USER MANUAL
SM-M317F/DS
SM-M317F/DSN
English. 03/2021. Rev.1.0
www.samsung.com
Table of Contents
Basics
5 Read me first
7 Device overheating situations and
solutions
10 Device layout and functions
14 Charging the battery
17 SIM or USIM card (nano-SIM card)
18 Memory card (microSD card)
20 Turning the device on and off
21 Initial setup
22 Fingerprint recognition
24 Face recognition
26 Camera
61 Contacts
63 Messages
65 Internet
66 Gallery
70 Multi window
73 Samsung Notes
73 Samsung Members
74 Galaxy Shop
74 Samsung Global Goals
74 Calendar
75 Reminder
76 Voice Recorder
78 My Files
78 Clock
78 Calculator
Apps and features
40 Introduction
41 Samsung account
42 Transferring data from your previous
device (Smart Switch)
44 Understanding the screen
52 Notification panel
54 Entering text
56 Installing or uninstalling apps
58 Phone
79 Game Launcher
80 Game Booster
81 Smart View
81 Sharing content
83 Google apps
84 Bixby Vision
85 AR Zone
89 Radio
90 Music Share
92 Screen capture
2
Table of Contents
Settings
93 Introduction
94 Samsung account
94 Connections
95 Wi-Fi
97 Bluetooth
98 NFC and contactless payments
(NFC-enabled models)
99 Data saver
99 Mobile data only apps
100 Mobile Hotspot
100 More connection settings
102 Sounds and vibration
102 Sound quality and effects
103 Separate app sound
103 Notifications
112 Advanced features
113 Motions and gestures
114 Dual Messenger
115 Digital Wellbeing and parental
controls
115 Battery and device care
115 Optimising your device
116 Battery
116 Storage
116 Memory
117 Device protection
117 Apps
117 General management
118 Accessibility
119 Software update
119 About phone
104 Display
105 Changing the screen mode or
adjusting the display colour
106 Wallpaper
106 Themes
106 Home screen
107 Lock screen
107 Smart Lock
108 Always On Display
109 Biometrics and security
110 Privacy
110 Location
111 Accounts and backup
111 Samsung Cloud
112 Google
Appendix
121 Troubleshooting
126 Removing the battery
3
Basics
4
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
•
The device may require a connection to a Wi-Fi or mobile network when using some apps
or features.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
5
Basics
•
Depending on the region or service provider, a screen protector is attached for protection
during production and distribution. Damage to the attached screen protector is not
covered by the warranty.
•
You can see the touchscreen clearly even in strong outdoor sunlight by automatically
adjusting the contrast range based on the surrounding environment. Due to the nature
of the product, displaying fixed graphics for extended periods may result in afterimages
(screen burn-in) or ghosting.
–
It is recommended not to use fixed graphics on part or all of the touchscreen for
extended periods and turn off the touchscreen when not using the device.
–
You can set the touchscreen to turn off automatically when you are not using it.
Launch the
of time you want the device to wait before turning off the touchscreen.
–
To set the touchscreen to automatically adjust its brightness based on the
surrounding environment, launch the
Adaptive brightness
•
Depending on the region or model, some devices are required to receive approval from
the Federal Communications Commission (FCC).
If your device is approved by the FCC, you can view the FCC ID of the device. To view the
FCC ID, launch the
device does not have an FCC ID, it means that the device has not been authorised for sale
in the U.S. or its territories and may only be brought to the U.S. for the owner’s personal
use.
•
The use of mobile devices on aeroplanes or ships may be subject to federal and local
guidelines and restrictions. Check with the appropriate authorities and always follow
crew instructions regarding when and how you may use your device.
Settings
app, tap
switch to activate it.
Settings
Display
app and tap
→
Screen timeout
Settings
About phone
app, tap
, and then select the length
Display
→
Status information
, and then tap the
. If your
•
Depending on the region, you can view the regulatory information on the device. To
view the information, launch the
information
•
Your device contains magnets. Keep a safe distance between your device and objects
that may be affected by magnets such as credit cards and implantable medical devices. If
you have an implantable medical device, consult your physician before use.
.
Settings
app and tap
About phone
→
Regulatory
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
6
Basics
Device overheating situations and solutions
When the device heats up while charging the battery
While charging, the device and the charger may become hot. During wireless charging or fast
charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or
performance and is in the device’s normal range of operation. If the battery becomes too hot,
the charging speed may decrease or the charger may stop charging.
Do the following when the device heats up:
•
Disconnect the charger from the device and close any running apps. Wait for the
device to cool down and then begin charging the device again.
•
If the lower part of the device overheats, it could be because the connected USB
cable is damaged. Replace the damaged USB cable with a new Samsung-approved
one.
•
When using a wireless charger, do not place foreign materials, such as metal objects,
magnets, and magnetic stripe cards, between the device and the wireless charger.
The wireless charging or fast charging feature is only available on supported models.
When the device heats up during use
When you use features or apps that require more power or use them for extended periods,
your device may temporarily heat up due to increased battery consumption. Close any
running apps and do not use the device for a while.
The following are examples of situations in which the device may overheat. Depending on
the functions and apps you use, these examples may not apply to your model.
•
During the initial setup after purchase or when restoring data
•
When downloading large files
7
Basics
•
When using apps that require more power or using apps for extended periods
–
When playing high-quality games for extended periods
–
When recording videos for extended periods
–
When streaming videos while using the maximum brightness setting
–
When connecting to a TV
•
While multitasking (or, when running many apps in the background)
–
When using Multi window
–
When updating or installing apps while recording videos
–
When downloading large files during a video call
–
When recording videos while using a navigation app
•
When using large amount of data for syncing with the cloud, email, or other accounts
•
When using a navigation app in a car while the device is placed in direct sunlight
•
When using the mobile hotspot and tethering feature
•
When using the device in areas with weak signals or no reception
•
When charging the battery with a damaged USB cable
•
When the device’s multipurpose jack is damaged or exposed to foreign materials, such as
liquid, dust, metal powder, and pencil lead
•
When you are roaming
Do the following when the device heats up:
•
Keep the device updated with the latest software.
•
Conflicts between running apps may cause the device to heat up. Restart the device.
•
Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.
•
Close apps that increase battery consumption or that run in the background when
not in use.
•
Delete unnecessary files or unused apps.
•
Decrease the screen brightness.
•
If the device overheats or feels hot for a prolonged period, do not use it for a while. If
the device continues to overheat, contact a Samsung Service Centre.
8
Basics
Precautions for device overheating
If you begin to feel uncomfortable due to the device overheating, stop using the device.
When the device heats up, the features and performance may be limited or the device may
turn off to cool down. The feature is only available on supported models.
•
If the device overheats and reaches a certain temperature, a warning message will appear
to prevent device failure, skin irritations and damages, and battery leakage. To lower the
device’s temperature, the screen brightness and the performance speed will be limited
and battery charging will stop. Running apps will be closed and all calling and other
features will be limited, except for emergency calls, until the device cools down.
•
If the second message appears due to a further increase of the device’s temperature, the
device will turn off. Do not use the device until the device’s temperature drops below the
specified level. If the second warning message appears during an emergency call, the call
will not be disconnected by a forced shut down.
Precautions for operating environment
Your device may heat up due to the environment in the following conditions. Use caution to
avoid shortening the battery’s lifespan, damaging the device, or causing a fire.
•
Do not store your device in very cold or very hot temperatures.
•
Do not expose your device to direct sunlight for extended periods.
•
Do not use or store your device for extended periods in very hot areas, such as inside a
car in the summertime.
•
Do not place the device in any areas that may overheat, such as on an electric heating
mat.
•
Do not store your device near or in heaters, microwaves, hot cooking equipment, or high
pressure containers.
•
Do not use a cable whose covering is peeled off or damaged, and do not use any charger
or battery that is damaged or malfunctioning.
9
Basics
Device layout and functions
Package contents
Refer to the quick start guide for package contents.
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible with
other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make sure
they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer to
the Samsung website.
10
Basics
Speaker
Light sensor
Flash
Microphone
Device layout
SIM card / Memory card
tray
Front camera
Touchscreen
Multipurpose jack (USB
Type-C)
Volume key
Side key (Fingerprint
recognition sensor)
GPS antenna
Rear camera
NFC antenna
(NFC-enabled models)
Speaker
Microphone
Main antenna
Main antenna
Earphone jack
11
Basics
•
When using the speakers, such as when playing media files or using speakerphone,
do not place the device close to your ears.
•
Be careful not to expose the camera lens to a strong light source, such as direct
sunlight. If the camera lens is exposed to a strong light source, such as direct sunlight,
the camera image sensor may be damaged. A damaged image sensor is irreparable
and will cause dots or spots in pictures.
•
If you use the device with its glass or acrylic body broken, there may be a risk of
injury. Use the device only after it has been repaired at a Samsung Service Centre.
•
If dust or foreign materials enter the microphone, speaker, or receiver, the device’s
sound may become quiet or certain features may not work. If you attempt to remove
the dust or foreign materials with a sharp object, the device may be damaged and its
appearance may be affected.
•
Connectivity problems and battery drain may occur in the following situations:
–
If you attach metallic stickers on the antenna area of the device
–
If you attach a device cover made with metallic material to the device
–
If you cover the device’s antenna area with your hands or other objects while
using certain features, such as calls or the mobile data connection
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not cover the light sensor area with screen accessories, such as a screen protector,
stickers, or a cover. Doing so may cause the sensor to malfunction.
•
Do not allow water to contact the touchscreen. The touchscreen may malfunction in
humid conditions or when exposed to water.
12
Basics
Hard keys
Key Function
•
Press and hold to turn the device on or off.
•
Side key
Side key +
Press to turn on or lock the screen.
•
Press twice to launch the app or feature you set.
•
Press simultaneously to capture a screenshot.
Volume Down key
•
Press and hold simultaneously to turn off the device.
Setting the Side key
Select an app or feature to launch by pressing the Side key twice.
Launch the
want.
Settings
app, tap
Advanced features
→
Side key
, and then select an option you
Soft buttons
Recents button
When you turn on the screen, the soft buttons will appear at the bottom of the screen. Refer
Back button
Home button
to Navigation bar (soft buttons) for more information.
13
Basics
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved battery, charger, and cable specifically designed for your
device. Incompatible battery, charger, and cable can cause serious injuries or damage to
your device.
•
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
Use only USB Type-C cable supplied with the device. The device may be damaged if
you use Micro USB cable.
To save energy, unplug the charger when not in use. The charger does not have a power
switch, so you must unplug the charger from the electric socket when not in use to
avoid wasting power. The charger should remain close to the electric socket and easily
accessible while charging.
Wired charging
Connect the USB cable to the USB power adaptor and plug the cable into the device’s
multipurpose jack to charge the battery. After fully charging, disconnect the charger from the
device.
14
Basics
Quick charging
Launch the
and then activate the feature you want.
•
Fast charging
Adaptive fast charging.
You can charge the battery more quickly while the device or its screen is turned off.
Settings
: To use the fast charging feature, use a battery charger that supports
app, tap
Battery and device care
→
Battery
→
More battery settings
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•
Optimise the device using the device care feature.
•
When you are not using the device, turn off the screen by pressing the Side key.
•
Activate power saving mode.
•
Close unnecessary apps.
•
Deactivate the Bluetooth feature when not in use.
,
•
Deactivate auto-syncing of apps that need to be synced.
•
Decrease the backlight time.
•
Decrease the screen brightness.
15
Basics
Battery charging tips and precautions
•
If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
•
If you use multiple apps at once, network apps, or apps that need a connection to
another device, the battery will drain quickly. To avoid losing power during a data
transfer, always use these apps after fully charging the battery.
•
Using a power source other than the charger, such as a computer, may result in a slower
charging speed due to a lower electric current.
•
The device can be used while it is charging, but it may take longer to fully charge the
battery.
•
If the device receives an unstable power supply while charging, the touchscreen may not
function. If this happens, unplug the charger from the device.
•
While charging, the device and the charger may heat up. This is normal and should not
affect the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging.
•
If you charge the device while the multipurpose jack is wet, the device may be damaged.
Thoroughly dry the multipurpose jack before charging the device.
•
If the device is not charging properly, take the device and the charger to a Samsung
Service Centre.
16
Basics
21 3 4
SIM or USIM card (nano-SIM card)
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
You can insert two SIM or USIM cards so you can have two phone numbers or service
providers for a single device. In some areas, data transfer speeds may be slower if two SIM
cards are inserted in the device than when one SIM card is inserted.
•
Use only a nano-SIM card.
•
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
Some services that require a network connection may not be available depending on
the service provider.
1 Insert the ejection pin into the hole next to the tray to loosen the tray.
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be
damaged.
2 Pull out the tray gently from the tray slot.
3 Place the SIM or USIM card on the tray with the gold-coloured contacts facing upwards.
4 Gently press the SIM or USIM card into the tray to secure it.
If the card is not fixed firmly into the tray, the SIM card may leave or fall out of the tray.
5 Insert the tray back into the tray slot.
•
If you insert the tray into your device while the tray is wet, your device may be
damaged. Always make sure the tray is dry.
•
Fully insert the tray into the tray slot to prevent liquid from entering your device.
17
Basics
SIM card manager
Launch the
•
SIM cards
•
Preferred SIM card
when two cards are activated.
•
More SIM card settings
Settings
: Activate the SIM card to use and customise the SIM card settings.
app and tap
: Select to use specific SIM cards for some features, such as voice calls,
Connections
: Customise the call settings.
→
SIM card manager
.
Memory card (microSD card)
Installing a memory card
Your device’s memory card capacity may vary from other models and some memory cards
may not be compatible with your device depending on the memory card manufacturer and
type. To view your device’s maximum memory card capacity, refer to the Samsung website.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device will ask to reformat
the card or will not recognise the card. To use the memory card, you must format it. If
your device cannot format or recognise the memory card, contact the memory card
manufacturer or a Samsung Service Centre.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
My Files
→
SD card
folder.
18
Basics
21 3 4
1 Insert the ejection pin into the hole next to the tray to loosen the tray.
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be
damaged.
2 Pull out the tray gently from the tray slot.
When you remove the tray from the device, the mobile data connection will be
disabled.
3 Place a memory card on the tray with the gold-coloured contacts facing upwards.
4 Gently press the memory card into the tray to secure it.
If the card is not fixed firmly into the tray, the memory card may leave or fall out of the
tray.
5 Insert the tray back into the tray slot.
•
If you insert the tray into your device while the tray is wet, your device may be
damaged. Always make sure the tray is dry.
•
Fully insert the tray into the tray slot to prevent liquid from entering your device.
Removing the memory card
Before removing the memory card, first unmount it for safe removal.
Launch the
SD card
Do not remove external storage, such as a memory card or USB storage, while the
Settings
→
Unmount
app and tap
.
Battery and device care
→
Storage
→ →
Advanced
→
device is transferring or accessing information, or right after transferring data. Doing
so can cause data to be corrupted or lost or cause damage to the external storage or
device. Samsung is not responsible for losses, including loss of data, resulting from the
misuse of external storage devices.
19
Basics
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
Launch the
SD card
Before formatting the memory card, remember to make backup copies of all important
data stored in the memory card. The manufacturer’s warranty does not cover loss of
data resulting from user actions.
Settings
→
Format
app and tap
.
Battery and device care
Turning the device on and off
Follow all posted warnings and directions from authorised personnel in areas where the
use of wireless devices is restricted, such as aeroplanes and hospitals.
Volume Down key
→
Storage
→ →
Advanced
→
Side key
Turning the device on
Press and hold the Side key for a few seconds to turn on the device.
Turning the device off
1 To turn off the device, press and hold the Side key. Alternatively, open the notification
panel, swipe downwards, and then tap
2 Tap
Power off
To restart the device, tap
.
Restart
.
.
20
Basics
Forcing restart
If your device is frozen and unresponsive, press and hold the Side key and the Volume Down
key simultaneously for more than 7 seconds to restart it.
Emergency mode
You can switch the device to emergency mode to reduce battery consumption. Some apps
and functions will be restricted. In emergency mode, you can make an emergency call, send
your current location information to others, sound an emergency alarm, and more.
To activate emergency mode, press and hold the Side key, and then tap
Alternatively, open the notification panel, swipe downwards, and then tap
mode
To deactivate emergency mode, tap
.
→
Turn off Emergency mode
The usage time left shows the time remaining before the battery power runs out. Usage
time left may vary depending on your device settings and operating conditions.
Emergency mode
→
Emergency
.
Initial setup
When you turn on your device for the first time or after performing a data reset, follow the
on-screen instructions to set up your device.
If you do not connect to a Wi-Fi network, you may not be able to set up some device
features during the initial setup.
.
21
Basics
Fingerprint recognition
In order for fingerprint recognition to function, your fingerprint information needs to be
registered and stored in your device.
•
This feature may not be available depending on the service provider or model.
•
Fingerprint recognition uses the unique characteristics of each fingerprint to
enhance the security of your device. The likelihood of the fingerprint sensor
confusing two different fingerprints is very low. However, in rare cases where
separate fingerprints are very similar the sensor may recognise them as identical.
•
If you use your fingerprint as a screen lock method, your fingerprint cannot be
used to unlock the screen for the first time after turning on the device. To use the
device, you must unlock the screen using the pattern, PIN, or password you set when
registering the fingerprint. Be careful not to forget your pattern, PIN, or password.
•
If your fingerprint is not recognised, unlock the device using the pattern, PIN,
or password you set when registering the fingerprint, and then re-register your
fingerprints. If your pattern, PIN, or password is forgotten, you will not be able to
use the device if you do not reset it. Samsung is not responsible for any data loss or
inconvenience caused by forgotten unlock codes.
•
If you change the screen lock method to
your biometric data will be deleted. If you want to use your biometric data in apps or
features, you must register your biometric data again.
Swipe
or
None
, which are not secure, all of
For better fingerprint recognition
When you scan your fingerprints on the device, be aware of the following conditions that
may affect the feature’s performance:
•
The device may not recognise fingerprints that are affected by wrinkles or scars.
•
The device may not recognise fingerprints from small or thin fingers.
•
To improve recognition performance, register fingerprints of the hand used most often to
perform tasks on the device.
•
The Side key has a built-in fingerprint recognition sensor. Ensure that the fingerprint
recognition sensor is not scratched or damaged by metal objects, such as coins, keys, and
necklaces.
22
Basics
•
Covering the fingerprint recognition sensor with protective films, stickers, or other
accessories may decrease the fingerprint recognition rate. If the fingerprint recognition
sensor is initially covered with a protective film, remove it before using the fingerprint
recognition sensor.
•
Ensure that the fingerprint recognition sensor and your fingers are clean and dry.
•
If you bend your finger or use a fingertip, the device may not recognise your fingerprints.
Make sure to cover the entire fingerprint recognition sensor with your finger.
•
In dry environments, static electricity can build up in the device. Avoid using this feature
in dry environments or before using the feature, discharge static electricity by touching a
metal object.
Registering fingerprints
1 Launch the
2 Read the on-screen instructions and tap
Settings
app and tap
Biometrics and security
Continue
.
→
Fingerprints
.
3 Set a screen lock method.
4 Place your finger on the Side key. After the device detects your finger, lift it up and place it
on the Side key again.
Repeat this action until the fingerprint is registered.
5 When you are finished registering your fingerprints, tap
You can check whether your fingerprint is registered by tapping
fingerprints
.
23
Done
.
Check added
Basics
Unlocking the screen with your fingerprints
You can unlock the screen with your fingerprint instead of using a pattern, PIN, or password.
1 Launch the
Settings
app and tap
Biometrics and security
→
Fingerprints
.
2 Unlock the screen using the preset screen lock method.
3 Tap the
Fingerprint unlock
switch to activate it.
4 On the locked screen, place your finger on the fingerprint recognition sensor and scan
your fingerprint.
Deleting registered fingerprints
You can delete registered fingerprints.
1 Launch the
2 Unlock the screen using the preset screen lock method.
3 Select a fingerprint to delete and tap
Settings
app and tap
Biometrics and security
Remove
.
→
Fingerprints
.
Face recognition
You can set the device to unlock the screen by recognising your face.
•
If you use your face as a screen lock method, your face cannot be used to unlock
the screen for the first time after turning on the device. To use the device, you must
unlock the screen using the pattern, PIN, or password you set when registering the
face. Be careful not to forget your pattern, PIN, or password.
•
If you change the screen lock method to
your biometric data will be deleted. If you want to use your biometric data in apps or
features, you must register your biometric data again.
Precautions for using face recognition
Before using the face recognition to unlock your device, keep the following precautions in
mind.
•
Your device could be unlocked by someone or something that looks like your image.
•
Face recognition is less secure than Pattern, PIN, or Password.
Swipe
or
None
, which are not secure, all of
24
Basics
For better face recognition
Consider the following when using face recognition:
•
Consider the conditions when registering, such as wearing glasses, hats, masks, beards, or
heavy makeup
•
Ensure that you are in a well-lit area and that the camera lens is clean when registering
•
Ensure your image is not blurry for better match results
Registering your face
For better face registration, register your face indoors and out of direct sunlight.
1 Launch the
2 Read the on-screen instructions and tap
Settings
app and tap
Biometrics and security
Continue
.
→
Face recognition
.
3 Set a screen lock method.
4 Select whether you are wearing glasses or not and tap
Continue
.
5 Position your face inside the frame on the screen.
The camera will scan your face.
•
If unlocking the screen with your face is not working properly, tap
to remove your registered face and register your face again.
•
To enhance the face recognition, tap
appearance.
Add alternative look
and add an alternate
Remove face data
Unlocking the screen with your face
You can unlock the screen with your face instead of using a pattern, PIN, or password.
1 Launch the
Settings
app and tap
Biometrics and security
→
Face recognition
.
2 Unlock the screen using the preset screen lock method.
3 Tap the
Face unlock
switch to activate it.
4 On the locked screen, look at the screen.
When your face is recognised, you can unlock the screen without using any additional
screen lock method. If your face is not recognised, use the preset screen lock method.
25
Basics
Deleting the registered face data
You can delete face data that you have registered.
1 Launch the
Settings
app and tap
Biometrics and security
→
Face recognition
2 Unlock the screen using the preset screen lock method.
3 Tap
Remove face data
Once the registered face is deleted, all the related features will also be deactivated.
→
Remove
.
Camera
Introduction
Take photos and record videos using various modes and settings.
Camera etiquette
•
Do not take photos or record videos of other people without their permission.
•
Do not take photos or record videos where legally prohibited.
.
•
Do not take photos or record videos in places where you may violate other people’s
privacy.
Taking photos
1 Launch the
You can also launch the app by pressing the Side key twice quickly or dragging
left on the locked screen.
•
Some camera features are not available when you launch the
locked screen or when the screen is turned off while the screen lock method is set.
•
The camera automatically shuts off when unused.
•
Some methods may not be available depending on the service provider or model.
2 Tap the image on the preview screen where the camera should focus.
To adjust the brightness of photos, tap the screen. When the adjustment bar appears, drag
the adjustment bar.
Camera
app.
Camera
to the
app from the
26
Basics
cameras.
3 Tap to take a photo.
To change the shooting mode, drag the shooting modes list to the left or right, or swipe to
the left or right on the preview screen.
Camera settings
Zoom
Preview thumbnail
Take a photo.
•
The preview screen may vary depending on the shooting mode and which camera is
Options for current shooting mode
Scene optimiser
Shooting modes list
Switch between the front and rear
being used.
•
When you take photos or videos with a high resolution or a high zoom ratio, the
focus may not be clear if the subject is close. Take photos or videos from a good
distance.
•
If photos you take appear blurry, clean the camera lens and try again.
•
Make sure that the lens is not damaged or contaminated. Otherwise, the device may
not work properly in some modes that require high resolutions.
•
Your device’s camera features a wide-angle lens. Minor distortion may occur in
wide-angle photos or videos and does not indicate device performance problems.
To correct the distortion in photos, tap
advanced options
, and then tap the
Ultra wide shape correction
on the preview screen, tap
Format and
switch to activate
it.
•
The maximum capacity for recording a video may vary depending on the resolution.
•
The camera may fog up or form condensation if the device is exposed to sudden
changes in air temperature, due to the difference in temperature outside and inside
the camera cover. Try to avoid such conditions when planning to use the camera. If
fogging does occur, allow the camera to dry naturally at room temperature before
taking photos or recording videos, otherwise results may look blurry.
27
Basics
Using zoom features
Select / or drag it to the left or right to zoom in or out. Alternatively, spread two fingers
apart on the screen to zoom in, and pinch to zoom out.
•
•
: The Ultra wide camera lets you take wide-angle photos or record wide-angle videos
of things like landscapes.
: The wide-angle camera lets you take basic photos or record normal videos.
Zoom features are available only when using the rear camera.
Using the camera button
•
Tap and hold the camera button to record a video.
•
To take burst shots, swipe the camera button to the edge of the screen and hold it.
•
If you add another camera button, you can move it anywhere on the screen and take
→
photos more conveniently. On the preview screen, tap
Floating Shutter button
the
switch to activate it.
Shooting methods
Options for current shooting mode
On the preview screen, use the following options.
and tap
•
: Activate or deactivate the flash.
•
•
•
•
•
•
•
•
•
: Select the length of the delay before the camera automatically takes a photo.
: Select an aspect ratio and resolution for photos.
: Activate or deactivate the motion photo feature. If you activate the feature, a video
clip will also be taken from a few seconds before tapping the camera button.
: Activate or deactivate the super steady feature to stabilise a video.
: Activate or deactivate the night hyperlapse feature.
: Select a frame rate.
: Select an aspect ratio for videos.
: Select a resolution for videos.
: Apply a filter effect or beauty effects.
28
Basics
•
: Select a metering method. This determines how light values are calculated.
Centre-weighted
exposure of the shot.
calculate the exposure of the shot.
•
: In
FOOD
outside the frame.
•
: In
FOOD
The available options may vary depending on the model or shooting mode.
uses the light in the centre portion of the shot to calculate the
Spot
uses the light in a concentrated centre area of the shot to
Matrix
mode, focus on a subject inside the circular frame and blur the image
mode, adjust the colour tone.
averages the entire scene.
Photo mode
The camera adjusts the shooting options automatically depending on the surroundings to
capture photos easily.
On the shooting modes list, tap
Scene optimiser
and tap to take a photo.
When the camera recognises the subject, the scene optimiser button will change and the
optimised colour and effect will be applied.
If this feature is not activated, tap on the preview screen and tap the
optimiser
switch to activate it.
Scene
29
Basics
Shot suggestions
The camera suggests the ideal composition for the photo by recognising the position and
angle of your subject.
On the preview screen, tap
1 On the shooting modes list, tap
A guide will appear on the preview screen.
and tap the
Shot suggestions
.
switch to activate it.
2 Point the guide at the subject.
The camera recognises the composition, and the recommended composition appears on
the preview screen.
3 Move the device so the guide matches the recommended composition.
When the ideal composition is achieved, the guide will change to yellow.
4 Tap to take a photo.
Ideal composition
Guide
Taking selfies
You can take self-portraits with the front camera.
1 On the preview screen, swipe upwards or downwards, or tap to switch to the front
camera for self-portraits.
2 Face the front camera lens.
To take self-portraits with a wide-angle shot of the landscape or people, tap
3 Tap to take a photo.
.
30
Loading...
