REPAIR PARTS
LIST
Model
SC883A
Commercial Upright
Base and Hood - TS881A
Page 1 of 2Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6442& ModelID...
Page 2 of 2Print Preview
Base and Hood - TS881A
Ref # Part Description Comments Qty
1 54097-6
2 79412
3 53143 SCREWS-PKG 10 (48868
4 38053-2 KNOB ASY-BLNER (38053-1
5 53228-2 SCREWS/PKG 10 (EW126-8P5Z
6 53160 CABLE CLAMPS/PKG 5
7 53238-13 SCREW PKG (53238-29
8 53238-14 SCREW PKG (53238-17
9 53214-1 WIRE NUTS/PKG 10
10 53102 LOCKWASHERS/PKG. (45943 (NLA)
11 56383-1SV DUCT ASSEMBLY (R)
12 49052-3 TAPE - FOAM
13 54352-15 MOTOR ASSEMBLY - PACKAGED
14 56382-1SV DUCT ASSEMBLY (L)
15 56382-1SV DUCT ASSEMBLY (L)
16 49052-3 TAPE - FOAM
17 30517 GASKET - MOTOR SEAL
18 24834A-3 PEDAL - FOOT (24834A-1
19 53097 SPRINGS-FT PED-PKG5
20 37034 SPRING-ADAPT RETAINER
21 53140 CLAMPS&SCREWS-PKG 6
22 53238-11 SCREW PKG (EW312-10T8
23 54173-1 WIRE ASSY (GROUNDING)
24 53425-29
25 53213-4 NUTS-PKG 10 (EW14-8ZP
26 54177 WIRE & TERMINAL ASSY
27 24964A-1 CAM (RIGHT) (24964A)
28 24965A-1 CAM (LEFT) (24965A
29 53118 RIVETS-PKG 10 (NLA) (NLA)
30 53133 STL WASHERS-PKG (48495 (NLA)
31 36263 COVER - WHEEL
32 53117 HOOD SPRINGS-PKG 10
33 52334 FAN CHAMBER REPL KIT
34 13770-1 COVER - FAN SCROLL(52334)
35 53238-14 SCREW PKG (53238-17
36 13770-1 COVER - FAN SCROLL(52334)
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6442& ModelID=2072...
Furniture Guard and Brush Roll - SC883A
Page 1 of 2Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6444& ModelID...
Page 2 of 2Print Preview
Furniture Guard and Brush Roll - SC883A
Ref # Part Description Comments Qty
1 37234-3 WHEEL & AXLE ASSEMBLY
2 53110 WASHERS-PKG 10 (47585
3 37183 AXLE - REAR
4 53121 PUSH NUTS-PKG 10
5 76334 FURNITURE GUARD ASSEMBLY
6 76369-1 REAR WHEEL OVERMOLD
7 55535-2 Discontinued, use 53201
8 53238-11 SCREW PKG (EW312-10T8
9 53076-2 AXLE SPRINGS-PKG (36407A
10 35859A-1 WHEEL - FRONT
11 35947A AXLE - FRONT
12 30563A BELT-DISTURBULATOR DRIVE
13 53270 DIST ASSY (12") (26060A-1)
14 53158 LOCKNUTS-PKG 10 (49175
15 26059A CAP - COVER
16 26057A CAP - DISTURBULATOR
17 54256 BRG & RET ASSY
18 53184 KLIPRINGS-PKG 10 (49900
19 25937 SHAFT - DISTURBULATOR
20 52282-4 BRISTLE STRIP SE (52282-3
21 13236-3 TUBE - DISTURBUL (13236
22 25922-1 BOTTOM PLATE ASSY
23 46538-4 FOAM TAPE(50")
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6444& ModelID=2072...
Bag - SC883A
Page 1 of 2Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6443& ModelID...
Page 2 of 2Print Preview
Bag - SC883A
Ref # Part Description Comments Qty
1 53469-23 ZIPPER BAG ASSY - PACKAGE
2 77491 DIRT TUBE & OVERMOLD ASSE
3 49461B-5 HARDWARE PKG - COMM UPRIG
4 78091
5 47722 SPRING - BAG(49077)
6 48410 SPRING - GARTER
7 63213 UPR ST DUSTBAG W/A&H PATCH
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6443& ModelID=2072...
Handle - TS881A
Page 1 of 2Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6445& ModelID...
Page 2 of 2Print Preview
Handle - TS881A
Ref # Part Description Comments Qty
1 Label
2 53238-18 SCREW PKG(PKG 10) 53238-25
3 60946 WASHER/PKG.10--( (56815
4 60945 SPRING (PKG.10) SC4570AT
5 28316-355N RETAINER - CORD
6 53197-1 SCREWS-PKG 10 (55372-1
7 76643-355N HOUSING - SWITCH (LH)
8 28073A ROCKER SWITCH
9 76767 UPPER CORD ASSY.
10 60192-1 WIRE SPLICE 5 (53214-2)
11 59741-316N SHIELD-WIRING
12 60947 SCREWS (PKG.10)SC4570AT
13 76644-355N HOUSING - SWITCH (RH)
14 36577A-23 SUPPLY CORD ASSY
15 15774-2SV UPRIGHT HANDLE & GRIP ASS
16 76644-355N HOUSING - SWITCH (RH)
17 76224 CORD - EXTENSION Extension cord not pictured
18 76225-355N CORD LOCK Extension cord lock not pictured
13154B-355N RETAINER - CORD (LOWER)
12637-8 TUBE - HANDLE (LOWER)
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6445& ModelID=2072...
Motor - TS881A
Page 1 of 2Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6446& ModelID...
Page 2 of 2Print Preview
Motor - TS881A
Ref # Part Description Comments Qty
1 54352-15 MOTOR ASSEMBLY - PACKAGED
2 53219-2 SCREWS PKG 10
3 53213-4 NUTS-PKG 10 (EW14-8ZP
4 53222-3 LK WSHRS-PKG10
5 30478 MOTOR BRUSH ASSY
6 53138 SCREWS-PKG 10
7 54396 MOTOR COVER ASSY - LABELE
8 20217E RETAINER - UPPER BEARING
9 53441-2 FIELD ASSY
10 56802-2 Discontinued, use 46713-1
11 54395-4 ARMATURE KIT
12 53088-2 BALL BEARINGS use 53088-4
13 30474A FAN - MOTOR COOLING
14 53142 SCREWS (PKG OF 1 (48855 (NLA)
15 53188-1 WASHERS-PKG10 (metal)
16 53148 FAN WASHERS-PKG 10 (felt)
17 77247-355N Fan Blower Motor
18 37012-2 PULLEY - MOTOR DRIVE
19 54169-1 MOTOR BASE ASSY
20 54412-2 BEARING&RETAINER(54412-1)
21 53088-1 BALL BEARING - PACKAGE
22 53187-1 RIVETS-PKG10
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6446& ModelID=2072...
Wiring Diagram - 76984 - TS881A
Page 1 of 1Print Preview
8/21/2007http://homecareparts.electroluxusa.com/print_assembly.asp?AssemblyID=6447& ModelID...
