Page 1

3Megapixel Weatherproof Network IR Camera

312.6 (12.31")

333.2 (13.12")

200.0 (7.87")

90.0 (4.49")

SNO-7084R

VIDEO

Imaging Device Total Pixels Effective Pixels Scanning System

Min. Illumination

S / N Ratio

Video Output

LENS

Focal Length (Zoom Ratio) Max. Aperture Ratio Angular Field of View Min. Object Distance Focus Control Lens Type / Mount Type

OPERATIONAL

IR LED Viewable Length Camera Title

Key Features

• 30fps@2,048x1,536/60fps@1,920x1,080

• Simplefocus(MotorizedVF),P-Iris

• Day&Night(ICR),EnhancedDIS,Defog

• 3Mreal-timeWDR(Max.120dB)

• Color:0.1Lux(F1.2,50IRE)  B/W:0Lux(IRLEDon)

• Built-inSD/SDHC/SDXCmemoryslot

• Multi-cropstreaming

• IP66/IK10

Dimensions

90.4 (3.56")

200.0 (7.87")

312.6 (12.31")

333.2 (13.12")

96.8 (3.81")

96.0 (3.78")

Unit : mm (inch)

Day & Night Backlight Compensation Wide Dynamic Range Contrast Enhancement Digital Noise Reduction Digital Image Stabilization Defog Motion Detection Privacy Masking Gain Control White Balance Electronic Shutter Speed Flip / Mirror Intelligent Video Analytics Alarm I/O Alarm Triggers

Alarm Events

NETWORK

Ethernet Video Compression Format

Resolution

Max. Framerate

Smart Codec Video Quality Adjustment Bitrate Control Method Streaming Capability Audio In Audio Out

Audio Compression Format

Audio Communication IP

Protocol

Security

Streaming Method Max. User Access

Edge Storage

Application Programming Interfac

Webpage Language

90.0 (4.49")

Web Viewer

Central Management Software

ENVIRONMENTAL

Operating Temperature / Humidity

Storage Temperature / Humidity Ingress Protection Vandal Resistance

ELECTRICAL

Input Voltage / Current

Power Consumption

MECHANICAL

Color / Material Dimensions (WxHxD) Weight

SNO-7084RN/P

1/2.8" PS Exmor 3.2M CMOS 2,065(H) x 1,565(V) 2,065(H) x 1,553(V) Progressive Color : 0.1Lux (F1.2, 50IRE), 0.06Lux (F1.2, 30IRE) B/W : 0Lux (F1.2, 50IRE), 0Lux (F1.2, 30IRE) 50dB CVBS : 1.0 Vp-p / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation Connector type

3 ~ 8.5mm (2.8x) motorized varifocal F1.2 H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele)

0.5m (1.64ft) Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) DC auto iris, P-Iris / Board-in type

20ea 30m (98.43ft) Off / On (Displayed up to 45 characters) Auto (ICR) / Color / B/W / External / Schedule Off / BLC / WDR 120dB SSDR (Samsung Super Dynamic Range) (Off / On) SSNRIII (2D+3D noise filter) (Off / On) Off / On Off / Auto / Manual Off / On (4 zones with 4 points polygonal) Off / On (32zones with 4 points of polygonal) Off / Low / Middle / High ATW / AWC / Manual / Indoor / Outdoor Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec) Off / On Tampering, Virtual line, Enter / Exit, Appear / Disappear, Audio detection, Face detection with metadata Input 1ea / Output 1ea Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input File upload via FTP and E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at event,

RJ-45 (10/100BASE-T) H.264 (MPEG-4 part 10/AVC), MJPEG 2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180

H.264 : Max. 30fps@2048 x 1536, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536

Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768

Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 Manual mode (Area-based : 5ea), Face detection mode H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control H.264 : CBR or VBR, MJPEG : VBR Multiple streaming (Up to 10 profiles) Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm Line out (3.5mm mono jack), Max output level : 1 Vrms G.711 u-law /G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz

G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps Bi-directional audio IPv4, IPv6 TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication Unicast / Multicast 15 users at unicast mode micro SD/SDHC/SDXC 4GB SD memory built-in, Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded ONVIF profile S, SUNAPI (HTTP API) v2.0, SVNP 1.2 English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish

Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11, 10, 9, 8),

SmartViewer

24V AC : -50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH 12V DC, PoE : -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH IP66 IK10

24V AC, 12V DC, PoE (IEEE802.3af class3) Max. 11.5W (12V DC), Max. 12.5W (PoE), Max. 13.0W / 19.0W (24V AC, Heater off / on) * Heater works at AC power input only

Dark gray / Aluminium

90.4 x 96.0 x 333.2mm (3.56" x 3.78" x 13.12")

1.19Kg (2.62 lb)

Mozilla Firefox (Ver. 19, 18, 17, 16, 15, 14, 13, 12, 11, 10, 9), Google Chrome (Ver. 25, 24, 23, 22, 21, 20, 19, 18, 17,16, 15), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only

External output
