Sanyo DS25320, DS13330, DS19330 User Manual
AS
Model Nos.:
No. de Modelo:
N
o
de modele:
Printed in U.S.A. SMC, April 2003
Impreso en U.S.A. SMC, Abril 2003
Imprimé aux É.-U. SMC, avril 2003
Part No. / No. de Parte / N
o
de pièce : 1AA6P1P3764 – –
Service Code/Código de Servicio / Code de service : 610 304 4095
Color TV Owner’s Manual
Color TV Manual Del Propietario
Manuel d’instructions du télécouleur
“Read this manual before assembling
(or using) this product.”
Importado Por :
Comercializadora México / Americana, S. DE R.L. DE C.V.
Nextengo N
º
78 / Col. Santa Cruz Acayucan
Del. Azcapotzalco, México D.F. C.P. / 02770, RFC CMA
9109119L0 Telefono: 55-5328-3500
Important Safety Instructions . . . . . . . . . . . . . . .2
Welcome to the World of Sanyo . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Basic Setup and Connections . . . . . . . . . . . . . . .4
Using the Front Audio / Video Input Jacks . . . .5
Connecting a Video Game . . . . . . . . . . . . . . . .5
Connecting a VCR, DVD Player,
orotherexternal equipment . . . . . . . . . . . . . . .5
Using the Remote Control . . . . . . . . . . . . . . . . . .6
TVAdjustment and Setup
How to operate the On-Screen Menu . . . . . . . .7
Adjusting the Picture . . . . . . . . . . . . . . . . . . . . .7
Adding orDeleting a Channel . . . . . . . . . . . . . .8
Closed-Captioning . . . . . . . . . . . . . . . . . . . . . . . .8
V-Guide Information . . . . . . . . . . . . . . . . . . . . . .9
V-Guide Operation (Parental Control) . . . .9 ~ 10
Helpful Hints (problems/solutions) . . . . . . . . . .11
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . .11
Warranty (Mexico) . . . . . . . . . . . . . . . . . . . . . .12
Warranty (U.S.A. and Canada) . . . . . . . . . . . .13
Child Safety Matters . . . . . . . . . . . . . .Back cover
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . .14 ~ 28
Contenido . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . .29 ~ 39
Table des matières . . . . . . . . . . . . . . . . . . . . . . 29
CONTENTS
DS25320
DS19330
TV screen image / Imagen de la Pantalla del televisor
Image de télévision © 2003 PhotoDisc, Inc.
“As an ENERGY STAR
®
Partner, Sanyo Manufacturing Corporation has determined
that this product meets the ENERGY STAR
®
guidelines for energy efficiency.”
DS13330
DS13330
DS19330
DS25320
AS
AS
AS
Positioning the appliance
1. Do not place your appliance on an unstable cart, stand, shelf or table.
Serious injury to an individual, and damage to the appliance, may result
if it should fall. Your salesperson can recommend approved carts and
stands or shelf and wall mounting instructions. An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
2. Slots and openings in the cabinet and in the back or bottom are
provided for ventilation. To ensure reliable operation of the appliance and
to protect it from overheating, these openings must not be blocked or
covered. The openings should never be covered with a cloth or other
material, and the bottom openings should not be blocked by placing the
unit on a bed, sofa, rug, or other similar surface. This appliance should
never be placed near or over a radiator or heat register. This appliance
should not be placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
3. Do not expose the appliance to rain or use near water . . . for example,
near a bathtub, swimming pool, kitchen sink, in a wet basement, etc.
Hooking Up Outdoor Antenna
LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER
NATIONAL ELECTRICAL CODE INSTRUCTIONS.
4. If an outside antenna is connected to the receiver, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built up static charges. Article 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead in
wire to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna
system extreme care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
Plug in the power cord
5. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power
company. This product is equipped with a polarized alternating current
line plug (a plug having one blade wider than the other). This plug will fit
into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of this polarized plug.
Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
6. Power-supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
Cleaning
7. Before cleaning, unplug the unit from the wall outlet. Do not apply liquid cleaners or aerosol cleaners directly to the unit. Use a dry cloth for cleaning.
Service & Repair
8. Unplug the appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. If the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the appliance.
C. If the appliance has been exposed to rain or water.
D. If the appliance has been dropped or the cabinet has been damaged.
E. If the appliance exhibits a distinct change in performance.
F. If the appliance does not operate normally by following the operating
instructions, adjust only those controls that are covered in the
operating instructions. Improper adjustment of other controls may
result in damage and will often require extensive work by a qualified
technician to restore the appliance to normal operation.
9. Upon completion of any service or repair, request the service technician’s assurance that only Factory Authorized Replacement Parts that
have the same characteristics as the original parts were used, and that
routine safety checks have been performed to determine that the
appliance is in safe operating condition. Unauthorized substitutions may
result in fire, electrical shock, or other hazards.
10. Never add accessories that have not been specifically designed for use
with this appliance as they may cause hazards.
11. For added protection during a lightning storm, or when the set is left
unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna. This will prevent damage to the set
due to lightning or power line surges.
12. Never push objects of any kind into this product through openings as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the
product.
EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATIONAL
ELECTRICAL CODE, ANSI/NFPA 70
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING
A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING
AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THIS UNIT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS. BEFORE
OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS. RETAIN THIS
LITERATURE FOR REFERENCE. Follow all instructions...
“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40
of the NEC that provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.”
NEC
- NATIONAL ELECTRICAL CODE
ANTENNA
LEAD IN
WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
2
◆ Trilingual On-Screen Menu
◆ Automatic Channel Search
◆ Auto Shut Off
◆ Closed-Captioning/Quikcap
◆ Digital picture controls
with on-screen display
◆ Auto Flesh Tone
◆ Automatic picture adjustments
◆ V-Guide (Parental Control)
◆ Front Audio/Video Input Jacks
◆ Game Mode
◆ Sleep Timer (3 hours)
◆ TV Reset
◆ 181 Channel Tuning System
VHF Channels 2-13
UHF Channels 14-69
Cable TV (CATV) 1, 14-125
◆ Automatic Fine Tuning
VHF and Cable Channels
◆ 24-key Remote Control
0~9 Numbered Channel Selection
Channel Scanning
Volume Mute
Power Recall
Display Sleep
Caption Reset
Menu V-Guide
Input
PICTURE TUBE SIZE
(Measured Diagonally)
DS13330 . . . . . . . . . . . . . . . . 13-inches
DS19330 . . . . . . . . . . . . . . . . 19-inches
DS25320 . . . . . . . . . . . . . . . . 25-inches
PICTURE RESOLUTION . . . . . 260 Lines
Video Input for . . . . . . . . . . . . . 350 Li ne s
ANTENNA INPUT . . UHF/VHF/CATV 75Ω
POWER REQUIREMENT . . 120VAC 60Hz
POWER
DS13330 . . . . . . . . . . . . . . . . . . . 45 watts
DS19330 . . . . . . . . . . . . . . . . . . . 58 watts
DS25320 . . . . . . . . . . . . . . . . . . . 78 watts
HORIZONTAL DIM. (Width)
DS13330 . . . . . . . . . . . . 14.0 in. (356mm)
DS19330 . . . . . . . . . . . . 19.2 in. (488mm)
DS25320 . . . . . . . . . . . . 24.4 in. (619mm)
VERTICAL DIM. (Height)
DS13330 . . . . . . . . . . . . 12.9 in. (327mm)
DS19330 . . . . . . . . . . . . 17.2 in. (438mm)
DS25320 . . . . . . . . . . . . 22.4 in. (570mm)
DEPTH DIM. (Thickness)
DS13330 . . . . . . . . . . . . 14.6 in. (372mm)
DS19330 . . . . . . . . . . . . 18.5 in. (470mm)
DS25320 . . . . . . . . . . . . 20.4 in. (517mm)
WEIGHT (Approx.)
DS13330 . . . . . . . . . . . 18.7 lbs. (8.5 Kg.)
DS19330 . . . . . . . . . . 35.2 lbs. (16.0 Kg.)
DS25320 . . . . . . . . . . 59.5 lbs. (27.0 Kg.)
SOUND (1 Speaker) . . . . . . . . Size: 8 cm
AMPLIFIER . . . . . . . . . Built-in with 1W/ch
FRONT A/V INPUT JACKS . . . Video/Audio
CAUTION: FCC Regulations state that improper modifications or unauthorized changes to this unit may void the
user’s authority to operate the unit.
FEATURES
SPECIFICATIONS
3
Welcome to the World of Sanyo
Thank you for purchasing a Sanyo Color Television. You made an excellent choice for Performance, Styling,
Reliability, and Value. The TV is designed with easy to use on-screen set-up instructions and operating features.
Need assistance? Visit our Web site at www.sanyoctv.com or call toll free 1-800-877-5032.
BASIC SET-UP & CONNECTIONS
4
QuickTips
■
The TV will automatically select the correct
Antenna mode for the
type of signal you
connect.
■
TV will switch off
automatically after 15
minutes if there is no
signal reception (cable
out or station not
broadcasting).
Exception—When the
Video mode is selected,
the TV will not automatically switch off when
signal reception has
stopped for 15 minutes.
■
See page 6 for Remote
control operation.
■
If you move the TV to a
new location, press the
RESET key twice after
connecting the signal,
and turning on the TV.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
UHF/VHF/CATV
75Ω
IN FROM
SAT.
CATV IN
OUT TO TV
S-VIDEO
CH3
CH4
L- -RAUDIOVIDEO
L- -RAUDIOVIDEO
FROM ANT.
OUT TO TV
IN
OUT
CONNECTING CABLE SERVICE, OUTDOOR OR INDOOR ANTENNA,
OR SATELLITE DISH RECEIVER TO TV
❶
TV Back
❶
❶
Cable
Service
Outdoor
Antenna
Indoor
Antenna
Satellite Receiver
TV Back
❶
POSITIONING THE TV
Do not position the TV in a confined area. Allow space for normal
air circulation around electronic
parts.
CATV FRANCHISE NOTE:
Cable companies, like public
utilities, are franchised by
local government authorities.
To receive cable programs,
even with equipment which
is capable of receiving cable
channels, the consumer
must subscribe to the cable
company’s service.
INITIAL SET-UP
1.
Install batteries in remote control, see page 6.
2.
Connect signal, see below.
3.
Plug in AC power cord.
4.
Press POWER key to turn on TV.
5. Follow on-screen instructions.
VCR Back
Note: If you do not have a
VCR connect signal directly
to TV 75 ohm jack.
AS
5
USING THE FRONT AUDIO/VIDEO INPUT
JACKS
QuickTips
■
Make sure all cable
connectors are fully
seated on jacks.
■
A solid Blue screen
with the word GAME
or VIDEO displayed
means that the
Game/Video mode is
selected, but no signal
is being detected at the
Video jack. Check
connection,
turn on external
equipment.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
CONNECTING A VIDEO GAME
Switch off TV and video game before connecting cables.
❶
Connect game Audio/Video Out jacks to the TV Audio/Video In Jacks.
❷
Press POWER key to turn on the TV. Turn on video game.
❸Press the INPUT key to select program source: TV signal or signal from the video game
connected to the A/V jacks. Press the MENU key
❹and select Game from the on-
screen menu. The TV will automatically change the screen and sound to factory preset
game settings.
ME N UCHCH
VO L
PO W E R
VI DE O IN AU DI O I N
VI DEO IN AUD IO I N
❶
Video Game
Remote Control
TV A/ V Input Jacks
CONNECTING A VCR, DVD PLAYER, OR OTHER EXTERNAL EQUIPMENT TO THE TV
Switch off TV and external equipment before connecting cables. (Cables are not supplied.)
❶
Connect VCR, DVD, or other equipment’s Audio Video Out to the TV Audio Video In jacks.
❷Press POWER to turn on the TV.
Turn on external equipment also.
❸
Press the INPUT key to select the
signal you have connected to the
A/V jacks.
Notes:
– When connecting stereo external
equipment, one connector will not
be used. Just leave extra audio
plug (red) disconnected from
both units.
– Only one device at a time can be
connected to these jacks.
PO W E R
VI DE O IN AU DI O IN
TV A/V Input Jacks
Back of VCR
❸
Remote Control
❷
Back of DVD
❶
Camcorder
Press
INPUT key after
connections.
❷
❸
❹
Press
INPUT key after
connections.
AS
MENU
VOL
POWER
VIDEO IN AUDIO IN
VIDEO IN AUDIO IN
POWER
MENU
CH
VOL
RESETINPUT
RECALL
MUTE
DISPLAY
VOL
POWER
VIDEO IN AUDIO IN
IN
RF
CHANNEL
CH3 CH4
OUT
RL
AUDIO
VIDEO
COMPONENT VIDEO OUT
Y
A/V OUT
A/V JACKS
VIDEO
VIDEO
P
B PR
L- -R
AUDIO
L- -R
AUDIO
POWER
MENU
VOL
MUTE
CH
RECALL
RESETINPUT
VOL
DISPLAY
6
INSTALL BATTERIES AS SHOWN
(2 AAA, not included)
Notes:
– Do not mix old batteries with new ones or mix different
types of batteries together.
– Remove the batteries if the remote control will not
be used for a month or more. Weak batteries may leak
and cause damage. (Normal battery life is roughly six
months.)
USING THE REMOTE CONTROL
QuickTips
■
Be sure batteries are
installed correctly.
■
Point the remote
control toward the TV.
Objects between the
remote control and the
TV may cause misoperation of the remote
control function.
■
The “C” in front of the
number on your screen
indicates a cable
channel.
■
Adjusting the volume
level: Flashing Right
arrow indicates volume
is increasing and
Flashing Left
arrow
indicates volume is
decreasing.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
➀
➁
➂
➃
➀
Input Key—Press to select the
program source to watch: TV signal
or signal from DVD or other equipment you have connected to the A/V
jacks.
➁
Menu Key—Use this key with the
▲/▼ and – /+ keys to navigate and
adjust features of the on-screen menu
system (see pages 7 ~ 8).
➂
Channel Scanning (CH ▲/▼)
and Volume (VOL – /+) Keys
Press to scan through the channels
in memory and to adjust the volume.
➃
Mute Key—Press once to turn down
the volume. Press again to restore
volume to previous level.
➄
Number Keys—Two keys must be
pressed to select a channel. Example:
Press 0 then 6 to select channel 6. For
cable channels 100 through 125, press
and hold the 1 key until C1–– appears.
Then press the other two numbers.
➅
Caption Key (See page 8.)
➆
V - Guide Key (See pages 9 ~ 10.)
➇
Reset Key—Press this key twice to
restore factory settings. The TV will
automatically start Channel Search
and clear all customized settings.
These features will automatically
reset:
•
Picture Adjustments:Color, Sharpness, Bright, Contrast, and Tint
•
Channel Memory
•
Caption to OFF
•
V-Guide to OFF
•
Language to English
•
Sleep Timer (if previously set)
•
Game/Video to TV (if previously
set)
If desired, personal settings can be
made again using the menu options.
➈
Power Key—Press to turn TV on or
off.
➉
Recall Key—Select a channel; select
another channel using the number
keys. Press RECALL to switch
between the channels.
Display Key—Press once to display
the Channel number. Press twice to
display the channel number continuously. Press again to remove the
display.
Sleep Key—Press this key then
press the “0” key to set the Sleep
Timer. The desired time can be set
from 30 minutes up to 3 hours. Sleep
Timer will switch off the TV automatically. Note: The Sleep Timer
cancels when the TV is turned off or
if a power failure occurs.
IMPORTANT NOTE: Spent or discharged batteries must be recycled or disposed of
properly in compliance with all applicable
laws. For detailed information, contact your
local County Solid Waste Authority.
REMOTE CONTROL KEYS
➠
Point towards TV
11
12
➄
➆
➅
➈
➉
➇
11
12
POWER
MENU
VOL
CH
MUTE
2
1
2
1
4
5
4
CAPTION
V-GUIDE
5
789
789
0
0
RESETINPUT
RECALL
VOL
DISPLAY
3
3
6
6
SLEEP
7
TV ADJUSTMENT AND SETUP
The on-screen menu provides the viewer with easy access to adjustments and settings. Just
use the keys on the remote control and follow the on-screen instructions.
HOW TO OPERATE THE
ON-SCREEN MENU
1. Press MENU key.
2. Use the ▲/▼ keys to highlight
the desired feature.
3. Use the – /+ keys to choose desired
option.
4. Press the MENU key to exit.
Items with submenus requires additional steps.
ADJUSTING PICTURE
For automatic picture adjustment:
Highlight Auto for normal viewing or Game
for video game setting.
To manually adjust the picture:
1. Highlight Manual.
2. Press the MENU key to access the picture
options.
3. Use the ▲ / ▼ keys to choose the item you want
to adjust: Color, Tint, Contrast, Bright and
Sharpness.
4. Use the – /+ keys to adjust.
5. Use the ▲ / ▼ keys to select another option or
press MENU key to exit.
For automatic game settings:
Choose Game option. The screen and sound will
automatically change to factory preset settings.
Note: Select the front A/V input jacks by pressing
the INPUT key on the remote control.
RESETTING THE CABLE/ANTENNA MODE OR CHANNEL SEARCH
Resetting the Cable–VHF/UHF Mode or CH. (Channel)
Search is required only if additional channels become
available, such as moving to another city or having a
cable service installed.
1. Choose Start from the Ch. Search menu options.
CH. Scan Memory +
ENGL FRAN ESPA
CH. Search +
Auto Manual Game
Cable VHF/UHF
CH. Search +
CH. Scan Memory +
ENGL FRAN ESPA
Use – +, ▲▼ keys
>>>>>
>
AAAAuuuuttttoo
oo Manual Game
>
>
CCCCoooolllloooorr
rr
Auto MMAANNUUAALL Game
>
>
Searching C34
Use – +, ▲▼ keys
❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙❙----------------------
--
QuickTips
■
Always follow onscreen instructions .
■
The menu will display
on the screen for
approximately 20
seconds. Press
MENU
again to redisplay.
■
All TV adjustments
are controlled through
the menu.
■
Press the RESET key
twice to clear all settings. The TV will
automatically start
Channel Search and
clear all customized
settings.
■
Use the CHANNEL
▲ / ▼ keys and
the
VOLUME – /+
keys to navigate
through the menus
and to make selections from the menus.
■
When setting the
Antenna mode,
choose Cable if your
TV is connected to
a cable system,
otherwise choose
VHF/UHF.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
Auto Manual GGGGaaaammmmeeee
>
>
➥
ADDING OR DELETING CHANNELS
1. Press MENU key.
2. Use the ▲/▼ keys to highlight CH. Scan Memory +.
3. Press the + key.
4. Enter the channel number you want to add or delete (example): C34. For cable channels
above 99, press and hold the 1 key until C1– – appears. Then enter the other two numbers.
5. Press the
+ key to change the present setting.
Example: Added will change to Deleted. This
takes about three seconds. During that time, the
word “Added” or “Deleted” will become
yellow.
6. Use the 0~9 or ▲▼ keys to choose other
channels to delete or add, or press the
MENU key to exit.
8
ENGL FRAN ESPA
CH. Scan Memory +
UUUUsssseeee ▲▲▲▲▼▼▼▼,,,, 0000~~~~9999,,,, ++++ kkkkeeeeyyyyss
ss
Deleted C34
C1: This is the main mode used for program captioning (words match the program you are
watching). These captions are generally one or two lines.
C2: This is an alternative mode for program captioning. Caption2 may be
used by the broadcaster to provide captions in another language, such as,
Spanish or French.
T1: This mode is used to display large amounts of text. This text will
appear within a black box that may be nearly as large as the TV screen.
Text displayed in this manner does not generally relate to the program.
These captions may be used by broadcasters to provide weather reports,
community bulletins, etc.
T2: This is an alternative mode used to display large amounts of text
same as (T1) Text1.
Quikcap: Quikcap allows captions to toggle on and off with the Mute
function. Press the MUTE key on the remote control to block the TV
sound; the captions display automatically. Press the MUTE key again to restore the sound, the
captions will disappear. Quikcap displays program captions in the Caption1 mode.
SETTING CAPTIONS
1.Press the CAPTION key on the remote control.
2.Press the 0 key to select options: OFF, C1, C2, T1, T2, or QUIKCAP.
Caption: C1/ C2
Text: T1/ Text2
CLOSED-CAPTIONING
Captioning is text information transmitted along with the picture and sound so it can be displayed on the TV screen. Because different types of captions can be transmitted with the TV
signal, separate captioning modes are provided. The captioning modes recognized by this
model are: C1 (Caption1), C2 (Caption2), T1 (Text1), and T2 (Text2). Local broadcasters
decide which caption signals to transmit.
QuickTips
■
Channels deleted from
scan memory can be
selected with the
number keys.
■
Restoring deleted
channels, use the
on-screen menu to
manually add channels
or start CH. (Channel)
Search from the menu.
It may take a few
minutes to search thru
the available channels.
OR
■
Press the RESET
key twice.
■
If Caption Text mode is
selected and NO
captioned text is broadcasted, a black box
may appear and
remain on the TV
screen as shown
below.
To remove this black
box, set captioning to
any mode other than
Text1 or Text2 or press
the RESET key to
cancel captioning and
other customized
settings.
■
Channel number will
not display continuously when captioning
is on.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
TWO OUTS AND TWO STRIKES
TONIGHT: BECOMING MOSTLY
CLOUDY WITH A 40 PERCENT
CHANCE OF RAIN. COLD WITH
A LOW IN THE UPPER 30's WEST
WIND AROUND 20 MPH, SHIFTING TO NORTHWEST AROUND
MIDNIGHT. FRIDAY: MOSTLY
CLOUDY AND COLDER WITH
A 50 PERCENT CHANCE OF
RAIN. HIGH IN THE MID 50's.
9
ABOUT MPAA AND TV PARENTAL GUIDELINES
MPAA and TV Parental Guidelines are rating systems that provide advance cautionary
information to parents about the content of movie and television programming.
The V-Guide system contain both age-based and content-based settings. This gives parents
discretionary ways of choosing appropriate material for their children to view.
Content ratings are represented by the initials D (Suggestive Dialog), L (Adult Language),
S (Sexual Situations), V (Violence), and FV (Fantasy Violence). When programming contains
any or all of these conditions, these letters become part of the icon that is displayed on the TV
screen.
A rating icon will generally appear in the upper left hand corner of the TV
screen for about fifteen seconds at the beginning of a program and should be
repeated at the beginning of the second hour of a long program. It may also
appear when returning from commercials. There may be other instances when
these icons will be displayed as well. Parents are encouraged to become familiar with these
icons and their meanings.
V-GUIDE (PARENTAL CONTROL) INFORMATION
NOTE: THIS FEATURE IS DESIGNED TO COMPLY WITH THE UNITED STATES OF
AMERICA’S FCC V-CHIP REGULATIONS. THEREFORE, IT MAY NOT
FUNCTION WITH BROADCASTS THAT ORIGINATE IN OTHER COUNTRIES.
This Sanyo television is equipped with an electronic V-Chip to interpret MPAA and TV
Parental Guidelines rating codes. When these codes are detected, the TV will automatically
display or block the program, depending upon choices you make when setting up the V-Guide
system.
QuickTips
■
Use the CHANNEL
▲ / ▼ keys
and the VOLUME
– /+ keys to
navigate through
the menus and to make
selections
from the menus.
■
V-Guide feature is
accessible only from
the remote control.
■
The TV guidelines
rating icon will
appear generally in the
upper left hand cor ner
of your TV screen
.
■
The V-Guide display
remains on screen for
approximately 20
seconds. If it
disappears, press
the V-GUIDE ke y.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
V-GUIDE OPERATION
Use this feature to supervise television viewing for young children. This television can be set to
automatically block programs with content you deem as inappropriate for your children to view,
including: suggestive dialog, adult language, sexual situations, violence, and fantasy violence.
The ability of the television to block the reception of specific programming content depends
upon several conditions: 1) The program must be rated, 2) Networks must broadcast the rating
code data, 3) Cable companies must transmit the rating code signal, and 4) The TV must be
properly setup to decode the signal.
(Continued on page 10.)
10
SETTING MPAA MOVIE RATING
1. Press the V-GUIDE key on the remote
control to display menu.
2. Press the + key to switch V-Guide ON.
3. Use the ▲ / ▼ keys to select MPAA Rating,
if necessary.
4. Press the + key to select rating options:
X, NC17, R, PG13, PG, or G.
5. Press the MENU key to Block (B) or
Unblock (U) selected rating. For
example, X U.
SETTING TV RATINGS
6 Use the ▲ / ▼ keys to highlight TV Ratings.
7. Press the + key to select rating options:
TVMA, TV14, TVPG, TV-G, TVY7,
TV-Y, or Contents
8. Press the MENU key to Block (B) or
Unblock (U) selected rating. For
example, TVMA U.
SETTING CONTENT-BASED
GUIDELINES
9. Use the – /+ keys to select Contents.
10. Press the MENU key to display the Contents
options: D, L, S, V, or FV. (D-Suggestive
Dialog, L-Adult Language, S-Sexual Situation,
V-Violence, FV-Fantasy Violence)
11. Use the ▲ / ▼ keys to select desired option:
D, L, S, V, or FV.
12. Use the – /+ keys to set rating.
For example, D : TV14 U.
13. Press the MENU key to Block (B) selected
rating.
14. Use the ▲ / ▼ keys to highlight another content
rating. Repeat steps 11 through 13 to block or
unblock rating.
15. Press the V-GUIDE key to exit.
TURNING OFF THE V-GUIDE
1. Press the V-GUIDE key.
2. Use the – /+ keys to select OFF.
Note:Networks and local stations may or
may not include the content ratings
portion of the TV Parental Guidelines.
QuickTips
■
When in the V-Guide
menu system, the
– /+ keys allows you
to navigate between
the ratings and the
options menu.
■
The TV will automatically block (B) ratings
above or unblock (U)
ratings below selection.
For example, if you
block rating R, NC17
and X will be blocked
as well.
■
Blocking TVY7 does not
block higher ratings.
■
You can block a content
rating such as TVPG-V
and still be able to
watch TVPG programs
with ratings of S-L-D
provided TVPG is
unblocked (U).
■
To temporarily unblock
or view Blocked (B)
programs , set
V-GUIDE to OFF, or
press the RESET key
twice to clear all
Blocked (B) ratings
and other customized
settings.
Need help?
Visit our Web site at
www.sanyoctv.com
or Call 1-800-877-5032
MPAA Ratings :
TV Ratings :
Use – +, ▲▼ keys
MENU key to Block
X U
OFFOOOONNNN
>
>
OFFOOOONNNN
>
>
MPAA Ratings :
TV Ratings :
X B
MPAA Ratings :
TV Ratings :
Use – +, ▲▼ keys
MENU key to Block
TVMA U
OFFOOOONNNN
>
>
MPAA Ratings :
TV Ratings :
TVMA B
OFFOOOONNNN
>
>
MPAA Ratings:
TV Ratings :
Contents
OFFOOOONNNN
>
>
L:
S:
V:
FV :
D:
TV14 B
Use – +, ▲▼ keys
MENU key to Block
Press MENU key
11
HELPFUL HINTS (Problems/Solutions)
Before calling for assistance, please check the condition that most closely resembles your problem in the
following chart, then try the solutions for that condition. Visit our Web site at
www.sanyoctv.com
or call toll free 1-800-877-5032.
●
Press POWER key.
●
Sleep Timer may have been set.
●
Unplug TV for a few seconds.
●
Adjust antenna.
●
Try a different channel.
●
Select Auto from the on-screen menu
or press RESET key.
●
Turn off Mixer, Drill, Blender, etc.
●
Press RESET key.
●
Switch OFF Captions (see page 8).
●
Try a different channel.
●
Adjust antenna.
●
Select Auto from Picture on-screen
menu or press RESET key.
●
Try a different channel.
●
Adjust Volume.
●
Select Cable from on-screen menu; then
start CH. (channel) Search using Menu.
●
Select VHF/UHF from on-screen menu;
then start CH. (channel) Search using
menu.
●
Select CH. Scan Memory and manually
add channels or start channel search.
●
Press RESET key to clear setting.
●
Set V-Guide to OFF or press the
RESET key.
●
Select Caption1 or Caption2
(see page 8).
●
Reselect your menu language choice
using the on-screen menu.
●
Replace batteries.
●
Aim remote control at front of TV.
TV turns off by itself.
No picture, poor picture, or
wavy lines in picture.
Black box
on screen.
Poor color or no color.
No sound, poor sound.
No Cable channels
above number 13.
No UHF channels,
VHF OK.
Cannot select or scan
some channels.
No Captioning.
Menu System words seem
misspelled.
Remote Control will
not work.
Cabinet makes popping
sound.
●
Check signal (Cable/Ant.) connection.
●
Power surge protection feature.
●
Check antenna connections.
●
May be station trouble.
●
Brightness or Contrast misadjusted.
●
Possible interference from household
appliance.
●
TV station is broadcasting a Caption
text signal without any textual data.
●
Check if program is in color.
●
Check antenna connections.
●
Color or Tint misadjusted.
●
May be station trouble.
●
May be station trouble.
●
May be MUTE function.
●
Cable Channel Indicator C should
appear next to channel number.
●
Cable Channel Indicator C should not
appear next to channel number.
●
Channel may be removed from
memory.
●
Check antenna connections.
●
V-Guide is set to block programming.
(See pages 9 ~ 10.)
●
Tune to a station that is broadcasting a
Closed-Caption signal.
●
Maybe a foreign language is
selected.
●
Check batteries.
●
Check if TV set is plugged in.
Problem: Check these Conditions: Try these Solutions:
●
This is a normal condition during warm-up and cool down of
the plastic cabinet parts.
CARE AND CLEANING
The surface of the cabinet can be damaged if not properly maintained. Many common household aerosol
sprays, cleaning agents, solvents, and polishes will cause permanent damage to the fine surface.
1. Unplug the power cord before cleaning the television.
2. Clean the screen and cabinet with a soft dry cloth.
Note: Never spray liquids on the screen because it can run down and drip onto the chassis.
This may cause component failure not covered under Warranty.
12
MEXICO GUARANTEE
IMPORTADOR:
COMERCIALIZADORA MEXICO
AMERICANA, S.DE R.L. DE C.V.
A V. NEXTENGO N
o
78
COL. SANTA CRUZ ACAYUCAN
DEL. AZCAPOTZALCO, MÉXICO, D.F. C.P. 02770
RFC: CMA9109119L0
GUARANTEE
THE APPARATUS THAT YOU HAVE ACQUIRED HAS AONE YEAR GUARANTEE FOR MANUFACTURING DEFECTS AND
A ONE YEAR SERVICE WARRANTY FROM THE DATE OF PURCHASE GRANTED BY:
COMERCIALIZADORA MEXICO-AMERICANA, S. DE R.L. DE C.V.
UNDER THE FOLLOWING CONDITIONS:
1. TO MAKE THE GUARANTEE EFFECTIVE, SIMPLY SHOW THIS POLICYFILLED OUTBY THE STORE OR SUPPLIER
UNIT OR THIS SALES INVOICE, WITH THE APPARATUS IN ANY OF THE SERVICE CENTERS INDICATED ON THIS
GUARANTEE.
2. IF THE FAULT IS ATTRIBUTED TO AMANUFACTURING DEFECT, THE APPARATUS WILLBE REPLACED OR YOUR
MONEY REFUNDED. DURING THE 30 DAYS SUBSEQUENTTO THE PURCHASE THE GUARANTEE WILLBE VALID
ATTHE STORE WERE THE APPARATUS WAS PURCHASED, PRESENTING THE ABOVE DOCUMENTS.
3. REPAIR TIME WILL NEVER BE MORE THAN 30 DAYS. IF THIS TIME HAS ELAPSED, AND THE PRODUCT ISN’T
REPAIRED, COMERCIALIZADORA MEXICO AMERICANA, S. DE R.L. DE C.V. WILL PROCEED TO EFFECTUATE
THE EXCHANGE FOR AN EQUIVALENT APPARATUS OR THE RETURN OF THE BUYING-SALE COST
RESPECTIVELY.
4. THIS GUARANTEE WILL COVER ITS TOTALITY OF PIECES, COMPONENTS AND SERVICE REPAIR OF PRODUCT,
AND THE RESPECTIVE COST OF TRANSPORTATION.
THIS GUARANTEE WILL
BE NULL AND VOID IN THE FOLLOWING CIRCUMSTANCES:
*
WHEN PRODUCT HAS BEEN USED IN A DIFFERENT CONDITION THAN ITS NORMAL USE.
*
WHEN PRODUCT HASN’T BEEN OPERATING CORRECTLY ACCORDING TO THE INSTRUCTIONS IN THIS MANUAL.
*
WHEN PRODUCT HAS BEEN CHANGED OR REPAIRED BY PERSONS NOT AUTHORIZED FROM THE
MANUFACTURER, IMPORTER, OR MERCHANT RESPONSIBLE RESPECTIVE.
CENTRO DE SERVICIO Y LUGAR DONDE OBTENER PARTES,
COMPONENTES, CONSUMIBLES Y ACCESORIOS:
SUCURSAL VALLEJO SUCURSAL MINERVA
Poniente 126 N
o
288 B Silos No135, Col. Minerva
Col. Nueva Vallejo Deleg. Iztapalapa
México, D.F. México, D.F. 09810
Tels. 5567-5378 Tels. 5646-4551
5368-0105, 8589-8033 5646-4550
DESCRIPTION: ________________________________ BRAND: __________________ MODEL:__________________
CLIENT’S NAME: __________________________________________________________________________________
ADDRESS: ______________________________________________________________________________________
EXTERIOR NUMBER: _______________________ INTERIOR NUMBER: _______________________
SUB DIVISION: ____________________________________________ STATE/DELEGATION: _______________________
TELEPHONE: _____________________________________________
STAMP, DATE AND SIGNATURE
OF
STORE
DESCRIPTION: Television
BRAND: SANYO
MODELS: DS13330
DS19330
DS25320
Loading...
