Washing Machine

user manual

WA456* WA422* WA400*

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service or accessory

parts, please register your product at or contact

www.samsung.com/register

1-800-SAMSUNG (726-7864)

key features of your new washer

1. Large Capacity

Even bulky garments and blankets get super clean. Samsung’s large capacity washer provides the room clothes need for a more thorough, cleaner wash.

2. AquaJet

AquaJetTM washes loads gently and more thoroughly than conventional top loaders.Faster drum rotation and the absence of an agitator inside the machine help circulate foam more evenly throughout all your clothes, while powerful water jets provide a thorough rinse.

3. Digital Inverter Motor

The power to handle anything! Our direct-drive inverter motor delivers power right to the washer tub from a variable speed, reversible motor. The beltless direct-drive motor generates a higher spin speed for more eective, quiet operation. The washer also has fewer moving parts, meaning fewer repairs.

4. Mist Shower

A separate nozzle sprays water equally throughout the tub so that the rinse cycle is eective even with a small amount of water.

5. VRT® (Vibration Reduction Technology)

This Samsung washer performs smoothly at top spin speeds, minimizing noise and vibration.

6. Eco Plus (WA456*)

If you select this option, the water temperature is set to slightly lower than during the normal wash course to save energy.

(WA456*)

7. Pure Cycle™ (Tub Cleaning Cycle)

Clean your drum with one button! Pure Cycle is specially designed to remove detergent residue and dirt bulidup in the tub, without the need for special chemical detergents.

8. My Cycle

This is a convenient function that enables you to save a frequently-used wash course. Once this is set, you can do a wash simply by pressing the Power, My Cycle, and Start buttons in sequence.

9. Smart Care (WA456*)

Samsung’s Smart Care, an automatic error-monitoring system, detects and diagnoses problems at an early stage and provides quick and easy solutions.

2_ key features of your new washer

safety information

Congratulations on your new Samsung Washer. This manual contains important information on the installation, use, and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many beneﬁts and features.

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washer.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

What the icons and signs in this user manual mean:

Hazards or unsafe practices that may result in severe personal injury

WARNING

or death. To reduce the risk of ﬁre, explosion, electric shock, or personal injury

when using your washer, follow these basic safety precautions:

CAUTION

These warning icons are here to prevent injury to you and others. Please heed them explicitly. After reading this section, keep it in a safe place for future reference.

Read all instructions before using the appliance.

Hazards or unsafe practices that may result in minor personal injury or property damage.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric shock.

Call the service center for help.

Note

SAVE THESE INSTRUCTIONS

safety information _3

safety information

WARNING: To reduce the risk of ﬁre, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following:

WARNING

1. Read all instructions before using the appliance.

2. Do not wash or dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other ﬂammable or explosive substances as they give o vapors that could ignite or explode.

3. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the appliance is used near children.

4. Before the appliance is removed from service or discarded, remove the lid of the washing or drying compartment.

5. Do not reach into the appliance if the drum is moving.

6. Do not install or store this appliance where it will be exposed to the weather.

7. Do not tamper with the controls.

8. Do not repair or replace any part of the appliance or attempt any servicing unless it is speciﬁcally recommended in the user-maintenance instructions or in published userrepair instructions that you understand and have the skills to carry out.

9. Do not add gasoline, dry-cleaning solvents, or other ﬂammable or explosive substances to the wash water. These substances give o vapors that could ignite or explode.

10. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for 2 weeks or more, before using a washer or combination washer-dryer, turn on all hot water faucets and let the water ﬂow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is ﬂammable, do not smoke or use an open ﬂame during this time.

State of California Proposition 65 Warnings:

WARNING

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances known to the State of California to cause cancer, birth defects, or other reproductive harm, and requires businesses to warn of potential exposure to such substances. This product contains a chemical known to the State of California to cause cancer, birth defects, or other reproductive harm. This appliance can cause low-level exposure to some of the substances listed, including benzene, formaldehyde, and carbon monoxide.

SAVE THESE INSTRUCTIONS

4_ safety information

CRITICAL INSTALLATION WARNINGS

WARNING

Plug the power cord into an AC 120 V / 60 Hz/wall socket rated at 15 amps or higher. Use the socket for this appliance only. In addition, do not use an extension cord.

- Sharing a wall socket with other appliances, using a power strip, or extending the power cord may result in electric shock or ﬁre.

- Do not use an electric transformer. It may result in electric shock or ﬁre.

- Ensure that the power voltage, frequency, and current match the product’s speciﬁcations. Failing to do so may result in electric shock or ﬁre.

Have this appliance installed by a qualiﬁed technician or service company.

- Failing to do so may result in electric shock, ﬁre, an explosion, problems with the product, or injury.

Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis.

- Unplug the power plug and clean it with a dry cloth.

- Failing to do so may result in electric shock or ﬁre.

Plug the power plug into the wall socket in the right direction so that the cord runs towards the ﬂoor.

- If you plug the power plug into the socket in the opposite direction, the electric wires within the cable may be damaged and this may result in electric shock or ﬁre.

This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- Improper grounding may result in electric shock, ﬁre, an explosion, or problems with the product

- Never plug the power cord into a socket that is not grounded correctly. Make sure the socket you use is grounded in accordance with local and national codes.

Do not install this appliance near a heater or inﬂammable material. Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to direct sunlight or water (rain drops). Do not install this appliance in a location where gas may leak.

- This may result in electric shock or ﬁre.

Plug the power plug into the wall socket ﬁrmly. Do not use a damaged power plug, damaged power cord, or loose wall socket.

- This may result in electric shock or ﬁre.

Do not pull or excessively bend the power cord. Do not twist or tie the power cord. Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

- This may result in electric shock or ﬁre.

Do not pull the power cord when unplugging the power plug.

- Unplug the power plug by holding the plug.

- Failing to do so may result in electric shock or ﬁre.

If the power plug or power cord are damaged, contact your nearest service center.

SAVE THESE INSTRUCTIONS

safety information _5

safety information

INSTALLATION CAUTIONS

CAUTION

Position the appliance so that the power plug is easily accessible.

- Failing to do so may result in electric shock or ﬁre due to electric leakage. Install your appliance on a level and hard ﬂoor that can support its weight.

- Failing to do so may result in abnormal vibrations, noise, or problems with the product.

Unplug the power plug when the appliance is not being used for long periods of time or during a thunder/lightning storm.

- Failing to do so may result in electric shock or ﬁre.

CRITICAL USAGE WARNINGS

WARNING

If the appliance is ﬂooded, cut the power immediately and contact your nearest service center. If the appliance emits a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact your nearest service center.

- Failing to do so may result in electric shock or ﬁre. In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area

immediately. Do not turn any appliance or light on or o.

- Do not use a ventilating fan.

- A spark may result in an explosion or ﬁre. Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or

other ﬂammable or explosive substances.

- This may result in electric shock, ﬁre, or an explosion. Do not force the washer lid open while the washer is operating (high-temperature washing/ drying/spinning).

- Water ﬂowing out of the washer may cause burns or cause the ﬂoor to be slippery. This may result in injury.

- Forcing the lid open can damage the product or cause injury.

Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washer before using it.

Do not insert your hand under the washer.

- This may result in injury.

SAVE THESE INSTRUCTIONS

6_ safety information

Do not touch the power plug with wet hands.

- This may result in electric shock. Do not turn the appliance o by unplugging the power plug while the washer is in operation.

- Plugging the power plug into the wall socket again may cause a spark and result in electric shock or ﬁre.

Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.

- If a child places a bag over its head, it may suocate.

Do not let children or inﬁrm persons use this washer unsupervised.

- Failing to do so may result in electric shock, burns or injury.

Do not insert your hand or a metal object under the washer while it is operating.

- This may result in injury.

Do not attempt to repair, disassemble, or modify the appliance yourself.

- Do not use any fuse (such as cooper, steel wire, etc.) other than the standard fuse.

- If you need to repair or reinstall the appliance, contact your nearest service center.

- Failing to do so may result in electric shock, ﬁre, problems with the product, or injury.

If any foreign substance such as water enters the appliance in any area other than the tub, unplug the power plug and contact your nearest service center.

- Failing to do so may result in electric shock or ﬁre.

If the water supply hose comes loose from the faucet and ﬂoods the appliance, unplug the power plug.

- Failing to do so may result in electric shock or ﬁre.

USAGE CAUTIONS

CAUTION

If the washer is contaminated by a foreign substance such as detergent, dirt, food waste, etc., unplug the power plug and clean the washer using a damp, soft cloth.

- Failing to do so may result in discoloration, deformation, damage or rust.

The clear portion of the lid can be broken by a strong impact. Take care when using the

washer.

- If the clear portion is cracked or broken, it may result in injury.

After a water supply failure or when reconnecting the water supply hose, open the faucet slowly. Open the faucet slowly after a long period of non-use.

- The air pressure in the water supply hose or the water pipe may result in damage to a part or in water leakage.

If a drain error occurs during an operation, check if there is a draining problem.

- If the washer is used when it is ﬂooded because of a draining problem, it may result in electric shock or ﬁre due to electric leakage.

Do not insert your hand under the washer.

- This may result in injury.

SAVE THESE INSTRUCTIONS

safety information _7

safety information

Insert the laundry into the washer completely so that laundry does not get caught in the lid.

- If laundry gets caught in the lid, it may result in damage to the laundry or the washer, or result in water leakage.

Ensure that the faucet is turned o when the washer is not being used.

- Ensure that the water supply hose connectors are properly tightened.

- Failing to do so may result in property damage or injury.

Open the faucet and check if the water supply hose connector is ﬁrmly tightened and that there is no water leaking before using the product.

- If the water supply hose connectors are loose, it may result in water leakage.

Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in electric shock, ﬁre, problems with the product, or injury.

Do not operate the appliance with wet hands.

- This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the appliance.

- As well as being harmful to humans, it may also result in electric shock, ﬁre,or problems with the product.

Do not place an object that generates a electromagnetic ﬁeld near the washer.

- This may result in injury due to a malfunction.

Since the water drained during a high-temperature wash or drying cycle is hot, do not touch the water.

- This may result in burns or injury.

Do not wash, spin, or dry water-proof seats, mats, or clothing*.

- Do not wash thick, hard mats even if the washer mark is on the care label. This may result in injury or damage to the washer, walls, ﬂoor, or clothing due to abnormal vibrations.

* Items not to wash: Woolen bedding, rain covers, ﬁshing vests, ski pants, sleeping bags,

diaper covers, sweat suits, and bicycle, motor cycle, car covers, etc.

Do not operate the washer when detergent dispenser is removed.

- This may result in electric shock or injury due to water leakage.

Do not insert your hand into the detergent dispenser after opening it.

- This may result in injury as your hand may be caught.

SAVE THESE INSTRUCTIONS

8_ safety information

Do not place any non-laundry objects, such as shoes, food waste, or animals into the washer.

- This can cause abnormal vibrations that can damage the washer, and, in the case of pets, cause severe injury or death.

Do not press the buttons using sharp objects such as pins, knifes, ﬁngernails, etc.

- This may result in electric shock or injury.

Do not wash laundry contaminated by oils, creams, or lotions usually found in skincare shops or massage clinics.

- This may result in the rubber seal becoming deformed and water leakage.

Do not leave metal objects (safety pins, hair pins, etc.) or bleach in the tub for long periods of time.

- This may cause the tub to rust.

- If rust appears on the surface of the tub, apply a neutral cleansing agent to the surface and use a sponge to clean it. Never use a metal brush.

Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry contaminated by dry cleaning detergent.

- This may result in spontaneous combustion or ignition due to heat from the oxidation of the oil.

Do not use hot water from water cooling/heating devices.

- This may result in problems with the washer.

Do not use natural hand-washing soap in the washer.

- If it hardens and accumulates inside the washer, it may cause problems with the product, discoloration, rust, or bad odors.

Do not wash large laundry items such as bedding in the washing net.

- Failing to do so may result in injury due to abnormal vibrations.

- Place smaller items, such as lace socks and lingerie in the washing net.

Do not use hardened detergent.

- If it accumulates inside the washer, it may result in water leakage.

Do not wash throw rugs or doormats.

- If you wash throw rugs or doormats, the sand will accumulate inside the washer. It may result in error such as no draining.

CRITICAL CLEANING INSTRUCTIONS

WARNING

Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, or alcohol to clean the appliance.

- This may result in discoloration, deformation, damage, electric shock, or ﬁre.

Before cleaning or performing maintenance, unplug the appliance from the wall socket.

- Failing to do so may result in electric shock or ﬁre.

SAVE THESE INSTRUCTIONS

safety information _9

contents

INSTALLING YOUR WASHER

OPERATING INSTRUCTIONS

WASHING A LOAD OF LAUNDRY

11 Unpacking your washer 11 Overview of your washer 12 Basic location requirements

12 Electrical 12 Grounding 12 Water 13 Drain facility 13 Flooring 13 Location considerations 13 Alcove or closet installation 14 Required dimensions for Installation

14 Important note to installer

18 Loading your washer 18 Getting started

19 Overview of the control panel

21 Child Lock [ ] 22 Signal 22 Garment+ 22 My Cycle 22 Delay Start 23 Pre Soak 23 AquaJetTM (WA456*) 23 Eco Plus (WA456*) 23 Mist Shower 23 Smart Care (WA456*) 24 Washing clothes using the cycle selector

25 Detergent use 25 Features

MAINTAINING YOUR WASHER

10_ contents

TROUBLESHOOTING

APPENDIX

28 Cleaning the exterior 28 Cleaning the interior 28 Storing your washer 28 Preserving the top cover and the front frame 29 Cleaning the dispensers 30 Pure Cycle

31 Check these solutions if your washer… 33 Information codes

35 Fabric care chart 36 Cycle chart 38 Helping the environment 38 Declaration of conformity 38 Speciﬁcation

installing your washer

UNPACKING YOUR WASHER

Unpack your washer and inspect it for shipping damage. Make sure you have received all the items shown below. If your washer was damaged during shipping, or you do not have all of the items, contact 1-800-SAMSUNG (1-800-726-7864).

To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

Packing materials can be dangerous to children; Keep all packing material (plastic bags, polystyrene, etc.) well out of childrens’ reach.

WARNING

OVERVIEW OF YOUR WASHER

01 installing your washer

Drain Hose

Power Cord

Adjustable legs

Parts supplied

Hose guide User manual book Plastic zip hose tie Water intake cap

Tools needed

Control panel

Lid

Wrench Flat screwdriver Level

Parts not supplied

Water supply hoses

• Ifyouloseanaccessoryandwanttopurchaseareplacement,contactthe

Samsung service center (1-800-SAMSUNG (1-800-726-7864)).

• Thedesignofthepartsandaccessoriesmaydierfromthepicturesabove.

Their design is subject to change without notice for product improvement.

• Donotreuseoldhoses.Onlyusenewwatersupplyhoseswhenyouinstallthe

washing machine. Old water supply hoses can leak or burst causing ﬂooding and property damage.

• Conrmthattherearerubberwashersinsideeachcouplingofthewater

supply hoses.

installing your washer _11

installing your washer

BASIC LOCATION REQUIREMENTS

Electrical

• 120 Volt 60 Hz 15 AMP fuse or circuit breaker

• Individual branch circuit serving only your Washer is recommended.

• Your Washer is equipped with a power cord.

NEVER USE AN EXTENSION CORD.

CAUTION

Grounding

ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE.

This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.

This appliance is equipped with a power cord having a three-prong grounding plug for use in a properly installed and grounded outlet.

The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

An improperly connected equipment-grounding conductor can increase the risk of electrical shock. Check with a qualiﬁed electrician or serviceman if you are not sure whether the

WARNING

appliance is properly grounded. Do not modify the plug provided with the appliance – if it does not ﬁt the outlet, have a proper outlet installed by a qualiﬁed electrician.

IMPORTANT SAFETY PRECAUTIONS

• To prevent unnecessary risk of ﬁre, electrical shock or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. It is the personal responsibility of the appliance owner to provide adequate electrical service for this appliance.

NEVER CONNECT THE GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES, OR HOT WATER PIPES.

CAUTION

Water

To correctly ﬁll your Washer in the proper amount of time, water pressure of 20 to 116psi (137 to 800kPa) is required.

Water pressure less than 20 psi may cause water valve failure, or may not allow the water valve to shut o completely, or may extend the ﬁll time beyond what your Washer controls allow, causing your Washer to turn o. A time limit is built into the controls to prevent ﬂooding in your home if a hose becomes loose.

The water faucets must be within 4 feet / 122 cm of the back of your Washer to match the inlet hoses provided with your Washer.

Accessory inlet hoses are available in various lengths up to 10 feet / 275 cm for faucets that are further away from the back of your Washer.

To avoid the possibility of water damage:

• Have water faucets easily accessible

• Turn o faucets when the washer is not in use.

• Periodically check that there is no leakage from the water inlet hose ﬁttings.

CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS.

WARNING

12_ installing your washer

Drain facility

The recommended height of the standpipe is 39 in / 99 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached to the washer at the factory.

Flooring

For best performance, you must install your washer on a solidly constructed ﬂoor. Wood ﬂoors may need to be reinforced to minimize vibration and/or unbalanced load situations. Carpeting and soft tile surfaces are contributing factors to vibration which can cause your washer to move slightly during the spin cycle.

Never install your washer on a platform or weakly supported structure.

Location considerations

Do not install your washer in areas where water may freeze, since your washer will always retain some water in its water valve, pump, and hose areas. Frozen water can damage the belts, the pump, hoses, and other components.

Alcove or closet installation

MINIMUM CLEARANCES FOR CLOSET AND ALCOVE INSTALLATIONS:

Sides – 1 in / 25 mm Rear – 6 in / 152 mm

Gap between end of water valve and the wall

- Case 1. Assemble supply hose after installing : Over 3.9 in (10 cm).

- Case 2. Assemble supply hose before installing : Over 2.8 in (7cm). If the washer and dryer are installed together, the closet front must have at least a 72 in² (465 cm²)

unobstructed air opening. Your washer alone does not require a speciﬁc air opening.

Closet Front – 2 in / 51 mm TOP - 21 in / 533 mm

01 installing your washer

1 in.

(2.5 cm)

1 in.

(2.5 cm)

27.0 in.

(68.6 cm)

A. Recessed area B. Side view - closet or conﬁned area

27.0 in.

(68.6 cm)

1 in.

(2.5 cm)

2 in.

(5.1 cm)

21 in.

(53.3 cm)

Case 1. 3.9 in (10 cm). Case 2. 2.8 in (7 cm).

29.3 in

(74.4 cm)

6 in

(15.2 cm)

installing your washer _13

installing your washer

Required dimensions for Installation

43.9 in

(111.4 cm)

29.3 in

(74.4 cm)

27.0 in.

(68.6 cm)

* Required spacing

39.3in

(99.9 cm)

58.1 in

(147.5 cm)

48 in.² *

(310 cm²)

24 in.² *

(155 cm²)

43.9 in

(111.4 cm)

29.3 in

(74.4 cm)

3 in.

(7.6 cm)

3 in.

(7.6 cm)

Closet or Door

IMPORTANT NOTE TO INSTALLER

Please read the following instructions carefully before installing your washer. These instructions should be retained for future reference. We recommend you hire a professional to install this washer.

STEP 1 Selecting a Location

Before you install the washer, make sure the location:

• Has a hard, level surface without carpeting or ﬂooring that may obstruct ventilation.

• Is away from direct sunlight.

• Has adequate ventilation.

• Is not exposed to freezing temperatures (temperatures under 32 °F or 0 °C).

• Is away from heat sources such as oil or gas.

• Has enough space so that the washer doesn’t rest on its power cord.

14_ installing your washer

STEP 2

Connecting the water and the drain

Connecting the water supply hose

The water supply hoses are not supplied with your washer and must be purchased separately. Before installing the water

CAUTION

supply hoses, make sure there are rubber gaskets inside the ﬁttings at both ends of each new water hose. Installing the water supply hoses without rubber gaskets can cause water leakage.

When you initially install the washer, be sure to use new hoses. Failing to do so may result in a water leakage or overﬂow and

CAUTION

may damage your property. Do not connect multiple water supply hoses together to

increase the length of the supply hose. Hoses connected this

CAUTION

way can leak and the leakage can cause electrical shock. If a hose is too short, replace the hose with a longer, high pressure hose.

1. Connect the ends of the water supply hoses to the HOT and COLD faucets.

2. Tighten the ﬁttings by hand until they are snug, and then tighten them an

additional two-thirds of a turn with a wrench.

When you fasten the ﬁttings, do not fasten them too tightly or apply

CAUTION

tape or sealant to the faucets or water supply intakes. This can damage the ﬁttings.

After you have connected the water supply hoses to the faucets, ensure that they are connected correctly by pulling the water supply hoses downwards

3. Place the unconnected ends of the hoses into a bucket and open

the faucets connected to the two water supply hoses for 10 or 15 seconds to remove any foreign substances from the hoses. Close the faucets before continuing.

Coupling

01 installing your washer

Rubber Washer

Cold Hot

4. Connect the ends of the water supply hoses to the water supply

intake connections at the back of the washer.

The water supply hose connected to the HOT faucet must be

CAUTION

connected to the hot water supply intake and the water hose connected to the COLD faucet must be connected to the COLD water supply intake.

5. Tighten the ﬁttings by hand until they are snug, and then tighten them

an additional two-thirds of a turn with a wrench.

To ensure the correct water usage, connect both the HOT and COLD water faucets. If either or both are not connected, an “nF” (no ﬁll) error can occur.

If you do not want to use the HOT water supply hose, insert the water intake cap into the HOT water supply intake hole. In this case, you must select the Tap Cold option for the water temperature.If you select the Tap Cold option, all the lamps for the water temperature options are turned o.

Conﬁrm that the water supply hoses are not twisted or bent. If

CAUTION

the hoses are twisted or bent, the hoses can leak and cause electric shock due to the water leakage.

6. Turn on the HOT and COLD water supplies and check all the water

supply intake connections and the faucets for water leaks.

installing your washer _15

installing your washer

Connecting the drain hose

The end of the drain hose can be positioned in three ways:

Over the edge of a wash basin

Secure the guide to the side of the basin wall with a hook or to the tap with a piece of string to prevent the drain hose from moving.

In a standpipe or laundry tub

The standpipe must be no shorter than 39 in (99 cm) and no longer than 96 in (245cm).

Make sure that the connection between the drain hose and the standpipe is not airtight.

STEP 3

Leveling your washer

See if the washer is level by checking the position of the tub:

1. Slide the washer into position.

2. Open the lid of the washer, and pour the water into the tub to

just below the pulsator level.

96” Max

39” Min

Laundry tub Stand pipe

Hose

retainer

Tie

strap

Pulsator

39” Min (99 cm)

3. If the washer is level, the pulsator is positioned at the center of the

water as shown in the ﬁgure. If not, level your washer by turning the front leveling feet clockwise or counterclockwise as necessary.

Turn the front leveling feet clockwise to raise the washer, and counterclockwise to lower the washer.

16_ installing your washer

Loosen Lock

Adjustable legs

STEP 4

Powering your washer

Plug the power cord into a 3-prong, well grounded 120 volt 60 Hz approved electrical outlet protected by a 15-amp fuse or comparable circuit breaker.

Your washer is grounded through the third prong of the power cord when plugged into a three-prong grounded electrical outlet.

STEP 5

Running a test cycle

Run a test cycle as follows to check if your washer is properly installed.

1. Load about 6 pounds of laundry into the tub.

2. Press the Power button to turn on your washer.

3. Select the Rinse+Spin cycle by turning the Cycle Selector.

4. Press the Start/Pause button to start the test cycle.

5. The washer should not rock or vibrate excessively when water is supplied or when washing

or spinning, and should drain well during the spin cycle.

If water leaks while water is being supplied or drained, check the water connections. Refer to the “Connecting the water and the drain” section on pages 15~16 for instructions.

If the washer rocks and vibrates excessively, level your washer again. Refer to the “Leveling your washer” section on page 16 for instructions.

01 installing your washer

STEP 6

Calibration mode

Your Samsung washing machine detects the laundry weight automatically. For more accurate weight detection, please run Calibration Mode after the installation. To run Calibration Mode, follow these steps:

1. Remove laundry or any contents in the machine and turn on the machine.

2. On the WA456, press the Delay Start and Eco Plus buttons simultaneously, and then press

the Power button. On the WA422 or WA400, press the Delay Start and Pre Soak buttons simultaneously, and then press the Power button. The machine turns on.

3. Press the Start/Pause button to activate “Calibration Mode”.

4. The pulsator rotates clockwise and counterclockwise for approximately 1 minute.

5. When “Calibration Mode” is ﬁnished, “End” (WA456*) / “En” (WA422*, WA400*) appears on

the display, and the machine automatically turns o. The washing machine is now ready for use.

installing your washer _17

operating instructions

WARNING: To reduce the risk of ﬁre, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following:

WARNING

LOADING YOUR WASHER

• You can ﬁll the tub with dry, unfolded clothes, but DO NOT OVERLOAD the tub, No more than 3/4 full.

• Overloading may reduce washing eciency, cause excess wear, and possibly cause creasing or

wrinkling of the load.

• Wash delicate items such as bras, hosiery, and other lingerie in the Delicates/Hand Wash cycle with similar lightweight items.

• When washing big bulky items or a few smaller items that don’t ﬁll the tub completely – a rug, a pillow, stued toys, or one or two sweaters, for example – add a few towels to improve spin performance.

• Do not insert bulky items except for Bedding in this cycle.

During the spin cycle, the washer may add additional water to redistribute the clothes and correct an imbalance inside the drum.

• When washing heavily soiled loads, do not overload your washer to ensure good cleaning results.

• To add a forgotten item:

1. Press the Start/Pause button to pause the washer.

2. Wait for the door to unlock automatically, and then open the door.

3. Add the item, close the door, and then press the Start/Pause button. The cycle will resume.

GETTING STARTED

1. Load your washer.

2. Add liquid (or powder) detergent and additives to the dispenser (see pages 25~27).

3. Select the appropriate cycle and options for the load (see pages 19~24).

4. Close the lid.

5. Press the Start/Pause button.

6. The Wash Indicator light illuminates.

7. The estimated cycle time will appear in the display.

The time may ﬂuctuate to indicate the time remaining in the cycle better.

The actual time required for a cycle may dier from the estimated time in the display depending on the water pressure, water temperature, detergent, and laundry.

8. Before your washer starts to ﬁll, it will make a series of clicking noises to check the door lock and do a quick drain.

• When the cycle is complete, the Door Lock light will go out and “End” (WA456*) / “En” (WA422*,WA400*) will appear in the display.

• Pressing the Power button cancels the cycle and stops your washer.

•

The Wash, Rinse ,and Spin indicator lights will illuminate during those portions of the cycle.

18_ operating instructions

washing a load of laundry

OVERVIEW OF THE CONTROL PANEL

WA456*

03 washing a load of laundry

WA422*/WA400*

Cycle Selector

Select the appropriate cycle for the type of load. The cycle you select determines the tumble pattern and spin speed for the

cycle.

To minimize wrinkling of laundry, select the Perm Press cycle.

Normal - For most fabrics including cottons, linens, and normally soiled garments.

Heavy Duty - For sturdy, colorfast fabrics and heavily soiled garments. Colors/Darks (WA456*) - For brightly or dark colored casual garments. Bedding - For bulky items such as blankets and sheets. When you are

washing comforters, use liquid detergent.

Spin - Drains the water and spins at a high speed. Rinse + Spin - Use for loads that need rinsing only or to add rinse-added

fabric softener to a load. Perm Press - For wash-and-wear, synthetic fabrics, and lightly to normally

soiled garments. Active Wear (WA456*) - Use this cycle to wash exercise wear such as sports

jerseys, training pants, shirts/tops and other performance clothing. This cycle provides eective soil removal with gentle action for special fabric care.

Delicates/Hand Wash - For sheer fabrics, bras, lingerie, silks, and other handwash-only fabrics. For best results, use liquid detergent.

Quick Wash - For lightly soiled garments needed quickly. Pure CycleTM - Use to clean dirt and bacteria from the drum. Regular use

(after every 20 washes) is recommended. No detergent or bleach is needed (see page 30).

43 5 6

8 9

washing a load of laundry _19

washing a load of laundry

Display

Temperature

selection button

Spin selection

button

Soil Level

selection button

Select Cycle

Option

Provides instructions and diagnostics while keeping you updated on the cycle status and time remaining.

Press the button repeatedly to cycle through the dierent water temperature options.

Hot - Whites and heavily soiled, colorfast items. Warm - Colorfast items. Eco Warm - Moderately soiled, colorfast items; most wrinkle-free items. Cold - Brightly colored, very lightly soiled items. Tap Cold - Cold water with no warm water added.

 If you select the Tap Cold option, all the lamps for the water

temperature options are turned o.

Press the button repeatedly to cycle through the dierent spin speed options.

High - Use for underwear, t-shirts, jeans, and sturdy cottons. Medium - Use for jeans, wrinkle-free or wash-and-wear items, and

synthetics.

Low - Use for delicate items needing a slow spin speed. No Spin - Drains your washer without spinning. Use for extremely delicate

items that cannot tolerate any spin. Press the button to select the soil level/washing time.

Heavy - For heavily soiled loads. Normal - For moderately soiled loads. This setting is best for most loads. Light - For lightly soiled loads.

Press these buttons to select dierent cycle options. Delay Start - Delay the start of any cycle for up to 19 hours in one-hour

increments. Displayed hour indicates the time the wash will be started. Eco Plus (WA456*) – To increase your energy savings on your wash cycles.

(Less hot water consumption)

Pre Soak - Remove stains more thoroughly by specifying additional time. AquaJetTM (WA456*) – Improves the washing & rinsing performance using

falling water Smart Care (WA456*)- Use this function to check if the washing machine

is out of order using your smart phone when the washing machine malfunctions. This function is set if you press and hold the AquaJet™ key for 3 seconds when an error occurs or if you don’t push any buttons when the power is on.

Extra Rinse (WA422*/WA400*) - Add an additional rinse at the end of the cycle to more thoroughly remove laundry additives and perfumes.

Start/Pause

selection button

My Cycle button

Power button

Press to pause and restart cycles.

Press and hold for 3 seconds to Save. Create and/or use a cycle you create with customized temperature, spin, soil level, option, etc.

Press once to turn your washer on. Press again to turn your washer o. If the washer is left on for more than 10 minutes without any buttons being touched, the power automatically turns o.

20_ washing a load of laundry

Child Lock [ ]

Child Lock prevents children from playing with your washer.

Activating the Child Lock function

Press and hold the Spin and Soil Level buttons simultaneously for approximately 3 seconds.

• When you activate the Child Lock function, the “Child Lock [ ]” lamp blinks.

Using the Child Lock function

If the lid is opened when the Child Lock function is on, “ds” is displayed and an alarm sounds.

• If the lid is closed while “ds” is displayed, the alarm sound stops and the information code turns from ”ds” to “CL”.

• If the water level in the tub is above the safe water level, “ds” is displayed on the LED display and the washing machine starts to drain water by force after 30 seconds.

• If the water level in the tub is above the safe water level and the Child Lock function is turned on while the door is open, “CL” is displayed on the LED display even if the power of the washing machine is turned o and the washing machine drains water by force.

• Even if the power of the washing machine is turned o, if the lid is opened while the water level in the tub is above the Reset water level, “CL” is displayed on the LED display without the alarm sounding and the washing machine starts to drain water. When the draining operation ﬁnishes, the power is automatically turned o again.

• After the compulsory drain, the “CL” code display blinks at 1 second intervals and the product enters the “CL” mode. (When the product is in the “CL” mode, only the Power button works.)

• To cancel the “CL” mode, you need to turn the power o and then on again.

• To cancel the “ds” mode, deactivate the Child Lock function. To deactivate the Child Lock

function, press and hold the Spin and the Soil Level buttons simultaneously for at least 3seconds.

Adding laundry when Child Lock is on

• Toaddlaundry,deactivatetheChildLockfunction.TodeactivatetheChildLock

function, press and hold the Spin and the Soil Level buttons simultaneously for at least 3seconds. See “Pause Option” on page 24 for additional details.

03 washing a load of laundry

Deactivating the Child Lock function

Press and hold both the Spin and Soil Level buttons simultaneously for approximately 3seconds.

• When you deactivate the Child Lock function, the “Child Lock [ ]” is turned o.

• The Child Lock function prevents children or the inﬁrm from accidently operating the washer

and injuring themselves.

• Ifachildentersthewashingmachine,thechildmaybecometrappedandsuocate.

WARNING

• OnceyouhaveactivatedtheChildLockfunction,itcontinuesworkingevenifthepower

CAUTION

is turned o.

• Forcingthelidopencanresultininjuryordamagetotheproduct.

To add laundry after you have activated the Child Lock function, you must ﬁrst pause or deactivate the Child Lock function.

washing a load of laundry _21

washing a load of laundry

Signal

When the cycle is complete, a chime will sound. When you press and hold both the Temp. and Spin buttons simultaneously for 3 seconds or more, the chime will sound intermittently.

Garment+

You can add or take out laundry items even after the wash has started, as long as the “Garment+” light is on. Pushing the Start/Pause button unlocks the lid. If you open the lid and want to continue the wash cycle, close the lid, and then press the Start/Pause button.

If you have activated Child Lock, you must deactivate it ﬁrst. See page 21.

My Cycle

Lets you save a custom wash cycle (temperature, spin, soil level, etc.) and then recall and use it with one button convenience.

To save a cycle and selected options as your My Cycle, follow these steps:

1. Press the Power button.

2. Select a cycle using the Cycle Selector.

3. After cycle selection, set each option.

See the “Cycle Chart” on page 36 ~ 37 for available option settings with each cycle.

4. You can then store the selected cycle and options by pressing and holding the My Cycle button

for longer than 3 seconds. The cycle and options you select will be displayed the next time you choose the My Cycle function.

5. Press the My Cycle button to load and use the saved My Cycle options. The “My Cycle” light will

indicate activation. Also, the chosen course and option lights will ﬂicker.

You can change the My Cycle settings by repeating the process above. The last saved settings will be displayed the next time you choose the My Cycle function.

If you press My Cycle and release it within 3 seconds, the previously saved course and options appear. If you press and hold My Cycle for 3 second or longer, the currently set course and options are saved and the LED blinks for 3 seconds.

Delay Start

You can set the washing machine to start your wash automatically at a later time, by choosing a delay time. The hour displayed indicates the time at which the wash will be started.

1. Set your wash course.

2. Press the Delay Start button repeatedly until the delay time is set.

3. Press the Start/Pause button. The “Delay Start” indicator will be lit, and the clock will begin

counting down until it reaches the set time.

4. To cancel a Delay Start function, press the Power button and then turn the washing machine on

again.

22_ washing a load of laundry

Pre Soak

Use this function when the laundry is heavily contaminated or stained. This function improves the wash performance by adding a Pre Soak cycle.

- If you select this function, the total cycle time is increased by 15 minutes.

- When the Pre Soak cycle starts, the washing machine repeats a wash cycle after supplying

water and then performs a 5-minute soak cycle.

- When the Pre Soak cycle is complete, the conﬁgured wash cycle starts without draining water.

AquaJetTM (WA456*)

After supplying water, the drum rotation creates a waterfall that dissolves the detergent more thoroughly. This allows the detergent to penetrate more evenly into the clothes and remove stains more eectively, even on big loads, giving you a better wash, During the rinse cycle, the waterfall passes through the fabric, removing detergent residue thoroughly.

Courses AquaJetTM Function

Normal, Heavy Duty, Perm Press,

Colors/Darks, Active Wear, Rinse+Spin

Bedding, Delicates/Hand Wash, Spin, Quick Wash, Pure Cycle

Available

Not Available

Eco Plus (WA456*)

This function sets the temperature some what lower than the typical washing cycle and extends the wash time slightly. With laundry time slightly extended, it’s possible to keep the same level of washing performance with cooler water. This function reduces energy consumption and maintains the quality of the wash.

03 washing a load of laundry

Mist Shower

Mist Shower sprays water from a nozzle that is independent of the main water supply system. This soaks the laundry with water from the beginning of the wash cycle and ensures an eective wash even with a small amount of water.

(The Mist Shower function may not work if there are too many laundries.)

Smart Care (WA456*)

This function enables you to check the status of the washing machine using a smartphone.

1. To enable the Smart Care function, press and hold the AquaJet™ key for 3 seconds after turning the power on or when an error occurs.

• Theerrorcodehistoryisdeletedafteryouusethisfunction.

2. The Smart Care indicator is lit on the display.

3. Run the Smart Care app on your smart phone.

• TheSmartCarefunctionisoptimizedfortheGalaxyS,GalaxyS2,iPhone4andiPhone

4S.

4. Focus your smart phone’s camera on the display panel of the washing machine.

5. If the smart phone’s camera is focused on the display panel of the washing machine,

the panel and error message is automatically recognized and the error type and countermeasures are displayed on the smart phone.

washing a load of laundry _23

washing a load of laundry

6. If the smartphone fails to recognize the error code more than twice, please enter the error

code displayed on the display panel of the washer manually into the Smart Care app.

Downloading the Smart Care app

• DownloadtheSamsungLaundryAppintoyourmobilephonefromtheAndroidmarket

or Apple App store. (Search word : Samsung Smart Washer/Dryer)

Precautions when using Smart Care

• Iflightfromalightbulb,uorescentbulb,orlampisreectedonthedisplaypanelof

the washing machine, the smartphone may not be able to recognize the panel or error message easily.

• Ifyouholdthesmartphoneattoolargeananglerelativetothefrontofthedisplaypanel,

it may not be able to recognize the error code. For best results, hold the smartphone so that the front of the panel and the smartphone are parallel or nearly parallel.

Washing clothes using the cycle selector

Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed.

1. Press the Power button.

2. Open the lid.

3. Load the articles of clothing one at a time loosely into the drum, without overﬁlling it.

4. Add liquid (or powder) detergent, softener, and/or bleach (if necessary) to the appropriate

compartments. See pages 25~27.

5. Close the lid.

6. Use the Cycle Selector to select the appropriate cycle according to the type of material:

Normal, Heavy Duty, Colors/Darks(WA456*), Bedding, Spin, Rinse+Spin, Perm Press, Active Wear(WA456*), Delicates/Hand Wash, Quick Wash, Pure CycleTM. The relevant indicators will illuminate on the control panel.

7. At this time, you can control the wash temperature, the number of rinse cycles, the spinning

speed, and the delay time by pressing the appropriate option button.

8. Press the Start/Pause button on the Cycle Selector and the wash will begin. The process

indicator will light up and the remaining time for the cycle will appear in the display.

Pause Option

When the Garment + LED is on, you can add laundry items to or remove laundry items from the wash.

To remove or add laundry items when the Garment + LED is on, follow these steps:

1. Press the Start/Pause button to unlock the lid.

The lid cannot be opened when the water is too HOT.

2. Remove or add laundry items.

3. Close the lid, and then press the Start/Pause button to restart the wash.

If you have Child Lock on, you must deactivate it ﬁrst. See page 21.

When the cycle is ﬁnished:

After the total cycle has ﬁnished, the power will turn o automatically.

1. Open the lid.

2. Remove laundry.

24_ washing a load of laundry

DETERGENT USE

Your washer is designed to use high eciency (HE) detergents.

• For best cleaning results, use a high eciency detergents such as Tide HE, Wisk HE, Cheer HE or Gain HE*. High eciency detergents contain suds suppressors that reduce or eliminate suds. When fewer suds are produced, the load tumbles more eciently and cleaning is maximized.

Regular detergent is not recommended. Use HE detergents only.

WARNING

Reducing the amount of detergent may reduce the quality of cleaning. It is important to pre–treat stains, sort carefully by color and soil level, and avoid overloading. * Brand names are trademarks of their respective manufacturers.

FEATURES

Automatic dispenser

Your washer has separate compartments for dispensing detergent and color-safe bleach and fabric softener. Add all laundry additives to their respective compartments before starting your Washer.

The automatic dispenser MUST ALWAYS be in place before you start your washer. DO NOT open the automatic dispenser when your washer is running.

• Never exceed the manufacturer’s recommendations when adding detergent.

• This compartment holds liquid detergent for the main wash cycle, which is added to the

load at the beginning of the cycle.

• When using powdered detergent, remove the liquid detergent compartment from the detergent drawer. The washer will not dispense powdered detergent from the liquid detergent compartment.

03 washing a load of laundry

To add detergent to the automatic dispenser:

1. Open the dispenser drawer.

2. Load the recommended amount of liquid (or powder) detergent into the detergent

compartment before you start your wash.

3. Close the drawer slowly and smoothly to avoid spilling, splashing, or premature dispensing of

the contents.

It is normal for a small amount of water to remain in the dispenser compartments at the end of the cycle.

Do not put chlorine bleach in the dispenser drawer.

washing a load of laundry _25

Liquid detergent compartment

washing a load of laundry

Loading the Liquid (or Powder) detergent compartment

1. Pour the recommended amount of laundry detergent

directly into the detergent compartment before starting your washer.

2. If you are using color-safe bleach, add it with the detergent

to the detergent compartment.

When adding color-safe bleach with detergent, it is best if both laundry products are in the same form – liquid.

When using powdered detergent, remove the liquid detergent compartment from the detergent drawer. The washer will not dispense powdered detergent from the liquid detergent compartment.

Loading the Bleach compartment (WA456*)

(Liquid chlorine bleach only)

1. Add chlorine bleach to the bleach compartment.

DO NOT exceed the MAX FILL line.

• Avoid splashing or over–ﬁlling the compartment.

• Your washer automatically dispenses bleach into the

tub at the appropriate time.

2. The dispenser automatically dilutes liquid chlorine bleach

before it reaches the wash load.

• Never pour undiluted liquid chlorine bleach directly onto the load or into the tub. It is a powerful chemical and can cause fabric damage, such as weakening of the ﬁbers or color loss, if not used properly.

• If you prefer to use color–safe, non–chlorine bleach, add it to the appropriate detergent compartment. DO NOT pour color–safe bleach into the Bleach compartment.

Bleach

compartment

Liquid detergent compartment

Loading the Bleach compartment (WA422*/WA400*)

(Liquid chlorine bleach only) Add chlorine bleach to the bleach compartment. DO NOT exceed the bleach compartment.

- Avoid splashing or over–ﬁlling the compartment.

• Neverpourundilutedliquidchlorinebleachdirectly

onto the load or into the tub. It is a powerful chemical and can cause fabric damage, such as weakening of the ﬁbers or color loss, if not used properly.

• Ifyouprefertousecolor–safe,non–chlorinebleach,

add it to the appropriate detergent compartment. DO NOT pour color–safe bleach into the Bleach compartment.

26_ washing a load of laundry

Bleach

compartment

Loading the Fabric softener compartment

1. Pour the recommended amount of liquid fabric softener

into the softener compartment. For smaller loads, use less than one capful.

2. Dilute the fabric softener with water until it reaches MAX

FILL in the compartment.

3. The dispenser automatically releases liquid fabric softener

at the proper time during the rinse cycle.

• Use the softener compartment ONLY for liquid fabric softeners.

• DO NOT use the Downy Ball* in the fabric softener compartment with this washer. It will not add fabric softener at the appropriate time. Use the detergent compartment.

• Do not use liquid fabric softener that is too sticky as it may not mix with the water suciently.

* Brand names are trademarks of their respective manufacturers.

Fabric softener compartment

03 washing a load of laundry

washing a load of laundry _27

maintaining your washer

CLEANING THE EXTERIOR

Turn o the water faucets after ﬁnishing the day’s washing. This will shut o the water supply to your washer and prevent the unlikely possibility of damage from

escaping water. Leave the lid open to allow the inside of your washer to dry out. Use a soft cloth to wipe up all detergent, bleach or other spills as they occur. Clean the following as recommended: Control Panel – Clean with a soft, damp cloth. Do not use abrasive powders or cleaning pads. Do not spray

cleaners directly on the panel.

CLEANING THE INTERIOR

Clean the interior of your washer periodically to remove any dirt, soil, odor, mold, mildew, or bacterial residue that may remain in your washer as a result of washing clothes.

Failure to follow these instructions may result in unpleasant conditions, including odors and/or permanent stains on your washer or laundry.

Hard water deposits may be removed, if needed. Use cleaners labeled “Washer safe”.

STORING YOUR WASHER

Washers can be damaged if water is not removed from hoses and internal components before storage. Prepare your washer for storage as follows:

• Select the Quick Wash cycle and add bleach to the automatic dispenser. Run your washer through the cycle without a load.

• Turn the water faucets o and disconnect the inlet hoses.

• Unplug your washer from the electrical outlet and leave your washer lid open to let air circulate inside the

drum.

• If your washer has been stored in below–freezing temperatures, allow time for any leftover water in your washer to thaw out before use.

PRESERVING THE TOP COVER AND THE FRONT FRAME

Do not place any heavy or sharp objects or a detergent box on the washing machine. They can scratch or damage the top cover of the unit.

Since the entire washing machine has a high-gloss ﬁnish, the surface can be scratched or damaged. Avoid scratching or damaging the surface when using the washing machine.

28_ maintaining your washer

CLEANING THE DISPENSERS

The automatic dispenser may need to be cleaned periodically due to laundry additive buildup.

1. Pull the dispenser drawer straight back until it stops.

2. Tilt the dispenser drawer upward and remove it.

3. Remove the inserts from the 3 compartments. Rinse the

inserts and the drawer with warm water to remove traces of accumulated laundry products.

04 maintaining your washer

4. To clean the drawer opening, use a small, non-metal brush

to clean the recess. Remove all residue from the upper and lower parts of the recess.

5. Return the inserts to the proper compartments and replace

the drawer. By placing the dispenser drawer rail  on top of the compartment rail  (Tilt the dispenser drawer downward and insert it.), and then pushing the drawer in ﬁrmly and slowly.

maintaining your washer _29

maintaining your washer

PURE CYCLE

Pure Cycle is a self-cleaning cycle that removes mold that may occur inside the washing machine.

1. Press the Power button.

2. Select the Pure CycleTM course.

• Once the Pure CycleTM course is selected, the only function

3. Press the Start/Pause button.

• If you press the Start/Pause button, Pure Cycle begins.

• Using Pure Cycle, you can clean the drum without using a

CAUTION

• Never use Pure Cycle when laundry is in the washing

The Pure Cycle Auto Indicator Function

• If the “Pure Cycle” is lit after a wash, it indicates that tub

• If you do not run Pure Cycle, the “Pure CycleTM” indicator

• Although the Pure Cycle Auto Indicator appears once a

that can be set is Delay Start.

WA456*

WA422* / WA400*

cleansing agent.

machine. This may cause damage to the laundry or a problem with the washing machine.

WA456*

(drum) cleaning is required. In this case, remove the laundry from the washing machine, turn the power on, and clean the drum by running Pure Cycle.

turns o. However, the “Pure CycleTM” indicator will light again after two washes. Not running Pure Cycle at this point will not cause a problem with the washing machine.

WA422* / WA400*

month or so, the frequency may dier depending on the number of times the washing machine is used.

30_ maintaining your washer

+ 102 hidden pages
