Samsung SM-T530NYKUBNN, SM-T530NZWAXAR User Manual

TABLET
User Manual
Please read this manual before operating your device
and keep it for future reference.
Legal Notices
Legal Notices
Warning: This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG mobile device, including but not limited to, accessories, parts, or software relating there to (the “mobile device”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.
Open Source Software
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:
http://opensource.samsung.com.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.
i
EM_SM-T530NU_UM_ENG_NH2_101514_F1
Legal Notices
SAFE™ (Samsung For Enterprise)
SAFE™: “SAFE™” (Samsung for Enterprise) is a mark for a Samsung device which has been tested against Samsung’s own internal criteria for interoperability with certain third party security­related solutions for MDM and VPN. The testing includes field testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. During the testing, the device is tested with the security solutions to see if the solutions work with the device as described by the third party security solution providers. The testing, for example, includes field testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. For more information about Samsung’s SAFE™ program, please refer to www.samsung.com/us/safe.
Disclaimer of Warranties: EXCEPT AS OTHERWISE PROVIDED IN THEIR STANDARD END USER LICENSE AND WARRANTY, TO THE FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD., SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE “SAMSUNG ENTITIES”) EXPRESSLY DISCLAIM ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, INTEROPERABILITY OR NON­INFRINGEMENT, WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES AND APPLICATIONS TESTED WITH SAFE™ DEVICES. IN NO EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES OR APPLICATIONS TESTED WITH SAFE™ DEVICES. In addition, information technology security protection will be affected by features or functionality associated with, among other things the e-mail platform, master data management, and virtual private network solutions selected by the software provider, solution provider or user. Choice of an e-mail, master data management, and virtual private network solution is at the sole discretion of the software provider, solution provider or user and any associated effect on information technology security protection is solely the responsibility of the software provider, solution provider or user.
For complete statement of limited warranty, please refer to www.samsung.com/us/safe, available on the web and where Samsung smartphones and mobile devices are sold. [091714]
Samsung Telecommunications America (STA), LLC
Headquarters:
1301 E. Lookout Drive Richardson, TX 75082
1-800-SAMSUNG (726-7864) 1-888-987-HELP (4357)
Internet Address:
www.samsung.com
©2014 Samsung Telecommunications America, LLC. Samsung is a registered trademark of SamsungElectronics Co., Ltd.
Do you have questions about your Samsung Mobile Device?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at: www.samsung.com/us/support
The actual available capacity of the internal memory is less than the specified capacity because the operating system and default applications occupy part of the memory. The available capacity may change when you upgrade the device.
Nuance logo are trademarks or registered trademarks of Nuance Communications, Inc., or its affiliates in the United States and/or other countries.
The Bluetooth Design”) , and combination mark (Bluetooth word mark and “B Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.
microSD the SD Card Association.
®
, VSuite™, T9® Text Input, and the Nuance
®
word mark, figure mark (stylized “B
™
and the microSD logo are Trademarks of
ii
Legal Notices
Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail, Google Maps, Google Music, Google Hangouts, Picasa, Play Newsstand, YouTube and other Google marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the WirelessFidelity Alliance, Inc.
Swype and the Swype logos are trademarks of Swype, Inc.
Ascender is a trademark of Ascender Corporation which is registered in the U.S. Patent and Trademark Office and certain other jurisdictions.
Georgia is a trademark of Microsoft Corporation which is registered in the U.S. Patent and Trademark Office and certain other jurisdictions.
Other company and product names mentioned herein may be trademarks of their respective owners.
NOOK
®
, NOOK Apps™, NOOK Book®, NOOK Catalogs™, NOOK Kids®, NOOK Magazine™, NOOK Newspaper®, NOOK Newsstand™, NOOK Profiles™, NOOK Store®, NOOK Video™, NOOK Today™, ArticleView®, LendMe®, PagePerfect™, and the NOOK logos are trademarks of barnesandnoble. com llc or its affiliates. Your use of NOOK is subject to the NOOK Terms of Service located in the Settings section of this device and here: NOOK. com/legal. Contains Reader® Mobile technology by Adobe Systems Incorporated. Adobe®, Reader®, and Reader® Mobile are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Your NOOK includes the Merriam-Webster’s Collegiate
®
Dictionary, Eleventh Edition, with Geographic and Biographic Information. Merriam­Webster and Collegiate are trademarks of Merriam­Webster, Inc. and are used herein pursuant to license. Copyright © 2009-2011 Merriam-Webster, Inc. All rights reserved.
Screen images used with permission of barnesandnoble.com llc. Screen images simulated.
Online Legal Information
The online version of the Health/Safety and Warranty guide for your device can be found at:
www.samsung.com.
iii

Table of Contents

Table of Contents
Getting Started.................................................................1
Front View........................................................................... 2
Back View........................................................................... 3
Assemble Your Device ............................................... 4
Setting Up Your NOOK
Set Up Accounts on Your Device........................ 7
Know Your Device.........................................................8
®
.......................................... 5
Home Screen....................................................................9
Status Bar.........................................................................12
Navigation, Motions, and Gestures ..................13
Notification Panel.........................................................14
Multi Window ..................................................................15
Entering Text ...................................................................17
NOOK ...................................................................................... 18
NOOK Features on the Home Screen............19
Your NOOK ......................................................................21
NOOK Reader................................................................22
NOOK Shop and the NOOK Store
NOOK Apps ....................................................................30
NOOK Library.................................................................31
NOOK Video
NOOK Profiles ...............................................................35
NOOK Settings..............................................................39
NOOK Search ................................................................41
Sideloading Files..........................................................42
Dictionaries......................................................................43
NOOK Legal Information.........................................44
Applications ...................................................................... 45
Apps Screen ...................................................................46
Google Applications ..................................................48
Other Applications ......................................................50
®
...............28
TM
..............................................................33
Calculator..........................................................................51
Calendar............................................................................52
Camera and Video......................................................53
Contacts.............................................................................55
Email ....................................................................................59
GALAXY Apps...............................................................60
Gallery.................................................................................61
Internet................................................................................63
Memo ..................................................................................65
Music Player....................................................................66
My Files..............................................................................67
S Voice ...............................................................................68
Video Player....................................................................69
WatchON...........................................................................70
World Clock.....................................................................71
Settings.................................................................................. 72
How to Use Settings ..................................................73
Wi-Fi and Wi-Fi Direct................................................ 74
Bluetooth...........................................................................76
Airplane Mode ...............................................................78
Data Usage......................................................................79
Location Services ........................................................80
More Networks..............................................................81
Nearby Devices.............................................................82
Screen Mirroring ...........................................................83
Sound Settings..............................................................84
Display Settings ............................................................86
Multi Window Settings ..............................................87
Lock Screen ....................................................................88
Wallpaper Settings......................................................89
Font.......................................................................................90
Notification Panel.........................................................91
iv
Table of Contents
Accessibility.....................................................................92
Blocking Mode ..............................................................94
Language and Input Settings...............................95
Palm Motion ....................................................................97
Smart Screen..................................................................98
Accounts............................................................................99
Cloud ................................................................................ 100
Backup and Reset.................................................... 101
Date and Time Settings ........................................ 102
Accessories.................................................................. 103
Application Manager............................................... 104
Default Applications ................................................ 106
Users................................................................................. 107
Battery.............................................................................. 108
Power Saving Mode................................................ 109
Storage............................................................................ 110
Security............................................................................ 112
About Your Device ................................................... 114
v
Welcome
Welcome
Welcome to the best of both worlds. The Samsung Galaxy Tab
®
4 NOOK® 10.1 integrates NOOK’s award­winning reading experience and Barnes&Noble’s enormous selection of content with Samsung’s leading edge technology, allowing you to connect to the world when you need and escape from it when you want.
And with the fully integrated NOOK
®
experience, browsing,
Contact Us
If you have questions about your NOOK that this guide doesn’t answer, be sure to visit the NOOK online support center at:
NOOK.com/support
The online support center offers additional information about your NOOK, including:
A PDF version of this guide that you can download
•
to your computer
Tutorial videos
•
Frequently Asked Questions
•
Chat with a NOOK Expert
•
You can also contact Barnes & Noble Customer Support by sending email to:
nook@barnesandnoble.com
purchasing, and enjoying your content has never been easier. Enjoy your new device, and please visit your neighborhood Barnes&Noble store where our booksellers are always ready
tohelp.
Stay in Touch
Follow us on Facebook and Twitter to receive daily reviews, exclusive offers, and free NOOK Books®.
https://www.facebook.com/nook
https://www.twitter.com/nookbn

Getting Started

Learn about your mobile device hardware, assembly procedures, and how to get started using your new device.
Getting Started

Front View

Volume microSD cardslot
Power/Lock button
Front camera
Recent apps Home
Back: Tap to return to the previous screen, or to
•
close a dialog box, menu, or keyboard.
Front camera: Take self-portraits and record
•
videos of yourself.
Home button: Press to return to the Home screen.
•
microSD slot: Install an optional memory card
•
(not included) for storage of files.
Recent apps: Tap to display recent apps or touch
•
and hold for home screen options.
button
Back
Power/Lock button: Press and hold to turn the
•
device on or off. Press to lock or wake up the screen. Press and hold to turn the device off or restart it, or for quick access to Airplane Mode, Emergency Mode, and to Mute, Vibrate, and Sound modes.
Volume: Press to adjust the volume of your
•
device’s sounds and audio.
2
Front View
Getting Started

Back View

Rear camera
Infrared transmitter
Headset jack
Speaker
Microphone USB charger/Accessory port
Headset jack: Connect an optional headset
•
(notincluded).
Speaker
Microphone: Records audio and detects voice
•
commands.
Rear camera: Take pictures and record videos.
•
Infrared transmitter: Controls external devices
•
using infrared light.
Speaker: Plays music, and other sounds.
•
3
USB charger/Accessory port: Connect the
•
Charger/USB cable (included), and other optional accessories (not included).
Back View
Getting Started

Assemble Your Device

Prior to use, install an optional memory card (not included), and charge the battery.
Install an Optional Memory Card
You can install an optional microSD or microSDHC memory card (not included) to expand available memory space.
Note: A memory card can be installed at any time; it is not necessary to install it prior to using the device.
For more information on installing a memory card, see Install a Memory Card.
Charge the Battery
Your device is powered by a rechargeable, standard Li-Ion battery. A Wall/USB Charger (charging head and USB cable) is included with the device for charging the battery from any standard outlet.
The battery comes partially charged. A fully discharged battery requires up to four hours of charge time. You can use the device while charging.
Caution: Use only Samsung-approved charging devices and batteries. Samsung accessories are designed to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.
To charge the battery:
1. Insert the USB cable into the port.
2. Connect the USB cable to the charging head, and then plug the charging head into a standard outlet.
3. When charging is complete, unplug the charging head from the outlet and remove the USB cable from the device.
Caution: Failure to unplug the wall charger before you remove the battery, can cause damage to the device.
When to Charge the Battery
When the battery is weak and only a few minutes of operation remain, the battery icon ( ) blinks and the device sounds a warning tone at regular intervals.
In this condition, your device conserves its remaining battery power by dimming the screen.
When the battery level becomes too low, the device automatically turns off.
► For a quick check of your battery level, view the
battery charge indicator located in the upper­right corner of your device’s display. A solid color (
) indicates a full charge.
4
You can also choose to display a percentage value. Viewing a percentage value can provide a better idea of the remaining charge on the battery. For more information, see Battery.
Assemble Your Device
Getting Started
The set-up process for your Samsung Galaxy Tab 4 NOOK guides you through setting up four types of accounts:
A Google/Gmail account for accessing Google
•
Play and the Google App Store.
®
Setting Up Your NOOK
6. Read the End User License Agreement (EULA) for Software. If you agree to the EULA, touch the check box I understand and agree to the terms and conditions above. (If you do not agree to the EULA, you will not be able to use your NOOK.)
A Samsung account for using buying and using
•
Samsung apps.
A Dropbox account for storing and syncing files
•
such as videos and photos.
A NOOK account with up to 6 NOOK profiles for
•
accessing the NOOK Store and NOOK content such as NOOK Books, the NOOK Newsstand, and NOOK apps. Each NOOK profile requires a Google account on your tablet.
Note: You will need to connect to a Wi-Fi network to set up your NOOK.
When you first turn on your NOOK, it displays a Samsung Galaxy welcome screen.
1. Touch Start.
Your NOOK displays a list of the Wi-Fi networks it detects in your area.
2. Touch the name of the Wi-Fi network to which you want to connect. If the network displays a lock symbol, you will be prompted to enter a password to connect to the network. If you do not know the password, ask the network administrator. Once you have entered the password in the password dialog box, touch Connect.
3. Once your NOOK connects to the network, touchNext.
4. Set the date, time, and time zone for your NOOK. Touch any of these items to call up a dialog box for making changes.
7. The EULA screen also offers you a chance to share diagnostic data with Samsung. Touch Yes or No to indicate your decision.
8. Touch Next.
Your NOOK prompts you to sign in to your Google account or to create a Google account if you do not have one. You will need a Google account to access Google Play and other Google apps on your device.
9. If you want to make use of Google apps, either create a Google account or sign in to your existing Google account. (If you have previously set up two-factor authentication for your Google account, you will be prompted to launch a Web browser and enter a verification code to finish logging in.) Your Google account then displays fields for personalizing your tablet.
10.Enter your first name and last name. Touch Done.
11. Your NOOK prompts you to set up a Samsung account for accessing Samsung Galaxy apps. You can sign in, create a new account, or sign in with your Google ID. Touch the button with your choice. To skip setting up or signing in with a Samsung account, touch Skip.
12.Next your NOOK displays an account creation or sign-in page for Dropbox. Your NOOK includes a 50 GB Dropbox account for two years. Dropbox can automatically save your pictures and videos to the web and any computers you link your Dropbox account to. Touch the button to create or sign in or, to skip this step, touch Skip.
5. Touch Next.
5
Setting Up Your NOOK
®
Getting Started
13.Next your device displays a full-screen welcome page for NOOK. (Until you have set up a NOOK account, your NOOK will display this same welcome page whenever you launch any NOOK app such as the NOOK Library.)
Follow the steps below to set up your NOOK account.
4. Add credit card information for your account. Enter:
The first name on the credit card account.
•
The last name on the credit card account.
•
5. Touch the pop-up menu to select the card type. Choose from:
Visa
•
Registering an Existing NOOK Account
If you already have a Barnes & Noble or NOOK account, touch Sign In.
1. On the Sign In screen, enter the email address and password for your account.
2. Touch Sign In.
Creating a New NOOK Account
If you do not already have a Barnes & Noble or NOOK account, touch Create Account.
1. On the screen for creating your account, enter:
Your first name
•
Your last name
•
The email address you want to use for your
•
NOOK account
A password
•
A security question
•
MasterCard
•
Amex
•
Discover
•
DinersClub
•
JCB
•
6. Touch pop-up menus to select the expiration date for the credit card.
7. Touch Next.
8. Enter the billing address for the credit card. Enter:
Street address
•
City
•
State
•
ZIP Code
•
Country (either the United States or Canada)
•
9. Touch Submit.
Your NOOK enters this information and creates your account.
2. Touch Submit. Your NOOK opens a dialog box
3. If you have read the legal notices and accept
Note: If you do not accept the legal terms, you will not be able to use your NOOK.
Note: Next you will set up a credit card for your account. You have the option of skipping this step, but you will not be able to make any purchases in the NOOK Shop until a credit card has been added to your account.
with links to legal notices, including the NOOK Device Terms of Service, the NOOK Store Terms of Service, and the NOOK Privacy Policy. To ready any of these notices, touch its link.
them, touch Accept.
Note that you will need to create device accounts for each user assigned a profile on your NOOK. For example, if Julie owns a NOOK and creates an adult profile for her husband Mike and a child account for her daughter Sarah, both Mike and Sarah will need user accounts on the NOOK, in addition to their NOOK profiles.
Note: Your NOOK has 16 GB of internal storage to hold all its apps and NOOK Store content. You can extend this storage by adding SDHC/SHD SD Card with up to an additional 64 GB. See the section on inserting an SD Card for details.
6
Setting Up Your NOOK
®
Getting Started

Set Up Accounts on Your Device

NOOK Account
Use your existing NOOK account or create a new one to make the best use of the NOOK features on your device. See NOOK for more information about the NOOK features.
Google Account
Your new device uses your Google Account to fully utilize its Android features, including Gmail, GoogleHangouts, and the Google Play Store.
When you turn on your device for the first time, set up your existing Google Account, or create a new GoogleAccount.
– or –
To create a new Google Account or set up your Google Account on your device at any time, use Accounts settings. Formore information, see
Accounts.
Samsung Account
Create a Samsung account, for access to Samsung content and apps on your device.
When you turn on your device for the first time, set up your existing Samsung account, or create a new Samsung account.
– or –
To create a new Samsung account or set up your Samsung account on your device at any time, use Accounts settings. Formore information, see
Accounts.
► From a Home screen, tap Apps >
Settings> Accounts > Add account >
Samsungaccount.
► From a Home screen, tap Apps >
Settings> Accounts > Add account >
Google.
7
Set Up Accounts on Your Device

Know Your Device

Learn some of the key features of your mobile device, including the screens and icons, as well as how to navigate the device and enter text using the keyboard.
Warning: Please note that a touch screen responds best to a light touch from the pad of your finger or a non-metallic stylus. Using excessive force or a metallic object when pressing on the touch screen may damage the tempered glass surface and void the warranty.
Know Your Device

Home Screen

NOOK Widgets
Status Icons Notification Icons Status Bar
Recent Reading Home Screen Indicator App Apps
Apps Screen: Provides quick access to all of your
•
applications.
App Shortcuts: Shortcuts to your favorite
•
applications.
Home Screen Indicator: Indicates which
•
Homescreen is presently displayed.
NOOK Widgets: Self-contained applications that
•
run on the Home screen (not shortcuts) .
Shortcuts Screen
Notification Icons: Display new email messages,
•
notifications, available software updates, and so on.
Recent Reading: Shortcut to the NOOK reader,
•
which opens to the last material you were reading.
Status Bar: Displays device status icons (right)
•
and notification icons (left).
Status Icons: Display information about the
•
device, such as the network signal strength, battery level, the time, and so on.
9
Home Screen
Know Your Device
The Home screen is the starting
App Shortcuts
point for using your device.
Customize your Home screen by adding application shortcuts, widgets, folders, andusing wallpapers.
Manage Home Screens
Your device comes with multiple Home screens to hold apps and widgets. You can rearrange the Home screens in a different order.
1. From a Home screen, pinch the screen.
– or –
Touch and hold an empty space on the screen.
2. Use these options to manage screens:
Add a screen: Scroll to the end of the
•
screens, and then tap Add.
Remove a screen: Touch and hold on a
•
screen, and then drag it to the Remove.
Set a screen as the main Home screen:
•
Tap Main Home screen at the top of a screen. This screen displays when you press
the Home Key.
Change the order of screens: Touch and
•
hold on a screen, and then drag to a new position.
You can use app shortcuts to launch an app from any Home screen.
Add a Shortcut to a Home Screen
1. From a Home screen, tap Apps.
2. Touch and hold an app shortcut, drag it to a Home screen and release it.
Remove a Shortcut
1. Touch and hold a shortcut to releaseit.
2. Drag the icon to
Note: Removing a shortcut does not delete the app, it just removes the shortcut from the Home screen.
Remove and release it.
Widgets
Widgets are self-contained apps that run on a Homescreen. There are all kinds of widgets, including links to a specific contact, Internet bookmarks, Gmail and email accounts, and manyothers.
Add a Widget to the Home Screen
1. Touch and hold an empty space on the screen, and then tap Widgets.
2. Touch and hold a widget, drag it to a Homescreen and release it.
Remove a Widget
•
Touch Home screen settings for options:
Transition effect: Change the visual effect
-
used when you move between Home screens.
Flipboard Briefing: Display all Flipboard
-
Briefing updates on the Home screen.
1. From a Home screen, touch and hold a widget to releaseit.
2. Drag the widget to the Remove icon and releaseit.
Note: Removing a widget does not delete the widget, it just removes the widget from the Home screen.
10
Home Screen
Know Your Device
Folders
Change the Wallpaper
Place folders on the Home screen to organize items.
Adding Folders
1. From a Home screen, touch and hold an app shortcut.
2. Drag the shortcut onto Create folder and release.
Enter a folder name.
•
Tap Add to place additional apps in the
•
folder.
Tap Done on the keyboard.
•
A folder will be created with the shortcut(s) inside.
Using Folders
1. Tap the folder to open it and access the shortcuts inside.
2. To add shortcuts to the folder, touch and hold the shortcut, and then drag it onto the folder and release.
Change the look of the Home and Lock screens with wallpaper. You can display a favorite picture, or choose from preloaded wallpapers.
1. From a Home screen, pinch the screen.
– or –
Touch and hold an empty space on the screen.
2. Tap Wallpapers, and then choose Home screen, Lock screen, or Home and lock screens.
3. Tap a wallpaper to see a sample, and then tap Set wallpaper.
Tap More images to select an image from the
•
Gallery, Google Photos, or other location (if available).
Tap Bubbles or Phase beam for animated
•
wallpaper. Animated wallpaper consumes additional battery power.
Tap Travel wallpaper to see recommended
•
travel destinations (Lock screen only).
3. To delete a folder, touch and hold the folder until it detaches, and then drag it to release.
Remove and
11
Home Screen
Know Your Device

Status Bar

The Status Bar at the top of the Home screen provides device information (such as network status, battery charge, and time) on the right side and notification alerts on the left.
Status Icons
Battery is fully charged.
Battery is low.
Battery is charging.
Mute mode is enabled.
Wi-Fi is active.
Notification Icons
New email has arrived
New Gmail has arrived.
Download of a file or app is in progress.
File is being uploaded or sent.
Location service (GPS) is active.
App updates are available from the Google Play Store.
App updates are complete.
Keyboard is in use.
Connected to a computer using a USBcable.
When NOOK updates are available, a NOOK icon appears in the Status Bar.
12
Status Bar
Know Your Device

Navigation, Motions, and Gestures

Touchscreen Navigation
Tap
Lightly tap items to select or launch them.
Tap the on screen keyboard to enter characters
•
ortext.
Tap an item to select it.
•
Tap an app icon to launch the application.
•
Touch and Hold
Activate onscreen items by a touch and hold gesture.
Touch and hold a widget on the Home screen to
•
move it.
Touch and hold a field to display a pop-up menu
•
of options.
Drag
To drag, touch and hold on an item, and then move it to a new location.
Drag an app shortcut to add it to a Home screen.
•
Drag a widget to a place it in a new location on a
•
Homescreen.
Pinch and Spread
Pinch the screen using your thumb and forefinger or spread by moving your fingers apart.
Pinch or spread the screen to zoom in or out while
•
viewing a picture or a webpage.
Pinch or spread the screen to zoom in or out while
•
taking a picture.
Motion Control
Swipe or Slide
To swipe, lightly drag your finger vertically or horizontally across the screen.
Swipe the screen to unlock the device.
•
Swipe the screen to scroll through the
•
Homescreens or menu options.
Control your device by making specific gestures with your hand above the device’s screen.
Enable Motion Control
1. From a Home screen, tap Apps > Settings > Controls tab > Palm motion.
2. Touch ON/OFF to enable Motion Control.
For more details, see Palm Motion.
13
Navigation, Motions, and Gestures
Know Your Device
Notification Panel
Quick settings
Settings
View additional Quick settings
Adjust screen
brightness
Tap a notification
to launch its app
or view it
Notification icons display on the Status Bar displaying calendar events, device status, and more. For details about these notifications, open the Notification Panel.
Volume
Clear all notifications
Quick Settings
In addition to notifications, the Notification Panel also provides quick access to device functions such as Wi-Fi, allowing you to quickly turn them on or off.
► To view additional Quick settings, tap
Viewall.
Notification Panel Settings
View the Notification Panel
1. Swipe down on the Status Bar to display the Notification Panel.
2. Scroll down the list to see notification details.
•
•
3. To close the Notification Panel, swipe upward from the bottom of the screen or press the
Tap an item to open it.
To clear a single notification, drag the notification left or right. Tap Clear all to clear all notifications.
Backkey.
To customize the Notification Panel, see
Notification Panel.
14
Notification Panel
Know Your Device

Multi Window

Multi Window Tray
Window Controls Tray Controls
Multitask by using multiple applications at the same time.
Activate Multi Window
1. From a Home screen, tap Apps > Settings > Device tab > Multiwindow.
2. Tap ON/OFF to activate.
Tap Open in multi window view to
•
automatically view content in Multi window when you open files from My Files or Video player, or attachments from email.
Tip: You can also activate Multi window from the Notification Tray. For more information, see
Notification Panel.
Using Multi Window
After enabling Multi Window, you can use it to run multiple apps at the same time.
Note: Multi Window view is not available for all apps. NOOK apps do not currently support Multi Window.
The apps display together on a split screen. You can switch between the apps, adjust the size of their display on the screen, and copy information from one app to the other.
1. Swipe from the right edge of the screen toward the center to display the Multi window tray. (After a few seconds, the tray will be hidden again.)
2. Touch and drag apps off of the tray and release.
15
Multi Window
Know Your Device
Window Controls
Select an application window and tap Border
button in the middle of the window border.
Control Buttons
Switch locations between Multi window applications.
Change the Order of Apps in the MultiWindow Tray
1. Swipe the right edge of the screen toward the center to display the Multi window tray.
2. Tap an hold an app, drag it to a new position in the tray and then drop it.
Share items between the application windows. Drag an item to share from one window to another. Some applications may not support this feature.
Maximize the application.
Close the application.
Customize Multi Window
You can customize Multi window to suit your preferences.
Create a Window Group
If you use certain apps together in Multi window often, you can create a window group to quickly display the two apps in Multi window.
The window group will be stored in the Multi window tray, so you can choose it any time to display the two apps.
Choose Apps to Display in the MultiWindow Tray
You can choose the apps you want to display in the Multi window tray.
1. Swipe the right edge of the screen toward the center to display the Multi window tray.
2. Tap
•
•
•
Tray Controls > Edit for options:
To remove an app from the tray, tap and drag it off of the tray and place it in the storage area.
To add an app to the tray, tap and drag it from the storage area to the tray.
To relocate an app, tap and drag it to a new location.
Multi Window Settings
To customize Multi Window, see
Multi Window Settings.
1. Swipe the right edge of the screen toward the center to display the Multi window tray.
2. Tap
Tray Controls > Create.
16
Multi Window
Know Your Device

Entering Tex t

Using the SamsungKeyboard
Type your text input using a QWERTY keyboard.
Predictive Text
Options key
Special Keys
Touch and hold for quick access to cut(x), copy (c), paste (v), undo (z), redo(y), and select all (a).
Tap to insert numbers and symbols.
Predictive Text
Predictive text suggest words matching your text entries, and, optionally, completes common words automatically. Predictive text can learn your personal writing style from your contacts, messages, email, and social networking sites — improving its accuracy of predicting your text entries.
Configure the Samsung Keyboard
To customize the Samsung Keyboard, see
Samsung Keyboard Settings.
Using Google Voice Typing
Instead of typing, speak your text input.
Touch and hold the Options key to:
Use Google Voice Typing.
Use your handwriting to enter text.
Access the clipboard.
Access keyboard settings.
Insert emoticons.
Change the layout of the keyboard.
1. On the Samsung Keyboard, tap Google Voice Typing.
2. Speak your text.
Configure Google Voice Typing
To customize Google Voice Typing, see
Google Voice Typing Settings.
17
Entering Text

NOOK

®
The Samsung Galaxy Tab 4 NOOK NOOK’s award-winning reading experience and Barnes&Noble’s enormous selection of content with Samsung’s leading edge technology, allowing you to connect to the world when you need and escape from it when you want.
®
10.1 integrates
And with the fully integrated NOOK browsing, purchasing, and enjoying your content has never been easier. Enjoy your new device, and please visit your neighborhood Barnes&Noble store where our booksellers are always
ready tohelp.
®
experience,
NOOK

NOOK Features on the Home Screen

NOOK Library Widget NOOK Discovery Widget
NOOK App Shortcuts
The Home screen features widgets and apps shortcuts that provide quick and easy access to your NOOK Library and to new NOOK Content.
NOOK Library Widget
This widget displays books, periodicals, or apps from your Library. A scrollable carousel presents the items you have most recently purchased or accessed.
To open a book or periodical, tap its cover.
To see a broader selection of content, tap the More button. Swipe left or right to scroll through a carousel of recently purchased or accessed items.
To open your Library, tap
NOOK Discovery Widget
The NOOK Discovery Widget presents new recommendations and special offers from the NOOKStore.
NOOK Library.
19
NOOK Features on the Home Screen
NOOK
App Shortcuts
The Home screen features shortcuts to these apps:
NOOK Shop: Opens the NOOK Store where you can shop for books, periodicals, and apps.
NOOK Search: Lets you search the NOOK Store and your Library for keywords.
NOOK Today: Presents new recommendations and promotions from the NOOK Store.
NOOK Library: Opens your Library, giving you access to your NOOK Books and any other content you have purchased through the NOOK Store or sideloaded onto your NOOK.
NOOK Settings: Lets you adjust configuration settings for NOOK features on your device.
Open Book Icon
The open-book icon in the lower left-hand corner of the Home screen provides a shortcut to the book or periodical you have been reading most recently.
20
NOOK Features on the Home Screen
NOOK

Your NOOK

The Your NOOK app presents recommendations and special offers from the NOOK Store. Tapthe app to open it.
By default, the Your NOOK app appears in the row of app shortcuts on the Home Screen.
21
Your NOOK
NOOK

NOOK Reader

Opening a Book or Periodical
To open a book or periodical in the Library or the Library widget, tap its cover.
Turning Pages
To turn to the next page, tap the right side of the screen. Or swipe from the right side of the screen.
To turn back to the previous page, tap the left side of the screen. Or swipe from the left side of the screen.
Placing a Bookmark
Tap the upper right hand corner of the screen to bring up the bookmark ribbon . Now tap on the
bookmark ribbon to add a bookmark.
Changing Type Size, Font, Margins, and Other Page Elements
1. Tap the center of the page.
2. Tap
3. Select the type size, font, margins, line spacing, and color theme you want. If the publisher has recommended a page design, you can switch to it by toggling the Publisher Defaults on.
to open the Text Options window.
Searching a Book
1. Tap the center of the page.
2. Tap to open the options menu.
3. Tap Find in Book.
4. Type the word or phrase you want to find.
Viewing a List of Bookmarks
1. Tap the center of the page.
2. Tap to open the Contents window.
3. Tap the Bookmarks tab.
4. To move to a bookmarked page, tap the page in the list of bookmarked pages.
Displaying the Table of Contents
1. Tap the center of the page.
2. Tap to open the Contents window.
3. To move to a chapter or section, tap its name in the Contents.
5. Tap the Search button (a magnifying glass).
6. Tap the right arrow or left arrow to find the next or previous appearance of the word or phrase.
Viewing the Details Page
1. Tap the center of the page.
2. Tap to open the options menu.
3. Tap View Details.
22
NOOK Reader
NOOK
Configuring Reader Settings
1. Tap the center of the page.
2. Tap
3. Tap Settings.
4. On the Settings screen, configure the Reader:
to open the options menu.
Tap the radio button for the Page Turn Effect
•
you want: Curl, Slide or None.
Tap the check box to enable or disable 2-page
•
layouts of PDFs.
Tap the check box to show or hide the Status
•
Bar in books.
Download and select other free dictionaries.
•
(Only one dictionary may be active at a time.)
Using Social Features in a Book
1. Tap the center of the page.
2. Tap
to open the Share menu.
3. Tap View Details. If the book can be lent, it will display a LendMe button.
4. Tap LendMe.
5. Select the contact to whom you would like to lend the book.
Displaying the Status Bar in Books
By default, your NOOK does not display the black Status Bar with the battery and Wi-Fi icons, the clock, and other notifications when you are reading a book.
To display the Status Bar in books, do this:
1. Open the NOOK Settings app.
2. Tap Books.
3. Tap Show status bar, making sure that the check box is selected.
3. Tap any of the following:
Recommend
•
Post Reading Status
•
Rate and Review
•
Like on Facebook
•
Lending a Book to a Contact
Many books can be lent through the NOOK LendMe program. If a book is lendable, you may lend it once. The friend you lend it to has up to 7 days to accept or decline your offer. Once the offer is accepted, your friend has up to 14 days to read the book. While the book is on loan, it is not available to you for reading. After the 14 days, the book is automatically returned to you and becomes available for you to read.
1. Tap the center of the page.
2. Tap to open the options menu.
Changing the Page Turn Effect
Your NOOK offers a choice of three animated effects when you turn a page in a NOOK Book or other EPUB-formatted ebook or magazine. The page can curl as though you were turning a paper page, one page can slide smoothly to the other, or there can be no special effect at all as the one page simply flashes to the next.
To select the Page Turn Effect you want for Books, do this:
1. Open the NOOK Settings app.
2. Tap Books.
3. Tap the Page Curl Effect you want:
Curl
•
Slide
•
None
•
To change this setting for Magazines, open the Magazines screen in NOOK Settings and select the effect you want: Curl or Slide.
23
NOOK Reader
Loading...
+ 91 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
