Samsung UE65KS8000T, UE55KS8000T, UE49KS8000T Operating Instructions

USER MANUAL

8 SERIES

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register M o d e l _________________ S e r i a l N o . _______________________

Warning! Important Safety Instructions

(Please read the Safety Instructions before using your TV.)

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

Class II product : This symbol indicates that it does not require a safety connection to electrical earth (ground).

AC voltage : This symbol indicates that the rated voltage marked with the symbol is AC voltage

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol indicates that this product has included important literature concerning operation and maintenance.

The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure reliable operation of this apparatus and to protect it from overheating, these slots and openings must never be blocked or covered.

– Do not place this apparatus in a confined space, such as a bookcase or built-in cabinet, unless proper ventilation is provided. – Do not place this apparatus near or over a radiator or heat register, or where it is exposed to direct sunlight.

– Do not place vessels (vases etc.) containing water on this apparatus, as this can result in a fire or elec tric shock. Do not expose this apparatus to rain or place it near water (near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool etc.). If this apparatus accidentally gets wet, unplug it and contact an authorised dealer immediately.

This apparatus uses batteries. In your community, there might be environmental regulations that require you to dispose of these batteries properly. Please contact your local authorities for disposal or recycling information.

Do not overload wall outlets, extension cords or adaptors beyond their capacity, since this can result in fire or electric shock. Power-supply cords should be placed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay

particular attention to cords at the plug end, at wall outlets, and the point where they exit from the appliance. To protect this apparatus from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall

outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power line surges. Before connecting the AC power cord to the DC adaptor outlet, make sure that the voltage designation of the DC adaptor corresponds to the

local electrical supply. Never insert anything metallic into the open parts of this apparatus. This may cause a danger of electric shock. To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus. Be sure to plug in the power cord until it is firmly seated. When unplugging the power cord from a wall outlet, always pull on the power cord's

plug. Never unplug it by pulling on the power cord. Do not touch the power cord with wet hands. If this apparatus does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately

and contact an authorised dealer or service centre. Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are to leave the house for an extended period of time

(especially when children, elderly or disabled people will be left alone in the house).

– Accumulated dust can cause an elec tric shock, an electric leakage, or a fire by causing the power cord to generate sparks and heat or

by causing the insulation to deteriorate. Be sure to contact an authorised service centre for information if you intend to install your TV in a location with heavy dust, high or low temperatures, high humidity, chemical substances, or where it will operate 24 hours a day such as in an airport, a train station, etc. Failure to do so may lead to serious damage to your TV.

Use only a properly grounded plug and wall outlet.

– An improper ground may cause electric shock or equipment damage. (Class l Equipment only.)

To turn off this apparatus completely, disconnect it from the wall outlet. Be sure to have the wall outlet and power plug readily accessible. Store the accessories (battery, etc.) in a location safely out of the reach of children. Do not drop or strike the product. If the product is damaged, disconnect the power cord and contact a service centre. To clean this apparatus, unplug the power cord from the wall outlet and wipe the product with a soft, dry cloth. Do not use any chemicals such

as wax, benzene, alcohol, thinners, insecticide, aerial fresheners, lubricants, or detergents. These chemicals can damage the appearance of the TV or erase the printing on the product.

Do not expose this apparatus to dripping or splashing. Do not dispose of batteries in a fire. Do not short-circuit, disassemble, or overheat the batteries. There is danger of an explosion if you replace the batteries used in the remote with the wrong type of battery. Replace only with the same or

equivalent type.

DC voltage : This symbol indicates that the rated voltage marked with the symbol is DC voltage.

Caution, Consult Instructions for use : This symbol instructs the user to consult the user manual for further safety related information.

English - 2

Features of your new TV

Home Screen

In Home Screen, you can easily run the apps that have been used previously or frequently. The apps can also be moved or deleted in the screen.

e-Manual

Get help from a detailed, on-screen user's manual built into your TV.

Voice Interaction

Access and control menu options and functions using voice commands.

–

Refer to the e-Manual chapter, Smart Features > Using Voice Interaction.

English - 3

Contents

01 What's in the Box?

02 Assembling the TV

6 Attaching the TV to the Stand

6 Mounting the TV on a Wall (Optional)

8 Providing proper ventilation for your

8 Arranging the cables with the cable

guide

8 Covering the ports with the Cover

Terminal

9 Safety Precaution: Securing the TV to

the wall

03 Connections

10 Connecting devices to your TV

11 Connecting to the Internet

12 Connecting to a COMMON INTERFACE

slot (Your TV viewing Card Slot)

04 The TV Controller

05 Performing the initial setup

18 Initial setup

06 Selecting Connected Devices

07 The e-Manual

08 Troubleshooting and

Maintenance

23 What is Remote Support?

24 Eco sensor and screen brightness

24 Caring for the TV

09 Specifications and other

information

25 TVSpecications

26 Licences

29 Warranty Card

13 Using the TV Controller

14 The Standard Remote Control

15 The Samsung Smart Remote

16 About the Samsung Smart Remote

18 Controlling External Devices with

the TV Remote - Using the Universal Remote

* The figures and illustrations in this User Manual are provided for reference only and may differ from the actual product appearance. The product design and specifications may change without notice. CIS languages (Russian, Ukrainian, Kazakhs) are not available for this product, since this is manufactured for customers in the EU region.

English - 4

01 What's in the Box?

Please make sure the following items are included with your TV. If any items are missing, contact your dealer.

Samsung Smart Remote & Batteries (AA x 2) Remote Control & Batteries (AAA x 2)

Regulatory Guide /

Warranty Card

Power Cord

– The items’ colours and shapes may vary depending on the models. – Cables not included can be purchased separately. – Check for any accessories hidden behind or in the packing materials when opening the box.

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect with the product (i.e. where the user manual has not been read).

(b) you bring the unit to a repair centre and there is no defect with the product (i.e. where the user manual has not been read).

You will be informed of the administration fee amount before a technician visits.

User Manual One Connect One Connect Cable

1EA

2EA

Wall mount

Adapter

1EA 2EA

Cable Guide Cleaning cloth Cover Terminal

Warning: Screens can be damaged from direct pressure when handled incorrectly. We recommend lifting the TV at the edges, as shown.

English - 5

Don't Touch This Screen!

02 Assembling the TV

Attaching the TV to the Stand

<49”-65”>

M4 X L14 (4EA)

<75”>

M4 X L16 (4EA)

Make sure you have all the accessories shown, and that you assemble the stand following the provided assembly instructions.

Mounting the TV on a Wall (Optional)

M4 X L14 (3EA)

If you mount this product on a wall, follow the instructions exactly as recommended by the manufacturer. Unless it is correctly mounted, the product may slide or fall, thus causing serious injury to a child or adult and serious damage to the product.

Wall mount bracket

Wall mount Adapter

Wall mount bracket

English - 6

VESA wall mount kit notes and specifications

You can install your wall mount on a solid wall perpendicular to the floor. Before attaching the wall mount to surfaces other than plaster board, contact your nearest dealer for additional information. If you install the TV on a ceiling or slanted wall, it may fall and result in severe personal injury.

– Standard dimensions for wall mount kits are shown in the table below. – When purchasing our wall mount kit, a detailed installation manual and all parts necessary for

assembly are provided. – Do not use screws that do not comply with the VESA standard screw specifications. – Do not use screws that are longer than the standard length or do not comply with VESA

standard screw specifications. Screws that are too long may cause damage to the inside of the

TV set. – For wall mounts that do not comply with the VESA standard screw specifications, the length of

the screws may differ depending on the wall mount specifications. – Do not fasten the screws too firmly. This may damage the product or cause the product to fall,

leading to personal injury. Samsung is not liable for these kinds of accidents. – Samsung is not liable for product damage or personal injury when a non-VESA or non-specified

wall mount is used or the consumer fails to follow the product installation instructions. – Do not mount the TV at more than a 15 degree tilt.

When using a third-party wall mount, note that the assembling screw length(C) is shown below.

Product

Family

UHD-TV 49~75 400 x 400

Inches

Do not install your wall mount kit while your TV is turned on. This may result in personal injury from electric shock.

VESA Spec.

(A * B)

C (mm)

Standard

Screw

M8 4

Quantity

English - 7

Providing proper ventilation for your TV

When you install your TV, maintain a distance of at least 10 cm between the TV and other objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper ventilation may result in a fire or a problem with the product caused by an increase in its internal temperature.

When you install your TV with a stand or a wall mount, we strongly recommend you use parts provided by Samsung Electronics only. Using parts provided by another manufacturer may cause difficulties with the product or result in injury caused by the product falling.

Installation with a stand. Installation with a wall-mount.

10 cm

Other Cautions

– The actual appearance of the TV may differ from the images in this manual, depending on the

model. – Be careful when you touch the TV. Some parts can be somewhat hot.

Arranging the cables with the cable guide

Covering the ports with the Cover Terminal

–

Before covering the ports with the cover terminal, tidy up the cables on the TV.

English - 8

Safety Precaution: Securing the TV to the wall

Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang on or destabilise the TV. This action may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided in the Safety Flyer included with your TV. For added stability and safety, you can purchase and install the anti-fall device as described below.

WARNING: Never place a television set in an unstable location. A television set may fall,

causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as

•

Using cabinets or stands recommended by the manufacturer of the television set.

•

Only using furniture that can safely support the television set.

•

Ensuring the television set is not overhanging the edge of the supporting furniture.

•

Not placing the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television set to a suitable support.

•

Not placing the television set on cloth or other materials that may be located between the television set and supporting furniture.

•

Educating children about the dangers of climbing on furniture to reach the television set or its controls.

If your existing television set is being retained and relocated, the same considerations as above should be applied.

Preventing the TV from falling

1. Put the screws into one set of brackets, and then firmly

fasten them to the wall. Confirm that the screws are firmly

attached to the wall.

– You may need additional material such as wall anchors

depending on the type of wall.

2. Put the screws into a second set of brackets, and then

fasten the screws to the TV.

– These screws may not be supplied with the TV. For a

49~75 inch model, purchase M8 screws.

3. Connect the brackets fixed to the TV and the brackets fixed

to the wall with a durable, heavy-duty string, and then tie

the string tightly.

– Install the TV near the wall so that it does not fall

backwards.

– Connect the string so that the brackets fixed to the wall

are at the same height as or lower than the brackets fixed to the TV.

English - 9

03 Connections

Connecting devices to your TV

You can connect various external devices using the connectors located at the back of the product. Check the connectors and then refer to the Quick Guide for more instructions on supported external devices.

For more information about connections, see the e-Manual chapter "Connections." Make sure you have the correct cable before plugging it in. Illustrations of common plugs and ports

are shown below.

HDMI

USB

Optical

Cable Plugs Ports

Warning

Do not plug cables in upside down. Be sure to check the orientation of the plug before plugging it in.

English - 10
