SAMSUNG YP-T10JQW User Manual

MP3 Player

user manual

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service, please

www.samsung.com/global/register

YP-T10

features of your new MP3 Player

Good looking. Smart. Reliable. And lots of fun. Your new MP3 player is all this and more. Its compact silhouette takes up the tiniest space in your pocket, and its state-of-the-art technology delivers rich sound, vibrant pictures. You’ll love your new MP3 player, whether you’re exercising, downloading your favorite tunes, watching videos or even listening to FM Radio. Use it once, and you’ll wonder how you ever lived without it.

PUTTING THE “MULTI” IN MULTIMEDIA

We call it an MP3 player, but it’s much more than that. It allows you to view pictures, text, and videos and listen to FM radio. The built-in Bluetooth wireless technology turns your MP3 player into your own personal network.

TOUCH NAVIGATION!

You can tap on the touch pad to navigate through the menus.

WHERE FORM MEETS FUNCTION

Sure, it’s sleek and good-looking. But it’s easy to hold and use, too.

LONGER PLAY TIME AND SHORTER DOWNLOADING!

A fully charged battery can play up to 30 hours of music or 4 hours of video. Download times are shorter. Because of its USB 2.0 capability, the player is much faster than models with USB 1.1.

ACOUSTIC WONDER

Your new MP3 player has built-in DNSe™ (Digital Natural Sound engine), Samsung’s unique sound technology created to deliver richer, deeper sound for an unbelievable listening experience.

safety information

What the icons and signs in this user manual mean :

WARNING

CAUTION

NOTE

These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference.

Means that death or serious personal injury is a risk.

Means that there is a potential risk for personal injury or material damage.

To reduce the risk of ﬁ re, explosion, electric shock, or personal injury when using your MP3 Player, follow these basic safety precautions:

Means hints or referential pages that may be helpful to operate the player.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Call the service center for help.

safety information

This manual describes how to properly use your new mp3 player. Read it carefully to avoid damaging the player and injuring yourself. Pay particular attention to the following serious warnings:

PROTECT YOURSELF



Do not disassemble, repair, or modify this product on your own.



Do not get the product wet or drop it in water. If the product gets wet, do not switch it on because you could get an electric shock. Instead,

CAUTION

contact a Samsung Customer Service Center near you.



Do not use the product when it thunders with lightening. Otherwise, it will cause malfucntion or a risk of electric shock.



Do not use the earphones while you are driving a bicycle, automobile or motorcycle.

CAUTION

It can cause a serious accident, and furthermore, is prohibited by law in some areas. Using the earphones while walking or jogging on a road, in particular, on a crosswalk can lead to a serious accident.



For your safety, make sure the earphone cable does not get in the way of your arm or other surrounding objects while you are taking exercise or a walk.



Do not place the product in damp, dusty, or sooty areas because these environments could lead to ﬁ re or electric shock.

WARNING

PROTECT YOURSELF

Using earphones or headphones for an extended time may cause serious



WARNING

damage to your hearing.

If you are exposed to sound louder than 85db for an extended time, you may adversely affect your hearing. The louder the sound is, the more seriously damaged your hearing may be (an ordinary conversation is between 50 to 60db and road noise is approximately 80db). You are strongly advised to set the volume level to

medium (the medium level is usually less than 2/3 of the maximum).

If you feel a ringing in the ear(s), lower the volume or stop using the



earphones or headphones.

PROTECT YOUR MP3 PLAYER

Do not leave the player in temperatures above 95°F (35°C), such as a



sauna or a parked car. Do not cause excessive impact on the player by dropping it.



Do not place heavy objects on top of the player.



Prevent any foreign particles or dust from entering into the product.



Do not place the product near magnetic objects.



Be sure to backup important data. Samsung is not responsible for data loss.



Use only accessories provided by or approved by Samsung.



Do not spray water on the product. Never clean the product with chemical



substances such as benzene or thinner, as it may cause ﬁ re, electric

CAUTION

shock or deteriorate the surface.

Failure to follow these instructions may lead to physical injuries or damage to



CAUTION

the player.

When printing this user manual, we recommend that you print in color and



NOTE

check “Fit to Page” in the print option for better viewing.

THE BASICS

10 What’s included 11 Your MP3 Player 14 Screen displays 17 Using the touch button 18 Charging the battery 19 Caring for the battery 19 Turning the power on & off 20 Playing music 20 Controlling the volume 21 Disabling the buttons 21 Browsing for ﬁ les using “File

Browser” 22 Deleting ﬁ les with “File Browser” 23 Changing the settings and

preferences

23 Menu style settings 24 Sound settings 25 Display settings 26 Language settings 27 Date&time settings 28 System settings

31 Resetting the system

SAMSUNG MEDIA STUDIO

32 PC requirements 33 Installing Samsung Media Studio 34 Transferring ﬁ les to the player with

Samsung Media Studio

contents

LISTENING TO MUSIC

37 Listening by category 38 Pausing 38 Searching within a track 38 Playing from the beginning of the

current track 38 Playing the previous track 38 Playing the next track 39 Creating a playlist using Samsung

Media Studio

39 Creating a Playlist 40 Adding music ﬁ les to a playlist you’ve

created

41 Transferring a playlist to your player

using media studio

42 Creating a playlist on your MP3

player 43 Playing a playlist 44 Deleting a ﬁ le from the playlist 44 Deleting all ﬁ les from the playlist 45 Using the music menu

WATCHING A VIDEO

52 To pause playing during the playback 53 To move to a speciﬁ c frame 53 To play the previous video ﬁ le 53 To play the next video ﬁ le 54 Using the video menu

contents

VIEWING PICTURES

LISTENING TO FM RADIO

USING THE DATACAST

ENJOYING

THE PRIME PACK

57 Viewing pictures 58 Using the picture Menu

62 To use the mute function 63 To search for fm stations 64 Using the FM radio menu

71 Registering a channel 72 Creating a new channel group 72 Transferring a datacast from

<Media Studio> 73 Viewing Datacasts

74 Reading text 75 Using the Text menu 80 Voice Recording 82 Playing video games 84 Viewing the address book

contents

USING BLUETOOTH

TROUBLESHOOTING

104

APPENDIX

108

85 What is Bluetooth? 87 Using a Bluetooth stereo headset 90 Using a Bluetooth mobile phone 96 Transferring ﬁ les to/from a bluetooth

device 101 Using the Bluetooth menu 102 Bluetooth settings

104 Troubleshooting

108 Menu Tree 109 Product Speciﬁ cations 111 License

the basics

WHAT’S INCLUDED

Your new mp3 player comes with these accessories. If you’re missing any of these items, contact Samsung Customer Service Center.

Player

USB Cable Installation CD

The accessories in your box may look slightly different than these.

10 _ the basics

Earphones

YOUR MP3 PLAYER

Screen display

Power & Hold switch

Slide and hold in the opposite direction of the arrow for power on/off. Slide in the direction of the arrow to lock the button functions.

If a player malfunction occurs,

Reset Hole

press the reset hole with a pointed

object to re-initialize the system.

the basics _ 11

YOUR MP3 PLAYER (Continued)

These buttons are ‘Touch’ buttons.

Tap to display the menu screen.

Tap to increase the volume or move to an

Tap to move to the previous screen.

Press and brieﬂ y hold to move to the

Left ﬁ le browser button

Tap to move to the previous track/menu or

play the current track from the beginning.

Press and brieﬂ y hold to quickly scan tracks.

Play/Pause, Select button

Tap to select the play/pause and function,

move to the next screen.

Down volume button

Tap to reduce the volume or move to a

Right ﬁ le browser button

Tap to move to next track/menu. Press

and brieﬂ y hold to quickly scan tracks.

12 _ the basics

Menu button

Up volume button

upper item/menu.

Back button

main menu screen.

lower item/menu.

YOUR MP3 PLAYER (Continued)

Earphone connection jack

Neck string hole

USB connection port

Microphone

Earphones

Labeled “L” for the left earpiece and “R” for the right earpiece. Also serves as an antenna for FM Radio in the MP3 player.

the basics _ 13

SCREEN DISPLAYS

Music

Songs

NOTE

The screen pictures are for illustration purposes only. The actual screen may differ.

Bluetooth/Lock Indicator

Parent Menu Indicator

Battery Status

Current track playing / Total

number of tracks Indicator

Play Speed Indicator

Current Time

Total Play Time

Play/Pause, Search Indicator

Music Mode Indicator

Play Mode Indicator

DNSe Mode Indicator

Music Play Screen

Play Status Bar

Current Play Time

Music Title

14 _ the basics

SCREEN DISPLAYS (Continued)

Video

Bluetooth/Lock Indicator

Battery Status

Current Time

Total Play Time

Play/Pause, Search

Indicator

Video Track 1

Video Mode Indicator

File Name

Play Status Bar

Current Play Time

the basics _ 15

SCREEN DISPLAYS (Continued)


Picture Image1.jpg

[Preview Screen]

FM Radio

MANUAL

Pictures

Bluetooth/Lock Indicator

Battery Status

Current ﬁ le /Total number of ﬁ les Indicator

Current Time

Music Play Status

Picture Mode Indicator

Parent Menu Indicator

File Name

Bluetooth/Lock Indicator

Battery Status

Current Time

Radio Mode Indicator

Manual/Preset Indicator

Current Frequency(MHz) Indicator

16 _ the basics

USING THE TOUCH BUTTON

Tap on touch screen with your ﬁ ngertip.

To avoid damage to the touch screen, do not use any object other than your ﬁ ngers



NOTE

to operate it.

Do not tap on the touch screen if your ﬁ ngers are not clean.



Do not tap on the touch screen with gloves on.



The touch screen may not function if you use a ﬁ ngernail or other instruments such



as a ballpoint pen.

the basics _ 17

CHARGING THE BATTERY

Charge it before using the player for the ﬁ rst time and when you haven’t used it for a long time. The battery for your mp3 player will fully charge in about 3 hours, although total charging time varies depending on your PC environment.

Before you start - Remove the earphones before connecting the USB cable.



Screen Display



USB connected



Charging...



Fully Charged

1. Connect the larger end of the USB cable to the USB Connection Port on the

bottom of the player.

2. Connect the USB cable to the USB port ( ) on your PC.

18 _ the basics

CARING FOR THE BATTERY

Your battery will last longer if you follow these simple guidelines for caring and storing it.

• Recharge and store the battery within the temperature range of 5°C~35°C (40°F~95°F).

• Do not overcharge (longer than 12 hours). Excessive charging or discharging may shorten the battery’s life.

• Battery life naturally shortens slowly over time.

If you are charging the player while it is connected to a laptop computer, make sure



the laptop’s battery is also fully charged or that the laptop is plugged into its power

NOTE

source.

TURNING THE POWER ON & OFF

Turning the Power on

Slide and hold the direction of the arrow.

Power is turned on.



Turning the Power off

Slide and hold the direction of the arrow again.

Power is turned off.



Your mp3 player will be automatically turned off when none of the buttons have



NOTE

been pressed for a speciﬁ c length of time in the pause mode. The factory setting for <Auto Power Off> is 1 minute, but you can change this length of time. See page 29 for more information.

switch in the opposite

the basics _ 19

PLAYING MUSIC

Load music ﬁ les onto your new mp3 player using Samsung Media Studio. Learn more about Media Studio on page 34.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Music

2. Tap [ ] to select <Music> and tap [ ].

3. Use [ ] and [ ] to select a music ﬁ le of your choice.

4. Tap [ ].

The music ﬁ le will begin playing.



Tap [



NOTE

] to move to the previous screen.

Press and brieﬂ y hold [

] to move to the main menu screen.

CONTROLLING THE VOLUME

Tap [ ].

You will see a volume control icon.



The range of volume is set between 0 to 30.



] to increase the volume or [ ] to decrease it.

Tap [



Music

20 _ the basics

DISABLING THE BUTTONS

The hold function disables all the other buttons on the mp3 player, so that if you accidentally bump one-while working out, for example-your music won’t be interrupted.

1. Slide the switch in the direction of the arrow.

2. Slide the switch in the opposite direction of

Music

the arrow to release the Lock function.

BROWSING FOR FILES USING “File Browser”

Search easily for ﬁ les using the “File Browser” function.

1. Press and brieﬂ y hold [ ] to move to the main menu

screen.

2. Tap [ ] to select <File Browser> and tap [ ].

The <File Browser> folder list containing “Music, Playlists, Video,



Pictures, Datacasts, Texts, Games, Recorded Files and Received Files” appears.

3. Tap [ ] to select a desired folder.

4. Tap [ ] to bring up the ﬁ le list in the selected folder.

Tap [ ] to move to the previous screen.



5. Tap [ ] to select a desired ﬁ le.

6. Tap [ ].

The ﬁ le will start playing.



the basics _ 21

DELETING FILES WITH “File Browser”

1. Press and brieﬂ y hold [ ] to move to the main menu

screen.

2. Tap [ ] to select <File Browser> and tap [ ].



The <File Browser> folder list appears.

3. Tap [ ] to select a desired folder and tap [ ].

4. Tap [ ] to select the ﬁ le that you want to delete and tap [ ].

5. Tap [ ] to select <Delete> and tap [ ].

The conﬁ rmation window will appear.



6. Tap [ ] to select <Yes> and tap [ ].

The ﬁ le will be deleted



Once ﬁ les are deleted, they cannot be recovered.



CAUTION

File Browser

Music

Playlists

Video

Pictures

Datacasts

Tex t s

Games

Recorded Files

Received Files

22 _ the basics

CHANGING THE SETTINGS AND PREFERENCES

Your mp3 player comes with settings and preferences that were set up at the factory, but you can change these pre-set values to truly customize your player.

Ta p [ ] to move to the previous screen.



Press and brieﬂ y hold [

NOTE

Menu Style Settings

You can change the menu design and font and delete background image of the main menu.

1. Press and brieﬂ y hold [ menu screen.

2. Tap [



3. Tap [ ] to select <Menu Style> and tap [ ].



4. Use the [ ] and [ ] to set functions.



Menu Style Setting Options

Menu Design : You can change the style of the main menu screen. Select from



<Sammy>, <Pendant> and <My Skin>.

Color Tone : You can change the menu and screen background color. If you set



<Sammy> in <Menu Design>, <Color Tone> will be disabled.

Font : You can change the font type of the menu language. Select one from 3



font types. In some menu languages, <Font> will be disabled.



Reset My Skin : default image. If you set <Sammy> or <Pendant> in <Menu Design>, <Reset My Skin> will be disabled.

] to select <Settings> and tap [ ].

The <Settings> menu appears.

The <Menu Style> menu appears.

Tap [ ] to move to the next item/select the menu.

Tap [ menu.

] to move to the main menu screen.

] to move to the main

] to move up or down through the current

Initializes the background image of the screen display to its

Settings

Menu Style

Sound Display Language Date & Time System

the basics _ 23

CHANGING THE SETTINGS AND PREFERENCES (Continued)

Sound Settings

You can set Master EQ, Beep Sound and Volume Limit.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Tap [ ] to select <Settings> and tap [ ].

The <Settings> menu appears.



3. Tap [ ] to select <Sound> and tap [ ].

The <Sound> menu appears.



4. Use the [ ] and [ ] to set functions.

Sound Setting Options

Master EQ : You can optimize sound settings.



] to select the frequency you want to adjust. Tap [ ] to adjust the

Tap [ selected frequency’s level and then tap [

Beep Sound : Sets the beep sound for button operations to on or off. Select from <Off> and <On>. During music playback, the beep will be disabled even if set to <On>.

Volume Limit : You can avoid hearing damage by setting the limit of the volume when using the earphone. <On> will limit the maximum volume level to 15. The maximum volume level when volume limit is set to <Off> is 30. Even if you have selected <Off>, the volume will be set back to 15 to avoid hearing damage when you turn the player back on.

Settings

Menu Style

Sound

Display Language Date & Time System

24 _ the basics

CHANGING THE SETTINGS AND PREFERENCES (Continued)

Display Settings

Change the display off time and brightness of your screen.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Tap [ ] to select <Settings> and tap [ ].

The <Settings> menu appears.



3. Tap [ ] to select <Display> and tap [ ].

The <Display> menu appears.



4. Use the [ ] and [ ] to set functions.

Display Setting Options

Display Off : If no buttons are tapped within the time set shown below, the



screen display will automatically be turned off. Select either <15 sec>, <30 sec>, <1 min>, <3 min>, <5 min> or <Always On>. Press any button to turn it back on.

Brightness : You can adjust the brightness of the display screen. Select a level



from <0-10>, where 10 is the brightest.

Settings

Menu Style Sound

Display

Language Date & Time System

the basics _ 25

CHANGING THE SETTINGS AND PREFERENCES (Continued)

Language Settings

The menus on your new mp3 player can be set to appear in any one of multiple languages. You can change your preference language easily.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Tap [ ] to select <Settings> and tap [ ].



The <Settings> menu appears.

3. Tap [ ] to select <Language> and tap [ ].

The <Language> list appears.



<English>, <한국어>, <Français>, <Deutsch>,



<Italiano>, <日本語>, <ㅔԧЁ᭛>, <㐕储Ё᭛>, <Español>, <Ɋɭɫɫɤɢɣ>, <Magyar>, <Nederlands>, <Polski>, <Português>, <Svenska>, <ѳъѕ>, <ýeština>, <ƧǌǌǈǎǊǋƽ>, <Türkçe>, <Norsk>, <Dansk>, <Suomi>, <Español (Sudamérica)>, <Português (Brasil)>, <Indonesia>, <TiӃng ViӋt>, <Bulgarian>, <Română>, <ɍɤɪɚʀɧɫɶɤɚ>, <Slovenšþina>, <Slovenský>.

4. Tap [ ] to select a desired language and tap [ ].

The supported languages can be changed or added.



NOTE

Settings

Menu Style Sound Display

Language

Date & Time System

26 _ the basics

CHANGING THE SETTINGS AND PREFERENCES (Continued)

Date&Time Settings

You can set the current time and date.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Tap [ ] to select <Settings> and tap [ ].



The <Settings> menu appears.

3. Tap [ ] to select <Date&Time> and tap [ ].

The <Date&Time> screen appears.



4. Tap [ ] to move to <Year, Month, Date, Hour, Min, AM/PM> and tap [ ] to set each item.

5. Tap [ ].

6. Tap [ ] to select <Yes> and tap [ ].

The time setting is completed.



Settings

Menu Style Sound Display Language

Date & Time

System

the basics _ 27

CHANGING THE SETTINGS AND PREFERENCES (Continued)

System Settings

Choose the sleep timer, start mode, auto power off, default setting that’s right for you.

1. Press and brieﬂ y hold [ ] to move to the main menu screen.

Tap [ ] to select <Settings> and tap [ ].

The <Settings> menu appears.



3. Tap [ ] to select <System> and tap [ ].

The <System> menu appears.



4. Use the [ ] and [ ] to set functions.

Settings

Menu Style Sound Display Language Date & Time

System

28 _ the basics

CHANGING THE SETTINGS AND PREFERENCES (Continued)

System Setting Options

My Proﬁ le : You can set your name and birth date. See page 30.



Sleep : Turns off power automatically after the preset time. Select either <Off>,



<15min>, <30min>, <60min>, <90min>, or <120min>.

Start Mode : You can set the start screen displayed when you turn on the



player. Select from <Main Menu> and <Last State>. Select <Main Menu> to start the system with the main menu screen while <Last State> will use the last used menu screen.



Auto Power Off : Automatically turns power off when there is no button operation after the preset time in the pause mode. Select either <15sec>, <30sec>, <1min>, <3min>, <5min> or <Always On>.



Default Set : Returns all settings to the default value. Select either <Yes> or <No>. <Yes> initializes all settings to default. <No> cancels default settings.



Format : Formats the internal memory. Select either <Yes> or <No>. Selecting <Yes> will format the internal memory and delete all ﬁ les on the player. Selecting <No> does not format the internal memory. Check before formatting it.



About : Tap [ number. <Firmware Version> displays the current ﬁ rmware version. <Memory> - <Used> indicates the usage, <Available> indicates the remaining

<Files> - You can check the number of music ﬁ les, videos, pictures, texts and

Regarding the Built-In Memory



1GB=1,000,000,000 bytes : actual formatted capacity may be less as the

NOTE

internal ﬁ rmware uses a portion of the memory.

] to check the ﬁ rmware version, memory capacity and ﬁ le

capacity and <Total> indicates the total memory capacity.

entire ﬁ les.

the basics _ 29

CHANGING THE SETTINGS AND PREFERENCES (Continued)

My Name Settings

Tap [ ] to select <My Proﬁ le> and tap [ ].

Tap [ ] to select <My Name> and tap [ ].

The Rename My Name window appears.



Use [ ] and [ ] to rename the device.

[ ] : The input mode switches from uppercase



English to lowercase English and to number.

] : You can delete the characters one at a time.

[



[

] : Conﬁ rm your change.



Once you completed the name setting, you will see your name when you



turn on or off the player.

My Birthday Settings



Before you start - First, you should set the clock for the current time. See

Tap [ ] to select <My Proﬁ le> and tap [ ].

Tap [ ] to select <My Birthday> and tap [ ].



The Edit My Birthday window appears.

Tap [ ] to move to <Year, Month, Date> and tap

page 27.

[ ] to set each item.

4. Tap [ ].

Once you completed the birth date settings, you will be



reminded of your birthday when you turn on the player.

Rename My Name

YP-T10_

Edit My Birthday

30 _ the basics

+ 83 hidden pages
