페이지 1 / 1SAMSUNG External DVD Writer User's Manual
Index Safety Precautions Features Installing Device Driver How to Use Storing/Cleaning Troubleshooting Specificatio
Samsung's OMS (Optical Media Solution) Customer Support Website
(http://www.samsung-ODD.com) offers the latest versions of firmware for ODD products,
user instructions and product information.
Select Lang
English
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩index.htm
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Main Page
Safety Precautions
Safety Precautions
During Installing
During Operating
Others
RoHS & WEEE
Install the External DVD Writer
Installing Drive
Removing USB Converter cable
Features
Device Driver
Select Languages
English
Exterior
System Requirements
Features
Checking USB 2.0 and Installing USB
Driver
Firmware Update
Confirming the Installation of Device Driver
How To Use External DVD Writer
How to Use the Drive
How to Use DVD±R/RW and Other Discs
How to use the TruDirect
Troubleshooting
Troubleshooting
Caution: Possible Errors
Storing/Cleaning
Storing the Disc
Cleaning the Disc
When the LED Blinks
Specifications
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩index₩i...
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
This symbol indicates explanations about extremely dangerous matters. If users ignore this
symbol and handle the device the wrong way, serious injury or death could result.
This symbol indicates explanations about dangerous matters. If users ignore this symbol and
handle the device the wrong way, damage to home or property could result.
Important to read and understand at all times
Do not disassemble
Always make sure that the disc does not have a crack before use. If the disc has a crack (especially
around the center hole), it is recommended to make a copy immediately and use the copy instead.
When a cracked disc is used continuously, the size of the crack is likely to grow and this will
eventually result in irreparable damage to the disc.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩safety...
A
A
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
Do not drop the drive, and protect it from severe shocks.
- It can damage the drive or cause it to malfunction.
Do not place the drive in direct sunlight.
void low-or high-temperature environments.
void high-humidity environments.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩safety...
페이지 1 / 2SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
Handle with caution to prevent damage from an external shock.
Do not drop the drive, and protect it from severe shocks.
- It can damage the drive or cause it to malfunction.
Do not move the drive while in operation.
Make sure to close all working programs before attempting to open and
always use the open button.
Do not insert a pin into the emergency eject hole while in operation.
Do not use cracked, distorted or damaged discs.
In particular, a disc with a crack on the inner tracks may break
while in use.
Do not disconnect the power cord while the drive is working.
-This may result in an operational error.
Do not put any heavy things on the drive.
Always check to be sure the disc is not cracked before use. If you find a crack on the disc
(especially around the center hole), make a copy of the disc immediately and use the copy instead.
Continued use of a cracked disc will cause the crack to become bigger, resulting in irreparable damage
to the disc.
Do not use low-quality discs (illegal, scratched, damaged, etc.).
Samsung is not responsible for any loss resulting from the use of such discs.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩safety...
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
Never allow food particles or foreign substances to enter the drive
casing.
To protect against the risk of fire, do not spill such liquids as
alcohol and benzene on the drive.
Do not disassemble, attempt to repair or modify the device
without an express approval as directed in the manual.
- To reduce the risk of damage, electric shock and fire.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩safety...
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
Samsung Eco-mark
The Samsung’s own Eco mark helps
consumers to easily understand that
Samsung develops eco-friendly
products. This mark represents
Samsung’s continuous effort to develop
eco-friendly products.
(Restriction of the use of certain hazardous substances in electrical and electronic equipment)The
RoHS
RoHS, the environmental regulation announced by European Union, restricts the use of lead , mercury,
cadmium, hexavalent chromium, PBB, and PBDE in products put on the market in The European Union
after July 1, 2006.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other Europ ean countries with separate collection systems)
This mark shown on the product or its literature, indicates that it should not be disposed
with other household wastes at the end of its working life. T o prevent possible harm to the
environment or human health from a uncontrolled waste disposal, plea se separate this
from other types of wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for
disposal.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩safety...
A
페이지 1 / 2SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
LED
1.
Emergency Eject Hole
3.
Open Button
2.
z
Design and specifications are subject to change without prior notice.
USB Interface Port
1.
Setup guide
pplication software & User manual CD
(software: Nero Express 7 Essentials, InCD5, Nero Vision Essentials, Nero ShowTime Essentials, Nero
BackItUp Essentials, Nero Recode Essentials, TruDirect)
2 port Usb cable, Usb extension cable
Eject Pin, Pouch
z
The type of accessories varies depending on a product model.
and some accessories described herein are subject to change without notice.
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩feature...
y
페이지 1 / 1SAMSUNG DVD±R/RW Drive User's Manual
Select Languages
English
You need to have an IBM-compatible PC with the following specifications.
Item Description
OS
CPU
RAM
Interface
The drive's performance may not be able to achieve its ma ximum performance according to the PC
s
stem environment.
Microsoft Windows 2000(SP4)/XP(SP 1.0 or higher)/Vista
Pentium4 2.0GHz or above
512Mbytes or greater
USB 2.0 Interface connector
10/9/2008file://D:₩CD 3 LED수정된CD₩SE-T084M_Tru_0514₩manual₩T084M₩2₩en₩feature...
