then press [OK].

Title search will start.

Chapter:

Press [ B] to move to the number next to chapter. Use [K / L] or [the Number buttons] to enter a desired chapter number to search, then press [OK].

After the search, playback will start automatically.

Note

•

In search mode display, total numbers of each search contents (title/chapter/time) are shown as a denominator.

1/ 5 1/ 50:01:00 / 1:23:45

total number of titles

total number of chapters

DVD Video

total time of the title

for

The number next to will be highlighted.

3) Use [K / L] or [the Number buttons] to enter a desired track/file number to search, then press [OK].

After the search, playback will start automatically.

Note

•

During CD playback you can enter a track number directly using [the Number buttons] for track search without displaying the menu.

54 EN54 EN

Page 55

Time Search

1) During playback, press [DISPLAY] to bring up the display menu.

If the display menu is already shown, skip to step 2.

2) Use [{ / B] to select

e.g.) DVD-video

1/ 5 1/ 50:01:00 / 1:23:45

e.g.) audio CD

1/ 5CD0:00:15 / 0:05:00

The number next to will be highlighted.

To move to the number next to

When time search is not available,

counter are not displayed.

3) Use [K / L / { / B] or [the Number buttons] to enter a desired time to search, then press [OK].

After the search, playback will start automatically.

, then press [OK].

DVD Video

, Press [ B].

and time

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Note

•

Timesearchisavailableonlyinthesametrack,leor

title.

Editing

Others Español

55EN 55EN

Page 56

SELECTING THE FORMAT OF AUDIO AND VIDEO

You can select the format of audio and video as you prefer depending on the contents of the disc you are playing back.

Switching Subtitles

DVD-video may have subtitles in 1 or more languages. Available subtitle languages can be found on the disc case. You can switch subtitle languages anytime during playback.

1) During playback, press [DISPLAY] to bring up the display menu.

2) Use [{ / B] to select

to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

3) Use [K / L] to select a desired subtitle language, then press [OK].

1/ 5 1/ 5

OFF

1.English

0:01:00 / 1:23:45

DVD

Video

Subtitle will be displayed in the selected language. When selecting “OFF”, subtitle will disappear.

Note

•

Some discs will only allow you to change the subtitle from the disc menu. Press [TOP MENU] or [DISC MENU] to display the disc menu.

•

If a 4-digit language code appears in the subtitle menu, refer to “LANGUAGE CODE” on page 88.

Switching Audio Soundtrack

When playing back a DVD-video recorded with 2 or more soundtracks (these are often in different languages), you can switch them during playback.

When playing back audio CD you can switch “L/R”(stereo), “L”(left) or “R”(right).

1) During playback press [DISPLAY] to bring up the display menu, then proceed to step 2) or press [AUDIO] then proceed to step 3).

•

If the display menu is already shown, skip to step 2.

2) Use [{ / B] to select menu.

3) Use [K / L] to select a desired audio soundtrack or audio channel, then press [OK].

For DVD-video

•

Audio soundtrack will switch.

1/ 5 1/ 5

1.Dolby Digital 5.1ch English

2.Dolby Digital 2ch English

•

If the title contains both main and sub audio, you can further select “L” (main), “R” (sub) or “L/R” (mixed of main and sub).

For audio CD

•

Audio channel will switch.

e.g.) audio CD

1/ 5

1. L/R

2. L

3. R

to display the selection

0:01:00 / 1:23:45

DVD

Video

0:00:15 / 0:05:00

56 EN56 EN

Note

•

Some discs will only allow you to change the soundtrack from the disc menu. Press [TOP MENU] or [DISC

MENU] to display the disc menu.

Page 57

SELECTING THE FORMAT OF AUDIO AND VIDEO

Switching Camera Angles Reducing Block Noise

Introduction

Some DVD-video have scenes shot from 2 or more angles. Angle information should be on the disc case if

the disc contains multi-angle scenes.

1) During playback, press [DISPLAY] to bring up the display menu.

2) Use [{ / B] to select

, then press [OK].

e.g.) DVD-video

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

Angle icon appears when a switching camera angle is

available.

Angle will switch each time you press [OK].

Note

•

Angle icon does not appear on the TV screen if the “Angle Icon” is set to “OFF” in the “Playback” menu. Refer to page 76.

This function reduces noise in the playback picture.

1) During playback, press [DISPLAY] to bring up the display menu.

2) Use [{ / B] to select

to display the selection

menu.

e.g.) DVD-video

1/ 5 1/ 5

0:01:00 / 1:23:45

DVD

Video

3) Use [K / L] to select a desired option, then press [OK].

1/ 5 1/ 5

OFF Type 1 Type 2

0:01:00 / 1:23:45

DVD

Video

Your setting will be activated. OFF : When playing back titles with a few noises

such as DVD-video.

Type 1 : For the titles recorded in long time mode

such as EP or SLP mode.

Type 2 : Same as type 1, only more effective.

Connections Basic Setup Function Setup VCR Functions

Recording

Playback

Editing

Others Español

57EN 57EN

Page 58

INFORMATION ON DISC EDITING

4 5 6

Guide to a Title List Editing Discs

Title list allows you to check the titles recorded on the disc easily. You can choose a title to play back from this list and easily edit the titles as you prefer.

Press [DVD], then press [TOP MENU].

Title List

ORG

JAN/30/15 1:00AM L1 LP 12:00AM (2:00:00) JAN/30/15 L1 LP

1 2 3

4 5 6

1 / 2

3 312

Edit

ORG

Scene Delete

Edit Title Name

Chapter Mark Protect

JAN/30/15 11:00PM L1 LP

1. Title list: List of the titles recorded on the disc, and

their information.

2. The protect icon: Appears when the title has been

protected. (Original titles only)

3. Arrow: Indicating there is a previous / next page.

4. Title list icon: Indicates a type of the displayed title

list.

: VR (Original)

ORG

: VR (Playlist)

Video

5. Title name

6. Title information: Displays various information on

the selected title.

7. Submenu: Submenus for the selected menu are

displayed here.

8. Title name (editable): If you do not name the title,

the recorded date, time and the recording mode are displayed here.

9. Progress bar:

Indicating the progress of the playback. The vertical lines in the bar indicates chapter marks, and “

” sliding on the bar indicates current point of

playback displayed in the preview window.

10. Preview window: Preview of the selected title is

displayed here.

11. Playback status: Indicating the current playback

status of the selected title.

Press [C] to exit the title list.

0 : 00 : 59

789

: Video mode

You can edit discs for the following items. Be sure that once you edit titles, they will not remain as original.

•

Adding Titles to a Playlist (Refer to page 61.)

•

Erasing All Playlists (Refer to page 62.)

•

Deleting a Title (Refer to page 63.)

•

Deleting a Part of a Title (Refer to page 64.)

•

Putting Names on Titles (Refer to page 66.)

•

Setting Chapter Marks (Refer to page 67.)

•

Clearing Chapter Marks (Refer to page 68.)

•

Dividing a Title (DVD-RW only) (Refer to page 69.)

•

Combining Titles (Refer to page 70.)

•

Setting or Releasing the Title Protection (Refer to page 71.)

(Possible editing functions depend on the recording format and editing method.)

Original and playlist (VR mode)

For VR mode DVD-RW, you can edit the recordings in playlist without changing the original recordings. Playlist does not take up much disc space. After you make a recording to VR mode DVD-RW, a playlist will be created automatically.

What “Original” or “Playlist” is for?

Throughout this manual, you will find original and playlist which refer to the actual content and the edited version.

•

Original content refers to what’s actually recorded in the VR mode on a DVD-RW.

•

Playlist content refers to the edited version of the VR mode DVD-RW; how the original content is to be played back.

Finalizing a disc

•

This will allow a disc that is recorded on this unit to be

playedbackonotherDVDplayer—withoutnalization

it will not be playable on other DVD player.

•

AfternalizingaDVD-RW/-R,youcannoteditany

information that is on that disc.

Note

•

When selecting “Edit” on pop-up menu of the title list and edit the title, the title list is displayed after writing the edited contents onto the disc.

•

The capacity indicator in the right side of the title list may not indicate the precise capacity in the disc.

•

The capacity indicator may not indicate the capacity for the titles of which recording time is short.

•

OnceyouhavenalizedaDVD-R,youcannoteditor

record anything on that disc.

58 EN58 EN

Page 59

FORMATTING A DISC

Choosing the Recording Format of a Brand-New DVD-RW

When inserting a brand-new DVD-RW, the unit automatically starts to initialize the disc. DVD-RW will be formatted either video or VR mode according to the recording format mode setting of the unit. Before inserting a brand-new DVDRW, you need to set the recording format to the desired mode. You can also manually format a DVD-RW once it has been used.

Press [SETUP].

Use [K / L] to select “DVD Menu”,

then press [OK].

Setup

General Setting

Timer Programming

Title List

DVD Menu

Use [K / L] to select “Format”, then

press [OK].

DVD Menu

Format

Finalize

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Note

•

The recording format setting is effective only for DVDRW. You cannot change the recording format for a DVD-R.

•

You cannot mix two formats on one DVD-RW disc. If you insert a disc that has been formatted before, the recording format is not changed if you select another format in the “Setup” menu only. To reformat a disc (change disc format type), refer to “Reformatting a Disc Manually” on page 60.

Use [K / L] to select “Format Mode”,

then press [OK].

DVD Menu

Format Finalize

Use [K / L] to select “Video mode” or

“VR mode”, then press [OK].

Press [SETUP] to exit.

Start

Format Mode

Insert a brand-new disc.

Formatting will start.

Formatting 90%

Formatting is completed.

“100%” is indicated.

Editing

Others Español

59EN 59EN

Page 60

FORMATTING A DISC

Reformatting a Disc Manually

If you are using a DVD-RW, you can format the disc by performing “Format”. You can format DVD-RW for either video mode recording or VR mode recording.

Insert a recordable disc.

Press [SETUP].

Use [K / L] to select “DVD Menu”,

then press [OK].

Setup

General Setting

Timer Programming

Title List

DVD Menu

Use [K / L] to select “Format”, then

press [OK].

e.g.) VR mode DVD-RW

DVD Menu

Format Finalize Disc Protect OFF ON Delete All Playlists

Note

•

When you reformat the disc, the contents of the disc are erased.

•

For DVD-RW, make sure that the recording format is set to the desired mode. (See steps 1 to 6 in “Choosing the Recording Format of a Brand-New DVD-RW” on page 59.)

•

This unit may not be able to reformat a disc that is not previously formatted by this unit (e.g. DVD disc formatted by PC or another recorder).

Use [K / L] to select “Start”, then

press [OK].

DVD Menu

Format Finalize Disc Protect OFF ON Delete All Playlists

Selection menu will appear and prompt you to confirm.

Start Format Mode

Use [K / L] to select “Yes”, then press

[OK].

Formatting will start. If you want to cancel formatting, select “No”.

Are you sure?

Yes

Formatting is completed.

“100%” is indicated.

Formatting 100%

60 EN60 EN

Page 61

CREATING/DELETING PLAYLIST

Adding Titles to a Playlist

Introduction

Playlist

For VR mode DVD-RW, you can create the playlist as you wish.

You can add up to 99 titles to a playlist (as long as the total number of the playlist does not exceed 999 chapters).

Press [DVD].

Press [TOP MENU].

•

If the “Playlist” screen appears, press [DISC MENU] to switch the “Original” screen.

Use [K / L/ 0 / 1] to select the desired

title, then press [OK].

Use [K / L] to select “Add To Playlist”,

then press [OK].

Play From Start

Edit

Title Delete

Add To Playlist

Use [K / L] to select “Yes”, then press

[OK].

Create a Playlist ?

Yes

The title is added to playlist.

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Note

When a playlist contains 99 titles or more or 999 chapters or more, “Add to Playlist” cannot be selected.

Press [RETURN] or [C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Editing

Others Español

61EN 61EN

Page 62

Erasing All Playlist

CREATING/DELETING PLAYLIST

Playlist

A playlist can be deleted if it is no longer needed.

Press [DVD].

Press [SETUP].

Main menu will appear.

Use [K / L] to select “DVD Menu”,

then press [OK].

Use [K / L] to select “Delete All

Playlists”, then press [OK].

DVD Menu

Format Finalize Disc Protect OFF ON Delete All Playlists

Use [K / L] to select “Yes”, then press

[OK].

Delete entire playlist?

Yes

“Are you sure?” will appear. Use [K / L] to select “Yes” and then press [OK].

DVD Menu

Format Finalize Disc Protect OFF ON Delete All Playlist

Delete entire play list?

Are you sure?

Yes

Note

Deleting a playlist will not increase the available recording time on the disc.

62 EN62 EN

Playlist is deleted. Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Page 63

DELETING TITLES

Introduction

You can delete a title which you do not need anymore. Please be advised that the titles once deleted cannot be

brought back to the disc. For DVD-RW, when the last recorded title in the title list is

deleted, the available disc space to record on will be increased. For DVD-R, the disc space to record on will not be changed.

Press [DVD].

In stop mode, press [TOP MENU].

Title list original or playlist will appear.

•

For VR mode DVD-RW, press [DISC MENU] to switch between “Original” and “Playlist”.

Use [K / L/ 0 / 1] to select the desired

title, then press [OK].

e.g.) VR mode DVD-RW original

Title List

JAN/30/15 12:00AM L1 LP 12:00AM (2:30:00) JAN/30/15 L1 LP

4 5 6

2 3

1 / 6

Use [K / L] to select “Title Delete”,

then press [OK].

Play From Start

Edit

Title Delete

Add To Playlist

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Use [K / L] to select “Yes”, then press

[OK].

Delete this title?

Yes

After that, “Are you sure?” will appear, select “Yes” and then press [OK].

Title will be deleted.

Press [RETURN] or [STOP C] to exit.

Data will be written onto the disc momentarily.

Writing to Disc 90%

This operation may take a while to be completed.

Editing

Others Español

63EN 63EN

Page 64

Deleting a Part of a Title

EDITING DISCS

You can delete a specific part of a title. Even when parts of title are deleted from the playlist, the

original title will remain as it is.

Press [DVD].

In stop mode, press [TOP MENU].

Title list original or playlist will appear.

•

For VR mode DVD-RW, press [DISC MENU] to switch between “Original” and “Playlist”.

Use [K / L/ 0 / 1] to select the desired

title, then press [OK].

e.g.) VR mode DVD-RW original

Title List

JAN/30/15 12:00AM L1 LP 12:00AM (2:30:00) JAN/30/15 L1 LP

4 5 6

2 3

1 / 6

Use [K / L] to select “Edit”, then press

[OK].

Play From Start

Edit

Title Delete

Add To Playlist

Note

When a scene is deleted from an original, the playlist related to the original will be deleted. You cannot select “Scene Delete” if the number of chapter marks in the original or playlist is more than 999. (Depends on the content, there is a case that you cannot select “Scene Delete” before the number of chapter marks reaches 999.) The recordable disc space will not increase even after deleting a part of a title on the playlist.

Use [K / L] to select “Scene Delete”,

then press [OK].

e.g.) VR mode DVD-RW playlist.

Edit

Scene Delete

Edit Title Name Chapter Mark Title Dividing Title Combining

JAN/30/15 1:00AM L1 LP

Instructions continue on the next page.

1 : 25 : 47

64 EN64 EN

Page 65

EDITING DISCS

Introduction

Use [H / G],

[E ], [ D], [ B] and [F] to find the start

point, then press [OK].

Edit - Scene Delete

Start

End Preview Delete

JAN/30/15 1:00AM L1 LP

1 : 25 : 47

Then use [H / G], [E ], [ D], [ B] and [F] again to move to the end point, and press [OK].

Edit - Scene Delete

Start

End

Preview Delete

JAN/30/15 1:00AM L1 LP

The cursor will move to “Preview”. The bar at the bottom of the screen indicates the

total and the elapsed time of the title, and the area selected for deletion is indicated in red.

You can check the preview by pressing [OK].

•

Before and after 5 seconds of the deleted point will be played back for preview.

1 : 45 : 00

Use [K / L] to select “Delete” then press

[OK].

Edit - Scene Delete

Start

End Preview Delete

JAN/30/15 1:00AM L1 LP

1 : 47 : 00

Use [K / L] to select “Yes” then press

[OK].

“Are you sure?” will appear. Select “Yes” using [K / L] and then press [OK].

Edit - Scene Delete

Are you sure?

Yes No

JAN/30/15 1:00AM L1 LP

1 : 50 : 00

The part of the title is deleted.

Press [RETURN] and then [RETURN] or

[C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Editing

Before editing

Edited

start point end point

Others Español

65EN 65EN

Page 66

EDITING DISCS

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

! ” # $ % & ’ ( ) *

+ , - . / : ; < = >

? @ [ ] ^ _ { | }

ABC

abc @ ! ?

123

(*1) (*1)

Select

Press

Putting Names on Titles

You can put title names on the titles and change the names from this menu.

Use [K / L] to select “Yes”, then press

[OK].

Edit - Edit Title Name

ORG

Yes

Follow steps 1 to 3 in “DELETING

TITLES” on page 63 to display “Edit”

menu.

Use [K / L] to select “Edit Title Name”,

then press [OK].

Edit

ORG

Scene Delete

Edit Title Name

Chapter Mark

Protect

MY FAVORITE

1 : 05 : 00

The name you entered will be activated for the title.

After this operation is completed, press

[RETURN] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Guide to Edit Title Name

1) Use [K / L] to select a desired character set, then press [OK].

2) Follow the list below, use [the Number buttons] repeatedly until the desired letter appears. When you finish entering a title name, press [OK].

JAN/30/15 1:00AM L1 LP

To enter a title name, follow the steps

of “Guide to Edit Title Name” on this

page.

ORG

•

66 EN66 EN

Edit - Edit Title Name

Whenyounishenteringatitlename,press[OK].

1 : 05 : 00

ABC

abc

123

@! ?

1 : 05 : 00

character set

area for entering title names

*1 Press , character set will be changed to “ @!? ”

mode automatically. Press

to to back to the

previous character set.

•

To delete letters, press [CLEAR] repeatedly. Holding [CLEAR] to delete all letters.

•

Use [0 / 1] to move the cursor to the left and right.

•

You can enter up to 30 letters.

Note

•

Undenedlettersinatitlenameareshownby“*”.If

you delete them, adjoining letters may change to “*” or others.

Page 67

EDITING DISCS

Setting Chapter Marks

You can put chapter marks in each title. Once a chapter is marked, you can use it for the chapter search feature.

Follow steps 1 to 3 in “DELETING

TITLES” on page 63 to display “Edit”

menu.

Use [K / L] to select “Chapter Mark”,

then press [OK].

Submenu will appear.

Use [SKIP H / G],

[REV E], [FWD D], [PLAY B] and

[PAUSE F] to find the point where you will create a new chapter mark. Or, use [SKIP H / G] to find a chapter mark that you wish to delete.

Use [K / L] to select “Add” or

“Delete”, then press [OK].

e.g.) VR mode DVD-RW original

Edit - Chapter Mark

ORG

Add

Delete

Chapter 2 / 3

Introduction

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Note

Maximum numbers of chapter for each DVD: VR mode DVD : 999 chapters per entire original and

playlist Besides the above-mentioned, it is not likely to be able to add according to recorded time and number of chapters.

JAN/30/15 1:00AM L1 LP

1 : 25 : 47

Use [K / L] to select “Yes”, then press

[OK].

If you select “Add” at step 4, a new chapter mark will be added, and if you select “Delete” at step 4, the chapter mark will be deleted.

e.g.) Add

Edit - Chapter Mark - Add

ORG

Yes

Chapter 2 / 3

JAN/30/15 1:00AM L1 LP

A new chapter mark will be added.

1 : 25 : 47

Press [RETURN].

Press [RETURN] again and then

[RETURN] or [STOP C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Editing

Others Español

67EN 67EN

Page 68

EDITING DISCS

Setting or Clearing All Chapter Marks at Once

For titles in video mode DVD-RW, you can set or edit chapters at every time interval. You can clear the chapter mark too.

You can specify the interval of chapter marks for titles last more than 5 minutes.

Follow steps 1 to 3 in “DELETING

TITLES” on page 63 to display “Edit”

menu.

Use [K / L] to select “Chapter Mark”,

then press [OK].

Edit

Video

Edit Title Name

Chapter Mark

JAN/30/15 1:00AM L1 LP

1 : 25 : 47

Use [K / L] to select the desired

interval, then press [OK].

Edit - Chapter Mark

Video

OFF

5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

JAN/30/15 1:00AM L1 LP

1 : 25 : 47

Use [K / L] to select “Yes”, then press

[OK].

Chapter marks are added. If you select “OFF” at step 3, all the chapter

marks are erased.

Press [RETURN] and then [RETURN] or

[STOP C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Note

You cannot select a chapter mark interval that exceeds the length of a title. The length of chapters may slightly deviate from the one specified at the step 3. A chapter mark may be delayed depending on the recording content. Maximum number of chapter for video mode DVD is 99 chapters per title. The interval for auto chapter may be up to two minutes different from the time option you set.

68 EN68 EN

Page 69

Dividing a Title

EDITING DISCS

Introduction

Playlist

You can divide one title into two new titles.

Press [DVD].

In stop mode, press [TOP MENU].

•

For VR mode DVD-RW, press [DISC MENU] to select “Playlist”.

Use [K / L/ 0 / 1] to select a desired

title, then press [OK].

Use [K / L] to select “Edit”, then press

[OK].

e.g.) VR mode DVD-RW playlist

Play From Start

Edit

Title Delete

Use [SKIP H], [SKIP G], [REV E],

[FWD D], [PAUSE F] and [PLAY B] to

decide the point at which you will divide the title.

Use [K / L] to select “Title Dividing”,

then press [OK].

Connections Basic Setup Function Setup VCR Functions

Recording Playback

Note

You cannot divide a title on the disc when the number of recording titles reaches the maximum of 99, and the number of recording chapters reaches the maximum of

999.

Use [K / L] to select “Yes”, then press

[OK].

e.g.) VR mode DVD-RW playlist

Edit - Title Dividing

Yes

JAN/30/15 1:00AM L1 LP

The title will be divided into two new titles. Both title names are identical.

Writing to Disc 90%

This operation may take a while to be completed.

For VR mode DVD-RW: Proceed to step 7.

Press [RETURN] or [STOP C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

1 : 25 : 47

Editing

Others Español

69EN 69EN

Page 70

Combining Titles

Playlist

You can combine two titles into a single title.

EDITING DISCS

Follow steps 1 to 3 in “Dividing a Title”

on page 69 to display “Edit” menu.

Use [K / L] to select “Title

Combining”, then press [OK].

Edit

Scene Delete

Edit Title Name Chapter Mark Title Dividing Title Combining

JAN/30/15 1:00AM L1 LP

Title combining setting window will appear. Selected title grays out, and the frame of the next

title becomes yellow.

Edit - Title Combining

JAN/30/15 11:00PM L1 LP 11:00PM (0:30:00) JAN/30/15 L1 LP

1 +

4 5 6

1 : 25 : 47

2 3

1 / 6

Use [K / L / { / B] to select another

title to combine, then press [OK].

Selection menu will appear.

Use [K / L] to select “Yes”, then press

[OK].

Combine selected titles?

Yes

The two titles will combine into a single title.

Title List

JAN/30/15 12:00AM L1 LP 12:00AM (2:30:00) JAN/30/15 L1 LP

2 3

Note

You cannot select the same title twice and combine it into a single title. If either one of the two original titles is deleted, the combined new title is also deleted.

70 EN70 EN

4 5 6

1 / 6

Press [RETURN] or [C] to exit.

Data will be written onto the disc momentarily.

This operation may take a while to be completed.

Page 71

EDITING DISCS

Setting or Releasing the Title Protection

Introduction

Original

To prevent the accidental editing or erasing of the titles, you can protect them in “Edit” menu.

You can cancel the title protection feature after it is applied.

Follow the steps 1 to 3 in

on Titles”

page 66

“Putting Names

to display “Edit”

menu.

Use [K / L] to select “Protect”, then

press [OK].

Edit

ORG

Scene Delete

Edit Title Name Chapter Mark Protect

JAN/30/15 1:00AM L1 LP

•

If the title is protected, icon will appear in the original list.

1 : 25 : 47
