Samsung UE-37C6620UK, UE32C6620UK, UE-40C6620UK, UE46C6620UK User Manual

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.

Country

EIRE 0818 717100 www.samsung.com/ie

U.K 0845 SAMSUNG (7267864) www.samsung.com/uk

Customer Care Centre

Web Site

LED TV

user manual

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

Model _____________ Serial No. _____________

BN68-02840F-00

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and speciﬁcations may be changed without notice.

Digital TV notice

1. Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.

2. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Programme Guide), VOD (Video On Demand) and so on, are not included in this speciﬁcation. So, they cannot be workable at this moment.

3. Although this TV set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

4. Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business.

5. Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers.

6. For more information, please contact your local Samsung customer care centre.

The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV

✎

performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconﬁguring TV setting or not.

Still image warning

Avoid displaying still images (like jpeg picture ﬁles) or still image element (like TV programme logo, panorama or 4:3 image format, stock or news bar at screen bottom etc.) on the screen. Constant displaying of still picture can cause ghosting of LED screen, which will affect image quality. To reduce risk of this effect, please follow below recommendations:

• Avoid displaying the same TV channel for long periods.

• Always try do display any image on full screen, use TV set picture format menu for best possible match.

• Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed up the burnout process.

• Frequently use all TV features designed to reduce image retention and screen burnout, refer to proper user manual section for details.

WARNINGS: Image retention, commonly known as screen burn-in, can occur on most types of television if the same image is displayed

✎

continuously. The most common causes of image retention are logos that remain stationary on the TV screen. These logos are common on many programmes received via a Set-top Box. To reduce this risk, avoid displaying still images for long durations and lower the brightness or contrast settings to decrease the intensity of the picture. Extended viewing of movies and programs in aspect ratios that are different from the aspect ratio of the TV may cause image retention. Always endeavour to avoid black borders top or bottom by using the zoom function. This will help eliminate the black borders and ﬁt the picture to the entire area of the screen. Using a video game console may cause image retention and is not recommended. When using a PC input, avoid displaying still images for long durations and reduce the brightness or contrast settings to decrease the intensity of the picture.

IMPORTANT: Image retention issues are not covered by your Samsung® warranty.

✎

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation. Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

✎

If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.

The appearance may differ depending on the product.

✎

Installation with a stand. Installation with a wall-mount.

10 cm

English

10 cm

Contents

Getting Started

Connections

Basic Features

Advanced Features

4 Accessories 5 Viewing the Control Panel 6 Viewing the Remote Control 7 Connecting to an Antenna 7 Plug & Play (Initial Setup)

8 Connecting to an AV Device 9 Connecting to an Audio Device 10 Changing the Input Source

11 How to Navigate Menus 11 Using the INFO button (Now & Next guide) 11 Planning Your Viewing 13 Channel Menu 15 Picture Menu 18 Sound Menu 20 Setup Menu 23 Support Menu

24 Connecting to a PC 25 Network Connection 32 Media Play 41 Anynet+ 44 Internet@TV 47 AllShare

Other Information

TOOLS

This function can be used by

pressing the TOOLS button on the

remote control.

49 Analogue Channel Teletext Feature 50 Assembling the Cables 51 Installing the Wall Mount 53 Anti-theft Kensington Lock 53 Securing the TV to the wall 54 Troubleshooting 58 Speciﬁcations 60 Index

Warning! Important Safety Instructions Wiring the Mains Power Supply Plug (UK Only) Warranty Card

Check the Symbol!

Note One-Touch Button

English

Getting Started

Accessories

✎

Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer.

✎

The items’ colours and shapes may vary depending on the models.

✎

Cables not included in the package contents can be purchased separately

y Remote Control & Batteries (AAA x 2) y Owner’s Instructions y Quick Setup Guide

(M4 X L8)

y Blanking Bracket y Holder-Ring (4EA) y Holder-Wire stand

y Cable Tie y Holder-Wire (3EA) y Power Cord Clamp

y Cleaning Cloth y Power Cord

y Component Adapter y AV Adapter y SCART Adapter

UE32C6600 / UE37C6600 / UE40C6600 / UE46C6600

See separate guide for installing the stand.

y Stand (1EA) y Guide Stand (1EA) y Screws (10 EA)

UE32C6620 / UE37C6620 / UE40C6620 / UE46C6620

See separate guide for installing the stand.

y Stand (1EA) y Guide Stand (1EA) y Screws (9EA)

✎

For best cable connection to this product, be sure to use cables with a maximum thickness as below:

y Maximum thickness - 0.55 inches (14mm)

5EA (M4 X L12)

5EA (M4 X L8)

(M4 X L8)

English

Viewing the Control Panel

✎

The product colour and shape may vary depending on the model.

Power Indicator

Speakers

Remote control sensor Aim the remote control towards this spot on the TV.

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

SOURCE

MENU Displays an on-screen menu, the OSD (on screen display) of your TV’s features.

(Power)

Toggles between all the available input sources. In the on-screen menu, use this button as you would use the ENTERE button on the remote control.

Adjusts the volume. In the OSD, use the ◄ and ► buttons on the remote control.

Changes the channels. In the OSD, use the ▼ and ▲ buttons on the remote control.

Turns the TV on or off.

Remote control sensor

buttons as you would use the

01 Getting Started

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

English

Getting Started

Viewing the Remote Control

✎

This is a special remote control for the visually impaired persons and has Braille points on the Power, Channel and Volume buttons.

Turns the TV on and off.

Displays and selects the available video

sources (p. 10).

Have direct access to channels.

Alternately select Teletext ON / Double

/ Mix / OFF.

Adjusts the volume.

Opens the OSD.

Displays the Content View, which

includes Channel Manager,

Internet@TV, Media Play, and AllShare.

Quickly select frequently used functions.

Selects the on-screen menu items and changes the values seen on the menu.

Returns to the previous menu.

These buttons are for the

Channel Manager, Internet@TV,

Media Play menu, etc.

Use these buttons in Media Play and

Anynet+ (HDMI-CEC) modes

(p. 32, 41). (The button also controls recording for Samsung recorders that support the

Anynet+(HDMI-CEC),TimeShift and PVR

features.)

POWER

ON/OFF

SOURCE

TTX/MIX

MUTE

CH LIST

CONTENT

TOOLS

RETURN

A B C D

@ TV

MEDIA.P

INTERNET

P.SIZE

SUBT.

PRE-CH

GUIDE

INFO

EXIT

f-g

DUAL

Turns the remote control light on or off. When on, the buttons become illuminated for a moment when pressed. (Using the remote control with this button set to ON will reduce the battery usage time.)

Returns to the previous channel.

Cuts off the sound temporarily.

Changes channels.

Displays channel lists on the screen (p. 13).

Displays the EPG (Electronic Programme Guide) (p. 11).

Displays information on the TV screen.

Exits the menu.

MEDIA.P: Displays Media Play (p. 32). INTERNET@TV: Link to various internet

services (p. 44).

DUAL f-g: Sound effect selection

(p. 20).

AD: Turns the audio description on and

off (p. 19). This is not available in some locations.

P.SIZE: Selects the picture size (p . 17). SUBT.: Displays digital subtitles (p. 21).

Installing batteries (Battery size: AAA)

English

✎

NOTE

Use the remote control within 23 feet from the TV.

Bright light may affect the per formance of the remote control.

Avoid using nearby special fluorescent light or neon signs. The colour and shape may vary depending on the model.

Connecting to an Antenna

When the TV is initially powered on, basic settings proceed automatically.

✎

Preset: Connecting the mains and antenna.

VHF/UHF Antenna

Cable

ANT OUT

button.

POWER

button.

Power Input

Plug & Play (Initial Setup)

When the TV is initially powered on, a sequence of on-screen prompts will assist in conﬁguring basic settings. Press the

POWERP button. Plug & Play is available only when the Input source is set to TV.

✎

To return to the previous step, press the Red button.

Selecting a language

Selecting Store Demo

or Home Use

Selecting a country

Selecting an antenna

Selecting a channel

Setting the

Clock Mode

Time Zone

Viewing the

HD Connection Guide. Enjoy your TV.

Press the ▲ or ▼ button, then press the ENTER Select the desired OSD (On Screen Display) language. Press the ◄ or ► button, then press the ENTER

y Select the Home Use mode. Store Demo Mode is for retail

environments.

y To return unit’s settings from Store Demo to Home Use (standard):

Press the volume button on the TV. When you see the volume OSD,

press and hold MENU for 5 sec. Press the ▲ or ▼ button, then press the ENTER Select the appropriate country. Press the ▲ or ▼ button, then press the ENTERE button. Select Air or Cable. Press the ▲ or ▼ button, then press the ENTER Select the channel source to memorise. When setting the antenna source to Cable, a step

appears allowing you to assign numerical values (channel frequencies) to the channels. For more information, refer to Channel → Auto Store (p. 13).

✎

Press the ENTERE button at any time to interrupt the memorization process. Set the Clock Mode automatically or manually. Press the ▲ or ▼ button to select Auto, then press the ENTER Press the ▲ or ▼ button to select the your time zone, then press the ENTER

(depending on the country) The connection method for the best HD screen quality is displayed.

Press the ENTER

button.

01 Getting Started

If You Want to Reset This Feature...

Select Setup - Plug & Play (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0.” If you want to change the PIN number, use the Change PIN function.

English

Connections

Connecting to an AV Device

Using an HDMI or HDMI/DVI cable: HD connection (up to 1080p)

Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, cable box, satellite receiver (STB)

DVD /

HDMI OUT

Blu-ray player

WhiteRed

✎

HDMI IN 1(DVI), 2, 3, 4, PC/DVI AUDIO IN

When using an HDMI/DVI cable connection, you must use the HDMI IN 1(DVI) jack for video. A DVD, Blu-ray

player, HD cable box, HD STB satellite receiver, cable box, or STB satellite receiver may require a DVI-HDMI (DVI to HDMI) cable or DVI-HDMI (DVI to HDMI) adapter. The PC/DVI AUDIO IN jack is required for audio.

If an external device such as a DVD / Blu-ray player / cable box / STB satellite receiver supporting a HDMI

versions older than 1.3 is connected, the T V may operate abnormally (e.g. no screen display / no sound / annoying flicker / abnormal colour).

If there is no sound after connecting an HDMI cable, check the HDMI version of the external device. If you

suspect the version is older than 1.3, contact the provider of the device to confirm the HDMI version and request an upgrade.

It is recommended you purchase an HDMI-certified cable. Otherwise, the screen may appear blank or a

connection error may occur.

Using a Component (up to 1080p) or Audio/Video (480i only) and Scart Cable

Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR

Blu-Ray player

COMPONENT OUT

VCR / DVD

PR PB Y

DVD /

AUDIO OUT

R-AUDIO-L

DVI OUT

AUDIO OUT

R-AUDIO-L

DVD /

Blu-ray player

VCR

VIDEO OUTAUDIO OUT

R-AUDIO-L

WRWR

EXT

✎

In Ext. mode, DTV Out supports MPEG SD Video and Audio only.

✎

To obtain the best picture quality, the Component connection is recommended over the A/V connection.

English

RGB

RedRed WhiteWhite YellowRed Blue Green

W R

Connecting to an Audio Device

Using an Optical (Digital) or Headphone Cable Connection

Available devices: digital audio system, ampliﬁer, DVD home theatre

OPTICAL

✎

DIGITAL AUDIO OUT (OPTICAL)

When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume

of both the TV and the system.

5.1 CH (channel) audio is available when the T V is connected to an external device supporting 5.1 CH.

When the receiver (home theatre) is set to on, you can hear sound output from the TV’s optical jack. When the

TV is receiving a DTV signal, the TV will send 5.1 CH sound to the home theatre receiver. When the source is a digital component such as a DVD / Blu-ray player / cable box / STB (Set-Top-Box) satellite receiver and is connected to the TV via HDMI, only 2 CH audio will be heard from the home theatre receiver. If you want to hear 5.1 CH audio, connect the digital audio out jack from your DVD / Blu-ray player / cable box / STB satellite receiver directly to an amplifier or home theatre.

✎

Headphones H: You can connect your headphones to the headphones output on your set. While the headphones are connected, the sound from the built-in speakers will be disabled.

Sound function may be restricted when connecting headphones to the TV.

Headphone volume and TV volume are adjusted separately.

02 Connections

digital audio system

English

Connections

SOURCE

CONNECTIONS COMMON INTERFACE Slot

To watch paid channels, the “CI or CI+ CARD” must be inserted. If you don’t insert the “CI or CI+ CARD,” some channels will display

the message “Scrambled Signal”. The pairing information containing a telephone number, the “CI or CI+

CARD” ID the Host ID and other information will be displayed in about 2~3 minutes. If an error message is displayed, please contact your service provider.

When the conﬁguration of channel information has ﬁnished, the message “Updating Completed” is displayed, indicating the channel list is updated.

✎

NOTE

You must obtain a “CI or CI+ CARD” from a local cable service provider.

When removing the “CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI or CI+ CARD” may

cause damage to it. Insert the “CI or CI+ CARD” in the direction marked on the card.

The location of the COMMON INTERFACE slot may be different depending on the model.

“CI or CI+ CARD” is not supported in some countries and regions; check with your authorized dealer.

If you have any problems, please contact a service provider.

Insert the “CI or CI+ CARD” that supports the current antenna settings. The screen will be distorted or will not be seen.

Changing the Input Source

Source List

Use to select TV or an external input sources such as a DVD / Blu-ray player / cable box / STB satellite receiver.

■ TV / Ext. / PC / AV / Component

/ HDMI1/DVI / HDMI2 / HDMI3 / HDMI4 / USB

✎

In the Source List, connected inputs will be highlighted.

✎

Ext. and PC always stay activated.

Edit Name

■ VCR / DVD / Cable STB / Satellite STB / PVR STB /

AV Receiver / Game / Camcorder / PC / DVI PC / DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA:

Name the device connected to the input jacks to make your input source selection easier.

✎

When a PC with a resolution of 1920 x 1080 @ 60Hz is connected to the HDMI IN 1(DVI) port, you should set to DVI PC mode under Edit Name.

✎

When connecting an HDMI/DVI cable to the

HDMI IN 1(DVI) port, you should set to DVI PC or

DVI Devices mode under Edit Name.

English

Basic Features

H LIST

MUTE

POWE

OURCE

PRE-C

TOOLS

TTX/MI

ON/OFF

How to Navigate Menus

Before using the TV, follow the steps below to learn how to navigate the menu and select and adjust different functions.

NTEN

UIDE

INF

RETURN

EXIT

1 ENTERE / Direction button: Move the cursor and

select an item. Conﬁrm the setting.

2 RETURN button: Returns to the previous menu. 3 MENU button: Displays the main on-screen menu. 4 EXIT button: Exits the on-screen menu.

Using the INFO button (Now & Next guide)

The display identiﬁes the current channel and the status of certain audio-video settings.

The Now & Next guide shows daily TV programme information for each channel according to the broadcasting time.

y Scroll ◄, ► to view information for a

desired programme while watching the current channel.

y Scroll ▲, ▼ to view information for other channels. If you

want to move to the currently selected channel, press the ENTER

DEF

DTV Air

button.

Life On Venus Avenu e

Unclass ified

No Det aild Inform ation

18:00 ~ 6:00

INFO

18:11 Thu 6 Jan

Watch

Information

Planning Your Viewing

03 Basic Features

How to Operate the OSD (On Screen Display)

The access step may differ depending on the selected menu.

The main menu options appear on the screen:

Picture, Sound, Channel, Setup, Input, Application, Support.

▲ / ▼ Select an icon with the ▲ or ▼

2 3 4 5

ENTER

▲ / ▼

◄ / ►

button.

Press ENTERE to access the sub-menu.

Select the desired submenu with the ▲ or ▼ button.

Adjust the value of an item with the ◄ or ► button. The adjustment in the OSD may differ depending on the selected menu.

Press ENTERE to complete the conﬁguration.

Press EXIT.

ENTER

EXIT

Guide

The EPG (Electronic Programme Guide) information is provided by broadcasters. Using programme schedules provided by broadcasters, you can specify programmes you want to watch in advance so that the channel automatically changes to the selected programme channel at the speciﬁed time. Programme entries may appear blank or out of date depending on a channel status.

Using Channel View

Guide

DTV Air 800 five

Home and Away 18:00 - 18:30

Drama

800 ﬁve

Channel View - TV

Today

27 28 800 24 16 6

Dani is devastated when scott makes clear his views on marriage...

Discovery DiscoveryH&L five price-drop.tv QVC R4DTT

View Mode +24 Hours Ch. Mode Information k Page

1 2 3 4 5 6

18:00 - 19:00 19:00 - 20:00

American Chopper

Programmes resume at 06:00 Home and... No Information QVC Selection No Information

)

Family Affairs

Tine Team

Fiv...

)

GUIDE

2:10 Tue 1 Jun

Dark Angel



Watch

English

Basic Features

Using Scheduled View

Guide

)

Family Affairs

)

Dark Angel

800 800

View Mode Information

1 4 6

button again and

DTV Air 800 five

Family Affairs 18:00 - 18:30

Drama

800 ﬁve

Scheduled View

18:30

Today

19:15

Today

Red (View Mode): View the list of programmes that

Tanya confesses all to a stunned Babs. Conrad is anxious to hear...

are playing now or coming up.

Yellow (+24 Hours): Viewing the list of programmes to

be broadcasted after 24 hours.

Blue (Ch. Mode): Select the type of channels you want to display on the Channel View window. (All, TV, Radio, Data/Other, My Channel 1~4)

4 Information: Displays details of the selected

programme.

(Page): Move to next or previous page.

6 ENTER

button

– When selecting the current programme, you can

watch the selected programme.

– When selecting the future programme, you can

reserve to watch the selected programme. To cancel the schedule, press the ENTER select Cancel Schedules.

2:10 Tue 1 Jun

five five



Cancel

■ Channels: Shows the channel list according to channel type.

My Channels: Shows the group of the channel.

■

Scheduled: Shows all the currently reserved

programmes.

✎

Using the colour buttons with the Channel Manager

Red (Antenna): Toggle among Air or Cable.

Green (Zoom): Enlarges or shrinks a channel

number.

Yellow (Select): Select desired channels and press

the Yellow button to set all the selected channels at the same time. The c mark appears to the left of the selected channels.

Blue (Sor t): Change the list ordered by channel

name or channel number.

(Page): Move to next or previous page.

(Tools): Displays the Channel Manager option

menu. (The options menus may differ depending on the situation.)

Channel Status Display Icons

Icons Operations

An analogue channel.

A channel selected.

A channel set as a Favourite.

A programme currently being broadcast.



A locked channel.

A reserved programme.

)

Channel Manager

Delete or set favourites channels and use the programme guide for digital broadcasts. Select a channel in the Channels, My Channels or Scheduled screen.

c 1 1futech 2 * 24ore.tv

15 abc1

3 BBC World 23 bid-up.tv 33 Boonerang 32 Cartoon Nwk

5 Class News 4 \ Coming Soon 27 Discovery



Tools

Channels

All

Radio Data/Other Analogue

Air Antenna Zoom Select Sort k Page

English

¦ Using Favourite Channels

Channel Menu

03 Basic Features

My Channels

(in Channel Manager) Shows all favourite channels.

■ Edit My Channels channels to desired my channels group.

✎

The “*” symbol will be displayed and the channel will be set as a my channel.

1. Select a channel and press the TOOLS button.

2. Add or delete a channel in the my channel groups

you want among 1, 2, 3 and 4.

One or more groups can be selected.

3. After you have changed the settings, the channel list

for each group can be viewed in my channels.

Channels

Air Antenna Zoom Select Sort k Page

All

Radio Data/Other Analogue

: You can set the selected

c 1 1futech 2 * 24ore.tv

Edit My Channels

15 abc1

Lock

3 BBC World

Timer Recording

23 bid-up.tv

Timer Viewing

33 Boonerang

Edit Channel Number

32 Cartoon Nwk

Delete

5 Class News 4 \ Coming Soon 27 Discovery



Tools

Channel List

You can see all the channels searched. Use to select a customized channel, for the

currently selected input, from the lists All / TV / Radio / Analogue.

✎

The current input is indicated in the bottom left corner of the Channel List window. Select a different input by pressing the A button.

CH LIST

¦ Retuning Channels

Antenna (Air / Cable)

Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to the TV (i.e. an Air or a Cable system).

Country

The PIN input screen appears. Enter your 4 digit PIN number.

■ Digital Channel: Change the country for digital channels.

■ Analogue Channel: Change the country for analogue channels.

Auto Store

Scans for a channel automatically and stores in the TV.

✎

Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked using the Child Lock function, the PIN input window appears.

■ Antenna Source (Air / Cable) antenna source to memorise.

■ Channel Source (Digital & Analogue / Digital / Analogue): Select the channel source to memorise.

When selecting Cable → Digital & Analogue or Digital: Provide a value to scan for cable channels.

Search Mode (Full / Network / Quick): Scans for all channels with active broadcast stations and stores them in the TV.

✎

If you select Quick, you can set up the Network,

Network ID, Frequency, Modulation and Symbol Rate manually by pressing the button on

the remote control.

Network (Auto / Manual): Selects the Network ID setting mode among Auto or Manual.

Network ID: When Network is Manual, you can set up Network ID using the numeric buttons.

Frequency: Displays the frequency for the channel.

(differs in each country)

Modulation: Displays available modulation values. Symbol Rate: Displays available symbol rates.

: Select the

English

Basic Features

Manual Store

Scans for a channel manually and stores in the TV.

✎

If a channel is locked using the Child Lock function, the PIN input window appears.

■ Digital Channel: When scanning has ﬁnished, channels are updated in the channel list.

✎

When selecting Antenna → Air: Channel, Frequency, Bandwidth

✎

When selecting Antenna → Cable: Frequency, Modulation, Symbol Rate

■ Analogue Channel (Programme, Colour System, Sound System, Channel, Search): If there is abnormal sound or no sound, reselect the sound standard required.

✎

Channel mode

P (programme mode): When tuning is complete,

the broadcasting stations in your area have been assigned to position numbers from P0 to P99. You can select a channel by entering the position number in this mode.

C (aerial channel mode) / S (cable channel mode):

These two modes allow you to select a channel by entering the assigned number for each aerial broadcasting station or cable channel.

¦ Editing Channels

Channel Manager Option Menu (in Channel Manager)

1. Select a channel and press the TOOLS button.

2. Edit the channel name or number using the Edit Channel Name or Edit Channel Number menu.

■ Edit Channel Name (analogue channels only): Assign your own channel name.

■ Edit Channel Number (digital channels only): Edit the number by pressing the number buttons desired.

¦ Other Features

Channel Manager

Channel Manager Option Menu

Set each channel using the Channel Manager menu options (Lock / Unlock, Timer Viewing, Sort, Delete, Select All / Deselect All). Option menu items may differ depending on the channel status.

1. Select a channel and press the TOOLS button.

2. Select a function and change its settings.

■ Lock / Unlock: Lock a channel so that the channel cannot be selected and viewed.

✎

NOTE

This function is available only when the Child Lock

is set to On. The PIN input screen appears. Enter your 4-digit PIN,

the default of which is “0-0-0-0”. Change the PIN using the Change PIN option.

■ Timer Recording (digital channels only): Allows you to record a programme currently being broadcasted or make a reservation to record a programme scheduled for broadcast.

✎

A USB device with 4GB of memory or greater must be connected to the T V.

✎

A USB storage device cannot record until it completes the Device Performance Test.

■ Timer Viewing: You can set a desired channel to be displayed automatically at the reserved time. Set the current time ﬁrst to use this function.

✎

When a digital channel is selected, press the ► button to view the digital Programme.

■ Sort (analogue channels only): This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using the auto store.

■ Delete: You can delete a channel to display the channels you want.

■ Select All / Deselect All: Select all the channels or deselect all the selected channels in the channel manager.

Cable Search Option

(depending on the country) Sets additional search options such as the frequency and

symbol rate for a cable network search.

■ Freq.Start / Freq.Stop: Set the start or stop frequency (differs in each country).

■ Modulation: Displays available modulation values.

■ Symbol Rate: Displays available symbol rates.

English

Scheduled

(in Channel Manager) You can view, modify or delete a show you have reserved to

watch.

■ Change Info: Change a show you have reserved to watch.

■ Cancel Schedules: Cancel a show you have reserved to watch.

■ Information: Display a show you have reserved to watch. (You can also change the reservation information.)

■ Select All / Deselect All: Select or deselect all reserved programmes.

¦ Adjusting Picture Settings

Backlight / Contrast / Brightness / Sharpness / Colour / Tint (G/R)

Your television has several setting options for picture quality control.

✎

NOTE

In analogue TV, Ext., AV modes of the PAL system,

the Tint (G/R) function is not available. In PC mode, you can only make changes to

Backlight, Contrast and Brightness. Settings can be adjusted and stored for each

external device connected to the TV.

03 Basic Features

Channel List Transfer

The PIN input screen appears. Enter your 4 digit PIN number. Imports or exports the channel map. You should connect a USB storage to use this function.

■ Import from USB: Import channel list from USB.

■ Export to USB: Export channel list to USB. this function is available when USB is connected.

Fine Tune

(analogue channels only) If the signal is weak or distorted, ﬁne tune the channel

manually.

✎

Fine tuned channels are marked with an asterisk “*”.

✎

To reset the fine-tuning, select Reset.

Picture Menu

¦ Changing the Preset Picture Mode

Mode

Select your preferred picture type.

■ Dynamic: Suitable for a bright room.

■ Standard: Suitable for a normal environment.

■ Natural: Suitable for reducing eye strain.

✎

Natural is not available in PC mode.

■ Movie: Suitable for watching movies in a dark room.

¦ Economical Solutions

Eco Solution

■ Energy Saving (Off / Low / Medium / High /

Picture Off / Auto)

brightness of the TV in order to reduce power consumption. If you select Picture Off, the screen is turned off, but the sound remains on. Press any button except volume button to turn on the screen.

■ Eco Sensor (Off / On): To enhance your power savings; the picture settings will automatically adapt to the light in the room.

✎

If you adjust the Backlight, the Eco Sensor will be set to Off.

Min Backlight: When Eco sensor is On, the minimum screen brightness can be adjusted manually.

✎

If Eco Sensor is On, the display brightness may change (become slightly darker or brighter) depending on the surrounding light intensity.

■ No-Signal Power Off (Off / 15 min / 30 min / 60 min): To avoid unnecessary energy consumption, set how long you want the TV to remain on if it's not receiving a signal.

✎

Disabled when the PC is in power saving mode.

: This adjusts the

English

Basic Features

¦ Changing the Picture Options

Advanced Settings

(available in Standard / Movie mode) You can adjust the detailed setting for the screen including

colour and contrast.

✎

In PC mode, you can only make changes to

Dynamic Contrast, Gamma, White Balance and LED Motion Plus.

Advanced Settings

Black Tone : Off ►

Dynamic Contrast : Medium

Shadow Detail : -2

Gamma : 0

Expert Pattern : Off

RGB Only Mode : Off

Colour Space : Native

■ Black Tone (Off / Dark / Darker / Darkest): Select the black level to adjust the screen depth.

■ Dynamic Contrast (Off / Low / Medium / High): Adjust the screen contrast.

■ Shadow Detail (-2~+2): Increase the brightness of dark images.

■ Gamma: Adjust the primary colour intensity.

■ Expert Pattern (Off / Pattern1 / Pattern2): By running the Expert Pattern function, the picture can be calibrated without a generator or ﬁlter. If the OSD menu disappears or a menu other than the Picture menu is opened, the calibration is saved and the Expert Pattern window disappears.

✎

While the Exper t Pattern is running, sound is not outputted.

✎

Only enabled in DTV, Component and HDMI modes.

✎

Disabled for channels that support MHEG if Digital Text is Enable.

■ RGB Only Mode (Off / Red / Green / Blue): You can adjust Colour or Tint (G/R) of Red, Green or Blue for the picture from an external device (DVD player, home theatre, etc.).

▼

Move

Enter

Return

■ Colour Space (Auto / Native / Custom): Adjust the range of colours available to create the image. To adjust

Colour, Red, Green, Blue and Reset, set Colour Space to Custom.

■ White Balance: Adjust the colour temperature for a more natural picture.

R-Offset / G-Offset / B-Offset: Adjust each colour’s (red, green, blue) darkness.

R-Gain / G-Gain / B-Gain: Adjust each colour’s (red, green, blue) brightness.

Reset: Resets the White Balance to it’s default settings.

■ Flesh Tone: Emphasize pink “Flesh Tone.”

■ 10p White Balance (Off / On): Controls the white balance in 10 point interval by adjusting the red, green, and blue brightness.

✎

Available when the picture mode is set to Movie and when the external input is set to HDMI or Component.

✎

Some external devices may not support this function.

Interval: Select interval to adjust. Red: Adjust the red level. Green: Adjust the green level. Blue: Adjust the blue level. Reset: Resets the 10p White Balance to its default

settings.

■ Edge Enhancement (Off / On): Emphasize object boundaries.

■ xvYCC (Off / On): Setting the xvYCC mode on increases detail and colour space when watching movies from an external device (e.g. DVD player) connected to the HDMI or Component IN jacks.

✎

Available when the picture mode is set to Movie and when the external input is set to HDMI or Component.

✎

Some external devices may not support this function.

■ LED Motion Plus (Off / On): Removes drag from fast scenes with a lot of movement to provide a clear picture.

English

Picture Options

✎

In PC mode, you can only make changes to the Colour Tone, Size and Auto Protection Time.

Picture Options

Colour Tone : Normal ►

Size : Auto Wide

Screen Mode : 16:9

Digital Noise Filter : Auto

MPEG Noise Filter : Auto

HDMI Black Level : Normal

Film Mode : Off

■ Colour Tone (Cool / Normal / Warm1 / Warm2)

✎

Warm1 or Warm2 will be deactivated when the picture mode is Dynamic.

✎

Settings can be adjusted and stored for each external device connected to an input on the T V.

■ Size: Your cable box/satellite receiver may have its own set of screen sizes as well. However, we highly recommend you use 16:9 mode most of the time.

Auto Wide: Automatically adjusts the picture size to the 16:9 aspect ratio.

16:9: Adjusts the picture size to 16:9 for DVDs or wide broadcasting.

Wide Zoom: Magniﬁes the picture size more than 4:3.

✎

Adjusts the Position by using ▲, ▼ buttons.

Zoom: Magniﬁes the 16:9 wide pictures vertically to ﬁt the screen size.

✎

Adjusts the Position or Size by using ▲, ▼ button.

4:3: The default setting for a movie or normal broadcasting.

✎

Do not watch in 4:3 format for a long time. Traces of borders displayed on the left, right and centre of the screen may cause image retention(screen burn) which are not covered by the warranty.

Screen Fit: Displays the full image without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p) signals are inputted.

▼

Move



Enter



Return

P.SIZE

✎

NOTE

Depending on the input source, the picture size

options may vary. The available items may differ depending on the

selected mode. In PC mode, only 16:9 and 4:3 modes can be

adjusted. Settings can be adjusted and stored for each

external device connected to an input on the T V. After selecting Screen Fit in HDMI (1080i / 1080p)

or Component (1080i / 1080p) mode: Adjusts the Position or Size by using ▲, ▼, ◄, ► button.

If you use the Screen Fit function with HDMI 720p

input, 1 line will be cut at the top, bottom, left and right as in the overscan function.

■ Screen Mode (16:9 / Wide Zoom / Zoom / 4:3): Available only when picture size is set to Auto Wide. You can determine the desired picture size at the 4:3 WSS (Wide Screen Service) size or the original size. Each European country requires different picture size.

✎

Not available in PC, Component or HDMI mode.

■ Digital Noise Filter (Off / Low / Medium / High / Auto / Auto Visualisation): When the broadcast signal is weak, some static and ghosting may appear. Select one of the options until the best picture is displayed.

Auto Visualisation: When changing analogue channels, displays the intensity of the current signal and deﬁnes the screen noise ﬁlter.

✎

Only available for analogue channels.

■ MPEG Noise Filter (Off / Low / Medium / High / Auto): Reduces MPEG noise to provide improved picture quality.

■ HDMI Black Level (Normal / Low): Selects the black level on the screen to adjust the screen depth.

✎

Available only in HDMI mode (RGB signals).

■ Film Mode (Off / Auto1 / Auto2): Sets the TV to automatically sense and process ﬁlm signals from all sources and adjust the picture for optimum quality.

✎

Available in TV, AV, COMPONENT (480i / 1080i) and HDMI (480i / 1080i).

■ 100Hz Motion Plus (Off / Clear / Standard / Smooth / Custom / Demo): Removes drag from fast scenes with a lot of movement to provide a clearer picture.

✎

If noise occurs on the screen, please set up the 100Hz Motion Plus to Off. If 100Hz Motion Plus is Custom, you can set up the Blur Reduction, Judder Reduction or Reset manually.

✎

If 100Hz Motion Plus is Demo, you can compare the difference of on and off modes.

03 Basic Features

English

Basic Features

Blur Reduction: Adjusts the blur reduction level from video sources.

Judder Reduction: Adjusts the judder reduction level from video sources when playing ﬁlms.

Reset: Reset the custom settings.

■ Auto Protection Time (2 hours / 4 hours / 8 hours / 10 hours / Off): If the screen remains idle with a still image for a certain period of time deﬁned by the user, the screen saver is activated to prevent the formation of ghost images on the screen.

Picture Reset (OK / Cancel)

Resets your current picture mode to its default settings.

¦ Setting up the TV with Your PC

Set the input source to PC.

Auto Adjustment

Adjust frequency values/positions and ﬁne tune the settings automatically.

Not available when connecting with an HDMI/DVI cable.

Screen

■ Coarse / Fine: Removes or reduces picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (Coarse) and Finetune again. After the noise has been reduced, readjust the picture so that it is aligned to the centre of screen.

■ Position: Adjust the PC screen position with direction button (▲ / ▼ / ◄ / ►).

■ Image Reset: Resets the image to default settings.

Using Your TV as a Computer (PC) Display

Setting Up Your PC Software (Based on Windows XP) Depending on the version of Windows and the video card,

the actual screens on your PC may differ in which case the same basic set-up information will almost always be applied. (If not, contact your computer manufacturer or Samsung Dealer.)

1. Click on “Control Panel” on the Windows start menu.

2. Click on “Appearance and Themes” in the “Control

Panel” window and a display dialog-box will appear.

3. Click on “Display” and a display dialog box will appear.

4. Navigate to the “Settings” tab on the display dialog-box.

y The correct size setting (resolution) [Optimum: 1920 X

1080 pixels]

y If a vertical-frequency option exists on your display

settings dialog box, the correct value is “60” or “60 Hz”. Otherwise, just click “OK” and exit the dialog box.

Sound Menu

¦ Changing the Preset Sound Mode

SRS TheaterSound

■ Standard: Selects the normal sound mode.

■ Music: Emphasizes music over voices.

■ Movie: Provides the best sound for movies.

■ Clear Voice: Emphasizes voices over other sounds.

■ Amplify: Increase the intensity of high-frequency sound to allow a better listening experience for the hearing impaired.

¦ Adjusting Sound Settings

Equalizer

Adjusts the sound mode (standard sound mode only).

■ Balance L/R: Adjusts the balance between the right and left speaker.

■ 100Hz / 300Hz / 1kHz / 3kHz / 10kHz (Bandwidth Adjustment): Adjusts the level of speciﬁc bandwidth frequencies.

■ Reset: Resets the equalizer to its default settings.

¦ Sound Systems, Etc.

SRS TruSurround HD (Off / On)

(standard sound mode only) This function provides a virtual 5.1 channel surround sound

experience through a pair of speakers using HRTF (Head Related Transfer Function) technology.

SRS TruDialog (Off / On)

(standard sound mode only) This function allows you to increase the intensity of a voice

over background music or sound effects so that dialog can be heard more clearly.

Audio Language

(digital channels only) Change the default value for audio languages.

✎

The available language may dif fer depending on the broadcast.

English

Audio Format

(digital channels only) When sound is emitted from both the main speaker and the

audio receiver, a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function.

✎

Audio Format option may differ depending on the broadcast. 5.1ch Dolby digital sound is only available when connecting an external speaker through an optical cable.

Audio Description

(not available in all locations) (digital channels only)

This function handles the Audio Stream for the AD (Audio Description) which is sent along with the Main audio from the broadcaster.

■ Audio Description (Off / On): Turn the audio description function on or off.

■ Volume: Adjust the audio description volume.

Auto Volume (Off / Normal / Night)

To equalize the volume level on each channel, set to Normal.

■ Night: This mode provides an improved sound experience compared to Normal mode, making almost no noise. It is useful at night.

Speaker Select (External Speaker / TV Speaker)

A sound echo may occur due to a difference in decoding speed between the main speaker and the audio receiver. In this case, set the TV to External Speaker.

✎

When Speaker Select is set to External Speaker, the volume and MUTE buttons will not operate and the sound settings will be limited.

✎

When Speaker Select is set to External Speaker

TV Speaker: Off, External Speaker: On

✎

When Speaker Select is set to TV Speaker

TV Speaker: On, External Speaker: On

✎

If there is no video signal, both speakers will be mute.

Additional Setting

(digital channels only)

■ DTV Audio Level (MPEG / HE-AAC): This function allows you to reduce the disparity of a voice signal (which is one of the signals received during a digital TV broadcast) to a desired level.

✎

According to the type of broadcast signal, MPEG / HE-AAC can be adjusted between -10dB and 0dB.

✎

To increase or decrease the volume, adjust between the range 0 and -10 respectively.

■ SPDIF Output: SPDIF (Sony Philips Digital InterFace) is used to provide digital sound, reducing interference going to speakers and various digital devices such as a DVD player.

Audio Format: During the reception of a digital TV broadcast, you can select the Digital Audio output (SPDIF) format from the options PCM or Dolby Digital.

✎

By connecting to 5.1ch speakers in a Dolby Digital setup, maximize your interactive 3D sound experience.

Audio Delay: Correct audio-video sync problems, when watching TV or video, and when listening to digital audio output using an external device such as an AV receiver (0ms ~ 250ms).

■ Dolby Digital Comp (Line / RF): This function minimizes signal disparity between a dolby digital signal and a voice signal (i.e. MPEG Audio, HE-AAC, ATV Sound).

✎

Select Line to obtain dynamic sound, and RF to reduce the difference between loud and soft sounds at night time.

Line: Set the output level for signals greater or less than

-31dB (reference) to either -20dB or -31dB. RF: Set the output level for signals greater or less than

-20dB (reference) to either -10dB or -20dB.

Sound Reset (OK / Cancel)

Reset all sound settings to the factory defaults.

03 Basic Features

English

+ 44 hidden pages
