User Manual
SM-T533
www.samsung.com
About this manual
This device provides high quality mobile communication and entertainment using Samsung’s
high standards and technological expertise. This user manual is specially designed to detail
the device’s functions and features.
•
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Images and screenshots may differ in appearance from the actual product.
•
Content may differ from the final product, or from software provided by service providers
or carriers, and is subject to change without prior notice. For the latest version of the
manual, refer to the Samsung website,
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Applications related to the content may not work
properly depending on the device’s specifications and the environment that it is used in.
•
Available features and additional services may vary by device, software, or service
provider.
•
Applications and their functions may vary by country, region, or hardware specifications.
Samsung is not liable for performance issues caused by applications from any provider
other than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or applications to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
www.samsung.com
.
use of media.
•
Default applications that come with the device are subject to updates and may no longer
be supported without prior notice. If you have questions about an application provided
with the device, contact a Samsung Service Centre. For user-installed applications,
contact service providers.
2
About this manual
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
•
Depending on the region or model, some devices are required to receive approval
from the Federal Communications Commission (FCC). If your device is approved by the
→
FCC, you can view the FCC ID of the device. To view the FCC ID, tap
Settings
→
GENERAL
•
Depending on the region, you can view the regulatory information on the device. To
view the information, tap
information
→
About device
.
.
→
Settings
→
GENERAL
→
About device
→
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Regulatory
Copyright
Copyright © 2015 Samsung Electronics
This guide is protected under international copyright laws.
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or
by any means, electronic or mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written permission of Samsung
Electronics.
3
About this manual
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi CERTIFIED™, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
•
All other trademarks and copyrights are the property of their respective owners.
4
Table of Contents
Getting started
7 Device layout
8 Buttons
9 Package contents
10 Charging the battery
12 Inserting a memory card
14 Turning the device on and off
15 Holding the device
15 Locking and unlocking the device
15 Adjusting the volume
15 Switching to silent mode
Basics
16 Indicator icons
17 Using the touch screen
20 Rotating the screen
20 Palm motions
22 Using Multi Window
37 Transferring files
38 Securing the device
39 Upgrading the device
Communication
40 Contacts
44 Email
45 Gmail
46 Hangouts
47 Google+
47 Photos
Web & network
48 Internet
50 Chrome
51 Bluetooth
52 Screen Mirroring
26 Notifications
27 Home screen
30 Applications screen
31 Using applications
32 Help
32 Entering text
34 Connecting to a Wi-Fi network
36 Setting up accounts
36 Setting up user profiles
Media
53 Music
55 Camera
60 Gallery
64 Video
65 YouTube
5
Table of Contents
Application & media stores
66 Play Store
67 Galaxy Apps
67 Play Books
68 Play Movies & TV
68 Play Music
68 Play Games
68 Play Newsstand
Utilities
69 Memo
70 S Planner
72 Kids Mode
Settings
84 About Settings
84 CONNECTIONS
87 DEVICE
90 CONTROLS
93 GENERAL
96 Google Settings
Appendix
97 Troubleshooting
102 Removing the battery
73 Dropbox
73 Cloud
74 Drive
75 Hancom Office Viewer
77 Alarm
78 World clock
79 Calculator
79 S Voice
80 Google
80 Voice Search
81 My Files
Travel & local
83 Maps
6
Getting started
Volume button
Memory card slot
Device layout
Power button
Front camera
Touch screen
Recent apps button
Home button
Rear camera
Microphone
Speaker
Back button
GPS antenna
Headset jack
Speaker
Multipurpose jack
7
Getting started
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.
Buttons
Button Function
•
Press and hold to turn the device on or off.
Power
Recent apps
Home
Back
Volume
•
Press and hold for more than 7 seconds to reset the device if
it has fatal errors or hang-ups, or freezes.
•
Press to lock or unlock the device. The device goes into lock
mode when the touch screen turns off.
•
Tap to open the list of recent applications.
•
Tap and hold to access additional options for the current
screen.
•
Press to return to the Home screen.
•
Press and hold to launch Google search.
•
Tap to return to the previous screen.
•
Press to adjust the device volume.
8
Getting started
Package contents
Check the product box for the following items:
•
Device
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Other accessories may not be compatible with your device.
•
Use only Samsung-approved accessories. Malfunctions caused by using
unapproved accessories are not covered by the warranty service.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
9
Getting started
Charging the battery
Use the charger to charge the battery before using it for the first time.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
•
If you use multiple applications at once, network applications, or applications
that need a connection to another device, the battery will drain quickly. To avoid
disconnecting from the network or losing power during a data transfer, always use
these applications after fully charging the battery.
Charging with the charger
Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into
the multipurpose jack.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
10
Getting started
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
•
If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
After fully charging, disconnect the device from the charger. First unplug the charger from the
device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Checking the battery charge status
When you charge the battery while the device is off, the following icons will show the current
battery charge status:
Charging Fully charged
11
Getting started
Reducing the battery consumption
Your device provides options that help you save battery power. By customising these options
and deactivating features in the background, you can use the device longer between charges:
•
When you are not using the device, switch to sleep mode by pressing the Power button.
•
Close unnecessary applications with the task manager.
•
Deactivate the Bluetooth feature.
•
Deactivate the Wi-Fi feature.
•
Deactivate auto-syncing of applications.
•
Decrease the backlight time.
•
Decrease the brightness of the display.
Inserting a memory card
Your device accepts memory cards with maximum capacities of 64 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
SD card
folder.
12
Getting started
Open the cover of the memory card slot.
1
Insert a memory card with the gold-coloured contacts facing downwards.
2
Push the memory card into the slot until it locks in place.
3
Close the cover of the memory card slot.
4
Removing the memory card
Before removing the memory card, first unmount it for safe removal. On the Home screen, tap
→
Settings
Open the cover of the memory card slot.
1
Push the memory card until it disengages from the device, and then pull it out.
2
Close the cover of the memory card slot.
3
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
→
GENERAL
→
Storage
→
Unmount SD card
.
13
Getting started
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap
FORMAT SD CARD
Before formatting the memory card, remember to make backup copies of all
important data stored on the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
→
→
Settings
ERASE EVERYTHING
→
GENERAL
.
→
Storage
→
Format SD card
→
Turning the device on and off
When turning on the device for the first time, follow the on-screen instructions to set up your
device.
Press and hold the Power button for a few seconds to turn on the device.
•
Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
•
Press and hold the Power button and tap
features.
To turn off the device, press and hold the Power button, and then tap
14
Flight mode
to disable the wireless
Power off
.
Getting started
Holding the device
Do not cover the antenna area with your hands or other objects. This may cause connectivity
problems or drain the battery.
Locking and unlocking the device
When not in use, lock the device to prevent unwanted operation. Pressing the Power button
turns off the screen and puts the device into lock mode. The device automatically gets locked
if it is not used for a specified period.
To unlock the device, press the Power button or the Home button when the touch screen is
turned off, tap anywhere on the screen, and then flick your finger in any direction.
Adjusting the volume
Press the Volume button left or right to adjust the sound volume when playing music or
video.
Switching to silent mode
Use one of the following methods:
•
Press and hold the Volume button left until it switches to silent mode.
•
Open the notifications panel at the top of the screen, and then tap
Sound
.
15
Basics
Indicator icons
The icons displayed at the top of the screen provide information about the status of the
device. The icons listed in the table below are most common.
Icon Meaning
Wi-Fi connected
Bluetooth feature activated
GPS activated
Synced with the web
Alarm activated
Mute mode activated
Flight mode activated
Error occurred or caution required
Battery power level
16
Basics
Using the touch screen
Use only fingers to use the touch screen.
•
Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.
•
To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.
Finger gestures
Tapping
To open an application, to select a menu item, to press an on-screen button, or to enter a
character using the on-screen keyboard, tap it with a finger.
17
Basics
Tapping and holding
Tap and hold an item for more than 2 seconds to access available options.
Dragging
To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the
target position.
Double-tapping
Double-tap on a webpage or image to zoom in a part. Double-tap again to return.
18
Basics
Flicking
Flick left or right on the Home screen or the Applications screen to see another panel. Flick up
or down to scroll through a webpage or a list, such as contacts.
Pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
19
Basics
Rotating the screen
Many applications allow display in either portrait or landscape orientation. Rotating the
device causes the display to automatically adjust to fit the new screen orientation.
To prevent the display from rotating automatically, open the notifications panel and deselect
Screen rotation
•
Some applications do not allow screen rotation.
•
Some applications display a different screen depending on the orientation.
.
Palm motions
Use palm motions to control the device by touching the screen.
Before using motions, make sure the palm motion feature is activated. On the Home screen,
tap
the right.
→
Settings
→
CONTROLS
→
Palm motion
, and then drag the
Palm motion
switch to
20
Basics
Sweeping
Sweep your hand across the screen to capture a screenshot. The image is saved in
Screenshots
. It is not possible to capture a screenshot while using some applications.
Covering
Cover the screen with a palm to pause media playback.
Gallery
→
21
Basics
Using Multi Window
Use this feature to run multiple applications on the screen at the same time.
•
Only applications on the Multi Window tray can run.
•
This feature may not be available depending on the region or service provider.
To use Multi Window, on the Home screen, tap
and then drag the
Multi window
switch to the right.
→
Settings
→
DEVICE
→
Multi window
Using a split screen Multi Window
Drag your finger from the right edge of the screen towards the middle of the screen.
1
Alternatively, tap and hold
The Multi Window tray appears at the right side of the screen.
.
Multi Window tray
,
22
Basics
Tap and hold an application icon on the Multi Window tray, and then drag it to the screen.
2
Release the application icon when the screen turns blue.
Tap and hold another application icon on the Multi Window tray, and then drag it to a
3
new location.
23
Basics
Launching Multi window from the list of recent apps
Tap .
1
Tap to launch an application in Multi Window.
2
Select another application to launch in Multi Window.
3
24
Basics
Sharing content between applications
You can easily share content between applications, such as
and dropping them.
Some applications may not support this feature.
1
Launch
Email
and
Internet
in a split screen Multi Window.
Email
and
Internet
, by dragging
Access the Multi
Window options
Tap the circle between the application windows, and then tap .
2
Tap the circle between application windows to access the following options:
•
: Switch locations between Multi Window applications.
•
: Share items, such as images, text, or links, between application windows by
dragging and dropping them.
•
: Maximise the window.
•
: Close the application.
25
Basics
Tap and hold an item in the Internet window and drag it to a location in the Email
3
window.
Notifications
Notification icons appear on the status bar at the top of the screen to report new messages,
calendar events, device status, and more. Drag down from the status bar to open the
notifications panel. Scroll the list to see additional alerts. To close the notifications panel, drag
up the panel.
From the notifications panel, you can view your device’s current settings. Drag down from the
status bar, and then tap
•
Wi-Fi
: Activate or deactivate the Wi-Fi feature.
•
Location
•
Sound
•
Screen rotation
•
Bluetooth
: Activate or deactivate the GPS feature.
: Activate or deactivate silent mode.
: Allow or prevent the interface from rotating when you rotate the device.
: Activate or deactivate the Bluetooth feature.
to use the following options:
26
Basics
•
Multi window
•
Screen Mirroring
•
Sync
: Activate or deactivate auto-syncing of applications.
•
Smart stay
•
Power saving
•
Do not disturb
: Set the device to use Multi Window.
: Activate or deactivate the screen mirroring feature.
: Activate or deactivate the smart stay feature.
: Activate or deactivate power-saving mode.
: Activate or deactivate blocking mode. In blocking mode, the device will
block notifications. To select which notifications will be blocked, tap
→
Sounds and notifications
•
Flight mode
The available options may vary depending on the region or service provider.
To rearrange the options on the notifications panel, open the notifications panel, tap
tap and hold an item, and then drag the item to another location.
: Activate or deactivate flight mode.
→
Do not disturb
.
Settings
→
DEVICE
→ ,
Home screen
The Home screen is the starting point to access all of the device’s features. It displays indicator
icons, widgets, shortcuts to applications, and others.
The Home screen can have multiple panels. To view other panels, scroll left or right.
Rearranging items
Adding an application icon
On the Home screen, tap , tap and hold an application icon, and then drag it into a panel
preview.
27
Basics
Moving an item
Tap and hold an item and drag it to a new location. To move it to another panel, drag it to the
side of the screen.
Removing an item
Tap and hold an item, and drag it to the rubbish bin that appears at the top of the Home
screen. When the rubbish bin turns red, release the item.
Rearranging panels
Adding a new panel
Pinch on the screen and tap .
Moving a panel
Pinch on the screen, tap and hold a panel preview, and then drag it to a new location.
Removing a panel
Pinch on the screen, tap and hold a panel preview, and then drag it to the rubbish bin at the
top of the screen.
28
Basics
Setting wallpaper
Set an image or photo stored in the device as wallpaper for the Home screen.
On the Home screen, tap and hold the empty area, and then tap
1
screen
Scroll left or right and select from images displayed at the bottom of the screen.
2
To select photos taken by the device’s camera or other images, tap
Select an image, resize the frame if necessary, and then set it as wallpaper.
3
.
Wallpapers
From Gallery
→
Home
.
Using widgets
Widgets are small applications that provide convenient functions and information on your
Home screen. To use them, add widgets from the widgets panel to the Home screen.
•
Some widgets connect to web services. Using a web-based widget may result in
additional charges.
•
The widgets available may vary depending on the region or service provider.
On the Home screen, tap and hold the empty area, and then tap
on the widgets panel, and then tap and hold a widget to add it to the Home screen. Put it on
a location you want, resize it by dragging the frame if necessary, and then tap anywhere on
the screen to save the location of the widget.
Widgets
. Scroll left or right
29
Basics
Applications screen
The Applications screen displays icons for all applications, including any new applications
installed.
On the Home screen, tap
To view other panels, scroll left or right.
to open the Applications screen.
Rearranging applications
This feature is available only in the customisable grid view.
Tap
→
Edit
, tap and hold an application, and then drag it to a new location. To move it to
another panel, drag it to the side of the screen.
Organising with folders
Put related applications together in a folder for convenience.
Tap
→
Edit
, tap and hold an application, and then drag it to
name and then tap
to save the arrangement.
Done
. Put applications into the new folder by dragging, and then tap
Create folder
. Enter a folder
Rearranging panels
Pinch on the screen, tap and hold a panel preview, and then drag it to a new location.
Installing applications
Use application stores, such as
Galaxy Apps
, to download and install applications.
Uninstalling applications
Tap →
Uninstall/disable apps
Default applications that come with the device cannot be uninstalled.
, and then select an application to uninstall it.
30
Loading...
