Samsung SMX-C20BP, SMX-C200RP, SMX-C200BP, SMX-C20RP, SMX-C19BP User Manual

...

SMX-C19BP/SMX-C19RP/SMX-C19LP/SMX-C19UP SMX- C20BP/SMX- C20RP/SMX- C20LP/SMX- C20UP SMX- C24BP/SMX- C24RP/SMX-C24LP/SMX-C24UP

SMX- C200BP/SMX- C200RP/SMX-C200LP/SMX-C200UP

Memory Camcorder

www.samsung.com/register

User Manual

key features of your memory camcorder

Samsung memory camcorder utilises a 2.7-inch 230k pixel Widescreen LCD which allows bright and clear monitoring. In addition, the LCD Enhancer adjusts colour and brightness to the screen lighting conditions for better monitoring under strong sunlight.

In Smart Auto mode, you can record more easily and conveniently in high quality, without having to set recording mode individually according to the recording situation.

Latest video compression technology, H.264, uses a high compression rate to sharply increase the recordable time with the same size storage.

The Samsung memory camcorder has 3DNR (3-dimensional noise reduction), high-sensitivity colour expression (intelligent colour expression), High performance Anti-Shake (Hyper DIS), and automatic face detection features.

This function captures 16 still images arbitrarily from the selected video and saves them into the storage media. It presents a quick overview of your video, helping you to understand the overall topic.

This function provides the preview of storyboard to be printed, which gives you digest of the recorded video without viewing the whole sequence of it.

High-resolution Colour Widescreen LCD (2.7” WIDE TFT LCD)

Shooting Custom Scenes

H.264/AVC (MPEG4 part 10/Advanced Video Coding) Encoding

High quality image through Mobile DNIe

Make a digest of your video with Storyboard printing!

Make all your recordings with a simple iVIEW button!

You can record a long scene in short intervals. Record artistic, documentary videos including the passage of clouds, blooming ﬂ owers etc. Use this function to make share videos, educational programmes or for other purposes.

The memory camcorder’s external memory slot accepts high capacity SDHC cards. In addition to this slot, the memory camcorder has a built-in high capacity ﬂ ash memory that allows you to record videos (or photos). Play and transfer videos quickly and easily using the memory type of your choice.

This camcorder is designed for comfort when making long recordings. With this ergonomic design, you can shoot subjects comfortably from any position.

The built-in editing software Intelli-studio installs directly from this camcorder to your PC, when you simply connect your camcorder to a PC via USB cable. Intelli-studio also allows direct uploading of your contents to YouTube or Flickr and Facebook. Sharing the contents with your friends is simpler than ever before.

This method uses the software built in your camcorder to upload your recordings to the website such as the YouTube with a simple operation.

SMART

AUTO

Time Lapse Recording Catches the Moment

Twice the memory options 16GB (SMX-C24 only)

Comfortable, Ergonomic Design

Direct upload of your videos to the Web!

Direct Uploading Your Recordings with easy Sharing button

iii

What the icons and signs in this user manual mean;

WARNING

Death or risk of serious personal injury.

CAUTION

Potential risk of personal injury or material damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or personal injury when using your camcorder, follow these basic safety precautions:

Hints or referential pages that may be helpful when operating the camcorder.

These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference.

Warning!

• This camcorder should always be connected to an AC outlet with a protective grounding connection.

•

Batteries should not be exposed to excessive heat such as sunshine, ﬁre or similar.

Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains

socket, therefore the mains plug shall be readily accessible.

SAFETY WARNINGS

before reading this user manual

PRECAUTIONS

This camcorder is designed exclusively for use with the high-capacity built-in ﬂash memory 16GB (SMX-C24 only) and an external memory card. This camcorder records video in H.264/ AVC (MPEG4 part 10/Advanced Video Coding) format compliant with the Standard resolution (SD-VIDEO) format. Please note that this camcorder is not compatible with other digital video formats. Before recording important video, make a trial recording.

- Play back your trial recording to make sure the video and audio have been recorded properly.

The recorded contents cannot be compensated for:

- Samsung cannot compensate for any

damages caused when recording is not made normally or recorded contents cannot be played back because of a defect in the camcorder or memory card. Also, Samsung cannot be held responsible for your recorded video and audio.

- Recorded contents may be lost due to an error when handling this camcorder or memory card, etc. Samsung shall not be held responsible for the loss of recorded contents, and cannot compensate for any damages.

Make a backup of important recorded data.

- Protect your important recorded data by copying the ﬁles to a PC. We recommend copying the data to your PC or other recording media for storage. Refer to the software installation and USB connection guide.

- Data recorded on a card in this camcorder from other digital/analogue media or devices is protected by the copyright act and cannot be used without permission of

•

the copyright owner except for personal enjoyment. Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand.

Handle the liquid crystal display (LCD) with care:

- The LCD is a very delicate display device: Do not press its surface with excessive force, hit it or prick it with a sharp object.

- If you push the LCD surface, display unevenness may occur. If unevenness does not disappear, turn the camcorder off, wait for a few moments, and then turn it on again.

- Do not place the camcorder with the open LCD screen down.

- Close the LCD monitor when not using the camcorder.

Liquid crystal display:

- The LCD screen is a product of high precision technology. Out of the total pixels (approx. 230,000 pixels of an LCD monitor ), 0.01% or less pixels may be out (black dots) or may remain lit as coloured dots (red, blue, and green). This shows the limitations of the current technology, and does not indicate a fault that will interfere with recording.

- The LCD screen will be slightly dimmer than usual when the camcorder is at low temperature, as in cold areas, or right after the power is turned on. Normal brightness will be restored when the temperature inside the camcorder rises. Note that this will have no effect on the image in a storage media, so there is no cause for concern.

Hold the camcorder correctly:

- Do not hold the camcorder by the LCD monitor when lifting it: the LCD monitor could detach and the camcorder may fall.

•

Before using this camcorder

Important notes

Important information on use

Do not subject the camcorder to impact:

- This camcorder is a precision machine. Take great care that you do not strike it against a hard object or let it fall.

- Do not use the camcorder on a tripod in a place where it is subject to severe vibrations or impact.

No sand or dust!

- Fine sand or dust entering the camcorder

or AC power adaptor could cause malfunctions or defects.

No water or oil!

- Water or oil entering the camcorder or AC

power adaptor could cause electric shock, malfunctions or defects.

Heat on surface of product:

- The surface of the camcorder will be

slightly warm when used, but this does not indicate a fault.

Be careful of unusual ambient temperature:

- Using the camcorder in a place where the

temperature is over 104°F (40°C) or lower than 32°F (0°C) may result in abnormal recording/playback.

- Do not leave the camcorder on a beach or

in a closed vehicle where the temperature is very high for a long time: This could cause a malfunction.

Do not point directly at the sun:

- If direct sunlight strikes the lens, the

camcorder could malfunction or a ﬁre could occur.

- Do not leave the camcorder with the LCD

screen exposed to direct sunlight: This could cause a malfunction.

Do not use the camcorder near TV or radio:

- This could cause noise to appear on the TV

screen or in radio broadcasts.

Do not use the camcorder near strong radio waves or magnetism:

- If the camcorder is used near strong radio

waves or magnetism, such as near a radio transmitter tower or electric appliances, noise could enter video and audio that

•

are being recorded. During playback of normally recorded video and audio, noise may also be present in picture and sound.

Do not expose the camcorder to soot or steam:

- Thick soot or steam could damage the camcorder case or cause a malfunction.

Do not use the camcorder near corrosive gas:

- If the camcorder is used in a place where there is dense exhaust gas generated by gasoline or diesel engines, or corrosive gas such as hydrogen sulphide, the external or internal terminals could corrode, disabling normal operation, or the battery connection terminals could corrode, so that power will not turn on.

Do not use the camcorder near an ultrasonic humidiﬁer:

- Calcium and other chemicals dissolved in water could scatter in the air, and white particles could adhere to the optical head of the camcorder, which could cause it to operate abnormally.

Do not clean the camcorder body with benzene or thinner:

- The coating of exterior could peel off or the case surface could deteriorate.

- When using a chemical cleaning cloth, follow the instructions.

Keep the memory card out of reach of children to prevent swallowing. To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily accessible.

•

Important information on use

About this user manual

Notes regarding trademarks

All the trade names and registered trademarks mentioned in this manual or other documentation provided with your Samsung product are trademarks or registered trademarks of their respective holders. Windows® is registered trademark or trademark of Microsoft Corporation, registered in the United States and other countries. Macintosh is trademark of Apple Inc. YouTube® is a trademark of Google Inc. Flickr® is a trademark of Yahoo.

Facebook® is a trademark of Facebook Inc.

All the other product names mentioned herein may be the trademark or registered trademarks of their respective companies. Furthermore, “TM” and “®” are not mentioned in each case in this manual.

•

Thank you for purchasing this Samsung Camcorder. Please read this user manual carefully before you use the camcorder and keep it handy for future reference. Should your camcorder fail to operate correctly, refer to Troubleshooting. The SMX-C24 has a 16GB built in ﬂash memory, but can also be used with memory cards. The SMX-C19, SMX-C20, SMX-C200 does not have built-in ﬂash memory and uses memory cards exclusively. Although some features of SMX-C19, SMX-C20, SMX-C24 and SMX-C200 are different, they operate in the same way. Illustrations of model SMX-C20 are used in this user manual. The displays in this user manual may not be exactly the same as those you see on the LCD screen. Designs and speciﬁcations of storage media and other accessories are subject to change without any notice. Descriptions of the “built-in memory” in this user manual apply only to the following model: SMX-C24

•

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government ofﬁce, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

For Open Source Licence information, refer to the “OpenSourceInfo.pdf” in the provided CDROM.

•

vii

The safety precautions illustrated below are to prevent personal injury or material damage. Heed all instructions carefully.

WARNING

Do not touch product.Prohibited action.WARNING Death or risk of serious personal injury.

This precaution must be kept.Do not disassemble

product.

CAUTION

Means that there is a potential risk of personal injury or material damage.

Unplug from power supply.

safety information

Do not bend the power-cord or damage the AC power adaptor by pressing on it with a heavy object. There may be a risk of ﬁre or electric shock.

Do not allow water or metal and inﬂammable matter to enter the camcorder or AC power adaptor. Doing so may pose a ﬁre hazard.

Do not aim the LCD screen directly into the sun. Doing so could cause eye injuries, as well as lead to malfunctioning of internal parts of the product.

Using the camcorder at temperatures over 140°F (60°C) may result in ﬁre. Keeping the battery at a high temperature may cause an explosion.

Do not disconnect the AC adaptor by pulling on its power-cord, as this could damage the power-cord.

No oil! Oil entering the camcorder or AC power adaptor could cause electric shock, malfunctions or defects.

LIO

Do not use the AC adaptor if it has damaged, split or broken cords or wires. Doing so may cause ﬁre or electric shock.

Do not overload outlets or extension cords as this may result in abnormal heat or ﬁre.

No sand or dust! Fine sand or dust entering the camcorder or AC power adaptor could cause malfunctions or defects.

SAND

viii

Keep the camcorder away from water when used near the beach or pool or when it rains. There is a risk of malfunction or electric shock.

Keep the used lithium battery or memory card out of the reach of children. If the lithium battery or memory card is swallowed by children, consult a physician immediately.

If the camcorder malfunctions, immediately detach the AC adaptor or battery from the camcorder immediately to avoid ﬁre or injury.

If the camcorder makes an abnormal sound, or smells or smokes, unplug the power-cord immediately and request service from a Samsung service centre. There is a risk of ﬁre or personal injury.

Do not attempt to disassemble, repair, or reform the camcorder or the AC adaptor to avoid a risk of ﬁre or electric shock.

Keep the power-cord unplugged when not in use or during lightning storms to prevent ﬁre hazard.

When cleaning the AC adaptor, unplug the power-cord to avoid a risk of a malfunction or electric shock.

Do not plug or unplug the power cord with wet hands. There is a risk of electric shock.

Do not connect the AC adaptor unless the plug can be fully inserted with no part of the blades exposed.

Do not dispose of battery pack in a ﬁre as it may explode.

Never use cleaning ﬂuid or similar chemicals. Do not spray cleaners directly on the camcorder.

diulfgninaelc

CAUTION

safety information

Do not use the camcorder near direct sunlight or heating equipment. This may cause a malfunction or injury.

Do not expose the camcorder to sudden changes in temperature or a humid places. There is also a risk of defect or electric shock when using outdoors during lightning storms.

Do not expose the camcorder to insecticide. Insecticide entering the camcorder could cause the product to operate abnormally. Turn the camcorder off and cover it with vinyl sheet, etc. before using insecticide.

Do not use the camcorder near dense exhaust gas generated by gasoline or diesel engines, or corrosive gas such as hydrogen sulphide. Doing so may corrode the external or internal terminals, disabling normal operation.

Do not expose the camcorder to soot or steam. Thick soot or steam could damage the camcorder case or cause a malfunction.

Do not leave the camcorder in a closed vehicle where the temperature is very high for a long time.

Do not use the camcorder on a tripod (not supplied) in a place where it is subject to severe vibrations or impact.

Do not drop or expose the camcorder, battery pack, AC adaptor or other accessories to severe vibrations or impact. This may cause a malfunction or injury.

Do not press the surface of the LCD with force, or hit it with a sharp object. If you push the LCD surface, display unevenness may occur.

Do not place the camcorder with the open LCD screen down.

Do not leave the LCD monitor open when not using the camcorder.

Do not hold the camcorder by the LCD monitor when lifting it. The LCD monitor could detach and the camcorder may fall.

Do not wipe the camcorder body with benzene or thinner. The exterior coating could peel off or the case surface could deteriorate.

Do not use the camcorder near TV or radio. This could cause noise on the TV screen or to radio broadcasts.

Do not use the camcorder near strong radio waves or magnetism such as speakers or large motors. Noise could enter video or audio that are being recorded.

Keep important data separately. Samsung is not responsible for data loss.

Use Samsung-approved accessories only. Using products from other manufacturers may cause overheating, ﬁre, explosion, electric shock or personal injuries due to abnormal operation.

Place the camcorder on a stable surface and a place with ventilation openings.

Use the mains plug where it can be readily operable. If any problem occurs with the product, the mains plug must be removed to disconnect power completely. Turning off the power button on the product does not completely disconnect the power.

contents

QUICK START GUIDE

GETTING TO KNOW YOUR

CAMCORDER

PREPARATION

ABOUT THE STORAGE

MEDIA

RECORDING

PLAYBACK

09 What's included with your camcorder

10 Front & left view 11 Rear & bottom view

12 Using the hand strap 12 Adjusting the LCD screen 13 Basic camcorder positioning 14 Connecting a power source 16 Checking the battery state 19 Basic operation of your camcorder 20 Switching to the power saving mode 21 LCD screen indicators 25

Turning the screen indicators on/off 26 Shortcut menu (OK guide) 28 Initial setting : Time Zone, Date and Time

& OSD Language

30 Selecting the storage media

(SMX-C24 only) 31 Inserting / ejecting the memory card 32 Selecting a suitable memory card 34 Recordable time and capacity

35 Recording videos 36 Quick view function in the record mode 37 Recording with ease for beginners :

Smart Auto Mode 38 Taking photos 39 Zooming in and out

40 Changing the playback mode 41 Playing videos 43 Viewing photos

44 Changing the menu settings 44 Recording menu items 45 iSCENE 46 Video

Resolution 47 Photo Resolution 47 16:9 Wide 48 EV (Exposure Value) 49 Back

Light 50 Focus 52 Anti-Shake (HDIS) 53 Digital

Effect 54 Fader 55 Wind cut 55 Digital

Zoom 56 Time Lapse REC 58 Guideline

59 Playback menu items 59 Play option 60 Delete 61 Protect 62 Story-Board Print 63 Using the

VIEW 64 Copy (SMX-C24 only) 65 Divide 66 Combine 67

Share Mark 68 Slide Show 69 Slide Show Option 69 File Info

70 Changing the menu settings in "settings" 71 Settings menu items ( ) 72 Storage Info 73 Format 73 File No. 74 Time Zone 75 Date Type 76 Time Type 76 Date/Time Display

RECORDING OPTIONS

PLAYBACK OPTIONS

SETTINGS OPTIONS

USING WITH A WINDOWS

COMPUTER

CONNECTING TO OTHER

DEVICES

MAINTENANCE & ADDITIONAL

INFORMATION

TROUBLESHOOTING

SPECIFICATIONS

77 LCD Brightness 77 LCD Colour 78 LCD Enhancer 78 Auto LCD Off 79 Menu Design 79 Transparency 80 Beep Sound 80 Shutter Sound 81 Auto Power Off 81 PC Software 82 TV Display 82 Default Set 83 Version 83 Demo

84 Checking your computer type 85 What you can do with a Windows

computer 86 Using the Intelli-studio programme 92

Transferring videos/photos from the camcorder to your computer

94 Connecting to a TV 95 Viewing on a TV screen 96

Recording (dubbing) images on a VCR or DVD/HDD recorder

97 Maintenance 98 Additional information 99 Using your camcorder abroad

100 Troubleshooting

109 Specifications

contents

1. Insert a memory card. ²page 31

• You can use commercially available SDHC (SD High Capacity) or SD memory cards with this camcorder.

• Set the appropriate storage media. (

SMX-C24

only)

2. Insert the battery into the battery slot.

page 14

• Gently slide the Battery pack release switch in the direction as shown in the diagram.

3. Charge the battery fully.

page 15

• The battery is fully charged when the CHG (charging) indicator light turns green.

quick start guide

You can record videos in H.264 format!

You can record videos in H.264 format, which enables you to conveniently email and share videos with your friends and family. You can also take photos with your camcorder.

+

This quick start guide introduces the basic operation and features of your camcorder. See the reference pages for more information.

STEP2: Record with your camcorder

STEP1: Get ready

Recording start/stop button

Zoom lever

CHG indicator

LCD screen

Photo button

Recording start/stop button

[Battery pack release] Switch

Your camcorder is compatible with H.264 recording format, which achieves efﬁ cient coding of high quality video with less capacity. You can record videos in SD (standard deﬁ nition). The default setting is "TV Fine (720x576/50i)".

page 46

You can not take photos while you are recording videos.

•

quick start guide

Recording videos with H.264 format

Recording photos

Your camcorder uses advanced H.264 compression technology to realise the clearest video quality. ²page 46

1. Open the LCD screen.

2. Press the Power

button.

3. Press the Recording start/stop

button.

•

To stop recording, press the Recording start/stop button.

Captures a moving subject instantly and saves the scene as a photo image.

1. Open the LCD screen.

2. Press the Power

button.

3. Press the Photo

button fully when

you are ready.

0:00:00 [475Min]

STEP3: Play back videos or photos

You can ﬁ nd your desired recordings quickly by using the thumbnail index view.

1. Press the Mode

button to select the Play mode.

• The thumbnail index view appears. The thumbnail of the latest created or played ﬁ le is highlighted.

2. Select the Video or Photo thumbnail index view screen.

• You can simply switch between video and photo thumbnail view using the zoom lever.

3. Use the Control button (// / ) to select a desired video or photo, and then press the Control button (OK).

Viewing the LCD screen of your camcorder

Viewing on a TV

You can enjoy detailed, brilliant quality videos on a connected TV. ²page 95

STEP4: Save recorded videos or photos

Simple and fun! Enjoy the various features of Intelli-studio on your Windows computer.

Using the Intelli-studio programme built in your camcorder, you can import videos/photos into your computer, edit or share the videos/photos with your friends. For details, see page 84.

0:00:00 [475Min]

STBY

9999

Video

Move Full View


1/10

Move Play

Video

1/100:00:55


quick start guide

STEP5: Delete videos or photos

If the storage media is full, you cannot record new videos or photos. Delete videos or photos data that have been saved on a computer from the storage media. Then you can record new videos or photos on newly freed-up space.

Press the Mode button to select the Play mode  Press the MENU button  Control button ( / /  / /OK) to select "Delete."

page 60

The Intelli-studio runs automatically once the camcorder is connected to a Windows computer (when you specify "PC Software: On").

page 81

Viewing the videos/photos from your PC

1. Launch the Intelli-studio program by connecting the camcorder to your PC via the USB cable.

• A new ﬁle saving screen appears with the Intelli-studio main window. Click "Yes", the uploading procedure will start.

2. The new ﬁles are saved to your PC and registered to "

Contents Manager

" on the Intelli-

studio programme.

• You can arrange the ﬁles by different options such as Face, Date, Location, etc.

3. You can double-click on the ﬁle you would like to start playing.

Sharing videos/photos on YouTube/Flickr/Facebook

Share your contents with the world, by uploading photos and videos directly to a web site with a single click. Click on the "Share

"  "Upload" tab on the browser.

page 89

"Contents Manager"

Saved ﬁles

WHAT'S INCLUDED WITH YOUR CAMCORDER

Your new camcorder comes with the following accessories. If any of these items are missing from your box, call Samsung’s Customer Care Centre.

getting to know the camcorder

Checking your accessories

Model name Colour

Built-in

memory

Memory

card slot

LCD

screen

Lens

SMX-C19BP Black -

1 slot

colour

10x

(Optical),

1200x

(Digital)

SMX-C19RP Red SMX-C19LP Blue -

SMX-C19UP Purple SMX-C20BP/C200BP Black SMX-C20RP/C200RP Red -

SMX-C20LP/C200LP Blue -

SMX-C20UP/C200UP Purple -

SMX-C24BP Black 16GB

SMX-C24RP Red 16GB

SMX-C24LP Blue 16GB

SMX-C24UP Purple 16GB

- Although some features of the models are different, they operate in the same way.

The contents may vary depending on the sales region. Parts and accessories are available for purchase at your local Samsung dealer. SAMSUNG is not responsible for reduced battery life time or malfunctions caused by any unauthorised use of accessories. A memory card is not included. See page 32 for memory cards compatible with your camcorder. Your camcorder includes a user manual CD and a quick start guide (printed). (Optional accessories) : This is an optional accessory. To buy one, contact your nearest Samsung dealer.

•

Optional accessories

Battery pack

(IA-BH130LB)

AC power

adaptor

(AA-MA9 type)

Audio/Video

cable

USB cable Hand strap

User manual CD Quick start guide

Optional accessories

Carrying case

Memory card

getting to know the camcorder

FRONT & LEFT VIEW

Lens

Recording start/stop button

Control button (S/T/W/X/OK),

Zoom (W/T) button

MENU button

LCD screen

Power

button

Built-in speaker

Share button

Display

button

Mode

button

SMART AUTO /

VIEW button

Charging indicator (CHG)

Hand strap hook


button

Zoom lever (W/T)

󱯎 󱯐

󱯒

󱯔 󱯖 󱯘 󱯚

󱯜 󱯞 󱯠 󱯡

󱯢 󱯣 󱯤 󱯥

Be careful not to cover the internal microphone and lens during recording.

REAR & BOTTOM VIEW

Jack/ Battery pack/ Memory card cover Memory card slot

USB jack (

) Battery pack slot

AV jack (AV) Internal microphone

DC IN jack (DC IN) Tripod receptacle

Battery pack release switch

󱯎 󱯐 󱯒 󱯔 󱯖

󱯘 󱯚 󱯜 󱯞

SD/SDHC

Usable Memory Cards

(512MB~32GB)

USING THE HAND STRAP

Attach the strap and place your hand through the loop to prevent the camcorder from damage by being dropped.

preparation

This section provides information that you should know before using this camcorder; such as how to use the provided accessories, how to charge the battery, and how to setup the operation mode and initialise setup.

ADJUSTING THE LCD SCREEN

The wide LCD screen on your camcorder offers high quality image viewing.

1. Open the LCD screen with your ﬁ nger.

•

The screen opens up to 90°.

2. Rotate the LCD screen towards the lens.

•

When you open the LCD, it can be folded up to 25° to make parallel with the lens.

• You can rotate it up to 180° towards the lens and up to 90° backward. To view recordings more conveniently, rotate the screen by 180° towards the lens, then fold it back to the body.

• Remove ﬁ ngerprints or dust on the screen with a soft cloth.

• When the LCD screen is rotated by 180° toward the lens, the left and the right sides of the subject

are shown in reverse as if you were looking at a mirror. This is not a problem and does not affect the image being recorded.

Excessive rotation may damage the connective hinge between the screen and the camcorder.

BASIC CAMCORDER POSITIONING

Use both hands while taking a video or picture to prevent the camcorder from shaking. Try to avoid any slight movement while shooting.

Aim the camcorder as shown in the illustration.

1. Hold the camcorder with your both hands.

2. Hook up the hand strap to ﬁ t to hand.

3. Make sure your footing is stable and there is no

danger of colliding with another person or object.

4. Aim and focus as shown in the illustration.

• This camcorder lens shooting angle is approx. 25˚ higher than the rest of the camcorder body. Make sure the camcorder lens is angled for proper shooting.

• It is recommended to keep the sun behind you while shooting.

Adjusting the shooting angle

25˚

CONNECTING A POWER SOURCE

Be sure to charge the battery pack before you start using your camcorder. Use the IA-BH130LB battery pack only. The battery pack may be charged a little at the time of purchase.

It is recommended you purchase one or more additional battery packs to allow continuous use of your camcorder.

•

preparation

Remove the battery pack separately from the camcorder while not in use. It is recommended to prepare an additional battery pack for prolonged outdoor use. Contact your nearest Samsung Electronics Service Centre for purchasing additional battery packs.

•

Battery pack insertion/ejection

Inserting the battery pack Ejecting the battery pack

1. Slide and open the battery slot cover as

shown in the diagram.

2. Insert the battery pack into the battery slot

until it locks.

Make sure that the SAMSUNG logo

is facing left while the battery pack is placed as shown in the diagram.

3. Push the battery cover down until it meets

the camcorder body, then slide it up to close.

•

1. Slide and open the battery slot cover and

push the Battery pack release switch.

Gently push the battery pack release

switch in the direction as shown in the diagram to eject the battery.

2. Pull the ejected battery out in the direction

as shown in the diagram.

3. Push the battery cover down until it meets

the camcorder body, then slide it up to close.

•

[Battery pack release] switch

1. Insert the battery in the camcorder.

page 14

2. Press the Power

button to turn off

the camcorder.

3. Open the connector cover of the unit.

4. Charge the battery using the

AC power adaptor or USB cable.

The CHG (charge) lamp lights up and charging starts. When the battery is fully charged, the charging (CHG) lamp turns green. ²page 16 Make sure you plug the adaptor cable or USB cable into the camcorder in the proper direction. See the

diagram

to the right.

Using the AC power adaptor

Connect the AC power adaptor to the camcorder properly and plug the AC power adaptor in the wall outlet.

Using the USB cable

Connect the USB cable to the camcorder properly and connect the other end to a USB port of a PC.

•

When recording indoors with an available wall outlet, it is convenient to use the AC power supply instead of the battery pack. When charging, if both the USB cable and AC power adaptor are connected, the AC power adaptor will override the USB. If the camcorder is turned on, the battery will still charge, but more charging time will be needed. It is recommended you to keep the camcorder turned off while charging.

•

Charging the battery pack at low temperature may take longer or fail to fully charge (green indicator will not turn on). Please make sure that there are no foreign substances in the plug and socket when you connect the AC power supply to the camcorder. Fully charge the battery pack before use. When using the AC power supply, place it close to the wall outlet. If you experience a malfunction while using the camcorder, separate the AC power supply immediately from the wall outlet. Do not use the AC power supply in a tight space, such as between furnishings.

•

Connecting the AC power adaptor

Connecting the USB cable

Wall Outlet

PRECHECK!

Be sure to charge the battery before you start using your camcorder. Use the battery pack and the AC power adapter provided with the camcorder.

•

Charging the battery

You can charge the battery using the AC power adaptor or USB cable.

Charging state

Charge

Charging Fully Charged Error

LED Colour

(Orange) (Green) (Orange Blink)

The colour of the charging indicator shows the charging state.

preparation

Charging (CHG) lamp

The Battery Level Display shows the amount of battery power remaining in the battery pack.

Battery Level Display

CHECKING THE BATTERY STATE

You can check the charging state and remaining battery capacity.

If error persists with charging the battery, contact your nearest SAMSUNG authorized service center. Before using the camcorder, charge the battery. Above ﬁ gures are based on a fully charged battery pack at normal temperature. Low ambient temperature may affect the use time.

•

0:00:00 [475Min]

STBY

9999

Battery level

indicator

State Message

Fully charged

25%~50% used

50%~75% used

75%~95% used

95%~99% used

Exhausted (ﬂ ickers):

The device will be forced to

turn off after 3 minutes.

Change the battery pack as soon as possible.

(ﬂ ickers): The device will be forced to turn off

after 3 seconds.

"Low battery"

For your reference, the approximate time with fully charged battery pack:

Battery type IA-BH130LB

Charging time

Using an AC power adaptor

approx.

2 hr.

Using a USB cable

approx.

4 hr

Video resolution

720 x 576 (50i) 640 x 480 (25p)

TV Super

Fine ( )

TV Fine

( )

TV Normal

( )

Web Fine

( )

Web Normal

( )

Mode

Continuous

recording time

approx. 160min.

Playback time

approx. 180min.

Continuous Recording (without zoom)

Charging, recording and playback times with fully charged battery pack (with no zoom operation, etc.)

- The time is only for reference. Figures shown above are measured under Samsung's test

environment, and may differ according to user and condition.

- We recommend using the AC power adaptor when using the Time Lapse REC Function.

The continuous recording time of the camcorder in the table shows the available recording time when the camcorder is in the recording mode without using any other function after recording starts. When actually recording, the battery pack may discharge 2-3 times faster than this reference, since the record start/stop and zoom functions are being operated, and playback is performed. Prepare additional charged battery pack(s) to allow for the time you are planning to record on the camcorder. Note that the battery pack discharges faster in a cold environment.

The beneﬁts of the battery pack: the Battery pack is small but has a large power capacity. It should be recharged at temperatures between 50°F ~ 86°F (10°C ~ 30°C). However, when it is exposed to cold temperatures (below 32°F (0°C)), its usage time is reduced and it may cease to function. If this happens, place the battery pack in your pocket or any other warm, protected place for a short time, then reattach it to the camcorder. Do not put the battery pack near any heat source (i.e. ﬁre or a heater). Do not disassemble, apply pressure to, or heat the battery pack. Do not allow battery pack terminals to be short-circuited. It may cause leakage, generate heat, or cause ﬁre.

•

About the battery pack

The charging time will vary depending on the remaining battery level.

The recording time is affected by temperature and environmental conditions. We recommend only using the original battery pack that is available from your Samsung retailer. When the battery reaches the end of its life, please contact your local dealer. The batteries have to be dealt with as chemical waste. Make sure that the battery pack is fully charged before starting to record. To preserve battery power, keep your camcorder turned off when you are not operating it. Even when the power is switched off, the battery pack will still discharge if it is left inserted on the camcorder. If you do not use the camcorder for an extended time period, keep it with the battery completely depleted. To save battery power, you can set the "Auto Power Off" function, which turns off the camcorder if there is no operation for 5 minutes. To disable this option, change the setting of "Auto Power Off" to "Off". ²page 81 When not using the camcorder for an extended period: It is recommended that you fully charge the battery pack once every 6 months, attach it to the camcorder and use it up: then remove the battery pack and store it in a cool place.

•

Maintaining the battery pack

Use only Samsung-approved battery packs. Do not use batteries from other manufacturers because there is a danger of overheating, ﬁre or explosion. Samsung is not responsible for problems occurring due to using unapproved batteries.

Before detaching the power source, make sure that the camcorder’s power is turned off. Failure to do so can result in camcorder malfunction. Use a nearby wall outlet when using the AC power adaptor. Disconnect the AC power adaptor from the wall outlet immediately if any malfunction occurs while using your camcorder. Do not use the AC power adaptor in a narrow space, such as between a wall and furniture.

•

Battery capacity decreases over time and through repeated use. If decreased usage time between charges becomes signiﬁcant, it is probably time to replace it with a new one. Each battery's life is governed by storage, operating and environmental conditions.

It is recommended that you use the AC power adaptor to power the camcorder from a household AC outlet when you perform settings on it, play back, or use it indoors. Make the same connections as you do when charging the battery pack.

page 15

•

About the battery life

Using an AC power source

preparation

Be sure to use the speciﬁed AC power adaptor to power the camcorder. Using other AC power adaptors could cause electric shock or result in ﬁre. The AC power adaptor can be used around the world. An AC plug adaptor is required in some foreign countries. If you need one, purchase it from your distributor.

•

BASIC OPERATION OF YOUR CAMCORDER

This section explains the basic techniques of recording videos or photos and also basic settings on your camcorder. Set the appropriate operation mode according to your preference using Power

and Mode

buttons.

This camcorder provides one record mode for both video and photo recordings. You can easily record videos or photos in the same mode without having to switch modes. One play mode is also provided for video and photo recordings. When the camcorder is turned on, the self-diagnosis function operates and a message may appear. In this case, refer to "Warning indicators and messages" (on pages 100-102) and take corrective action.

•

Turning the camcorder on or off

You can turn the power on or off by pressing the Power

button.

1. Open the LCD screen and press the Power

button to turn on the camcorder.

2. To turn off the camcorder, press the Power

button.

Setting the operating modes

You can switch the operating mode in the following order each time you press the Mode button: Record mode

Play mode

Mode Functions

Record mode To record videos or photos.

Play mode To play videos or photos, or edit them.

When using this camcorder for the ﬁ rst time

When you use your camcorder for the ﬁ rst time or reset it, the time zone screen appears for the start-up display. Select your geographical location and set the date and time.

page 28

If you do not set the date and time, the time zone screen appears every time you turn on the camcorder.

Mode button

Power button

preparation

SWITCHING TO THE POWER SAVING MODE

If you need to use camcorder for the extended time, the following functions enable you to prevent unnecessary energy consumption.

In STBY mode:

• The camcorder switches to sleep mode when the LCD screen is closed.

In Playback mode (Includes the thumbnail view mode):

• The camcorder switches to the sleep mode when the LCD screen is closed, and then if idle for more than 5 minutes the camcorder turns off. However, if "Auto Power Off: 5 Min" is set, the camcorder turns off after 5 minutes. ²page 81

• If you open the LCD screen or connect a cable to the camcorder during sleep mode, the sleep mode ends and returns back to the last used operation mode.

• The power saving mode does not work in the following situations:

- When the camcorder has a DC power cable connection. (AC power adaptor, USB cable)

- While recording, playback, or the slideshow is being operated.

- When the LCD screen is opened.

• The camcorder consumes the less battery power in the power saving mode (about 50% of the power consumption in the standby mode) However, if you plan to use the camcorder for the maximum length of time period, it is recommended to turn off the camcorder by pressing the Power

button when not using it.

LCD screen is open

LCD screen is closed

After 5 minutes

After 2 minutes

After 3 minutes

After 5 minutes

< In the STBY mode>

Sleep mode

Move Play

Video

1/10

0:00:00 [475Min]0:00:00 [475Min]

0:00:00 [475Min]

STBY

9999

0:00:55


Auto LCD Off / Auto Power Off

CHG

Green Blink

 The LCD brightness is controlled after regular period to prevent unnecessary power

consumption by following settings: "Auto LCD Off: On", "Auto Power Off: 5 Min"

0:00:00 [475Min]

STBY

9999

+ 91 hidden pages

Samsung SMX-C20BP, SMX-C200RP, SMX-C200BP, SMX-C20RP, SMX-C19BP User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
