27”* LCD High-definition Colour TV with
ATSC Digital Tuner
AVL-279
* Diagonal measure
Monday to Friday 9am-5pm (Eastern)
Help Line: 1-800-263-224
www.sanyo.ca
Important Information
WARNING:
CAUTION-To reduce the risk of electric shock, do not perform
"Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to
the grounding system of the building, as close to the point of cable entry as practical.”
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
any servicing other than that contained in the
operating instructions unless you are qualified to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be
regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eia.org
FCC STATEMENT
FCC Notice
LCD TV: A CLASS B digital device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly approved by the
manufacturer could cause harmful interference and would void the user's authority to operate this device.
WARNING: This is a CLASS B product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures to counter interference.
1
Important Safety Precautions
Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the
following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your
LCD TV product, please read the following precautions carefully before usiang the product.
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions---All operating instructions must be followed.
5. Do not use this apparatus near water---for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock, or
other hazards.
6. Clean only with dry cloth---Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
7. Ventilation---Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions. The vents and other openings in the cabinet are
designed for ventilation. Do not cover or block these vents and openings since
insufficient ventilation can cause overheating and/or shorten the life of the product.
Do not place the product on a bed, sofa, rug or other similar surface, since they can
block ventilation openings. This product is not designed for built-in installation; do not
place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer’s instructions are followed.
8.Heat sources---Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.Grounding or Polarization---Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not recommended by
the manufacturer. Use of improper attachments can result in accidents.
2
Important Safety Precautions (continued)
12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley,
stand, tripod or table. Placing the product on an unstable base can cause the product to fall,
resulting in serious personal injuries as well as damage to the product. When mounting the
product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting
hardware recommended by the manufacturer.
13. Move Carefully---When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor
surfaces can cause the product to fall from the trolley.
14.Lightning---Unplug this apparatus during lightning storms or when unused for long periods
of time.
For added protection for this television equipment during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna. This will prevent damage to the equipment due to lightning and power-line surges.
15. Servicing---Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
16. Replacement parts---In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
17.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other
equipment as this can result in a risk of fire or electric shock.
18.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltage flows in the
product, and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid
on the product.
19.Damage requiring service---If any of the following conditions occur, unplug the power cord from the AC outlet, and request a
qualified service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not described in
the instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in the
product indicates that the product needs servicing.
20.Safety checks---Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.
21.Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer. This is a safety feature.
3
Important Safety Precautions (continued)
22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your product dealer or local power company. For added protection for this product
during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect
the cable system. This will prevent damage to the product due to lightning and power line surges. When the unit has to be used with
another power supply voltage, the power cable must be changed. Consult your product dealer. The socket outlet should be installed
near the equipment and easily accessible. Use only the power cord designated by our dealer to ensure safety and EMC. When
connecting other products such as VCRs and personal computers, you should turn off the power of the unit for protection against
electric shock.
23.Panel protection---The LCD panel used in this product is made of glass. Therefore, it can
break when the product is dropped or impacted upon by other objects. Be careful not to be
injured by broken glass pieces in case the LCD panel breaks.
24.Pixel defect---The LCD panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active
pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your
product.
< If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with
respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
NEC—NATIONAL ELECTRICAL CO DE
< An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can collide with such power lines or circuits.
When installing an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits, as contact with them might be fatal.
4
Table of Contents
Important Information ..............................................................................................................................1
Important Safeguards...............................................................................................................................2
Table of Contents .....................................................................................................................................5
Introducing the TV ...................................................................................................................................7
Remove the TV from the Box............................................................................................................7
Installing the TV ................................................................................................................................7
Carrying or Moving the TV................................................................................................................7
Attach the Speaker to the Display.....................................................................................................8
Remove the Stand ............................................................................................................................8
TV Controls and Connectors .........................................................................................................9
Font Panel.........................................................................................................................................9
Side Panel.........................................................................................................................................10
Connecting the TV....................................................................................................................................11
Viewing Locked or Blocked Programs ..............................................................................................38
Other Information .....................................................................................................................................39
Thank you for choosing SANYO. This product incorporates latest-generation features including an ATSC digital
tuner. Please read all instructions carefully to obtain maximum benefit of your product. Questions? Our toll-free
number is 1-800-263-2244, 9am-5pm, Monday to Friday (Eastern time).
Remove the TV from
the Box
Installing the TV
STOP! To safely remove the television from the box
It’s best to use 2 people to remove the television for
stability.
1. Removecardboard holders from the box.
2. Remove the cardboard; however, keep the wrapping
on the television to protect it while moving.
3. Lift onto installation location as the diagram illustrates.
= Keep enough space above and behind the Display.
=
The TV should be installed near an easily accessible
power outlet.
=
To prevent internal heat buildup, do not block the
ventilation openings.
Do not install the TV in a hot or humid place, or in a
=
place subject to excessive dust or mechanical
vibration.
=
Be sure to take measures to prevent the TV from
toppling over and causing injury.
= To obtain the best picture, do not expose the screen to direct illumination or
direct sunlight. It is recommended to use spot lighting directed down from the
ceiling or to cover the windows that face the screen with opaque drapery. It is
desirable to install the TV in a room where the floor and walls are not of a
reflective material.
6 inches
(15 cm)
or more
Cautions:
Do not install the TV in protruding locations.
=
Do not install this unit in restaurants where oily vapors occur. Dust absorbing
=
oil may enter into the unit and damage the unit.
Do not install this unit outdoors. If the unit is exposed to rain, it may result in fire
=
or electric shock. If the unit is exposed to direct sunlight, the unit may heat up
and cause damage to the unit.
Do not install this unit in a vehicle or hang from the ceiling. Bumping of the
=
vehicle may cause the unit to fall down and cause injury.
Do not install this unit in a ship or vessel. If the unit is exposed to seawater, it
=
may cause fire or damage the unit.
If you install the unit on a non-level surface, the unit may fall or drop and cause
=
injury or damage.
If you place the unit on an unstable surface, the unit may fall and cause injury or
=
damage.
Do not hang anything on the unit. If you do so, the unit may fall from the stand or
=
wall-mount bracket, causing damage or serious injury.
Carrying or Moving
the TV
7
=
When you move the TV, carry it by two people.
=
When you move the TV, hold the upper and bottom frames of the TV, not the
speaker.
=
As the glass surface of the TV has a special coating, be careful to avoid
touching the glass surface as far as possible.
When transporting, do not subject the unit to shocks or vibration, or excessive
=
force.
Introducing the TV
Attach the Speaker
System to the Display
The appearance of the unit
may differ from the actual
one.
To deattach the speaker,
perform the steps in reverse
order.
If applicable:
Removing the Stand
for Wall-Mounting
Cautions:
1. Carefully handle the unit during setup and consult authorized service
personnel to ensure successful installation.
2. Before performing work spread cushioning over the base area to lay the
Display on. This will prevent it from being damaged.
3. Disconnect the AC power cord firstly.
Screw the Speaker and the Fixed
board to the unit using the supplied
screws and tighten securely, then
install the two Connecting covers as
the diagram illustrates.
Connect only the supplied speaker
audio cables between the speaker
terminals on the unit and the
speaker matching polarity
according to the terminals’ color.
Fixed board
Screws
Connecting cover
Fixed board
Screws
Connecting cover
Cautions:
1. Carefully handle the unit during setup and consult authorized service
personnel to ensure successful installation.
2. Before performing work spread cushioning over the base area to lay the
Display on. This will prevent it from being damaged.
3. Disconnect the AC power cord firstly.
1
Rear cover
Take off the rear cover.
Do not remove the stand and
speaker from the Display unless
using an optional bracket to
mount it.
The appearance of the unit may
differ from the actual one.
To attach the stand, perform the
steps in reverse order.
2
Screws
Stand
Loosen the screws on the
Stand to remove the Stand.
3
Replace the rear cover
8
Introducing the TV
TV Controls and Connectors
Front Panel
1
2
ItemDescription
Power Indicator
1
Remote Sensor
2
CH-/CH+
3
VOL-/VOL+
4
MENU
5
6
POWER
7
INPUT
Receives IR (infrared) signals from the remote control.
Press to scan through channels. In menu operations, these buttons serve as down/up buttons.
Press to adjust the volume. In menu operations, these buttons serve as left/right buttons.
To access the Menu main page.
Turn the unit on or off.
To display the INPUT source list or to quickly select input source.
CH-
CH+
VOL-
VOL+
MENU
INPUT
3
4
5
6
7
9
TV Controls and Connectors
Side Panel
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
RF
COMPONENT
Y
Y
P
P
b
b
P
P
r
r
Introducing the TV
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
( )
PC/DTV INPUT
RS-232
RF
COMPONENT
Y
Y
P
P
b
b
P
P
r
1
2
3
4
5
r
R
R
L
L
12
S- VIDEO
AV
VIDEO
VIDEO
L
L
R
R
2 1
VCR(OUTPUT)
VIDEO
COAXIAL
DIGITAL AUDIO
OUT
( )
USBUPGRADE PORT
R
L
R
L
S- VIDEO
AV
VIDEO
L
R
2 1
ItemDescription
HDMI IN
1
Audio IN for DVI
2
or D-Sub interface
D-Sub IN
3
RS-232 terminal
4
RF IN
5
HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-digital audio/video
interface between this TV and any HDMI-equipped audio/video component, such as a set-top box and
DVD player. HDMI supports enhanced, or high-definition video, plus two-channel digital audio.
Use this audio input when you are using DVI connection or D-Sub connection. A HDMI-to-DVI adapter
is necessary when you are connecting a DVI-equipped device to this TV.
Connects to a PC or other Analog RGB devices such as Video Conferencing or Set-top Boxes.
For service only. The user should not use this terminal.
RF input that connects to your cable system or outdoor antenna.
VIDEO
6
R
L
12
7
L
R
8
9
10
11
12
TV Left Side
VCR(OUTPUT)
VIDEO
COAXIAL
DIGITAL AUDIO
OUT
USB UPGRADE PORT
R
L
()
Componet Video
6
S-VIDEO input
7
Composite Video
8
Headphones jack
9
Video/Audio OUT
10
Coaxial Digital
11
Audio OUT
12
USB Port
Connect to your DVD player’s or digital set-top box’s component video (YPbPr) and audio (L/R) jacks.
Component video provides better picture quality than the S-VIDEO or the composite video connections.
Connects to the S-VIDEO output jack of your VCR or other video equipment that has S-VIDEO.
S VIDEO provides better picture quality than the composite video connection.
Connect to the composite video and audio output jacks on your VCR or other video device.
Connects to your headphones. If your headphones do not match the jack, use a suitable plug
Connects to your headphones. If your headphones do not match the jack, use a suitable plug
adaptor (not supplied).
Connects to your VCR to record programs as desired or connects to hook up a second TV or monitor.
Only analog TV programs, AV1and AV2 input sources can be output through the AV output jacks.
Connects to the digital audio input of a digital audio component.
For service only. The user should not use this port.
10
Connecting the TV
Basic Connections
Overview
Connecting Antenna
System
To display clear crisp pictures, you must connect your TV correctly and choose
the correct display format. It is strongly recommended to connect the cable and
antenna input using a 75-ohm coaxial cable to receive optimum picture quality
signal. A 300-ohm twin lead cable can be easily affected by radio noise and the
like, resulting in signal deterioration. If you use a 300-ohm twin lead cable, keep it
as far away as possible from the TV.
The way in which you connect your TV will vary, depending on how your home
receives a signal (antenna and satellite; cable and cable box).
Do not use an indoor antenna, which is especially susceptible to radio noise.
Disconnect all power sources before making any connections.
For best results, use this connection if you have an antenna system.
Antenna cable
Connecting Cable
System
Be sure to choose [Antenna] before you start Auto Program. See chapter
Be sure to choose [Antenna] before you start Auto Program. See chapter
[Getting Started] for details.
For best results, use this connection if you have a cable system.
CATV cable
Be sure to choose [Cable] before you start Auto Program. See chapter
[Getting Started] for details.
11
Basic Connections
Connecting the TV
Connecting Cable Box
(Basic)
Use this connection if you have a cable system and your cable company
scrambles some channels, such as premium channels or all channels (which
requires you to use a cable box).
Connect the CATV cable to the cable box’s input jack. Then use a coaxial
cable to connect the cable box’s output jack to the TV’s RF input jack.
If the cable box has audio/video or S-Video jacks, connect your TV to them for
better picture quality and stereo sound.
Note: Sound will be in mono only from the RF output jack of most cable
CATV cable Coaxial Cable
OUT
IN
Cable box
Be sure to choose [Cable] before you start Auto Program. See chapter
[Getting Started] for details.
Connecting Digital
Cable Box
(Best)
Connect the RF coaxial cable from the cable wall outlet to the input of the
digital cable box.
Use a component video cable to connect the YPbPr jacks of your digital cable
box to the TV’s component jacks.
Component video connection is necessary to view high-definition digital
broadcasting in 1080i, 720p, 480i and 480p. This TV displays most format
types of picture.
The component jacks do not provide audio, so audio cables must be
connected to provide sound.
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
RF
Y
P
b
P
r
R
L
12
Audio cableRF coaxial cable
Component video cable
Digital Cable Box
S- VIDEO
VIDEO
L
R
2 1
AV
VIDEO
L
R
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
12
Connecting the TV
Basic Connections
Connecting Satellite
Receiver
Connect the satellite antenna cable to the satellite receiver’s SATELLITE IN jack.
Use AV cables to connect the satellite receiver’s AUDIO and S-VIDEO OUT jacks
to the TV’s AUDIO and S-VIDEO IN jacks.
TV Right Side
S-VIDEO
cable
Satellite Receiver
Satellite
antenna
cable
Cables are often color-coded
AV cable
If your is not equipped with S-VIDEO, use a VIDEO cable
satellite receiver
to connectors. Connect red to
(yellow) instead of the S-VIDEO cable.
Connecting Digital
Satellite Receiver
Connect the RF coaxial cable from the satellite dish to the input of the digital
satellite receiver.
Use a component video cable to connect the YPbPr jacks of your digital
satellite receiver to the TV’s component jacks.
Component video connection is necessary to view high-definition digital
broadcasting in 1080i, 720p, 480i and 480p. This TV displays most format
types of picture.
The component Jacks do not provide audio, so audio cables must be
connected to provide sound.
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
RF
Y
P
b
P
r
R
L
12
Audio cableRF coaxial cable
Component video cable
Digital Satellite Receiver
13
S- VIDEO
VIDEO
L
R
2 1
AV
VIDEO
L
R
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
Using External Equipment
Connecting the TV
Introduction
Equipment with HDMI
Connection
You can connect many types of external equipment to your TV, like a DVD player,
VCR, Digital TV tuner, PC, HDMI equipment, game console and camcorder. To
view external source images, select the input source from INPUT on the remote
control unit or on the Display.
Notes and Cautions:
= Disconnect all power sources before making any connections.
= Disconnect all power sources before making any connections.
= Carefully check the terminals for position and type before making any
= Carefully check the terminals for position and type before making any
connections.
connections.
= The packing contents of this TV may not include the cables or adaptors
= The packing contents of this TV may not include the cables or adaptors
mentioned in this chapter.
mentioned in this chapter.
= Refer to your external equipment operation manual carefully before making
= Refer to your external equipment operation manual carefully before making
connections.
connections.
= Loose connectors can result in image or color problems. Make sure that all
= Loose connectors can result in image or color problems. Make sure that all
connectors are securely inserted into their terminals.
connectors are securely inserted into their terminals.
= Refer to your external equipment operation manual for the signal type.
= Refer to your external equipment operation manual for the signal type.
= The illustration of the external equipment may be different depending on your
= The illustration of the external equipment may be different depending on your
model.
For best results, use this connection if your equipment has a High-Definition
Multimedia Interface (HDMI).
Using a HDMI cable, connect the equipment’s HDMI OUT jack to the TV’s HDMI
IN jack.
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
RF
COMPONENT
Y
Y
P
P
b
b
P
P
r
r
R
R
L
L
12
S- VIDEO
AV
VIDEO
VIDEO
L
L
R
R
2 1
Equipment with HDMI output
HDMI cable
The HDMI jack provides both video and audio signals, so it is not necessary to
connect the audio cable.
14
Connecting the TV
Using External Equipment
Equipment with DVI
Connection
If you are connecting equipment with a DVI connector to this TV, you will need to
use an adapter. You can use a commercial HDMI-to-DVI cable or an HDMI
adapter. Both are available at your local electronics store. When you use the
adapter, you will also need to use separate audio cables for sound as DVI
connector is for video signals only .
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
S- VIDEO
AV
VIDEO
VIDEO
L
R
2 1
Audio cable
RF
Y
P
b
P
r
R
L
12
L
R
HDMI-to-DVI cable or adapter
Equipment with DVI output
Equipment with Coaxial
Digital Audio
You can use the TV's Coaxial Digital Audio OUT jack to connect a digital audio
device, such as an audio amplifier.
Use an coaxial audio cable to connect the TV’s Coaxial Digital Audio OUT jack to
the device’s Coaxial Digital Audio IN jack.
VCR(OUTPUT)
VIDEO
R
COAXIAL
DIGITAL AUDIO
L
OUT
()
Coaxial audio cable
USB UPGRADE PORT
TV Left Side
Audio amplifier
LINE
OUT
LINE
L AUDIO R
IN
COAXIAL
AUDIO IN
The Digital Audio OUT jack is available only when a digital TV channel is
received.
15
Using External Equipment
Connecting the TV
Connecting a VCR for
Playing Back
Use AV cables to connect the VCR’s AV output jacks to the TV’s AV input jacks.
If your VCRs have S-VIDEO jacks, for best picture quality, use an S-VIDEO
connection instead of the video cable (yellow) on your combined A/V cable.
Use a S-VIDEO cable to connect the VCR’s S-VIDEO OUT jack to the TV’s SVIDEO IN jack. S-VIDEO does not provide audio, so audio cables must be
connected to provide sound.
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
S- VIDEO
AV
VIDEO
VIDEO
L
R
2 1
RF
Y
P
b
P
r
S-VIDEO
cable
R
L
12
L
R
Cables are often color-coded
Cables are often color-coded
to connectors. Connect red to
to connectors. Connect red to
red, white to white, etc.
S-VIDEO
VCR
AV cable
Connecting a VCR for
Recording
The S-video terminal share the same audio jacks with video2 and has priority
over the video2 jack.
Use AV cables to connect the VCR’s AV input jacks to the TV’s VCR output jacks.
VCR for Recording
VCR(OUTPUT)
VIDEO
S-VIDEO
R
COAXIAL
DIGITAL AUDIO
L
OUT
()
USB UPGRADE PORT
TV Left Side
AV cable
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
Only analog TV programs, AV1and AV2 input sources can be output through
the AV output jacks.
16
Connecting the TV
Using External Equipment
Connecting a DVD
Player with Component
Video Connectors
Use a component video cable to connect the DVD player’s YPbPr jacks to the
TV’s YPbPr jacks.
Use an audio cable to connect the DVD player’s AUDIO OUT jacks to the TV’s
AUDIO IN jacks. Be sure to use the same row of inputs that you used for the video
connection.
Component video cable
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
RF
Y
P
b
P
r
R
L
12
Audio cable
DVD Player
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
S- VIDEO
AV
VIDEO
VIDEO
L
L
R
R
2 1
Connecting a DVD
Player with S-Video
and Audio Connectors
The YPbPr jacks on your DVD player are sometimes labeled YCbCr, or Y, B-Y
and R-Y. If so, connect the cables to like colors.
Use an AV cable to connect the DVD player’s AUDIO OUT jacks to the TV’s
AUDIO IN jacks.
Use a S-VIDEO cable to connect the DVD player’s S-VIDEO OUT jack to the TV’s
S-VIDEO IN jack.
TV Right Side
S-VIDEO
cable
DVD Player
AV cable
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
17
If your DVD player is not equipped with S-VIDEO, use a VIDEO cable (yellow)
instead of the S-VIDEO cable.
Using External Equipment
Connecting the TV
Connecting a PC
If you connect your PC to the TV, you can watch your personal computer’s display
on the TV.
When your PC is connected to the TV with the D-Sub cable and audio cable, you
can view and listen to the PC’s video and audio output on the TV.
TV Right Side
HDMI
INPUT
D -Sub/DVI
AUDIO INPUT
D-Sub INPUT
()
PC/DTV INPUT
RS-232
COMPONENT
Y
P
b
P
r
R
L
S- VIDEO
AV
VIDEO
VIDEO
L
R
2 1
RF
Y
P
b
P
r
R
L
12
L
R
D-Sub cable
(analog RGB)
Audio cable
(stereo mini plugs)
To monitor port
(15-pin D-Sub)
To audio output jack
Connecting a Camcorder
or “PlayStation”
Use an AV cable to connect the camcorder or “PlayStation” AV output jacks to the
TV’s AV input jacks.
Camcorder“PlayStation”
or
TV Right Side
AV cable
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
18
Loading...
+ 44 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
