Samsung TC300 User Guide

LED TV MONITOR

(MFM TV)

user manual

TC300

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and speciﬁcations may be changed without notice.

Digital LED display notice

1. Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.

2. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital LED display over cable.

3. Although this LED display set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

4. Depending on the countries/areas where this LED display set is used some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business.

5. Some Digital LED display functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers.

6. For more information, please contact your local Samsung customer care centre.

The reception quality of LED display may be affected due to differences in broadcasting method between the countries. Please check the LED

✎

display performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconﬁguring LED display setting or not.

Still image warning

Avoid displaying still images (like jpeg picture ﬁles) or still image element (like LED display programme logo, panorama or 4:3 image format, stock or news bar at screen bottom etc.) on the screen. Constant displaying of still picture can cause ghosting of screen, which will affect image quality. To reduce risk of this effect, please follow below recommendations:

• Avoid displaying the same LED display channel for long periods.

• Always try do display any image on full screen, use LED display set picture format menu for best possible match.

• Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed up the burnout process.

• Frequently use all LED display features designed to reduce image retention and screen burnout, refer to proper user manual section for details.

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation. Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

The actual appearance of the LED display may differ from the images in this manual, depending on the model.

✎

Be careful when you touch the LED display. Some parts can be somewhat hot.

✎

Installation with a stand. Installation with a wall-mount.

10 cm

• An administration fee may be charged if either – (a) an engineer is called out at your request and there is no defect in the product

 (i.e. where you have failed to read this user manual). – (b) you bring the unit to a repair centre and there is no defect in the product  (i.e. where you have failed to read this user manual).

• The amount of such administration charge will be advised to you before any work or home visit is carried out.

10 cm

English

Getting Started

Connections

Basic Features

Advanced Features

4 Safety Precautions 11 Accessories 12 Viewing the Control Panel 13 Viewing the Remote Control

14 Connecting to an Antenna 14 Setup (Initial Setup) 15 Connecting to an AV Device 16 Connecting to a COMMON INTERFACE slot 17 Connecting to a Audio device and PC 19 Changing the Input Source

19 How to Navigate Menus 20 Using the INFO button (Now & Next guide) 20 Using the Channel Menu 22 Channel Menu 23 Picture Menu 25 Sound Menu 27 System Menu 30 Support Menu

31 Using the Media Play

Other Information

This function can be used by pressing the TOOLST

button on the remote control.

38 Analogue Channel Teletext Feature 39 Attaching a Wall Mount/Desktop Stand 40 Anti-theft Kensington Lock 41 Troubleshooting 45 Speciﬁcations

Check the Symbol!

ENGLISH

Note

Indicates additional information.

English

Getting Started

Icons used for safety precautions

Safety Precautions

WARNING

CAUTION

Do not perform.

Must be followed.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

Failing to follow the precautions marked with this sign may result in a serious injury or even a fatality.

Failing to follow the precautions marked with this sign may result in a personal injury or property damage.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been included with this product.

¦ Power Related

✎

The following images are for your reference and may differ depending on models and countries.

Warning

Avoid using a damaged power cord or plug or a loose power outlet.

Otherwise, it may result in

electric shock or ﬁre.

Avoid connecting multiple electric appliances to a single wall outlet.

Otherwise, it may result in ﬁre due

to overheating of the wall outlet.

Avoid plugging in or unplugging the power supply with wet hands.

Otherwise, it may result in

electric shock.

Make sure to connect the power cord to a grounded wall outlet (for insulation class 1 equipment only).

Otherwise, it may result in

electric shock or injury.

Plug the power plug in ﬁrmly.

Otherwise, it may result in ﬁre.

Avoid bending or twisting the power cord excessively and avoid placing heavy objects on the cord.

Otherwise, it may result in electric

shock or ﬁre due to a damaged power cord.

English

Getting Started

Keep the power cord and the product away from a heater.

Caution

Avoid unplugging the power plug while the product is operating.

When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord.

¦ Installation Related

Warning

Avoid placing burning candles, mosquitorepellentor cigarettes on the product.

Otherwise, it may result in electric shock or ﬁre.

Otherwise, it may damage the product due to electric shock.

Otherwise, it may result in electric shock or ﬁre.

Otherwise, it may result in ﬁre.

If the pins of the power plug or the wall outlet are covered in dust, clean it using a dry cloth.

Otherwise, it may result in ﬁre.

Make sure to use only the power cord supplied by our company. In addition, do not use the power cord of another electric appliance.

Otherwise, it may result in electric

shock or ﬁre.

Connect the power plug to a wall outlet that can be easily reached.

When a problem occurs with the

product, you must unplug the power plug to cut the power off completely. You cannot cut the power off completely using only the power button on the product.

Ask an installation engineer or relevant company to install the product onto the wall.

Otherwise, it may result in injury.

Make sure to use the speciﬁed

wall mount.

Avoid installing the product in a badly-ventilated location such as inside a bookshelf or closet.

Otherwise, it may result in ﬁre

due to internal over-heating.

Avoid installing the product in a location that is unstable or exposed to excessive vibration such as on an unstable or slanted shelf.

The product may fall and this

may result in damage to the product or injury.

If you use the product in a

location exposed to excessive vibrations, it may result in a problem with the product or ﬁre.

Keep the plastic bags used to pack the product away from children.

If children place the plastic

bags over their heads, they may suffocate.

Avoid installing the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and installing it within a vehicle.

This may result in electric shock

or ﬁre.

English

Getting Started

SAMSUNG

Caution

Avoid installing the product in a location exposed to direct sunlight and installing the product near a heat source such as a ﬁreplace or heater.

This may shorten the product

life cycle or cause ﬁre.

Bend the outdoor antenna cable downwards at the location where it comes in the house so that rainwater does not ﬂow in.

If rainwater enters the product,

it may result in electric shock or ﬁre.

Do not let the product drop while moving it.

This may result in a problem

with the product or injury.

When installing the product on a console or shelf, make sure that the front of the product does not protrude out of the console or shelf.

Otherwise, this may cause the

product to fall off and result in a malfunction or injury.

Make sure to use a cabinet or

shelf suitable to the size of the product.

If the product is installed in a location where the operating conditions vary considerably, a serious quality problem may occur due to the surrounding environment. In this case, install the product only after consulting one of our service engineers about the matter.

Places exposed to microscopic

dust, chemicals, too high or low temperature, high humidity, airports or stations where the product is continuously used.

Avoid installing the product where children may reach it.

If a child touches the product,

the product may fall and this may result in injury.

Since the front part is heavier,

install the product on a ﬂat and stable surface.

Install the antenna far away from any high voltage cables.

If the antenna touches or falls

onto a high voltage cable, it may result in electric shock or ﬁre.

Do not place the product face down on the ﬂoor.

This may damage the panel of

the product.

When putting the product down, handle it gently.

Otherwise, it may result in a

problem with the product or injury.

English

Getting Started

¦ Cleaning Related

Warning

Before cleaning the product, unplug the power cord.

Otherwise, it may result in

electric shock or ﬁre.

Caution

Avoid spraying cleansing agent directly onto the product.

This may result in discoloration

or cracking of the exterior of the product or the panel coming off.

When cleaning the product, do not spray water directly over the product parts.

Make sure that water does not

enter the product. Otherwise, it may result in ﬁre,

electric shock or a problem with the product.

When cleaning the product, disconnect the power cord and clean the product with the supplied cleaning cloth.

Avoid using chemicals such as

wax, benzene, alcohol, thinner, mosquitorepellent, fragrance, lubrication or cleansing agent when cleaning the product.

 This may result in the exterior

being deformed or the print being removed.

¦ Usage Related

Warning

If you can't get the product clean with just the supplied cloth, use a soft, damp cloth with a "monitorexclusive cleansing agent" and wipe the product with it.

If no monitor-exclusive cleansing

agent is available, dilute a cleansing agent with water at a ratio of 1:10 before cleaning the product.

Since a high voltage runs through the product, never disassemble, repair or modify the product yourself.

Otherwise, it may result in ﬁre or

electric shock. If the product needs to be ﬁxed,

contact a service centre.

Since the exterior of the product is easily scratched, be sure to use the supplied cleansing cloth.

To move the product, turn the power off and unplug the power cord, the antenna cable and any other wires connected to the product.

Otherwise, it may result in electric

shock or ﬁre due to the damaged power cord.

English

Getting Started

GAS

100

If the product generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact a service centre.

Otherwise, it may result in

electric shock or ﬁre.

If you drop the product or the case is damaged, turn the power off and unplug the power cord. Contact a service centre.

Otherwise, it may result in ﬁre or

electric shock.

When thunder or lighting occurs, unplug the power cord and under no circumstance touch the antenna cable as this is dangerous.

Otherwise, it may result in

electric shock or ﬁre.

Avoid moving the product by pulling the power cord or antenna cable.

Otherwise, it may result in

electric shock, ﬁre or a problem with the product due to damage to the cable.

Avoid letting children hang or climb onto the product.

Otherwise, it may result in the

product falling and this may result in injury or death.

Avoid placing objects such as toys and cookies on top of the product.

If a child hangs over the product

to grab an object, the object or the product may fall and this may result in injury or even death.

Avoid dropping an object over the product or cause impact to the product.

Otherwise, it may result in electric

shock or ﬁre.

When a gas leak occurs, do not touch the product or the power plug and ventilate immediately.

A spark may result in an

explosion or ﬁre. During a thunder or lighting

storm, do not touch the power cord or antenna cable.

Avoid lifting up or moving the product by holding only the power cord or signal cable.

Otherwise, it may result in

electric shock, ﬁre or a problem with the product due to damage to the cable.

Take care not to block the vent by a table cloth or curtain.

Otherwise, it may result in ﬁre

due to internal overheating.

Avoid using or placing inﬂammable spray or objects near the product.

This may result in an explosion

or ﬁre.

Avoid inserting metal objects such as a chopsticks, coins or hairpins, or inﬂammable objects into the product (the vents, ports, etc).

If water or substances enters

the product, turn the power off, unplug the power cord and contact a service centre.

Otherwise, it may result in a

problem with the product, electric shock or ﬁre.

English

Getting Started

-_-

Caution

Avoid placing a liquid container such as a vase, ﬂowerpot, beverage, cosmetics or drugs, or a metal object over the product.

If water or substances enter

the product, turn the power off, unplug the power cord and contact a service centre.

Otherwise, it may result in a

problem with the product, electric shock or ﬁre.

Displaying a still image for a long time may create a persistent image or stain on the screen.

If you do not use the product

for a long time, use the power-saving mode or set the screensaver to the moving picture mode.

Set the appropriate resolution and frequency for the product.

Otherwise, it may result in eye

strain.

Do not press down hard on the product. The product may become deformed or damaged.

When not using the product for a long time such as leaving your home, unplug the power cord from the wall outlet.

Otherwise, it may cause dust

accumulation and result in ﬁre caused by overheating or short circuit or result in an electric shock.

Avoid turning the product upside down or move the product holding only the stand.

This may cause the product to

fall, resulting in damage to the product or injury.

Watching the product from too close a distance continuously may damage your eyesight.

It is important to give your eyes some rest (5 minutes every hour) when viewing the product screen for long periods of time.

This will alleviate any eye strain.

Avoid using a humidiﬁer or cooker near the product.

Otherwise, it may result in electric

shock or ﬁre.

Since the display panel is hot after using it for a long time, do not touch the product.

English

Getting Started

Keep the small accessories in a location out of the reach of children.

Avoid placing a heavy object over the product.

Otherwise, it may result in a

problem with the product or injury.

Be careful that children do not place the batteries in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

If children have had the battery

in their mouths, consult your doctor immediately.

Use only speciﬁed standard batteries. Do not use new and used batteries together.

This may cause a battery to

break or leak and may cause ﬁre, injury, or contamination (damage).

Take care when adjusting the angle of the product or the height of the stand.

If your hand or ﬁnger is caught,

you may be injured. If the product is tilted excessively,

the product may fall and this may result in injury.

When replacing the batteries, insert them with right polarity (+, -).

Otherwise, the battery may

become damaged or it may cause ﬁre, personal injury or damage due to leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

The customer can return used

or rechargeable batteries to a nearby public recycling centre or to a store selling the same type of the battery or rechargeable battery.

English

Getting Started

Accessories

✎

Please make sure the following items are included with your LED display. If any items are missing, contact your dealer.

✎

The items’ colours and shapes may vary depending on the models.

✎

Cables not included in the package contents can be purchased separately.

✎

Check that there is no accessory hidden behind packing materials when you open the box.

CAUTION: INSERT SECURELY LEST SHOULD BE DETACHED IN SET

[

User Manual



Remote Control & Batteries (AAA x 2)



Warranty Card / Safety Guide (Not available in some locations)



Stand Connector Stand Base D-Sub Cable Stereo Cable

Input Cables (Sold Separately)

Quick Setup Guide



Cleaning Cloth



Power Cord



HDMI to DVI Cable Audio Cable Component Cable HDMI Cable

English

Getting Started

Viewing the Control Panel

✎

The product colour and shape may vary depending on the model.

Control Panel

SOURCE

MENU Displays an on-screen menu, the OSD (on screen display) of your LED display's features.

(Power)

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

Remote control sensor Aim the remote control towards this spot on the LED display.

Standby mode

Do not leave your LED display in standby mode for long periods of time (when you are away on a holiday, for example). A small amount of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

Toggles between all the available input sources. In the on-screen menu, use this button as you would use the ENTERE button on the remote control.

Adjusts the volume. In the OSD, use the buttons on the remote control.

Changes the channels. In the OSD, use the and d buttons on the remote control.

Turns the LED display on or off.

buttons as you would use the l and r

buttons as you would use the u

English

Getting Started

Viewing the Remote Control

✎

This is a special remote control for the visually impaired and has Braille points on the Channel and Number buttons.

Turns the TV on and off.

Have direct access to channels.

Alternately select Teletext ON, Double,

Mix or OFF.

Adjusts the volume.

Displays the main on-screen menu.

Displays the Contents Home, which

includes Channel List, Guide, Media

Play, Schedule Manager, and Source.

Quickly select frequently used functions.

Move the cursor and select an item.

Conﬁrm the setting.

Returns to the previous menu.

Use these buttons according to the

direction on screen.

PIP: Turns the PIP on or off.

P.SIZE: Selects the Picture Size.

AD/SUBT.: Turns the audio description

on and off (not available in some

locations). / Displays digital subtitles.

Displays and selects the available video sources.

Returns to the previous channel.

Cuts off the

Changes channels.

Displays channel lists on the screen. Displays the EPG (Electronic Programme

Guide).

Displays information on the TV screen.

Exits the menu.

Using these buttons in Media Play mode.

sound temporarily.

Installing batteries (Battery size: AAA)

English

Connections

Connecting to an Antenna

When the LED display is initially powered on, basic settings proceed automatically.

✎

Preset: Connecting the mains and antenna.

ANT OUT

Power Input

Setup (Initial Setup)

When the LED display is initially powered on, a sequence of on-screen prompts will assist in conﬁguring basic settings. Press the

POWERP button. Setup is available only when the Input Source is set to TV.

✎

Before turning on the LED display, make sure the antenna cable is connected.

Selecting a menu

language Selecting Store Demo

or Home Use

Selecting an area

Auto Tuning

Setting the Clock Mode Set the Clock Mode automatically or manually.

Complete

Press the twice when done.

Press the

Press the ENTER Press the ENTER Press the

ﬁnd and store channels on your TV. Do you need to search for channels?

Press the ENTER

or d button to select a menu language. Press ENTERE button

or d button, then press the ENTERE button.

Select the Home Use mode. Store Demo Mode is for retail environments.

To return the unit’s settings from Store Demo to Home Use (standard):

Press the volume button on the LED display. When you see the volume OSD, press and hold MENU for 5 sec.

Store Demo is only for shop display. If you select it, several functions are

not able to use. Please select Home Use when you watch at home.

button. Select the appropriate area by pressing the u or d button.

button to conﬁrm your choice.

or d button to select correct option, and then press ENTERE button twice. Let’s

Yes, I need to. All the channels available will be found and stored on your TV. (Auto Tuning

necessary) No, I don’t need to. My set-top box provides all the channels that are available, so I don't

need to search for channels.

✎

You can complete Setup by selecting it.

Air / Cable: Select the antenna source to memorise.

Digital & Analogue / Digital / Analogue: Select the channel source to memorise.

✎

You can check more details on page22.

Auto: Select the time zone (depending on the country) where you are located.

Manual: Allows you to manually set the current date and time.

✎

If the customer chooses "No, I don’t need to." in step 4, the clock just can be set manually.

button.

If You Want to Reset This Feature...

Select System - Setup (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0”. If you want to change the PIN number, use the Change PIN function. You should do Setup (MENU → System) again at home although you did in shop.

✎

If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets the PIN to “0-0-0-0”: POWER (off) → MUTE → 8 → 2 → 4 → POWER (on).

English

Connections

Connecting to an AV Device

Using an HDMI or an HDMI to DVI cable (up to 1080p)

Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, VCR

HDMI OUT

DVI OUT

AUDIO OUT

✎

HDMI IN(DVI) / PC/DVI AUDIO IN

If an HDMI to DVI cable is connected to the HDMI IN(DVI) port, the audio does not work.

The picture may not display normally (if at all) or the audio may not work if an external device that uses an older version of

HDMI mode is connected to the LED display. If such a problem occurs, ask the manufacturer of the external device about the HDMI version and, if out of date, request an upgrade.

Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may occur.

A basic high-speed HDMI cable or one with ethernet is recommended. This product does not support the ethernet

function via HDMI.

Using a Scart Cable

Available devices: DVD, VCR

DVD /

Blu-ray player

DVD /

Blu-ray player

EXT (RGB)

✎

In Ext. mode, DTV Out supports MPEG SD Video and Audio only.

VCR / DVD

EXT

English

+ 32 hidden pages
