Samsung SM-G900F User Manual

User Manual

SM-G900F

English (EU). 03/2014. Rev.1.0

www.samsung.com

Table of Contents

Read me first

Getting started

8 Device layout

10 Buttons

11 Package contents

12 Installing the SIM or USIM card and

battery

15 Charging the battery

18 Inserting a memory card

20 Turning the device on and off

20 Holding the device

21 Locking and unlocking the device

39 Using the power saving feature

41 Accessing help information

Personalising

42 Switching to easy mode

42 Managing the Home and Apps screens

45 Changing the screen lock method

46 Setting wallpaper

46 Changing ringtones

47 Setting up accounts

47 Moving contacts from other devices to

your device

Basics

22 Using the touch screen

25 Indicator icons

26 Notifications and quick setting panels

30 Home and Apps screens

34 Opening apps

34 Installing or uninstalling apps

36 Entering text

Network connectivity

50 Connecting to a mobile network

50 Connecting to a Wi-Fi network

52 Using Download booster

52 Using Smart network switch

53 Tethering devices and using mobile

hotspots

Motions & usability features

55 Control motions

59 Air view

59 Multi Window

64 Toolbox

2

Table of Contents

65 One-handed operation

66 Increasing touch screen sensitivity

Phone

67 Making calls

70 Receiving calls

71 During a call

Contacts

73 Adding contacts

74 Managing contacts

Gallery

99 Viewing content on the device

101 Modifying content on the device

103 Accessing additional options

103 Tagging faces

104 Using Tag buddy

Internet & SNS

105 Internet

106 Chrome

107 Hangouts

107 ChatON

Messages & email

77 Messages

80 Email

82 Google Mail

Camera

84 Taking photos or videos

86 Using the HDR (Rich tone) effect

86 Using selective focus mode

88 Launching Camera on the locked

screen

88 Using the shooting mode

89 Using shot & more mode

91 Using dual camera mode

92 Using virtual tour mode

94 Applying filter effects

94 Using the zoom feature

S Health

109 About S Health

110 Starting S Health

111 Customising the S Health main screen

112 Using S Health menus

113 Measuring steps taken

115 Using the Exercise mate

118 Recording food intake

120 Using the additional menus

121 Configuring settings for S Health

Voice features

123 S Voice

125 Voice Recorder

127 Voice Search

128 Car mode

95 Using remote viewfinder mode

96 Changing Camera settings

3

Table of Contents

Multimedia

136 Music

139 Video

141 YouTube

142 Flipboard

142 Google+

142 Photos

143 Play Games

143 Play Music

143 Play Newsstand

Security

144 Finger Scanner

148 Private mode

166 Magnifier

167 Maps

167 Memo

168 My Files

170 Torch

Connecting with other
devices

171 NFC

173 Bluetooth

176 S Beam

177 Quick connect

181 Smart Remote

184 Screen mirroring

186 Using the mobile printing feature

Safety

150 Emergency mode

152 Sending help messages

153 Severe weather notification (Geo

News)

Utilities

155 S Finder

156 S Planner

159 Calculator

159 Clock

161 Drive

161 Dropbox

162 Google

163 Kids Mode

Device & data manager

187 Upgrading the device

188 Transferring files between the device

and a computer

189 Backing up and restoring data

190 Performing a data reset

Settings

191 About Settings

191 QUICK SETTINGS

191 NETWORK CONNECTIONS

196 CONNECT AND SHARE

197 SOUND AND DISPLAY

201 PERSONALISATION

4

Table of Contents

203 MOTION

204 USER AND BACKUP

205 SYSTEM

212 APPLICATIONS

219 Google Settings

Accessibility

220 Accessibility

221 Using the Home button to open

accessibility menus

221 TalkBack

233 Changing the font size

233 Magnifying the screen

233 Setting notification reminders

Troubleshooting

234 Reversing the display colours

234 Colour adjustment

235 Setting flash notification

235 Turning off all sounds

235 Customising caption settings

236 Adjusting the sound balance

236 Using mono audio

236 Using baby crying detector

237 Using auto haptic

237 Using the assistive menus

239 Turning on the screen with the air

gesture feature

239 Using the smart scroll feature

240 Setting tap and hold delay options

240 Using interaction control mode

241 Answering or ending calls

241 Using single tap mode

241 Configuring accessibility settings

243 Using other useful features

5

Read me first

This device provides mobile communication and media services using Samsung’s latest
standards and technological expertise. This user manual and the information available at

www.samsung.com

•

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider, or
device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other

contain details about the device’s functions and features.

purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.

•

You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services. To avoid additional charges, select
an appropriate data tariff plan. For details, contact your service provider.

•

Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.

6

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Note: notes, usage tips, or additional information

7

Getting started

Infrared LED

Headset jack

Device layout

Notification light

Proximity/Light/Gesture
sensor

Earpiece

Touch screen

Home button

Recent apps button

Microphone

GPS antenna

Front camera

Power button

Back button

Multipurpose jack

Microphone for
speakerphone

Rear camera

Flash

Back cover

Speaker

Volume button

NFC antenna (on the
battery)

Main antenna

8

Getting started

The microphone at the top of the device is active only when you use the speakerphone or
take videos.

•

Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.

•

Do not use a screen protector. This causes sensor malfunctions.

Maintaining water and dust resistance

The device may be damaged if water or dust enters the device. Follow these tips carefully to
prevent damage to the device and to maintain the water- and dust-resistant performance of
the device.

•

Do not immerse the device in water deeper than 1 m and keep it submerged for more
than 30 minutes.

•

Ensure that the back and multipurpose jack covers are tightly closed. Otherwise, they
may not provide protection from water and dust.

•

Do not immerse the device in water for extended periods.

•

Do not expose the device to water moving with force, such as ocean waves or waterfalls.

•

Do not open the device’s covers when the device is in water or in very humid places, such
as swimming pools or bathrooms.

•

Do not open the back cover using wet hands or when the device is wet.

•

The rubber seal fitted to the back cover is an important component of the device. Take
care when opening and closing the back cover to avoid damaging the rubber seal. Also,
ensure that the rubber seal is free from debris, such as sand or dust to prevent damage to
the device.

•

Do not detach or remove the multipurpose jack cover from the device.

•

Do not expose the device to salt water, ionised water, or soapy water.

•

The back and multipurpose jack covers may be loosened if the device is dropped or
receives an impact. Ensure that all the covers are properly aligned and tightly closed.

9

Getting started

•

If the device has been immersed in water or the microphone or the speaker is wet,
sound may not be heard clearly during a call. Ensure that the microphone or the speaker
is clean and dry by wiping it with a dry cloth.

•

If the device gets wet, dry it thoroughly with a clean, soft cloth.

•

The water-resistant design of the device causes it to vibrate slightly in certain conditions.
Vibrations in these conditions, such as when the volume level is high are normal and do
not affect the device’s performance.

•

The touch screen and other features may not work properly if the device is used in water
or in other liquids.

•

Your device has been tested in a controlled environment and certified to be water­and dust-resistant in specific situations (meets requirements of classification IP67 as
described by the international standard IEC 60529 - Degrees of Protection provided
by Enclosures [IP Code]; test conditions: 15 - 35 °C, 86 - 106 kPa, 1 meter, 30 minutes).
Despite this classification, your device is not impervious to water damage in any
situation.

Buttons

Button Function

•

Press and hold to turn the device on or off.

Power

Recent apps

•

Press to lock or unlock the device. The device goes into
lock mode when the touch screen turns off.

•

Tap to open the list of recent apps.

•

Tap and hold to access additional options for the current
screen.

•

Press to unlock the device. The device goes into lock
mode when the touch screen turns off.

Home

•

Press to return to the Home screen.

•

Press twice to launch

•

Press and hold to launch

10

S Voice

Google

.

.

Getting started

Button Function

Back

Volume

•

Tap to return to the previous screen.

•

Press to adjust the device volume.

Package contents

Check the product box for the following items:

•

Device

•

Battery

•

Quick start guide

•

The items supplied with the device and any available accessories may vary
depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible
with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Some accessories, such as docking
devices, may not have the same water- and dust-resistance certification. Before
purchasing accessories, ensure that they are compatible with the device.

•

Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

11

Getting started

Installing the SIM or USIM card and battery

Insert the SIM or USIM card provided by the mobile telephone service provider, and the
included battery.

•

Only microSIM cards work with the device.

•

Some LTE services may not be available depending on the service provider. For
details about service availability, contact your service provider.

Remove the back cover.

1

Be careful not to damage your fingernails when you remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

12

Getting started

Insert the SIM or USIM card with the gold-coloured contacts facing downwards.

2

•

Do not insert a memory card into the SIM card slot. If a memory card happens to
be lodged in the SIM card slot, take the device to a Samsung Service Centre to
remove the memory card.

•

Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.

Insert the battery.

3

2

1

13

Getting started

Replace the back cover.

4

1

•

Ensure that the back cover is closed tightly.

•

Use only Samsung-approved back covers and accessories with the device.

2

Press

Align

Removing the SIM or USIM card and battery

Remove the back cover.

1

Pull out the battery.

2

14

Getting started

Press the SIM or USIM card with your finger, and then pull it out.

3

Charging the battery

Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the device by connecting them via the USB cable.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection
to another device, the battery will drain quickly. To avoid disconnecting from the
network or losing power during a data transfer, always use these apps after fully
charging the battery.

15

Getting started

Connect the USB cable to the USB power adaptor.

1

Open the multipurpose jack cover.

2

When using a USB cable, plug the USB cable into the right side of the multipurpose jack

3

as shown in the image below.

•

Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.

•

Ensure that the back cover and the multipurpose jack cover are closed tightly to
prevent water and dust entering the device. Open or loose covers may allow water
and dust to enter the device and cause damage.

•

Be careful not to damage or detach the multipurpose jack cover. A damaged or
missing cover can result in water damage to the device.

Plug the USB power adaptor into an electric socket.

4

•

The device can be used while it is charging, but it may take longer to fully charge
the battery.

•

If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.

•

While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.

•

If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.

16

Getting started

After fully charging, disconnect the device from the charger. First unplug the charger

5

from the device, and then unplug it from the electric socket.

Do not remove the battery before removing the charger. This may damage the
device.

To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.

Close the multipurpose jack cover.

6

Ensure that the multipurpose jack cover is closed tightly.

Reducing the battery consumption

Your device provides options that help you save battery power. By customising these options
and deactivating features in the background, you can use the device longer between charges:

•

When you are not using the device, switch to sleep mode by pressing the Power button.

•

Close unnecessary apps with the task manager.

•

Deactivate the Bluetooth feature.

•

Deactivate the Wi-Fi feature.

•

Deactivate auto-syncing of apps.

•

Decrease the backlight time.

•

Decrease the brightness of the display.

17

Getting started

Inserting a memory card

Your device accepts memory cards with maximum capacities of 128 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.

•

Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory
appears in the

Remove the back cover.

1

Insert a memory card with the gold-coloured contacts facing downwards.

2

My Files

→

SD card

folder.

Replace the back cover.

3

18

Getting started

Removing the memory card

Before removing the memory card, first unmount it for safe removal. On the Home screen, tap

Apps

→

Settings

Remove the back cover.

1

Pull out the memory card.

2

Replace the back cover.

3

Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.

→

Storage

→

Unmount SD card

.

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.

On the Home screen, tap

→

card

Erase everything

Before formatting the memory card, remember to make backup copies of all
important data stored on the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.

Apps

.

→

Settings

→

Storage

→

Format SD card

→

Format SD

19

Getting started

Turning the device on and off

When turning on the device for the first time, follow the on-screen instructions to set up your
device.

Press and hold the Power button for a few seconds to turn on the device.

To turn off the device, press and hold the Power button, and then tap

Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.

Holding the device

Power off

.

Do not cover the antenna area with your hands or other objects. This may cause connectivity
problems or drain the battery.

20

Getting started

Locking and unlocking the device

Pressing the Power button turns off the screen and puts the device into lock mode. The
device automatically gets locked if it is not used for a specified period.

To unlock the device, press the Power button or the Home button and flick your finger in any
direction within the unlock screen area.

You can change the unlock code to unlock the device. Refer to ‘Changing the screen lock
method’ for details.

21

Basics

Using the touch screen

•

Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.

•

To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.

•

Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.

•

It is recommended to use fingers when you use the touch screen.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen tap it with a finger.

22

Basics

Tapping and holding

Tap and hold an item for more than 2 seconds to access available options.

Dragging

To move an icon or thumbnail, tap and hold it and drag it to the target position.

Double-tapping

Double-tap on a webpage or image to zoom in a part. Double-tap again to return.

23

Basics

Flicking

Flick left or right on the Home screen or the Apps screen to see another panel. Flick up or
down to scroll through a webpage or a list, such as contacts.

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

24

Basics

Indicator icons

The icons displayed on the status bar provide information about the status of the device. The
icons listed in the table below are most common.

The status bar may not appear at the top of the screen in some apps. To display the
status bar, drag down from the top of the screen.

Icon Meaning

No signal

Signal strength

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

HSPA+ network connected

LTE network connected

Wi-Fi connected

Bluetooth feature activated

GPS activated

Call in progress

Missed call

Air gesture feature activated

Smart screen feature activated

Synced with the web

Connected to computer

No SIM or USIM card

New text or multimedia message

Alarm activated

25

Basics

Icon Meaning

Mute mode activated

Vibration mode activated

Flight mode activated

Error occurred or caution required

Battery power level

Notifications and quick setting panels

Using the notifications panel

When you receive new notifications, such as messages or missed calls, indicator icons appear
on the status bar. To see more information about the icons, open the notifications panel and
view the details.

To open the notifications panel, drag the status bar downwards.

To close the notifications panel, drag the bar from the bottom of the screen upwards.

26

Basics

Launch Settings.

You can use the following functions on the notifications panel.

Activate or deactivate options.

Tap and hold options to view

more detailed settings.

View all quick setting buttons.

Launch S Finder.

Adjust the brightness.

Launch Quick connect.

Clear all notifications.

Tap a notification and perform
various actions.

Adjusting the brightness

To set the device to adjust the brightness automatically, tick
brightness from the automatic level, drag the brightness adjustment bar to the left or right.

When battery power is low, the brightness adjustment bar disappears from the notifications

Auto

. To manually adjust the

panel.

27

Basics

Using the quick setting panel

A number of quick setting buttons are available on the notifications panel. To view or access
more quick setting buttons, open the quick setting panel. When you open the quick setting
panel, you can activate or deactivate various features or configure settings.

To open the quick setting panel, drag the status bar downwards with two fingers.

To close the quick setting panel, drag the bar from the bottom of the screen upwards.

To rearrange quick setting buttons on the notifications panel, tap
and then drag the item to another location.

Use the following options:

•

Wi-Fi

: Activate or deactivate the Wi-Fi feature. Refer to ‘Connecting to a Wi-Fi network’ for

details.

•

Location

•

Sound

: Activate or deactivate the GPS feature.

/

Vibration

/

Mute

: Activate or deactivate sound mode and silent mode. You can

, tap and hold an item,

set the device to vibrate or mute all sound in silent mode.

•

Screen rotation

Some apps do not allow screen rotation.

•

Bluetooth

•

Mobile data

: Activate or deactivate the Bluetooth feature.

: Allow or prevent the interface from rotating when you rotate the device.

: Activate or deactivate the mobile data connection.

28

Basics

•

Download booster

Download booster’ for details.

•

U.power saving

power saving feature’ for details.

•

Multi window

•

Toolbox

•

Mobile hotspot

devices and using mobile hotspots’ for details.

•

Screen Mirroring

mirroring’ for details.

•

NFC

•

Sync

: Hide or show the toolbox icon. Refer to ‘Toolbox’ for details.

: Activate or deactivate the NFC feature. Refer to ‘NFC’ for details.

: Activate or deactivate auto-syncing of apps.

: Activate or deactivate the download booster feature. Refer to ‘Using

: Activate or deactivate ultra power-saving mode. Refer to ‘Using the

: Set to use Multi Window. Refer to ‘Multi Window’ for details.

: Activate or deactivate the Wi-Fi tethering feature. Refer to ‘Tethering

: Activate or deactivate the screen mirroring feature. Refer to ‘Screen

•

Smart stay

the screen stays on as long as you look at it.

•

Smart pause

feature, playback pauses when you look away from the screen.

•

Power saving

saving feature’ for details.

•

Blocking mode

will block notifications. To select which notifications will be blocked, tap

Blocking mode

•

Flight mode

•

Car mode

•

Private mode

•

Touch sensitivity

touch screen sensitivity’ for details.

: Activate or deactivate the smart stay feature. When you activate this feature,

: Activate or deactivate the smart pause feature. When you activate this

: Activate or deactivate power-saving mode. Refer to ‘Using the power

: Activate or deactivate blocking mode. In blocking mode, your device

.

: Activate or deactivate flight mode.

: Activate or deactivate car mode. Refer to ‘Car mode’ for details.

: Activate or deactivate private mode. Refer to ‘Private mode’ for details.

: Activate or deactivate the touch sensitivity feature. Refer to ‘Increasing

Settings

→

29

Basics

Home and Apps screens

Home screen

The Home screen is the starting point to access all of the device’s features. It displays widgets,
shortcuts to apps, and more. Widgets are small apps that launch specific app functions to
provide information and convenient access on your Home screen.

The Home screen can have multiple panels. To view other panels, scroll left or right. To
customise the Home screen, refer to ‘Managing the Home and Apps screens’ for details.

A widget

An app

A folder

Screen indicators

Favourite apps

30

Basics

Home screen options

Tap and hold an area, or pinch your fingers together on the Home screen to access the
options available on the Home screen.

31

Basics

Using My Magazine

Tap or scroll right on the Home screen to open

My Magazine

displays live social network updates and news that you are interested in.

My Magazine

.

Access additional
options.

To select the content to be displayed, tap →
interest you.

To update the content automatically when

Auto refresh on opening

tick

To deactivate

My Magazine

.

, on the Home screen, tap and hold an empty area or pinch your

fingers together on the screen. Then, tap

My Magazine

Home screen settings

Settings

, and then select the categories that

opens, tap →

and deselect

Settings

My Magazine

, and then

.

32

Basics

Apps screen

The Apps screen displays icons for all apps, including any new apps installed.

On the Home screen, tap

Apps

to open the Apps screen. To view other panels, scroll left or
right, or select a screen indicator at the bottom of the screen. To customise the Apps screen,
refer to ‘Managing the Home and Apps screens’ for details.

Access additional
options.

An app

Screen indicators

33

Basics

Opening apps

On the Home screen or the Apps screen, select an app icon to open it.

To open the list of recently-used apps, tap

and select an app icon to open.

Closing an app

Close apps not in use to save battery power and maintain device performance.

Tap

all

→ , and then tap

. Alternatively, tap → .

End

next to an app to close it. To close all running apps, tap

Installing or uninstalling apps

Samsung Apps

Use this app to purchase and download dedicated Samsung apps.

Tap

Samsung Apps

on the Apps screen.

End

This app may not be available depending on the region or service provider.

Installing apps

Browse apps by category or tap to search for a keyword.

Select an app to view information about it. To download free apps, tap
download apps where charges apply, tap the button that shows the app’s price.

By default, the device automatically updates any installed app when a new version is
available. To change the default setting or to update apps manually, tap

→

Auto update apps

, and then select an option.

Free

. To purchase and

→

Settings

34

Basics

Play Store

Use this app to purchase and download apps and games that are able to run on the device.

Tap

Play Store

This app may not be available depending on the region or service provider.

Installing apps

Browse apps by category or tap to search for a keyword.

on the Apps screen.

Select an app to view information about it. To download free apps, tap
and download apps where charges apply, tap the price and follow the on-screen instructions.

•

To install apps that you download from other sources, on the Apps screen, tap

Settings

•

By default, the device automatically updates any installed app when a new version
is available. To change the default setting or to update apps manually, tap

Settings

→

Security

→

Auto-update apps

→

Unknown sources

, and then select an option.

.

INSTALL

. To purchase

→

Downloading suggested apps

You can view and download dedicated Galaxy device apps.

On the Apps screen, tap

Essentials

To download all apps in the list, tap

widget or the

→

Galaxy Essentials

GALAXY Gifts

Download all

. Or, on the Home screen, tap the

widget, and then tap next to an app.

.

GALAXY

Managing apps

Uninstalling or disabling apps

To disable default apps, on the Apps screen, tap →
apps that you can disable. Select an app and tap

To uninstall downloaded apps, on the Apps screen, tap

Uninstall

app, and then tap

. Alternatively, on the Apps screen, tap

Uninstall

.

35

Uninstall/Disable apps

Disable

Settings

.

→

Downloaded apps

→

Application manager

. appears on

→ →

, select an

Basics

Enter a space.

Enabling apps

On the Apps screen, tap →

Alternatively, on the Apps screen, tap
select an app, and then tap

•

Hiding apps: Hide apps in the Apps screen only. You can continue to use hidden
apps.

•

Disabling apps: Disable selected default apps that cannot be uninstalled from the
device. You cannot use disabled apps.

•

Uninstalling apps: Uninstall downloaded apps.

Show disabled apps

Enable

Settings

.

→

, select apps, and then tap

Application manager

, scroll to

Done

.

DISABLED

,

Entering text

A keyboard appears automatically when you enter text to send messages, create memos, and
more.

Text entry is not supported in some languages. To enter text, you must change the
input language to one of the supported languages.

Suggested keywords

Set options for the Samsung

keyboard.

Enter uppercase.

Enter punctuation marks.

Delete a preceding character.

Break to the next line.

Setting input languages

Tap →
more languages, you can change the languages by sliding the space key left or right.

Select input languages

, and then select the languages to use. If you select two or

36

Basics

Changing the keyboard layout

Tap , select a language under

INPUT LANGUAGES

, and then select a keyboard layout to

use.

On the 3x4 keyboard, a key has three or four characters. To enter a character, tap
repeatedly the key corresponding to the character.

Using additional keyboard functions

Tap and hold to use the following functions. Other icons may appear instead of the icon
depending on the last function that was used.

•

: Enter text by voice.

Change the language.

Open the keyboard.

Start or pause entering text by
voice.

Ensure that the Wi-Fi or mobile network is connected before using this feature. You
may incur additional charges when using this feature via the mobile network.

•

: Switch to handwriting mode.

Switch to the standard keyboard.

This feature may not be available depending on the region or service provider.

37

Basics

•

•

•

: Add an item from the clipboard.

: Set options for the keyboard.

: Enter emoticons.

•

: Switch to the floating keyboard. You can move the keyboard to another location by

dragging

Switch to the standard keyboard.

.

Copying and pasting

Tap and hold over text.

1

Drag or to select the desired text, or tap

2

Select all

to select all text.

Tap

Copy

or

Cut

3

Place the cursor where the text is to be inserted and tap →

4

you have previously copied, tap

. The selected text is copied to the clipboard.

→

Clipboard

and select the text.

Paste

. To paste text that

38

Basics

Using the power saving feature

Power saving mode

Save battery power by limiting the device’s functions.

On the Apps screen, tap

Power saving mode

the

Power saving

tap

Select from the following options:

•

Block background data

mobile data connection.

•

Restrict performance

Back buttons’ backlight.

•

Greyscale mode

to activate it.

Settings

switch to the right. Alternatively, open the quick setting panel and

: Limit various options, such as turning off the Recent apps and

: Display colours on the screen as grey tones.

→

Power saving

: Prevent apps that are running in the background from using a

→

Power saving mode

, and then drag

Ultra power saving mode

Use this mode to extend the device’s battery power. In ultra power saving mode the device
performs the following:

•

Displays colours on the screen as grey tones.

•

Limits access to default apps and to various other apps that can be selected from a list.

•

Deactivates the mobile data connection when the screen turns off.

•

Deactivates the Wi-Fi and Bluetooth features.

39

Basics

On the Apps screen, tap

Ultra power saving mode

the
and tap

U.power saving

Launch Phone.

Launch Internet.

Remaining battery power

Settings

→

switch to the right. Alternatively, open the quick setting panel

to activate it.

Power saving

→

Ultra power saving mode

Access additional options.

Launch Messages.

Add more apps to use.

Estimated battery running time

, and drag

To add an app on the Home screen, tap and select an app.

To remove an app from the Home screen, tap

OK

tap

.

→

Remove

, select an app with , and then

To change the network connectivity or sound settings, tap

To deactivate the ultra power saving feature, tap

→

Disable ultra power saving mode

The maximum standby time is the estimated time that the device will maintain a
battery charge. The standby time is the time taken for the battery to fully discharge
if the device is not used. Standby time may vary depending on device settings and
operating conditions.

→

Settings

.

.

40

Basics

Accessing help information

To access help information for an app while you are using the app, tap →

To access help information to learn how to use the device and apps, on the Apps screen, tap

Settings

→

Help

.

•

Some apps may not support this feature.

•

To use the feature, connect to a Wi-Fi or mobile network.

Help

.

41

Personalising

Switching to easy mode

Easy mode provides an easier user experience by using a simpler layout and bigger icons on
the Home screen. You can access the most popular apps and frequently-used settings, and
add shortcuts to your favourite contacts.

Done

Done

Settings

.

.

On the Apps screen, tap
layout, and then tap

To return to standard mode, on the Home screen, tap

Standard mode

→

→

Easy mode

→

Easy mode

Easy settings

, select apps to apply simpler

→

Easy mode

→

Managing shortcuts

To add a shortcut to an app to the Home screen, scroll left, tap , and then select an app.

To add a shortcut to a contact on the Home screen, scroll right, tap

To delete a shortcut from the Home screen, tap

→

Edit

, select an app or contact with .

.

Managing the Home and Apps screens

Managing the Home screen

Adding items

Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.

To add widgets, on the Home screen, tap and hold an empty area, tap
a widget, and then drag it to the Home screen.

42

Widgets

, tap and hold

Personalising

Moving and removing an item

Tap and hold an item on the Home screen, and then drag it to a new location.

To move the item to another panel, drag it to the side of the screen.

You can also move frequently-used apps to the shortcuts area at the bottom of the Home
screen.

To remove an item, tap and hold the item. Then, drag it to
the screen.

Remove

that appears at the top of

Creating a folder

On the Home screen, tap and hold an app, and then drag it to

1

at the top of the screen.

Enter a folder name.

2

Tap , select the apps to move to the folder, and then tap

3

Create folder

Done

.

that appears

Managing panels

On the Home screen, tap and hold an empty area to add, move, or remove a panel.

To add a panel, scroll left to the last panel, and then tap

To move a panel, tap and hold a panel preview, and then drag it to a new location.

.

To remove a panel, tap and hold a panel preview, and then drag it to
the screen.

To set a panel as the main Home screen, tap

.

Remove

at the top of

43

Personalising

Managing the Apps screen

Changing view mode

On the Apps screen, tap →

View as

and select a sorting method.

Hiding apps

Hide apps that you do not want to see on the Apps screen.

On the Apps screen, tap

To display hidden apps, tap

→

Hide apps

→

, select apps, and then tap

Show hidden apps

Done

, select apps, and then tap

Moving items

On the Apps screen, tap →

To move the item to another panel, drag it to the side of the screen.

To move an item to a new panel, drag it to

Edit

. Tap and hold an item and drag it to a new location.

Create page

that appears at the top of the screen.

Creating folders

On the Apps screen, tap →

1

app, and then drag it to

Create folder

Create folder

. Alternatively, tap →

that appears at the top of the screen.

.

Done

Edit

, tap and hold an

.

Enter a folder name.

2

Tap , select the apps to move to the folder, and then tap

3

Done

.

44

Personalising

Changing the screen lock method

You can change the way that you lock the screen to prevent others accessing your personal
information.

On the Apps screen, tap
lock method. The device requires an unlock code whenever unlocking it.

If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.

Settings

→

Lock screen

→

Screen lock

, and then select a screen

Pattern

Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.
Set a backup PIN to unlock the screen when you forget the pattern.

Fingerprints

Register your fingerprints to unlock the screen. Refer to ‘Finger Scanner’ for details.

PIN

A PIN consists of numbers only. Enter at least four numbers, and then enter the password
again to verify it.

45

Personalising

Password

A password consists of characters and numbers. Enter at least four characters including
numbers and symbols, and then enter the password again to verify it.

Setting wallpaper

Set an image or photo stored in the device as wallpaper for the Home screen or the locked
screen.

On the Apps screen, tap

1

tap and hold an empty area or pinch your fingers together on the screen, and then tap

Wallpapers

Select a screen to change or apply wallpaper to.

2

Scroll left or right and select from images displayed at the bottom of the screen.

3

To select photos taken by the device’s camera or other images, tap

Tap

4

Set wallpaper

.

or

Settings

Done

→

Wallpaper

.

. Alternatively, on the Home screen,

More images

Changing ringtones

Change ringtones for incoming calls and notifications.

On the Apps screen, tap

Settings

→

Sound

.

.

To set a ringtone for incoming calls, tap
a song stored on the device or in your account as a ringtone, tap

To set a ringtone for notifications, tap

Ringtones

Notifications

46

, select a ringtone, and then tap OK. To use

, select a ringtone, and then tap OK.

Add

.

Personalising

Setting up accounts

Adding accounts

Some apps used on your device require a registered account. Create accounts to have the
best experience with your device.

On the Apps screen, tap
Then, follow the on-screen instructions to complete the account setup.

To sync content with your accounts, select an account and tick items to sync.

Settings

→

Accounts

→

Add account

and select an account service.

Removing accounts

On the Apps screen, tap

ACCOUNTS

, select the account to remove, and then tap →

Settings

→

Accounts

, select an account service under

Remove account

.

MY

Moving contacts from other devices to your device

Moving contacts using Samsung Smart Switch

You can move contacts to your device from other devices and computers using Samsung
Smart Switch.

Samsung Smart Switch is not supported on some devices or computers.

Using Smart Switch Mobile

You can use this app to transfer contacts from one mobile device to another. This feature is
supported when transferring contacts between selected Samsung mobile devices only.

47

Personalising

Before using this feature

Ensure that the Smart Switch Mobile app is installed on the two devices. You can download
the app from

On the two devices, launch

1

On both devices, read and agree to the terms and conditions, and then tap

2

Bring the devices close together, and then tap

3

On the device you are transferring contacts from, tick

4

On the device to transfer contacts to, tap OK to start transferring contacts from the other

5

device.

Samsung Apps

or

Play Store

Smart Switch Mobile

.

.

Connect

Contacts

on either device.

and tap

Confirm

Transfer

.

.

Using Smart Switch with computers

Use this feature to transfer a backup of your contacts from a computer to your device. You can
also transfer contacts from selected manufacturer’s mobile devices to your device.

Before using this feature

Ensure that the Smart Switch for computers is installed on the computer. You can download
the app from the Samsung Smart Switch website (

Back up contacts from a previous device to the computer. For details, contact the device’s

1

manufacturer.

On the computer, launch

2

On the computer, read and agree to the terms and conditions, and then click

3

Connect your current device to the computer using the USB cable.

4

On the computer, click the manufacturer of the previous device and follow the on-screen

5

instructions to transfer contacts to your device.

Smart Switch

.

www.samsungsmartswitch.com

).

Agree

.

48

Personalising

Moving contacts using Samsung Kies

Import a backup contacts file from your computer via Samsung Kies to restore contacts
on your device. You can also back up contacts to the computer via Samsung Kies. Refer to
‘Connecting with Samsung Kies’ for details.

49

Network connectivity

Connecting to a mobile network

Connect the device to a mobile network to use the Internet when a Wi-Fi network is not
available.

On the Apps screen, tap
open the quick setting panel and tap

Settings

→

Data usage

Mobile data

, and then tick

to activate it.

Mobile data

. Alternatively,

Connecting to a Wi-Fi network

Connect the device to a Wi-Fi network to use the Internet or share media files with other
devices. Refer to ‘Wi-Fi’ for additional options.

•

Your device uses a non-harmonised frequency and is intended for use in all
European countries. The WLAN can be operated in the EU without restriction
indoors, but cannot be operated outdoors.

•

Turn off Wi-Fi to save the battery when not in use.

On the Apps screen, tap

1

and tap and hold

Wi-Fi

Settings

.

→

Wi-Fi

. Alternatively, open the quick setting panel

Drag the

2

Select a network from the list of detected Wi-Fi networks. Networks that require a

3

password appear with a lock icon.

Tap

4

connect to it any time it is available.

Wi-Fi

Connect

switch to the right.

. After the device connects to a Wi-Fi network, the device will automatically

50

Network connectivity

Adding Wi-Fi networks

If the desired network does not appear in the networks list, tap
bottom of the networks list. Enter the network name in
type and enter the password if it is not an open network, and then tap

Network SSID

Add Wi-Fi network

, select the security

Connect

.

at the

Activating Wi-Fi Passpoint

Wi-Fi Passpoint enables the device to search for and connect to a certified Wi-Fi network. You
can use the Passpoint feature to connect to public Wi-Fi networks that support automated
authentication. When you move to a new location it will search for and connect to another
certified Wi-Fi network.

This feature may not be available depending on the region.

→

Tap

Advanced

, and then tick

Passpoint

.

Forgetting Wi-Fi networks

Any network that has ever been used, including the current network, can be forgotten so the
device will not automatically connect to it. Select the network in the networks list and tap

Forget

.

51

Network connectivity

Using Download booster

Use this feature to download large files faster via Wi-Fi and mobile networks simultaneously.
Before using this feature, ensure that the mobile data connection and Wi-Fi features are
activated. A stronger Wi-Fi signal will provide a faster download speed.

On the Apps screen, tap

booster
booster

switch to the right. Alternatively, open the quick setting panel and tap
to activate it.

•

You may incur additional charges when downloading files via a mobile network.

•

When you download large files, the device may heat up. If the device exceeds a set
temperature, the feature will turn off.

•

If network signals are unstable, the speed and performance of this feature may be
affected.

•

If the Wi-Fi and mobile network connections have significantly different data
transfer speeds, the device may use only the fastest connection.

•

This feature supports Hypertext Transmission Protocol (HTTP) 1.1 only. The feature
cannot be used with other protocols, such as HTTPS or FTP.

Settings

→

Download booster

Using Smart network switch

, and then drag the

Download

Download

Use this feature to maintain a stable network connection when you browse webpages,
download content, and more. Before using this feature, ensure that the mobile data
connection and Wi-Fi features are activated.

You may incur additional charges when using this feature via a mobile network.

On the Apps screen, tap
automatically switches from a Wi-Fi network to a mobile network when the current Wi-Fi
network is weak or unstable. When the Wi-Fi network signal becomes strong, the device
switches from the mobile network back to the Wi-Fi network.

Settings

→

Wi-Fi

, and then tick

Smart network switch

. The device

52

Network connectivity

Tethering devices and using mobile hotspots

About tethering and mobile hotspots

Use this feature to share the device’s mobile data connection with computers and other
devices if an Internet connection is unavailable. Connections can be made via the Wi-Fi
feature, USB, or the Bluetooth feature.

You may incur additional charges when using this feature.

Using the mobile hotspot

Use your device as a mobile hotspot to share your device’s mobile data connection with other
devices.

Before using this feature

•

Ensure that the Wi-Fi feature is deactivated.

•

Ensure that the device’s mobile data connection is activated.

On the Apps screen, tap

1

Drag the

2

•

list.

•

To set a password for the hotspot, tap →
Then, enter a password and tap

On the other device’s screen, search for and select your device from the Wi-Fi networks

3

list.

Mobile hotspot

appears on the status bar. Other devices can find your device on the Wi-Fi networks

Settings

switch to the right.

→

Tethering and mobile hotspot

Save

.

Configure

→

Mobile hotspot

and select the level of security.

.

53

Network connectivity

Using USB tethering

Share the device’s mobile data connection with a computer via a USB cable.

On the Apps screen, tap

1

Connect your device to the computer via the USB cable.

2

Tick

3

4

USB tethering

appears on the status bar when the two devices are connected.

On the computer, use your device’s mobile data connection.

.

Settings

→

Tethering and mobile hotspot

.

Using Bluetooth tethering

Share the device’s mobile data connection with connected computers and other devices via
Bluetooth.

Before using this feature

•

Ensure that your device is paired with the other device via Bluetooth. Refer to ‘Bluetooth’
for details.

•

Ensure that the computer that you connect to supports the Bluetooth feature.

On your device, on the Apps screen, tap

1

Tick

2

3

4

Bluetooth tethering

On the connected device, open the Bluetooth settings screen, tap →

appears on the status bar when the two devices are connected.

On the connected device, use the device’s mobile data connection to access the Internet.

The connection methods may vary depending on the connected devices.

.

Settings

→

Tethering and mobile hotspot

Internet access

.

.

54

Motions & usability features

Control motions

Excessive shaking or impact to the device may result in unintended inputs. Control
motions properly.

Air browse

On the Apps screen, tap

Air browse

Move your hand to the left or right across the sensor to go to the next or previous item.
Alternatively, move your hand up or down across the sensor to go to the next or previous
item.

switch to the right.

Settings

→

Motions and gestures

→

Air browse

, and then drag the

55

Motions & usability features

Direct call

On the Apps screen, tap

Direct call

While viewing call, message, or contact details, pick up and hold the device to your ear to
make a call.

switch to the right.

Settings

→

Motions and gestures

→

Direct call

, and then drag the

Smart alert

On the Apps screen, tap

Smart alert

the

When you pick up the device after it has been idle for some time or when the screen has
turned off, it vibrates if you have missed calls or new messages.

switch to the right.

Settings

→

Motions and gestures

→

Smart alert

, and then drag

56

Motions & usability features

Mute/Pause

On the Apps screen, tap

Mute/Pause

the

switch to the right.

Settings

→

Motions and gestures

→

Mute/Pause

, and then drag

Covering screen with hand

Cover the screen with a palm to mute incoming calls or alarms, or to pause media playback.

Turning device over

Turn the device over to mute incoming calls or alarms, or to pause media playback.

57

Motions & usability features

Smart pause

Playback pauses automatically when you look away from the screen. It resumes when you
look at the screen again.

Capture screen

On the Apps screen, tap
drag the

Place the side of your hand on the screen and sweep it across the screen from the right to the
left or vice versa to capture a screenshot. The image is saved in the

Screenshots

Capture screen

folder.

It is not possible to capture a screenshot while using some apps.

Settings

switch to the right.

→

Motions and gestures

→

Capture screen

Gallery

, and then

→ →

Album

→

58

Motions & usability features

Air view

Use this feature to perform various functions while your finger is hovering over the screen.
Point at the screen to preview content or view information in a pop-up window.

On the Apps screen, tap

Settings

Multi Window

→

Air view

, and then drag the

Air view

switch to the right.

About Multi Window

Use this feature to run two apps on the screen at the same time. You can use this feature to
view emails or use the Internet while you play a video simultaneously.

Launching Multi Window

On the Apps screen, tap

1

switch to the right. Alternatively, open the quick setting panel and tap
activate it.

Settings

→

Multi window

, and then drag the

Multi window

Multi window

to

59

Motions & usability features

Tap at the left side of the screen to open the Multi Window tray.

2

Multi Window tray handle

Tap and hold an app icon to launch from the Multi Window tray. Then, drag it to one of

3

the two windows.

App icons marked with
same time.

can be launched in separate windows on the screen at the

60

Motions & usability features

Creating a Multi Window combination

Use this feature to save the combination of the currently-running Multi Window apps.

Launch two apps in a split screen Multi Window.

1

Open the Multi Window tray and tap →

2

Enter a title and tap OK.

3

The currently-running Multi Window combination is added to the Multi Window tray.

Create

.

Adjusting the window size

Drag the circle between the app windows up or down to adjust the size of the windows.

61

Motions & usability features

Using Multi Window options

When you use Multi Window apps, select the app window and a white frame will appear
around it. Tap the circle between app windows to access the following options:

•

: Switch locations between Multi Window apps.

62

Motions & usability features

•

: Drag and drop text or copied images from one window to another. Tap and hold an

item in the selected window and drag it to a location in another window.

Some apps may not support this feature.

•

: Close the app.

Rearranging apps on the Multi Window tray

You can rearrange the apps on the Multi Window tray.

On the Apps screen, tap

1

switch to the right. Alternatively, open the quick setting panel and tap
activate it.

Open the Multi Window tray and tap →

2

The device displays the available apps that you can use on the Multi Window tray.

Settings

→

Multi window

Edit

, and then drag the

.

Multi window

Multi window

to

63

Motions & usability features

Tap and hold an app and drag it to the Multi Window tray.

3

Tap

4

Done

.

Toolbox

You can easily launch various apps from the toolbox icon while using other apps.

Open the quick setting panel and tap

Settings

tap
screen.

To launch an app, tap

To move the toolbox icon, tap

To change the apps that are in the toolbox, tap and hold

To hide the toolbox icon, tap and hold

→

Toolbox

, and then drag the

and select an app.

Toolbox

and drag it to another location.

to activate it. Alternatively, on the Apps screen,

Toolbox

, and then drag it to

switch to the right. appears on the

, and then drag it to

Remove

.

Edit

.

64

Motions & usability features

Enlarge or reduce the screen

One-handed operation

You can switch to one-handed operation mode to conveniently operate the device with one
hand.

On the Apps screen, tap

handed operation

Settings

→

One-handed operation

switch to the right.

, and then drag the

One-

To switch to one-handed operation mode, hold the device in one hand. Then, quickly drag
your thumb from the edge of the screen to the centre of the screen and back again.

size.

Open the side menu and
access favourite apps.

Return to the full screen view.

Open the side menu and
access favourite contacts.

Return to the Home screen.

Adjust the volume.

Return to the previous screen.

Open the list of recent apps.

65

Motions & usability features

Managing shortcuts to contacts or apps

You can manage shortcuts to contacts or apps by opening the side menu.

Tap or to open the side menu.

1

Tap at the bottom of the side menu.

2

Tap and hold a contact’s image or an app, and then drag it to the side menu.

3

To delete a shortcut to a contact’s image or an app, tap

Tap .

4

.

Increasing touch screen sensitivity

Use this feature to operate the screen while wearing gloves.

On the Apps screen, tap
Alternatively, open the quick setting panel and tap

•

Use leather gloves for better recognition while touching the screen. Other types of
material may not be recognised.

•

For best results, tap the screen firmly while wearing gloves.

•

The screen may not respond if you are wearing gloves when using the device
through the S View cover window.

Settings

→

Display

, and then tick

Increase touch sensitivity

Increase touch sensitivity

.

to activate it.

66

Phone

View favourite contacts.

View call and message logs.

Making calls

Tap

Tap

Phone

Keypad

on the Apps screen.

, enter a phone number, and then tap to make a voice call, or tap to make a

video call. You can also make calls to phone numbers listed in

Enter the number using the

keypad.

Add the number to the contacts

list.

Logs, Favourites

View the contacts list.

Access additional options.

Preview the phone number.

, and

Contacts

.

Delete a preceding character.

67

Phone

Making calls from call logs or contact lists

Tap

Logs

or

Contacts

, and then drag a contact or a phone number to the right to make a call.

To deactivate the call by dragging an icon to the right feature, tap
and then deselect

Swipe to call or send msg

.

Making calls from the favourites list

→

Settings

→

Contacts

,

You can easily call contacts that you communicate with frequently by adding them to the
favourite contacts list.

To add contacts to the favourites list, tap

To make a call to a favourite contact, tap

Contacts

Favourites

, select a contact, and then tap .

and select a contact.

68

Phone

Number prediction

Tap

Keypad

When entering numbers on the keypad, automatic predictions appear. Select one of these to
make a call.

.

Speed dial numbers

Tap

Keypad

For speed dial numbers, tap and hold the corresponding digit.

To assign a contact to a speed dial number, tap and hold an available speed dial number on
the keypad, tap
number, and then select a contact.

.

OK

, and then select a contact. Or, tap

Contacts

→ →

Speed dial

, select a

Making an international call

Tap

Keypad

Tap and hold 0 until the + sign appears. Enter the country code, area code, and phone
number, and then tap

To block outgoing international calls, tap

barring

.

.

→

. Then, select a call type and deselect

Settings

International calls

→

Call

→

More settings

.

→

Call

69

Phone

Receiving calls

Answering a call

When a call comes in, drag outside the large circle.

If you are using an app when a call comes in, tap

If the call waiting service is activated, another call can be made. When the second call is
answered, the first call is put on hold.

Answer

in a pop-up window.

Rejecting a call

When a call comes in, drag outside the large circle.

If you are using an app when a call comes in, tap

To send a message when rejecting an incoming call, drag the reject message bar upwards.

To create various rejection messages, on the Apps screen, tap

→

Call rejection

→

Rejection messages

→

Automatically rejecting calls from unwanted numbers

Tap

1

Phone

on the Apps screen.

Reject

Create

in the pop-window.

Phone

.

→ →

Settings

→

Call

2

3

4

Tap →

Tap

Tap

Settings

Auto reject list

Save

.

→

Call

→

→

Call rejection

Create

, enter a number, and then assign a category.

→

Auto reject mode

→

Auto reject numbers

Missed calls

If a call is missed, appears on the status bar. Open the notifications panel to view the list of
missed calls. Alternatively, on the Apps screen, tap

Phone

→

Logs

to view missed calls.

.

70

Phone

During a call

During a voice call

The following actions are available:

•

: Increase the volume.

•

Add call

•

Keypad

•

End call

•

Speaker

the speakerphone.

•

Mute

: Dial a second call.

: Open the keypad.

: End the current call.

: Activate the speakerphone. Keep the device away from your ears when using

: Turn off the microphone so that the other party cannot hear you.

•

Bluetooth

•

→

Hold

•

→

Contacts

•

→

Memo

•

→

Messages

•

→

Personalise call sound

•

→

Settings

When you launch apps during a call, a pop-up window for the call screen (
continue your phone conversation while using apps.

To move the pop-up window, drag it to another location.

To delete the pop-up window, tap and hold it, and then tap

To return to the call screen, tap the pop-up window.

: Switch to a Bluetooth headset if it is connected to the device.

: Hold a call. Tap

: Open the contacts list.

: Create a memo.

: Send a message.

: Change the call settings.

Unhold

: Select a type of call sound to use with a headset.

to retrieve the held call.

OK

.

) appears. You can

71

Phone

During a video call

The following actions are available:

•

→

Hide me

•

→

Outgoing image

•

→

Capture image

•

→

Record video

•

→

Memo

•

→

Message

•

→

Keypad

•

→

Speaker off

away from your ears when using the speakerphone.

: Hide your image from the other party.

: Select an image to show it to the other party.

: Capture the other party’s image.

: Take a video of the other party’s images.

: Create a memo.

: Send a message.

: Open the keypad.

/

Speaker on

: Activate or deactivate the speakerphone. Keep the device

•

→

Switch to headset

•

→

Enable dual camera

feature. Use the front and rear cameras so that the other party can see you and your
surroundings.

Video calling with dual camera mode will be provided for up to 3 minutes. After
3 minutes the device will turn off the rear camera for optimal performance.

Tap the screen to use the following options:

•

Switch

•

Mute

•

End call

: Switch between the front and rear camera.

: Turn off the microphone so that the other party cannot hear you.

: End the current call.

: Switch to a Bluetooth headset if it is connected to the device.

/

Disable dual camera

: Enable or disable the dual camera

72

Contacts

Adding contacts

Moving contacts from other devices

You can move contacts from other devices to your device. Refer to ‘Moving contacts from
other devices to your device’ for details.

Creating contacts manually

On the Apps screen, tap

1

Tap and enter contact information.

2

•

: Add an image.

•

/ : Add or delete a contact field.

Tap

Save

3

To add a phone number to the contacts list from the keypad, tap
and then tap

.

Add to contacts

Contacts

.

→

Contacts

.

Keypad

Creating contacts from business cards

Take a photo of a business card and extract contact information from it.

On the Apps screen, tap

1

Contacts

→

Contacts

.

, enter the number,

Tap →

2

To select or add languages to recognise, tap

Business cards

→ .

73

→

Target language

.

Contacts

Place a business card on the flat surface and rotate the device to landscape orientation.

3

Adjust the device to fit the card inside the frames on the screen. When the frames

4

turn green, the device automatically takes a photo. The device also reads the contact
information from the business card and converts it to a contact entry.

•

If the device does not take the photo automatically, tap .

•

To take photos of business cards manually, tap →

•

To extract text from a stored image, tap →

Load image

Auto capture

.

→

Off

.

Edit or add more information and tap

5

Managing contacts

Editing a contact

On the Apps screen, tap

1

Select a contact to edit and tap .

2

Edit the contact information or tap

3

Tap

Save

4

.

Contacts

Save

.

→

Contacts

Add another field

.

to add more contact information.

Deleting a contact

Select a contact to delete, tap →

Sharing a contact

Select a contact to share, tap →

Delete

Share name card

.

74

, and then select a sharing method.

Contacts

Managing groups

On the Apps screen, tap

Tap

.

Contacts

→

Contacts

.

Creating a new group

Tap , enter a group name, and then tap

Save

.

Adding contacts to a group

Select a group, and then tap . Select contacts to add, and then tap

Deleting a group

Tap →

Delete group

, select user-added groups, and then tap

Done

Sending a message or email to group’s members

Select a group, tap →

Done

, enter a message, and then tap the send button.

Send message or email

→

Message

or

Email

Done

.

.

, select members, tap

Merge contacts with accounts

Merge contacts that are saved in the device with your accounts.

On the Apps screen, tap

Tap

→

Merge accounts

Contacts

→

Google

→

Contacts

or

.

Samsung account

.

Importing and exporting contacts

Import contacts from storage services to your device or export contacts from the device to
storage services.

On the Apps screen, tap

Tap

→

Settings

→

Contacts

Contacts

→

Contacts

→

Import/export

.

, and then select an import or export option.

75

Contacts

Searching for contacts

On the Apps screen, tap

Use one of the following search methods:

•

Scroll up or down the contacts list.

•

Drag a finger along the index at the right side of the contacts list to scroll through it
quickly.

•

Tap the search field at the top of the contacts list and enter search criteria.

Once a contact is selected, take one of the following actions:

•

: Add to favourite contacts.

•

/ : Make a voice or video call.

•

: Compose a message.

•

: Compose an email.

Contacts

→

Contacts

.

Adding shortcuts for contacts to the Home screen

Add shortcuts to contacts that you frequently communicate with on the Home screen.

On the Apps screen, tap

1

Select a contact.

2

3

Tap →

Add shortcut to home screen

Contacts

→

Contacts

.

.

76

Messages & email

Messages

Sending messages

Send text messages (SMS) or multimedia messages (MMS).

You may incur additional charges for sending or receiving messages while you are
outside your home service area.

Tap

1

2

Messages

Tap .

on the Apps screen.

Add recipients and enter a message.

3

Enter recipients.

Attach files.

Enter emoticons.

Enter a message.

Tap to send the message.

4

Access additional options.

Select contacts from the
contacts list.

Send the message.

77

Messages & email

While composing a message, tap to use one of the following options:

•

Quick responses

•

Insert smiley

•

Add subject

•

Add slide

•

Schedule message

•

Discard

•

Font size

: Add message slides.

: Cancel composing the message.

: Change the font size of text in the text field.

: Select a message template and enter a message.

: Enter emoticons.

: Enter a subject.

: Set a specified time and date for a message to be sent.

Sending scheduled messages

While composing a message, tap →

•

If the device is turned off at the scheduled time, is not connected to the network,
or the network is unstable, the message will not be sent.

•

This feature is based on the time and date set on the device. The time and date
may be incorrect if you move across time zones and the network does not update
the information.

Schedule message

. Set a time and date and tap

Done

.

Adding contacts to the priority list

Set contacts that you communicate with frequently as priority contacts. Send them messages
by selecting a contact icon from above the messages list.

Tap

Tap to add priority senders.

Done

To remove contacts from the priority list, tap and hold a contact, and then tap

priority senders

. To add more contacts, tap .

→ →

Done

→

.

Inbox

or

Contacts

, select contacts to add, and then tap

Manage

78

Messages & email

Viewing incoming messages

Incoming messages are grouped into message threads by contact. Select a contact to view
the person’s messages.

You may incur additional charges for sending or receiving messages while you are
outside your home service area.

While viewing a message, tap

•

Video call

•

View contact

•

Add to Contacts

•

Quick responses

•

Add recipient

•

Insert smiley

•

Add subject

•

Add slide

•

Schedule message

•

Add to priority senders

them from the priority senders list.

•

Add to spam numbers

spam or remove a phone number from the spam list.

: Make a video call to the contact.

: View the contact’s information.

: Add the contact to the contacts list.

: Enter a message by selecting one from message templates.

: Add recipients to send the message to.

: Enter emoticons.

: Enter a subject.

: Add message slides.

: Set a specified time and date from a message to be sent.

to use one of the following options:

/

Remove from priority senders

/

Remove from spam numbers

: Add contacts to or remove

: Identify a phone number as

•

Discard

•

Font size

: Cancel composing the message.

: Change the font size of text in the text field.

79

Messages & email

Managing messages

While viewing the list of messages, tap and use the following options:

•

Select

•

Delete

•

Draft messages

•

Locked messages

•

Scheduled messages

•

Spam messages

•

Font size

•

Settings

•

Help

: Select messages to delete or to identify them as spam.

: Delete all or selected messages.

: View messages saved for later delivery.

: View locked messages.

: View scheduled messages.

: View spam messages.

: Change the font size.

: Change message settings.

: Access help information about sending and managing messages.

Email

Setting up email accounts

Tap

Email

Set up an email account when opening

Enter the email address and password. Tap
Mail, or tap
instructions to complete the setup.

To set up another email account, tap

Sending messages

Tap

Email

Tap

on the Apps screen.

Email

Manual setup

on the Apps screen.

at the bottom of the screen. Enter recipients, subject, and message, and then tap .

for a company email account. After that, follow the on-screen

→

for the first time.

Next

for a private email account, such as Google

Manage accounts

→ .

Tap

Tap

Tap

to add a recipient from the contacts list.

to attach images, videos, and others.

→ to insert images, events, and others into the message.

80

Messages & email

Delete the message.

Sending scheduled messages

While composing a message, tap →
date, and then tap

•

If the device is turned off at the scheduled time, is not connected to the network,

Done

.

or the network is unstable, the message will not be sent.

•

This feature is based on the time and date set on the device. The time and date
may be incorrect if you move across time zones and the network does not update
the information.

Reading messages

Tap

Email

Tap
new messages, tap

Tap a message to read.

on the Apps screen.

, select an email account to use, and new messages are retrieved. To manually retrieve

.

Schedule email

. Tick

Schedule email

, set a time and

Add this email address to the

contacts list.

Forward the message.

Reply to all recipients.

Reply to the message.

Access additional options.

Open attachments.

Mark the message as a reminder.

Go to the previous or next
message.

81

Messages & email

Adding contacts to the priority list

Set contacts that you communicate with frequently as priority contacts.

Tap
email addresses or select contacts to add, and then tap

To add more contacts to the priority list, tap

To remove contacts from the priority list, tap and hold a contact, tap

senders

→

Priority senders

, tap on each contact, and then tap

→

Tap to add priority senders

.

Done

→

Enter email

OK

or

Done

.

Google Mail

Use this app to quickly and directly access the Google Mail service.

Tap

Google Mail

•

This app may not be available depending on the region or service provider.

•

This app may be labelled differently depending on the region or service provider.

Sending messages

on the Apps screen.

or

Contacts

.

Edit list of priority

, enter

Tap , enter recipients, a subject, and a message, and then tap .

82

Messages & email

Delete the message.

Reading messages

Tap a message to read.

Keep the message for long-term

storage.

Mark the message as a reminder.

Preview attachment.

Mark the message as unread.

Access additional options.

Reply to the message.

83

Camera

Taking photos or videos

About taking photos or videos

Use this app to take photos or videos.

Use

Gallery

content on the device’ for details.

Camera etiquette

•

Do not take photos or videos of other people without their permission.

•

Do not take photos or videos where legally prohibited.

•

Do not take photos or videos in places where you may violate other people’s privacy.

to view photos and videos taken with the device’s camera. Refer to ‘Viewing

•

The camera automatically shuts off when unused.

•

Make sure that the lens is clean. Otherwise, the device may not work properly in
some modes that require high resolutions.

•

The front camera lens is suitable for taking wide-angle photos. Minor distortion
may occur in wide-angle photos and does not indicate device performance
problems.

Tap

1

2

Camera

Tap the image on the preview screen where the camera should focus.

When the subject is in focus, the focus frame turns green.

on the Apps screen.

84

Camera

Display current

Tap to take a photo or to take a video.

3

•

To change the focus while taking a video, tap where you want to focus. To focus on the
centre of the screen, tap

•

To capture an image from the video while recording, tap .

Switch between the

front and rear

camera.

Activate or

deactivate selective

focus mode.

Activate or

deactivate HDR (Rich

tone).

Change camera

settings.

.

mode.

Start taking a video.

Take a photo.

Change the
shooting mode.

View photos and
videos you have
taken.

Viewing photos or videos

You can view photos or videos immediately after taking them by opening the preview
thumbnail on the camera screen.

Tap the preview thumbnail at the bottom right of the screen.

85

Camera

Without effect With effect

Using the HDR (Rich tone) effect

Take photos with rich colours and reproduce details even in bright and dark areas.

On the Apps screen, tap

Camera

→ , and then take a photo.

Using selective focus mode

Use the out-of-focus effect to blur the background and make your subject stand out.

86

Camera

Before using this mode

•

It is recommended that you position subjects between 10-50 cm from the device. Place
subjects that you want to focus on close to the device.

•

When taking photos, ensure there is sufficient distance between the subject and the
background. The distance should be more than twice the distance between the device
and the subject.

•

The quality of photos taken by the device may be affected in the following situations:

–

Photos of subjects that are moving.

–

Photos that are taken when the device is moving.

–

Indoor photos, low-light conditions, or if there is strong light behind a subject.

–

Photos using a background that cannot be distinguished from the subject, such as
shadows or plain-coloured walls.

Tap

1

2

3

4

5

6

Camera

Tap at the right side of the screen.

does not appear, tap →

If

Tap the image on the preview screen where the camera should focus.

When the subject is in focus, the focus frame turns green.

Tap to take a photo.

Tap the preview thumbnail at the bottom right of the screen to edit the photo.

Tap and select one of the following:

•

Near focus

•

Far focus

on the Apps screen.

Selective focus

: Make the subject stand out and blur the background around the subject.

: Blur the subject and make the background stand out around the subject.

to activate it.

7

•

Pan focus

Tap

Done

: Make the subject and its background stand out.

.

87

Camera

Launching Camera on the locked screen

To quickly take photos of special moments, launch

On the locked screen, drag outside the large circle.

1

Tap the image on the preview screen where the camera should focus.

2

When the subject is in focus, the focus frame turns green.

Tap to take a photo or to take a video.

3

Camera

on the locked screen.

Using the shooting mode

Several photo effects are available.

On the Apps screen, tap

•

Auto

: Use this to allow the camera to evaluate the surroundings and determine the ideal

mode for the photo.

Camera

→

MODE

.

•

Beauty face

•

Shot & more

identifies the photos with

•

Panorama

identifies the photo with

To get the best shot, follow these tips:

–

Move the camera slowly in one direction.

–

Keep the camera’s viewfinder within the guide frame.

–

Avoid taking photos of a subject in front of unrecognisable backgrounds, such as
empty skies or plain walls.

: Take a photo with lightened faces for gentler images.

: Take a series of photos and apply various effects to them. The device

in

: Take a photo composed of many photos strung together. The device

in

Gallery

Gallery

.

.

88

Camera

•

Virtual tour shot

: Take photos of a space by moving the device and shooting from

different angles to create a stereoscopic image. The device identifies the photo with

Gallery

•

Dual Camera

image captured by the front camera appears in an inset window in the image taken by
the rear camera, or vice versa.

•

Download

.

: Take landscape photos or videos with the rear or the front camera. The

: Download more shooting modes from

Samsung Apps

.

Using shot & more mode

About shot & more mode

Use this mode to take a series of photos and modify them by applying various effects using
the shooting modes.

The zoom function is not available while taking photos in this mode.

in

Tap

1

2

3

4

Camera

Tap

MODE

Tap .

The device takes a series of photos and displays the available shooting modes.

Select a shooting mode and apply an effect to the photos.

•

Best photo

series, scroll left or right. The device recommends the best photo and identifies it with

.

on the Apps screen.

→

Shot & more

: Take a series of photos and save the best one. To view other photos in the

.

89

Camera

•

Best face

best possible image. Tap the white frame on each face and choose the best individual
pose for each subject from the poses that appear at the bottom of the screen. Then,
merge the images into a single photo. The device recommends the best photo and

: Take multiple group shots at the same time and combine them to create the

identifies it with

•

Drama shot

motion trails.

•

5

Eraser

•

Panning shot

appear to be moving fast. Tap
the angle of blurring to apply to the background. Tap
finger around the large circle to adjust the angle of blurring. To adjust the level of
background blurring, drag the screen to the left or the right.

Tap .

: Erase moving objects in the background. Tap to erase moving objects. Tap

to restore the original photo.

Drama shot

Tap

1

Camera

on the Apps screen.

.

: Take a series of photos and combine them to create an image that shows

: Apply an effect to the subject’s background that makes the subject

Object

to select a subject. Tap

and draw a circle with your

Motion blur

to change

Tap

2

3

4

5

MODE

Tap .

The device takes a series of photos and displays available effects.

When you are finished taking photos, tap

Select more photos that have motion trails you want to use at the bottom of the screen.

To edit the motion trails of selected photos, tap

Tap
photo as desired and tap

→

Shot & more

to display subject’s motion trails or tap to erase the motion trails. Edit the

.

Done

Drama shot

.

.

and select a photo.

90

Camera

are available.

Tap to save.

6

To get the best shot, follow these tips. The device may not take photos properly in
other shooting conditions.

•

Hold the camera steady and remain still while taking photos.

•

Take photos of a subject that is moving in one direction.

•

Take photos with backgrounds that are free of moving objects.

•

Avoid taking photos of a subject and background with similar colours.

Using dual camera mode

When you take a landscape photo with the rear camera, the photo or video captured by the
front camera appears in an inset window, or vice versa. Use this feature to take a beautiful
landscape photo and a self-portrait simultaneously.

On the Apps screen, tap
Tap

to take a photo or tap to take a video.

Switch between the

front and rear

camera.

Tap to resize it or

move the location.

•

You can record videos in dual camera mode for up to 5 minutes in Full HD and up

Camera

→

MODE

→

Dual Camera

to switch to dual camera mode.

Select among
various styles that

to 10 minutes in HD or VGA.

•

While taking videos in this mode, sound is recorded by the internal microphone.

91

Camera

Using virtual tour mode

About virtual tour mode

Use this shooting mode to take photos in a space by moving forwards, and rotating left
or right. Photos of the space are taken from different angles. You can view the photos in a
slideshow and simulate actually moving through the space.

Tap

1

2

3

Camera

Tap

MODE

Move with the device to position the dot inside the large circle in the centre of the
preview screen. The device detects when you stop and starts to take photos from that

on the Apps screen.

→

Virtual tour shot

.

position in the space.

Move slowly forwards, or rotate left or right while taking photos. Whenever the dot is

4

inside the large circle, the device takes a photo automatically.

92

Camera

Move with the device slowly in the direction of the arrow. When the dot is in the centre of

5

the large circle, the device starts taking photos. Repeat this action to take more photos.

To see a preview of the photo, tap
images were taken is displayed on each preview thumbnail.

To delete the last photo that was taken, tap

To finish, tap .

6

at the bottom left of the screen. The direction where

Undo

.

Viewing photos

View a series of photos taken from different locations and directions.

On the Apps screen, tap

1

Select an image with the icon on the image thumbnail.

2

Tap .

3

The device displays the photos in a slideshow.

Gallery

.

Drag to view the

photo from other

locations and

directions.

Start or pause the

slideshow.

Display movement
paths.

93

Camera

Applying filter effects

Use the filter effects to take unique photos or videos.

Tap

1

Camera

on the Apps screen.

Tap →

2

To download more effects, tap

To change the order of effects or hide effects from the list, tap

Effects

, and then select an effect to apply.

Download

.

Using the zoom feature

Zoom in and out the screen when taking photos or videos.

Manage effects

.

Use one of the following methods:

•

Spread two fingers apart on the screen to zoom in, and pinch to zoom out.

The zoom in/out effect is available when using the zoom feature while shooting
video.

94

Camera

Using remote viewfinder mode

Use your device as a viewfinder for another device. You can control the other device remotely
to take photos or videos from a distance. Your device displays the same image that is
displayed on the connected device.

Tap

1

2

3

4

5

Camera

Tap →

Tap

Easily connect via NFC

•

Easily connect via NFC

•

Wi-Fi Direct settings

Tap the image on the preview screen where the device should focus.

Tap to take the photo displayed on the connected device’s viewfinder.

Ensure that the device you want to connect to supports the remote viewfinder mode.

on the Apps screen.

Remote viewfinder

or

: Activate the NFC feature on both devices.

: Activate the Wi-Fi Direct feature on both devices.

.

Wi-Fi Direct settings

to connect to another device.

95

Camera

Changing Camera settings

Reorganising camera shortcuts

On the Apps screen, tap

1

Tap and hold an item and drag it to a slot at the left of the screen.

2

You can reorganise camera shortcuts for fast and easy access on the preview screen.

Camera

→ .

Configuring settings

On the Apps screen, tap
still camera and video camera modes. The available options vary depending on the mode
used.

•

Picture size

more memory.

•

Burst shots

•

Picture stabilisation

the brightness of the photo without the flash.

This option is not available when you take videos.

: Select a resolution. Use higher resolution for higher quality. But it takes up

: Take a series of photos of moving subjects.

Camera

: Set the device to automatically detect darker conditions and adjust

→ . Not all of the following options are available in both

96

Camera

•

Face detection

them.

•

ISO

: Select an ISO value. This controls camera light sensitivity. It is measured in film­camera equivalents. Low values are for stationary or brightly-lit objects. Higher values are
for fast-moving or poorly-lit objects.

•

Metering modes

: Set the device to recognise people’s faces and help you take photos of

: Select a metering method. This determines how light values are
calculated.
measures the light value at a specific location.

•

Tap to take pics.

•

Selective focus

•

Video size

more memory.

•

Recording mode

•

Video stabilisation

camera is moving.

•

Audio zoom

•

Effects

•

Flash

: Activate or deactivate the flash.

•

Timer

•

HDR (Rich tone)

Centre-weighted

: Tap the image on the preview screen to take photos.

: Use this to take a photo with an out-of-focus effect.

: Select a resolution. Use higher resolution for higher quality. But it takes up

: Change the recording mode.

: Activate or deactivate anti-shake. Anti-shake helps focus when the

: Make the sound from the zoomed subject louder while recording.

: Select among various effects that are available.

: Use this for delayed-time shots.

: Use this to improve the contrast ratio in photos. HDR enhances the

measures background light in the centre of the scene.

Matrix

averages the entire scene.

Spot

details in areas affected by too much or too little light.

•

Location tag

•

To improve GPS signals, avoid shooting in locations where the signal may be
obstructed, such as between buildings or in low-lying areas, or in poor weather
conditions.

•

Your location may appear on your photos when you upload them to the Internet.
To avoid this, deactivate the GPS tag setting.

: Attach a GPS location tag to the photo.

97

Camera

•

Storage

•

Review pics/videos

•

Remote viewfinder

take photos or videos.

•

White balance

range. The settings are designed for specific lighting situations. These settings are similar
to the heat range for white-balance exposure in professional cameras.

•

Exposure value

camera’s sensor receives. For low-light situations, use a higher exposure.

•

Guide lines

•

Voice control

•

Help

: Select the memory location for storage.

: Set the device to show photos or videos after taking them.

: Set the device to use as a viewfinder and control the other device to

: Select an appropriate white balance, so images have a true-to-life colour

: Change the exposure value. This determines how much light the

: Display viewfinder guides to help composition when selecting subjects.

: Set the device to take photos with voice commands.

: Access help information for using the camera.

•

Reset

: Reset the camera settings.

98

Gallery

Launch Camera.

Search for images or videos.

Viewing content on the device

Tap

1

Gallery

on the Apps screen.

Sort images or videos by time,

album, and more.

Select an image.

2

Access additional options.

Images and videos

•

Selecting multiple images:

When you tap and hold an image,
select more.

•

Selecting all images:

When you tap and hold an image,

Select all

.

appears on the image. Then, tap images to

appears on the image. Then, tap

99

1 selected

→

Gallery

Modify the image.

Send the image to others.

Select an option.

3

Move to the previous screen.

Search for other devices to view

the image.

Viewing content stored on other devices

Access additional options.

Delete the image.

You can view content stored on other devices if the devices are registered with Samsung Link.
Sign in to your Samsung account to view a list of other devices that have content available
to view. Ensure that the registered devices are turned on and connected to a Wi-Fi or mobile
network. Visit

link.samsung.com

for more information.

You may incur additional charges when you view content stored on other devices via
the mobile network. To avoid additional charges, use the Wi-Fi feature.

Tap

, select a device under

CONNECTED DEVICES

, and then select content.

100
