REPAIR PARTS
LIST
Model
SC9180A
Commercial Upright
Base & Hood - SC9180A
Page 1 of 2Print Preview
6/29/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6755& ModelID...
Page 2 of 2Print Preview
Base & Hood - SC9180A
Ref # Part Description Comments Qty
1 63862 HOOD ASSEMBLY - PACKAGED
2 63863 GUARD, CARRIER & GRPHCS-P
3 77134A-119N ADAPTER - BASE
4 77130 GASKET - ADAPTER
5 77822 TUBE - COOLING
6 63857 BASE ASSEMBLY - PACKAGED
7 63858 BRUSHROLL - CARTONED
8 77118 SOLEPLATE ASSEMBLY
9 54669-6 SCREW PACKAGE
10 78580 GASKET - SOLEPLATE
11 78907 GASKET - SOLEPLATE REAR
12 53238-27 SCREW PKG
13 77129 FELT - SOLEPLATE
14 54943 SPRING PKG-10
15 77411 FRONT AXLE
16 77117-355N FRONT WHEEL W/IN MOLD BUS
17 77116-355N WHEEL - CARRIAGE
18 77114-380N KNOB - HEIGHT ADJUSTMENT
19 53238-11 SCREW PKG (EW312-10T8
20 53201 CLAMPS-PKG 10 (55535-2
21 63860 REAR WHEEL & AXLE ASSEMBL
22 78652 VULCANIZED PAPER - MICROS
23 78290SV RETAINER ASSEMBLY
24 77136 SPRING - HANDLE RELEASE
25 77135-380N HANDLE RELEASE
26 77140 CLAMP - MOTOR
27 53238-27 SCREW PKG
28 59397-7
29 77133 BELT - POLY V
30 63861 BRUSHROLL MOTOR ASSY - CT
31 77132-119N COVER - BRUSHROLL MOTOR
53158 LOCKNUTS-PKG 10 (49175
76995 END CAP
77124 WASHER - FELT
53114 DIST BRG/PKG 6
76994 SHAFT - DISTURBULATOR
76993 PULLEY
76992 TUBE - INNER
76991 TUBE - DISTURBULATOR
63859 BRISTLE STRIPS - PACKAGED
76996 RETAINER - BEARING
53115 TOL RINGS-PKG10
78749 FOAM STRIP
6/29/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6755& ModelID=2151...
Body - SC9180A
Page 1 of 2Print Preview
6/29/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6757& ModelID...
Page 2 of 2Print Preview
Body - SC9180A
Ref # Part Description Comments Qty
1 77281-355N LATCH - TOP COVER
2 77528 SPRING - TOP COVER
3 77273-308N COVER - TOP
4 77844 HINGE PIN - TOP COVER
5 63867 SPRING PACKAGE
6 77282-355N LEVER - BAG IN PLACE
7 77270-355N INLET - BAG
8 77274 GASKET - TOP COVER
9 77271-355N INLET - COVER
10 53238-27 SCREW PKG
11 60160 SCREW PKG 10 (55927 (NLA)
12 77480-355N GRILL - PRE-MOTOR FILTER
13 77883 MEDIA - FILTER
14 77495 CLAMP - PLATE
15 77289 GASKET - FRONT COVER
16 77267-308N COVER - FRONT
17 77290 TUBE - HANDLE
18 63866 UPPER HANDLE ASSEMBLY
19 77292-355N QUICK CORD RELEASE
20 63864 HOSE & WAND ASSY - CARTON
21 77275-355N DIRT TUBE
22 78310 GASKET - DIRT TUBE
23 77125 VALVE ASSEMBLY
24 70051-380N HOSE - CONNECTOR
25 77284-355N ADAPTER - LOWER CORD HOOK
26 77529 SHAFT - CORD HOOK
27 77283-355N LOWER CORD HOOK
28 77266-308N COVER - MOTOR
29 60192-1 WIRE SPLICE 5 (53214-2)
30 46713-5 CABLE TIE (NLA)
31 77285-313N SHROUD - MOTOR
32 77818 GASKET - MOTOR SHROUD
33 77295A GROMMET - SUCTION MOTOR
34 63865 MOTOR ASSEMBLY - CARTONED
35 77288-316N GASKET - MOTOR CAN
36 77287-119N SHROUD - MOTOR COVER
37 78129 GASKET - COVER MOTOR SHRO
38 78261-1 REAR HOUSING ASSEMBLY
39 77141-119N BUSHING - NYLON
40 39252-19 THERMOSTAT & TERMINAL ASS
41 63262 BAG ASSY PACKAGE (A&H SEN
42 77527 JUMPER CORD - UPPER
43 77530 JUMPER WIRE - MOTOR
44 77291-355N COVER - HEPA SHROUD
45 68910-4 HEPA FILTER (WASHABLE)- C
46 77286-355N SHROUD - HEPA
47 78117 VULCANIZED PAPER
48 77816-1 SWITCH - ROCKER
49 77744-355N HANDLE - CARRY REAR
50 78295 SUPPLY CORD ASSEMBLY
51 76224 CORD - EXTENSION
6/29/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6757& ModelID=2151...
Wiring 78573 - SC9180A
Page 1 of 1Print Preview
6/29/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6758& ModelID...
