Samsung SM-W750V User Guide
User Guide
MOBILE PHONE
User Manual
Please read this manual before operating your
phone and keep it for future reference.
Warning!
This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to
the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to
Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited
to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation
and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or
otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All
applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product, including but not limited to 'PowerTOP' and 'e2fsprogs', incorporate source code covered
under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open
source licenses. To obtain the source code covered under the open source licenses, please visit:
http://opensource.samsung.com
.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE
WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
VZN-W750V_UM_English_NB3_TN_033114_F3
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR
YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER
MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.
IF YOUR CARRIER PROHIBITS THIS, IF YOU ATTEMPT TO DOWNLOAD SOFTWARE ONTO THE DEVICE WITHOUT AUTHORIZATION, YOU WILL
BE NOTIFIED ON THE SCREEN THAT THE PHONE WILL NO LONGER OPERATE AND BE INSTRUCTED TO POWER DOWN THE DEVICE. YOU
MUST THEN CONTACT YOUR CARRIER TO RESTORE THE DEVICE TO THE CARRIER AUTHORIZED SETTINGS.
Samsung Telecommunications America (STA), LLC
Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082
Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Internet Address:
http://www.samsung.com
©
2014 Samsung Telecommunications America, LLC. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
The actual available capacity of the internal memory is less than the specified capacity because the operating system and default
applications occupy part of the memory. The available capacity may change when you upgrade the device.
ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.
Openwave® is a registered Trademark of Openwave, Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
©Samsung Telecommunications America, LLC (“Samsung”). Samsung, Super AMOLED, and Samsung Link are all trademarks of
Samsung Electronics Co., Ltd. and/or its related entities. Other company names, product names and marks mentioned herein are
the property of their respective owners and may be trademarks or registered trademarks. Appearance of device may vary.
©Verizon Wireless. Verizon Wireless and the Verizon Wireless logos are trademarks of Verizon Trademark Services LLC. All
company names, trademarks, logos and copyrights not property of Verizon Wireless are the property of their respective owners.
Your phone features earSmart™, an intelligent voice processor that delivers a clear voice experience, allowing you to
in nearly any environment. earSmart technology uses the science of human hearing to distinguish sounds, identify your voice, and
suppress surrounding noise for clear conversations just about anywhere.
How Does It Work?
•
The earSmart voice processor in your phone captures your voice and all the sounds around you.
•
Working like the human ear, it processes and distinguishes these sounds, isolates your voice conversation, and removes background noise – from both
ends of a call.
•
It also automatically equalizes and adjusts voice volume so you can hear and talk naturally, even in the noisiest places.
•
With earSmart technology, you can talk where you want, and have clear conversations for mobile calls, video chats, even speakerphone calls, without
worrying about surrounding noise.
hear and be heard
™
Table of Contents
Section 1: Getting Started ...........................5
Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . 5
Memory Card . . . . . . . . . . . . . . . . . . . . . . . . .10
Turning your Phone On or Off . . . . . . . . . . . . . 11
Locking and Unlocking your Phone . . . . . . . . . 11
Using the Start-Up Wizard . . . . . . . . . . . . . . . .11
Setting Up Your Voice Mail . . . . . . . . . . . . . . . .12
Phone Updates . . . . . . . . . . . . . . . . . . . . . . . . 12
Section 2: Understanding Your Phone .....13
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Back, Top, and Bottom View . . . . . . . . . . . . . . 15
Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . 16
Speech Engine . . . . . . . . . . . . . . . . . . . . . . . .19
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . .20
Customizing Your Home Screen . . . . . . . . . . . . 21
Section 3: Entering Text ............................24
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Using the QWERTY Keyboard . . . . . . . . . . . . . . 26
Changing the Text Input Mode . . . . . . . . . . . . . 26
1
Using Alphabetic Mode . . . . . . . . . . . . . . . . . .26
Using Symbol and Numeric Mode . . . . . . . . . .27
Using Emoticon Mode . . . . . . . . . . . . . . . . . . .27
Using Text Suggestions . . . . . . . . . . . . . . . . . .28
Keyboard Settings . . . . . . . . . . . . . . . . . . . . . .28
Copy and Paste . . . . . . . . . . . . . . . . . . . . . . . .28
Section 4: Call Functions ..........................30
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . .30
Making a Call from People . . . . . . . . . . . . . . . .31
Answering a Call . . . . . . . . . . . . . . . . . . . . . . .31
History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Options During a Call . . . . . . . . . . . . . . . . . . . .33
Section 5: Your People Hub ......................36
Importing SIM Contacts to Your Phone . . . . . . .36
Adding a New Contact . . . . . . . . . . . . . . . . . . .36
Editing an Existing Contact . . . . . . . . . . . . . . .37
Deleting Contacts . . . . . . . . . . . . . . . . . . . . . .38
Creating a New Group . . . . . . . . . . . . . . . . . . .38
Group Options . . . . . . . . . . . . . . . . . . . . . . . . .39
Using Your People List . . . . . . . . . . . . . . . . . . 39
Linking People . . . . . . . . . . . . . . . . . . . . . . . . 41
Synchronizing Accounts . . . . . . . . . . . . . . . . . 42
What’s New . . . . . . . . . . . . . . . . . . . . . . . . . . 43
People Options . . . . . . . . . . . . . . . . . . . . . . . . 43
Additional People Options . . . . . . . . . . . . . . . . 44
Recent Activities . . . . . . . . . . . . . . . . . . . . . . 44
Section 6: Messaging ............................... 45
Types of Messages . . . . . . . . . . . . . . . . . . . . 45
Creating and Sending Text Messages . . . . . . . 46
Voice to Text Messages . . . . . . . . . . . . . . . . . 47
Creating and Sending Multimedia Messages . 47
Messaging Conversations . . . . . . . . . . . . . . . 48
Online Messaging . . . . . . . . . . . . . . . . . . . . . 51
Using Email . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Section 7: Multimedia .............................. 56
Xbox Music Pass . . . . . . . . . . . . . . . . . . . . . . 56
Music+Videos . . . . . . . . . . . . . . . . . . . . . . . . 56
Playing Music . . . . . . . . . . . . . . . . . . . . . . . . 57
Playing Videos . . . . . . . . . . . . . . . . . . . . . . . . 58
Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Photo Editor . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Section 8: Applications .............................71
GPS Applications . . . . . . . . . . . . . . . . . . . . . . 71
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
App Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
ATIV Beam . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Bing Finance . . . . . . . . . . . . . . . . . . . . . . . . . 74
Bing News . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Bing Sports . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Bing Weather . . . . . . . . . . . . . . . . . . . . . . . . . 74
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Data Sense . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Help+Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . 79
Live Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . 79
MangaCamera . . . . . . . . . . . . . . . . . . . . . . . . 79
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Mini Diary . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
2
Music+Videos . . . . . . . . . . . . . . . . . . . . . . . . . 81
My Verizon Mobile . . . . . . . . . . . . . . . . . . . . . . 81
NFL Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Office . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
OneNote . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Paper Artist . . . . . . . . . . . . . . . . . . . . . . . . . . .83
People . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Photo Editor . . . . . . . . . . . . . . . . . . . . . . . . . .84
Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Samsung Link . . . . . . . . . . . . . . . . . . . . . . . . .85
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Share Box . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Shooting Modes . . . . . . . . . . . . . . . . . . . . . . .85
Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Video Trimmer . . . . . . . . . . . . . . . . . . . . . . . . .87
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
VZ Navigator . . . . . . . . . . . . . . . . . . . . . . . . . .88
Wallet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
WatchON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
3
Section 9: Connections .............................90
Internet Explorer . . . . . . . . . . . . . . . . . . . . . . .90
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
PC Connections . . . . . . . . . . . . . . . . . . . . . . . .94
Section 10: Changing Your Settings ........95
System Settings . . . . . . . . . . . . . . . . . . . . . . .95
Application Settings . . . . . . . . . . . . . . . . . . . .113
Section 11: Health and Safety
Information ..........................................122
Exposure to Radio Frequency (RF) Signals . . .122
Specific Absorption Rate (SAR) Certification
Information . . . . . . . . . . . . . . . . . . . . . . . . .127
FCC Part 15 Information to User . . . . . . . . . . .128
Smart Practices While Driving . . . . . . . . . . . .129
Battery Use and Safety . . . . . . . . . . . . . . . . .130
Samsung Mobile Products and Recycling . . . .132
UL Certified Travel Charger . . . . . . . . . . . . . .133
Display / Touch-Screen . . . . . . . . . . . . . . . . .134
GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Emergency Calls . . . . . . . . . . . . . . . . . . . . . .135
Care and Maintenance . . . . . . . . . . . . . . . . . 136
Responsible Listening . . . . . . . . . . . . . . . . . 137
Operating Environment . . . . . . . . . . . . . . . . 139
Restricting Children's Access to Your
Mobile Device . . . . . . . . . . . . . . . . . . . . . . 141
FCC Notice and Cautions . . . . . . . . . . . . . . . 141
Other Important Safety Information . . . . . . . 141
Section 12: Warranty Information .......... 143
Standard Limited Warranty . . . . . . . . . . . . . . 143
End User License Agreement for Software . . 148
Index ........................................................ 156
4
Section 1: Getting Started
This section reviews how to get started by configuring
your hardware, activating your service, and setting up your
voice mail.
Setting Up Your Phone
Prior to use, it is necessary to install both the battery and
SIM into their corresponding internal compartments.
1. Locate the slot on the side of the cover, use this slot to
pull the cover up, and then lift it away from the phone.
5
Installing the SIM Card
A Subscriber Identity Module (SIM Card) is a “smartcard”
that houses personal information, such as your mobile phone
number, calling plan, account information, and content, such
as contacts, text messages, and call history.
The Verizon Wireless 4G LTE SIM Card is compatible with any
Verizon Wireless 4G LTE certified device. You can move the
4G LTE SIM Card from one device to another and your
wireless service will work seamlessly as long as you have a
compatible device and service plan. To see which devices
are compatible with the Verizon Wireless 4G LTE SIM Card,
visit
verizonwireless.com/certifieddevice
.
With the battery removed, carefully slide the SIM card
into the SIM card socket (as shown) until the card locks
into place.
Make sure that the card’s gold contacts face into the
phone and that the upper-left angled corner of the card
is positioned as shown.
Important! The plug-in SIM card information and its contacts
can be easily damaged by scratching or bending,
so be careful when handling, inserting, or
removing the card. Keep all SIM cards out of
reach of small children.
Note: If the card is not inserted correctly, the phone will not
detect the SIM card. Re-orient the card back into the
slot if the SIM is not detected.
Getting Started 6
Installing the Battery
1. Insert the battery into the opening on the back of
the phone, making sure the three metal connectors
align (1).
2. Gently press down to secure the battery (2).
3. Replace the battery cover (the back of the phone) by
aligning the bottom of the battery cover with the phone
as shown.
7
4. Press the cover down into place.
5. Press down firmly along the edges of the cover to
ensure that the cover is flush with the phone. You
should hear a light click as the cover locks in place.
Note: Make sure the battery is properly installed before
switching on the phone.
Charging a Battery
Your phone is powered by a rechargeable Li-ion battery. The
Wall/USB Charger, which is used to charge the battery, is
included with your phone. Use only approved batteries and
chargers. Long backlight settings, searching for service,
vibrate mode, browser use, and other variables may reduce
the battery’s talk and standby times.
Although you can use the phone while the battery is
charging, doing so requires additional charging time.
Note: You must fully charge the battery before using your
phone for the first time. A discharged battery recharges
fully in approximately 4 hours.
Getting Started 8
Using the Wall/USB Charger
1. Connect the USB cable to the power adapter.
2. Plug the power adapter into a standard electrical
outlet.
3. Connect the small end of the USB cable into the
phone’s Micro USB Charging Port.
When you connect the charger, your phone powers on
automatically. Your Windows phone stays powered on
whenever it is charging.
9
4. When charging is finished, remove the flat end from
the interface connector jack on the phone.
Caution! Failure to unplug the wall charger before you
remove the battery can cause damage to the phone.
Low Battery Indicator
When the battery is weak and only a few minutes of talk time
remain, the “Battery critically low” warning appears and the
device sounds a warning tone at regular intervals.
For a quick check of your battery level, glance at the battery
charge indicator located in the upper-right corner of your
device’s display. A solid battery icon ( ) indicates a
full charge.
When the battery level becomes too low, the phone
automatically turns off.
Note: If the phone automatically turns off because the battery
level is too low, you must charge the battery until the
phone turns on automatically.
Memory Card
Your device supports optional, removable, microSD or
microSDHC memory cards (not included) for storage of
music, pictures, and other files.
For more information about using memory cards, see “Phone
Storage” on page 102.
Installing a Memory Card
1. Locate the microSD card slot on the side of the phone.
2. Place the card with the gold strips facing down.
3. Carefully slide the optional microSD card into the card
slot (as shown) until it “clicks” into place.
Removing a Memory Card
Warning! To prevent damage to data stored on the memory
card, unmount the card before removing it from the
device.
1. From the Home screen, touch Settings. Under the
system menu, touch phone storage ➔ SD card ➔
remove SD card.
2. At the prompt, read the warning and select OK to
continue. Wait for the SD card safe to remove icon to
appear in the Status bar and Notification panel.
3. Locate the microSD card slot on the side of the phone.
4. Push the memory card inward to release the lock, and
then carefully pull the card out.
Getting Started 10
Turning your Phone On or Off
To tu rn ON, press and hold the Power/Lock button.
To po wer OFF, press and hold the Power/Lock button
and follow the prompts.
Note: The display language is preset to English at the factory.
To change the language, use the Language menu. For
more information, refer to “Language + Region” on
page 106.
Locking and Unlocking your Phone
Prevent accidental key presses by locking your phone.
To lock, press the Power/Lock button.
To unlock, press the Power/Lock button. Then swipe
your finger up the screen.
Note: Your phone is able to make emergency calls without
being set up or having a SIM card installed, if your
mobile operator allows. To place an emergency call,
touch emergency call and dial 911 or the appropriate
emergency phone number.
11
Using the Start-Up Wizard
The very first time you turn on your phone, the Start-up
Wizard screen will guide you through the basics of setting up
your device.
Follow the prompts to choose a default language, country/
region and time zone, date and time, Wi-Fi network.
• To get apps, play games, automatically sync Windows Live
information to the web, and more, you need a Microsoft
account. If you already have an Xbox LIVE, Hotmail, or
Windows ID, you already have a Microsoft account.
The Start-up Wizard will prompt you to sign in with your
existing Microsoft account, or to create a new one.
Note: If you choose Sign in later, you can postpone setting up
your Microsoft account. A Microsoft account required
screen displays when you try to use a feature that
requires that you be signed in.
• You can also set up Backup Assistant Plus, a free service
from Verizon Wireless that automatically backs up your
contacts. Visit
verizonwireless.com/baplus
to learn more.
Setting Up Your Voice Mail
1. From the Home screen, touch .
2. Dial *86 and touch Call, or touch voicemail.
3. If you hear a greeting, press # to interrupt, and follow
the setup tutorial.
Note: These steps may be different depending on your
cellular network.
Accessing Your Voice Mail
1. From the Home screen, touch .
2. Dial *86 and touch Call, or touch voicemail.
3. When you hear the greeting, press # to interrupt, and
follow the prompts.
Accessing Your Voice Mail from Another Phone
1. Dial your wireless phone number.
2. When you hear the greeting, press the # to interrupt,
and follow the prompts.
Important! Voice mailboxes not set up within 45 days will be
canceled. Your voice mailbox is not password
protected until you create a password by
following the setup tutorial.
Visual Voice Mail
View a list of messages without dialing into a mailbox. Listen
or erase with the touch of a button.
From the Home screen, swipe left to display the
Applications menu and touch Voicemail. Follow
the prompts to set up visual voice mail.
Note: Data charges apply when using Visual Voice Mail.
Phone Updates
Updating your phone can make it work better and add new
features. Updates can also make your phone more secure.
For more information, refer to “Phone Update” on page 108.
Getting Started 12
Section 2: Understanding Your Phone
1
2
3
4
5
6
7
8
This section outlines some key features of your phone and
describes the screen and the icons that appear when the
phone is in use. It also shows how to navigate through
the phone.
Front View
The following items can be found on the front of your phone.
1. Earpiece: Use to hear the caller.
2. Proximity and light sensors: The Proximity sensor
detects how close an object is to the surface of the
screen (such as when your face is against the phone
during a call or the phone is in your pocket), locks the
keys to prevent accidental key presses, and turns off
the screen. Light sensors use the ambient light level to
adjust screen brightness and contrast.
3. Front-facing camera: Use to photograph yourself, or
view yourself while video chatting.
13
4. Indicator icons: Shows the information needed to
operate your phone, such as the received signal
strength, phone battery level, and time. If the icons are
not showing, touch the top of the display to show them.
5. Display: Shows the information needed to operate
your phone, such as the Application Tiles, icons, and so
on.
6. Back: Use to step backwards when navigating a menu
or web page. Touch and hold the Back key to view the
current screen and up to six screens most recently
displayed.
7. Home: Access the Home screen from any screen.
Touch and hold to activate the voice search engine.
8. Bing search: Access the Bing search engine, which
allows you to search for items on the internet, scout,
music, vision, and voice. For more information, refer to
“Bing Search” on page 18.
Note: Some applications, such as People and Store, display a
search button that allows you to search within that
application.
Understanding Your Phone 14
Back, Top, and Bottom View
2
4
9
7
5
6
1
8
3
The following items can be found on the back, the top, and
the bottom of your phone.
15
1. IR transmitter: Used to emit infrared signals used for
controlling external devices.
2. 3.5mm headset jack: Plug in for accessories.
3. Power/Lock: Press and hold the Power/Lock button
until the phone switches on. Also be use to lock or
unlock the touch screen. For more information on
locking your phone, see “Locking and Unlocking your
Phone” on page 20.
4. Flash: Use when taking photos or recording videos.
5. USB/charging port: Use to connect a charger or other
optional accessories such as a USB/data cable.
6. Microphone: Allows callers to hear you when you are
speaking to them. Also allows you to use the voice
search engine.
7. External speaker: Allows you to hear when the
Speakerphone is turned on.
8. Volume: Adjust the ringer volume while in standby
mode or adjust the voice volume during a call. When
receiving an incoming call, briefly press down either
volume key to mute the ring tone. Also use to adjust
the volume while playing music or videos, press the
volume key to display additional controls.
9. Rear-facing camera: Use to take pictures and record
videos.
Display Layout
Your display screen provides a wealth of information about
the phone’s status and options, as well as providing access
to application icons. For more information, refer to “Front
View” on page 13.
Indicator Icons
This list identifies the symbols that appear on your phone’s
display and Indicator area:
Note: Touch the top of the screen to display hidden icons.
Displays your current signal strength. The greater the
number of bars, the stronger the signal.
Displays when there is no SIM card in the phone.
Displays when the SIM card is locked.
Displays your battery charge level. Icon shown is fully
charged.
Understanding Your Phone 16
Displays when your battery is charging and displays
battery charge level. Displays when the phone is
connected to a computer via a supported USB cable
connection.
Battery critically low, which means your battery
needs to be charged soon or your phone will turn off.
Displays when battery saver is on.
Displays when battery power or the state of the
battery is not currently known.
Displays when your connection to an EDGE network
is active.
Displays when your connection to an GPRS network
is active.
Displays when your connection to a HSDPA/HSUPA
network is active.
Displays when your connection to a RTT network is
active.
17
Displays when your connection to an EVDO network
is active.
Displays when your connection to an EVDV network
is active.
Displays when your connection to a UMTS network is
active.
Displays when your connection to a 4G network is
active.
Displays when your connection to a 4G LTE network
is active.
Displays when the ringtone is set to vibrate only.
Displays when the ringtone is set silent.
Displays when Bluetooth is activated and your phone
has been connected with a Bluetooth device.
Displays when Bluetooth is activated, but your phone
has not connected with a Bluetooth device.
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point (WAP).
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point (WAP).
Displays when Wi-Fi is active, but there is a
communication issue with the target Wireless
Access Point (WAP).
Indicates that Airplane Mode is active. You cannot
send or receive any calls or access online
information.
For more details on configuring your phone’s settings, see
“Changing Your Settings” on page 95.
Bing Search
Bing Search provides an onscreen Internet search engine. It
also lets you link to Local Scout, listens to music and
searches for it, scans text that can be used as a search term,
and lets you say a search term.
Tip: Some applications, such as People and Store, display a
search button that allows you to search within that
application.
1. From any screen, touch .
2. Touc h th e Bing Search bar.
3. Use the onscreen keyboard to enter the item you want
to search for.
4. Touch to see search results and then touch on a
link.
5. Touc h music to launch a Bing audio search,
causing the phone to start listening for nearby music.
If the recorded sample can be found in the Windows
Phone Store, the artist and song appears in a pop-up
window with a direct link to the Windows Phone Store,
which lets you purchase and download the song.
Understanding Your Phone 18
6. Touch vision to scan barcodes, QR Codes,
Microsoft Tags, book covers, CDs, DVDs, or text.
7. Touch voice (in the search bar) to use Voice Search.
Speak the word you want to search for, and then follow
the onscreen instructions.
8. Touch Options
• Music history: After touching music and
searching for music, your matches are saved here for
future reference.
•Settings: Opens the Search settings screen. For more
information, refer to “Search” on page 120.
to access the following options:
Speech Engine
There is an intuitive speech engine integrated into the Start
key on your phone.
1. From any screen, touch and hold to activate the
intuitive speech engine.
19
2. Speak the words that you would like to search on or
the action that you would like to perform.
The following examples show the flexibility of the
speech engine:
• “Call Chris mobile”
• “Find coffee in Seattle”
• “Open calendar”
• “Text Brandy”
• “Note send birthday card”
3. To change speech settings, see “Speech” on
page 107.
Note: The first time you use the Speech engine, you are asked
to allow Microsoft to use your voice data to provide and
improve the service, which makes additional features
available to you. Touch accept or decline. Touch
Privacy Statement for more information.
Menu Navigation
You can tailor the phone’s range of functions to fit your needs
using menus. Menus, sub-menus, and features can be
accessed by scrolling through onscreen menus.
Locking and Unlocking your Phone
To unlock your phone:
1. Press the Power/Lock button located on the upper
right side of your phone. The lock screen displays.
2. Swipe the lock screen in an upward direction.
3. The Home screen displays as shown.
Home Screen Overview
The Home screen is the starting point for many applications
and functions, and you can pin items like application icons,
shortcuts, contacts, and web pages to your Home screen to
give you instant access to information and applications. The
Home screen is accessible from any menu or application by
pressing
.
Navigating to the Application Menu
1. At the Home screen, swipe the screen to the left.
2. The Application Menu displays.
3. Touch one of the application icons to launch the app.
4. Swipe the screen up or down to access all of the
available application icons.
5. To return to the Home screen, swipe the display to the
right.
Navigating Using Sub-Menus
Sub-menus are available when you are at any screen such
as Phone, People, Messaging, or Internet and Options
displays at the bottom of the screen.
1. To uch
display
screen.
2. Touc h an option. The following example shows the call
history screen before and after touching
Options on the bottom right corner of your
. A sub-menu appears at the bottom of the
Options.
Understanding Your Phone 20
Customizing Your Home Screen
You can customize your Home screen by doing the following:
• Adding and removing application tiles on the Home screen
• Repositioning application tiles
• Changing the background
Adding a Tile from the Applications Menu
1. At the Home screen, swipe the screen to the left. The
Application menu displays.
2. Touch and hold an application.
3. Touch pin to start after it displays under the icon.
The application now appears as the bottom Tile on the
Home screen. You can then move it if you would like.
For more information, refer to “Moving Tiles On the
Home Screen” on page 21.
21
Removing a Tile from the Home Screen
To delete an Application Tile from your Home screen, follow
these steps:
1. From the Home screen, touch and hold the Application
Tile that you want to remove.
2. Touch unpin to delete the Tile.
Tip: After deleting any Application Tile, you can add it back
later by pinning it to the home screen from the
Applications Menu. For more information, refer to “Adding
a Tile from the Applications Menu” on page 21.
Moving Tiles On the Home Screen
To move an Application Tile on your Home screen, follow
these steps:
1. From the Home screen, touch and hold the Application
Tile that you want to move.
2. Drag the Tile to the new location and release.
3. Touch the center of the icon to place it in the new
location.
• Be careful not to touch unpin. If you do, the Tile
will be deleted.
Resizing Tiles On the Home Screen
Tiles may be displayed as small, medium, or large tiles.To
resize an Application Tile on your Home screen, follow these
steps:
1. From the Home screen, touch and hold the Application
Tile that you want to resize.
2. Touch
medium, and large.
Note: Not all tiles may be resized as small, medium, or large.
, , or to toggle between small,
Changing the Lock Screen Background
You can change the background of your Lock screen by
following these steps:
1. From the Home screen, swipe the screen to the left to
display the Application Menu, and then touch
Settings.
2. Under the system menu, touch lock screen.
3. Touc h th e Background field to choose an image
location:
•photo: Sets a photo as the Lock screen background.
Touch the change photo field to select a photo from
your photo albums. Slide the photo within the window
to crop it, and then touch to save.
•Bing: Randomly sets professional Bing images as the
Lock screen background.
• Live Wallpaper: Sets Live Wallpapers as the Lock
screen background. Touch the open app field to
launch Live Wallpaper.
• Photo Editor: Edit the background image with Photo
Editor. Touch the open app field to launch Photo Editor.
4. Touc h th e Power/Lock button
Lock screen background.
Understanding Your Phone 22
twice to view the new
Changing the Color Theme
You can change the color theme of your phone by following
these steps:
1. From the Home screen, swipe the screen to the left to
display the Application Menu, and then touch
Settings.
2. Under the system menu, touch theme.
3. Touch the Background field.
4. Touch on dark or light to set your background color.
5. Touch the Accent color field.
6. Touch on a color that you like.
7. Press to return to the Home screen.
Note: Battery power is consumed at a faster rate when the
background is set as light.
23
Section 3: Entering Text
This section describes how to select the desired text input
method when entering characters into your phone.
This section also describes the predictive text entry system
that reduces the amount of key strokes associated with
entering text.
Note: Your phone comes equipped with an orientation
detector that can tell if the phone is being held in a
portrait (upright) or landscape (sideways) orientation.
The landscape orientation makes entering text easier. If
the phone is sideways or upright, an onscreen, QWERTY
keyboard displays.
Keys
You can enter characters into your phone by using an
onscreen, QWERTY, portrait or landscape keyboard. In both
formats, the keys are associated with alphabetic letters,
special characters, or numbers, as shown in the following
layouts.
• From a screen where you can enter text, such as the New
Message screen, hold your phone in an upright position to
display the portrait version of the onscreen QWERTY
keyboard.
Entering Text 24
Loading...
