4 CHANNEL DVR
User Manual
SDS-P3040
4 Channel DVR
User Manual
Copyright
©
2013 Samsung Techwin Co., Ltd. All rights reserved.
Tra de mar k
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced, distributed or
changed, partially or wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided.
Use of this document and the subsequent results shall be entirely on the user's own responsibility. Samsung Techwin reserves the right to change the
contents of this document without prior notice.
Design and specifications are subject to change without prior notice.
The default password can be exposed to a hacking thread so it is recommended to change the password after installing the pro duct.
Set password for your wireless network if you use the product with a wireless router. Being not protected with password or using the
default wireless router password may expose your video data to potential threat.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
is the registered logo of Samsung Techwin Co., Ltd.
overview
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit.
Follow all the safety instructions listed below.
Keep these operating instructions handy for future reference.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
OVERVIEW
English _3
overview
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION
: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of electric shock is present within
this unit.
This exclamation point symbol is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING
• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
WARNING
1. Be sure to use only the standard adapter that is specified in the specification sheet.
Using any other adapter could cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or
damage to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat
generation or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
5. When installing the camera, fasten it securely and firmly. The fall of camera may cause personal injury.
6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water on
top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
8. If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately
disconnect the power source and contact the service center. Continued use in such a condition may cause fire
or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this
product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted
repair.)
10. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
11. Do not expose the product to the direct airflow from an air conditioner.
Otherwise, it may cause moisture condensation inside the Clear Dome due to temperature difference between
internal and external of the dome camera.
12. If you install this product in a low-temp area such as inside a cold store, you must seal up the wiring pipe with
silicon, so that the external air can not flow inside the housing.
Otherwise, external high, humid air may flow inside the housing, pooling moisture or vapor inside the product
due to a difference between internal and external temperature.
4_ overview
BEFORE START
This user manual provides Information for using the DVR such as brief introduction, part names, functions, connection
to other equipment, menu setup, etc.
You have to keep in mind the following notices :
SAMSUNG retains the copyright on this manual.
This manual cannot be copied without SAMSUNG’s prior written approval.
We are not liable for any or all losses to the product incurred by your use of non-standard product or violation
of instructions mentioned in this manual.
Prior to opening the case, please consult a qualified technician first. Whenever this is needed power must be
removed from the unit.
Before installing an additional HDD or connecting an external storage device (USB memory or USB HDD) to
this DVR, check the compatibility. Consult your provider for the compatibility list.
Warning
Battery
It is essential that when changing the battery in the unit, the replacement battery must be of the same type
otherwise there may be a possibility of an explosion.
The following are the specifications of the battery you are using now.
• Normal voltage : 3V
• Normal capacity : 170mAh
• Continuous standard load : 0.2mA
• Operating temperature : -20°C ~ +85°C (-4°F ~ +185°F)
OVERVIEW
Caution
• Connect the power cord into a grounded outlet.
• The Mains plug is used as a disconnect device and shall stay readily operable at any time.
• Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the
Instructions.
System Shutdown
Turning off the power while the product is in operation, or undertaking improper actions may cause damage
or malfunction to the hard drive or the product.
Please right-click to display the context sensitive menu and select <Shutdown>.
After selecting <OK> in the pop-up menu, you can pull off the power cord.
You may want to install a UPS system for safe operation in order to prevent damage caused by an
unexpected power stoppage. (Any questions concerning UPS, consult your UPS retailer.)
English _5
overview
Operating Temperature
The guaranteed operating temperature range of this product is 0°C ~ 40°C (32°F ~ 104°F).
This product may not work properly if you run right after a long period of storage at a temperature below the
guaranteed one.
Prior to using a device that has been stored for a long period in low temperatures, allow the product to stand
at room temperature for a period.
Especially for the built-in HDD in the product, its guaranteed temperature range is 5°C ~ 55°C (41°F ~ 131°F).
Likewise, the hard drive may not work at a temperature below the guaranteed one.
Security Precautions
The default password can be exposed to a hacking thread so it is recommended to change the password
after installing the product.
Set password for your wireless network if you use the product with a wireless router. Being not protected with
password or using the default wireless router password may expose your video data to potential threat.
Note that the security and other related issues caused by the unchanged password shall be responsible for
the user.
6_ overview
CONTENTS
OVERVIEW
3
CONNECTING WITH OTHER DEVICE
15
LIVE
21
3 Important Safety Instructions
5 Before Start
7 Contents
9 Features
11 Part Names and Functions (Front)
12 Part Names and Functions (Rear)
13 Remote Control
15 Installation
15 Checking the installation environment
16 Connecting the Video, Audio and Monitor
16 Connecting the USB
17 Connecting the Camera (SDC-5340BC)
19 Connecting the RS-485 Device
19 Connecting the Network
21 Getting Started
23 Live Screen Configuration
28 Live Mode
30 Zoom
30 Audio On/Off
30 Freeze
31 Event Monitoring
OVERVIEW
MAIN MENU
32
32 System Setup
44 Setting the Device
51 Setting the Recording
55 Setting the Event
57 Backup
58 Network Configuration
72 Controlling a PTZ device
English _7
overview
SEARCH & PLAY
75
WEB VIEWER
80
BACKUP VIEWER
107
75 Search
78 Playback
80 Introducing Web Viewer
81 Connecting Web Viewer (Mac)
82 Using Live Viewer (Mac)
83 Connecting Web Viewer (Windows)
84 Using Live Viewer (Windows)
90 Using Search Viewer
94 Viewer Setup
104 About
105 Mobile Viewer
107 SEC Backup Viewer
APPENDIX
110
110 Product Specification(Camera)
111 Product Specification(DVR)
113 Default Setting
116 Troubleshooting
119 Open Source License Report on the Product
8_ overview
FEATURES
The DVR employs H.264 video encoding for 4 channel inputs and audio encoding for 1 channels while simultaneously
supports hard disc recording and playback.
These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video
and audio data.
Provides a convenient User Interface
Supports CIF(S)/2CIF(M)/4CIF(L) recording formats
With the network specific codec, network transfer enabled regardless of the recording conditions
De-interlacing processor for better picture quality
Display of HDD information and status by using HDD SMART
Hard Disk overwrite function
Mass storage hard disk backup through high-speed USB 2.0
Simultaneous Record and Playback of 4 channel video data
Various Search Modes (Search by Time, Event, Backup and Motion Detection)
Various Recording Modes (Manual, Event, Scheduled Recording)
Alarm Interface
Remote Monitoring function by Network Viewer, Smart Viewer and Mobile Viewer
Standards Approvals
OVERVIEW
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
M
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
English _9
overview
Package Contents
Please unwrap the product, and place the product on a flat place or in the place to be installed.
Please check the following contents are included in addition to the main unit.
Package
POWER
REC
DVR (1SET) Adapter (1EA) / Power Cable (1EA) Mouse (1EA)
Remote Control (1EA) / Battery (2EA) SDC-5340BC (4SET) Camera Cable (4EA)
Camera Power Cable (1EA) Network Cable (1EA) Expansion pipe and Screw (12EA)
DIGITAL VIDEO RECORDER
10_ overview
Manual CD (1EA) Quick Start Guide (1EA) Warranty Card (1EA)
PART NAMES AND FUNCTIONS (FRONT)
POWER
REC
cb
Part Names Functions
USB Port Connects the USB devices.
DIGITAL VIDEO RECORDER
OVERVIEW
b
c
Remote Control
Receiver
LED Indicator
Input the remote control signal.
POWER : Displays the power ON/OFF status.
REC : Lights on when recording is in progress.
English _11
overview
PART NAMES AND FUNCTIONS (REAR)
SDR-3100
12
34
b c
AUDIO IN
VIDEO OUT
AUDIO OUT
VGA
Part Names Functions
CAMERA IN Video Signal input ports (BNC type connector).
VIDEO OUT Video Signal Output Port (RCA jack).
b
AUDIO IN Audio input signal port (RCA jack, CH1).
c
Ground
NETWORK NETWORK connector port.
DC 12V DVR power input port.
USB USB connector port.
Port to connect a separate earth-grounding cable.
Add a separate earth-grounding cable to use your product safely.
ALARM IN ALARM OUT
1 2 3 4 G 1 COM G
NETWORK
DC 12V
CONSOLE
USB
M
12_ overview
RS-485 Used to establish RS-485 communications.
VGA VGA Video Signal Output Port.
AUDIO OUT Audio Signal Output Port (RCA jack).
[CONSOLE] is designed for the service repair purpose only.
If using the VGA cable, the source from VGA will be displayed as main image on the screen along with the OSD
menus. Then, the BNC port will output the video signal alone.
If not using the VGA cable, the source from BNC will be displayed as main image on the screen along with the OSD
menus. If you connect the VGA cable after the system boot, only the video signal from VGA will be displayed.
REMOTE CONTROL
Displays the search menu.
Changes the screen mode.
Displays the Exit pop up screen.
Used as the numeric input keys, or displays a single
Skip Backward (by unit time),
Slow Rewind, Slow Forward,
Skip Forward (by unit time)
Goes to the system menu screen.
Up/Down/Left/Right(
Moves the cursor up/down/left/right, and runs the
Freezes the screen temporarily.
Runs the digital zoom (x2) function.
Starts or ends the live recording.
SEARCH
MODE
POWER
NUMBER [0~+10]
channel.
T/W
Zooms in or out.
MENU
)/ENTER
▲▼◄ ►
Select Menu.
FREEZE
ZOOM
REC
BACKUP
Displays the Backup Menu.
DVR
Activates the DVR function.
ID
Sets the ID of the system.
Select 2 digits from 0 ~ 9 while pressing the ID Key.
Move Frame
While paused, moves to the previous/next frame.
FR, STOP, PLAY/PAUSE, FF
SCROLL
Moves the menu scroll.
RETURN
Returns to the previous screen.
AUDIO
Turns Audio on/off.
ALARM
Cancels the Alarm.
REC LOCK
Selects the recording lock function.
PIP
Selects or deselects the PIP function.
,.
OVERVIEW
EP10-000522
English _13
overview
Using the Numeric buttons
1. Press any button among 1 to 4.
2. Move to the selected channel number.
Changing the Remote Control ID
1. Press the ID button of the remote control and check the ID displayed on the DVR screen.
The factory default ID of the remote control is 00.
2. Enter 2 digits of your selection in order, while pressing the system [ID] button.
3. When ID input is done, press the system [
If you want to change the remote control ID to 08: Press 0 and 8 in order while the system [ID] button is pressed.
M
Remote control's ID and DVR’s ID should be matched for proper operation. Refer to “
ID] button again to check the setting.
Remote Devices”. (Page 48)
14_ overview
connecting with other device
INSTALLATION
Please take note of the followings before using this product.
Do not use the product outdoor.
Do not spill water or liquid in the connection part of the product.
Do not impose the system to excessive shock or force.
Do not pull out the power plug forcefully.
Do not disassemble the product on your own.
Do not exceed the rated input/output range.
Use a certified power cord only.
For the product with an input ground, use a grounded power plug.
CHECKING THE INSTALLATION ENVIRONMENT
CONNECTING WITH OTHER DEVICE
Samsung Digital Video Recorder (“DVR” hereinafter) is a stateof-art security device, and contains mass storage hard disk(s)
and critical circuits inside.
When the temperature rises inside the product, the product
may breakdown and the product life be shortened.
Temperature
Unit: ºC
One Year: 24HR X 365 DAY =8,760 HR
One Year: 24HR X 365 DAY =8,760 HR
Life (Unit: HOURS)
English _15
connecting with other device
1
2
3
4
G1
COM
G
ALARM IN
ALARM OUT
NETWORK
USB
CONSOLE
VGA
AUDIO IN
AUDIO OUT
VIDEO OUT
DC 12V
CONNECTING THE VIDEO, AUDIO AND MONITOR
+ -
RS 485
Only one mouse port is available.
M
CONNECTING THE USB
1. By factory default, a USB port is provided for external connection.
2. You can connect a USB HDD, USB memory or mouse to the USB port.
3. If a USB HDD is connected to the system, recognition and settings are available in “Main Menu > Setting the
Device > Storage Device”. (Page 46)
4. This product supports hot-plugging, which connects/removes the USB device during the system operation.
If you use the USB device for Backup purposes, format it with FAT32 on PC if it is not formatted on the DVR.
J
16_ connecting with other device
CONNECTING THE CAMERA (SDC-5340BC)
Equipped with the IR LED and the illumination sensor, enables you to monitor at night as well as in daytime.
The camera is suitable for both internal and external use.
Please make sure not to fully expose the camera to rain. The camera must be installed under a shelter to avoid exposure to
excessive rain or moisture.
b
c
Name Description
IR LED These infrared LED's are controlled by the illumination sensor.
Lens Focal length of 3.6mm enables you to cover relatively longer range of monitoring.
b
Illumination Sensor Detects incoming light to control the IR LED.
c
CONNECTING WITH OTHER DEVICE
English _17
connecting with other device
1
23
4
G
1
COM
G
ALARM IN
ALARM OUT
NETWORK
USB
CONSOLE
VGA
AUDIO IN
AUDIO OUT
VIDEO OUT
DC 12V
Connecting with DVR
+ -
RS 485
Installing the camera
The camera can be installed on the wall, ceiling, shelf or a desired position using the provided bracket.
1. Select a position where you want to install the camera.
Make sure the selected position can sustain the weight of the camera.
2. Attach the camera bracket to the wall using the supplied screws.
• SDC-5340BC : (M4X L20).
M4 X L20
sized screws
3. Adjust the camera to target the video location and tighten the camera bracket handle on the camera
bracket.
Handle
Handle
4. Connect the camera cable to the camera.
You should be careful when installing the camera outdoors because the cable connectors may be wet with moisture
J
or pile up with impurities.
The camera satisfies the IP66 standard, and direct exposure to water or moisture may cause problem such as
condensation.
18_ connecting with other device
wall or ceiling
CONNECTING THE RS-485 DEVICE
1
2
3
4
G
1
COM
G
ALARM IN
ALARM OUT
NETWORK
USB
CONSOLE
VGA
AUDIO IN
AUDIO OUT
VIDEO OUT
DC 12V
Connect the rear [RS-485 +, –] port to the PTZ camera or system keyboard.
You can connect and control the PTZ camera which supports the RS-485
M
communication.
Check if the RS-485 device is compatible with the product first.
Pay attention not to change the polarity (+/-) of the RS-485 device when connecting it.
Depending on camera’s type, connection polarity can be different.
For further information, refer to the respective PTZ Camera’s documentation.
CONNECTING THE NETWORK
Connecting to Network through Ethernet (10/100BaseT)
+
RS-485
CONNECTING WITH OTHER DEVICE
Hub/Switcher
+ -
RS 485
NETWORK
RJ-45 Ethernet Cable
(Direct Cable)
Back Bone
Hub/Switcher
Windows
Network Viewer
English _19
connecting with other device
12
3
4
G
1
COMG
ALARM IN
ALARM OUT
NETWORK
USB
CONSOLE
VGA
AUDIO IN
AUDIO OUT
VIDEO OUT
DC 12V
1234G1COM
G
ALARM IN
ALARM OUT
NETWORK
USB
CONSOLE
VGA
AUDIO IN
AUDIO OUT
VIDEO OUT
DC 12V
Connecting to the Network using the router
+ -
xDSL or Cable Modem
RS 485
Broadband Router
NETWORK
xDSL or Cable Modem
DDNS Server
(Data Center)
Connecting to Network through ADSL
NETWORK
Phone(ADSL) Line
RJ-45 Ethernet Cable
(Direct Cable)
External Remote PC
+ -
RS 485
ADSL MODEM
Hub/Switcher
20_ connecting with other device
Windows
Network Viewer
live
GETTING STARTED
Starting the system
1. Connect the power cable of the DVR to the wall outlet.
It takes about 10 seconds to display the start screen after
M
booting.
2. You will see the initialization screen.
The initialization process will last about 1 minute.
If a new HDD is installed, the initialization process may
take longer.
3. The live screen appears with a beep.
Shutting Down the System
2013-01-01 01:10:25
2013-01-01
01:10:25
LIVE
REC
You can shut down the system only if you have logged into the DVR.
You require permission to shut down the system if you are not logged in as admin.
1. Press the [
right-click to display the context sensitive menu and select
POWER] button on the remote control or
2013-01-01 01:10:25
<Shutdown>.
2. The “
Shutdown” confirmation window appears.
Shutdown
3. Use the arrow keys on the remote control to move to
<
OK> and press the [ENTER] button or click <OK>.
The system will shut down.
4. Disconnecting the power cable for power off and
2013-01-01
01:10:25
reconnecting the power cable to restart.
For the permission management, refer to “Permission Management > Setting Permissions”. (Page 39)
M
Are you sure to shutdown?
OK Cancel
English _21
live
Login
To access a DVR or restricted menu, you should have logged in to the DVR.
1. In live mode, right-click any area of the screen.
You will see the context sensitive menu as in the right
figure.
2013-01-01 01:10:25
Scene Mode
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Login
2. Click <Login>.
The login dialog appears.
You can also see the login dialog to access a desired
menu by pressing the [MENU] button on the remote
control.
The login dialog will also appear if you press a menu button on
the remote control of the DVR when the corresponding menu
requires logging in.
After logged in, press [RETURN] on the remote control to display
the logout dialog.
By default, initial ID and password are set to “admin”, and “4321”.
The default password can be exposed to a hacking thread so it is recommended to change the password after
J
installing the product.
Set password for your wireless network if you use the product with a wireless router. Being not protected with
password or using the default wireless router password may expose your video data to potential threat.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
For the restricted permission, refer to “Permission Management > Setting Permissions”. (Page 39)
M
Locking All Buttons
This will restrict access to all buttons available in the DVR.
1. In Live mode, press buttons in the order of
[FREEZE][STOP (@)][FREEZE][MENU].
All buttons will be locked.
2. In the lock condition, press any button to display a dialog
where you are prompted to enter the password for
unlocking the buttons.
The button lock will be released if you enter the admin
password.
[STOP (@)]
2013-01-01 01:10:25
Login
ID admin
Password
OK Cancel
2013-01-01 01:10:25
Key Lock Password
ID admin
Password
OK Cancel
22_ live
LIVE SCREEN CONFIGURATION
CAM 01
Icons on the Live Screen
You can check the status or operation of the DVR with the icons on the live screen.
2013-01-01 00:00:01
CAM 01
Part Names Description
Current Date, Time Displays the current time and date.
Login Information When you are logged in, the “LOG ON” icon will be displayed.
b
Displayed if the zoom function is activated.
Freezes the screen temporarily.
LIVE
c
Screen Mode
System Operation
Video Input
Status
Displayed in Auto Sequence mode where all channels are switched at the specific
time interval.
This icon is displayed if a user with restricted access to the Record button tries to
make manual recording.
Only the user with the applicable permission can release (stop) the
recording.
Displayed if the HDD is full and the DVR has an insufficient space to record.
Displayed if no HDD is installed or the existing HDD should be replaced.
Displayed if the HDD needs a technical examination.
This will be displayed if the backup operation is in process.
Displayed if a new firmware is found from the network.
Displayed if no input is entered in the condition that the camera is set to <ON>.
Nothing will be displayed on the screen if the camera is set to <
OFF>.
English _23
live
Part Names Description
Camera Name/ Channel Displays the camera name and the changed channel, if any.
Displays the resolution of the recording screen. (Page 53)
Displayed in PTZ setting, and highlighted yellow if PTZ is in operation.
Displays AUDIO ON/MUTE.
Not displayed in video mode if deactivated.
Camera
Operation
Displayed if a motion detected in the condition that the motion detection is set to
<ON>.
Displays the current record mode from Record/Event/Schedule.
Error Information
• If the internal HDD is not connected, the “NO HDD”( ) message will appear; if there occurs a problem,
you will see the “HDD FAIL”(
) message in the top left corner. In this case, make sure you contact the
service center for assistance as this may cause a failure of recording, playback or backup.
If you see the NO HDD, HDD FAIL icons on the screen, contact the service center for more details.
M
Live Screen Menu
In addition to the buttons the remote control, you can access a desired menu by right-clicking the mouse any
area in live mode.
The context sensitive menu that appears by right-clicking the screen may differ, depending on the login/
logout, screen split mode and DVR operation mode.
Menu items of Search, Record, Backup, Shutdown can be deactivated, depending on the user permission.
M
24_ live
2013-01-01 01:10:25
Scene Mode
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
< Split Mode Menu >
2013-01-01 01:10:25
Scene Mode
PTZ Control
Zoom In
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
< Single Mode Menu >
Split Mode Menu
The context sensitive menu in split mode differs, depending on the login/logout status.
b
c
Menu Description
Scene Mode Refer to “Live Mode”. (Page 28)
Audio On/Off Refer to “Audio On/Off ”. (Page 30)
b
Freeze Refer to “Freeze”. (Page 30)
c
Stop Alarm Stops the alarm output and the event monitoring. Refer to “Event Monitoring”. (Page 31)
Record/Stop Starts/stops the standard recording.
Play Refer to “Search & Play > Play”. (Page 78)
Scene Mode
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
2013-01-01 01:10:25
LIVE
Search Refer to “Search & Play > Search”. (Page 75)
Backup Refer to “Main Menu > Setting the Backup”. (Page 57)
Main Menu Accesses the main menu. Refer to the Using the DVR section. (Page 32)
Shutdown Turns down the DVR.
Show/Hide Launcher Shows or hides the launcher. Refer to “View the Launcher Menu”. (Page 27)
Login/Logout You can log in or out.
English _25
live
Single Mode Menu
The single mode menu is available only in Single Mode.
The context sensitive menu for the One Channel mode, in Split mode is different from that of the Single mode.
2013-01-01 01:10:25
b
Menu Description
Full Screen
PTZ Control
Zoom In
Audio On
Freeze
Stop Alarm
Record
Play
Shutdown
Hide Launcher
Logout
Full Screen
Zoom In Enlarges the selected image. (Page 30)
b
Select and click a desired channel in Split mode to switch to the full screen of the selected
channel.
26_ live
View the Launcher Menu
The Launcher menu appears on the bottom of the live screen.
1. In Live mode, right-click to display the context menu and
select <Show Launcher>.
2. Move the cursor to the bottom and click a desired item in
the Launcher menu.
If no input is entered for 10 seconds, the menu will disappear.
M
The Launcher menu can be accessed only by using the mouse.
2013-01-01
01:10:25
2013-01-01 01:10:25
2013-01-01
01:10:25
LIVE
2013-01-01
01:10:25
AlarmPTZ Freeze
b c
Menu Description
Displays the current time and date.
Date/Time
Screen Mode
b
Menu Expansion Button Click to display the hidden menu to the right.
c
Audio Turns ON/MUTE the sound of the selected channel.
Zoom Enlarges the selected area. This is available only in Single Live mode.
PTZ
Alarm Stops the alarm if it's activated.
Freeze Freezes the Live screen temporarily.
The indication of AM/PM is displayed if you set 12 hours for the time format in “System >
Date/Time/Language > Time”. (Page 32)
Press this button to switch the screen mode in sequence.
The current mode is highlighted in white.
Runs the PTZ Control launcher.
The PTZ control launcher will be active on the Live screen after you select a single channel.
Play Enters Play mode if a file to play exist, and if not, enters Search mode.
Record Start/End recording the Live screen.
English _27
live
LIVE MODE
Displays 4 live video images in 3 different modes.
Switching the screen mode
To switch the split mode, select a screen mode in the launcher menu, or right-click to select a screen mode in
the context menu.
Press the [
items.
Switching the screen automatically
You can display 4 live single screens in sequence.
MODE] button on the remote control to switch the mode in the sequence of the launcher menu
CH1 CH2
CH3 CH4
4-split mode PIP Auto Sequence
CH1
CH2
CH1
28_ live
CH1
CH1
CH1
CH1
Single mode
In Single mode, If you have set <SEQ-Dwell Time> in “Setting the Device > Camera”, Auto Sequence will be
M
conducted at the set interval. (Page 44)
1
4
Channel Setting
You can display the channel in a desired area of a split screen.
1. Click a camera name to display a channel list where you can select a different channel.
2. Select a desired channel and click it.
The current channel will be switched to the selected one.
Use the cursor to select a channel to move, and drag and drop it to a desired channel; this can also
change the channel position.
Ex : if switching CH 1 to CH 4
LIVE
CH1 CH2
CH4 CH2
CH3 CH4
Switching to Single Mode
When in split mode, select and double-click a desired channel to switch to its Single mode.
Press the number corresponding to a desired channel the remote control to switch to its Single mode.
Refer to “Remote Control > Using the numeric buttons”. (Page 14)
Ex : If double-clicking CH 3 or pressing the number “3” on the remote control.
CH1 CH2
CH3 CH1
CH3 CH4
CH3
English _29
live
ZOOM
This is available only in Single Live mode. In Single mode, select a desired area and use the Zoom function to
enlarge it twice.
1. Select <Zoom In> in the right-click menu.
Press the [
The zoom box appears.
2. Use the direction keys, or drag and drop to specify an area to enlarge.
3. Press the [
4. Press the [ZOOM] button on the remote control, or simply click < > in the launcher menu to release
the zoom.
ZOOM] button on the remote control, or simply click < > in the launcher menu.
ENTER] button, or double-click the selected area to enlarge it twice.
In the enlarged image, use the direction buttons (◄ ►) on the remote controlto move the enlarged area.
2013-01-01 01:10:25
AUDIO ON/OFF
You can turn the sound on/off the CH1 in Live mode.
AUDIO ON/OFF in Single mode
Click the audio icon ( ) on the screen, or press the [AUDIO] button on the remote control to turn it on/off.
Only the channel where <Audio> is set to <ON> in “Device > Camera” displays the audio icon ( ) in Live mode
M
that you can use to turn the sound on/off.
FREEZE
This is available only in Live mode, this pauses playing the Live image temporarily.
>.
Freeze
> in the launcher menu.
1. Press the [
The playback of the image is stopped temporarily.
2. Press the [
This will release the freeze.
FREEZE] button the remote control, or click <
FREEZE] button again, or click <
Freeze
30_ live
EVENT MONITORING
This will display the channel in sync with a specific event (Motion/Video Loss) if it occurs.
In “Monitor > Event Display”, set the event monitoring to ON/OFF and specify the event display time. (Page 49)
• If multiple events occur simultaneously, the screen will switch to a split mode.
2~4 events : 4-split mode
-
• If the second event occurs within the set time of <
one is terminated. (Page 49)
Ex : If you set <Event Display> to 5 seconds, and only one event occurs in CH 1.
Event occurrence 5 seconds
Stop alarm
CH1
Ex : If you set <Event Display> to 5 seconds, and the second event occurs in CH 2 within the set time after the first
event occurred in CH 1.
Event Display>, the first event will last until the second
LIVE
Event occurrence
CH1
Press the [ALARM] button to reset the alarm settings and to release the event mode.
M
If an alarm activates in the condition you have set the event record, and pre/post alarm times, the event record will
be performed.
4 seconds 9 seconds
Stop alarm
CH1 CH2
English _31
main menu
You can setup the system properties, devices, and options for recording, event,
backup and network.
SYSTEM SETUP
You can setup Date/Time/Language, Permission, System Properties and Log.
Date/Time/Language
You can check and setup the current Date/Time and time related properties, as well as the language used for
the interface on the screen.
Setting the Date/Time/Language
Set the Date/Time/Language
Using the mouse may help make setup easier.
1. Press the [MENU] button on the remote control.
If not logged in, it prompts with login window.
Refer to “Login”. (Page 22)
2013-01-01 01:10:25
2. Use the left/right buttons (
◄ ►
) to select the <System>.
System property setup menu is selected.
3. Use the up/down buttons () to select <Date/Time/
Language
> and press the [ENTER] button.
4. Select <Date/Time/Language>.
A dialog to setup Date, Time and Language.
5. Use direction buttons (
◄ ►
) to select an item to set
and make your changes.
2013-01-01
01:10:25
System
Date/Time/Language
Permission Management
System Management
Log Information
Logout
Return
32_ main menu
• Date : Sets the date that will appear on the screen.
You can select the date format.
• Time : Sets the time and its format that will appear on the
screen.
Select either one from <
24 Hours, 12 Hours (AM/PM)>.
• Time Zone : Sets the time zone of your area based on the
Greenwich Mean Time (GMT).
GMT (Greenwich Mean Time) is standard World Time and the basis
of world time zone.
Date/Time/Language
Date/Time/Language
Date 2013-01-01 YYYY-MM-DD
Time 08:14:24 24 Hours
Time Zone GMT+09:00
Time Sync.
DST
Language English
Holiday
Setup
Dec First (Sun) 0 Dec First (Sun) 0
OK Cancel
• Time Sync. : You can set the DVR’s current time
synchronized to a selected <Time Server> regularly if you select to use <Time Server>.
In this case, <Date/Time/Language> setup does not allow time adjustment.
- Time Server : Enter an IP or URL address of the time
server.
- Last Sync Time : Displays the most recent synchronization
time from the selected time server.
- Activate as Server : Set to <Use> to allow the DVR to act
as a Time Server for other DVRs.
• DST : Set up Daylight Saving Time with its period to make
the time earlier than the GMT of its time zone by 1 hour
during the set period.
Date/Time/Language
Date/Time/Language
Date 2013 -01-01 YYYY-MM-DD
Time Synchronization Setup
Synchronization Use
Time 08:14:24 24 Hours
Time Server 203.248.240.103
Time Zone GMT+08:00
Last Sync Time Fail
Time Sync.
Activate as Server Use
DST
Language English
Holiday
Setup Not Used
Dec First (Sun) 0H Dec First (Sun) 0H
OK Cancel
OK Cancel
• Language : Select your language. Sets the language for the
interface.
English, French, German, Spanish, Italian, Chinese, Russian, Korean, Polish, Japanese, Dutch, Portuguese,
Turkish, Czech, Danish, Swedish, Thai, Romanian, Serbian, Croatian, Hungarian and Greek are available.
6. When the Date/Time/Language setup is done, press <
OK>.
MAIN MENU
You can also use numeric buttons on the remote control to enter values for Date, Time and other numeric fields.
M
English _33
main menu
Setting Holiday
You can set specific dates to Holidays according to your preferences.
Holidays are applied to <Recording Schedule> and <Alarm Schedule> too.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Date/Time/Language> window to select <Date/Time/Language>, and
press the [
2. Select <Holiday>.
A calendar for Holiday setup appears.
3. Use the left/right < > buttons to select year or month,
and press the [
ENTER] button.
ENTER] button.
Date/Time/Language
Date/Time/Language
2013 Jan
Sun Mon Tue Wed Thu Fri Sat
1 2 3 4 5
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30 31
Holiday
6 7 8 9 10 11 12
OK Cancel
4. Use direction buttons (
◄ ►
) to select a desired date,
and press the [ENTER] button.
You will see the “
Ex : Select January 14th and check on <1/14> only to make
every January 14th a holiday. Check both on <
Jan 2nd Mon> to make every January 14th and 2nd Monday
<
Setting Holiday” screen.
1/14> and
of January holidays.
5. When the Holiday setup is done, press <OK>.
Using the Calendar
Using the mouse may help make setup easier.
Select year and month.
Select the left/right <
adjust by 1 year/month.
Use direction buttons to select a date and press [ENTER] button.
A date with recorded data to be searched will appear in yellow in the System Log, Event Log, Time Search and
Event Search.
> key on the left/right side of year/month and press [ENTER] button to
Date/Time/Language
Date/Time/Language
2013 Jan
Setting Holiday
Sun Mon Tue Wed Thu Fri Sat
1 2 3 4 5
6 7 8 9 10 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30 31
Holiday
1 / 14
Jan 2nd Mon
OK Cancel
OK Cancel
34_ main menu
Permission Management
You can set permissions of each user over the DVR's specific function and settings.
Setting the Administrator
You can set and change Administrator’s ID and password.
The administrator can use and set all menu items and functions.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <
[
ENTER] button.
2. Select <
Permission Management>, and press
Admin>.
A dialog for Admin ID and Password input appears.
3. Use direction buttons (
◄ ►
) to move to a desired
item, and set the ID and password.
By default, initial ID and password are set to “admin”, and
M
“4321”.
The default password can be exposed to a hacking thread so it is recommended to change the password after
installing the product.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
4. When the administrator setup is done, press <OK>.
Using Virtual Keyboard
For alphanumeric inputs, the virtual keyboard window
appears.
Use direction buttons (
character, and press the [ENTER] button.
In the upper text input box of the virtual keyboard, there
displays a list of candidate words containing the selected
character.
Select a word from the list, or use the keyboard to enter the
whole word.
If there are many of candidate words, use < , > buttons to move between them forward and backward.
Select <OK>.
Entered word is applied.
For upper case letters, use <Caps Lock> button.
For special characters, use <Shift> button.
Using the virtual keyboard is the same to a normal keyboard use in your region.
You can enter the ID with case-insensitive alphanumeric characters only.
For the password, use alphabets and special characters excluding < \ > and <“>.
You can use number buttons on the remote control.
◄ ►
) to move to a desired
Permission Management
Admin
ID admin
New Password
Confi rm P/W
` 1 2 3 4 5 6 7 8 9 0 - =
q w e r t y u i o p [ ] \
a s d f g h j k l ; ‘
z x c v b n m , . /
Space Ctrl
Group
************
************
OK Cancel
OK Cancel
User Setup
Caps Lock
Shift
MAIN MENU
Del
English _35
main menu
Setting the Group
You can create user groups and setup permissions for those user groups.
You can register a user for each group in <User>.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <Permission Management>, and press
[ENTER] button.
2. Select <
3. Use direction buttons (
• Add, Delete, Rename : You can add, delete, rename a
group or modify the permissions given to the group.
The virtual keyboard appears when <Add> or <Rename> was selected.
- Add : When you first run the DVR with the admin account, only the admin account exists. Add has already
- Delete : Deletes a user group that is already registered. Selecting Delete will delete all user accounts
- Rename : Renames a group that is already registered. Select <
• Group Authority : Sets permissions to access menu items of each group.
Users of a group can access checked functions.
4. When the group setup is done, press <
Group>.
A window for <Add>, <Delete>, <Rename>, and
<
Group Authority> setup appears.
◄ ►
) to move to a desired
item, and set the value.
been deactivated. Select to display the virtual keyboard. Enter a group name. You can add up to 10
groups.
belonging to that group.
For entering a group name, refer to “Using Virtual Keyboard”. (Page 35)
OK>.
Permission Management
Admin
Group
Group Authority
Live View
Search
Backup
Group
Setup
Setup
Setup
OK Cancel
User
Add Delete Rename
Setup
Rename> to display the virtual keyboard.
To set the group authority
You can set the permissions of the group users to access the menu according to the channel.
1. Select a menu to which the group permission is assigned.
The menu where the group permission is assigned will be
displayed in the Live menu when a group user logs in.
• Live View : You can set the permission to access the Live
screen according to the channel.
• Search : You can set the permission to access the Search
menu according to the channel.
• Backup : You can set the permission to access the Backup
menu according to the channel.
2. Select <
OK>.
Select and assign a group user so that the user can access the specified menu.
36_ main menu
Permission Management
Admin
Group ABC
Group Authority
Group
Channel Setup
Live View
All
Search
1 2 3 4
Backup
Setup
Setup
Setup
OK Cancel
OK Cancel
User
Add Delete Rename
Setup
To restrict the user permissions
If the admin restricts all permissions of an added group, the users belonging to that group can access only
the default minimum menus and can change the user’s own password only.
1. Start the DVR.
If all permissions are restricted, only the Login dialog
should appear.
2. Log in with a registered user ID.
Login
ID abc
Password
OK Cancel
MAIN MENU
3. Right-click any area on the screen.
If all permissions are restricted, only the accessible context
2013-01-01 01:10:25
menus should appear.
Scene Mode
Audio Off
Freeze
Stop Alarm
User Menu
Hide Launcher
Logout
2012-01-01
01:10:25
To change the user password
If you log in with a user account that is restricted to access the menu, you can change your own password
only.
1. Log in with your account.
2. Select <
User Menu>.
The Permission Management setup screen appears.
3. Select <Permission Management>.
The Password setup dialog appears.
4. Enter a new password.
5. Select <
OK>.
You change to the password will be applied.
Permission Management
User
ID
New Password
Confi rm P/W
abc
************
************
OK Cancel
English _37
main menu
Setting the User
Users can be added only if a group was created in <Group> menu.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <
[ENTER] button.
2. Select <
A window for Add User appears.
3. Use direction buttons (
window.
A window for “
You can configure the Network Viewer settings including
name, ID, viewer, Select Group and password.
Result of the user setup appears in the <User> window.
To change the user property, use “
The “
desired item to be changed in the <User> window.
• Viewer : If you select <
Web Viewer and Network Viewer.
Refer to “Connecting Web Viewer (Mac)”. (Page 81)
For more information about use of Smartviewer, refer to the
Smartviewer's user guide.
4. When the user setup is done, press <OK>.
Permission Management>, and press
User>.
◄ ►
) to select <Add> from the
Add User” appears.
Edit User”.
Edit User” window appears when you select a
Use>, you will be given access to the
Permission Management
Admin
Group All Group
Group Name ID Viewer Del
Permission Management
Admin
Group All Group
Group Name ID Viewer Del
Group
Group
Add User
Name
ID
Viewer Not Used
Select Group ABC
Password
Confi rm P/W
User
OK Cancel
User
OK Cancel
OK Cancel
Setup
Previous/Next Page
Setup
Previous/Next Page
Add
Add
38_ main menu
Setting Permissions
You can set restricted access for all general users.
Items with restrictions will require logging in for use.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <Permission Management>, and press
[ENTER] button.
2. Select <
Setup>.
The Restricted Access, Restriction on Network Access,
Auto Log out, Manual Input of ID setup screen appear.
3. Use direction buttons (
◄ ►
) to move to a desired
item, and set the value.
• Restricted Access : All menu items allowed for a user can
be set with restricted access.
- Checked ( ) : Restricted
- Not checked (
If it is not checked ( ) in <Restricted Access>, any user can access the item no matter what the <Group Authority>
) : Accessible
setting.
If it is checked ( ) in <Restricted Access>, a user can access the item only if the user has permission in <Group
Authority> setting.
• Restriction on Network Access : Restricts remote access from a <Restricted Access> network.
- All Network : Restricts all access instances via Network Viewer and Web Viewer.
- Web Viewer : Restricts access via the Web Viewer.
• Auto Log out : A user will be automatically logged out if there is no operation on DVR for over set period of
time.
• Manual Input of ID : Prompts you to enter the user ID
manually for the login process.
- Checked ( ) : Encloses the registered user IDs with the
[] symbols.
Use the virtual keyboard to enter the user ID.
4. When the permission setup is done, press <OK>.
Permission Management
Admin
Restricted Access
Restriction on Network Access
Auto Log out OFF
Manual Input of ID ON
Group
Live View Backup All
All Network Web Viewer
OK Cancel
Login
ID
Password
OK Cancel
*****
User
Setup
MAIN MENU
English _39
main menu
System Management
You can check the system version, update to a newer version, as well as data backup and initialization.
Checking the System Information
You can check the current system version, broadcasting system, MAC address. You can update the system.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <
System Management>, and press [ENTER]
button.
2. Check the Software Version, Broadcast Format and MAC
Address.
• System Information : Shows the current system’s
information.
The values can not be changed by a user.
• S/W Upgrade : Updates the DVR’s software.
Ex : If you connect to a storage device that has upgradable
software
installed, and return to the <System Management> menu,
the current software version will be displayed.
System Management
System Information
System Information
Software Version v1.0xh_yymmddhhmmss
Broadcast Format
MAC Address 00:00:F0:54:FF:FF
S/W Upgrade
Device No Device
Version No S/W Data
System Management
System Information
System Information
Software Version v1.0xh_yymmddhhmmss
Broadcast Format
MAC Address 00:00:F0:54:FF:FF
S/W Upgrade
Device USB2FlashStorage
Version v1.0xh_yymmddhhmmss
Settings
NTSC
Previous
Settings
NTSC
Upgrade
Upgrade
• Updating the Software
1. Connect a device storing the software to be updated.
(It may take about 10 seconds to recognize the device.)
Upgradeable devices include USB memory and network device.
To update the network, the current DVR should have been
connected to the network.
Upgrade via the proxy server may not be enabled due to the
restricted access.
2. Select <System Management> from <System> window.
3. Select <
System Information>.
4. When the recognized device appears, select <
The <Upgrade> button will be activated only if the current <Software Version> of the <System Information> is
same to or older than that of <
S/W Upgrade>.
40_ main menu
Upgrade>.
Previous
System Management
System Information
System Information
Software Version v1.0xh_yymmddhhmmss
Broadcast Format
System Upgrade
MAC Address 00:00:F0:54:FF:FF
Current Version v1.0xh_yymmddhhmmss
New Version v1.0xh_yymmddhhmmss
S/W Upgrade
Do you want to upgrade?
Device USB2FlashStorage
Version V1.08_090731170402
Settings
NTSC
OK Cancel
Previous
Upgrade
5. Press <OK> in the “System Upgrade” window.
While updating, it shows the progress.
• Updating progresses with 3 steps as shown in the figure.
6. When the updating is done, it automatically restarts.
Do not turn the power off until it finishes restarting.
System Management
System Information
System Information
Software Version v1.0xh_yymmddhhmmss
Broadcast Format
S/W Upgrade
MAC Address 00:00:F0:54:FF:FF
Software upgrading...
S/W Upgrade
Device USB2FlashStorage
Version V1.08_090731170402
Settings
NTSC
Previous
System Management
System Information
System Information
Software Version v1.0xh_yymmddhhmmss
Broadcast Format
S/W Upgrade
S/W Upgrade
MAC Address 00:00:F0:54:FF:FF
Software upgrading...
S/W Upgrade
Device USB2FlashStorage
Version V1.08_090731170402
Settings
NTSC
Software upgrading...
Do not turn off during the upgrade.
Previous
Upgrade
Upgrade
MAIN MENU
If “Upgrade Failed” appears, retry from the step 4.
M
When you experience continued failure, consult the service
center for assistance.
When you perform S/W update remotely using Smart Viewer,
it may take a max of 3 minutes to complete the update since
Smart Viewer popped up a confirmation message. This is to
guarantee that the DVR set operates stably. For a faster
update, use the USB cable to connect to the DVR set.
English _41
main menu
Settings
You can copy and import the DVR settings by using a storage media.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <
button.
2. Select <
A window of storage device and load factory default
appears.
3. Use direction buttons (
item, and export or import settings data to a storage
device.
• Storage Device : Shows the connected storage device.
• Export : Exports DVR settings to the connected storage device.
• Import : Imports DVR settings from the storage device and applies to the DVR.
If <Include Network Settings> is checked, the network settings will be imported too.
• Load Factory Default : If <Default> is selected, a
confirmation dialog for “Load Factory Default” prompts.
Press <
4. To move to the previous menu, press <Previous>.
System Management>, and press [ENTER]
Settings>.
◄ ►
) to move to a desired
OK> to initialize the system to the factory default.
System Management
System Information
Storage Device 0 MB (Remained Capacity)
DVRUSB
USBDVR
Include Network Settings
Load Factory Default
System Management
System Information
Storage Device 0 MB (Remained Capacity)
DVRUSB
Load Factory Default
USBDVR
Include Network Settings
Load Factory Default
10041400
No data
Default
10041400
No data
Sure to Default Setting?
OK Cancel
Default
Settings
Previous
Settings
Export
Import
Export
Import
Previous
Log Information
You can browse logs on the system and events.
System Log
System Log shows log and timestamp on every system start up, system shutdown, and changes on system
settings.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <Log Information>, and press [ENTER] button.
2. Select <
System Log>.
Refer to “Using the Calendar”. (Page 34)
Click on the calendar <
> to display the calendar window.
• Type : When there are too many logs, you can display logs
of the desired format by selecting the type.
3. Use direction buttons (
item, and press <
◄ ►
Search>.
) to move to a desired
Log Information
System Log
Search Day 2013-01-01
First Page
No. Log List Date/Time
Event Log
Last Page
Previous
Backup Log
Search
Type View all
Previous/Next Page
42_ main menu
Event Log
Event log shows recorded events on alarms, motion detections and video loss.
It also shows the log and its timestamp.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <System> window to
move to <Log Information>, and press [ENTER] button.
2. Select <
3. Use direction buttons (
Event Log>.
◄ ►
) to move to the desired
item.
4. Set Search Day, Channel and Type and the press
<
Search>.
Refer to “Using the Calendar”. (Page 34)
Log Information
System Log
Search Day 2013-01-01
First Page
No. Log List Date/Time
7 Motion Detection [CH 1] 2013-01-01 00:02:14
6 Motion Detection [CH 2] 2013-01-01 00:02:14
5 Motion Detection [CH 3] 2013-01-01 00:02:14
4 Motion Detection [CH 4] 2013-01-01 00:02:18
3 Motion Detection [CH 3] 2013-01-01 00:02:18
2 Motion Detection [CH 2] 2013-01-01 00:02:18
1 Motion Detection [CH 1] 2013-01-01 00:02:18
Event Log
Last Page
CH All CHs Type View all
Previous
Backup Log
Search
Previous/Next Page
Click on the calendar < > to display the calendar window.
Backup Log
You can find out who backed up and the details (backup time, channel, device to use, file format, etc.).
Using the mouse may help make setup easier.
1. In the <System> window, press the up/down () button
to move to <
Log Information> and press the [ENTER]
button.
2. Select <
3. Use the four direction buttons (
Backup Log>.
◄ ►
) to move to a
desired item.
4. Specify a search term and select <
Search> in the right
corner.
Backup details for the search term will be listed.
Log Information
System Log
Search Day 2013-01-01 ~ 2013-01-02
First Page
No. User Date/Time
Event Log
Last Page
Backup Log
Previous/Next Page
Previous
Search
MAIN MENU
English _43
main menu
a
a
S
p
l
n
PTZ
SETTING THE DEVICE
You can setup Camera, Storage Device, Remote Device and Monitor.
Camera
Setting the Camera
You can set Video, Audio, Channel Name and Dwell Time of a Camera.
Using the mouse may help make setup easier.
1. Press Bthe [MENU] button on the remote control.
2. Use the left/right button (
Device setting menu is selected.
3. Use the up/down buttons (
and press [ENTER] button.
◄ ►
) to select <Device>.
) to move to <Camera>,
Device
Camera
Storage Device
Remote Device
Monitor
Logout
Return
4. Select <Camera>.
You will see a window where you can configure the
camera settings including Video, Audio, CH Name, SEQDwell Time.
5. Use direction buttons (
◄ ►
) to move to a desired
Camera
Camer
Camera
Camera
Camera
Camer
CH Video Audio CH Name SEQ-Dwell Time
1 ON ON CAM 01 5 sec
2 ON OFF CAM 02 5 sec
3 ON OFF CAM 03 5 sec
4 ON OFF CAM 04 5 sec
PTZ
PTZ
item, and set the value.
• Video
-<ON/OFF> : You can turn ON/OFF the selected channel’s
camera.
Screen Setup
creen Setu
Privacy Region
Privacy Regio
Privacy RegionScreen Setup
OK Cancel
OK Cance
OK Cancel
-<Covert1> : Shows information other than the video of
the selected channel.
For privacy protection, it does not display the video while the recording continues.
-<Covert2> : Shows nothing but an empty screen while the recording continues.
• Audio
- If set to <ON>, you can turn the audio of the channel ON/OFF on the Live screen.
- If set to <OFF>, the channel’s audio is off on the Live screen and not recorded.
Audio output is available for only CH1.
• CH Name : Up to 15 characters including blanks are allowed. (The first character should not be empty.)
Refer to “Using Virtual Keyboard”. (Page 35)
• SEQ-Dwell Time : You can set the dwell time between channels for the Live screen.
If set to <OFF>, the channel is not listed in the Auto Sequence mode.
44_ main menu
• Screen Setup : The video appeared on the screen may vary
depending on the channel’s camera, configure the DVR
display to your preferences.
Select a channel and adjust the <
(Brightness)>, <
(Contrast)>, and < (Color)> of the selected channel.
Press the <Init> to initialize settings back to the default 50.
• Privacy Region : You can specify a certain area of the
camera video to be protected for your privacy.
Screen Setup
CH1 50 50 50
6. When the camera setup is done, press <OK>.
To set the privacy region
Select <Privacy Region>.
When “Privacy Region” window appears, select a
channel for detection and set the area of motion
detection.
• To set the area in “
Privacy Region” window, select desired region
In the “
from <
• Privacy Region
You can specify up to 4 privacy zones for each channel,
which can be identified by the color.
1 Purple 2 Green 3 Blue 4 Yellow
• To set the area using <
When selected <
When the motion area setup is done, Right-click to select <
button on the remote control to display the “
- Clear All : Selected cell is removed from the Privacy Region.
- Menu : After selecting individual motion areas, move to the “Privacy Region”
window.
If selected <Apply to All CH>, selected motion area is applied to all channels.
When completing the privacy zone settings, click <OK>.
Privacy Region” window
Privacy Region
>.
CH1
Privacy Region1
Individual> selection
Individual>, “Privacy Region” window disappears and you can select cells one by one.
Menu> in the context menu or the [MENU]
Privacy Region” window again.
OK Cancel
Individual
OK Cancel
MAIN MENU
Init Apply to All CH
Apply to All CH
Clear All
Menu
English _45
main menu
Setting the PTZ
To use Camera’s PTZ functions, ID and protocols of each camera and DVR should be matched.
For other settings, refer to the “Remote Devices” settings. (Page 48)
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <
2. Select <
Camera>, and press [ENTER] button.
PTZ>.
A window of PTZ settings appears.
3. Use direction buttons (
◄ ►
) to move to a desired
item, and select it.
• ID : Set the ID of the connected camera of each channel.
You can easily setup by using the numeric buttons on the
remote control.
• Protocol : Set the protocol of the connected camera of each channel.
You can check the camera’s ID and protocol if you turn the camera off and on after connecting it to the DVR.
M
4. When the PTZ setup is done, press <OK>.
Storage Device
Camera
Camera
CH ID Protocol
1 0 > None
2 1 > None
3 2 > None
4 3 > None
PTZ
OK Cancel
You can check information on storage devices.
Confirming Devices
You can check storage devices and their free space, usage as well as status.
Devices available are HDD, and USB devices (Memory, HDD).
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <
2. Select <
Storage Device>, and press [ENTER] button.
Device>.
• No. : Shows the assigned number of the internal HDD.
• Used/Total : Shows the used/total capacity of the storage
device.
• Used : Sets the storage device’s usage.
- USB memory is used for backup purpose only.
• Status/Management : Shows the current status of the HDD,
as in Normal/Check/Replace.
- Normal : Available to use
- Check : Available to use but recommended to replace
- Replace : Requires immediate replacement.
3. To move to the previous menu, press <
OK>.
Storage Device
Device
Device No. Used/Total Used Status/Management
HDD 1 12.28G/499.37G Internal Normal
HDD Map
Format
OK Cancel
HDD Alarm
46_ main menu
Formatting
You can format a storage device.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <
2. Select <Format>.
A window for selection of device for formatting appears.
3. Use direction buttons (
formatted.
Storage Device>, and press [ENTER] button.
◄ ►
) to select a device to be
Storage Device
Device
Device Select Used/Total Used
HDD 1 12.28G/499.37G Internal
Format
Format
OK Cancel
HDD Alarm
MAIN MENU
4. Select <
Press <
Format> on the bottom of the screen.
OK> on the “Manage” confirmation window will
start formatting the selected device.
5. When the formatting is done, press <
Even when formatted, used HDD space will not be 0 GB due
M
to the space reserved by the system required for operating.
OK>.
Storage Device
Device
Device Select Used/Total Used
HDD 1 12.28G/499.37G Internal
Format
Manage
Format
HDD Alarm
Formatting deletes all recordings.
Proceed formatting?
OK Cancel
OK Cancel
English _47
main menu
Sy
1
R
0
y
pe
None
1
Half
e
ncel
HDD Alarm
You can set alarm settings for HDD defects such as Check Alarm Output Port, Replace Alarm Output Port,
and its duration.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <Storage Device>, and press [ENTER] button.
2. Select <
HDD Alarm>.
A window for setting HDD check and replace output ports
and their durations appears.
3. Use direction buttons (
◄ ►
) to move to the desired
item.
• Alarm
- If <BEEP> was selected, a beep will sound.
• Check Alarm Output Port : If HDD generates check alarm,
the alarm signal will output to the specified alarm output port.
• Replace Alarm Output Port : If HDD generates replace alarm, the alarm signal will output to the specified
alarm output port.
• Duration : Sets the alarm duration for the alarm signal and beep sound.
<Check> status means that the HDD is operating but it has problems that require technical examination.
M
(
) appears on the Live screen.
<Replace> status means that the HDD has defect and requires immediate replacement.
( ) appears on the Live screen.
Storage Device
Device
Check Alarm Output Port
Duration OFF
Replace Alarm Output Port
Duration OFF
Format
OK Cancel
HDD Alarm
BEEP
BEEP
4. When the HDD Alarm setup is done, press <OK>.
Remote Devices
You can set the RS-485 communication for use of PTZ Camera and system keyboard with the DVR.
Using the mouse may help make setup easier.
1. Use the up/down buttons (
move to <Remote Device>, and press [ENTER] button.
2. Use direction buttons (
item, and press [ENTER] button.
3. Set the values of each communication setup of the remote
device.
• Baudrate : Baud rate settings of the DVR, PTZ camera and
system keyboard should be matched for proper operations.
4. Specify the system keyboard and remote control ID, and
OK>.
click <
For changing the remote control’s ID, refer to “Changing the Remote Control ID”. (Page 14)
M
◄ ►
) in <Device> window to
) to move to the desired
Remote Device
Remote Devic
Remote Device
Baudrate Parity Data Stop Bit Transfer type
Baudrate Parity Data Stop Bit Transfer t
Baudrate Parity Data Stop Bit Transfer type
9600 None 8 1 Half Duplex
9600
9600 None 8 1 Half Duplex
stem Keyboard OFF ID
System Keyboard OFF ID
System Keyboard OFF ID 1
Remote Control ON ID 0
emote Control ON ID
Remote Control ON ID 0
8
OK Cancel
OK Ca
OK Cancel
1
Duplex
48_ main menu
Monitor
You can select which item(s) to be displayed on the screen.
Setting the Monitor
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <
2. Select <
3. Use direction buttons (
Monitor>, and press [ENTER] button.
Monitor>.
◄ ►
) to move to a desired
item, and set the value.
• Event Display : Sets the dwell time of the event channel
display on the monitor when an event occurs.
If selected <Continuous>, it displays the channel until you
press [ALARM] button to release it.
• Display : Displays only checked items on the monitor
screen.
• Video Out : You can set the video output mode.
- Auto : The default is set to Composite. (In VGA mode, the “SAMSUNG” logo will be displayed)
If a VGA source is connected, the source from the VGA will be displayed as main. (In Composite mode,
the spot screen will be displayed)
The monitor distributor is not supported.
To switch to VGA mode, turn off the DVR set and connect the VGA jack. (The VGA monitor will turn on)
- VGA : The main video mode will switch to VGA after the DVR set reboots; the composite source will be
displayed on the spot screen.
- Composite : The main video mode will switch to Composite after the DVR set reboots. In VGA mode, the
“SAMSUNG” logo will be displayed.
4. When the monitor setup is done, press <
OK>.
Monitor
Monitor
Event Display OFF
Display Date Time CH Name Icon
Video Output
Display Position Setup
Mode
VGA
OK Cancel
MAIN MENU
Setting Display position
Some monitors many not display information (camera name, icon, time information, etc.) about the DVR,
depending on the condition. Then, you can change the display position of the data.
1. In the <Device> window, press the up/down () button to move to <Monitor> and press the [ENTER]
button.
2. Select the <
3. Select <Display Position Setup> in the bottom.
You will move to the <Display Position Setup> window.
4. Use the four direction buttons or the number buttons on
the remote control to adjust the data position.
Monitor> item.
2013-01-01 01:10:25
Display Position Setup
30
30 30
30
OK Cancel
English _49
main menu
Setting the Screen Mode
You can configure the Live screen and Split Screens.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Device> window to
move to <
2. Select <
3. Use direction buttons (
item, and set the value.
• Live Screen : Select split modes for the Live screen.
4-split screens are included by default.
• Play Screen : Select split modes for the playback screen.
Single screen and 4-split screen are provided by default.
4. When the screen mode setup is done, press <
Monitor>, and press [ENTER] button.
Mode>.
◄ ►
) to move to a desired
OK>.
Monitor
Monitor
Live Screen
Play Screen
Mode
Live Play
OK Cancel
50_ main menu
SETTING THE RECORDING
You can setup scheduled recording, event recording and other recording related settings.
Recording Schedule
Make your reservation on a date and time to schedule the recording on specified time.
Using the mouse may help make setup easier.
1. Press the [MENU] button on the remote control.
2. Use the left/right button (
Record menu is selected.
3. Use the up/down buttons (
Schedule
4. Select <
>, and press [ENTER] button.
Recording Schedule>.
A window of scheduled recording setup appears.
5. Use direction buttons (
item, and set the value.
◄ ►
) to select <Record>.
) to move to <Recording
◄ ►
) to move to a desired
Record
Recording Schedule
Event Record Duration
REC Quality & Resolution
Record Option
Recording Schedule
CH1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
All
Sun
Mon
Tue
Wed
Thu
Fri
Sat
Hol
No Recording Continuous Event
Both(Cont&Evnt)
OK Cancel
Logout
MAIN MENU
Return
Apply to All CH
• Apply to All CH : If selected <
All CH
” window appears.
OK> to apply the setup to all channels.
Press <
Apply to All CH>, “Apply to
6. When the recording schedule setup is done, press <
Event recording and scheduled recording starts about 3
M
seconds prior to the event/schedule for guaranteed recording.
OK>.
Recording Schedule
CH1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
All
Sun
Apply to All CH
Mon
Tue
Wed
Thu
Fri
Sat
Hol
No Recording Continuous Event
Both(Cont&Evnt)
Apply recording schedule to all channels?
OK Cancel
Apply to All CH
OK Cancel
English _51
main menu
Recording Color Tags
Color Function Description
White No Recording No schedule / event recording
Orange Continuous Scheduled recording only
Blue Event Event recording only
Green Both(Cont&Evnt) Both scheduled / event recordings
Each press of a selected cell will cycle through <
No Recording>-<Continuous>-<Event>-
<Both(Cont&Evnt)>.
Event Record Duration
You can set the beginning and ending point of a recording on an event.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Record> window to
move to <Event Record Duration>, and press [ENTER]
button.
2. Use direction buttons (
◄ ►
) to move to a desired
item, and set the value.
•
Pre Event : The recording of an event will start at a pre-
determined time prior to the actual occurrence of the event.
If it is set to 5 seconds, the recording begins from 5
seconds before the event.
• POST Event : The recording will continue for a pre-
determined time after the actual end of an event.
If it is set to 5 seconds, the recording ends in 5 seconds after an event.
3. When the event recording duration setup is done, press <OK>.
Event Record Duration
CH Pre Event POST Event
1 OFF
2 OFF
3 OFF
4 OFF
1 min
1 min
1 min
1 min
OK Cancel
52_ main menu
REC Quality / Resolution
You can set resolution, fps and quality of recordings by channel, and by recording type of standard / event.
Setting Standard Recording Properties
You can set each channel’s resolution, quality and fps for normal recordings.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Record> window to
move to <
[
ENTER] button.
2. Select <
3. When the recording setup is done, press <
REC Quality & Resolution>, and press
Standard>.
OK>.
REC Quality & Resolution
Standard
Remaining count : 4CIF(L) : 2 2CIF(M) : 4 CIF(S) : 8
CH Resolution Record Rate Record Quality
1 CIF(S) 7fps Level4
2 CIF(S) 7fps Level4
3 CIF(S) 7fps Level4
4 CIF(S) 7fps Level4
Setting Event Recording Properties
You can set each channel’s resolution, quality and fps for event recordings.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Record> window to
move to <REC Quality & Resolution>, and press
[ENTER] button.
2. Select <
Event>.
Event recording setup window appears.
3. Use direction buttons (
◄ ►
) to move to a desired
item, and select it.
• Resolution : Sets the resolution of the recorded screen.
• Record Rate : Image Per Second, means the frames
recorded per a second.
• Record Quality : Sets the recording quality.
REC Quality & Resolution
Standard
Remaining count : 4CIF(L) : 2 2CIF(M) : 4 CIF(S) : 8
CH Resolution Record Rate Record Quality
1 4CIF(L) 7fps Level4
2 4CIF(L) 7fps Level4
3 4CIF(L) 7fps Level4
4 4CIF(L) 7fps Level4
Event
OK Cancel
Event
OK Cancel
MAIN MENU
The estimated total remaining count means the total number of remaining recordings for both standard and event
M
recordings.
You cannot increase the remaining count if the current remaining count has reached zero or there is no available
remaining count from any other page. If this is the case, reduce the remaining count for the current page, or do so
for the same channel on any other page.
4. When the Event recording setup is done, press <OK>.
English _53
main menu
Record Option
You can set the recording to stop or overwrite when the HDD is full.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Record> window to
move to <Record Option>, and press [ENTER] button.
2. Use direction buttons (
item, and set the value.
• Disk End Mode : If selected <Overwrite>, recording will
continue despite the HDD full while overwriting the oldest.
If selected <
Stop>, the recording will stop when the HDD is
full.
• Disk End Beep : If selected <Stop>, the button is activated.
If you check it, the beep will sound on the disk full and the
recording stops.
• Auto Delete : If you check it, Record Period setup is activated.
If you specify the auto deletion period, the recording data before the period will be deleted automatically.
This option will be enabled only if Disk End Mode is set to <Overwrite>.
3. When the recording option setup is done, press <OK>.
◄ ►
) to move to a desired
Record Option
Disk End Mode Overwrite
Disk End Beep
Auto Delete
Auto Delete
180 day
The recording information will be deleted.
Do you want to proceed?
OK Cancel
OK Cancel
54_ main menu
SETTING THE EVENT
You can set recording options for motion, and video loss event.
Motion Detection
You can set target detection region and motion, as well as the alarm signal output.
When the motion detection region is set, it detects motion within the area.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Event> window to
move to <Motion Detection>, and press [ENTER] button.
A window of motion detection area setup appears.
2. Use direction buttons (
◄ ►
) to move to a desired
item, and set the value.
Motion Detection
CH Mode Sensitivity Alarm Alarm Duration
1 OFF Level10(High) None 10 sec
2 OFF Level10(High) None 10 sec
3 OFF Level10(High) None 10 sec
4 OFF Level10(High) None 10 sec
• Mode : Sets whether to activate motion detection.
• Sensitivity : Sets the sensitivity level of the motion detection.
• Alarm : Sets the alarm output method.
For further information on alarm output, refer to “HDD Alarm >
OK Cancel
Motion Region
Alarm”. (Page 48)
• Alarm Duration : Sets the duration of alarm signal and alarm sound.
3. When the motion detection setup is done, press <
OK>.
Setting the Motion Detection Area
Select <Motion Region>.
When “Motion Region” window appears, select a
channel for detection and set the area of motion
detection.
• To set the area in “
In the “
Motion Region” window, select desired region
from <
• To set the area using <
In the “Motion Region” window, you can select cells
individually by using <
When selected <Individual>, “Motion Region” window disappears and you can select cells one by one.
When the motion area setup is done, Right-click to select <
button on the remote control to display the “Motion Region” window again.
- Select : Selected cell is set to be a part of motion detection area.
- Unselect : Selected cell is removed from the motion detection area.
- Inverse : Unselected cells are set to be the motion detection area.
- Menu :
After selecting individual motion areas, move to the “Motion Region” window.
If selected <Apply to All CH>, selected motion area is applied to all channels.
When the motion detection setup is done, press <OK>.
Motion Region” window
>.
Individual> selection
Individual>.
Motion Region
CH1
OK Cancel
Individual
Apply to All CH
Menu> in the context menu or the [MENU]
Select
Unselect
Inverse
Menu
MAIN MENU
English _55
main menu
Video Loss Detection
You can set the alarm to be generated on a camera disconnection, which causes a video loss.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Event> window to
move to <Video Loss Detection>, and press [ENTER]
button.
A window of video loss detection area setup appears.
2. Use direction buttons (
◄ ►
) to move to a desired
item, and set the value.
• Video Loss State : Sets whether to activate video loss
detection.
• Alarm : Sets the alarm output method.
For further information on alarm output, refer to “HDD Alarm >
Alarm”. (Page 48)
• Alarm Duration : Sets the duration of alarm signal and alarm sound.
• Help : Displays a help message that will appear if a video loss event occurs.
3. When the video loss detection setup is done, press <
OK>.
Alarm Schedule
Video Loss Detection
CH Video Loss State Alarm Alarm Duration
1 OFF None 10 sec
2 OFF None 10 sec
3 OFF None 10 sec
Help
4 OFF None 10 sec
If a video loss event occurs during the event
recording, the POST recording settings of
the applicable channel will be reset.
OK Cancel
OK
Help
You can set the conditions and operating hours for scheduled alarms.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Event> window to
move to <
2. A window of <
Alarm Schedule>, and press [ENTER] button.
Alarm Schedule> settings appears.
3. Alarm : Sets the alarm output method.
For further information on alarm output, refer to “HDD Alarm >
Alarm”. (Page 48)
• <ON> : Marked in orange, and always generates alarm on
Alarm Schedule
BEEP
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
All
Sun
Mon
Tue
Wed
Thu
Fri
Sat
Hol
OFF ON Event Sync
scheduled time.
• <
OFF> : Marked in white, no alarm is generated even if an
event occurs.
• Event Sync : Marked in Blue, generates alarm only when an event occurs.
When the alarm is generated on the scheduled time, you can stop the alarm by canceling the schedule.
M
4. When the Alarm Schedule setup is done, press <OK>.
OK Cancel
56_ main menu
BACKUP
You can check the backup device and set the backup schedule by channel or by time.
The product only supports external HDD of USB memory and USB type. (Page 111)
Setting the Backup
You can backup the desired data to a connected device.
Using the mouse may help make setup easier.
1. Press the [MENU] button on the remote control.
◄ ►
2. Use the left/right button (
Backup menu is selected.
) to select <Backup>.
Backup
Logout
Backup
MAIN MENU
Return
3. Press the [ENTER] button.
A backup window appears.
You can directly access it from the “Live screen menu”.
24
(Page
4. Use direction buttons (
)
◄ ►
) to move to a desired
item, and set the value.
• Backup Range : Sets the <Start> and <End> time for the
backup.
• Channel : Sets the channel to backup.
Backup
Start End
2013-01-01 00:01:06 2013-01-01 08:25:45
Overlap
List0
1 2 3 4 ALL
Device USB-Storage
Folder \20130101\
Check capacity
OK Cancel
Type DVR
Filename 0001
Backup
Used
Free
Change
You can select multiple channels.
• Device : Select a backup device from the recognized devices.
• Type : Sets the backup data format.
- DVR : Saved data can be played back only by the DVR.
- SEC : Saves data in the Samsung’s proprietary format with built-in viewer, which supports immediate
playback on a PC.
• Filename : You can set the back file name.
Refer to “Using Virtual Keyboard”. (Page 35)
• Check capacity : Shows the size of the selected backup data, used and available capacity of the selected
backup device.
Checking will stop if the backup size is over 200%.
• Overlap : Shows a list of overlapping data on a same time according to the number of data.
It appears when one channel has multiple data on a certain time point due to changing of time or time zone
settings, etc.
Refer to time and time zone of “Setting the Date/Time/Language”. (Page 32)
English _57
main menu
5. When the backup setup is done, press <OK>.
If no available device is recognized for backup, <OK> button is not activated.
The application may slow down during the backup.
J
You can switch to the menu screen during the backup in operation, but playback of data is not available.
If backup has failed, select “Device > Storage Device” and check the free space of the HDD and check also if the
HDD is properly connected.
Pressing the <Exit> during the backup will return to the previous menu, while the backup progresses.
M
NETWORK CONFIGURATION
It provides networked monitoring of Live screen from a remote place, and supports mail forwarding function with
events. You can configure the network environment which enables such functions.
Connection Mode
You can set the network connection route and protocol.
Setting the Connection
Sets the protocol and environment of the network.
Using the mouse may help make setup easier.
1. Press the [MENU] button on the remote control.
◄ ►
2. Use the left/right button (
) to select <Network>.
Network menu is selected.
3. Use the up/down buttons (
Mode
>, and press [ENTER] button.
4. Select <
Connection>.
) to move to <Connection
A window of connection mode setup appears.
5. Use direction buttons (
◄ ►
) to move to a desired
item, and set the value.
• Connection Mode : Sets the network connection mode.
• Bandwidth : Sets the maximum data flow to be transferred.
(Upload speed)
Options will vary depending on the selected connection
mode.
Static IP>, <Dynamic IP> : Select one from 50
- For <
kbps ~ 2Mbps, and Unlimited.
- For <ADSL>, select one from 50 kbps ~ 600 kbps.
Connection Mode
DDNS
Live Transfer
Mailing Service
Connection Mode
Connection
Connection Mode Static IP
Bandwidth 2Mbps
IP 192.168. 1.200
Gateway 192.168. 1. 1
Subnet Mask 255.255.255. 0
DNS
Protocol
Manual 168.126. 63. 1
OK Cancel
Logout
Return
Network
58_ main menu
• IP, Gateway, Subnet Mask, and DNS
- For <Static IP> : You can directly input IP address,
Gateway, Subnet Mask and DNS.
- For <Dynamic IP> : IP address, Gateway, and Subnet
Mask are set automatically.
ADSL> : IP address, Gateway, and Subnet Mask are
- For <
set automatically.
• User ID, Password : In case you selected ADSL, provide the
“
User ID” and its “Password”.
DNS server for <Dynamic IP> and <ADSL> can be set by user only if you selected <Manual>.
M
6. When the connection setup is done, press <OK>.
Setting the Protocol
Connection Mode
Connection
Connection Mode ADSL
Bandwidth 600kbps
IP
Gateway
Subnet Mask
DNS Manual 168.126. 63. 1
User ID ID
Password
Protocol
192.168. 1.200
192.168. 1. 1
255.255.255. 0
************
OK Cancel
MAIN MENU
1. Use the up/down buttons () in <Network> window to
move to <
Connection Mode>, and press [ENTER]
button.
2. Select <
3. Use direction buttons (
Protocol>.
◄ ►
) to move to a desired
item, and set the value.
• Protocol Type : Select the protocol type between TCP and
UDP.
If selected UDP, selections of Port (TCP), Port (UDP), and Unicast/
Connection Mode
Connection
Protocol Type TCP
Port(TCP) 4520 ~
Port(UDP)
Unicast/Multicast
Multicast IP
TTL
Webviewer Port 80
* Multi Browser Support :
TCP Port 4505~4530, Webviewer Port 80
Protocol
8000 ~ 8160
Unicast
224.126.63.1
OK Cancel
4524
5
Multicast are activated.
If setting the connection mode to ADSL, you cannot select UDP for the protocol type.
• Port(TCP) : Initially, <4520~4524> is set. It increases / decreases by 5.
- TCP : It has better stability and lower speed when compared to UDP, and recommended for internet
environments.
• Port(UDP) : Initially, <8000~8160> is set. It increases / decreases by 160.
- UDP : It has less stability and faster speed when compared to TCP, and recommended for local area
network (LAN) environments.
• Unicast/Multicast : Select one between Unicast and Multicast.
If selected Multicast, Multicast IP and TTL are activated.
- Unicast : Transfers data (UDP, TCP) individually to each connecting client.
- Multicast : Multiple client can receive the data (only in UDP) without putting additional traffic load to the
network.
• Multicast IP : User can directly input.
• TTL : Select from 0 ~ 255. Initial value for the TTL is set to <5>.
• Webviewer Port : Enter the port number for the Web Viewer. Initially, it is set to <80>.
• Multi Browser Support : You can use a Silverlight-compliant web browser to connect to the Web Viewer.
Multi browsers are enabled only if the TCP port is set to between 4505 and 4530 with the Web Viewer port
of 80. This is a security measure in order to enable Silverlight.
As UDP protocol may cause a packet loss on the network, it is recommended to use TCP protocols.
M
If you select UDP protocols and set port forwarding in the IP router, ending up with an unstable network connection,
configure the DMZ settings in the IP router as necessary.
4. When the protocol setup is done, press <OK>.
English _59
main menu
Notification
In a multi-browser environment, the web port should be set to 80 (private port).
J
Select one between 4505 and 4530 for RTSP
• Network Overview
Router (External IP: 109.112.92.133,
Local IP: 192.168.1.1)
Cable/ADSL
Modem
Internet
DDNS Server
(www.samsungipolis.com)
POWER
REC
DVR 1
DIGITAL VIDEO RECORDER
POWER
REC
DIGITAL VIDEO RECORDER
DVR 2
Local PC
DVR 1 DVR 2
System
WEB RTSP WEB RTSP
IP 192.168.1.200 192.168.1.200 192.168.1.202 192.168.1.202
Protocol TCP TCP TCP TCP
Private Port 80 4520~4524 81 4525~4529
Public Port 80 4520~4524 81 4525~4529
Connection Mode
Connection
Connection Mode Static IP
Bandwidth 2Mbps
IP 192.168.1.200
Gateway 192.168.1.1
Subnet Mask 255.255.255.0
DNS
Protocol
Manual 168.126.63.1
OK Cancel
Connection Mode
Connection
Connection Mode Static IP
Bandwidth 2Mbps
IP 192.168.1.202
Gateway 192.168.1.1
Subnet Mask 255.255.255.0
DNS
Protocol
Manual 168.126.63.1
OK Cancel
60_ main menu
Connection Mode
Connection
Protocol Type TCP
Port(TCP) 4520 ~
Port(UDP)
Unicast/Multicast
Multicast IP
TTL
Webviewer Port 80
* Multi Browser Support :
TCP Port 4505~4530, Webviewer Port 80
Protocol
8000 ~ 8160
Unicast
224.126.63.1
OK Cancel
Connection Mode
Connection
Protocol Type TCP
4524
5
Port(TCP) 4525 ~
Port(UDP)
Unicast/Multicast
Multicast IP
TTL
Webviewer Port 81
* Multi Browser Support :
TCP Port 4505~4530, Webviewer Port 80
Protocol
8000 ~ 8160
Unicast
224.126.63.1
OK Cancel
4529
5
• 1st Set Port Forwarding Setting
Port Forwarding is 4520~4524
(4520, 4521, 4522, 4523, 4524)
Port Forwarding is 80
MAIN MENU
SDR-3100
192. 168. 1. 200
TCP
4520
4520
• 2nd Set Port Forwarding Setting
Port Forwarding is 4525~4529
(4525, 4526, 4527, 4528, 4529)
SDR-3100
192. 168. 1. 202
TCP
4525
4525
SDR-3100
192. 168. 1. 200
TCP
80
80
Port Forwarding is 81
SDR-3100
192. 168. 1. 202
TCP
81
81
English _61
main menu
Connecting and Setting the Network
Networking may differ from the connection method, check your environment before setting the connection mode.
When no router is used
• Static IP mode
- Internet connection : Static IP ADSL, leased line, and LAN environments allows connection between the
DVR and remote user.
- DVR Network Settings : Set the <Connection Mode> in
<Connection> menu of the connected DVR to <Static IP>.
Consult your network manager for IP, Gateway and Subnet Mask.
• Dynamic IP (DHCP) mode
- Internet connection : Connect the DVR directly to a cable
modem, DHCP ADSL modem or FTTH network.
- DVR Network Settings : Set the <
Connection Mode> in
<Connection> menu of the connected DVR to <Dynamic IP>.
• ADSL (PPPoE: ID and password certification)
- Internet connection : An ADSL modem is directly connected to the DVR, where the ADSL connection
requires user ID and password.
- DVR Network Settings : Set the <
Connection> menu of the connected DVR to <ADSL>.
<
<User ID> and <Password> should be the same to the ADSL
Connection Mode> in
user information.
If you don’t know the ID and password, consult your ADSL service
provider.
Connection Mode
Connection
Connection Mode Static IP
Bandwidth 2Mbps
IP 192.168. 1.200
Gateway 192.168. 1. 1
Subnet Mask 255.255.255. 0
DNS
Connection Mode
Connection
Connection Mode ADSL
Bandwidth 600kbps
IP
Gateway
Subnet Mask
DNS Manual 168.126. 63. 1
User ID ID
Password
Protocol
Manual 168.126. 63. 1
OK Cancel
Protocol
192.168. 1.200
192.168. 1. 1
255.255.255. 0
************
OK Cancel
62_ main menu
When a router is used
To avoid IP address conflict with the DVR's static IP, check followings :
J
• Setting the DVR with a static IP
- Internet connection : You can connect the DVR to a router which is connected to an ADSL/Cable modem
or a router in a Local Area Network (LAN) environment.
• Setting the DVR Network
1. Set the <
2. Check whether the set IP address is in the static IP range provided by the Broadband Router.
IP, Gateway, and Subnet Mask : Consult your network manager.
3. Check the Gateway address and subnet mask are equal to those set in the Broadband Router.
• Setting the DHCP IP Address of the Broadband Router
1. To access the Broadband Router’s configurations, open a web browser on the local PC that is connected
to the Broadband Router and enter the router’s address (ex : http://192.168.1.1).
2. At this stage, make the local PC's windows network configurations to the below example :
Ex)
- Once connected to the Broadband Router, it prompts with password. While entering nothing to the User
Name field, enter “
- Access the router’s DHCP configuration menu and set its DHCP server activation, and provide the start and
end address.
Set the start address (192.168.0.100) and end address (192.168.0.200).
Connection Mode> in <Connection> menu of the connected DVR to <Static IP>.
Check whether the set IP address is in the static IP range provided by the Broadband Router.
If a DHCP server is configured with starting address (192.168.0.100) and end address (192.168.0.200), you should
J
set the IP address out of the configured DHCP range (192.168.0.2 ~ 192.168.0.99 and 192.168.0.201 ~
192.168.0.254).
IP : 192.168.1.2
Subnet Mask : 255.255.255.0
Gateway : 192.168.1.1
admin” into the password field and press <OK> to access the router configurations.
MAIN MENU
Above steps may differ from the router devices depending on the manufacturer.
M
English _63
main menu
• Setting Router’s Port Forwarding
1. Set the protocol to <
2. External Port Range : Enter the TCP Port set in the
Port(TCP)> in <Protocol> menu of the connected DVR.
<
If more than one DVRs are connected to the router, the
TCP port can be different.
3. Internal PC IP Address : Enter the IP address set to the
<
IP> in <Connection> menu of the connected DVR.
4. Internal Port Range : Set the same to the “External Port
Range”.
Above steps may differ from the router devices depending on the manufacturer.
M
Port forwarding is required when you want to access the DVR connected to the router from outside of the router’s
network.
In case of Port Forwarding Setting
1. Download the program.
Install it in your PC. Run <
To download visit http://www.simpleportforwarding.com/
download
TCP>.
Simple Port Forwarding>.
Connection Mode
Connection
Protocol Type TCP
Port(TCP) 4520 ~
Port(UDP)
Unicast/Multicast
Multicast IP
TTL
Webviewer Port 80
* Multi Browser Support :
TCP Port 4505~4530, Webviewer Port 80
Protocol
8000 ~ 8160
Unicast
224.126.63.1
OK Cancel
4524
5
2.
Click <(2)Do it now> in Check List.
Type your router information.
If you can’t find the exact router in the list, update the
router list or choose a similar router in the same
manufacturer.
3.
Click the icon for checking your router IP address.
b c
64_ main menu
Click <OK> for updating your router IP address.
Type your router Username & Password.
If you haven’t changed them, skip this procedure, for it
provides default value.
4.
Click <(4)Do it now> in Check List for choosing the
ports.
c
b
b
MAIN MENU
Click <
OK> for updating your router IP address.
IP Address : 192.168.1.200
Type : TCP
Start Port : 80
End Port : 80
IP Address : 192.168.1.200
Type : TCP
Start Port : 4520~4524
End Port : 4520~4524
c
English _65
main menu
5. After checking if the list is right, click <(5)Do it now> for
updating your router.
DDNS
You can set the DDNS site for a remote user’s network connection.
Using the mouse may help make setup easier.
1. Use the up/down buttons () in <Network> window to
move to <
DDNS>, and press [ENTER] button.
2. Use virtual keyboard to enter user inputs.
Refer to “Using Virtual Keyboard”. (Page 35)
• If selected <OFF> or <iPOLiS>, input fields are deactivated.
• If you select <
iPOLiS>, the “DDNS host address” item will
be displayed.
- Type your set ID in <
Product ID> field.
More specific information in “iPOLiS DDNS Setting”.
- Select <Use> in <Quick Connect> menu. After finishing
“iPOLiS DDNS Setting”, you can connect your DVR set with the address <http://www.samsungipolis.com/
HOMEDVR>.
The router used should support uPNP Port Forwarding function.
Note that uPNP Port Forwarding does not support UDP protocol.
If the program fails to read uPNP Port Forwarding List, try again after restarting the computer and router.
3. When the DDNS setup is done, press <OK>.
DDNS
DDNS Site iPOLiS
Server Name
Product ID HOMEDVR
Quick Connect Not Use Use
DDNS Host Address http://www.samsungipolis.com/HOMEDVR
www.samsungip...
OK Cancel
66_ main menu
DDNS Setting
DDNS is a short form of Dynamic Domain Naming System.
DNS (Domain Name System) is a service that routes a domain name consisting of user friendly characters (ex
: www.google.com) to an IP address consisting of numbers (64.233.189.104).
DDNS (Dynamic DNS) is a service that registers a domain name and the floating IP address with the DDNS
server so that the domain name can be routed to the IP address even if the IP is changed in a dynamic IP
system.
• Setting DDNS in the DVR
Set <
Protocol Type> in the <Protocol> menu of the connected DVR to the following :
Ex) Protocol Type : TCP
Port (TCP) : 4520~4524
DDNS Site : iPOLiS
iPOLiS DDNS Setting
1. Visit http://www.samsungipolis.com or
http://www.samsungipolis.co.kr and click <
2. If you have ID & PASSWORD, insert them.
Otherwise, click <
SIGN UP> for a new account.
LOGIN>.
MAIN MENU
3. After log in, register your set with your information.
b
b
c
English _67
main menu
4. After registration, you can see the list as below.
5. Select <
registration information.
6. You can see <
iPOLiS> and fill Server Name out with your
STATUS> changed to <ON> in 10 minutes,
DDNS
DDNS Site iPOLiS
Server Name
Product ID SDR3100HOME
Quick Connect Not Use Use
DDNS Host Address http://www.samsungipolis.com/SDR3100HOME
if all the network settings are right.
Live Transfer
Sets the quality of the image that is transferred from the DVR to the network.
Using the mouse may help make setup easier.
1. In the <Network> setting window, press the up/down
(
) button to move to <Live Transfer> and press the
ENTER] button.
[
The Live Transfer window appears.
2. Use the direction buttons (
◄ ►
) to move to a desired
item and set the value.
3. When the live transfer is done, press <OK>.
The resolution for real-time (live) transfer will be set to CIF(S).
(Page 53)
Live Transfer
Resolution
Quality Low
www.samsungip...
OK Cancel
CIF(S)
OK Cancel
68_ main menu
Mailing Service
You can send an e-mail to a DVR-registered user at a specific time interval, or if an event occurs.
If an event occurs with a channel where the camera’s video is set to <OFF> or the remaining recording count is set
M
to <
OFF>, only the text notification will be sent to the applicable email address.
The e-mail receivers are not able to adjust the attached image quality.
SMTP Setting
Sets the SMTP mail server.
Using the mouse may help make setup easier.
1. In the <Network> setting window, press the up/down
(
) button to move to <Mailing Service> and press the
[ENTER] button.
2. Select <
SMTP>.
You will see the SMTP setting window.
3. Use direction buttons (
◄ ►
) to move to a desired item
and set the value.
• ServerType : Displays the connected server type.
• Server : Enter a server to connect to.
• Port : Sets the communication port.
• Use Authentication : Check this if the SMTP server uses user authentication.
The account input box will be activated.
• User : Enter a user to use authentication when connecting to the SMTP server.
• Password : Enter the password of the SMTP server user.
• Secure Transfer : Select one from <Never> and <TLS(if Available)>.
• Sender : Use the virtual keyboard to enter the sender’s e-mail address.
Refer to “Using Virtual Keyboard”. (Page 35)
• TEST : Conducts the test on the server settings.
4. When the SMTP setting is done, press <
OK>.
Mailing Service
SMTP
ServerType SMTP mail Server
Server
Port 25
User
Password
Secure Transfer Never
Sender ex. user@example.net
TEST
Use Authentication
Event
OK Cancel
Group Recipient
MAIN MENU
English _69
main menu
Event Setting
You can set the interval and type of the event that will be sent to the user.
Using the mouse may help make setup easier.
1. In the <Network> setting window, press the up/down
(
) button to move to <Mailing Service> and press the
[ENTER] button.
2. Select <
3. Use direction buttons (
Event>.
◄ ►
) to move to a desired item
and set the value.
• Event Interval : Set the event interval.
If a series of events occurs, the e-mail will be sent at the specified
interval, not on each event.
• Use Event Transfer : Select an event type to send if an event
occurs.
If the selected event occurs, the e-mail will be sent to the group that has the recipient authority.
4. When the event setting is done, press <OK>.
Group Setting
You can set the group to whom the e-mail is sent, and specify the permission for each group.
You can add recipients for each group in the <
The recipient is set separately from the DVR user group.
Using the mouse may help make setup easier.
1. In the <Network> setting window, press the up/down
(
) button to move to <Mailing Service> and press the
ENTER] button.
[
2. Select <Group>.
3. Use direction buttons (
◄ ►
) to move to a desired item
and set the value.
• Add : Select <Add> and use the virtual keyboard to add a
group.
Refer to “Using Virtual Keyboard”. (Page 35)
• Delete : Deletes the selected group.
• Rename : You can reset the recipient permission of an existing group.
• Recipient Permission : Set the permission of the recipient group.
4. When the group setting is done, press <OK>.
Recipient> menu item.
Mailing Service
SMTP
Event Interval 10 min
Use Event Transfer
Motion
Change P/W HDD Info Video Loss
Power On/Off Manual Record
Mailing Service
SMTP
Group
Recipient Permission
Motion
Change P/W HDD Info Video Loss
Power On/Off Manual Record
Event
OK Cancel
Event
OK Cancel
Group
Group
Add Delete Rename
Recipient
Recipient
70_ main menu
Recipient Setting
You can add/remove a recipient(s) to/from the specified group and edit the group if necessary.
Using the mouse may help make setup easier.
1. In the <Network> setting window, press the up/down
(
) button to move to <Mailing Service> and press the
[ENTER] button.
2. Select <
3. Use direction buttons (
Recipient>.
◄ ►
) to move to a desired item
and set the value.
Mailing Service
SMTP
Group All Group
Group Name e-Mail Address Del
Event Group
OK Cancel
MAIN MENU
Recipient
Add
Previous/ Next Page
• Add : You can select a recipient name, e-mail address or
group.
You should have created a group in the <Group> menu
item before you can add a user to the group.
For inputting the recipient name and email address, refer to
“Using Virtual Keyboard”. (Page 35)
4. When the recipient setting is done, press <OK>.
Mailing Service
SMTP
Group ABC
Group Name e-Mail Address Del
Event Group
Add recipient
Name
Email
Select Group ABC
OK Cancel
OK Cancel
Recipient
Previous/Next Page
Add
English _71
main menu
CONTROLLING A PTZ DEVICE
The DVR enables you to adjust the settings of a PTZ camera as well as an ordinary one to your preference.
PTZ Device
The PTZ device can be activated only if a channel in connection with the PTZ camera is selected.
Getting started with PTZ
The PTZ camera is available, only if a channel is selected, in the following way :
Using the remote control buttons
Press the [PTZ] button on the remote control.
Using the launcher menu
Click PTZ <
Using the right-click menu in Live mode
PTZ
> to display the live launcher.
Right-click any area on the screen to display the context menu, and
PTZ Control>.
select <
Using icons on the live screen
Click the PTZ < > icon on the live screen.
2013-01-01 01:10:25
2013-01-01 01:10:25
Scene Mode
PTZ Control
Zoom In
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
The PTZ function is available only if the PTZ camera is
M
connected so that the <
> icon is displayed on the
screen.
72_ main menu
Using the PTZ camera
You can use one camera to perform all functions of PAN, TILT and ZOOM for monitoring multiple places and
set the preset to your preference in a desired mode.
1. Launch the <PTZ Control> menu.
As the PTZ <
yellow, you access the “
> icon on the bottom right corner turns
PTZ Control” mode to display the
“PTZ Control” menu.
Be sure to configure PTZ working environments before
M
operation, since the PTZ Working(Active) mark can be
PTZ Control CAM01
appeared to be activated even when PTZ is not operative.
2. Use the PTZ wheel in the launcher menu to adjust the
monitoring area, or use the direction buttons (
◄ ►
) on
the remote control to move the camera to a desired place.
• PTZ Wheel : Clicking a nearer point to the center will move in that direction slowly; clicking a farther point
from the center will move fast.
Keep clicking left to rotate the lens counter clockwise; keep clicking right to rotate the lens clockwise.
• Zoom ( ) : You can use the Zoom function of the PTZ camera.
• IRIS ( ) : Adjusts the intensity of radiation incoming to the iris.
• Focus ( ) : Enables you to adjust the focus manually.
• Auto Pan : The camera automatically runs between the two points that you selected.
• Scan : The camera moves to the preset points in the specified sequence.
If multiple presets are specified, the PTZ camera will automatically move to all of the preset points one at a
time.
• Pattern : Makes the PTZ camera remember and follow the past route.
The functions of Auto Pan, Scan and Pattern are supported in the protocols of Samsung, Panasonic and Pelco, and are
different in terms of the name and setting, depending on the protocols of Samsung, Panasonic and Pelco.
(Panasonic : Auto Pan, Sequence, Sort / Pelco : Auto Pan, Frame Scan (Scan), Pattern)
2013-01-01 01:10:25
Auto Pan
Select
Scan
Select
Pattern
Select
Preset
Select
Exit
Camera Setup
Select Preset
Save Rename
Delete Delete All
Delete Delete All
MAIN MENU
Before entering the PTZ device control mode, set the values of the PTZ device in the <Setting the PTZ> menu.
M
(Page 46)
English _73
main menu
**
MAIN MENU
**
...
VIDEO SET...
PRESET...
ZONE SET...
AUTO SET...
ALARM SET...
OTHER SET...
CLOCK SET...
SYSTEM INFO...
SAMSUNG PROTOCOL
ADDR 0
TYPE RS-485,HALF
BAUD 9600
LENS OK!
TILT OK!
PAN OK!
Preset Setting
A preset is a set of specific target points of a PTZ camera, and up to 127 presets per a camera can be stored.
1. In PTZ Control mode, use the direction buttons to adjust the camera in a desired direction.
2. Select the <
The virtual keyboard for inputting the preset will appear.
Refer to “Using Virtual Keyboard”. (Page 35)
• Save : You can save the preset settings.
• Rename : You can change the settings of the existing presets.
• Delete : Deletes the selected preset.
• Delete All : Deletes all existing presets.
M
3. Press <OK>.
The preset will be saved as a name that you entered.
Camera Setting
A PTZ camera has its own menu system. Optimize the PTZ camera according to the DVR.
1. Connect the PTZ camera to the DVR and run the PTZ
camera again to display the camera’s protocol setting
window.
2. Check the protocol ID of the camera.
In “Device > Setting the PTZ”, enter the PTZ camera ID in the
ID input box of the channel that is connected to the PTZ camera.
(Page 46)
Save> key.
If you replace the camera of the channel that stores the preset list with a new one, you should reset the preset
accordingly.
2013-01-01 01:10:25
SAMSUNG PROTOCOL
ADDR 0
TYPE RS-485,HALF
BAUD 9600
LENS OK!
TILT OK!
PAN OK!
3. Select <Camera Setup> in the PTZ Control menu.
The camera-specific menu appears.
You can configure the settings of only those cameras that support
the protocols of Samsung, Pelco D/P, AD and Panasonic.
If you are setting Auto Pan or Pattern in the camera menu, press
and hold the appropriate button for a certain time so that the button
operation can be different from that in normal PTZ setting.
74_ main menu
Camera Setup
Exit
2013-01-01 01:10:25
MAIN MENU
**
CAMERA SET
VIDEO SET...
PRESET...
ZONE SET...
AUTO SET...
ALARM SET...
OTHER SET...
CLOCK SET...
SYSTEM INFO...
**
...
search & play
SEARCH
You can perform the search for recorded data by the time or by the search criteria such as an event.
You can access the <Search> menu directly in Live mode.
1. In Live mode, right-click any area of the screen.
The Live menu appears.
2. Select <
Search>.
Or, press the [SEARCH] button on the remote control.
2013-01-01 01:10:25
Scene Mode
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
SEARCH & PLAY
3. The Search menu appears.
2013-01-01 01:10:25
4. The search can be restricted by the Auto Delete function.
Refer to “Setting the Recording > Record Option”.
(Page 54)
Overlapped data : It only appears if there exists overlapped
M
data on a certain time, produced due to the change of DVR’s
Time Search
Event Search
Backup Search
Motion Search
Return
time setup. The latest data comes first, from <List0>.
It does not appear in <
Backup Search>.
Time Search
You can search for recorded data of a desired time.
As the time to display may be different depending on the time zone and the DST standard time, the time of
data recorded in the same time can be displayed differently depending on time zone and DST settings.
Using the mouse may help make setup easier.
1. Select <Time Search> in the <Search> menu.
2. Select a date to search.
Refer to “Using the Calendar”. (Page 34)
3. The record data on the specific date will be listed.
The display bar is different according to the data type.
So check the data type for the color in the left pane.
4. Use direction buttons (
and press the [
ENTER] button.
◄ ►
) to set the search criteria
• Go to First : Moves to the earliest date.
• Go to Last : Moves to the most recent date.
• Time : Enter a time to perform the search or use the up/down button <>> to select one.
Time Search
2013-01-01
2013/01/01 00:01:17
Standard Schedule
Motion Etc
V.Loss
Go to First Go to Last
Overlapped Data List1
00:01
All Data
CAM 01
CAM 02
CAM 03
CAM 04
Play Return
Zoom In Zoom Out
English _75
search & play
• Zoom In : The map enlarges in detail.
It will switch in the sequence of 24 hours - 16 hours - 8 hours
- 4 hours.
• Zoom Out : The map will switch in the reverse order of the
Time Search
2013-01-01
Go to First
Overlapped Data List1
All Data
detailed mode above.
It will switch in the sequence of 4 hours - 8 hours - 16 hours
- 24 hours.
Double-click a desired time to zoom it in/out.
M
2013/01/01 00:01:17
Standard Schedule
Motion Etc
V.Loss
• Preview : Click <Channel> and select (click, drag) a time in
Duration> to display a still image for the portion.
<
- If the selected channel does not contain any recorded data, it will be marked black.
5. Select a data item and click <Play>.
The screen switches to the data playback mode.
Event Search
You can search for events by the channel and play them.
Using the mouse may help make setup easier.
1. Select <Event Search> in the <Search> menu.
2. Use direction buttons (
and press the [
All record events on a specific date will be found. (Normal/
◄ ►
ENTER] button.
) to set the search criteria
Schedule recording included)
• Date/Time Preview : If you select a data item in the list, the
still image of the selected data will be displayed in the left
preview pane.
• Event : Displays the type of the event that occurred.
3. Select a data item and click <
Play>.
The screen switches to the event data playback mode.
Event Search
CAM 01
2013-01-01
Overlapped Data List1
2013/01/01 00:01:22
No. Date/Time Preview Event
3 02:47:54 ~ 02:48:59 Motion
2 00:39:06 ~ 00:40:30 Motion
1 00:01:22 ~ 00:02:28 Motion
Go to Last
00:01
CAM 01
CAM 02
CAM 03
CAM 04
Play Return
Play Return
Zoom In Zoom Out
Go to First Go to Last
Previous/Next Page
76_ search & play
Backup Search
Searches for backup data in the connected backup device.
Only data in the format of DVR is included in the search.
Refer to <Type> in “Backup > Setting the Backup”. (Page 57)
Using the mouse may help make setup easier.
1. Select <Backup Search> in the <Search> menu.
2. Use direction buttons (
and press the [
◄ ►
ENTER] button.
) to set the search criteria
Backup Search
No. Folder File Name
1 20130101 16190000
• Record Period : Displays the record period.
• Channel info : Displays the recorded channel.
• Play Start Time : Select a time that you start playing.
3. Select a data item and click <
Play>.
The screen switches to the backup data playback mode.
File Name 16190000
Record Period 2013-01-01 01:01:01 - 2013-01-01 01:01:10
Play Start Time 2013-01-01 01:01:01
Play Return
Motion Search
If a motion is detected in each channel, you can set a desired area to perform the search.
You can use the mouse to select the related items.
1. Select <Motion Search> in the <Search> menu.
2. Use direction buttons (
and press the [
If you set the motion area to <Manual Area>, the <Setup>
◄ ►
ENTER] button.
) to set the search criteria
button will be activated.
• Motion Region : Select an area to perform the search.
- All Area : Searches for all areas of the selected channel.
- Current Area : Searches for the motion area for each
channel specified in “Motion Detection > Setting the
Motion Detection Area”. (Page 55)
- Manual Area : You can set the motion area manually.
• Setup : The Setup button will be activated only if you have
set the motion area to Manual. Press this button to display
the area setting window.
• Date/Time : The Date/Time will be automatically set by the
hour, and the end time will be automatically set to one hour
later than the start time if it is set.
• Preview : Select a data item in the list to display the still
image of the item.
3. Select a data item and click <Play>.
The screen switches to the motion data playback mode.
Motion Search
Channel CAM 01 Motion Region All Area
Date/Time 2013-01-01 03:41:18 2013-01-01 05:11:44
No. Start Time
7 01:01:30
6 01:01:25
5 01:01:20
4 01:01:15
2013/01/01 01:01:30
3 01:01:10
2 01:01:05
1 01:01:01
Motion Region
CH1
Play Return
OK Cancel
USB:USB2FlashStorage
Channel info 1
Go to First Go to LastOverlapped Data List1
Individual
Previous/Next Page
Previous/Next Page
Apply to All CH
Setup
Search
SEARCH & PLAY
English _77
search & play
2013-01-01 01:10:25
PLAYBACK
Play
You can play data stored in the HDD and backup a desired portion of the data.
Using the mouse may help make setup easier.
1. In Live mode, click <Play> in the right-click menu or
< > in the launcher menu, or press the Play button on
the remote control.
2. Use the up/down button (
For data search, refer to <Search>. (Page 75)
3. Select a data item and click <Play> in the Search menu.
The selected data is played and the play launcher appears
on the screen.
If there is an existing data, <Play> will start immediately without
performing the search.
• Playback Information : Displays the date and time of the
current data in the top corner.
) to select a menu.
2013-01-01 01:10:25
Scene Mode
Audio Off
Freeze
Stop Alarm
Record
Play
Search
Backup
Main Menu
Shutdown
Hide Launcher
Logout
• Backup : Click < > to set the current time to the start
time of backup; you can specify a backup area using the
mouse (yellow triangle).
Click <
> again to set the current time to the end time of
the backup and the “Backup Range” window appears.
- Type : Supports formats of DVR and SEC.
Refer to a list of formats in “Setting the Backup”.
(Page 57)
- Device : Select a backup device.
- Check Capacity : Enables you to check the capacity of
the selected storage device.
4. If you want to return to the Live screen in Play mode, click <
[] button on the remote control.
Backup Range
Start End
2013-01-01 00:01:06 2013-01-01 01:10:25
Device USB Storage Type DVR
Folder \20130101\ Filename 0001
Check capacity
OK Cancel
> in the launcher menu or press the
Backup
Used
Free
Change
REC
78_ search & play
Using the Playback Button
b c m n
Part Names Functions
Play Timeline Indicates the current playback point, and can be used to move.
Skip Backward Moves backward by unit time.
b
Backward Fast
c
Play
Backward Slow
Play
Step Backward Moves backward by one frame at a time.
Pause Stops playing the current video temporarily.
Stop Stops playback and moves to the live screen.
Used for quick backward playback.
Used for backward frame-by-frame search while in PAUSE.
SEARCH & PLAY
REC
Step Forward Moves forward by one frame at a time.
Forward Slow
Play
Forward Fast Play Used for quick forward playback.
Skip Forward Moves forward by unit time.
Return Return to the search setup screen.
Audio
m
REC Records all channels in Live mode.
n
Partial Backup
Mode Switch Click a desired playback mode or press [MODE] to switch the screen mode in sequence.
Ensured to play forward up to 4 channels simultaneously at a low speed.
In a split mode, the real time playback may not be supported, depending on the record
quality, resolution and number of channels. And some frame rates may be supported.
Sets Audio ON/OFF.
If using both web view and DVR set simultaneously, the audio signal will be output from the
DVR set.
Begins backup of the selected section of the video being played, with the specified starting/ending
point.
English _79
web viewer
web viewer
INTRODUCING WEB VIEWER
What is Web Viewer?
Web Viewer allows remote access to your DVRs. You have
access to live video, archived video etc.
Product Features
• Remote access from a standard browser
• Supports 1, 4 camera viewing formats (maximum of 4
cameras in the list).
• Gets JPEG, BMP format images to print and save to “Print
or Save JPEG, BMP format images”.
• Record video in AVI format-compatible with popular media
players. (needed the H.264 codec)
System Requirements
The following lists the minimum suggested hardware and operating system requirements needed to run the
Web Viewer.
Windows XP Professional
OS
Windows 2000
Windows Vista Home Basic / Premium
Windows 7
Safari 5.1.1 or later version
Web Browser Internet Explorer 6.0.2900.2180 or higher
CPU Intel Pentium 4, 2 GHz
Memory 512 MB
Monitor High Color 16-bit 1024 x 768
HDD
Even for computers of higher performance than recommended, you may experience frame skipping with the Web
J
Viewer if the computer is overloaded showing more than 80% of CPU usage.
50 MB(Installation space required)
* Additional HDD space required for recording.
Recorded file size will vary depending on recording quality settings.
80_ web viewer
CONNECTING WEB VIEWER (MAC)
Safari on MAC.
If you want to use DVR Web Viewer with Safari Browser on a Mac, please refer to this user guide and install
Multi Viewer with firmware upgrade if necessary.
• Brower versions available: Safari 5.1.1 or later version
• Silverlight: 4.0.60831.0 or later
1. Click [Click now to install] to display the installation
screen as shown.
WEB VIEWER
2. Double-click the [
Silverlight plug-in installation screen as shown.
3. Click [
4. Click [
Continue] to start installing Silverlight plug-in.
When done, you will see the screen as below.
Close] to exit from the Silverlight plug-in installation
screen.
Silverlight.pkg] icon to display the
English _81
web viewer
• If Microsoft Silverlight plug-in is already installed
1. Use a web browser to connect to the DVR.
2. If Silverlight plug-in is already installed, you will see the
screen as shown.
3. If the login screen does not appear, check if the DVR set is
connected properly with a valid IP address.
USING LIVE VIEWER (MAC)
The Live Viewer screen consists of following :
c
b
This displays the IP address and the model name of the connected DVR.
b These menus consist of <
c These buttons are used for the screen split and full screen mode.
Shows the IP address and model name of the connected DVR.
Select to turn the sound on/off.
Select <
These buttons are used for sequence and changing the screen channel.
These buttons are used for capture, print, and save the image.
Shows the channel of the connected DVR.
These buttons are used for PTZ related functions.
This displays the screen for connected camera with DVR.
DVR Time> or <PC Time> for the OSD time information display setting of the Live Viewer.
When you can’t play the file recorded in web, install the H.264 CODEC
ex) MAC: perian_1.2.3.dmg (http://perian.org)
LIVE>, <ABOUT>.
82_ web viewer
CONNECTING WEB VIEWER (WINDOWS)
1. Open your web browser and type the IP address or URL
of DVR into the URL address box.
The basic URL of the DVR is as following in case of MAC
M
address :
http://www.samsungipolis.com/User ID
You can also use registered URL which setups up in the Setup menu of your DVR.
2. Set the Admin ID and password same to those of the DVR
Admin.
For general users, enter the DVR user ID and password.
The default password can be exposed to a hacking thread so
J
it is recommended to change the password after installing the
product.
Set password for your wireless network if you use the product with a wireless router. Being not protected with
password or using the default wireless router password may expose your video data to potential threat.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
It allows up to 4 simultaneous access including the Admin and general users.
M
It does not allow multiple login of the Admin user.
Initial password of the Admin user is set to “4321”.
Password of the Admin and general users can be changed in <Permission Management> menu of the DVR.
Normal users should have set <Viewer> under <Permission Management> to <Use> before connecting to the
Web Viewer. (Page 35)
All settings are applied by the DVR’s settings.
http://www.samsungipolis.com/HOMEDVR
WEB VIEWER
3. Click <Install ActiveX Control…>.
Downloading Active-X control may take several minutes
according to the security settings on your PC.
4. Click <
Install>.
English _83
web viewer
5. You may have “Windows Security Alert” that attempts to
block this with the Windows Firewall. In that case, click
Unblock> to start Web Viewer.
<
6. Installation is complete.
Now you can see the main screen of Live Viewer.
USING LIVE VIEWER (WINDOWS)
The Live Viewer screen consists of following :
c
b
This displays the IP address and the model name of the connected DVR.
b These menus consist of <
c These buttons are used for the screen split and full screen mode.
Shows the IP address and model name of the connected DVR.
Select to turn the sound on/off.
Select the format of OSD information that will be displayed on Live Viewer.
Select <
These buttons are used for sequence and changing the screen channel.
These buttons are used for capture, print, and save the image.
Shows the channel of the connected DVR.
These buttons are used for PTZ related functions.
This displays the screen for connected camera with DVR.
DVR Time> or <PC Time> for the OSD time information display setting of the Live Viewer.
The initial split-screen mode is set according to the number of channels connected to DVR. You can change the
M
split-screen mode by clicking buttons for split-screen modes.
LIVE>, <SEARCH>, <SETUP>, <ABOUT>.
84_ web viewer
OSD Information Display
The channel number, video size, and IP address of the
connected DVR are displayed.
b This icon will appear if the audio signal is currently being
output.
c The current date and time will be displayed according to the
selected time information display setting <
<PC Time>.
Motion icon appears when motion is detected. It disappears
when pressed the [
It displays whether the PTZ controls are active.
If you have set PTZ cameras for the DVR, “PTZ” is displayed on
M
the screen. Select a PTZ camera channel and use the [
ALARM] button of the DVR.
DVR Time> or
PTZ] button for camera control.
Split-Screen
You can change the split mode by clicking each number icon.
b
WEB VIEWER
c
SINGLE MODE QUAD MODE
• Click <
The screen displays the selected camera connected to the DVR in
“
SINGLE MODE”.
• Click <
The screen displays the selected camera connected to the DVR in “
MODE
• Click <
The screen displays the selected camera connected to the DVR in “
SCREEN MODE
Double clicking on the screen or pressing any button of the keyboard
returns to the previous mode.
> button.
> button.
”.
> button.
”.
QUAD
FULL
English _85
web viewer
Connected DVR
This displays the IP address and the status of the connecting DVR.
Connection failure message
M
No Response : Appears when the DVR does not respond.
Access Denied : Appears when the maximum number of users is exceeded.
The number of simultaneous connections are limited to 4.
Setting the Display of the OSD Time Information
Select <DVR Time> or <PC Time> for the OSD time information display
setting.
• DVR Time : Based on the time of the connected DVR.
• PC Time : Based on the time of the PC currently running the Web Viewer.
• Audio : Sound On/Off
Changing the Live Screen Mode
• SEQUENCE : When this button is clicked, screens are switched at a
preset interval.
In SINGLE MODE, the channel numbers are sequentially switched from 1
to 4.
Preset interval (10 seconds)
• PREVIOUS : When this button is clicked, the previous screen appears.
• NEXT : When this button is clicked, the next screen appears.
In SINGLE MODE, the channel numbers are sequentially switched from 1
to 4.
Saving the Live Screen on the PC
• CAPTURE : Saves the current screen into a BMP or JPEG
file.
The default saving path is “C:\Program Files\Samsung\DVR
M
Web Viewer\SnapShot\Live”. To change the saving path, click
<
SAVE PATH ( )> button and then select the path you
want. For Windows Vista or 7, the saving path is “C:\users\
(user ID)\AppData\LocalLow\Samsung\DVR Web Viewer\
SnapShot\” by default.
The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_index”
Ex) 192.168.1.200_554_20130101_134132_01_00
86_ web viewer
• PRINT : Prints out the selected screen out of the currently
displayed live screens. It also prints the IP address, time,
camera number and the current event status together.
• RECORD : Saves the current image on the screen and
saves it as a avi video file.
To record it, it is required at least 1GB of available space.
M
The default saving path is “C:\Program Files\Samsung\DVR
Web Viewer\VideoClip\Live”. To change the saving path, click
<SAVE PATH ( )> button and then select the path you
want. For Windows Vista or 7, the saving path is “C:\users\
(user ID)\AppData\Local-Low\Samsung\DVR Web Viewer\VideoClip\”.
The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_index”
Ex) 192.168.1.200_554_20130101_135105_01_00
For AVI Save, you need the H.264 codec for playing saved files.
HDD Minimum Free Size : During the recording, if there is no more capacity available in the HDD than set free space
will prompt with a popup message : “Cannot record due to insufficient disc space in the HDD”.
WEB VIEWER
Changing the Live Screen Channel
• Blue numbers : The channel connected to the current live screen.
• Gray numbers : The channel not connected to the current live screen.
If you select 4-split mode, the channel button for each of cameras 1 ~ 4 will turn
blue.
English _87
web viewer
Using PTZ Camera
Click the direction buttons to control the camera.
• <
You can zoom in or out an image by using the ZOOM button.
• <
You can adjust the entering light amount by using the IRIS button.
• <
You can adjust the focus by using the FOCUS button.
• MENU : Appears the camera menu screen.
>
>
>
88_ web viewer
• Preset : Moves the lens direction to a preset direction.
1. If you click a preset, the camera moves to the selected
preset's position.
2. You can delete the selected preset or all presets.
3. You can save a new preset number and name.
You can save presets up to 127.
M
• Auto Pan : Moves the camera lens direction between 2
points set for the camera.
• Scan : Moves the camera lens direction between 2 preset
points of the camera.
• Pattern : You can set camera various movement patterns
such as zoom, move, etc. so that a camera automatically
moves according to the pattern.
While the DVR controls a PTZ camera, Web Viewer cannot
M
control the camera.
Camera menu setup is only available for camera supporting
the function.
Each function of PTZ is same to that of the DVR.
Pan/Tilt of the Smart dome camera is manipulated
automatically to center the camera to the mouse clicked point.
If you drag the mouse using the left button on a certain point,
Pan/Tilt of the Smart dome camera is manipulated
automatically to center the camera to the middle point between
the dragging start and end position.
Upward dragging will zoom out, while downward dragging will zoom in.
Tilt of Power PTZ operates properly within 45°.
Power and Pan Tilt functions are only available for camera supporting the functions.
Ex : Samsung SCP-2371
WEB VIEWER
English _89
web viewer
USING SEARCH VIEWER
The Search Viewer screen consists of following :
c
b
This displays the IP address and the model name of the connected DVR.
b There are 4 tabs available: <
c Switch to a split mode.
Shows the IP address and model name of the connected DVR.
Select the format of OSD information that will be displayed on Live Viewer.
These buttons are used for capture, print, and save the image.
This displays a calendar at which you can search the recorded video.
The duplicate check list will appear If there are found duplicates in the same timeline.
The duplicated items will be listed in latest-first order.
This displays a timeline at which you can search the recorded video by the time.
These buttons are used for controlling playback.
This displays the screen for playback of recorded video.
LIVE>, <SEARCH>, <SETUP>, <ABOUT>.
<SEQUENCE>, <PREVIOUS>, <NEXT> buttons are not available in SEARCH menu.
M
During the DVR backup, you may have a trouble accessing CMS & Web Search.
Web Viewer on only Internet Explorer can support “Search” function.
90_ web viewer
Split-Screen
You can change the split mode by clicking each number icon.
SINGLE MODE QUAD MODE
WEB VIEWER
• Click <
The screen displays the selected camera connected to the DVR in
“
SINGLE MODE”.
• Click < > button.
The screen displays the selected camera connected to the DVR in
“
QUAD MODE”.
> button.
Connected DVR
This displays the IP address and the status of the connecting DVR.
Connection failure message
M
No Response : Appears when the DVR does not respond.
Access Denied : Appears when the maximum number of users is exceeded.
The number of simultaneous connection is limited to 2.
English _91
web viewer
Saving the Live Screen on the PC
• CAPTURE : Saves the current screen into a BMP or JPEG
file.
The default saving path is “C:\Program Files\Samsung\DVR
M
Web Viewer\SnapShot\Search”. To change the saving path,
click <SAVE PATH ( )> button and then select the path
you want. For Windows Vista or 7, the saving path is “C:\
users\(user ID)\AppData\LocalLow\Samsung\DVR Web
Viewer\SnapShot\”.
The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_index”
Ex) 192.168.1.200_554_20130101_134132_01_00
• PRINT : Print out the current screen. It also prints IP
address, time, camera number and current event state.
• RECORD : While in playback, press this button saves the
video data of the selected channel as an AVI file. (It is saved
in the designated folder on your PC.)
To stop recording, click this button again.
To record it, it is required at least 1GB of available space.
M
The default saving path is “C:\Program Files\Samsung\DVR
Web Viewer\VideoClip\Search”. To change the saving path,
click <
SAVE PATH ( )> button and then select the path you want. For Windows Vista or 7, the saving path is “C:\
users\(user ID)\AppData\LocalLow\Samsung\DVR Web Viewer\VideoClip\”.
The file is automatically named as following : “IP address_Port number_YYYYMMDD_HHMMSS_camera number_index”
Ex) 192.168.1.200_554_20130101_135105_01_00
For AVI save, you need the H.264 codec for playing saved files.
92_ web viewer
Searching the Recorded Video in the Calendar
If the video data has been recorded on a date, the date is
distinguished in green. If you click the date, the recorded video
information is displayed in the time line. When you click
Today>, it will be synchronized with the system time (date) of
<
the current PC.
Check duplicates
If there are found duplicates in the same timeline after you changed the DVR
time, those duplicates will be listed in the <0> order with the latest one on top.
Searching the Recorded Video in the Timeline
It displays the recorded video data status on the DVR after a date is
selected. The normal mode displays the time ranging from 0 to 24 Hours
while the extension mode displays the time every 2 hours.
[Normal Mode]
• If you click <
• Each time line represents 1 hour.
> button, it changes to the extension mode.
WEB VIEWER
[Extension Mode]
• If you click <
• Each time line represents 5 minutes.
M
> button, it changes to the normal mode.
The channels are ranging from CH01 to CH04.
English _93
web viewer
Controlling Playback
b c
Fast Backward : Reverse-plays faster(2x~64x).
b Reverse Play : Performs Reverse Play.
c Play : Performs playback.
Fast Forward : Plays faster(2x~64x).
Go to First :
Step Backward : Performs one step reverseplay by one frame.
Pause : Stops the playback temporarily.
Step Forward : Performs one step forward by one frame.
Go to Last : Moves the last time of recorded video in the time line.
M
Moves the beginning time of recorded video in the time line.
Only the admin account can play the audio signal during the playback.
If using both web view and DVR set simultaneously, the audio signal will be
output from the DVR set.
VIEWER SETUP
You can configure the DVR settings remotely on the network.
To configure the DVR settings, click <Setup>.
System
You can configure the various settings of the DVR system.
Date/Time/Language
For more information, refer to <Date/Time/Language> in the <System Setup> menu. (Page 32)
1. Select <Date/Time/Language> in the System menu.
2. Configure the DVR settings according to your system
environment.
• Date/Time
Set the date and time.
94_ web viewer
• Time Synchronization Setup
Set the time synchronization.
• Display
Date Format
Time : Select a time format to display on the screen.
• DST (Daylight Saving Time)
DST is displayed an hour ahead of the standard time of the
time zone.
• Language
Select a preferred language for the DVR.
: Set the date type.
Holiday
WEB VIEWER
You can set specific dates to Holidays according to your
preferences.
For more information, refer to <Setting Holiday> in the
<System Setup> menu. (Page 34)
Permission Management
For more information, refer to <Permission Management> in the <System Setup> menu. (Page 35)
• Admin
You can change the admin ID or the password.
English _95
web viewer
• Group
Users are classified into groups and the permission can be set
according to the group.
First of all, add a group.
• User
You can add, change or remove a user or users.
• Setup
You can set the user permission.
System Management
For more information, refer to <System Management> in the <System Setup> menu. (Page 40)
• System Information
You can see information of the current system.
Check the software version, broadcast format and MAC
address.
96_ web viewer
Device
You can check a list of devices that are connected to the DVR and configure the necessary settings.
Device> in the menu screen.
Click <
For more information, refer to “Setting the Device”. (Page 44)
Camera
• Camera
You can configure the settings of the camera that is connected
to the DVR.
• Privacy Region
You can specify a certain area of the camera video to be
protected for your privacy.
WEB VIEWER
• PTZ
You can configure the settings of the PTZ camera that is
connected to the DVR.
Set the ID and protocol.
English _97
web viewer
Storage Device
You can check and change the settings of the storage device.
• Device
You will see a list of storage devices that are connected to the
DVR.
You can check the type, used/total, usage and status of the
device.
• HDD Alarm
You can set the alarm output channel and the alarm duration
for an error.
Remote Device
Specify the use of remote control and the remote control ID so
that you can synchronize with the DVR.
Monitor
• Monitor
You can configure the monitoring screen settings and set the
output system.
98_ web viewer
• Mode
You can switch between live mode and play mode.
Record
For more information, refer to <Setting the Recording>. (Page 51)
Recording Schedule
If you set a recording schedule for a specific date and time,
the recording will start at that specific time.
WEB VIEWER
- Apply to All CH : Click <Apply to All CH> to display the
confirmation window.
Event Record Duration
You can set the start and end times of recording that will be
activated if an event occurs.
English _99
web viewer
REC Quality & Resolution
• Standard/Event
You can set the resolution, frame rate and recording quality for
each channel.
Record Option
You can set the Disk End Mode.
Event
For more information, refer to <Setting the Event>. (Page 55)
Motion Detection
You can set the motion detection mode and the sensitivity as
well as the alarm output type and the duration.
100_ web viewer
Loading...
