COAXIAL REMOTE CONTROLLER

User Manual

SPC-300

•

COAXIAL REMOTE CONTROLLER

User Manual

Tra dem ark

The name of t his product is the re gistered tradem ark of Samsung Techwin C o., Ltd. Other tr ademarks mentio ned in this manual are t he registered tr ademark of their res pective compan y.

Restriction

Samsung Tech win Co., Ltd shall res erve the copyri ght of this document . Under no circumst ances, this docu ment shall be rep roduced, distr ibuted or changed , partially or who lly, without formal a uthorization o f Samsung Techwin.

Disclaimer

Samsung Tech win makes the best to v erify the integr ity and correc tness of the conte nts in this documen t, but no form al guarantee shall b e provided. Use of t his document and the s ubsequent resul ts shall be entirely on the user ’s own responsibili ty. Samsung Techwin res erves the right t o change the conten ts of this document without prior notice.

Warra nty

If the pro duct does not oper ate properly in no rmal conditions , please let us know. S amsung Techwin will res olve the probl em for free of charge. T he warranty pe riod is 3 years. How ever, the followings ar e excluded:

•

Data los s due to a damaged hard di sk

•

If the sys tem behaves abnorm ally because you r un a program irrelev ant to the system op eration.

•

Data los s due to virus infect ion

•

Deteriorated performance or natural worn-out in process of time

•

Sensor y phenomenon tha t does not affect t he performanc e or quality of the pr oduct (ex: worki ng noise).

is the regis tered logo of Sams ung Techwin Co., Ltd.

Safety information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.

This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

To reduce the risk of ﬁ re or electric shock, do not expose this appliance to rain

•

or moisture.

WARNING

Be sure to use only the standard adapter that is speciﬁ ed in the speciﬁ cation sheet.

1. Using any other adapter could cause ﬁ re, electrical shock, or damage to the product.

Incorrectly connecting the power supply or replacing battery may cause

2. explosion, ﬁ re, electric shock, or damage to the product.

Do not connect multiple controllers to a single adapter. Exceeding the capacity

3. may cause abnormal heat generation or ﬁ re.

Securely plug the power cord into the power receptacle. Insecure connection

4. may cause ﬁ re.

When installing the controller, fasten it securely and ﬁ rmly. The fall of controller

5. may cause personal injury.

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or

6. containers ﬁ lled with water on top of the controller. Doing so may cause personal injury due to ﬁ re, electric shock, or falling objects.

Do not install the unit in humid, dusty, or sooty locations. Doing so may cause ﬁ re

7. or electric shock.

If any unusual smells or smoke come from the unit, stop using the product. In

8. such case, immediately disconnect the power source and contact the service center. Continued use in such a condition may cause ﬁ re or electric shock.

If this product fails to operate normally, contact the nearest service center. Never

9. disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modiﬁ cations or attempted repair.)

When cleaning, do not spray water directly onto parts of the product. Doing so

10.

may cause ﬁ re or electric shock.

English 3

Safety information

CAUTION

Do not drop objects on the product or apply strong blows to it. Keep away from a

1. location subject to excessive vibration or magnetic interference.

Do not install in a location subject to high temperature (over 50°C), low

2. temperature (below -10°C), or high humidity. Doing so may cause ﬁ re or electric shock.

If you want to relocate the already installed product, be sure to turn off the power

3. and then move or reinstall it.

Remove the power plug from the outlet when there is a lighting storm. Neglecting

4. to do so may cause ﬁ re or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause ﬁ re.

Install it in a place with good ventilation.

Avoid aiming the controller directly towards extremely bright objects such as sun.

Apparatus shall not be exposed to dripping or splashing and no objects ﬁ lled with

8. liquids, such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at

9. any time.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

4 – COAXIAL REMOTE CONTROLLER

Important Safety Instructions

Read these instructions.

ing.

ct.

sal.

s.)

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the

7. manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, or other

8. apparatus (including ampliﬁ ers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A

9. polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs,

10.

convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories speciﬁ ed by the

11.

manufacturer.

Use only with cart, stand, tripod, bracket, or table

12.

speciﬁ ed by the manufacturer, or sold with the apparatus.

Unplug this apparatus when a card is used. Use caution

13.

when moving the cart/ apparatus combination to avoid injury from tip-over.

Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the

14.

apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

English 5

Contents

❖

Introduction

Introduction 6

Part names and functions 7

Installation

Checking Installation Environment 11

Installation precautions 11

Connection & Control

To Control the camera coaxial communications 12

To control the camera using RS-485 device via coaxial communications 13

To control the camera using RS-232 device via coaxial communications 14

To control the camera using RS-485 signal output 15

To control the camera using RS-485 signal output via RS-232 communications 16

Switch Setting Table 17

Speciﬁ cations

Speciﬁ cations 20

Dimensions 21

6 – COAXIAL REMOTE CONTROLLER

Introduction

INTRODUCTION

This remote controller can control A1 series cameras through A1 coaxial connection, and can control COAXITRON supporting cameras through COAXITRON communication.

Features

❖

Long-distance remote control

•

Through RS-485 communication, remote control is possible up to 1.2 kilometers.

Easy Control

•

Easy and simple 5-way keys for controlling the camera.

List of controllable models

❖

Capable of controlling A1 series camera products.

•

You can control cameras supporting COAXITRON.

What’s Included

❖

COAXIAL REMOTE CONTROLLER

SPC-300

User Manual

English 7

Introduction

356

PROTOCOL

❻

❼

PART NAMES AND FUNCTIONS

Front Panel❖

POWER

o p

STATUS LED

❶

- Displays the status of the current operation.

❷

POWER LED

- Switch to select the power source from DC 12 V or 4 AA batteries.

❸

POWER Switch

- If you slide it to ON, the controller turns on.

CABLE COMPENSATION Switch

❹

- For long distance coaxial communications, you can use this switch for amplifying

the control signal.

RS-485 TERMINATION & PROTOCOL Setting Switch

❺

- You can select to set the RS-485 termination (left 2-pin piano switch).

- To set the RS-485 termination (left 2-pin piano switch), turn the switch ON.

1ON2

TERMINATION

8 – COAXIAL REMOTE CONTROLLER

POWER

OFF ON

CABLE COMPENSATION

STATUS

ADDRESS

(X)100 (X)10

1ON2345678

1ON2

TERMINATION PROTOCOL

1ON2345678

PROTOCOL

(X)1

REMOTE CONTROLLER SPC-300

Introduction

For multi-protocol settings, you can set the protocol (right 8-pin piano switch),

baud rate, and communication mode of COAXIAL/COAXITRON/RS-485/RS-232.

1ON2

1ON2345678

TERMINATION

- Use pin 1,2,3 of the Protocol setting switch to select a protocol.

The protocol switch pin 4 sets the protocol to COAXIAL or COAXITRON.

- Use pin 5,6 of the Protocol setting switch to select a baud rate.

- The protocol switch pin 7 sets the protocol to COAXIAL (BNC communication)

or RS-485 output.

- Use pin 8 of the Protocol setting switch to select RS-232 input.

❻

Address Switch

For RS-232 / RS-485 communications, you can use this switch to set the address.

ADDRESS

(X)100 (X)10 (X)1

- Set the address by using three switches shown above.

- From the left, the number is hundreds, tens and ones place, respectively.

The effective range of valid address is between 0 and 255 (1~255 for multiprotocol).

PROTOCOL

Menu Navigation Key

❼

Use this to navigate through the menus.

For further details on ON/OFF setting of each switch for the applicable configuration,



NOTE

refer to SPC-300 Connection and Control section.

English 9

Introduction

❖

❶

❷

❸

❹

❺

PART NAMES AND FUNCTIONS

Rear Panel❖

- AA BATTERY

You can use 4 AA-sized batteries for the power.

- The average operation time is 20 hours based on the alkaline battery.

(If the battery is discharged, it can cause a distortion of the video signal, or electric interference.)

Remove the battery if you do not use the controller for a longer period. Otherwise, it



NOTE

may cause damage to the controller from a leak of the battery solution. Take caution not to change the specified polarity.



Do not use a new battery with an old one.



For storing used batteries, keep out of reach of children. Wasted batteries are to be



collected separately.

10 – COAXIAL REMOTE CONTROLLER

Introduction

RS-232C

VIDEO

DC 12VRS-485

Top❖

REMOTE CONTROLLER SCP-300

TX RX

n op

USB Port

❶

This terminal is used for updating the product’s ﬁ rmware.

❷

RS-232 Port (9-pin D SUB)

1ON23456781ON2

OUT IN

TERMINATION PROTOCOL

COMPENSATION

(X)100 (X)10 (X)1

CABLE

ADDRESS

OFF ON

POWER

POWER STATUS

- Used to control remotely using RS-232 communication.

❸

RS-485 Port (4-pin)

- Used to control remotely using RS-485 communication.

❹

VIDEO IN/OUT Connector (BNC)

- VIDEO IN receives coaxial communication from cameras, and VIDEO OUT

outputs the video signal.

❺

DC12V Power Connector (2-PIN)

- Used for connecting DC12V power source.

English 11

Installation

T K

❖

CHECKING INSTALLATION ENVIRONMENT

Please check the following instructions before installation for your safety.

•

The way of connecting the main product with external devices (COAXIAL BNC)

•

is very important to build up a proper system.

Do not disassemble the unit; doing so could expose you to dangerous high

•

voltage points.

INSTALLATION PRECAUTIONS

Make sure you turn off the product before installation.

•

Do not put a strong force on or shake the product; otherwise it may cause

•

malfunction.

Keep the product away from areas of strong magnetic ﬁ eld or electric

•

interference, or wireless devices such as radio or TV set.

Keep clean the installation place during and after the installation.

•

An abnormal smells from the product is a sign of abnormal condition, which

•

may cause ﬁ re or electric shock. In this case, disconnect the product from the main power immediately and contact the retailer for technical help from authorized servicing.

Keep the product away from a wet ﬂ oor, do not use an unearthed power

•

extension cable, worn-out power cord, neither forget earth-grounding.

Use a dry cloth only to dirt off the product. If the product is badly dirty, apply

•

neutral detergent on a cloth that is used to dirt off, and wipe it out with a dry cloth.

Do not use volatile substances such as alcohol, benzene or thinner as these

•

may damage the ﬁ nish.

12 – COAXIAL REMOTE CONTROLLER

Connection & Control

TO CONTROL THE CAMERA USING CONTROL MENU KEYS AND COAXIAL / COAXITRON OUTPUT

REMOTE CONTROLLER SCP-300

TERMINATION PROTOCOL

1ON23456781ON2

COMPENSATION CABLE

(X)100 (X)10 (X)1

OFF ON

ADDRESS

POWER

POWER STATUS

Connect the product to DC 12V power source or insert 4 AA-sized

batteries into the battery compartment.

(Power can be supplied via USB cable connection.)

Connect the VIDEO IN of the unit and VIDEO OUT of the AI Camera directly.

–

The A1 camera and SPC-300 should be directly connected to the VIDEO IN.

Connect VIDEO OUT of the main unit to a monitor’s video input terminal.

You can control camera menu after setting the switch as shown below:

PIN 4 Output Selection

1ON23456784

PROTOCOL

1ON23456787

PROTOCOL

–

Select the coaxial output by using the protocol switch pin 7. The pin 7 coaxial / RS-485 has the output priority.

–

To select from COAXIAL or COAXITRON, use the pin 4.

You can use the menu as following :

❖

Press and hold [ENTER]: Moves to the main menu screen.

–

Press [ENTER] brieﬂ y: Used to conﬁ rm the current settings.

–

Four Direction Keys: Used to move the cursor up/down or left/right.

–

No address setting is required for connecting COAXIAL / COAXITRON camera and SCP-300.



NOTE

If not in menu control, it operates ZOOM/FOCUS function for COAXIAL output. If not in



menu control, it operates PAN/TILT function for COAXITRON output. For COAXIAL control, the camera should be set to SAMSUNG-E protocol.



When controlling COAXITRON menu while the menu is turned on, press and hold



ENTER key to exit the menu screen.

ON COAXITRON

OFF

COAXIAL

PIN 7 Output Selection

ON COAXIAL OUT

OFF RS-485 OUT

English 13

SCX-RD100

Connection & Control

T V

TO CONTROL THE CAMERA USING RS-485 INPUT AND COAXIAL / COAXITRON OUTPUT

REMOTE CONTROLLER SCP-300

TERMINATION PROTOCOL

1ON23456781ON2

COMPENSATION CABLE

(X)100 (X)10 (X)1

OFF ON

ADDRESS

POWER

POWER STATUS

Connect the product to DC 12V power source or insert 4 AA-sized

batteries into the battery compartment.

(Power can be supplied via USB cable connection.)

Connect the VIDEO IN of the unit and VIDEO OUT of the AI Camera directly.

–

The A1 camera and SPC-300 should be directly connected to the VIDEO IN.

Connect VIDEO OUT of the main unit to a monitor’s video input terminal.

Connect TX(+/-) of RS-485 device to RX(+/-) of the main unit. (For a full duplex system, connect RX(+/-) of RS-485 device to TX (+/-) of main unit additionally.)

Use a combination of pin 1,2,3 of the Protocol setting switch to select a protocol.

Refer to the switch conﬁ guration table. (See page 18)

–

Using RS-485 device, you can control the camera menu.

Each mentioned protocol may require updating the firmware from the website.



NOTE

By factory default, protocols of SAMSUNG-E, SAMSUNG-T and PELCO-D/P are



supported.

To support additional protocol, access the website to update the program.



RS-232 and RS-485 communications cannot be used simultaneously.



COAXIAL and COAXITRON cannot be used simultaneously.



RS-485 input and COAXITRON control supports SAMSUNG-E and SAMSUNG-T



protocols only, while COAXIAL control supports all protocols.

For COAXIAL control, the camera should be set to SAMSUNG-E protocol.



14 – COAXIAL REMOTE CONTROLLER

Connection & Control

TO CONTROL THE CAMERA USING RS-232 DEVICE VIA COAXIAL COMMUNICATIONS

REMOTE CONTROLLER SCP-300

TERMINATION PROTOCOL

1ON23456781ON2

COMPENSATION CABLE

(X)100 (X)10 (X)1

OFF ON

ADDRESS

POWER

POWER STATUS

Connect the product to DC 12V power source or insert 4 AA-sized

batteries into the battery compartment.

(Power can be supplied via USB cable connection.)

Set the protocol switches 7 and 8 to ON.

Connect the VIDEO IN of the unit and VIDEO OUT of the AI Camera

directly.

For proper data communication, the unit and AI camera should be connected directly.

–

(If you connect a DVR or keyboard in the middle of the main unit and AI camera,

bidirectional communication will not be established.)

Connect VIDEO OUT of the main unit to a monitor’s video input terminal.

Connect the RS-232 device’s cable to the RS-232 port of the main unit.

Using RS-232 device, you can control the camera menu.

The RS-232 device is the same as RS-485 regarding the protocol setting, but

–

supports only the Samsung protocol.

For proper coaxial communication, AI camera should be set to Samsung protocol.

–

Refer to the switch settings. (See page 18)

RS-232 and RS-485 communications cannot be used for simultaneous input.



NOTE

RS-232 device control supports SAMSUNG-E protocol only.



English 15

Connection & Control

T O

TO CONTROL THE CAMERA USING RS-485 OUTPUT AND CONTROL MENU KEYS

REMOTE CONTROLLER SCP-300

TERMINATION PROTOCOL

1ON23456781ON2

COMPENSATION

CABLE

(X)100 (X)10 (X)1

OFF ON

ADDRESS

POWER

POWER STATUS

Connect the product to DC 12V power source or insert 4 AA-sized

batteries into the battery compartment.

(Power can be supplied via USB cable connection.)

Connect the RX(+/-) of the unit to the RS-485 (+/-) port of the camera.

Match the camera’s address, baud rate, and protocol to the same to

those of the unit.

For address switch, refer to the page 8.

Now you can control the camera by using the menus.

You can use the menu as following :

❖

Press and hold [ENTER]: Moves to the main menu screen.

–

Press [ENTER] brieﬂ y: Used to conﬁ rm the current settings.

–

Four Direction Keys: Used to move the cursor up/down or left/right.

Control of pan/tilt/zoom using the buttons is not supported.

–

To exit the menu screen, press and hold the key again.

RS-232 and RS-485 communications cannot be used simultaneously.



NOTE

5-direction key (control menu) only supports A1 camera’s menu control.



16 – COAXIAL REMOTE CONTROLLER

Connection & Control

TO CONTROL THE CAMERA USING RS-485 SIGNAL OUTPUT VIA RS-232 COMMUNICATIONS

REMOTE CONTROLLER SCP-300

TERMINATION PROTOCOL

1ON23456781ON2

COMPENSATION CABLE

(X)100 (X)10 (X)1

OFF ON

ADDRESS

POWER

POWER STATUS

Connect the product to DC 12V power source or insert 4 AA-sized

batteries into the battery compartment.

(Power can be supplied via USB cable connection.)

Set the protocol switch 8 to ON.

Connect the RX(+/-) of the unit to the RS-485(+/-) port of the camera.

Match the camera’s address, baud rate, and protocol to the same to those of the unit.

–

RS-232 device control supports SAMSUNG-E protocol only.

Connect the RS-232 device’s cable to the RS-232 port of the main unit.

Using RS-232 device, you can control the camera menu.

RS-232 and RS-485 communications cannot be used for simultaneous input.



NOTE

For the switch settings, see the switch setting table. (See page 18)



Input of video signal is required to control RS-485.



English 17

Connection & Control

SWITCH SETTING TABLE

Use a combination of pin 1,2,3 of the Protocol setting switch to select a protocol.

❖

1ON2

1ON23456781ON23

TERMINATION

Protocol Setting Switch

PIN 1 PIN 2 PIN 3

0 0 0 SAMSUNG-E HALF ALL

1 0 0 SAMSUNG-E FULL ALL

0 1 0 SAMSUNG-T SIMPLEX A

1 1 0 SAMSUNG-T FULL A

0 0 1 PELCO-D SIMPLEX A

1 0 1 PELCO-D FULL A

0 1 1 PELCO-P SIMPLEX A

0 0 1 PANASONIC HALF B

1 0 1 PANASONIC FULL B

0 0 1 HONEYWELL SIMPLEX C

1 0 1 HONEYWELL FULL C

0 0 1 VICON HALF D

1 0 1 VICON FULL D

0 1 1 AD SIMPLEX D

1 1 1 AD FULL D

Use pin 4, 7 and 8 of the Protocol setting switch to set the coaxial output.

❖

1ON23456784

PROTOCOL

1ON23456787

PROTOCOL

1ON23456788

PROTOCOL



Setting of the PIN 7 overrides that of PIN 4.

NOTE

18 – COAXIAL REMOTE CONTROLLER

(0 :r, 1 :q)

PROTOCOL

Protocol HALF/FULL

Software

(A, B, C, D)

PIN 4 Output Selection

ON COAXITRON

OFF

COAXIAL

PIN 7 Output Selection

ON COAXIAL OUT

OFF RS-485 OUT

PIN 8 RS-232 input

ON RS-232 input

OFF RS-232 No use

Type

Connection & Control

–

See the following table to set the baud rate.

1ON2

TERMINATION

1ON234567856

PROTOCOL

BAUD RATE PIN 5 PIN 6

38400 BPS OFF OFF

19200 BPS ON OFF

9600 BPS OFF ON

4800 BPS ON ON

English 19

Speciﬁ cations

SPECIFICATIONS

Item Description

COAXIAL

RS-232

RS-485

Multi-protocol (Supports 4 programs)

Environmental

Conditions

WEIGHT NET 200 g

Communication Method

Range Max. 500m (with 5C-2V cable)

Connector Type D-SUB 9P

Port 1 Port

BAUD RATE

Connector Type 4P Terminal Type

Port 1 Port

BAUD RATE 4800 / 9600 / 19200 / 38400 bps

USB PORT(USB2.0) S/W PROGRAM UPLOAD

VIDEO IN/OUT

A) SAMSUNG-E, SAMSUNG-T, PELCO-D/P

B) SAMSUNG-E, PANASONIC

C) SAMSUNG-E, HONEYWELL

D) SAMSUNG-E, VICON, AD

Operating Temp. -10˚C ~ +50˚C

Humidity Less than 90%

POWER DC12V ± 10%

DIMENSIONS (WxHxD) 150(W) X 36(H) X 102(D)

COAXIAL / COAXITRON INTERFACE

4800/9600/19200/38400bps

(Only Samsung protocol supported)

Composite Video

1.0Vp-p, 75ohm,

Cable Compensation out

(Select:S/L)

20 – COAXIAL REMOTE CONTROLLER

DIMENSIONS

Speciﬁ cations

Unit (mm)

English 21

SALES NETWORK

SAMSUNG TECHWIN CO., LTD.

Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400 TEL : +82-70-7147-8740~60, FAX : +82-31-8018-3745

SAMSUNG TECHWIN AMERICA Inc.

1480 Charles Willard St, Carson, CA 90746, UNITED STATES Tol Free : +1-877-213-1222, FAX : +1-310-632-2195 www.samsungcctvusa.com

www.samsungtechwin.com www.samsungsecurity.com

SAMSUNG TECHWIN EUROPE LTD.

Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS

TEL : +44-1932-45-5300, FAX : +44-1932-45-5325

AB68-00857A

P/NO. : Z680 6-1331-01A

Samsung SPC-300 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
