Samsung SR-74NMC, SR-69NMC, SR-67KTC, SR-671KTC, SR-65KTC User Manual [en, de, sk]
...
SR-61.../65/69/74... 2/8/00 2:43 PM Page 1
SR-61... SR-64..
SR-65... SR-67..
SR-69... SR-74..
OWNER’S INSTRUCTIONS
DA68-00611A REV(0.1)
SR-61.../65/69/74... 2/8/00 2:43 PM Page 1
F E AT U R E S
What is H.M.CYCLE(High-efficiency Multievaporator CYCLE)?
• Ahigh efficiency cooling method adopting
an independent cooler and an independent
cooling fan in freezing room and
refrigerating room, respectively.
• Anew cooling method providing an
economic energy, power cooling function
and supply of high humidity cool air by
independent cooler and cooling fan.
Surround Cooling System
• Freshness depends on cooling speed. T h e
surround cooling system blows cold air to
every corner for powerful cooling.
Door in Door (option)
• You don’t need to open the heavy door
thanks to this feature. And it is free from
frequent door openings and saves energy
g r e a t l y.
ELECTRONIC CONTROL
D I S P L AY ( o p t i o n )
• Foods can be stored in the fresh by cooling
quickly the foods when the of quick
refrigeration or freezing is selected.
C O N T E N T S
F E AT U R E S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
WARNINGS / SAFETYP R E C A U T I O N S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
I N S TALLING THE FRIDGE / FREEZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
P R E PARING THE FRIDGE / FREEZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
USING THE CONTROLF E AT U R E
USING THE C O N T R O LF E AT U R E
S TORING FOOD IN THE REFRIGERATOR OR FREEZER. . . . . 8
MAKING ICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
HOW TO DISASSEMBLE THE A C C E S S O R I E S. . . . . . . . . . . . . . . . . . .1 0
REPLACING THE INTERIOR LIGHT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
PROBLEMS AND SOLUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 2
USAGE PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 3
VIEW OF YOUR FRIDGE / FREEZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 4
( D I A LC O N T R O LT Y P E )
(ELECTRONIC CONTROLT Y P E )
. . . . . . . . . . . . . . .6
. . . . 7
1
SR-61.../65/69/74... 2/8/00 2:43 PM Page 2
WARNINGS / SAFETY P R E C A U T I O N S
To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to
observe the following safety precautions. (After reading these owner’s instructions, please keep them in
a safe place for reference). Remember to hand them over to any subsequent owner.
Indicates that a danger of death or
Wa r n i n g
Do not plug several appliances into the same
s o c k e t s .
• This could cause overheating and the risk of fire.
Keep the power plug away from the rear of the
f r i d g e / f r e e z e r.
• Adamaged power plug may cause fire due to
o v e r h e a t i n g .
Do not directly spray water inside or outside
the fridge/freezer.
• There is a risk of fire or electric shock.
Do not spray inflammable gas near the
f r i d g e / f r e e z e r.
• There is a risk of explosion or fire.
Do not bend the power cord excessively or
place heavy articles on it.
This constitutes a fire hazard.
serious injury exists.
Warning
C a u t i o n
Do not disassemble, repair or alter the
a p p l i a n c e .
• It may cause fire or abnormal operations, which
may lead to injury.
Pull the power plug out of the socket before
replacing the interior light in the refrigerator.
• Otherwise, there is a risk of electric shock.
Be sure to earth the appliance.
• Otherwise, it may cause material damage and
electric shock.
If you wish to dispose of the fridge/freezer,
throw it away after removing the door or its
s e a l s .
• In this way, it is not possible for a child to remain
trapped inside it.
If the power cord
is damaged, have it replaced immediately by the
m a n u f a c t u r e r, its service agent or a similarly
qualified person.
Do not insert the power plug with wet hands.
• You may receive an electric shock.
Do not put a container filled with water on top
of the appliance.
• If the water spills on to any electrical parts, it may
lead to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
• Incorrect insulation of the electrical parts may
cause an electric shock or fire.
Do not store volatile and inflammable
substances in the refrigerator.
• The storage of benzene, thinner, alcohol, ether,
L P gas or other such substances may cause an
e x p l o s i o n .
Indicates that a risk of personal
injury or material damage exists.
2
SR-61.../65/69/74... 2/8/00 2:43 PM Page 3
Warning
• Keep ventilation openings in the appliance
enclosure or mounting structure clear of
o b s t r u c t i o n .
• Do not use mechanical devices or any other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the
f r i d g e / f r e e z e r, unless they are a type
recommended by the manufacturer.
Do not touch any containers and food in the
freezer with wet hands.
• It may cause frostbite.
Remove any foreign matter from the power plug
p i n s .
• Otherwise, there is a risk of fire.
Do not insert your hand into the bottom area of
the appliance.
• Any sharp edges may cause personal injury.
After unplugging the appliance, wait for at least
five minutes before plugging it in again to the
wall socket.
• Abnormal operation of the freezer may cause
Caution
If the appliance is not to be used for a long
Do not store too much food in the appliance.
• When you open the door, an item may fall out and
cause personal injury or material damage.
Do not put bottles or any kinds of glass in the
f r e e z e r.
• The container may break and cause personal
i n j u r y.
If the wall socket is loose, do not insert the
power plug.
• May cause electric shock or fire.
Do not disconnect the power cord by pulling
o n i t .
• You may disconnect a wire and cause a short
c i r c u i t .
Do not store articles on top of the appliance.
• When you open or close the door, the articles m a y
fall and cause personal injury or materiald a m a g e .
Do not store pharmaceutical products,
scientific materials or other temperaturesensitive products in the refrigerator.
• Products that require strict temperature controls
must not be stored in the refrigerator.
Do not let a child hang from the door.
period of time, pull out the power plug.
• Any deterioration in the insulation may cause fire.
Do not let children touch or play with the
controller of the appliance.
• Do not allow children to play with this appliance.
• Repairs and maintenance of the appliance should
• Never put ice cubes or ice lollies straight from the
material damage.
only be performed by a qualified technician.
Incorrect repairs by an unqualified person are a
potential source of danger that may have critical
consequences for the user of the appliance.
freezer into your mouth. (The low temperature
may cause “freezer burns”.)
3
SR-61.../65/69/74... 2/8/00 2:43 PM Page 4
I N S TALLING THE FRIDGE/FREEZER
Allow an adequate space and install the fridge/freezer on a firm, level floor.
• If the appliance is not level, there may be unusual noises and poor cooling.
• Wait for at least one hour before plugging the appliance in.
Clean the fridge/freezer.
• Wipe and clean the appliance inside and outside with a damp cloth.
Plug the fridge/freezer into a wall socket used exclusively by this appliance.
• This appliance must be properly earthed.
Place the food in the fridge/freezer.
• It is recommended that you wait for the appliance to cool for 2-3 hours before storing food in it.
Warning
Use of an earthed socket exclusively for the appliance:
• If you are using a socket with an earthing terminal, you
d o not require a separate earthing connection.
Use of a non-earthed socket:
• Connect the “earthing wire” to the copper plate and bury
i t at a depth of at least 25 cm in the ground.
L E V E L L I N G
If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily.
The appliance tilts down to the left.
Turn the left adjusting leg in the direction of the arrow until
the appliance is level.
The appliance tilts down to the right.
Turn the right adjusting leg in the direction of the arrow
until the appliance is level.
4
