Page 1
XNV-6081R / XNV-8081R
2 MP/5 MP Network IR Dome Camera
Key Features
2 Megapixel & 5 Megapixel resolution
•
• 0.015Lux@F1.4 (Color), 0Lux (B/W, IR LED on) (XNV-6081R)
0.07Lux@F1.4 (Color), 0Lux (B/W, IR LED on) (XNV-8081R)
• Day & Night (ICR), WDR (150dB / 120dB)
• Hallway View, WiseStreamII Support
Video & Audio analytics, Audio playback
•
• DIS and shock detection with built-in gyro sensor
• Modular structure, PoE, 12VDC, 24VAC (Optional)
IP66/IP67, IP6K9K, IK10+, NEMA4X
•
Dimensions Accessories (Optional)
Unit : mm (inch)
125(4.9")
Ø180(7.1")
FIRST EDITION 042019 © 201 9 Hanwha Techwin Co., Ltd. All rights reserved.
SBP-187HMW (White) /
SBP-187HM
SBC-180B SPC-100AC
Page 2
XNV-6081R
VIDEO
Imaging Device
Eective Pixels 1945(H) x 1097(V) 2616(H) x 1976(V)
Minimum Illumination
Video Out
LENS
Focal Length (Zoom Ratio) 2.8~12mm (4.3x) motorized varifocal 3.9~9.4mm (2.4x) motorized varifocal
Maximum Aperture Ratio
Angular Field of View
Minimum Object Distance
Focus Control Simple focus
Lens Type
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range 0˚~360˚ / -45˚~85˚ / 0˚~355˚
OPERATIONAL
IR Viewable Length
Camera Title Displayed up to 85 characters
Day & Night Auto (ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range 150dB 120dB
Digital Noise Reduction SSNR
Digital Image Stabilization Support (built-in gyro sensor)
Defog Support
Motion Detection
Privacy Masking
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti icker (2~1/12,000sec)
Digital PTZ Support (Preset, Group)
Video Rotation Flip, Mirror, Hallway view (90˚/270˚)
Analytics
Business Intelligence People counting, Queue management, Heatmap
Alarm I / O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events
Audio In
Audio Out Line out, Max. output level : 1Vrms
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression H.265/H.264 : Main / Baseline / High, MJPEG
1/2.8" 2 MP CMOS 1/1.8" 6 MP CMOS
Color : 0.015Lux (F1.4, 1./30sec)
BW : 0Lux (IR LED on)
CVBS : 1.0 Vp-p / 75 composite, 720 x 480(N), 720 x 576(P) for installation
USB : Micro USB Type B, 1280 x 720 for installation
F1.4(Wide) ~ F3.6(Tele) F1.3
H : 119.5°(Wide)~27.9°(Tele) /
V : 62.8°(Wide)~15.7°(Tele) /
D : 142.1°(Wide)~32.0°(Tele)
0.5m (1.64ft)
DC auto iris, P-iris
50m (164.04ft)
V
8ea, 8-point polygonal zones
32ea, polygonal zones
- Color : Grey / Green / Red / Blue / Black / White
- Mosaic
Defocus detection, Fog detection, Face detection, Motion detection, Digital auto tracking,
Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line/ Directional detection,
Audio detection, Sound classification, Shock detection
File upload via FTP and e-mail
Notication via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover
Audio playback
Selectable (mic in/line in),
Supply voltage : 2.5VDC (4mA), Input impedance : 2K Ohm
Color : 0.07Lux (F1.2, 1/30sec)
BW : 0Lux (IR LED on)
H : 92.1˚(Wide)~38.7˚(Tele) /
V : 67.2˚(Wide)~29.0˚(Tele) /
D : 119.9˚(Wide)~48.6˚(Tele)
XNV-8081R
FIRST EDITION 042019 © 201 9 Hanwha Techwin Co., Ltd. All rights reserved.
Page 3
XNV-6081R
1920 x 1080, 1280 x 1024, 1280 x 960,
1280 x 720, 1024 x 768, 800 x 600, 800 x 448,
Resolution
720 x 576, 720 x 480, 640 x 480, 640 x 360,
320 x 240
Maximum Framerate
Smart Codec Manual (5ea area), WiseStream
Video Quality Adjustment
Bitrate Control
Streaming
H.265/H.264 : Max. 60fps / 50fps (60Hz/50Hz)
MJPEG : Max. 30fps / 25fps (60Hz/50Hz)
II
H.264/H.265 : Target bitrate level control
MJPEG : Target bitrate level control
H.264/H.265 : CBR or VBR
MJPEG : VBR
Unicast (20 users) / Multicast
Multiple streaming (Up to 10 proles)
G.711 u-law / G.726 Selectable
Audio Compression
G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC : 48Kbps at 16KHz
Protocol
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP
HTTPS (SSL) login authentication
Digest login authentication
Security
IP address ltering
User access log
802.1X authentication (EAP-TLS, EAP-LEAP)
Edge Storage
Micro SD/SDHC/SDXC 2 slots 512GB
ONVIF Prole S/G
Application Programming Interface
SUNAPI (HTTP API)
Wisenet open platform
Webpage Language
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,
Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Web Viewer
Recommended Browser : Google Chrome
Supported Browser : MS Explorer11, MS Edge, Mozilla Firefox(Windows 64bit only),
Apple Safari (Mac OS X only)
Memory 1024MB RAM, 256MB Flash
ENVIRONMENTAL
Operating Temperature / Humidity
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
* Start up should be done at above -35°C
Storage Temperature / Humidity -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Certication
IP66/IP67, IP6K9K, IK10+, NEMA4X
ELECTRICAL
Input Voltage PoE (IEEE802.3af, Class3), 24VAC (Optional), 12VDC
PoE : Max 12.95W, typical 10.3W
Power Consumption
12VDC : Max 10.8W, typical 8.4W
24VAC : Max 13.3W, typical 10.4W
MECHANICAL
Color / Material White / Aluminum
RAL Code RAL9003
Product dimensions / weight Ø180x125mm(7.09x4.92"), 1.75Kg(3.86 lb)
Conduit hole 3/4"
Hanging mount (Dome)
Skin cover (Dome) / Weather Cap
Gangplate mounting
SBP-187HMW (White), SBP-187HM (Ivory)
Ivory skin cover included; Optional: SBC-180B (Black) / Included Weather Cap (White)
Single, Double, 4" Octagon, Square
Power module SPC-100AC
The lastest product information / specification can be found at hanwhasecurity.com
*
* Design and specications are subject to change without notice.
* Wisenet is the proprietary brand of Hanwha Techwin.
FIRST EDITION 042019 © 201 9 Hanwha Techwin Co., Ltd. All rights reserved.
2560 x 1920, 2560 x 1440, 1920 x 1080,
1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720, 1024 x 768, 800 x 600, 800 x 448,
720 x 576, 720 x 480, 640 x 480, 640 x 360,
320 x 240
H.265/H.264 : Max. 30fps / 25fps (60Hz/50Hz)
MJPEG : Max. 30fps / 25fps (60Hz/50Hz)
PoE : Max 12.95W, typical 10.9W
12VDC : Max 11.7W, typical 8.9W
24VAC : Max 14.9W, typical 11.3W
XNV-8081R
