Microwave Oven
Owner’s Manual
SMV7165
Code No. : DE68-02701B
Safety
P
P
RECAUTIONS TO
OSSIBLE
E
XPOSURE TO
A
VOID
I
MPORTANT
When using any electrical appliance, basic safety precautions
should be followed, including the following:
S
AFETY INSTRUCTIONS
XCESSIVE
E
NERGY
E
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the front face of the oven
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
:
M
ICROWAVE
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there is
dangerous voltage inside. If the oven needs to be
repaired, call
an authorized service center near you.
1-800-361-3400 CANADA for the name of
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “
Excessive Microwave Energy
• This appliance must be grounded. Connect only to properly grounded
outlets. See “
manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may
explode if heated in this oven.
• Use this appliance only for its intended use as described in the
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook, or dry food. It
is not designed for industrial or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service
personnel. Contact the nearest authorized service facility for
examination, repair, or adjustment.
• Do not cover or block any of the openings on this appliance.
Important Grounding Instructions
Precautions to Avoid Exposure to
” on this page.
” on page 5 of this
S
AVE
T
HESE INSTRUCTIONS
2
Safety
Important Safety Instructions, continued
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
• Keep the inside of the oven clean. Food particles or spattered oils
stuck to the oven walls or floor can cause paint damage and reduce
the efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance carefully if paper, plastic,
or other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing
bags in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn
the oven off, disconnect the power cord, or shut off the power at
the fuse or circuit breaker panel. If the door is opened, the fire may
spread.
d. Do not use the oven compartment for storage purposes. Do not
leave paper products, cooking utensils, or food in the oven when
not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will
not cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The
containers can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from
hands and face.
• Remove lids from baby food before heating. After heating baby food,
stir well and test temperature by tasting before serving.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appliance when it is in
operation.
• This over-the-range oven was designed for use over ranges no wider
than 91.44 cm(36 inches). It may be installed over both gas and
electric cooking equipment.
• Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to be
boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE CONTAINER IS DISTURBED
OR A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury to persons:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway through heating it.
3. Do not use straight-sided containers with narrow necks.
4. After heating, allow the container to stand in the microwave
oven for a short time before removing the container.
5. Use extreme care when inserting a spoon or other utensil
into the container.
S
AVE
T
HESE INSTRUCTIONS
3
Safety
Important Safety Instructions for using the
heater features
(
Brown, Combi, Convection, Warm, Preheat, Cook Book Menu, Auto
Cook Menu, Speed Cook Menu)
• Do not touch hot areas of oven, and always use hot pads,
holders or gloves when removing hot items from the oven.
• Do not use these features to heat baby food or bottles.
• Do not use these functions for defrosting your food. There is
an “Auto Defrost“ especially for this.
• Do not use the warm feature to reheat cold foods. Do not
warm food for more than 1 hour.
• Do not use paper, cardboard, plastic or anything containing
these substances.
• Do not move oven when it is hot.
• Use caution when disposing of hot grease.
• Do not use paper products when appliance is operated in the
Brown, Combi, Cook Book Menu, Auto Cook Menu Speed
Cook Menu mode.
• Do not cover racks or any other part of the oven with metal foil
unless special instruction in the cookbook or this manual. This
will cause overheating of the oven.
• Use caution when heater features are in use. Heater functions
are Convection, Brown, Combi, Preheat, Warm, Auto Cook
Menu, Cook Book Menu, Speed Cook Menu.
• Do not let children use this oven unless under the supervision
of an adult.
• Failure to use caution can lead to bodily injury.
• Oversized foods or oversized metal utensils should not
inserted in microwave /toaster oven as they may create a fire
of electric shock.
• Do not clean with metal souring pads. Piece can burn off the pad and
touch electrical parts involving a risk of electric shock.
S
AVE
T
HESE INSTRUCTIONS
4
Safety
I
MPORTANT GROUNDING
I
NSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This
appliance is equipped with a cord that includes a grounding wire
and a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded. Plug the three-prong
power cord into a properly grounded outlet of standard 115-120
voltage, 60 Hz. Your oven should be the only appliance on this
circuit.
WARNING
Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or servicer if
you do not understand the grounding instructions or if you
are not sure if the appliance is properly grounded.
Do not use an extension cord with this appliance. If the
power cord is too short, have a qualified electrician or
service technician install an outlet near the appliance.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.
Note
Connect the oven only to a 20A greateror over
dedicated circuit.
THE VENT FAN
The fan will operate automatically under certain conditions
(see page 19).Take care to prevent the starting and spreading
of accidental cooking fires while the vent fan is in use.
• In the event of a grease fire on the surface units below the microwave
oven, smother a flaming pan on the surface unit by covering the pan
completely with a lid, a cookie sheet or a flat tray.
• Never leave surface units beneath your microwave oven unattended
at high heat settings. Boilovers cause smoking and greasy spillovers
that may ignite and spread if the microwave vent fan is operating. To
minimize automatic fan operation, use adequate sized cookware and
use high heat on surface units only when necessary.
• Clean Ventilating Hoods Frequently - Grease should not be allowed
to accumulate on hood of filter.
• When flaming foods under the hood, turn the fan on.
• Use care when cleaning the vent-hood filter. Corrosive cleaning
agent, such as lye-based oven cleaner, may damage the filter.
S
AVE
T
HESE INSTRUCTIONS
5
Contents
Safety ........................................................................................... 2
Contents ...................................................................................... 6
Your New Microwave Oven ........................................................7
Checking Parts ...................................................................................... 7
Warranty and Service Information ......................................................... 7
Setting Up Your Microwave Oven ......................................................... 7
Control Panel Buttons
.......................................................................... 8
Operation ..................................................................................... 9
Turning on the Power and Selecting a Display ..................................... 9
Selecting the Weight ............................................................................. 9
Selecting the Language ........................................................................ 9
Selecting the Sound .............................................................................. 9
Using the Settings feature ..................................................................... 9
Setting the Remind End Signal ........................................................... 10
Selecting the Child Lock ...................................................................... 10
Setting the Clock (12HR/24HR) .......................................................... 10
Using the Clock Button ........................................................................ 10
Setting the Word Speed ...................................................................... 10
Setting the Daylight Saving Time adjustment ...................................... 10
Setting the Demo Mode ...................................................................... 10
Using the Kitchen Timer ...................................................................... 11
Using the Pause/Cancel Button .......................................................... 11
Using the Help Button ......................................................................... 11
Using the Start/+1 min. Button ............................................................ 11
Using the Instant Cook Buttons ........................................................... 12
Reheating Automatically ..................................................................... 13
Using the Power/Auto Defrosting Button ............................................. 13
Using the Handy Helper Button ........................................................... 14
Handy Helper Chart ............................................................................ 14
Using the Kids Meals Button ............................................................... 14
Using the Snack Bar Button ................................................................ 15
Auto Defrosting Guide ......................................................................... 15
Using the microwave setting cooking times & Power levels ................ 16
Multi-stage Cooking (Maximum of 3 stages) ....................................... 16
Using the More/Less Buttons .............................................................. 16
Warming .............................................................................................. 17
Preheating the oven ............................................................................ 17
Convection Cooking ............................................................................ 17
Combination cooking {COMBI-Lo(Bake)} ............................................ 18
Combination cooking {COMBI-Hi(Roast)} ........................................... 18
How to Use the Shelf When Microwaving ........................................... 19
Turning the Turntable On/Off .............................................................. 19
Turning the Light On/Night/Off ........................................................... 19
Turning the Vent Fan Hi/Low/Off ......................................................... 19
Cooking Instructions ................................................................20
Cooking Utensils ................................................................................. 20
Testing Utensils ................................................................................... 20
Cooking Techniques ........................................................................... 21
General Microwave Tips ...................................................................... 21
Appendix ................................................................................... 22
Troubleshooting Guide ........................................................................22
Care and Cleaning ............................................................................... 22
How to Clean the Outside ....................................................................23
Light Bulb Replacement ....................................................................... 23
Exhaust Feature ..................................................................................24
Specifications .......................................................................................25
Warranty .................................................................................... 26
Quick Reference .......................................................Back Cover
6
Your New Microwave Oven
)
Checking Parts
Unpack your microwave oven and check to make sure that you have all the
parts shown here. If any part is missing or broken, call your dealer.
Owner’s
Manual
Wall Template
Grease Filters
Microwave oven
Installation
Instructions
Glass Tray
Charcoal filter
(Part No. : DE63-30016D)
Registration
Card
Top Template
Roller Guide Ring
Hardware-kit
(Part No. : DE92-90505E)
(Part No. : DE63-00196A
Warranty and Service Information
To help us to serve you better, please complete the enclosed registration card
and promptly return it by mail. If the registration card is missing, you can call
Samsung Electronics Canada, Inc., at 1-800-SAMSUNG (1-800-726-7864),
or register on-line at www.samsung.ca
When contacting Samsung, please provide the specific model and serial
number information which is usually located on the back or bottom of the
product. Please record these numbers below, along with the other requested
information. Keep this information in a safe place as a permanent record of
your purchase to aid in identification in case of theft or loss, and a copy of your
sales receipt as a proof of purchase if warranty service is needed.
MODEL NUMBER _______________________
SERIAL NUMBER _______________________
DATE PURCHASED _______________________
PURCHASED FROM _______________________
Warranty service can only be performed by a Samsung Authorized Service
Center. If you should require warranty service, provide the above information
with a copy of your sales receipt to the Samsung Authorized Service Center.
For service assistance and the location of the nearest service center, please
call 1-800-SAMSUNG (1-800-726-7864).
Setting Up Your Microwave Oven
1
Plug the cord into a grounded outlet. Once plugged in, the display on
your oven will show:
ENJOY YOUR COOKING --- PRESS SETTINGS BUTTON FOR
PERSONAL OPTIONS
2
Open the oven door by pulling the handle on the right side of the door.
3
Wipe the inside of the oven with a damp cloth.
4
Place the pre-assembled ring in the indentation in the center of the
oven.
Shelf
(Part No. : DE75-00044A)
Exhaust Adaptor
(Part No. : DE92-90242A)
5
Place the glass tray securely in the center of the pre-assembled roller
guide.
7
Your New Microwave Oven
Control Panel Buttons Control Panel Buttons
1. Convection p.17
2. Microwave p.16
3. Combi-Lo p.18
4. Power/Auto Defrost p.13
5. Instant Cook Buttons p.12
Instant settings to cook popular foods.
6. Handy Helper, Kids Meals, Snack Bar p.14
Selects type of dish to be reheated.
7. Number/Cooking Temperature Buttons
Sets Baking temperature, cooking time, amount, and power level.
8. More/Less p.16
Increase or decrease cooking time.
9. Power Level p.16
Press this button to set a power level other than high.
10. Pause/Cancel p.11
Press to pause oven or correct a mistake.
11. Turntable p.19
12. Preheat p.17
13. Warm p.17
Keeps food warm at 175 °F for up to one (1) hour
14. Auto Reheat p.13
15. Combi-Hi p.18
16. Help p.11
Press to see help information about the feature you are using.
17. Clock p.10
Sets current time.
18. Settings p.9~p.10
Press to set non-cooking features.
19. Kitchen Timer p.11
Sets kitchen or convenience timer.
20. Start / 1 min. + p.11
Press to start cooking. Adds one (1) minute while
oven is operating.
21. Vent p.19
22. Light p.19
6
7
8
9
10
1
2
3
4
5
12
13
14
15
16
17
18
19
20
11
21
22
8
Operation
Turning on the Power and Selecting a Display
The first time you plug the power cord into an outlet, or after there has been
an interruption in power, the display will show after four seconds:
ENJOY YOUR COOKING --- PRESS SETTINGS BUTTON FOR
PERSONAL OPTIONS
Press Settings button immediately after plugging in your oven. The display
will show:
1- WEIGHT 2- LANGUAGE
3- SOUND ON/OFF 4- REMIND ON/OFF
5- CHILD LOCK ON/OFF 6- CLOCK 12HR/24HR
7- WORD PROMPT SPEED 8- DAYLIGHT SAVING ON/OFF
9- DEMO ON/OFF
Selecting the Weight
You can choose between pounds(LBS) and kilograms(KG).
1
Press
Settings
The display shows :
2
Press
Settings
The display shows :
3
Press the
measurements you wish to use.
4
Press the
button and then press the 1 button.
LBS OR KG --- PRESS SETTINGS BUTTON
button.
KG
Settings
Start
button repeatedly to select the weight
button.
Selecting the Language
1
Press setting button and then press the 2 button.
The display shows:
SETTINGS BUTTON
2
Press the settings button to select English.
3
Press again to select French.
4
Press the
Start
LANGUAGE OPTION CONTROLS --- PRESS
button.
Selecting the Sound
1
Press
Settings
The display shows :
SETTINGS BUTTON
2
Press the
Press again to select
3
Press the
button and then press the 3 button.
SOUND VOLUME CONTROLS --- PRESS
Settings
Start
button to select
Sound OFF
button.
Sound ON
.
.
Using the Settings feature
Your new microwave oven can be customized to suit your personal tastes.
Simply press Settings to set these options. For your convenience, all the
options are summarized in the following table:
Item
• If there is a power interruption, you will need to reset these options.
Settings
No.
options
Display Weight Weight options are
1
Language
2
Choice
Sound Sound volume can be
3
Remind End
4
Signal
Child Lock This feature prevents from
5
Clock The clock can display
6
Word Prompt
7
Speed
Daylight
8
Savings Time
Adjustment
Demo Mode The Demo Mode can be
9
Description Operation
pounds and kilograms.
Language options are
English, French
turned On and Off.
The Remind End Signal
can be turned On and Off.
using of unsupervised
children.
either 12HR or 24HR time
modes.
There are five speeds,
from Level 1(slowest) to
Level 5(fastest).
Default is Level 3.
The time can be advanced
one hour for DST without
resetting the Clock.
turned On and Off.
Press
Settings, 1
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Press
repeatedly pressing
To set, press
Start
Settings, 2
Start.
Settings, 3
Start
Settings, 4
Start
Settings, 5
Start
Settings, 6
Start
Settings, 7
Start
Settings, 8
Start
Settings, 9
Start
and select by
Settings
.
and select by
Settings,
and select by
Settings
.
and select by
Settings
.
and select by
Settings
.
and select by
Settings
.
and select by
Settings
.
and select by
Settings
.
and select by
Settings
.
,
.
.
.
.
.
.
.
9
Operation
Setting the Remind End Signal
The Remind End Signal can be set On or Off.
1
Press the
The display shows
REMIND END SIGNAL ON/OFF --- PRESS SETTINGS BUTTON
2
Press the
Press again to select OFF.
3
Press the
To turn Remind End Signal off, repeat steps 1-3 above.
Settings
Settings
Start
button and then press the 4 button.
:
button to select ON.
button. The display returns to the time of day.
Selecting the Child Lock
1
Press the
The display shows :
CHILD LOCK ON / OFF --- PRESS SETTINGS BUTTON
2
Press the
Press again to select
3
Press the
Settings
Settings
Start
button.
button and then press the 5 button.
button to select
Lock OFF
Lock ON
.
.
Setting the Clock (12HR/24HR)
1
Press
Settings
The display will show:
BUTTON
2
Press the
Press again to select
3
Press the
button and then press the 6 button.
CLOCK 12HR/24HR --- PRESS SETTING
Settings
Start
button to select
12HR
button.
.
24HR
.
Setting the Word Speed
1
Press the
The display shows :
WORD PROMPT SPEED --- PRESS SETTINGS BUTTON
2
Press the
The display shows :
3
Press Settings button repeatedly to select the Word Speed you wish to
use:
SLOWEST, SLOW, NORMAL, FAST, FASTEST
If you continue to press
shown here:
4
Press the
Settings
Settings
Start
button and then press the 7 button.
button
SLOWEST
SLOWEST, SLOW, NORMAL, FAST, FASTEST
Settings
button
, the settings will cycle in the order
Setting the Daylight Saving Time adjustment
1
Press the
The display will show:
DAYLIGHT SAVING TIME --- PRESS SETTINGS BUTTON
2
Press the
Press again to select
3
Press the
If OFF is selected, time will go back one hour.
If the clock is set for standard time, this function allows convenient time
changes without needing to reset the clock. Daylight Saving Time begins
for most of the United States at 2 a.m. on the first Sunday of April, and
reverts to Standard time at 2 a.m. on the last Sunday of October.
Settings
Settings
Start
button and then press the 8 button.
button to select
Time OFF
butt on. Time of day wi ll adv ance one hour.
Time ON
.
.
Setting the Demo Mode
Using the Clock Button
1
Press the Clock button.
The display shows :
2
Use the number buttons to enter the current time.
You must press at least three numbers to set the clock.
For example, if the current time is 5:00, enter 5,0,0.
The display will show:
3
Press
Clock
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by pressing
the
Clock
button.
SET CLOCK WITH NUMERIC BUTTON
5:00
again. A colon will appear, indicating that the time is set.
10
1
Press the
The display shows :
BUTTON
2
Press the
Press again to select
3
Press the
Settings
Settings
Start
button
button and then press the 9 button.
DEMO MODE ON/OFF --- PRESS SETTINGS
button to select
Demo OFF
Demo ON
.
.
Operation
Using the Kitchen Timer
1
Press the
(max. settting time 99 min. 99 sec.)
(operating time 99min. 59sec.)
The display shows:
2
Use the
3
Press the
The display counts down and beeps when the time has elapsed.
Kitchen Timer
SET TIME WITH NUMERIC BUTTON
Number
buttons to set the length of time to run.
Start
button
button.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear instructions you have entered.
It also allows you to pause the oven’s cooking cycle, so that you can check
the food.
• To pause the oven during cooking : press
restart, press
• To stop cooking, erase instructions, and return the oven display to the time of day:
press
• To clear instructions you have just entered: press
then re-enter the instructions.
To cancel a timer setting: press
Start
button.
Pause/Cancel
button twice.
Pause/Cancel
Pause/Cancel
Pause/Cancel
button once.
button once. To
button once,
Using the Help Button
Your Microwave offers helpful instructions for many procedures.
• When you need feature information and helpful hints, press the Help button and
then press the button that you want to get information on.
Using the Start/+1 min. Button
This button offers a convenient way to heat food in one-minute increments at
the High power level.
1
Press the
the food. For example, press it twice for two minutes. The time will
display, and the oven starts automatically.
2
Add minutes to a program in progress by pressing the Start/+1 min.
button for each minute you want to add.
Start/+1 min.
button once for each minute you wish to cook
11
Operation
Using the Instant Cook Buttons
1 Press the Popcorn button corresponding to the food you are
cooking (Popcorn, for example).
The display shows:
Popcorn 3.5 OZ
2 Press the button repeatedly to select the serving size you want.
The display will cycle through all available serving sizes. Once you
select the correct serving size, the microwave will begin cooking
automatically.
If you don’t need to read all the menu options, simply press the
button to being cooking.
When the cooking time is over, the oven will beep. The oven will then
beep every minute until the door is opened.
Start
Instant Cook Chart
Item Weight Remarks
Popcorn Butter
Potato 1 EA, 2 EA
Frozen
Breakfast
Pizza
Reheat
Frozen
Dinner
Frozen
Vegetables
(3.5 oz),
Light
(3.0-3.5 oz)
3 EA, 4 EA
5 EA, 6 EA
4-6 oz
6-8 oz
1 Slice
2 Slices
3 Slices
4 Slices
8-10 oz
10-12 oz
12-14 oz
1 serving
2 servings
3 servings
4 servings
• Use one microwave-only bag of popcorn. Pop
only one bag at a time.
• Use caution when removing and opening hot
bag from oven.
• Prick each potato several times with fork.
• Place on turntable in spoke-like fashion.
• Remove from oven, wrap in foil and let stand 35min.
• Remove package from outer wrapping and
follow package instructions for covering and
standing.
• After cooking, let stand 1-3 min.
• Put the pizza on a microwave-safe plate with
wide end of slice towards the outside edge of
the plate.
• Do not let slices overlap. Do not cover.
• Before serving, let stand 1-2 min.
• Remove package from outer wrapping and
follow package instructions for covering and
standing.
• After cooking, let stand 1-3 min.
• Remove from package.
• Place the vegetables into a casserole bowl and
add a small amount of water (2-4Tbsp).
• Cover during cooking and stir before standing.
Fresh
Vegetables
Bacon 2 Slices
12
1 serving
2 servings
3 servings
4 servings
4 Slices
6 Slices
• Place the vegetables into a casserole bowl and
add a small amount of water (2-4Tbsp).
• Cover during cooking and stir before standing.
• Place 2 paper towels on plate and arrange
bacon on towels, do not overlap. Cover with
additional paper towel. Remove paper towel
immediately after cooking.
• Use More or Less button for desired crispness.
Operation
Reheating Automatically
To reheat food, select the type of dish and the number of servings you want to
reheat, then the oven will automatically set the reheating time.
1 Press the Auto Reheat button.
The display shows :
SELECT ITEM WITH THIS BUTTON
2 Press Auto Reheat repeatedly to select the type of dish you wish
to reheat. The initial serving size for each dish is one serving.
The display shows :
PLATE OF FOOD
CASSEROLE
PASTA
SOUP
You can select up to four servings for casseroles, pasta reheat and Soup
Reheat. Only one serving is available for a plate of food.
3 Use the Number buttons to increase the serving size.
For example, for three servings, press the 3 button(Refer to
the Auto Reheat Chart below for the servings).
The display shows the number of servings you have selected:
SELECT SERVING OR PRESS START
4 Press the Start button and reheating will begin.
Auto Reheat Chart
• Follow the instructions below when Auto Reheating different types of food.
Item Weight Remarks
Plate of
Food
1 serving
• Use only pre-cooked, refrigerated foods.
• Cover plate with vented plastic wrap or wax
paper.
• Contents
- 3-4 oz. meat, poultry or fish
( up to 6 oz. with bone)
- ½ cup starch (potatoes, pasta, rice,
etc.)
- ½ cup vegetables (about 3-4 oz.)
Casserole
Pasta
Reheat
Soup
Reheat
1 to 4 servings
(8 oz./serving)
1 to 4 servings
(8 oz./serving)
1 to 4 servings
(8 oz./serving)
• Use only refrigerated foods.
• Cover with lid or vented plastic wrap.
• Stir foods well before serving.
Using the Power/Auto Defrosting Button
To thaw frozen food, set the weight of the food and then the oven will automatically set the defrosting time, power level and standing time.
Please note that defrosting foods which weigh more than 1.0 lbs will take
several minutes longer than foods which weigh less.
1 Press the Power/Auto Defrost button.
The display shows:
SELECT ITEM WITH THIS BUTTON
2 Press the Power Defrost button 1 to 4 times and the items below
will appear in sequence on the display:
Press once - MEAT
Press twice - POULTRY
Press three times - FISH
Press four times - BREAD
The display shows:
ENTER WEIGHT WITH NUMERIC BUTTON
3 Enter your desired weight with number button.
The display shows: PRESS START
4 Press the Start button
5 When the oven beeps, open the door and turn food over.
Press the Start button to begin defrosting.
See page 15 for the Auto Defrosting Guide.
•
13
Operation
Using the Handy Helper Button
1
Press the
cooking. The display shows”
Press the
want.(Refer to the
Handy Helper
Handy Helper
Handy Helper Chart
button corresponding to the food you are
SELECT ITEM WITH THIS BUTTON
button repeatedly to select the item you
below)
”
2 Press the Number 1 or 2 button to select the serving size you want.
Only the 1 button(serving) is available for Soften Cream Cheese
and Melt Chocolate items.(Refer to the Handy Helper Chart below
for the serving)
3 Press the Start button to begin cooking.
Handy Helper Chart
Item Weight Remarks
Melt
Chocolate
Soften Cream
Cheese
Melt Butter 1 stick
1 cup chip • Place chocolate chips or square in a
1 package
(8 oz)
(1/4 lb.)
2 sticks
(1/2 lb.)
microwave-safe dish.
• Stir well at half time when the oven
beeps, and re-start the oven.
• Unwrap cream cheese and place on
microwave-safe dish. Cut in half
vertically.
• Let stand 1-2 minutes.
• Remove wrapping and cut butter in half
vertically.
• Place butter on microwave-safe dish,
cover with wax paper.
• Let stand 1-2 minutes, then stir.
Using the Kids Meals Button
1 Press the Kids Meals button corresponding to the food you are
cooking.
The display shows :
Press the
want.(Refer to the
Kids Meals
SELECT ITEM WITH THIS BUTTON
button repeatedly to select the item you
Kids Meals Chart
below)
2 Press the Number 1 or 2 button to select the serving size you want.
(Refer to the Kids Meals Chart below for the serving.)
3 Press the Start button to begin cooking.
Kids Meals Chart
Item Weight Remarks
Chicken
Nuggets
Hot Dogs 2 EA
French Fries 4-5 oz
Frozen
Sandwiches
4-5 oz
6-7 oz
4 EA
6-7 oz
1 EA
2 EA
• Put a paper towel on top of plate and
arrange nuggets in spoke fashion.
• Do not cover. Let stand 1 minute after
heating.
• Prick hot dogs, place on plate. When the
oven beeps, add buns and re-start the oven.
• Place 2 paper towels on microwave-safe
plate and arrange french fries on towels, do
not overlap.
• Blot with additional paper towel after
removal from oven.
• Place frozen sandwich in susceptor "sleeve"
(which is in package) and put on plate.
Note
Hot Dogs - For the best texture, buns should be added to hot dogs when
the oven beeps.
14
Operation
Using the Snack Bar Button
1 Press the Snack Bar button corresponding to the food you are
cooking.
The display shows :
Press the
want.(Refer to the
Snack Bar
SELECT ITEM WITH THIS BUTTON
button repeatedly to select the item you
Snack Bar Chart
below)
2 Press the Number 1 or 2 button to select the serving size you want.
Only the 1 bu tt on (s er vi ng ) i s a va il ab le fo r N ac ho s.
(Refer to the Snack Bar Chart below for the serving)
3 Press Start button to begin cooking.
Snack Bar Chart
Item Weight Remarks
Nachos 1 serving • Place tortilla chips on plate without
overlapping.
• Sprinkle evenly with cheese.
•Contents :
- 2 cups tortilla chips
- 1/3 cup grated cheese
Chicken Wings 5-6 oz
7-8 oz
Potato Skins 1 cooked
potato
2 cooked
potatoes
Cheese Sticks 5-7 pcs
8-10 pcs
• Use pre-cooked, refrigerated chicken
wings.
• Place chicken wings around plate in
spoke fashion and cover with wax paper.
• Cut cooked potato into 4 even wedges.
Scoop or cut out potato flesh, leaving
about 1/4" of skin.
• Place skins in spoke fashion around
plate.
• Sprinkle with bacon, onions and cheese.
Do not cover.
• Place cheese sticks on plate in spoke
fashion.
•Do not cover.
Auto Defrosting Guide
• Follow the instructions below when defrosting different types of food.
Food
Roast
Beef, Pork
Steaks,
Chops,
Fish
Ground
Meat
Whole
Chicken
Chicken
Pieces
Bread
Notes
Check foods when the oven signals. After the final stage, small sections may
still be icy; let them stand to continue thawing. Do not defrost until all ice crystals have thawed. Shielding roasts and steaks with small pieces of foil prevents the edges from cooking before the center of the food has defrosted.
Use narrow, flat, smooth strips of aluminum foil to cover the edges and thinner sections of the food.
Standard
Amount
2.5-6.0 lbs. Start with the food placed fat side down.
0.5-3.0 lbs. After each stage, rearrange the food. If
0.5-3.0 lbs. After each stage, remove any pieces of food
2.5-6.0 lbs. Remove giblets before defrosting poultry.
0.5-3.0 lbs. After each stage, rearrange or remove any
0.1-2.0 lbs.
After each stage, turn the food over and
shield any warm portions with narrow strips
of aluminum foil.
there are any warm or thawed portions of
food, shield them with narrow flat pieces of
aluminum foil. Remove any pieces of food
that are nearly defrosted. Let stand, covered, for 5-10 minutes.
that are nearly defrosted. Let stand, covered
with foil, for 5–10 minutes.
Start defrosting with the breast side down.
After the first stage, turn the chicken over
and shield any warm portions with narrow
strips of aluminum foil. After the second
stage, again shield any warm portions with
narrow strips of aluminum foil. Let stand,
covered, for 30–60 minutes in the refrigerator.
pieces of food that are nearly defrosted. Let
stand for 10-20 minutes.
Arrange rolls in a circle horizontally on
kitchen paper in the middle of turntable.
Turn over after half of defrosting time!
Procedure
15
Operation
Using the microwave setting cooking times &
Power levels
Your oven allows you to set up three different stages of cooking, each with its
own time length and power level. The power level lets you control the heating
intensity from Warm (1) to High (10/Power level).
One-stage Cooking
For simple one-stage cooking, you only need to set a cooking time.
The power level is automatically set at High. If you want to set the power at
any other level, you must set it using the Power Level button.
1
Press the Microwave Button.
2
Use the
from one second to 99 minutes, 99 seconds. To set a time over one
minute, enter the seconds too.
For example, to set 20 minutes, enter 2, 0, 0, 0 .
3
If you want to set the power level to something other than High, press
the
power level.
Power Levels:
The display shows :
THE FIRST STAGE COMPLETED. PRESS START OR SET THE
NEXT STAGE OF MICROWAVE, CONVECTION, BROWN OR
COMBI
Number
Power Level
0 = No Power 6 = Simmer
1 = Warm 7 = Medium High
2 = Low 8 = Reheat
3 = Defrost 9 = Sauté
4 = Medium Low 10 = High
5 = Medium Power level=High
buttons to set a cooking time. You can set a time
button, then use the number buttons to enter a
Multi-stage Cooking (Maximum of 3 stages)
1 Follow steps 1 and 2 in the “One-Stage Cooking” section on the
previous page.
The display shows :
START OR SET THE NEXT STAGE OF MICROWAVE,
CONVECTION, BROWN OR COMBI
When entering more than one cooking stage, the
must be pressed before the second cooking stage.
To set the power level at High for a stage of cooking, press the
Level
button twice.
THE FIRST STAGE COMPLETED. PRESS
Power Level
button
Power
2 Press the Microwave Button.
3 Use the Number buttons to set a cooking time.
4 Press the Power Level button, then use the number buttons to set
the power level of the second stage of cooking.
5
Press
Start
button to begin cooking, or repeat steps 2,3 and 4 to set a
cooking time and power level for a third stage of cooking.
When finished, press
Using the More/Less Buttons
The More or Less button allows you to adjust the pre-set cooking time.
It only works with 1,2, and 3 stage cooking, MW, Combi Lo/ Combi Hi, Convection, Auto Reheat, Preheat, Warm, Popcorn, Kitchen Timer buttons.
Use the More or Less button only after cooking has begun.
1
To ADD more time to a cooking procedure. Press the '9/More' button.
Each press adds 10 seconds to the cooking time.
2
To REDUCE the time of a cooking procedure. Press the '1/Less'
button. Each press reduces 10 seconds to the cooking time.
3
If you press the '9/More' or '1/Less' button after selecting auto cook or
speed cook button, each press adds /reduces the cooking time by 8%.
Start
button.
4
Press the
power level, press
button, and reenter all of the instructions.
Some recipes require different stages of cooking at different temperatures.
You can set multiple stages of cooking with your microwave.
Start
button to begin cooking. If you want to change the
Pause/Cancel
button before you press the
Start
16
Operation
Warming
You can keep food warm for up to one hour.
1 Press the Warm button.
The display shows: SET TIME WITH NUMERIC BUTTON
2 Use the Number buttons to set a warming time.
(max. time 60 min.)
3 Press the Start/+1 Min button.
• The side convection heater will operate only.
• The side convection heater will switch on and off to keep food
warm.
• The temperature of center of oven will remain at 175
°
F.
Preheating the oven
For convection cooking, it is recommended that you preheat the oven to the
appropriate temperature before placing the food in the oven.
When the oven reaches the requested temperature, it is maintained for
approximately 10 minutes; then switched off automatically.
1 Press the Preheat button.
The display shows:
ENTER DESIRED TEMP WITH NUMERIC BUTTON
2 Use the Number buttons to set a Temp up to 400 °F.
(100°F ~ 450°F Temp control.)
3 Press the Start button.
When the oven reaches the desired temperature, it will chime and the
display shows “
COOKING TIME OR PRESS START
When the oven beeps, place the food inside and follow the directions for
“convection baking”.
• Do not put any food in the oven during preheating.
• During preheat, you may hear noise from inside the oven.
This is simply the relay control sounding and is part of normal
operation.
(In Convection, Preheat and Warm modes)
PREHEAT DONE, PLACE FOOD IN OVEN SET
”.
Convection Cooking
The convection mode uses dry heat to cook and brown food.
A high speed fan circulates hot air inside the oven to heat food quickly and
evenly.
When you cook using convection, you can generally use the shelf rack .
1 Press the Convection button.
The display shows:
“
ENTER DESIRED TEMP WITH NUMERIC BUTTON
”.
2 Use the number button to set a temperature.
Convection cooking temperatures range from 100° F to 450° F.
To maintain a constant temperature, the oven’s door should be kept
closed as much as possible while cooking.
3 Use the number buttons to set a cooking time (max. time is 60 min).
4 The display shows: SET COOKING TIME OR PRESS START
5 Press Start/1 min.+ to begin to convection cooking.
17
Operation
Combination cooking {COMBI-Lo(Bake)}
•
Microwave and Convection
The combination cooking feature allows you to cycle automatically between
Microwave and Convection cooking.
:
1 Press the
The display shows:
"
SET COOKING TIME WITH NUMERIC BUTTON
Combi-Lo(Bake) button.
"
2 Use the number buttons to set a cooking time.
(max. time is 60 minutes.)
Maximum temperature 425°F micom control.
Microwave Power Level 10%
Maximum temperature that can be reached during cooking is 425°F.
3 Press Start/1min + to begin combination cooking.
Combi-Lo(Bake) Cooking Guide
• Preheat oven to 450F for all Combi-Lo(Bake) cooking.
• When using the Combi-Lo(Bake) mode, reduce the recipe cook time by 10~20%.
EX) A recipe states to cook a
30 minutes X 0.15 = 4 minutes 30 seconds saved.
The new cook time in Combi-Lo(Bake) mode will be:
30 minutes - 4 minutes 30 seconds = 25 minutes 30 seconds.
• Not recommended cakes, cookies, breads for best result.
Combi-Lo(Bake)
for 30 minutes at 400F
Combination cooking {COMBI-Hi(Roast)}
•
Microwave and Convection
The combination cooking feature allows you to cycle automatically between
Microwave and Convection cooking.
:
1 Press the
The display shows:
"
SET COOKING TIME WITH NUMERIC BUTTON
Combi-Hi(Roast) button.
"
2 Use the number buttons to set a cooking time.
(max. time is 60 minutes.)
Maximum temperature 425°F micom control.
Microwave Power Level 30%
Maximum temperature that can be reached during cooking is 425°F.
3 Press Start/1min + to begin combination cooking.
Combi-Hi(Roast) Cooking Guide
• Preheat oven to 450F for all Combi-Hi(Roast) cooking.
• When using the Combi-Hi(Roast) mode, reduce the recipe cook time by 20~30%.
EX) A recipe states to cook a
60 minutes X 0.25 = 15 minutes saved.
The new cook time in Combi-Hi(Roast) mode will be:
60 minutes - 15 minutes = 45 minutes.
• Recommended roast meats (beef,pork,poultry...) for best result.
Combi-Hi(Roast)
for 60 minutes at 400F.
18
Operation
How to Use the Shelf When Microwaving
• Make sure the shelf is positioned properly inside the
microwave to prevent damage to the oven from arcing.
• Do not use a microwave browning dish on the shelf. The shelf
could overheat.
• Do not use the oven with the shelf on the microwave floor.
This could damage the microwave.
• Use pot holders when handling the shelf-it may be hot.
• Do not use the shelf when cooking popcorn.
Food microwaves best when placed on the turntable or on the shelf in the
lower position.
For best results
Turning the Turntable On/Off
For best cooking results, leave the turntable on.
It can be turned off for large dishes.
Press Turntable On/Off button to turn the turntable on or off.
Sometimes the turntable can become too hot to touch.
Be careful touching the turntable during and after cooking.
Turning the Light On/Night/Off
Press to turn the Light On / Night /Off button on or off
Press Light On / Night /Off
three times
to turn the light off.
Turning the Vent Fan Hi/Low/Off
The vent fan removes steam and other vapors from surface cooking.
Press Vent Fan Hi/Low/Off button once for high fan speed, twice for low
fan speed and three times to turn the fan off.
Note
The Vent Fan protects the microwave from too much heat rising from
the cooktop below it. It automatically turns on if it senses too much
heat.
If you have turned the fan on, you may find that you cannot turn it off.
The fan will automatically turn off when the internal parts are cool. It
may stay on for 30 minutes or more after the cooktop and microwave
controls are turned off.
The Vent Fan will operate only in Hi/Low/Off mode while the microwave
is working.
once
for on light,
twice
for the night light and
19
Cooking Instructions
Cooking Utensils
Recommended Use
•
Glass and glass-ceramic bowls and dishes
cooking.
•
Microwavable plastic wrap
some steam to escape and avoid placing it directly on the food.
•
Wax paper
•
Paper towels and napkins
absorb excess moisture and prevent spattering. Do not use recycled paper
towels, which may contain metal and can catch fire.
•
Paper plates and cups
Do not use recycled paper, which may contain metal and can catch fire.
•
Thermometers
directions. Check the food in several places. Conventional thermometers may be
used once the food has been removed from the oven.
— Use as a cover to prevent spattering.
— Use only those labeled “Microwave-Safe” and follow all
— Use to cover. Leave a small opening for
— Use for short-term heating and covering; they
— Use for short-term heating at low temperatures.
Limited Use
•
Aluminum foil
areas. Using too much foil can damage your oven, so be careful.
•
Ceramic, porcelain, and stoneware
“Microwave-Safe”. If they are not labeled, test them to make sure they can be
used safely. Never use dishes with metallic trim.
•
Plastic
•
— Use only if labeled “Microwave-Safe”. Other plastics can melt.
Straw, wicker, and wood
flammable.
— Use narrow strips of foil to prevent overcooking of exposed
— Use these if they are labeled
— Use only for short-term heating, as they can be
Not Recommended
•
Glass jars and bottles
microwave, and can shatter.
•
Paper bags
designed for microwave use.
•
Styrofoam plates and cups
residue on food.
•
Plastic storage and food containers
tubs can melt in the microwave.
— These are a fire hazard, except for popcorn bags that are
— Regular glass is too thin to be used in a
— These can melt and leave an unhealthy
— Containers such as margarine
— Use for heating or
Testing Utensils
If you are not sure whether a dish is microwave-safe or not, you can perform
this test:
1
Fill 1 cup of glass measuring cup with water and put it inside your oven,
next to the dish you want to test.
2
Press the
High power.
The water should be warm and the dish you are testing should be cool. If the
dish is warm, then it is absorbing microwave energy and is not acceptable for
use in the microwave.
Recommended Use
•
Metal Pans
browning is important. Dark or dull finish metal pans are best for breads and pies
because they absorb heat and produce crisper crust.
•
Shiny aluminum pans
reflect heat and help produce a light tender crust.
•
Glass or Gladd-Ceramic
egg and cheese recipes due to the cleanability of glass.
Convection Cooking Use
•
Metal Pans
browning is important. Dark or dull finish metal pans are best for breads and pies
because they absorb heat and produce crisper crust.
•
Shiny aluminum pans
reflect heat and help produce a light tender crust.
•
Glass or Gladd-Ceramic
egg and cheese recipes due to the cleanability of glass.
Combination Cooking Use
•
Glass or Gladd-Ceramic
not to use items with metal trim as they may cause arcing (sparking) with the oven
wall or oven shelf. This can damage the cookware, the shelf or the oven.
•
Heat-Resistant Plastic
used, but it is not recommended for foods requiring all around browning, because
the plastic is a poor conductor of heat.
One Minute +
— Use for all types of baked products, but especially where
— Use for all types of baked products, but especially where
button once to heat them for one minute at
— Use for cakes, cookies or muffins because they
— Casserole or baking dishes are best suited for
— Use for cakes, cookies or muffins because they
— Casserole or baking dishes are best suited for
— baking containers are recommended. Be sure
— Microwave cookware (safe to 450F) may be
20
Cooking Instructions
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute heat
evenly. Food at the outside of the dish absorbs more energy and heats more
quickly, so stir from the outside to the center. The oven will turn off when you
open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with the
thicker, meatier parts toward the outside of the turntable where they receive
more microwave energy. To prevent overcooking, place thin or delicate parts
toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas
that need shielding include poultry wing-tips, the ends of poultry legs, and corners of square baking dishes. Use only small amounts of aluminum foil.
Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to microwave
energy. This is especially important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to cook
for a few minutes after the oven stops. Let foods stand to complete cooking,
especially foods such as roasts and whole vegetables. Roasts need this time
to complete cooking in the center without overcooking the outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let liquids stand a moment before serving. When heating
baby food, stir well and test the temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven in
moisture content should be covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food to help it cook.
Venting
After covering dish with plastic wrap, you vent plastic wrap by turning back
one corner so excess steam can escape.
General Microwave Tips
• Dense foods, such as potatoes, take longer to heat than lighter foods. Foods with
a delicate texture should be heated at a low power level to avoid becoming tough.
• Altitude and the type of cookware you are using can affect cooking time. When
using a new recipe, use the minimum cooking time and check the food
occasionally to prevent overcooking.
• Foods with a non-porous skin such as potatoes or hot dogs, should be pierced to
prevent bursting.
• Frying with heating oil or fat is not recommended. Fat and oil can suddenly boil
over and cause severe burns.
• Some ingredients heat faster than others. For example a jelly doughnut will be
hotter than the dough. Keep this in mind to avoid burns.
• Home canning in the microwave oven is not recommended because all harmful
bacteria may not be destroyed by the microwave heating process.
• Although microwaves do not heat the cookware, the heat from the food is often
transferred to the cookware. Always use pot holders when removing food from the
microwave and instruct children to do the same.
• Making candy in the microwave is not recommended as candy can be heated to
very high temperatures. Keep this in mind to avoid injury.
Guide for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the shell; they
can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
Guide for Cooking Vegetables in Your Microwave
• Vegetables should be washed just before cooking. Often, no extra water is
needed. If dense vegetables such as potatoes, carrots and green beans are being
cooked, add about ¼ cup of water.
• Small vegetables (sliced carrots, peas, lima beans, etc.) can be cooked faster than
larger ones.
• Whole vegetables, such as potatoes, acorn squash or corn on the cob, should be
arranged in a circle on the turntable before cooking. They will be cooked more
evenly if turned over after half the cooking time.
• Always place vegetables like asparagus and broccoli with the stem ends pointing
towards the edge of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the dish with a lid or vented
microwavable plastic wrap.
• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc., should
have their skin pricked in several spots before cooking to prevent them from
bursting.
• For more even cooking, stir or rearrange whole vegetables halfway through the
cooking time.
• Generally, the denser the food, the longer the standing time. (Standing time refers
to the time necessary for dense, large foods and vegetables to finish cooking after
they come out of the oven.) A baked potato can stand on the counter for five
minutes before cooking is completed, while a dish of peas can be served
immediately.
21
Appendix
Troubleshooting Guide
Before you call a repair person for your oven, check this list of possible problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make sure the wall switch is turned on.
• Remove the plug from the outlet, wait ten seconds, then plug it in again.
• Reset the circuit breaker or replace any blown fuse.
• Plug another appliance into the outlet; if the other appliance doesn’t work, have a
qualified electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t come
on.
• Make sure the door is closed securely.
• Check to see if packing material or other material is stuck to the door seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking instructions.
The power goes off before the set time has elapsed.
• If there has not been a power outage, remove the plug from the outlet, wait ten
seconds, then plug it in again. If there was a power outage, the time indicator will
display “
ENJOY YOUR COOKING - - - PRESS SETTINGS BUTTON
FOR PERSONAL OPTIONS
Reset the clock and any cooking instructions.
• Reset the circuit breaker or replace any blown fuse.
The food is cooked too slowly.
• Make sure the oven is on its own 20 amp circuit line. Operating another appliance
on the same circuit can cause a voltage drop. If necessary, move the oven to its
own circuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or metal ties. If using foil, use only
narrow strips and allow at least one inch between the foil and interior oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are positioned correctly.
Using your microwave causes TV or radio interference.
• This is similar to the interference caused by other small appliances, such as hair
dryers. Move your microwave further away from other appliances, like your TV or
radio.
”
Care and Cleaning
Follow these instructions to clean and care for your oven.
• Keep the inside of the oven clean. Food particles and spilled liquids can stick to the
oven walls, causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth and mild soap. Do not use harsh
detergents or abrasives.
• To help loosen baked on food particles or liquids, heat two cups of water (add the
juice of one lemon if you desire to keep the oven fresh) in a four-cup measuring
glass at
High
or two minutes.
• Remove the glass tray from the oven when cleaning the oven or tray. To prevent
the tray from breaking, handle it carefully and do not put it in water immediately
after cooking. Wash the tray carefully in warm sudsy water or in the dishwasher.
• Clean the outside surface of the oven with soap and a damp cloth. Dry with a soft
cloth. To prevent damage to the operating parts of the oven, don’t let water seep
into the openings.
• Wash the door window with very mild soap and water. Be sure to use a soft cloth
to avoid scratching.
• If steam accumulates inside or outside the oven door, wipe with a soft cloth.
Steam can accumulate when operating the oven in high humidity and in no way
indicates microwave leakage.
• Never operate the oven without food in it; this can damage the magnetron tube or
glass tray. You may wish to leave a cup of water in the oven when it is not in use to
prevent damage if the oven is accidentally turned on.
power for five minutes or until boiling. Let stand in the oven for one
22
Appendix
How to Clean the Outside
Do not use cleaners containing ammonia or alcohol on the microwave oven.
Ammonia or alcohol can damage the appearance of the microwave.
Case
Clean the outside of the microwave with a sudsy cloth. Rinse and then dry.
Wipe the window with a damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly. Do not use cleaning sprays, large
amounts of soap and water, abrasives or sharp objects on the panel—they
can damage it. Some paper towels can also scratch the control panel.
Door Surface
It’s important to keep the area clean where the door seals against the microwave. Use only mild, nonabrasive detergents applied with a clean sponge or
soft cloth. Rinse well.
Bottom
Clean off the grease and dust on the bottom often.
Use a solution of warm water and detergent.
Light Bulb Replacement
Cooktop Light
Replace the burned-out bulb with a halogen lamp(120V, 20W).
1. To replace the bulb(s), first disconnect the power at the main fuse or
circuit breaker panel or pull the plug.
2. Remove the screw at the front of the light cover and lower the cover.
3. Be sure the bulb(s) to be replaced are cool before removing. After
breaking the adhesive seal, remove the bulb by gently turning. Put in
new bulb.
4. Replace the light cover and screw. Connect electrical power to the
oven.
Oven Light
Replace the burned-out bulb with a halogen lamp(120V, 20W).
1. To replace the oven light, first disconnect the power at the main fuse
or circuit breaker panel or pull the plug.
2. Remove the top grille by taking out the 2 screws(on the front of outer
case. See page 24 for the Removing Charcoal Filter) that hold it in
place.
3. Next, press the snap located above the door near the center of the
oven.
4. Replace the halogen lamp(120V, 20W).
5. Replace the top grille and 2 screws, Connect electrical power to the
oven.
23
Appendix
Exhaust Feature
The Vent Fan
The exhaust fan has 2 metal reusable grease filters.
A charcoal filter can be used for removing smoke and odors in case the fan is
not vented outside.
Reusable Grease Filters
The metal filters trap grease released by foods on the cooktop. They also prevent flames from foods on the cooktop from damaging the inside of the microwave.
For this reason, the filters must ALWAYS be in place when the vent fan is
used. The grease filters should be cleaned once a month, or as needed.
Removing and Cleaning the Filters
To remove, slide it to the left using the tab. Pull it down and out.
To clean the grease filters, soak and then swish them around in hot water
and detergent.
Don’t use ammonia or ammonia products because they will darken the metal.
Light brushing can be used to remove embedded dirt.
Rinse, shake and let them dry before replacing.
To replace, slide the filters in the frame slot on the left of the opening. Pull up
and to the right to lock into place.
Charcoal Filter
The charcoal filter cannot be cleaned. It must be replaced.
If the oven is installed on the wall(or cabinet) and not vented to the outside,
the air will be recirculated through a disposable charcoal filter that helps
remove smoke and odors.
The charcoal filter should be replaced when it is noticeably dirty or discolored
(usually after 6 to 12 months, depending on hood usage).
Removing the Charcoal Filter
To remove the charcoal filter, disconnect power at the main fuse or circuit
breaker panel or pull the plug.
Remove the top grille by removing the 2 screws that hold it in place. Slide the
filter towards the front of the oven and remove it.
Screws
Remove 2 grille screws to remove the grill
24
Appendix
Installing the Charcoal Filter
To install a new filter, remove plastic and other outer wrapping from the new
filter.
Insert the filter into the top opening of the oven as shown. It will rest at an
angle on 2 side support tabs and in front of the right rear tab. Replace the
grille and 2 screws.
If you have a problem you cannot solve,
please call our service line:
1-800-361-3400
Specifications
Model Number SMV7165
Oven Cavity 1.6cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Consumption 1500 Watts
Power Output 950 Watts(IEC 705 TEST)
Heater 1350 Watts
Oven Cavity Dimensions 20
Outside Dimensions 29
Shipping Dimensions 33
Net/Gross Weight 76/86 lbs
7/8
”(W) X 10
7/8
”(W) X 15
3/8
”(W) X 20
9/32
15/16
5/32
”(H) X 14
”(H) X 15
”(H) X 19
5/32
13/32
11/32
”(D)
”(D)
”(D)
25
Warranty
SAMSUNG OVER-THE-RANGE(OTR) MICROWAVE
OVEN
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by Camco
Inc. (CAMCO) and delivered new, in the original carton to the original
consumer purchaser, is warranted by CAMCO against manufacturing
defects in materials and workmanship for a limited warranty period of:
One (1) Year Parts and Labor, Ten (10) Years Parts Warranty for
Magnetron
This limited warranty begins on the original date of purchase, and is
valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for
problem determination and service procedures. Warranty service can
only be performed by a SAMSUNG authorized service center. The
original dated bill of sale must be presented upon request as proof of
purchase to SAMSUNG or SAMSUNG's authorized service center.
SAMSUNG will repair or replace this product, at our option and at no
charge as stipulated herein, with new or reconditioned parts or products
if found to be defective during the limited warranty period specified
above. All replaced parts and products become the property of
SAMSUNG and must be returned to SAMSUNG. Replacement parts
and products assume the remaining original warranty, or ninety (90)
days, whichever is longer.
In-home service will be provided during the warranty labor period subject
to availability within the contiguous United States. In-home service is not
available in all areas. To receive in-home service, the product must be
unobstructed and accessible to service personnel. If during in-home
service repair can not be completed, it may be necessary to remove,
repair and return the product. If in-home service is unavailable,
SAMSUNG may elect, at our option, to provide for transportation of our
choice to and from a SAMSUNG authorized service center. Otherwise,
transportation to and from the SAMSUNG authorized service center is
the responsibility of the purchaser.
This limited warranty covers manufacturing defects in materials and
workmanship encountered in normal, noncommercial use of this product
and shall not apply to the following, including, but not limited to: damage
which occurs in shipment; delivery and installation; applications and
uses for which this product was not intended; altered product or serial
numbers; cosmetic damage or exterior finish; accidents, abuse, neglect,
fire, water, lightning or other acts of nature; use of products, equipment,
systems, utilities, services, parts, supplies, accessories, applications,
installations, repairs, external wiring or connectors not supplied or
authorized by SAMSUNG which damage this product or result in service
problems; incorrect electrical line voltage, fluctuations and surges;
customer adjustments and failure to follow operating instructions,
cleaning, maintenance and environmental instructions that are covered
and prescribed in the instruction book; problems caused by pest
infestations, and overheating or overcooking by user; glass tray or
turntable; reduced magnetron power output related to normal aging.
SAMSUNG does not warrant uninterrupted or error-free operation of the
product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE
LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER
THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO
OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY
PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL
NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE
TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED
BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS
BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF
ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN
THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG
AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE
FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY
FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND
PURCHASER'S PROPERTY AND TO OTHERS AND THEIR
PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO
USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY
BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY
SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND
STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty
lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
To obtain warranty service, please contact Camco
(Canadian exclusive distribution):
1-800-361-3400
www.samsung.ca
26
Note
27
Quick Reference
Feature Operation
Set Clock
One Stage
Cooking
Start / 1 min. +
Cooking
Power/Auto
Defrost
Set Cooking
Time and
Power Levels
1. Press CLOCK.
2. Use number buttons to enter the current time.
3. Press CLOCK again.
1. Use function buttons to set cooking time.
2. Press START.
1. Press the Start / 1 min. + button once for each
minute of cooking.
2. The time will be displayed and the oven will
start.
1. Press POWER/AUTO DEFROST.
2. Enter weight of food by pressing POWER/AUTO
DEFROST button repeatedly or using the
number buttons.
3. Press START.
4. When the oven beeps, turn food over. Press
START to resume defrosting cycle.
1. Use function buttons to set cooking time.
2. To set higher power level, press POWER
LEVEL and use the number buttons to enter the
power level.
3. Press START to begin cooking.
EXCLUSIVE CANADIAN DISTRIBUTOR
CAMCO INC.
5420 NORTH SERVICE ROAD
SUITE 300,
BURLINGTON, ONTARIO
CANADA, L7R 5B6
Samsung Electronics Co., Ltd.
Printed in Malaysia
Loading...
