Sangean DPR-34+ User Manual

DPR-34+

GB

Revision 1

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.

8. Do not install near any heat sources such
as ra di ators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.

1

9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blade s with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The wide
blade or the third prong are provided for
your safety. If the provided plug does not fit
into your outlet. consult an electrician for
replacement of the obsolete outlet.

10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacle s, and the point
where they exit from the apparatus.

11. Only use attachments/accessories specif ied
by the manufacturer.

GB

2

12. Use only with the cart, stand, tripod,
bracket, or table specified by
the manufacturer, or sold with
the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.

14. Refer all servicing to qualified
service personnel. Servicing is required
when the apparatus has been damaged in
any way, such as power-supply cord or plug
is damaged. liquid has been spilled or
objects have fallen into the a pparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.

3

15. To Reduce the Risk of Fire or
Electric Shock, Do not Expose This
Appliance To Rain or Moisture.

16. The Shock Hazard Marking and Associated
Graphical Symbol is provided on the bottom
panel of unit.

17. Apparatus shall not be exposed to
dripping or spla shing and no objects filled
with liquids, shall not be placed on
the apparatus.

GB

4

5

Controls

1. Headphone socket

2. Lock switch (Note: If this is activated the
radio will not operate)

3. T elescopic a ntenna

4. Power button

5. Volume Control

6. LCD display

7. Loudspeaker

8. Tuning/Menu jog wheel

9. DC socket

GB

6

Charging the radio

The DPR 34 features a built in 1800mAH
Lithium rechargeable battery to power the radio.
Before operating the radio for the first time
please fully charge the battery.

The DPR 34 is supplied with a 5V/500 mA
AC adaptor.

1. Insert the adaptor plug into the DC socket on
the right side of your radio. Plug the adaptor
into a standard mains outlet and the radio will
begin charging the built in battery.
Charging time is approx. 4 hours with ra dio
off and 10 hours with radio on. The battery
power icon on the LCD display will flash
whilst charging and stop flashing when the
radio is fully charged.

7

The battery run time is approx. 15 hours
listening through the speaker and approx
18 hours with headphones. Reduced power,
distortion, ‘stuttering’ sounds or battery power
indicator in “low” are all signs that the battery
needs to be recharged.

Note:
If charging the radio when the power is off,
the battery power icon does not display on
the LCD.

Headphones

The 3.5 mm stereo headphone socket located
on the top of your radio is provided for use
with stereo headphones or an earpiece.
Connecting headphones automatically mutes
the built in speaker.

Important:
Excessive volume levels from earphones
and headphones may cause damage to
your hearing.

GB

8
