Samsung WEP301 User Manual
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Português. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
E
li
h
Contents
Safety and usage information....................................................2
Your headset overview .............................................................3
Charging the headset ...............................................................4
Turning the headset on or off ....................................................4
Understanding various modes....................................................5
Pairing with your Bluetooth phone..............................................5
Using call features ...................................................................6
Safety approvals......................................................................7
UL certified travel adapter.........................................................8
Cautions.................................................................................9
Warranty and parts replacement.............................................. 10
Correct disposal of this product ............................................... 11
Specifications........................................................................ 12
ng
s
1
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc.
worldwide. Bluetooth QD ID: B012977
Safety and usage information
• Never disassemble or modify your headset for any reason.
Doing this may cause the headset to malfunction or become
combustible. Bring the headset to an authorized service
center to repair it or replace the battery.
• When using your headset while driving, follow local
regulations in the country or region you are in.
• Avoid storage at high temperatures (above 50° C/122° F),
such as in a hot vehicle or in direct sunlight, as this can
damage performance and reduce battery life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids.
At very high volumes, prolonged listening to the
headset can damage your hearing.
2
E
li
h
Your headset overview
Ear hook
Volume up
button
Multi-function
button
Vol ume do wn
button
ng
s
Microphone
Indicator
light
• If your headset responds slowly, stops responding, or
freezes, press the reset button on the back of the
headset with a pointed tool.
• Depending on which ear you will wear the headset,
simply adjust the ear hook accordingly.
Left
Earpiece
Reset button
Right
3
Charging the headset
Put the adapter into the jack on the headset
and into the electrical outlet.
Charge the headset until the red indicator
light turns blue.
Do not attempt to charge the headset with anything
other than the adapter provided.
You can use your headset while charging.
Turning the headset on or off
To turn the headset on, press and hold the Multi-function
button until the blue indicator light flashes 4 times.
To turn the headset off, press and hold the Multi-function
button until both blue and red indicator lights flash.
4
E
li
h
Understanding various modes
•
Standby mode
indicator light flashes every 3 seconds.
•
Active mode
indicator light flashes every 8 seconds.
•
Pairing mode
discover and connect to your headset on your phone.
•
Low battery mode
power left. The red indicator light flashes. You must
recharge the battery.
: The headset is waiting for a call. The blue
: The headset has a call in progress. The blue
: The blue indicator light stays lit. You can
: There is less than 10% of battery
Pairing with your Bluetooth phone
1 Enter Pairing mode.
• Turn off your headset and press and hold the Multifunction button until the blue indicator light remains lit
after blinking.
• If you turn it on for the first time, it proceeds into Pairing
mode immediately.
2 Search for and pair with your phone according to your
phone's user guide. (Bluetooth PIN: 0000, 4 zeros)
ng
s
5
• If the pairing is successful, the blue indicator light will
flash 10 times rapidly before entering Standby mode.
• If the blue indicator light remains lit, retry pairing.
When the headset and the phone are paired, the
headset attempts to reconnect automatically each
time it turns on. Otherwise, press the Multi-function
button to reconnect.
Using call features
Some features may not be supported by your phone.
In Standby mode
Press the Multi-function button to:
• Answer an incoming call
• Redial the last number called
Press and hold the Multi-function button to:
• Make a voice-activated call
• Reject an incoming call
Press and hold [+] and [-] at the same time to turn the
indicator light on or off.
6
E
li
h
In Active mode
Press the Multi-function button to:
• End a call
• Transfer a call from the phone to the headset
Press and hold the Multi-function button to:
• Place a call on hold
• Answer a second call
• Retrieve a call on hold
Press [+] or [-] to adjust the volume.
Press and hold [+] or [-] to turn the microphone off or on.
Safety approvals
FCC
FCC ID: A3LWEP300
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The device and its antenna must not be co-located or operating
in conjunction with any other antenna or transmitter.
ng
s
7
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment.
Industry Canada
IC ID: 649E-WEP300
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may cause
undesired operation of the device.
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry Canada
approved the equipment.
UL certified travel adapter
The travel adapter for this headset has met applicable UL safety
requirements. Please adhere to the following safety instructions
per UL guidelines.
8
E
li
h
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD
TO SERIOUS PERSONAL INJURY AND POSSIBLE PROPERTY
DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN THE U.S.A., USE AN
ATTACHMENT PLUG ADAPTOR OF THE PROPER
CONFIGURATION FOR THE POWER OUTLET.
THIS POWER UNIT IS INTENDED TO BE CORRECTLY
ORIENTATED IN A VERTICAL, HORIZONTAL, OR FLOOR MOUNT
POSITION.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s authority
to operate the equipment. Only use approved batteries,
antennas and chargers. The use of any unauthorized
accessories may be dangerous and void the phone warranty if
said accessories cause damage or a defect to the phone.
ng
s
9
Although your phone is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting, bending
or sitting on it.
Warranty and parts replacement
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase. (Depending on your country, the
length of warranty may vary.)
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation modification, or
repair by unauthorized third parties
10
E
li
h
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorized third parties voids any warranty
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling.
ng
s
11
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
Specifications
Item Specifications and description
Versions Compatible with Bluetooth 2.0 or
Profile Headset Profile, Hands-Free Profile
Operating range Up to 30 feet (10 meters)
Maximum Standby
time
Maximum Active time Up to 5 hours
* Depending on the phone type and usage, the actual time may
vary.
12
earlier
Up to 80 hours*
*
F
i
Table des matières
Information sur l'utilisation et la sécurité .................................. 14
Aperçu de l'oreillette .............................................................. 15
Chargement de l'oreillette.......................................................16
Mise en marche et fermeture de l'oreillette................................ 17
Compréhension des divers modes............................................ 17
Synchronisation de l'oreillette avec un téléphone Bluetooth ......... 18
Utilisation des fonctions d'appel............................................... 19
Agréments de sécurité............................................................ 20
Adaptateur de voyage conforme aux normes UL.........................22
Mises en garde...................................................................... 23
Garantie et remplacement des pièces ....................................... 23
Mise au rebut appropriée de ce produit.....................................25
Caractéristiques techniques..................................................... 26
rança
s
13
Bluetooth® est une marque déposée de Bluetooth SIG Inc. à
l'échelle mondiale. Bluetooth QD ID: B012977
Information sur l'utilisation et la sécurité
• Il ne faut jamais démonter ou modifier votre oreillette quelle
qu'en soit la raison. Cela risquerait d'entraîner le
dysfonctionnement de l'oreillette ou de la rendre
combustible. Veuillez vous rendre dans un centre de service
autorisé pour faire réparer l'oreillette ou pour remplacer la
pile.
• Lorsque vous utilisez votre oreillette en conduisant, veuillez
respecter les règles du pays ou de la région où vous vous
trouvez.
• Évitez de ranger l'oreillette dans des endroits à température
élevée (plus de 50 °C/122 °F), notamment dans un véhicule
stationné au soleil ou directement sous les rayons du soleil,
car cela pourrait nuire au fonctionnement et réduire la durée
de vie de la pile.
•
N'exposez pas l'oreillette ou ses accessoires à la pluie ou à
d'autres liquides.
14
F
i
Une utilisation prolongée de l'oreillette à un très
haut volume peut endommager votre ouïe.
Aperçu de l'oreillette
Crochet
auriculaire
Touche pour
augmenter
le volume
Microphone
Témoin
lumineux
Touche
multifonction
Touche pour
diminuer le
volume
▲
Gauche
▲
Droite
Left
Écouteur
Touche de
réinitialisation
rança
s
Right
15
Loading...
