Commercial
Vacuum Cleaner
OWNER’S GUIDE
SC5800 Series
Index
Important Information 2-4
Quick Reference...........5
Use ........................... 6-7
Accessories ..................7
Dust Bag ......................8
Filter .............................9
Brush Roll ................... 10
Brush Roll Belt ...........10
How to Remove
Blockages ................... 11
Warranty ..................... 12
For location of nearest Sanitaire/
Eureka Warranty Station or service
information call 1-800-800-8975.
Please Retain
We suggest you record the model, type and serial numbers
below. They are located on the silver rating plate on your
cleaner. For prompt and complete service information, always
refer to these numbers when inquiring about service.
Model& Type___________________________
Serial No. ______________________
It is also important to keep your receipt as proof of date of
purchase.
www.sanitairevac.com
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.
WARNING
To reduce the risk of fire, electric shock, or injury:
Do not use outdoors or on wet surfaces.
•
Do not leave vacuum cleaner when plugged in. Tu r n
•
off the switch and unplug the electrical cord when not in
use and before servicing.
• This appliance is provided with double insulation. Use only
identical replacement parts. See instructions for Servicing
of double-insulated appliances.
Do not allow to be used as a toy. Close attention is
•
necessary when used by or near children.
Use only as described in this manual. Use only
•
manufacturer’s recommended attachments.
Do not use with damaged cord or plug. If vacuum cleaner
•
is not working as it should, has been dropped, damaged,
left outdoors, or dropped into water, return it to a service
center before using.
Do not pull or carry by cord, use cord as a handle, close
•
a door on cord, or pull cord around sharp edges or
corners. Do not run vacuum cleaner over cord. Keep cord
away from heated surfaces.
Do not use extension cords or outlets with inadequate
•
current carrying capacity.
Turn off all controls before unplugging.
•
Do not unplug by pulling on cord. To unplug, grasp the
•
plug, not the cord.
Do not handle plug or vacuum cleaner with wet hands.
•
Do not put any object into openings. Do not use with any
•
opening blocked; keep free of dust, lint, hair, and anything
that may reduce airflow.
This vacuum cleaner creates suction and contains a
•
revolving brush roll. Keep hair, loose clothing, fingers, and
all parts of body away from openings and moving parts.
• Do not place cleaer on furniture or stairs as the brush roll
may cause damage. Place cleaner on floor with the handle
in storage position while using attachments.
Do not pick up anything that is burning or smoking, such
•
as cigarettes, matches, or hot ashes.
Do not use without dust bag or filter(s) in place.
•
Belt pulleys can become hot during normal use. To prevent
•
burns, avoid touching the belt pulley when servicing the
drive belt.
Use extra care when cleaning on stairs.
•
Do not use to pick up flammable or combustible liquids
•
such as gasoline, or use in areas where they may be
present.
Store your cleaner indoors in a cool, dry area.
•
Keep your work area well lighted.
•
Unplug electrical appliances before vacuuming them.
•
SAVE THESE INSTRUCTIONS
To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other). This plug
will fit in a polarized outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do
not change the plug in any way.
GENERAL INFORMATION
Use the cleaner to pick up dirt and dust particles. Avoid
picking up hard or sharp objects that could damage the
vacuum cleaner.
Service Information
The instructions in this booklet serve as a guide to routine
maintenance. For additional service information, telephone
our toll free number for the nearest Sanitaire/Eureka
Authorized Warranty Station. You should know the model,
type and serial number or date code when you call:
USA: 1-800-800-8975 Mexico: 5670-6169
Canada: 1-800-800-8975
.
2
If you prefer, you can write to The Eureka Company, Service
Division, 807 North Main St., Bloomington, Illinois 61701,
USA. In Canada, write to The Eureka Company, 866 Langs
Drive, Cambridge, Ontario N3H 2N7. Refer to The Eureka
Warranty for complete service information
DO NOT OIL the motor or the brush roll. The motor
and brush roll are permanently sealed and
lubricated.
Thermal Cut Off
This vacuum cleaner has a special thermostat that protects
the cleaner in case of motor overheating. If the cleaner suddenly shuts off, push the on/off switch off (0) and unplug the
cleaner. Check the cleaner for a possible source of overheating such as a full dust cup, a blocked hose or clogged
filter. If these conditions are found, fix them and wait at least
30 minutes before attempting to use the cleaner. After the
30 minute period, plug the cleaner back in and push the on/
off switch on (l). If the cleaner still does not run, then take it
to a Sanitaire/Eureka Authorized Service Center for repair.
CONSEILS DE SÉCURITÉ
Lors de l’utilisation d’un appareil électrique, quelques précautions élémentaires doivent être observées, incluant les suivantes:
LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER VOTRE ASPIRATEUR.
AVERTISSEMENT
Pour réduire le risque de feu, de choc électrique, ou de blessure:
• Ne pas utiliser à l’extérieur ou sur des surfaces mouillées.
• Cet appareil est muni d’un double-isolement. Utilisez
uniquement des pièces de rechange identiques. Voir les
instructions pour l’entretien d’appareils à doubleisolement.
• Fermez le commutateur et débranchez l’appareil
lorsque vous ne l’utilisez pas ou avant le nettoyage
ou l’entretien.
• Ne permettez pas qu’il soit utilisé comme jouet. Une
attention particulière est nécessaire lorsque utilisé par
ou prés d’un enfant.
• Suivez les recommandations d’utilisation de ce manuel.
Utilisez uniquement les accessoires recommandés par
le fabriquant.
• Ne pas utiliser si le cordon ou la fiche sont endommagés.
Si l’aspirateur ne fonctionne pas comme il le devrait, s’il a
été échappé, s’il est endommagé, s’il a été laissé à
l’extérieur ou échappé dans l’eau, retournez-le à un centre
de service avant d’utiliser.
• Ne pas le tirer ou le transporter par le cordon, ne pas
utiliser le cordon en guise de poignée. Ne pas fermer une
porte sur le cordon ou tirer le cordon sur des coins ou
bordures pointus. Ne pas circuler sur le cordon avec
l’aspirateur. Tenir le cordon à distance des surfaces
chauffantes.
• Ne pas utiliser des rallonges ou des prises qui n’ont pas
de capacité suffisante pour transporter le courant.
• Fermer tous les contrôles avant de débrancher.
• Ne pas débrancher en tirant sur le cordon. Pour
débrancher, tenez la fiche et non le cordon.
• Ne pas manipuler la fiche ou l’aspirateur avec les mains
mouillées.
• Ne pas rien insérer dans les ouvertures. Ne pas utiliser si
des ouvertures sont bloquées; assurez-vous qu’elles
soient dégagées de poussière, mousse, cheveux ou toute
autre chose qui pourrait réduire le passage de l’air.
• Cet aspirateur créé de la succion et contient un rouleau-
brosse tournant. Tenir les parties mobiles et les ouvertures
loin des cheveux, du linge, des doigts et de toute partie
du corps.
• Ne pas mettre l’aspirateur sur les meubles ou sur les
escaliers car le rouleau-brosse peut faire des dommages.
Placer l’aspirateur sur le plancher avec le manche en
entreposage position temps que les accessoires sont en
usage.
• Ne pas ramasser des objets qui brûlent ou fument comme
les cigarettes, allumettes ou cendres chaudes.
• N’utilisez pas sans le sac de poussière en place.
• Les poulies du courroie peuvent devenir chaudes pendant
l’utilisation normale. Pour prévenir des brûlures, évitez
de touché la poulie du courroie lorsque vous réparez la
courroie.
• Portez une attention particulière lorsque vous nettoyez
les escaliers.
• Ne pas utiliser pour ramasser des liquides inflammables
ou combustibles comme de l’essence: Ne pas utiliser dans
les endroits où ces liquides pourraient être présents.
• Entreposez votre aspirateur à l’intérieur dans un endroit
propre et sec.
• Maintenez un bon éclairage à l’endroit où vous travaillez.
• Débrancher les appareils électrique avant de les balayer.
CONSERVEZ CES INSTRUCTIONS
Afin de réduire le risque de choc électrique, cet appareil est muni d’une fiche polarisée (une des lames est plus large).
Cette fiche ne peut être insérée dans une prise polarisée que d’une seule façon. Si la fiche ne peut être insérée dans la
prise, retourner la fiche. Si la fiche ne peut toujours pas être insérée dans la prise, faire installer une prise adéquate par un
électricien qualifié. Ne pas modifier la fiche.
3
SERVICING OF DOUBLE-INSULATED APPLIANCES
A double-insulated appliance is marked with one or more of the following: The words “DOUBLE
INSULATION” or “DOUBLE INSULATED” or the double insulation symbol (square within a square).
In a double-insulated appliance, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated appliance, nor should a means for grounding be
added to the appliance. Servicing a double-insulated appliance requires extreme care and knowledge
of the system, and should be done only by qualified service personnel. Replacement parts for a
double-insulated appliance must be identical to the parts they replace.
THE SANITAIRE® COMMERCIAL LIMITED WARRANTY
WHAT THIS WARRANTY COVERS
Your Sanitaire commercial cleaner is warranted to be free from all defects in material and workmanship in normal use FOR A
PERIOD OF ONE YEAR. The warranty is granted only to the original purchaser of the cleaner. The warranty is subject to the
following provisions.
WHAT THIS WARRANTY DOES NOT COVER
• Parts of the cleaner that require replacement under normal use, such as bumpers, bags, bristle strips, belts, light bulbs,
hoses, and impellers.
• Damages or malfunctions caused by negligence, abuse, or use not in accordance with Owner's Guide.
• Defects or damages caused by unauthorized service or the use of other than Genuine Eureka parts.
WHAT THE EUREKA COMPANY WILL DO
The Eureka Company will, at its option, repair or replace a defective cleaner or cleaner part that is covered by this warranty. As
a matter of warranty policy, the Eureka Company will not refund the consumer's purchase price.
WARRANTY REGISTRATION
Please fill out and return the warranty registration card accompanying your cleaner.
OBTAINING WARRANTY SERVICE
To obtain warranty service you must return the defective cleaner or cleaner part along with proof of purchase to any Eureka/
Sanitaire Authorized Warranty Station. You will find the nearest location in the Yellow Pages under “Vacuum Cleaners-Service
and Repair.” Be certain that the Warranty Station is “Eureka/Sanitaire Authorized.”
For the location of the nearest Eureka/Sanitaire Authorized Warranty Station or for service information, telephone toll free:
USA: 1-800-800-8975
Mexico: 5670-6169
Canada: 1-800-800-8975
If you prefer, you can write to: In Canada write to:
The Eureka Company The Eureka Company
Service Division 866 Langs Drive
807 North Main Street Cambridge, Ontario N3H 2N7
Bloomington, IL 61701, USA
If it is necessary to ship the cleaner outside your community to obtain warranty repair, you must pay the shipping charges to the
Eureka/Sanitaire Authorized Warranty Station. Return shipping charges will be paid by the Warranty Station. When returning
parts for repair, please include the model, type, and serial numbers from the data plate on the cleaner.
FURTHER LIMITATIONS AND EXCLUSIONS
Any warranty that may be implied in connection with your purchase or use of the cleaner, including any warranty of
MERCHANTABILITY or any warranty for FITNESS FOR A PARTICULAR PURPOSE is limited to the duration of this warranty.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you.
Your relief for the breach of this warranty is limited to the relief expressly provided above. IN NO EVENT SHALL EUREKA BE
LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES THAT YOU MAY INCUR IN CONNECTION WITH YOUR
PURCHASE OR USE OF THE CLEANER. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights. You may also have other rights which vary by State.
4
QUICK REFERENCE
WARNING: Avoid injury. Keep loose clothing, hair,
fingers, and all other parts of body away
from any moving part (such as the revolving
brush). Turn off the switch and unplug the
cleaner before changing the cleaner height
setting.
9
10
12
1
3
5
6
8
1. Cord Retainer. To use, push electrical cord down into
cord retainer.
2. ON/OFF Switch. International symbol I means On,
International symbol O means Off.
3. Bag Compartment Latch. Pull up on latch to remove
bag compartment door giving access to the dust bag
and motor filter.
2
4
7
9
9
10
9
9. Hose Retainers (4). Place hose in retainers to store hose
on unit.
10. Electrical Cord Hooks (2). Wrap electrical cord around
them to store electrical cord on unit. The upper cord hook
rotates for quick cord release.
11. Nested Wand Storage. The crevice wand stores inside
the larger wand.
12. Carrying Handle. Use this handle to carry unit from one
place to another.
13. Dusting/Upholstery Brush Storage. Store the dusting
brush on back of cleaner.
NOTE: WHEN UNIT IS RUNNING, DO NOT ATTEMPT TO
REMOVE ANY OBJECT WHICH PREVENTS THE
BRUSH ROLL FROM TURNING.
First, turn off unit, unplug from the electrical socket, then
remove object from brush roll area. Ex: sock, rug, etc.
11
13
11
4. Filter Door Latch. Push down on latch and pivot out for
access to the filter compartment. Push up on latch to
close door.
5. Stair Handle. To use when cleaning stairs.
6. Headlight.
7. Handle Release. Step on handle release to pull handle
back to a comfortable operating position.
8. Cleaner Height Setting. An adjustment that raises or
lowers the cleaner base to match the type of floor surface.
Helpful Information:
Listen to your cleaner. If you notice a change in the
sound of the motor or a change in performance, it could
simply indicate a common usage or maintenance issue.
Such as, a need to raise or lower the carpet height
adjustment, possible blockage in hose or brush roll area,
or a broken or loose brush roll belt. These are all easy
to fix and the instructions are included in this owner’s
guide. Becoming familiar with the information in this
guide will help you to get the best possible performance
from your new cleaner for many years to come.
5
HOW TO ASSEMBLE
CAUTION: Assemble the cleaner before using.
CAUTION: Moving parts, make sure on/off switch is in
off (0) position before plugging in.
NOTE: Features may vary by model yet all parts
assemble the same.
Attach Handle
CAUTION: Do not catch cord under handle.
1
Grooves
2
1. From rear of cleaner, align handle with groove and slide
onto cleaner. If necessary, use thumb and finger
pressure to slide handle into position.
2. Attach handle with the two 1 inch screws provided in
the assembly packet. Use a Phillips
®
head screwdriver.
Store Hose and Accessories
Nested Wands
Dusting
Brush
Store Electrical Cord
NOTE: Hand tighten with screwdriver to be sure both
screws are firmly seated.
Attach Hose
3
Upper Hose
Retainer
4
Hose
Lower Hose Retainer
Cord
Retainer
5. You will find your cord retainer on the handle above the
upper cord hook. Firmly push the electrical cord down
into the cord retainer. This will place the cord out of the
way the next time you vacuum.
5
Cord Hook6
Plug
7
6
Cord Hook
3. Pick up hose and lay across upper hose retainer.
4. Push the end of the hose in the lower hose retainer to
secure.
6
6. Next wind the cord around the two cord hooks on the
back side of cleaner.
7. Secure the plug to the cord to prevent unwinding.
HOW TO USE
NOTE: While using accessories, do not place cleaner
on furniture or steps as the brush roll may
cause damage. Place cleaner on floor with the
handle in storage position.
1. To use accessories remove hose from rear of cleaner by
lifting up and twisting.
1
2
1. Handle Release. Step on handle release to pull handle
back to a comfortable operating position. To lower handle
completely to the floor, depress handle release a second
time.
Store
Helpful Information:
Operate
Clean
Under
2. Cleaner Height Setting. An adjustment that raises or
lowers the cleaner base to match the type of floor surface.
With the cleaner cord unplugged, set the adjustment to
lowest setting for maximum carpet cleaning. If the cleaner
is difficult to push, move adjustment to next highest
setting until cleaner is comfortable to push. The brush
roll must reach the carpet for effective cleaning. For ease
in moving the adjustment knob, place handle in operating
position and tilt cleaner back to remove weight from front
wheels.
Before cleaning under low
furniture, check area first
for objects that might
harm the unit or block the
vacuum hose.
2. Place desired accessory onto end of hose or wand.
Dusting/Upholstery
Crevice
Wand
Brush
Hose or Wand
Dusting/Upholstery Brush is for furniture, blinds,
books, lamp shades, shelves, curtains, draperies, cushions
and fabrics.
Crevice Wand cleans corners, stairs, baseboards, and
between cushions.
Nested extension wands to add reach.
• Grasp both wands near ridges.
WARNING:Avoid injury. Keep loose clothing, hair,
fingers, and all other parts of body away from
any moving part (such as the revolving
brush). Turn off the switch and unplug the
cleaner before changing the cleaner height
setting.
• Pull apart.
• Turn ridge end to center. • Push wands together.
7
ROUTINE MAINTENANCE
The instructions in this booklet serve as a guide to routine
maintenance. To avoid unnecessary service calls, check the
filters, belt, and brush roll often.
NOTE: When vacuuming carpet fresheners or
cleaners, powder, plaster dust, or similar fine
substances, the filters will require more
frequent maintenance.
NOTE: Turn off the switch and unplug the electrical
cord before changing the filter. Never operate
the vacuum cleaner without the filter assembly
in place.
Removing the Dust Bag (Style LS):
Remove dust bag cover by lifting up on latch
1
and pivoting dust bag cover out and away from
cleaner.
Latch
Installing New Dust Bag:
BEND FLAPS FORWARD
➀
PUSH BAG INTO HOUSING
➂
PLACE BAG FLANGE
➁
ON TOP OF SHELF
➂
➃
2
Grasp dust bag flaps and pull out from
cleaner.
Flaps
POSITION BAG BOTTOM
➃
BEHIND RIBS
Reinstalling the Dust Bag Cover:
Place the bottom of the dust bag cover on cleaner lining up
grooves on outer edge of cover with rails on side of cleaner.
Rotate cover up, pressing against cleaner until it locks into
place.
Rails on
Cleaner
Grooves on
inside edge
of bag cover
8
ROUTINE MAINTENANCE (continued)
Pre-Motor
Filter
Pre-Motor Filter
Check the pre-motor filter each time the dust bag is changed.
Clean or replace as needed.
To Clean Pre-Motor Filter
1. Remove filter centered in the bottom of the bag
compartment.
2. Shake filter to remove excess dust. If necessary, the filter
can be cleaned by vacuuming with another cleaner or
washing with mild detergent.
3. Reinstall filter after completely dry.
Use GENUINE EUREKA replacement pre-motor filter,
Part No. 71480.
Models equipped with Cartridge Filter (Only
cartridge style filters can be used with these models.)
Check the True HEPA filter each time dust bag is changed.
Replace twice a year or as needed.
How To Clean Filters
1. Remove from cleaner.
2. To remove debris, tap filter against waste container or
brush off. You may also vacuum the filter using a different
cleaner. If filter needs further cleaning, wash in warm
water using a mild detergent. To clean between filter
pleats, fan open under running water.
3. When all parts are completely dry, follow the above
steps in reverse to reassemble.
NOTE:Do not put any parts in a dishwasher.
NOTE:Your washable filter may need to be replaced if
cleaning it does not restore cleaning
performance.
Be sure to use GENUINE EUREKA replacement filters.
True HEPA Cartridge
Latch
Filter Door Latch
To remove True HEPA
1. Push down on filter door latch and pull door away from
cleaner.
2. Push down on HEPA cartridge latch and remove filter.
To replace True HEPA
1. Place bottom tabs of filter cartridge into slots. Rotate
filter toward cleaner, press firmly against cleaner to latch.
Make sure True HEPA cartridge latch is secured on
both sides.
2. Replace filter door by placing tabs of door into slots on
cleaner. Rotate door up and against cleaner until it locks
into place.
NOTE: To have the benefit of a sealed True HEPA
system, you must use one of the True HEPA
cartridge
Use GENUINE EUREKA replacement True HEPA filter,
HF5.
filter systems.
cartridge
cartridge
filter
filter
PERIODIC MAINTENANCE
How To Change Light Bulb (Only for models with a
headlight)
NOTE: Turn off the power switch and disconnect the
electrical cord before changing light bulb.
1. Lower handle. Remove the screw from lens cover.
2. Pull lens cover from cleaner.
3. Pull old light bulb out of socket.
4. Push new light bulb into socket.
5. Replace lens cover.
6. Secure with screw.
Use GENUINE EUREKA replacement light bulb,
Part No. 57940-2.
9
PERIODIC MAINTENANCE (CONTINUED)
Brush Roll
The brush roll turns as it sweeps and combs the carpet nap.
Remove hair and threads from the brush roll so it continues
brushing the carpet. To maintain the most efficient cleaning,
the bristles must touch the carpet. To test the bristle length,
hold a ruler against the underneath side of the cleaner. If
the bristles no longer touch the ruler, replace the brush roll.
Brush Roll Belt, Style U
The brush roll belt turns the brush roll to agitate, sweep,
and comb the carpet nap. Check the belt regularly to be
sure it is in good condition. Replace the belt if it stretches,
cracks or loses tension. Cut away any hair or threads wound
around the brush roll or the belt pulley because the buildup
could cause the belt to rotate unevenly.
How To Replace Brush Roll Belt
NOTE: Turn off the switch and unplug the electrical cord
before replacing belt. Belt pulleys can become
hot during normal use. To prevent injury, avoid
touching the motor shaft when changing the belt.
5
6. Place new brush roll around motor shaft.
6
2
2
2
1. Lower handle to floor to change belt.
2. Remove three screws indicated by screwdrivers in above
illustration. Lift hood to remove.
NOTE: The carpet height adjustment has to be in the
lowest or highest position to remove or reinstall
the hood.
1
4
Motor
Shaft
Belt
7
6. Place belt around brush roll pulley.
7. Align left end cap with base. Push end cap securely into
place.
8. Push right end cap into base until it snaps into place.
8
9
IMPORTANT
9. Rotate brush roll by hand two full rotations
to properly position belt.
3
3. Lift left end of brush roll.
4. Remove and discard old brush roll.
10
Brush
Roll
10. Place hood back on cleaner. Make sure hood front is
behind furniture guard. Replace three screws.
11. Tighten screws.
Use GENUINE EUREKA replacement belt, Style U. Look
for the GENUINE EUREKA product symbol.
Problem Solving
To Clear Blockages in Hose
NOTE:Turn off the switch and unplug the electrical cord
before clearing hose.
Nested
Wands
Hose
Adapter
Tabs
Lower
Hose
Adapter
Base
Hose
5. Locate lower hose adapter on the back of the cleaner.
6. Remove lower hose adapter from rear of cleaner by lifting
up and twisting.
7. Check for blockages in the hose and base hose. Flexing
the hose may help loosen any blockage. If no blockage
is found, continue to step 8. If blockage is found, clear
and continue to step 11.
1. Locate upper hose adapter on the back of the cleaner.
2. Remove nested wands from back of cleaner for easy
access to hose adapter tabs.
3. Press hose adapter tabs together and pull hose adapter
away from cleaner. The hose adapter will unscrew off hose
for easy access to debris if necessary.
4. Check for blockages at cleaner opening and in hose. If
no blockage is found, continue to step 5. If blockage is
found, clear and continue to step 11.
8. Remove hood from cleaner and check for a blockage in
the brush roll area. Make sure the hose inlet is clear.
9. After the blockage is found and cleared, replace the hood
on the cleaner.
10. Place lower hose adapter back into the base hose.
11. Install the upper hose adapter onto the back of the
cleaner, line it up with the cleaner opening and push it
against the cleaner until both tabs lock into place.
11
NOTE: Turn off the switch and unplug the
electrical cord before servicing.
PROBLEM SOLUTION
Motor will not start. Push plug securely into outlet.
Motor suddenly Thermal Cut Off, see Page 2.
stops.
Does not clean the Clean or replace the filters: Hint: If picking
carpet or floor. up fine dust, the filters may
No suction at the Be sure hose adapter is secure. Page 11.
end of hose.
Headlight not Replace light bulb. Page 9.
working.
Noise from brush Remove hood and clean debris or items
roll area. from the brush roll area.
Cleaner is hard to Put handle in operating position. Tilt the
push. cleaner back to raise the front wheels off floor.
Cleaner height knob Hint: Put handle in operating position. Tilt
will not turn. the cleaner back to raise the front wheels off floor.
Bag Cover will not go Dust bag must be installed properly in cleaner or
onto cleaner properly. bag cover will not go onto cleaner. Make sure the
Hood will not come off. Hood cannot be removed from cleaner unless the
Missing parts or Call 1-800-800-8975 between 8 a.m. to 7:30 p.m.
questions?
Try another outlet.
Check circuit breaker.
fine substance tends to reduce suction when it
blocks the airflow through the filters.
Be sure the dust bag is properly seated into the
cleaner body. Page 8.
Replace dust bag. Page 8.
Be sure hose adapter is secure on back of cleaner.
Page 11.
Check base hose and long hose. Page 11.
Replace a broken, cut, loose or out of shape belt.
Clean hair and thread from bristles and end cap
area.
Replace brush roll if bristles are worn.
Clean or replace filters. Hint: If picking up fine dust,
the filters may
tends to reduce suction when it blocks the airflow
through the filters.
Remove any clogs from the hose that restrict the
airflow. Check base hose and long hose. Page 11.
Replace dust bag. Page 8
Replace a broken, cut, loose or out of shape belt.
Page 10.
Then turn the knob to a higher setting.
Replace a broken, cut loose or out of shape belt.
Page 10.
Then turn the knob.
dust bag cardboard flange is on the support shelf.
See page 6.
cleaner height setting is in the lowest or highest
position.
All three screws must be removed from the top of
the hood. Page 10.
(CST), Monday through Friday and 10 a.m. to 6:30
p.m, Saturday. Know the model and serial numbers when you call.
not look dirty, but a fine substance
not look dirty, but a
Part No. 73524 (10/03)
©2003 White Consolidated, Ltd.
Printed in U.S.A.
Loading...
