Samsung SHG-220, SHG-220S User Manual

OUTDOOR HOUSING

SHG-220/SHG-220S

Installation Manual
Instalationshandbuch
Manuel D’installation

Manual De Instalación

GB

D

F

E

C

J

K

IMPORTANT SAFEGUARDS

1. Read Instructions - All the safety and operating instructions should be read before the
unit is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future
reference.

3. Heed Warnings - All warnings on the unit and in the operating instructions should be
adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Attachments - Do not use attachments not recommended by the product manufacturer
as they may cause hazards.

6. Accessories - Do not place this unit on an unstable stand, tripod, bracket, or mount.
The unit may fall, causing serious injury to a person and serious damage to the unit.
Use only with a stand, tripod, bracket, or mount recommended by the manufacturer or
sold with the product. Any mounting of the unit should follow the manufacturer's
instructions and should use a mounting accessory recommended by the
manufacturer. An appliance and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.

7. Power Sources - This unit should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply you plan
to use, consult your appliance dealer or local power company. For units intended to
operate from battery power or other sources, refer to the operating instructions.

8. Power Lines - An outdoor system should not be located in the vicinity of overhead
power lines or other electric light or power circuits or where it can fall into such power
lines or circuits. When installing an outdoor system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
U.S.A. models only - refer to the National Electrical Code Article 820 regarding
installation of CATV systems.

9. Servicing - Do not attempt to service this unit yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.

10. Replacement Parts - When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the
same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

11. Safety Check - Upon completion of any service or repairs to this unit, ask the service
technician to perform safety checks to determine that the unit is in proper operating
condition.

12. Coax Grounding - If an outside cable system is connected to the unit, be sure the
cable system is grounded. U.S.A. models only--Section 810 of the National Electrical
Code, ANSI/NFPA No.70-1981, provides information with respect to proper grounding
of the mount and supporting structure, grounding of the coax to a discharge unit, size
of grounding conductors, location of discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.

1

FCC & ICES INFORMATION (U.S.A.AND CANADIAN MODELS ONLY)

WARNING - This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules and ICES-003 of Industry
Canada. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential installation. This equipment
generates, uses, and radiates radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the interference at
his own expense. Intensional or unintensional changes or modifications not expressly
approved by the party responsible for compliance shall not be made. Any such changes
or modifications could void the user’s authority to operate the equipment.

If necessary, the user should consult the dealer or an experienced radio/television
technician for corrective action. The user may find the following booklet prepared by the
Federal Communications Commission helpful: "How to Identify and Resolve Radio-TV
Interference Problems." This booklet is available from the U.S. Government Printing
Office, Washington, DC 20402, Stock No.004-000-00345-4.

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC

SHOCK. DO NOT OPEN!

GB

CAUTION:

TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

This label may appear on the bottom of the unit due to space limitations.

The lightning flash with an arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert
the user to presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

2
