Sanyo DS25204, DS19204 User Manual

AS

Model Nos. :

Color TV Owner’s Manual

DS13204
DS19204
DS25204

* “As an ENERGY STAR

®

Partner, Sanyo Manufacturing Corporation has determined

that this product meets the ENERGY STAR®guidelines for energy efficiency.”

POSITIONING THE TV

Do not position the TV in a confined area. Allow space for normal
air circulation around electronic parts.

CHILD SAFETY

Sanyo is committed to making home entertainment safe
and enjoyable. Always use an appropriate table or stand
when positioning your TV. Use appropriate brackets,
braces, or straps to anchor your furniture in place. But

NEVER screw anything directly to the television.

Do not place televisions on dressers, shelves, desks,

carts, etc. where curious or excited children could pull,
push, or otherwise cause the unit to fall and cause
personal injury.

Never place toys or other items on top of the TV that
could pique children’s curiosity causing them to climb
about the furniture.

Always use stands that are designed to support the size
and combined weight of your television and other
electronic devices.

IMPORTANT NOTE:
Spent or discharged bat­teries must be recycled or
disposed of properly in
compliance with all appli­cable laws. For detailed
information, contact your
local County Solid Waste
Authority.

BASIC SETUP AND CONNECTIONS

1.

Install batteries in remote control (2 AAA, not included).

2.

Connect signal. (See illustration below.)

3.

Plug in AC power cord.

4.

Press the POWER key to turn on TV.

5. Follow on-screen instructions.



TV



Cable
Service

Outdoor
Antenna

Indoor
Antenna

Satellite
Receiver

TV



VCR

CATV FRANCHISE NOTE:

Cable companies, like
public utilities, are fran­chised by local govern­ment authorities. To
receive cable programs,
even with equipment
which is capable of receiv­ing cable channels, the
consumer must subscribe
to the cable company’s
service.



PICTURE TUBE SIZE (Measured Diagonally)

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-inches

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-inches

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-inches

PICTURE RESOLUTION

Antenna Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260 Lines

Video Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350 Lines

ANTENNA INPUT . . . . . . . . . . . . . UHF/VHF/CATV 75Ω

POWER REQUIREMENT . . . . . . . . . . . . . . . 120VAC 60Hz

POWER

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 watts

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 watts

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 watts

HORIZONTAL DIM. (Width)

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . . 14.0 in. (356mm)

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . . . 19.2 in. (488mm)

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . . . 24.4 in. (619mm)

VERTICAL DIM. (Height)

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . . 12.9 in. (327mm)

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . . . 17.2 in. (438mm)

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . . . 22.4 in. (570mm)

DEPTH DIM. (Thickness)

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . . 14.6 in. (372mm)

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . . . 18.5 in. (470mm)

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . . . 20.4 in. (517mm)

WEIGHT (Approx.)

DS13204 . . . . . . . . . . . . . . . . . . . . . . . . . 18.7 lbs. (8.5 Kg.)

DS19204 . . . . . . . . . . . . . . . . . . . . . . . . 35.2 lbs. (16.0 Kg.)

DS25204 . . . . . . . . . . . . . . . . . . . . . . . . 59.5 lbs. (27.0 Kg.)

SOUND (1 Speaker) . . . . . . . . . . . . . . . . . . . . . Size: 8 cm

AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . Built-in with 1W/ch

FRONT A/V INPUT JACKS . . . . . . . . . . . . . Video/Audio

CAUTION: FCC Regulations state that unauthorized changes or

modifications to this equipment may void the user’s
authority to operate it.

SPECIFICATIONS

Printed in U.S.A. SMC, April 2004

Service Code: 610 312 7484

Par t No. :

1JC6P1P0164A–

Welcome to the World of Sanyo

Thank you for purchasing a Sanyo Color Television. Yo u made an excellent choice for Performance,

Styling, Reliability, andValue. This television is designed with easy to use on-screen set-up instructions and
operating features.

If you need assistance visit our Web site at www.sanyoctv.com or call toll free 1-800-877-5032.

UNITED STATES AND CANADA WARRANTY

ONE-YEAR LIMITED WARRANTY

THIS LIMITED W ARRANTY IS VALID ONLY ON SANYO TELEVISIONS PURCHASED AND
USED IN THE UNITED STATES OF AMERICA, CANADA, AND PUERTO RICO, EXCLUD­ING THE UNITED STA TES’OTHER TERRIT ORIES AND PR O TECT ORATES.THIS LIMITED
WARRANTY APPLIES ONLY TO THE ORIGINAL PURCHASER, AND DOES NOT APPLY
TO PRODUCTS USED FOR INDUSTRIAL OR COMMERCIAL PURPOSES.

FOR ONE YEAR from the date of purchase, Sanyo Manufacturing Corporation will replace
any defective TV.

To insure proper warranty exchange, keep the original sales receipt for evidence of
purchase.Return the defective TV to the retailer along with the receipt and the inc lud­ed accessories, such as the remote control. The defective TV will be exchanged for
the same model, or a replacement model of equal value, if necessary. Replacement
model will be contingent on availability and at the sole discretion of Sanyo
Manufacturing Corporation.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

OBLIGATIONS

For one year from the date of purchase, Sanyo Manufacturing Corporation warrants this
product to be free from defects in material and workmanship under normal use and condi­tions. Should replacement be necessary under this warranty for any reason due to manu­facturing defect or malfunction during the first year from date of original purchase, Sanyo
Manufacturing Corporation will provide a new TV via exchange at the retailer.

For customer assistance, whether during or out of the warranty period, call toll free
1-800-877-5032.

Weekdays 7:30 AM – 7:00 PM Central Time
Saturday 7:30 AM – 4:00 PM Central Time

This warranty expresses specific contractual rights; retail purchasers may have additional
statutory rights which vary from state to state.

(EFFECTIVE: August 1, 2002)

For your protection in the event of theft or loss of this product, please fill in the infor­mation requested below and KEEP IN A SAFE PLACE FOR YOUR OWN PERSONAL
RECORDS.

Model No. ________________________________ Date of Purchase ____________________

Serial No. ________________________________ Purchase Price ______________________

(Located on back of unit)

Where Purchased ____________________

AS

Sanyo Manufacturing Corp.

3333 Sanyo Road, Forrest City, AR 72335

Positioning the appliance

1. Do not place your appliance on an unstable cart, stand, shelf
or table. Serious injury to an individual, and damage to the
appliance, may result if it should fall. Your salesperson can
recommend approved carts and stands or shelf and wall
mounting instructions. An appliance and cart
combination should be moved with care. Quick
stops, excessive force, and uneven surfaces
may cause the appliance and cart combination
to overturn.

2. Slots and openings in the cabinet and in the back or bottom are
provided for ventilation. To ensure reliable operation of the appli­ance and to protect it from overheating, these openings must
not be blocked or covered. The openings should never be cov­ered with a cloth or other material, and the bottom openings
should not be blocked by placing the unit on a bed, sofa, rug, or
other similar surface. This appliance should never be placed
near or over a radiator or heat register. This appliance should not
be placed in a built-in installation such as a bookcase unless
proper ventilation is provided.

3. Do not expose the appliance to rain or use near water . . . for
example, near a bathtub, swimming pool, kitchen sink, in a wet
basement, etc.

Hooking Up Outdoor Antenna

LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER
NATIONAL ELECTRICAL CODE INSTRUCTIONS.

EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATION­AL ELECTRICAL CODE, ANSI/NFPA 70

4. If an outside antenna is connected to the receiver, be sure the

antenna system is grounded so as to provide some protection
against voltage surges and built up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70, provides infor­mation with respect to proper grounding of the mast and sup­porting structure, grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.

An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When
installing an outside antenna system extreme care should be

taken to keep from touching such power lines or circuits as con­tact with them might be fatal.

Plug in the power cord

5. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your product
dealer or local power company. This product is equipped with
a polarized alternating current line plug (a plug having one
blade wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose
of this polarized plug. Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can result in
a risk of fire or electric shock.

6. Power-supply cords should be routed so that they are not like­ly to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, conven­ience receptacles, and the point where they exit from the
product.

Cleaning

7. Before cleaning, unplug the unit from the wall outlet. Do not apply
liquid cleaners or aerosol cleaners directly to the unit. Use a dry
cloth for cleaning.

Service & Repair

8. Unplug the appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

A. If the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the appliance.
C. If the appliance has been exposed to rain or water.
D. If the appliance has been dropped or the cabinet has been

damaged.
E. If the appliance exhibits a distinct change in performance.
F. If the appliance does not operate normally by following the

operating instructions, adjust only those controls that are

covered in the operating instructions. Improper adjust-

ment of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the appliance to normal operation.

9. Upon completion of any service or repair, request the service
technician’s assurance that only Factory Authorized
Replacement Parts that have the same characteristics as the
original parts were used, and that routine safety checks have
been performed to determine that the appliance is in safe
operating condition. Unauthorized substitutions may result in
fire, electrical shock, or other hazards.

10. Never add accessories that have not been specifically designed
for use with this appliance as they may cause hazards.

11. For added protection during a lightning storm, or when the set
is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna. This will pre­vent damage to the set due to lightning or power line surges.

12. Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS VOLT­AGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS
PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPOR­TANT OPERATING AND MAINTENANCE INSTRUCTIONS
IN THE LITERATURE ACCOMPANYING THIS UNIT.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLI­ANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUC­TIONS. BEFORE OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUC­TIONS. RETAIN THIS LITERATURE FOR REFERENCE. Follow all instructions...

“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to
Article 820-40 of the NEC that provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.”

Note: If you do not have a

VCR, connect signal
directly to TV 75 ohm
jack.

ENGLISH

*Model DS25204 only

ENERGY STAR

AS

A

S

V
IDEO

I
N

L-

AU

D
I
O

-R

OUT TO TV

CATV IN

S-VIDEO

L- -RAUDIOVIDEO

L- -RAUDIOVIDEO

IN FROM

SAT.

OUT

CH3
CH4

IN

FROM ANT.

OUT TO TV

UHF/VHF/CATV
75Ω

ANTENNA
LEAD IN
WIRE

GROUND
CLAMP

ELECTRIC
SERVICE

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

EQUIPMENT

NEC

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

- NATIONAL ELECTRICAL CODE

Setting Content-Based Rating

9. Select Contents.

10. Press the MENU key to display the Contents options: D, L, S,

V, or FV. (D-Suggestive Dialog, L-Adult Language, S-Sexual
Situation, V-Violence, FV-Fantasy Violence)

11. Highlight desired option: D, L, S, V, or FV.

12. Use the – /+ keys to select rating.

13. Press the MENU key to change rating (B↔U).

14. Use the  /  keys to highlight another content rating. Repeat

steps 11 through 13 to block or unblock rating.

15. Press the V-GUIDE key to exit.

Turning Off the V-Guide

1. Press the V-GUIDE key.

2. Use the – /+ keys to select OFF.

ON-SCREEN MENU OPERATION

1. Press MENU.

2. Use the  / keys to highlight a feature.

3. Use the – /+ keys to choose an option.

4. Press MENU to exit.

Items with submenus requires additional steps.

Automatic Picture Adjustment

1. Highlight Auto for normal viewing or Game for video game settings.

Note: When you choose Game, the picture and sound will auto adjust to ideal game settings.

Manual Picture Adjustment

1. Highlight Manual.

2. Press MENU.

3. Use the  /  keys to choose Color

,

Tint, Contrast, Bright, or Sharpness.

4. Use the – /+ keys to make adjustment.

Resetting the Cable–VHF/UHF Mode or Channel Search

These changes are required only if additional channels become available, such as switching from Antenna to
Cable.

1. Highlight CH Search and press the + key.

Adding or Deleting Scan Memory Channels

1. Press MENU key.

2. Highlight CH. Scan Memory.

3. Press the + key.

4. Enter the channel number you want to add or delete.

5. Press the + key to change the present setting. Example: Added

will change to Deleted. This takes about three seconds. During that
time, the word “Added” or “Deleted” will become yellow.

6. Use the 0~9 or  keys to choose other channels to delete or add,
or press the MENU key to exit.

V-GUIDE OPERATION

Setting MPAA Movie Rating

1. Press V-GUIDE.

2. Press the + key to switch V-Guide ON.

3. Highlight MPAA Rating, if necessary.

4. Press the + key to select a rating option.

5. Press the MENU key to change rating (B↔U).

Setting TV Ratings

6 Highlight TV Ratings.

7. Press the + key to select rating option.

8. Press the MENU key to change rating (B↔U).

Auto Manual Game

Cable VHF/UHF
CH. Search +
CH. Scan Memory +

ENGL FRAN ESPA

Use –+,  keys

>

>

>>>

>

OFFOOOONNNN

MPAA Ratings : XU

TV Ratings :

Use – +,  keys
MENU key to Block

>

>

OFFOOOONNNN
MPAA Ratings :

TV Ratings : Contents

Press MENU key

>

>

Deleted C34

UUUUsssseeee

,,,,0000~~~~9999,,,,++++ kkkkeeeeyyyyss

ss

This symbol on the nameplate means the product is Listed by Underwriters’ Laboratories
Inc. It is designed and manufactured to meet rigid U.L. safety standards against risk of
fire, casualty and electrical hazards.

OFFOOOONNNN
MPAA Ratings :

TV Ratings : TVMA U

Use – +,  keys
MENU key to Block

>

>

CARE AND CLEANING

1. Unplug the power cord before cleaning the television.

2. Clean the screen and cabinet with a soft dry cloth.

Note: Never spray liquids on the screen because it can run down and drip onto the

chassis. This may cause component failure not covered under Warranty.

D: TV14 B

L:
S:
V:
FV :

Use – +,  keys
MENU key to Block

PO W E R

VI DE O IN AU DI O IN

TV

Camcorder

DVD Player



Press INPUT after
making connections.

Video Game

What you will need

:



AV Cable - 1

Notes:

– Switch off TV and external equipment before connecting cables. (Cables are not supplied with the TV.)
– One audio plug will not be used when connecting a stereo device. Just leave the red audio plug

disconnected from both units.

– Only one device at a time can be connected to these jacks.

USING FRONT A/V JACKS

1. Connect a Video Game, Camcorder, or other external equipment to the TV as shown below.



Input Key—Press to select the program
source to watch: TV signal or signal from
DVD Player or other equipment you have
connected to the A/V jacks.



Menu Key—Use this key with the  /
and – /+ keys to navigate and adjust features
of the on-screen menu system.



Channel Scanning (CH  / ) and
Volume (VOL – /+) Keys—Press to scan

through the channels in memory and to
adjust the volume.



Mute Key—Press once to suppress the vol­ume. Press again to restore volume to pre­vious level.



Caption Key—Captioning is text informa­tion transmitted along with the picture and
sound so it can be displayed on the TV
screen.

1. Press CAPTION.

2. Press 0 (zero) to select options: OFF,

C1, C2, T1, T2, or QUIKCAP.

Notes: Quikcap switches captions on and off

with the Mute function.
If a black box appears on the screen,

press the RESET key twice.



V-Guide Key—(See V-Guide Operation.)

Note: This feature is designed to comply

with the United States of America’s
FCC V-Chip regulations. Therefore,
it may not function with broadcasts

that originate in other countries.
Use this feature to supervise the television
viewing of young children. This TV can be set
to automatically block programs with content
you deem as inappropriate for your children to
view.



Reset Key—Press this key twice to restore
factory settings. The TV will automatically
start Channel Search and clear all cus­tomized settings. These features will auto­matically reset:

•

Picture Adjustments:Color, Sharpness,
Bright, Contrast, and Tint

•

Channel Memory

•

Caption to OFF

•

V-Guide to OFF

•

Language to English

•

Sleep Timer

•

Game/ Video mode to TV

If desired, personal settings can be made
again using the menu options.



Power Key—Press to turn TV ON or OFF.



Recall Key—Press to switch between the
last two channels you selected.



Display Key—Press once to display the
channel number. Press twice to display the
channel number continuously. Press again to
remove the channel number.

Number Keys—Press two keys to select a
channel. Example: Press 0 then 6 to select
channel 6. For cable channels 100 through
125, press and hold the 1 key until C1––
appears. Then press the other two numbers.

Sleep Key—Press this key then press the
“0” key to set the Sleep Timer. The desired
time can be set from 30 minutes up to 3
hours in 30-minute increments. Sleep Timer
will switch off the TV automatically.

Note: The Sleep Timer cancels when the

TV is turned off or if a power failure
occurs.

11

12




















11

12

REMOTE CONTROL OPERATION



Point towards TV

MEXICO GUARANTEE

IMPORTADOR:
COMERCIALIZADORA MEXICO
AMERICANA, S.DE R.L. DE C.V.
AV. NEXTENGO No78
COL. SANTA CRUZ ACAYUCAN
DEL. AZCAPOTZALCO, MÉXICO D.F., C.P. 02770
RFC: CMA9109119L0

GU

ARANTEE

THE APPARATUS THAT YOU HAVE ACQUIRED HAS A ONE YEAR GUARANTEE FOR MANU­FACTURING DEFECTS AND A ONE YEAR SERVICE WARRANTY FROM THE DATE OF PUR­CHASE GRANTED BY:

COMERCIALIZADORA MEXICO-AMERICANA, S. DE R.L. DE C.V.

UNDER THE FOLLOWING CONDITIONS:

1. TO MAKE THE GUARANTEE EFFECTIVE, SIMPLY SHOW THIS POLICY FILLED OUT BY
THE STORE OR SUPPLIER UNIT OR THIS SALES INVOICE, WITH THE APPARATUS IN
ANY OF THE SERVICE CENTERS INDICATED ON THIS GUARANTEE.

2. IF THE FAULT IS ATTRIBUTED TO A MANUFACTURING DEFECT, THE APPARATUS
WILL BE REPLACED OR YOUR MONEY REFUNDED. DURING THE 30 DAYS SUBSE­QUENT TO THE PURCHASE THE GUARANTEE WILL BE VALID AT THE STORE WERE
THE APPARATUS WAS PURCHASED, PRESENTING THE ABOVE DOCUMENTS.

3. REPAIR TIME WILL NEVER BE MORE THAN 30 D AYS.IF THIS TIME HAS ELAPSED, AND
THE PRODUCT ISN’T REPAIRED, COMERCIALIZADORA MEXICO AMERICANA, S. DE
R.L. DE C.V.WILL PROCEED TO EFFECTUATE THE EXCHANGE FOR AN EQUIVALENT
APPARATUS OR THE RETURN OF THE BUYING-SALE COST RESPECTIVELY.

4. THIS GUARANTEE WILL COVER ITS TOTALITY OF PIECES, COMPONENTS AND SER­VICE REPAIR OF PRODUCT, AND THE RESPECTIVE COST OF TRANSPORTATION.

THIS GUARANTEE WILL BE NULL AND VOID IN THE FOLLOWING CIRCUMSTANCES:

*

WHEN PRODUCT HAS BEEN USED IN A DIFFERENT CONDITION THAN ITS NORMAL USE.

*

WHEN PRODUCT HASN’T BEEN OPERATING CORRECTLY ACCORDING TO THE
INSTRUCTIONS IN THIS MANUAL.

*

WHEN PRODUCT HAS BEEN CHANGED OR REPAIRED BY PERSONS NOT AUTHORIZED
FROM THE MANUFACTURER, IMPORTER, OR MERCHANT RESPONSIBLE RESPECTIVE.

CENTRO DE SERVICIO Y LUGAR DONDE OBTENER PARTES,
COMPONENTES, CONSUMIBLES Y ACCESORIOS:

SUCURSAL VALLEJO SUCURSAL MINERVA
Poniente 126 No288 B Silos No135, Col. Miner va
Col. Nueva Vallejo Deleg. Iztapalapa
México, D.F. México, D.F. 09810
Tels. 5567-5378 Tels. 5646-4551
5368-0105, 8589-8033 5646-4550

DESCRIPTION: __________________BRAND: ________________MODEL: ____________

CLIENT’S____________________________________________________________________
ADDRESS: __________________________________________________________________
EXTERIOR NUMBER:______________ INTERIOR NUMBER: ________________________
SUB DIVISION: __________________________STATE/DELEGATION: __________________
TELEPHONE: ____________________

STAMP, DATE AND SIGNATURE

OF

STORE

DESCRIPTION: Television
BRAND: SANYO
MODELS: DS13204

DS19204
DS25204

POWER

MENU

VOL

MUTE

1

1

4

4

789

789

CAPTION

V-GUIDE

CH

RESETINPUT

RECALL

VOL

DISPLAY

3

2

3

2

6

5

6

5

SLEEP

0

0

POWER

VIDEO IN AUDIO IN

RL

AUDIO

VIDEO

A/V OUT

COMPONENT VIDEO OUT

Y

P

B PR

MENU

VOL

MUTE

POWER

CH

RESETINPUT

RECALL

VOL

DISPLAY
