Sanyo EM-S5002W User Manual

INSTRUCTION MANUAL AND COOKING GUIDE

EM-S5002W

Microwave Oven

Read these instructions carefully before using your microwave oven. If you follow the instructions, your oven will provide you with many years of good service.

SAVE THESE INSTRUCTIONS

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE

ENERGY

(a) Do not attempt to operate this oven with the door open since

open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door

or allow soil or cleaner residue to accumulate on sealing surfaces.

that the oven door close properly and that there is no damage to the: (1) DOOR (bent) (2) HINGES AND LATCHES (broken or loosened) (3) DOOR SEALS AND SEALING SURFACES

(d) The oven should not be adjusted or repaired by anyone except

properly qualified service personnel.

SPECIFICATIONS

Model: EM-S5002W Power Source: AC 120 V, 60 Hz Power Consumption: 1450W Maximum Output: 1000W Oven Capacity: 1.1 cu. ft. Turntable Diameter: 12

/8"

Outside Dimensions: (w x h x d) 20

/16" x 12" x 181/2"

Weight: Approx. 39.5 lbs.

Specifications subject to change without notice.

WARNING:Handling the cord on this product or cords associated with

accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

TABLE OF CONTENTS

SAFETY

■ Proper and Safe Use of Your Oven.............................................4

■ Important Safety Instructions......................................................5

■ Grounding Instructions ................................................................6

■ Utensils.......................................................................................6-7

SETTING UP YOUR OVEN

■ Names of Oven Parts and Accessories.......................................8

■ Tu rntable Installation....................................................................8

■ Installation.....................................................................................9

OPERATION

■ Control Panel and Features .......................................................10

■ Setting Clock ...............................................................................11

■ Child Lock-Out.............................................................................11

■ Kitchen Timer..............................................................................12

■ Time Cooking ..............................................................................12

■ Multistage Cooking.....................................................................13

■ Direct Access Cooking................................................................14

■ Defrost by Weight.......................................................................16

■ Timed Defrost..............................................................................17

■ Defrosting Chart..........................................................................18

■ Cook Meat by Weight.................................................................19

COOKING GUIDE

■ Cooking Principles and Techniques ..........................................20

MAINTENANCE

■ Tr oubleshooting..........................................................................21

■ Questions and Answers .............................................................22

■ Cleaning.......................................................................................22

■ Warranty.................................................................................23-24

ESPAÑOL

■ OPERACION ................................................................................25

■ GARANTÍA .............................................................................38-39

SAFETY

SET UP

OPERATION

COOKING GUIDE

MAINTENANCE

ESPAÑOL

SAFETY

PROPER AND SAFE USE OF YOUR OVEN

• The oven must be on a leveled surface.

• The turntable and turntable roller rest must be in the oven during cooking.

• Place the cookware gently on the turntable and handle it carefully to avoid possible breakage.

• Incorrect use of browning dish may cause the turntable to break.

• Use carefully when cooking food in the microwave oven to avoid burning due to excessive cooking.

•Use only the specified bag size when using Direct Access Popcorn.

• Failure to maintain the oven in a clean condition could lead to deterioration that could adversely affect the life of the appliance and possibly result in a hazardous situation.

• The oven has several built-in safety switches to ensure that the power remains off when the door is open. Do not tamper with these switches.

• Do not operate the microwave oven empty. Operating the oven with no food or food that is extremely low in moisture can cause fire, charring or sparking.

• Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause it to break.

• Do not remove feet from the bottom of the oven.

• Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur and could cause physical injury.

• Do not heat narrow-necked containers, such as syrup bottles.

• Do not attempt to deep-fry in your microwave oven.

• Do not do home canning in this microwave oven as it is impossible to be sure all contents of the jar have reached boiling temperature.

•Do not use this microwave oven for commercial purposes. This microwave oven is made for household use only.

•To prevent eruptive boiling of hot liquids and beverages or scalding yourself, stir liquid before placing the container in the oven and again halfway through cooking time. Let stand in the oven for a short time and stir again before removing the container.

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

WARNING -

To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy:

1. Read all instructions before using the appliance.

2. Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” on page 2.

3. As with most cooking appliances, close supervision is necessary to reduce the risk of a fire in the oven cavity.

If materials inside the oven ignite:

• Keep the oven door closed

•Turn the oven off, and

• Disconnect the power cord or shut off power at the fuse or circuit breaker panel.

Keep in mind the following rules at all times:

a. Do not overcook food. Carefully

attend the appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.

b. Do not use the oven cavity for storage

purposes. Do not store combustible items such as bread, cookies, paper products, etc. inside the oven. If lightning strikes the power line, the oven may turn on by itself.

c. Remove wire twist-ties and metal

handles from paper or plastic containers/bags before placing them in the oven.

4. This oven must be grounded. Connect only to properly grounded outlet. See “GROUNDING INSTRUCTIONS” on page 6.

5. Install or locate this oven only in accordance with the provided installation instructions.

6. Some products such as whole eggs, water with oil or fat, sealed containers and closed glass jars may explode and therefore should not be heated in this oven.

7. Use this appliance only for its intended use as described in the manual. Do not use corrosive chemicals or vapors in this appliance. This oven is specifically designed to heat or cook food. It is not designed for industrial or laboratory use.

8. As with any appliance, close supervision is necessary when used by children.

9. Do not operate this oven if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped.

10. This appliance should be serviced only by qualified service technicians. Contact the nearest authorized service facility for examination, repair or adjustment.

11. Do not cover or block any vents on the oven.

12. Do not store or use this appliance outdoors.

13. Do not use this oven near water, near a kitchen sink, in a wet basement or near a swimming pool, or similar locations.

14. Do not immerse cord or plug in water.

15. Keep cord away from heated surfaces.

16. Do not let cord hang over edge of table or counter.

17. When cleaning door and oven surfaces that meet when door is closed, use only mild, nonabrasive soaps or detergents applied with a sponge or soft cloth. (See “Cleaning” instructions on page 22.)

18. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. This could result in very hot liquids suddenly boiling over when the container is disturbed or a spoon or other utensil is inserted into the liquid.

SAVE THESE INSTRUCTIONS

SAFETY

GROUNDING INSTRUCTIONS

To reduce the risk of injury to persons:

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or service person if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-pronged grounding plug, and a 3-slot receptacle that will accept the plug on the appliance.

•

A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

• Longer cord sets or extension cords may be used if care is exercised in their use.

•If a long cord or extension cord is used:

1) The marked electrical rating of the cord

set or extension cord should be at least as great as the electrical rating of the

appliance.

2) The extension cord must be a

grounding-type 3-wire cord, and

3) The longer cord should be arranged so

that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

UTENSILS

See following page for further instructions “Materials you can use in microwave oven or to be avoided in microwave oven.”

Utensil Test:

1.Fill a microwave-safe container with 1 cup of cold water (250 mL) along with the utensil in question.

Cook on maximum power (PL 10) for 1 minute.

Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.

Do not exceed 1 minute testing time.

CAUTION:

1. Do not use plastic containers for testing.

2. Some containers and dishware may be warm (or hot) in only one area. Do not use a container that becomes warm anywhere.

CAUTION

Personal Injury Hazard

•Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches pierced before cooking.

DANGER

Electric Shock Hazard

•Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard

• Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

Three-pronged (grounding) plug

Properly polarized and grounded outlet

SAFETY

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil

Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5 cm) away from oven walls.

Browning dish

Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5 mm) above the turntable. Incorrect usage may cause the turntable to break.

Dinnerware

Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes.

Glass jars

Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.

Glassware

Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.

Oven cooking bags

Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to escape.

Paper plates and Use for short-term cooking/warming only. Do not leave cups oven unattended while cooking.

Paper towels

Use to cover food for reheating and absorbing fat. Use with supervision for short-term cooking only. Do not use recycled paper towels, they may contain metal and could ignite

Parchment paper

Use as a cover to prevent splattering or a wrap for steaming.

Plastic

Follow the manufacturer’s instructions. Only use items labeled “Microwave Safe”. Some plastic containers soften as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced or vented as directed by package.

Plastic wrap Microwave-safe only. Use to cover food during cooking

to retain moisture. Do not allow plastic wrap to touch food. Thermometers Microwave-safe only (meat and candy thermometers). Wax paper

Use as a cover to prevent splattering and to retain moisture.

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray

May cause arcing. Transfer food into microwave-safe dish. Food carton with

May cause arcing. Transfer food into microwave-safe dish. metal handle

Metal or metal-

Metal shields the food from microwave energy. Metal trim trimmed utensils may cause arcing.

Metal twist ties May cause arcing and could cause a fire in the oven. Paper bags May cause a fire in the oven. Plastic foam cups Plastic foam may melt or contaminate the liquid inside

when exposed to high temperature. Wood

Wood will dry out when used in the microwave oven and

may split or crack.

SET UP

NAMES OF OVEN PARTS AND ACCESSORIES

Remove the oven and all materials from the carton. Your oven comes with the following accessories:

1 Turntable 1 Turntable roller rest 1 Instruction Manual

1. Place the roller rest on the cavi-

ty bottom.

2. Place the turntable on top of the

roller rest as shown in the diagram. Make sure the turntable hub is securely locked in the receptacle.

• Never place the turntable upside down. The turntable should

never be restricted.

• Both turntable and roller rest must always be used during cooking.

• All food and containers of food are always placed on the turntable for cooking.

• If turntable or roller rest cracks or breaks, contact your nearest authorized service center for more information regarding replacement.

TURNTABLE INSTALLATION

Door Safety Locks

Shuts off oven power if door is opened during operation.

Door Handle

• Pull handle gently to open door.

• When you open the door during cooking process, the cooking stops but the program will not be canceled. Touch START to resume cooking.

INSTALLATION

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

NOTE: This unit is not designed for 50 Hz or any circuit other than a 120-volt/ 60-Hz AC circuit. This oven is designed for countertop installation.

Countertop Installation

Select a level surface that provides enough open space for the intake and/or outlet vents.

A minimum clearance of 3 inches is required between the oven and any adjacent wall. One side must be open.

• Leave a minimum clearance of 3 inches above the oven.

• Do not remove the legs from the bottom of the oven.

•

Blocking the intake and/or outlet openings can damage the oven.

• Place the oven as far away from radios and TV’s as possible. Operation of microwave oven may cause interference to your radio or TV.

•

If the cabinet is covered with a protective film, remove the film.

2. Plug your oven into a standard 120-volt / 60-Hz household outlet. Be sure the electrical circuit is at least 15 amperes and that your microwave oven is the only appliance on the circuit.

WARNING:

Do not install oven over a range cooktop or other heat-producing appliance.

If installed near or over a heat source, the oven could be damaged and the warranty would be void.

SET UP

OPERATION

CONTROL PANEL AND FEATURES

(1) DISPLAY WINDOW

Shows cooking time in minutes and seconds during cooking. Shows clock time when oven is not in use.

(2) DIRECT ACCESS KEYPADS

Preprogrammed to cook or reheat popular foods with minimal number of steps.

(3) START/MINUTE PLUS

Press START after entry to start oven. Press START to add a minute while cooking.

(4) POWER LEVEL

Use to set power levels other than 100%.

(5) KITCHEN TIMER

Use as a timer even while a cooking program is in progress.

(6) MULTISTAGE COOKING

Use when programming multiple stage cooking.

(7) COOK MEAT BY WEIGHT

Use to cook beef, lamb, or pork. The time and power level are programmed accordingly when you enter the type and weight of food.

(8) DEFROST BY WEIGHT

Use to defrost large, dense food. The time and power level are programmed accordingly when you enter the weight of the food.

(9) TIMED DEFROST

Use to defrost by time. The power level is programmed accordingly when you enter the defrosting time.

(10) NUMBER keypads

Use to enter time, weight or amount.

(11) CLOCK

Use to set the clock.

(12) STOP/RESET

Press Once: Stops oven. Press Twice: Stops oven and clears all stettings.

OVEN SETTINGS

One Beep: Oven accepts the entry. Two Beeps: Oven does not accept the entry. Check and re-enter.

SETTING CLOCK

To set the correct time of day, follow the steps below.

Example: To set 3:15: Step Procedure Keypad

1 Press CLOCK.

CLOCK

Press 3, 1 and 5 to enter time of day.

3 1 5

You must press at least 3 numbers to set the clock (one for hour and two for minutes).

Press CLOCK.

CLOCK

The clock starts counting.

Note:•

If the clock (or display) shows any abnormality, unplug the oven from the AC outlet. Plug it in again and then reset the clock

• When the oven is first plugged in, or when power resumes after a power interruption, the display will show ENTER CLOCK TIME. To set the clock, follow the instructions above.

• If you would not like the clock displayed, press STOP/RESET. You can use the oven without setting the clock.

CHILD LOCK-OUT

The oven has a safety feature which prevents use by children. The feature locks the operation of the oven until canceled.

To set: Step Procedure Keypad

Press and hold STOP/RESET for

STOP/RESET

3 seconds.

LOCK indicator lights.

To cancel: Step Procedure Keypad

Press and hold

STOP/RESET

for

STOP/RESET

3 seconds. The LOCK indicator turns off.

STOPPING THE OVEN WHILE IN OPERATION

You can stop the oven by pressing STOP/RESET or by opening the door.

2. You can resume cooking by closing the door and pressing START.

OPERATION

KITCHEN TIMER

You can use the Kitchen Timer function independently, even while a cooking program is in progress.

Example: To set timer for 3 minutes: Step Procedure Keypad

Press KITCHEN TIMER. Press 3 0 0 for 3 minutes.

Enter the amount of time that you

want to count down using the number keys. Enter time in minutes and seconds using up to 4 digits.

Press START.

You must press START within 5 seconds after time is entered.

Note:

•

The countdown time can be seen in the display window for 3 seconds before clock or cooking time can be viewed.

•

To cancel kitchen timer, press KITCHEN TIMER and then STOP/RESET.

TIME COOKING

This basic microwave cooking method allows you to cook food for a desired time. The oven can be programmed for 99 minutes 99 seconds. In addition to 100% (maximum) power level, you can select different microwave power from 9 levels, 1-9 (10-90% of total power

level).

KITCHEN TIMER

3 0 0

START

Example: To cook at 80% power level for 20 minutes: Step

Procedure Keypad

Enter a cooking time in minutes and seconds. Enter 20 minutes by pressing 2, 0, 0, and 0.

Press POWER LEVEL then use the number keys to enter the power level. Use a single digit to enter a power level:

Press START.

Note: •

If no power level is entered, the power level will always be 100%.

•

You can add extra minutes while using TIME COOKING. Press START while cooking is in progress to add time in 1 minute increments (maximum 99 minutes). This feature cannot be used with the DIRECT ACCESS programs.

•To check the power level during cooking, press POWER LEVEL.

2 0 0 0

POWER

LEVEL

(80 appears in the display)

START

9 90% 8 80% 7 70% 6 60% 5 50% 4 40% 3 30% 2 20% 1 10%

+ 28 hidden pages
