Samsung SPR7100 User Manual

Digital Cordless Telephone
SP-R7100
User’s Manual
Your batteries are guaranteed for six months. Please ensure you FULLY CHARGE the batteries for a period of AT LEAST 10 HOURS BEFORE you use your phone to make a call.
This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to emergency services.
ELECTRONICS
Printed in Korea
Code No. : GG68-00000A
English. 11/2002. Rev.1.0
9. This unit requires rechargeable Ni-MH batteries. Do not use alkaline batteries.
10. Clean the charge points with a dry
cloth from time to time.
11. Ringer Equivalence Number (REN)-1.0.
The REN is a customer guide indicating approximately the maximum number of items of apparatus that should be connected simultaneously to the line. The sum of REN’s of the individual items should not exceed a total value of 4.
12. You can use this equipment to make
999, or 112 emergency calls.
13. You can use this equipment on a
telecommunication system that uses Loop Disconnect or DTMF signalling.
It is strongly recommended that the equipment is configured to use DTMF signalling for access to public or private emergency services. DTMF signalling also provides faster call setup.
14. If you are connected to a Private
Branch Exchange, you may have to press a digit, for example “9”, to get an outside line. Then you dial as normal. If you need a pause, you should insert it after the digit and before the number you require.
15. You may sometimes experience problems in making calls. These difficulties can include:
• Line connection problems.
• Problems hearing the conversation on both ends of the line.
16. This equipment will NOT work at all if the mains or battery supply is removed.
17. You can connect the equipment to the telecommunication systems specified as long as you follow the instructions in this manual.
18. This equipment has been approved for use with the following facilities:
• Last Number Redial.
• Call Barring.
• Memory Dial.
Any other use will invalidate the approval of the equipment and it then ceases to comply with the standards against which approval was granted.
19. SAVE THESE INSTRUCTIONS.
1. Never push objects of any kind into your telephone through case or cabinet openings as they may touch dangerous voltage points resulting in risk of fire or shock.
2. To reduce the risk of electric shock, do not disassemble your telephone. Take it to a qualified service technician if repair work is required. Opening or removing covers may expose you to dangerous voltage or other risks. Incorrect reassembly could cause electric shock when the unit is subsequently used.
3. Unplug this unit from the telephone jack and wall outlet, and refer servicing to qualified service personnel under the following conditions:
• When the power supply cord, plug, or adaptor is damaged or frayed.
• If liquid has been spilled into the product.
• If the product has been exposed to rain or water.
• If the product does not operate properly after instructions have been followed.
• If the product has been dropped, or the cabinet appears damaged.
• If the product exhibits a distinct change in performance.
4. Avoid using your telephone during a lightning storm. There may be a remote risk of electric shock from lightning. If possible, unplug the AC adaptor and telephone cord for the duration of the lightning storm.
5. Never dispose of batteries in a fire. There is a serious risk of explosion and / or the release of highly toxic chemicals. Dispose of used batteries in accordance with local regulations.
6. When going on holiday or not using the phone for a long period of time, please disconnect the mains power from the base and remove the battery from the handset.
7. If the handset is not used for a long time and the battery becomes fully discharged, please recharge the handset for a minimum of 10 hours before using again.
8. If the battery is self-discharged because it has not been used, the operational life of the battery may be reduced. To recover the full storage capacity of the battery, recharge the battery for a minimum of 10 hours and use until it is fully discharged. This process needs to be repeated several times.
Safety Precautions and Important Notice
When using your telephone, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury.
2 3
54
Getting Started
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing Handset Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Charging the Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Turning the Handset On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
LCD Window Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Choosing Dial Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General Functions
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Camp on Busy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Last Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Caller ID Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Out of Range Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Battery Level Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Key Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tone Dial Switchover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Registered Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Intercom Between Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Call Transfer Between Handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Using the Menus
Accessing a Menu Option by Scrolling . . . . . . . . . . . . . . . . . . . . . . . 26
Accessing a Menu Option by Index System . . . . . . . . . . . . . . . . . . . . 27
Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PhoneBook
Storing Phone Numbers and Names in the Phonebook . . . . . . . . . . . 29
Recalling a Number from Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . 31
Deleting Number(s) from the Phonebook . . . . . . . . . . . . . . . . . . . . . . 33
Call Log
Viewing and Dialling the Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Saving the Received Numbers in Phonebook . . . . . . . . . . . . . . . . . . . 36
Deleting the Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Greeting Message
Writing Greeting Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Barring
Setting Call Bar Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Ring
Selecting Ring Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Time
Call Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Ring Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting
Key Beep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Back Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Base Number Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Language Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Changing Flash Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
System
Registering a New Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Removing a Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Resetting a Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Changing PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Base
Selecting Base Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Finding Base Automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
