Samsung SCHR970 Users Manual

SCH-R970

This document is watermarked because certain important information in the document has not yet been verified. This document has been sent to you as
a draft and for informational purposes only. The document should only be used for internal purposes and may not be distributed outside of Samsung,
except to Samsung's carrier customer for testing purposes. Distributing the document outside of Samsung, except to Samsung's carrier customer for
testing purposes could result in legal exposure to the company if the preliminary, unverified information in the draft turns out to be inaccurate.

DRAFT

FOR INTERNAL USE ONLY

ANDROID SMARTPHONE

User Manual

Please read this manual before operating your

phone and keep it for future reference.

GH68_3XXXXA Printed in Korea

Intellectual Property

DRAFT

FOR INTERNAL USE ONLY

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone
System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the
rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain
with SAMSUNG and its suppliers.

Open Source Software

Some software components of this product, including but not limited to 'PowerTOP' and 'e2fsprogs', incorporate source code
covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and
other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://opensource.samsung.com

.

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING

USC_SCH-R970_UM_Eng_MBD_CB_031913_D1

THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED

DRAFT

FOR INTERNAL USE ONLY

WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS
OR BENEFITS.

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,
OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY.
SAFE™: "SAFE™" (Samsung for Enterprise) is a mark for a Samsung device which has been tested against Samsung's own

internal criteria for interoperability with certain third party security-related solutions for MDM and VPN. The testing includes field
testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the
Samsung device. During the testing, the device is tested with the security solutions to see if the solutions work with the device as
described by the third party security solution providers. The testing, for example, includes field testing with local network
connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. For more
information about Samsung's SAFE™ program, please refer to

Disclaimer of Warranties: EXCEPT AS OTHERWISE PROVIDED IN THEIR STANDARD END USER LICENSE AND WARRANTY, TO THE
FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD., SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND
THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE "SAMSUNG ENTITIES") EXPRESSLY DISCLAIM ANY AND ALL
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
INTEROPERABILITY OR NON-INFRINGEMENT, WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™
DEVICES AND APPLICATIONS TESTED WITH SAFE™ DEVICES. IN NO EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY
DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO
INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES OR APPLICATIONS TESTED WITH SAFE™ DEVICES. In

www.samsung.com/us/safe

.

addition, information technology security protection will be affected by features or functionality associated with, among other

DRAFT

FOR INTERNAL USE ONLY

things the e-mail platform, master data management, and virtual private network solutions selected by the software provider,
solution provider or user. Choice of an e-mail, master data management, and virtual private network solution is at the sole
discretion of the software provider, solution provider or user and any associated effect on information technology security
protection is solely the responsibility of the software provider, solution provider or user. For complete statement of limited
warranty, please refer to

devices are sold. [101212]

www.samsung.com/us/safe

, available on the web and where Samsung smartphone and Galaxy Tab™

Samsung Telecommunications America (STA), LLC

Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082

Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
Toll Free Tel: [phone].HELP (4357)

Internet Address:

http://www.samsung.com

©2012 Samsung Telecommunications America, LLC. Samsung is a registered trademark of Samsung Electronics Co., Ltd.

Do you have questions about your Samsung Mobile Phone?

DRAFT

FOR INTERNAL USE ONLY

For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:

www.samsung.com/us/support

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.

®

, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications,

Nuance
Inc., or its affiliates in the United States and/or other countries.

microSD™, microSDHC™ and the microSD logo are Trademarks of the SD Card Association.
Adobe and Flash are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other

countries.

®

, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

DivX
DivX Certified
ABOUT DIVX VIDEO: DivX

Certified
videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified
Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in License settings under Settings > About
device > Legal information. Go to

Wi-Fi
LTE is a trademark of ETSI.
Google, the Google logo, Google Search, Gmail, Maps, Navigation, Places, Google Talk, YouTube, Picasa, Android and Google Play

are trademarks of Google, Inc.

®

to play DivX® video up to HD 720p, including premium content.

®

®

device that plays DivX video. Visit

is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX

www.divx.com

for more information and software tools to convert your files into DivX

®

device must be registered in order to play purchased DivX Video-on-

®

, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance.

vod.divx.com

for more information on how to complete your registration.

©Samsung Telecommunications America, LLC (“Samsung”). Samsung and Super AMOLED are both trademarks of Samsung

DRAFT

FOR INTERNAL USE ONLY

Electronics Co., Ltd. and/or its related entities. All product and brand names are trademarks or registered trademarks of their
respective companies. Screen images simulated. Appearance of the phone may vary.

Table of Contents

DRAFT

FOR INTERNAL USE ONLY

Section 1: Getting Started .......................... 4

Understanding this User Manual . . . . . . . . . . . . 4

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . 6

Turning Your Phone On . . . . . . . . . . . . . . . . . 14

TTY Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Displaying Your Phone Number . . . . . . . . . . . 16

Your Google™ Account . . . . . . . . . . . . . . . . . 17

Creating a Samsung Account . . . . . . . . . . . . . 18

Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Securing Your Phone . . . . . . . . . . . . . . . . . . . 19

Section 2: Understanding Your Phone ..... 20

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Side Views . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Motions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . 36

Customizing the Home Screen . . . . . . . . . . . . 38

Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . 44

Section 3: Accounts and Contacts ...........50

Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Section 4: Calling ......................................63

Making Calls . . . . . . . . . . . . . . . . . . . . . . . . . 63

Multi-party Calling . . . . . . . . . . . . . . . . . . . . . 65

Answering Calls . . . . . . . . . . . . . . . . . . . . . . . 66

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . 67

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 69

1

Section 5: Messaging ................................74

DRAFT

FOR INTERNAL USE ONLY

Types of Messages . . . . . . . . . . . . . . . . . . . . .74

Text and Multimedia Messaging . . . . . . . . . . .74

Emergency alerts . . . . . . . . . . . . . . . . . . . . . .78

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Google Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Section 6: Applications and Widgets .......83

Accessing Applications . . . . . . . . . . . . . . . . . . 83

Applications List . . . . . . . . . . . . . . . . . . . . . . . 85

Accessing Widgets . . . . . . . . . . . . . . . . . . . .124

2

Section 7: Connections ...........................128

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128

Wi-Fi Direct . . . . . . . . . . . . . . . . . . . . . . . . . .129

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

VPN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

PC Connections . . . . . . . . . . . . . . . . . . . . . . .131

Tethering . . . . . . . . . . . . . . . . . . . . . . . . . . . .134

Portable Wi-Fi Hotspot . . . . . . . . . . . . . . . . . .134

Beaming . . . . . . . . . . . . . . . . . . . . . . . . . . . .136

AllShare Cast . . . . . . . . . . . . . . . . . . . . . . . . .137

Nearby devices . . . . . . . . . . . . . . . . . . . . . . .138

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . .138

Section 8: Settings .................................. 140

Accessing Settings . . . . . . . . . . . . . . . . . . . .140

Connections . . . . . . . . . . . . . . . . . . . . . . . . .142

My device . . . . . . . . . . . . . . . . . . . . . . . . . . .155

Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185

Section 9: Health and Safety

DRAFT

FOR INTERNAL USE ONLY

Information ........................................ 196

Exposure to Radio Frequency (RF) Signals . . 196
Specific Absorption Rate (SAR) Certification

Information . . . . . . . . . . . . . . . . . . . . . . . . 201

FCC Part 15 Information to User . . . . . . . . . . 203

Commercial Mobile Alerting System (CMAS) . 203

Smart Practices While Driving . . . . . . . . . . . 203

Battery Use and Safety . . . . . . . . . . . . . . . . . 205

Samsung Mobile Products and Recycling . . . 207

UL Certified Travel Charger . . . . . . . . . . . . . 208

Display / Touch-Screen . . . . . . . . . . . . . . . . 208

GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

Emergency Calls . . . . . . . . . . . . . . . . . . . . . 209

Care and Maintenance . . . . . . . . . . . . . . . . . 210

Responsible Listening . . . . . . . . . . . . . . . . . 211

Operating Environment . . . . . . . . . . . . . . . . 213

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices . . . . . . . 215

Restricting Children's Access to

Your Mobile Device . . . . . . . . . . . . . . . . . . 217

FCC Notice and Cautions . . . . . . . . . . . . . . . 217

Other Important Safety Information . . . . . . . . 218

Section 10: Warranty Information ..........220

Standard Limited Warranty . . . . . . . . . . . . . . 220

End User License Agreement for Software . . 225

Index .........................................................233

3

Section 1: Getting Started

DRAFT

FOR INTERNAL USE ONLY

This section allows you to quickly start using your Samsung
SCH-R970 phone by installing the SIM and microSD cards,
installing and charging the battery, activating your service,
and setting up your voicemail account.

Understanding this User Manual

The sections of this manual generally follow the features of
your phone. A robust index for features begins on page 233.

Also included is important safety information that you should
know before using your phone. Most of this information is
near the back of the guide, beginning on page 196.

This manual gives navigation instructions according to the
default display settings. If you select other settings,
navigation steps may be different.

Unless otherwise specified, all instructions in this manual
assume that you are starting from the Home screen. To get to
the Home screen, you may need to unlock the phone or
keypad. (For more information, refer to “Securing Your
Phone” on page 19.)

4

Note:

Instructions in this manual are based on default settings,
and may vary from your phone, depending on the
software version on your phone, and any changes to the
phone’s Settings.

Unless stated otherwise, instructions in this User Manual
start with the phone unlocked, at the Home screen.

All screen images in this manual are simulated. Actual
displays may vary, depending on the software version of
your phone and any changes to the phone’s Settings.

Special Text

DRAFT

FOR INTERNAL USE ONLY

In this manual, you’ll find text that is set apart from the rest.
These are intended to point out important information, share
quick methods for activating features, to define terms, and
more. The definitions for these methods are as follows:

•

Notes

: Presents alternative options for the current feature, menu,

or sub-menu.

•

Tips

: Provides quick or innovative methods, or useful shortcuts.

•

Example

: Gives an example of the feature or procedure.

•

Important

: Points out important information about the current

feature that could affect performance.

•

Warning

: Brings to your attention important information to
prevent loss of data or functionality, or even prevent damage to
your phone.

Text Conventions

This manual provides condensed information about how to
use your phone. To make this possible, the following text
conventions are used to represent often-used steps:

➔

Example:

Arrows are used to represent the sequence of
selecting successive options in longer, or
repetitive, procedures.

“Press

Settings ➔ Wi-Fi

Home

, then touch Menu

.”

Getting Started 5

➔

Setting Up Your Phone

DRAFT

FOR INTERNAL USE ONLY

Before using your phone, you need to install the SIM card,
the microSD™ card, and the battery into their respective
internal slots and compartment.

Caution!

Do not bend or twist the back cover excessively.
Doing so may damage the cover.

Important!

Removing the battery cover

Before removing or replacing the battery cover,
make sure the phone is switched off. To turn the
phone off, hold down the power key until the
power-off image displays, then touch

Power off

.

1. Locate the cover removal opening (1).

2. Place your fingernail in the opening and pry the cover

away from the device (2).

6

Installing the battery cover

DRAFT

FOR INTERNAL USE ONLY



Align the cover (1) and press it firmly into place (2),
making sure it snaps into place at the corners.

Installing the SIM Card

When you subscribe to a 4G LTE cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, available optional
services, and many others features. This SIM card will only
work with this device.

Important!

The SIM card must be installed for your phone to
establish a network connection.

The plug-in SIM card information and its contacts
can be easily damaged by scratching or bending,
so be careful when handling, inserting, or
removing the card. Keep all SIM cards out of reach
of small children.

1. Remove the battery cover. (See “Removing the battery

cover” on page 6.)

2. Locate the SIM card slot on the bottom inside of the

phone.

3. Make sure the gold contacts of the SIM card face

downward and that the notched corner of the card
faces outward to the right (as shown).

Getting Started 7

4. Carefully slide the SIM card into the SIM card socket

DRAFT

FOR INTERNAL USE ONLY

(as shown) until the card locks into place.

Note:

If the SIM card is not inserted correctly, the phone
cannot make a network connection.
Once the SIM card is inserted, do not remove it.

If your SIM card is ever separated from the device or
damaged, your device will not function. If you experience any
issues with your device, contact Customer Service at 888­944-9400 or visit your nearest U.S. Cellular

8

®

retail location.

SIM Card Limited Warranty

Subject to the exclusions contained below, United States
Cellular Corporation (“U.S. Cellular”) warrants to the original
purchaser (“You” or “Your”) of the handset with which the
SIM card was provided that the SIM card will be free from
defects in material and workmanship for a period of one (1)
year from the date You purchased the handset (the “Warranty
Period”). This warranty is not transferable. Should a defect
appear during the Warranty Period, U.S. Cellular will send a
replacement SIM card to Your address within the United
States without charge provided that you request the
replacement SIM card during or within thirty (30) days
following the Warranty Period by calling U.S. Cellular
Customer Service at 888-944-9400 (or dialing 611 on Your
U.S. Cellular handset) or by visiting a U.S. Cellular retail
store.

REPLACEMENT OF THE SIM CARD AS PROVIDED HEREIN IS
YOUR EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY,
AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED INCLUDING, WITHOUT LIMITATION, ANY
WARRANTIES OF TITLE, FITNESS FOR A PARTICULAR
PURPOSE, MERCHANTABILITY, NONINFRINGEMENT OR
ARISING FROM COURSE OF DEALING OR USAGE OF TRADE.
NEITHER U.S. CELLULAR NOR ANY OF ITS AFFILIATES OR

RETAILERS SHALL BE LIABLE TO YOU FOR ANY DIRECT,

DRAFT

FOR INTERNAL USE ONLY

INDIRECT, INCIDENTAL, SPECIAL, ECONOMIC, EXEMPLARY,
PUNITIVE OR CONSEQUENTIAL DAMAGES (INCLUDING,
WITHOUT LIMITATION, LOSS OF DATA, LOSS OF REVENUE OR
PROFITS, DAMAGE TO PROPERTY OR LOSS OF USE). IN NO
EVENT SHALL U.S. CELLULAR’S, ITS AFFILIATES’ OR
RETAILERS’ LIABILITY TO YOU OR ANY THIRD PARTY WITH
RESPECT TO THE SIM CARD EXCEED THE COST OF
REPLACING THE SIM CARD.

THIS LIMITED WARRANTY SHALL BE CONSTRUED UNDER
THE LAWS OF THE STATE OF ILLINOIS, EXCLUDING ITS
CONFLICTS OF LAW PROVISIONS. SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, OR THE DISCLAIMER OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATIONS AND DISCLAIMERS MAY NOT
APPLY TO YOU.

No agent, employee, dealer, retailer, representative or
reseller is authorized to modify or extend the terms of this
Limited Warranty.

Removing the SIM Card

1. Remove the battery cover.

2. Remove the battery.

3. Firmly press the card into the slot and release it. The

card should pop partially out of the slot.

4. Remove the card from the slot.

5. Replace the battery cover.

Installing a Memory Card

Your device lets you install a microSD (SD) or microSDHC
memory card to expand available memory to store images,
videos, music, applications, and data.

1. Remove the battery cover. (See “Removing the battery

cover” on page 6.)

2. Locate the microSD card slot on the bottom inside of

the phone.

3. With the gold contacts facing down, carefully slide the

memory card into the slot (as shown), pushing gently
until it clicks into place.

Getting Started 9

Important!

DRAFT

FOR INTERNAL USE ONLY

10

Be sure to align the gold contact pins on the
memory card with the phone’s contacts.

Removing a Memory Card

Important!

1. Press
Settings ➔ Storage ➔ Unmount SD card

2. Remove the battery cover. (See “Removing the battery

cover” on page 6.)

3. Firmly press the Memory card into the slot and
carefully release it. The card should pop partially out of
the slot.

4. Remove the card from the slot.

5. Replace the battery cover. For more information, refer

to “Installing the battery cover” on page 7.

To prevent damage to information stored on the
memory card, unmount the card before removing it
from the phone.

Home

, then touch Menu

➔

.

Battery

DRAFT

FOR INTERNAL USE ONLY

Your phone is powered by a rechargeable, standard Li-Ion
battery. A Wall/USB Charger (Charging Head and USB cable)
is included with the phone, for charging the battery.

Note:

The battery comes partially charged. You must fully
charge the battery before using your phone for the first
time. A fully discharged battery requires up to 4 hours of
charge time.

After the first charge, you can use the phone while
charging.

Warning!

Use only Samsung-approved charging devices and
batteries. Samsung accessories are designed to
maximize battery life. Using other accessories may
invalidate your warranty and may cause damage.

Note:

Failure to unplug the wall charger before you remove the
battery, can cause damage to the phone.

Battery Indicator

The battery icon in the Annunciator Line shows battery
power level. Two to three minutes before the battery
becomes too low to operate your phone, the empty battery
icon will flash and a tone will sound. If you continue to
operate the phone without charging the battery, the phone
will power off.

Installing the Battery

1. Remove the battery cover. (See “Removing the battery

cover” on page 6.)

2. Slide the battery into the compartment (1) so that the

tabs on the end align with the slots at the bottom of the
phone, making sure the connectors align.

3. Gently press down to secure the battery (2).

Getting Started 11

Removing the Battery

DRAFT

FOR INTERNAL USE ONLY

1. Remove the battery cover. (See “Removing the battery

cover” on page 6.)

2. Lift the battery up by the slot provided (1).

3. Lift the battery up and out of the phone (2).

12

Charging the Battery

Your phone is powered by a rechargeable Li-ion battery. A
wall charger, which is used for charging the battery, is
included with your phone. Use only approved batteries and
chargers. Ask your local Samsung dealer for further details.

Before using your phone for the first time, you must fully
charge the battery. A discharged battery recharges fully in
approximately 4 hours.

Note:

Verify that the battery is installed prior to connecting the
wall charger. If both the wall charger is connected and
the battery is not installed, the handset will power cycle
continuously and prevent proper operation. Failure to
unplug the wall charger before you remove the battery,
can cause the phone to become damaged.

Important!:

It is recommended you fully charge the battery

before using your device for the first time.

1. Insert the USB cable into the device’s Charger/

DRAFT

FOR INTERNAL USE ONLY

Accessory jack at the bottom of the device.

Note:

This illustration displays both the correct and incorrect
orientation for connecting the USB cable. If the USB
cable is incorrectly connected, damage to the accessory
port will occur therefore voiding the phone’s warranty.

2. Connect the USB cable to the charging head.

3. Plug the charging head into a standard AC power

outlet. The device turns on with the screen locked and
indicates both its charge state and percent of charge.

Warning!:

While the device is charging, if the touch screen
does not function due to an unstable power supply
unplug the USB power adapter from the power outlet
or unplug the USB cable from the device.

Getting Started 13

4. When charging is finished, first unplug the charger’s

DRAFT

FOR INTERNAL USE ONLY

power plug from the AC wall outlet, then disconnect
the USB cable connector from the device.

Important!

If your handset has a touch screen display, please
note that a touch screen responds best to a light
touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object
when pressing on the touch screen may damage
the tempered glass surface and void the warranty.
For more information, refer to “Standard Limited
Warranty” on page 220.

Turning Your Phone On



Press and hold the
upper right side of the phone) for three seconds.
While powering on, the phone connects with the
network, then displays the Locked screen and any
active Notification alerts.

14

Power/Lock

key (on the

Note:

Your phone’s internal antenna is located along the
bottom back of the phone. Do not block the antenna;
doing so may affect call quality or cause the phone to
operate at a higher power level than necessary.

Unlocking Your Phone

DRAFT

FOR INTERNAL USE ONLY

1. If needed, press Press
Home

to wake

the screen.

2. If there are no

Notification alerts on
your phone, swipe the
screen to unlock it.
The Home screen
appears.

Turning Your Phone Off

Note:

If you have purchased your phone online, the first time
you power your phone on and unlock the screen, the
Activation Wizard

Follow the prompts to activate and set-up your phone.

Welcome

screen appears.

1. Press and hold the

upper right side of the device) for two seconds.

2. At the prompt, touch

appears.

3. At the prompt, touch

Power/Lock Key

Power off

. The

OK

.

Getting Started 15

Power off

(on the

pop-up

TTY Mode

DRAFT

FOR INTERNAL USE ONLY

Your phone is fully TTY-compatible, allowing you to connect a
TTY device to the phone’s headset jack. Before you can use
your phone with a TTY device, you’ll need to enable TTY
Mode.

For more information, refer to “Other call settings” on page

73.

Voicemail

All unanswered calls to your phone are sent to voicemail,
even if your phone is turned off, so you’ll want to set up your
voicemail and personal greeting as soon as you activate your
phone.

Setting up Voicemail

1. Press

touch and hold .

2. Follow the automated instructions to set up your new

password and record a greeting.

16

Home

, then touch

Phone

, then

Checking Voicemail

1. Press

touch and hold .

2. Follow the automated instructions to manage

voicemail.

Tip:

You can also access
number from any touch-tone phone.

Displaying Your Phone Number



Press

Settings ➔ About device ➔ Status

Your phone number displays under

Home

, then touch

Voicemail

Home

by dialing your phone

, then touch Menu

Phone

, then

➔

.

My phone number

.

Your Google™ Account

DRAFT

FOR INTERNAL USE ONLY

Your new phone uses your Google account to fully utilize its
Android features, including Gmail, Google Maps, Google Talk,
and the Google™ Play. When you turn on your phone for the
first time, you should set up a connection with your existing
Google account, or create a new Google account.

Home

.

or

New

, then touch

screen displays.

to continue.

1. Press

Gmail

The

Add a Google Account

2. Touch

3. Follow the on-screen instructions to sign in if you

Existing

already have a Google account, or to create a Google
Account.

Applications

➔

Resetting your Google Account Password

A Google account password is required for Google
applications. If you misplace or forget your Google Account
password, follow these instructions to reset it:

1. From your computer, use an Internet browser to

navigate to

2. Once the Web Page loads, click on the
your account?

3. Under

reset prompts.

http://google.com/accounts

link.

Forgot your password?

.

Can’t access

, follow the password

Getting Started 17

Creating a Samsung Account

DRAFT

FOR INTERNAL USE ONLY

An active Samsung account is required to use applications
such as AllShare Play and Media Hub.

1. From the Home screen, touch
Settings

The

2. Under Accounts, touch

3. From the

account

4. From the

account

a Samsung account.

5. Read the Terms and conditions, then touch the

all the terms

6. Touch

7. Enter the required information and touch

8. At the Welcome screen, touch

9. Follow the on-screen instructions to verify your email

address and activate your account.

18

screen appears in the display.

Add account

Add account

.

Samsung account

and follow the on-screen instructions to create

Agree

screen, touch

above

check box.

.

Menu ➔ Settings

.

screen, touch

Next

.

Samsung

Create new

I accept

Sign up

.

.

Roaming

When you travel outside your home network’s coverage area,
your phone can roam to acquire service on other compatible
digital networks. When Roaming is active, the Roaming icon
( ) appears in the Annunciator Line (Notification Bar) of
the display.

Tip:

You can set your phone’s roaming behavior. (For more
information, refer to “Mobile networks” on page 148.)

During roaming, some services may not be available.
Depending on your coverage area and service plan, extra
charges may apply when making or receiving calls.

Note:

Contact your Wireless Provider for more information
about your coverage area and service plan.

Securing Your Phone

DRAFT

FOR INTERNAL USE ONLY

By default, the phone locks automatically when the screen
times out, or you can lock it manually. You can unlock the
phone using one of the default Unlock screens, or for
increased security, use a personal screen unlock pattern, a
Personal Identification Number (PIN), or a password.

For more information about creating and enabling a Screen
unlock pattern, see “Lock screen” on page 165.

Note:

Unless stated otherwise, instructions in this User Manual
start with the phone unlocked, at the Home screen.

Locking the phone manually



Press the
side of the phone.

Power/Lock

key on the top right

Unlocking the phone

For information on unlocking your phone, see “Unlocking
Your Phone” on page 15.

Unlocking with a Personal Screen Unlock Pattern

1. Press

2. Draw your personal unlock pattern on the screen.

For more information, refer to “Lock screen” on page 165.

Unlocking with a Password

1. Press

2. Enter your Password.

3. Press

OK

Home

to wake the screen.

Home

to wake the screen.

.

Getting Started 19

Section 2: Understanding Your Phone

DRAFT

FOR INTERNAL USE ONLY

–

Features

•

5.0-inch 1920x1080 Super AMOLED Full HD touch screen

•

CDMA 1X/EV-DO Rev-A /LTE Wireless Technology

•

1.9 gigahertz quad-core processor with 16 or 32 GB memory and
2 GB RAM

•

Android® 4.2 platform

•

Google Play™ Store, plus pre-loaded applications

•

SAFE™ Certified

•

Connections

–

Wi-Fi 802.11 a/b/g/n (2.4 and 5 GHz bands)

–

Mobile Hotspot

–

Bluetooth 4.0

–

Tet he rin g

–

VPN

–

NFC

–

Android Beam

–

S Beam

–

Wi-Fi Direct

–

AllShare Cast

–

DLNA

20

USB 2.0

•

Messaging Services

–

Text Messaging

–

Picture Messaging

–

Video Messaging

–

Voice Messaging

–

Email

–

Mobile Instant Messenger (IM)

–

Chat

•

13 Megapixel Camera-Camcorder with LED flash + 2 Megapixel
Front Camera-Camcorder

•

Picture Gallery

•

Video Player (1080p — MP4 and 3GP)

•

DivX Certified® to play DivX® video up to HD 1080p, including
premium content

•

Music Player (AAC, AAC+, eAAC+, MP3, and WMA)

•

Speakerphone

•

Support for microSD™ and microSDHC™ Memory Cards up to
64GB capacity

Front View

1
2

3

4

6

5

7

8

DRAFT

FOR INTERNAL USE ONLY

1.

Earpiece:

Use during calls to listen to callers.

LED Indicator

2.

notifications or phone status.

3.

Menu Key

screen.

Home Key

4.

screen if the phone is locked. Press and hold to display
recent applications or to launch Task Manager.

5.

Microphone

your voice, and when recording.

Back Key

6.

option.

1.9 Megapixel Front Camera

7.

recording video.

8.

Proximity and Light Sensors

nearby objects to control device functions or blank the
screen display, such as when you hold the phone to
your ear during a phone call. Detect ambient light to
determine screen brightness when

Automatic brightness

and when taking pictures with the Front camera.

: Flashes or glows to alert you to alert

: Press to display options for the current

: Press to display the Home screen, or Lock

: Use during calls to allow callers to hear

: Press to return to the previous screen or

: Use for taking pictures and

: Detect the presence of

Brightness

(see “Brightness” on page 162),

Understanding Your Phone 21

is set to

Side Views

1

3

2

DRAFT

FOR INTERNAL USE ONLY

1.

Volume Key

Master Volume. During calls or music playback, press
to adjust volume. Press to mute the ringtone of an
incoming call.

USB Power/Accessory Port

2.

charging or to sync music and files.

3.

Power/Lock Key

off. Press to lock the phone, or to wake the screen for
unlocking.

22

: From the Home screen, touch to adjust

: Connect a USB cable for

: Press and hold to turn the phone on or

Back View

1

2
3

4

5

DRAFT

FOR INTERNAL USE ONLY

1.

2.

3.

4.

5.

Noise cancelation microphone

noise that the phone uses to produce a quiet
background during calls and video chats.

Camera Flash
8 Megapixel Camera Lens

recording videos.

External Speaker

Speakerphone mode, media sounds (music and video),
and other sounds.

3.5mm Headset Jack

TTY equipment.

: Use when taking photos.

: Play ringtones, call audio when in

Understanding Your Phone 23

: Captures background

: Use when taking photos or

: Plug in an optional headset or

Navigation

DRAFT

FOR INTERNAL USE ONLY

Navigate your phone’s features using the command keys and
the touch screen.

Warning!

Please note that a touch screen responds best to a
light touch from the pad of your finger or a non­metallic stylus. Using excessive force or a metallic
object when pressing on the touch screen may
damage the tempered glass surface and void the
warranty. For more information, see “Warranty
Information” on page 220.

Command Keys

Menu Key

Touch Menu
options for the current screen or feature.

Home Key

Press the
Press and hold the

recent applications, or to launch Task Manager.

Back Key

Touch Back
step.

Context-sensitive Menus

While using your phone, context-sensitive menus offer
options for the feature or screen currently in use.

To access context-sensitive menus:

Touch

•

•

Touch and hold on an item.

24

Menu

.

to display a context-sensitive menu of

Home Key

to display the Home screen.

Home Key

to launch a menu of

to return to the previous screen, option or

Motions

DRAFT

FOR INTERNAL USE ONLY

Finger Motions

Touch

Touch items to select or launch them. For example:

•

Touch the on-screen keyboard to enter characters or text.

•

Touch an item to select it.

•

Touch an app’s icon to launch the application.

Touch and Hold

Activate on-screen items by a touch and hold gesture. For
example:

•

Touch and hold a widget or icon on the Home screen to move it.

•

Touch and hold on a field to display a pop-up menu of options.

Swipe

Swipe your finger vertically or horizontally across the screen.
For example:

•

Unlocking the screen

•

Scrolling the Home screen or a menu

•

Combine touch and hold with swipe to drag an item to a new
location.

Pinch

Using two fingers, make a pinch motion on the screen. For
example:

•

Pinch in to zoom in on pictures or screens.

•

Pinch out to zoom out on pictures or screens.

Understanding Your Phone 25

•

DRAFT

FOR INTERNAL USE ONLY

Motions

Your phone recognizes motion, to allow you to navigate and
access features by moving the phone in specific patterns.

To use motions to control your phone, enable the
settings. (For more information, see “Motions and gestures”
on page 176.)

•

Direct call

: When this option is set to On, you can lift the phone to
your ear to call a contact displayed in a Messaging, Contacts, or
Call Log screen.

•

Smart alert

to be automatically notified of missed calls, messages, and alerts
that occurred while the phone was stationary.

: When this option is set to On, you can lift the phone

Motion

Double tap to top

the top of the phone takes you to the top of the list.

26

: When this option is set to On, a double tap on

•

DRAFT

FOR INTERNAL USE ONLY

Tilt to zoom

with your thumbs on the screen while in Gallery or Internet, then
tilting the phone forward and back causes the screen to zoom in
or out.

: When this option is set to On, touching and holding

•

Pan to move icon

holding on the screen, then moving the phone in a side-to-side
motion, moves a highlighted icon to a new location on the Home
screen.

•

Pan to browse images

phone in a panning motion while viewing an image moves focus
around in the image.

•

Shake to update

phone causes Bluetooth or Wi-Fi screens to scan for devices.

: When this option is set to On, touching and

: When this option is set to On, moving the

: When this option is set to On, shaking the

Understanding Your Phone 27

•

DRAFT

FOR INTERNAL USE ONLY

Turn over to mute/pa use

the phone screen-down automatically mutes incoming call
ringtones and alerts sounds.

: When this option is set to On, turning

Hand motions

Use your hand to swipe across the screen, or cover the
screen.

•

Palm swipe to capture

the screen with the side of your hand (left to right, or right to left)
captures a screen shot.

28

: When this option is set to On, swiping

•

DRAFT

FOR INTERNAL USE ONLY

Palm touch to mute/pause

the screen with your hand mutes or pauses media playback.

: When this option is set to On, covering

Using Multi Window

This feature allows you to run multiple applications on the
current screen at the same time.

Note:

Only applications found within the Multi window tray can
be active atop another current application on the screen.

When launching applications that contain multimedia
files (music/video), audio from both files will be played
simultaneously.

Activating and Deactivating Multi window

To activate Multi window:

1. Touch and hold

appears briefly (by default) on the left side of the
screen, then closes, leaving only the Multi window tab
showing.

2. Touch the tab to open the Multi window tray,

showing some of the available Multi window apps.

3. Swipe the tray upwards to show more Multi window

apps.

Back

. The Multi window tray

Understanding Your Phone 29

To deactivate Multi window:

DRAFT

FOR INTERNAL USE ONLY



With the Multi window tab showing, touch and hold

Back

. This action hides the Multi window tab

from view.

Repositioning the Multi Window

The Multi window contains two components: tab and apps
tray. The tab can be manually moved across the screen. The
apps tray (containing the scrollable apps) can be relocated to
launch from any side of the screen (top, bottom, left, or
right).

To move the tab:

1. Activate the Multi window feature. (See “To activate

Multi window:” on page 29.)

2. In a single motion, touch and hold the tab for

approximately one-second, then slowly drag it to its
new location

Note:

This is a quick way to get the tab out of the way if you
can’t get to a button or option behind it.

30

along the current

screen edge.

To relocate the Multi window tray:

1. Activate the Multi window feature. (See “To activate

Multi window:” on page 29.)

2. Touch the tab to display the apps tray (containing the

scrollable apps).

Note:

Notice that when the apps are visible, the tab turns a
dark grey. Its only in this state that the entire panel can
be relocated.

3. In a single motion, touch and hold the Multi window

DRAFT

FOR INTERNAL USE ONLY

tab for approximately one-second to detach it from
the screen (1), then slowly drag it to its new location

along any other

move it to the top, bottom, or either side.

available screen edge (2). You can

Customizing the Multi Window tray

The applications found within the Multi window tray can be
organized by either being rearranged or removed.

To rearrange the Multi window applications:

1. Activate the Multi window feature.

2. Touch the tab to display the apps tray (containing the

scrollable apps).

3. In a single motion, touch and hold a desired app until it

detaches from the tray, then carefully drag it to a new
location in the list of apps. Lift your finger or stylus off
the screen to let go of the app and drop it into its new
location.

To remove a Multi window application:

1. Activate the Multi window feature.

2. Touch the tab to display the Multi window tray

(containing the scrollable apps).

3. To uch

4. Follow the prompt to remove apps from the Multi

5. Ta p

Edit

window tray to the revealed staging area.

Done

process.

(located at the bottom of the list).

once you have completed the removal

Understanding Your Phone 31

To restore a Multi window application:

DRAFT

FOR INTERNAL USE ONLY

1. Activate the Multi window feature.

2. Tap the tab to display the apps panel (containing the

scrollable apps).

Edit

3. Tap the

reveal the staging area containing any previously
removed apps.

4. Locate the desired application.

5. In a single motion, touch and hold a desired app until it

detaches from the staging area, then carefully drag it
to a new location in the current list of apps.

Using Multi Window to run multiple apps on the same screen

Any of the apps found within the Multi window panel can be
run at the same time as a current on-screen app.

Once multiple apps are running on the same screen, you can
then choose to either swap their positions or maximize a
desired app.

32

button (located at the bottom of the list) to

Note:

Only applications found within the Multi-window panel
can be active atop another current application on the
screen.

When launching applications that contain multimedia
files (music/video), audio from both files will be played
simultaneously.

In this example we will be launching both the Internet and
Maps applications.

1. Launch an application, such as Internet.

•

From the Home screen, touch

2. Activate the Multi window feature. (See “To activate

Multi window:” on page 29.)

3. Touch the Multi window tab to display the apps tray.

4. Touch and hold the desired app, such as

until it detaches from the tray.

5. In a single motion, drag the app over the current app

and drop the new Multi window app over either the top
or bottom area of the current on-screen app.

Internet

.

Maps

,

Note:

App #1 Max

App #2 Border

Swap
apps

bar

Close

DRAFT

FOR INTERNAL USE ONLY

Once two applications are running, the device displays a
split screen view containing both the initial app and the
new Multi window app. Each application is still
independent of the other.

To swap the locations of the
applications:

1. With the two

applications shown in a
split screen, touch the
Border bar to show the
on-screen icons.

2. Touch the desired

application area (top or
bottom).

3. Touch

The current apps swap
places.

Swap apps

.

To increase the size of a desired application window:



With the two applications shown in a split screen,
touch and hold the Border bar, then drag it to resize the
desired window.

To seperate the current applications:

1. With the two applications shown in a split screen,

touch the Border bar to show the on-screen icons.

2. Touch the desired application area (top or bottom).

3. Touc h

both maximized.

To close an application:

1. With the two applications shown in a split screen,

touch the Border bar to show the on-screen icons.

2. Touch the desired application area (top or bottom).

3. Touc h

Maximize apps

Close app

. The current apps are the

. The current apps swap places.

Understanding Your Phone 33

Notifications

DRAFT

FOR INTERNAL USE ONLY

Notifications shows information about connections, alerts
and other items.

1. Touch and drag downward from the top of the screen

to display notifications.

2. Touch an item to open that item, or to launch a related

app or feature.

Clear

3. Touch

34

to clear all Notifications.

Quick Settings Menu

Use Quick Settings toggles at the top of Notifications to
control popular settings. Slide your finger right and left
across the Quick Settings menu to see all of the toggles.

•

Wi-Fi

: Turn Wi-Fi On or Off. For more information about using

Wi-Fi, see

•

GPS

: Turn Standalone GPS services on or off. For more

information, see

•

Sound

: Touch to switch between your sound settings, and the

two Silent modes, Mute and Vibrate. For more information, see

“Volume”

•

Screen rotation

control whether the screen automatically updates when you
rotate the phone. See

•

Bluetooth

using Bluetooth, see

•

Mobile data

mobile data. For more information, see

On or Off”

“Wi-Fi”

on page 128.

“Location services”

on page 156.

: Enable or disable the Auto rotation setting, to

“Auto-rotate screen”

: Turn Bluetooth On or Off. For more information about

“Bluetooth”

: Activate or deactivate your phone’s access to

on page 146.

on page 185.

on page 162.

on page 130.

“Turning Mobile data

•

DRAFT

FOR INTERNAL USE ONLY

Blocking mode

control which notifications you receive. For more information,
refer to

•

Power saving

information, see

•

AllShare Cast

control whether your phone shares the contents of its display with
other Digital Living Network Alliance (DLNA) certified devices,
such as Smart televisions. For more information, refer to

“AllShare Cast”

•

Sync

Clearing Notifications

1. Sweep your finger downward from the top of the

screen to display Notifications.

2. Touch a notification to clear it, or to launch an app.

– or –
Touch

: Enable or disable the Blocking mode setting, to

“Blocking mode”

: Enable or disable Power saving mode. For more

: Enable or disable the AllShare Cast setting, to

: Enable or disable synchronization with your accounts.

on page 155.

“Power saving mode”

on page 137.

on page 164.

Clear

to clear all notifications

Understanding Your Phone 35

1.

1

3

4

5

5

6

2

DRAFT

FOR INTERNAL USE ONLY

Home Screen

The Home screen is the starting point for using your phone.

Note:

Unless stated otherwise, instructions in this User Manual
start with the phone unlocked, at the Home screen.

All screen images in this manual are simulated. Actual
displays may vary, depending on the software version of
your phone and any changes to the phone’s Settings.

36

Status Bar

battery power, and connection details. For a list of
icons, see “Status Bar Icons” on page 37.

2.

Multi window tab
Home screen

3.

Place shortcut icons, widgets, and other items to
customize your phone to your needs. For more
information, see “Home Screen” on page 36.

4.

Primary Shortcuts

apps. For more information, see “Primary Shortcuts”
on page 39.

5.

Panel Indicator

screen panels appears in the display.

Shortcuts

6.

are found on the Home screen by default, and you can
add more shortcuts to your favorite apps. For more
information, see “Shortcuts” on page 40.

7.

Widgets

widgets are found on the Home screen by default, and
you can add your favorites. For more information, see
“Widgets” on page 40.

: Presents icons to show network status,

: Access Multi window tray. (.)

: The starting point for using your phone.

: Shortcuts to your phone’s common

: Shows what panel of 7 available Home

: Shortcuts to common apps.These shortcuts

: Apps that run on the Home screen. These

Status Bar Icons

DRAFT

FOR INTERNAL USE ONLY

The Status Bar shows network and battery status and other
details.

Airplane Mode Active

are disabled. See “Airplane mode” on page 146.

USB Connected

using a USB cable.

Voice Call

: A voice call is in progress.

: All wireless communications

: The phone is connected to a computer

Device Power Critical

remaining. Charge immediately.

GPS Location Active

services are active. See “Location services” on page

185.

Missing SIM

No Network

: Battery has very little power

: One or more GPS location

: No LTE SIM is installed.

: No wireless network is available.

Speakerphone

Missed Call

Mute

Battery Level

Battery Charging

: Speakerphone is enabled.

: Displays when there is a missed call.

: Voice or playback volume is muted.

: Shown fully charged.

: Battery is charging.

3G connection

4G LTE Connection

Signal Strength

the number of bars, the stronger the signal.

New Message

New Voicemail

indicates the number of new messages.

: Phone is active on a 3G system.

: Phone is active on a 4G LTE system.

: Current signal strength. The greater

: You have new message(s).

: You have new voicemail. A number

Understanding Your Phone 37

New Email Message

DRAFT

FOR INTERNAL USE ONLY

: You have new email.

TTY

: TTY Mode is active.

Silent mode

silenced, and Vibrate is not active. See “Volume” on
page 156.

Vibrate

See “Vibrations” on page 158.

SD Card Ready

prepare the card for use.

SD Card Removed

Bluetooth Active

Bluetooth Connected

another Bluetooth device.

Wi-Fi Active

network.

Wi-Fi Action Needed

Fi network. For more information about configuring
Wi-Fi, see “Wi-Fi Settings” on page 143.

38

: All sounds except media and alarms are

: All sounds are silenced, and Vibrate is active.

: A memory card scan is underway, to

: A memory card was un-installed.

: Bluetooth is turned on.

: Your device is connected with

: Wi-Fi is active, and connected to a Wi-Fi

: Action needed to connect to Wi-

Display settings

You can customize display settings to your preferences. For
more information, see “Display” on page 160.

Extended Home Screen

The Home screen consists of the Home panel, plus panels
that extend beyond the display width to provide more space
for adding shortcuts, widgets and folders.

Slide your finger horizontally across the screen to scroll to
the left or right side panels. As you scroll, the indicator at the
bottom of the display shows your current position.

Customizing the Home Screen

Customize the Home screen to suit your preferences.

•

Add Shortcuts

page 40.

•

Add Widgets

•

Add Folders

•

Change the Wallpaper

on page 41.

: For more information, see

: For more information, see

: For more information, see

: For more information, see

“Shortcuts”

“Widgets”

“Folders”

on

on page 40.

on page 41.

“Wallpaper”

Adding and removing Home screen panels

DRAFT

FOR INTERNAL USE ONLY

Your phone comes with 7 Home screen panels. You can
customize the Home screen to include up to the seven
default panels, and set one panel as Home.

1. From the Home screen, touch
Edit page

.

2. Slide your finger across the screen to scroll the panels,
and use these controls to configure panels:

Remove

: Touch and hold on a panel, then drag it

Remove

to

Add

up to the default total of six.

Change panel sequence

to different positions.

Tip:

You can also “pinch” the Home screen to display Edit
options.

.

: Touch a previously-removed panel to add it,

Menu

, then touch

: Touch and drag panels

Primary Shortcuts

Primary Shortcuts appear at the bottom of the display. You
can edit the Primary Shortcuts, except for

Editing the Primary Shortcuts

To add or remove shortcuts:



Touch and hold a shortcut, then drag it from the
Primary Shortcuts to the Home screen, or from the
Home screen to the Primary Shortcuts.

To remove shortcuts:



Touch and hold the shortcut until
then drag the shortcut to the

Apps

.

Remove

appears,

Remove

icon.

Understanding Your Phone 39

Widgets

DRAFT

FOR INTERNAL USE ONLY

Widgets are self-contained applications that you can place
on the Home screen for quick, direct access.

Adding Widgets to the Home screen

1. Press the

panel, then touch and hold on the screen to display the

Home screen

2. Touch

3. Touch the

Adding Widgets from Apps

1. Press the

2. Touch

3. Touch a widget, then follow the prompts to configure

Removing Widgets



40

Add to Home screen

.

widgets

the prompts to configure the widget and place it on the
Home screen.

screen panel.

the widget and place it on the Home screen.

Touch and hold the widget until
then drag the widget to the

Home

key, swipe to a Home screen

menu.

, then select

Widgets

tab, then touch a widget and follow

Home

key, and swipe to a Home

Apps

, then touch the

Widgets

Remove

Remove

icon.

Apps and

tab.

appears,

Shortcuts

Use App shortcuts to launch applications from the Home
screen. Your phone comes with app shortcuts already placed
on the Home screen, and you can add your favorites.

Adding Shortcuts to the Home Screen

Adding shortcuts from the Home screen

1. Press the

the screen to display the

2. Tou ch

selection.

3. Follow the prompts to configure the shortcut and add it

to the Home screen.

Adding Shortcuts from Apps

1. Press the

2. Touch

3. Touch and hold on an app until it appears on the Home

screen.

Removing Shortcuts



Touch and hold the shortcut until
then drag the shortcut to the Remove icon.

Home

key, then touch and hold on

Add to Home screen

Apps and widgets ➔ Apps

Home

key.

Apps

.

menu.

tab, then touch a

Remove

appears,

Folders

DRAFT

FOR INTERNAL USE ONLY

Place folders on the Home screen to organize items.

Adding Folders

1. Press the

2. Touch and hold on the screen to display the
screen

menu, then select

– or –
Touch

3. The folder appears on the Home screen. Touch the
folder to name it.

Removing Folders



Touch and hold the folder until
then drag the folder to the Remove icon.

Menu ➔

Home

key.

Add to Home screen ➔ Folder

Create folder

.

Remove

Home

appears,

Wallpaper

Choose a picture to display in the background of the Home
screen. You can choose from pre-loaded wallpaper images,
or select a picture you’ve taken with the Camera or
downloaded.

.

1. Press the

screen to display the

Set wallpaper ➔ Home screen
lock screens

2. Choose a source:

•Gallery

•Live wallpapers

• Wallpaper

Note:

You can also set Wallpaper in Settings. For more
information, see “Wallpaper” on page 160.

Home

key, touch and hold on the

Home screen

.

: Choose a picture stored on your phone or on an
optional installed memory card. Touch a picture to select it,
then use the crop tool to resize the picture, if desired. Touch

Done

to save the picture as wallpaper.

: Choose from pre-loaded animated wallpaper

images. Touch a wallpaper, then touch

: Choose from pre-loaded wallpaper images. Touch

a wallpaper, then touch

Set wallpaper

Understanding Your Phone 41

menu, then select

/

Lock screen

Set wallpaper

.

/

Home and

.

Apps

DRAFT

FOR INTERNAL USE ONLY

Apps holds all applications installed on your phone.
Applications that you download and install from the Google
Play™ Store or from the web are also added to Apps.

The Apps screen is like the Home screen, it consists of
panels that extend beyond the display width to provide more
space. Slide your finger horizontally across the screen to
scroll to the left or right side panels. As you scroll, the
indicator at the bottom of the display shows your current
position.

For more information about applications, see “Applications
and Widgets” on page 83.

You can place shortcuts to apps on the Home screen, for
quick access to the app. For more information, see “Adding
Shortcuts from Apps” on page 40.

1. Press the

2. Slide your finger left or right to scroll the Apps screens.

3. Touch an icon to launch the application.

42

Home

key, then touch

Apps

.

Customizing the Apps Screens

Choosing a view

By default, app icons appear in Grid view. You can change
the view to list view.

1. Press the

2. Tou ch Menu ➔ View type

3. Choose an option:

• Customizable Grid

touch and hold on apps to move them from screen to screen.

• Alphabetical grid

• Alphabetical list

Home

key, then touch

.

: The default view, which allows you to

: Icons are arranged in a grid, in A-Z order.

: Icons display in a list, sorted from A-Z.

Apps.

Apps screen options

DRAFT

FOR INTERNAL USE ONLY

1. Press the

2. Touch Menu

•Play Store

apps to download.

•Edit

: Touch and hold an app icon for these options:

–

Drag it to a new location.

–

Drag it to to create a new folder to contain the icon.

–

Drag it to to create a new apps screen and place the icon
on it.

–

Drag it to to launch Application manager to view information
about the app. For more information, refer to

manager”

–

Drag to (if available) to remove the icon. The trashcan is
only available for apps you’ve installed. Pre-loaded apps cannot
be removed.

•Create folder

• Uninstall

phone. Pre-loaded apps cannot be un-installed.

• Downloaded applications

downloaded.

Home

for options:

: Launch Google Play™ Store, to browse for new

on page 189.

: Add folders in which to group your apps.

: Remove an app that you downloaded from your

key, then touch

“Application

: Display all apps you’ve

Apps.

•View type

• Share apps

• Hide applications

: Configure the apps screen.

: Select apps you’ve downloaded (not available for
pre-loaded apps) to share via Bluetooth, Dropbox, Email,
Flipboard, Gmail, Google+, Messaging, S Memo, Wi-Fi Direct.

/

Show hidden applications

whether app icons are visible in Apps. Hiding an icon does not
remove the app from your phone.

Understanding Your Phone 43

: Control

Entering Text

New
Paragraph

Text Input Mode

Shift
Key

Delete
Key

Space Bar

Voice Typing
and Settings

DRAFT

FOR INTERNAL USE ONLY

This section describes how to enter words, letters,
punctuation, and numbers when you need to enter text.

Text Input Methods

There are three text input methods available:

•

Google Voice typing

•

Samsung keyboard (default)

QWERTY keypad that can be used in both portrait and
landscape orientation.

•

Swype

: a new way to enter text on touch screens. Instead
of tapping each key, use your finger to trace over each
letter of a word.

(To change the input method, see “Keyboards and Input
Methods” on page 139.)

: allows you to enter text by speaking.

: Samsung’s on-screen

Entering Text Using the Samsung Keyboard

From a screen where you can enter text, rotate your phone
counterclockwise to a Landscape orientation. The on-screen
QWERTY keypad will display.

Changing the Text Input Mode - Keypad

There are two main keypad layout keys that will change the
on-screen keys within the QWERTY keypad.

Sym

and

Abc

The available Text Input modes are:

.

44

Symbol/Numeric Mode

DRAFT

FOR INTERNAL USE ONLY

symbol, and emoticon keys.

ABC Mode

: activates the default alphabet keys.

Can also be set to

) key.

(

: activates the number,

Abc

or

abc

by using the shift

Note:

When in

Abc

mode, the

Sym

mode, the

Using ABC Mode

1. If desired, rotate your phone counterclockwise to a

Landscape orientation.

2. When you tap the

screen displays:

Sym

button will appear. When in

Abc/ABC/abc

button will appear.

Enter message

field, the following

3. Tap the desired alphabetic characters.

4. The screen initially opens in ABC mode. After typing the

first letter, the shift key ( ) will change to
and following letters will be lowercase.

5. Tap to input another upper-case letter or tap

change to in ABC mode. All following letters
will be uppercase until you tap the shift key again.

Using Symbol/Numeric Mode

Use Symbol/Numeric Mode to add numbers, symbols, or
emoticons.

1. Rotate your phone counterclockwise to a Landscape

orientation.

twice to switch to ABC mode. The shift key will

Understanding Your Phone 45

2. Tap

DRAFT

FOR INTERNAL USE ONLY

3. Tap the desired number, symbol, or emoticon

4. Tap t he

5. Tap to return to Abc mode.

Predictive Text

By using the Predictive Text option, you can have next-letter
prediction and regional error correction, which compensates
for pressing the wrong keys on the QWERTY keyboard.
Predictive text is turned on by default.

1. Press and hold

2. Tap the ON/OFF slider, located to the right of the

46

at the bottom of the screen. The following

screen displays:

characters.

button to access additional symbols.

on the keyboard, then tap .

Predictive text

field, to .

3. In the text portion of the message screen, begin typing

a word. A list of word options is displayed. Tap one of
the words to replace the word that has already been
typed or scroll the line of words to the left for more
word choices.

4. Continue typing your message. Tap to send the

message or press
information, refer to “Creating and Sending Messages”
on page 101.

Note:

You can also use Predictive Text mode in the portrait
orientation.

for more options. For more

Entering Text Using Handwriting

DRAFT

FOR INTERNAL USE ONLY

You can enter text simply by using your finger to handwrite
letters on your screen.

1. Press and hold

2. From the keypad, tap .

3. Use your finger tip to write out each character. You can

print or use cursive.

4. You can write out your entire message using the

Handwriting feature or tap to switch back to
Samsung keyboard mode.

on the keyboard, then tap .

Using the Google Voice Typing Feature

You can use your voice to enter text using the Google Voice
typing feature.

1. Ta p

on the keyboard.

2. At the

into the microphone.

Samsung Keyboard Settings

For information on how you can configure your Samsung
keyboard settings, see “Samsung Keyboard settings” on
page 140.

3. If the red microphone turns gray, then the feature has

timed out and you should tap the microphone icon to
start again.

The text is displayed in the message as you are
speaking.

4. Tap to return to the keyboard.

Speak now

prompt, speak clearly and distinctly

Understanding Your Phone 47

Note:

DRAFT

FOR INTERNAL USE ONLY

The feature works best when you break your message
down into smaller segments.

Entering Text Using Swype

Swype™ is a text input method that allows you to enter a
word by sliding your finger or stylus from letter to letter,
lifting your finger between words. Swype uses error
correcting algorithms and a language model to predict the
next word. Swype also includes a tapping predictive text
system.

The following example shows how to enter the word “This”.
Put your finger down on the “T”, and without lifting, glide it
to the “h”, then to the “i” then over to the “s”.

48

Enabling and Configuring Swype

The Samsung keyboard is the default text input method, so
to use Swype, you must first change the default keyboard
setting.

To enable Swype:

1. From a screen where you can enter text, touch and

drag down from the Notifications area then tap

Select input method

2. Tap the

The Swype keyboard is displayed.

Swype Settings

For information on how you can configure your Swype
settings, see “Swype Keypad Settings” on page 141.

Swype Text Entry Tips

You can access the SwypeTips application and watch a video
or tutorial on using Swype. You can also use the following
Swype text entry tips.

•

Create a squiggle (like an S shape) to create a double letter (such
as pp in apple).

•

Touch and hold a key to view the punctuation menu then make a
selection.

.

Swype

radio button. It will turn green.

•

DRAFT

FOR INTERNAL USE ONLY

Move your finger or stylus over the apostrophe to enter

contractions.

•

Double-tap on the word you want to change to correct a
misspelled word, then tap the delete key to erase one character.
Touch and hold the delete key to erase an entire word.

Understanding Your Phone 49

Section 3: Accounts and Contacts

DRAFT

FOR INTERNAL USE ONLY

Accounts

Your phone provides the ability to synchronize information,
from a variety of accounts, including Email, Facebook,
Google, and your Samsung account. Depending on the
account, you can choose to synchronize your calendar,
contacts, and other types of content.

Contacts from your accounts appear in your phone’s
Contacts.

With synchronization, you can ensure that information on
your phone is updated with any information that changes in
your accounts.

50

Setting Up Your Accounts

Set up and manage your accounts with the
settings.

For information about setting up other, non-synchronized
email accounts, see “Configuring Email Accounts” on
page 79.

Tip:

For more information on setting up your email, contact
your Wireless Provider.

Adding an account

1. From the Home screen, touch Menu
Settings ➔Accounts

2. Under

3. Select an account type, then follow the prompts to

enter your credentials and sign in.

4. The phone communicates with the provider’s server to
set up your account on the phone.

My accounts

.

, touch

Add account

Accounts

, then touch

.

Controlling Synchronization

DRAFT

FOR INTERNAL USE ONLY

You can choose to have your phone automatically
synchronize with your accounts, or manually synchronize
each account when you want to check messages.

You may also choose to limit automatic or background
synchronization to extend battery life.

Menu

1. From the Home screen, touch
Settings ➔Accounts

2. Under

3. Under

My accounts

The related account type screen appears.

Accounts

Sync settings

listing some or all of the following synchronization
settings:

•Sync Calendar

•Sync Contacts

•Sync Email

•Sync Gmail

• Sync Google Photos

• Sync Google Play Books

• Sync Google Play Magazines

.

, touch the desired account type.

, touch the desired account ID. The

screen for the selected account appears

, then touch

• Sync Google Play Movies & TV

• Sync Google Play Music

• Sync Internet

• Sync Picasa Web Albums

• Sync Tasks

4. Touch these settings to enable/disable synchronization

of the associated file types. When enabled, a check
mark appears in each setting check box.

•

•

Tip:

You can control automatic synchronization using the
toggle in the Quick Settings menu on the Notifications
screen. (For more information, refer to “Quick Settings
Menu” on page 34.)

With automatic synchronization enabled, your phone
automatically synchronizes its related files with similar files on
on-line file servers.
With automatic synchronization disabled, you can manually

Sync all

sync accounts by touching
for each account.

in the account type screen

Sync

Accounts and Contacts 51

Google Account Privacy Settings

DRAFT

FOR INTERNAL USE ONLY

Personalize the Privacy settings for Google accounts:

1. From the Home screen, touch
Settings ➔Accounts

2. Under

3. Under

52

My accounts

type screen appears.

Privacy

•Maps & Latitude

accounts.

•Search

: Manage Google accounts location histories and

search histories.

• Location settings

location information for Google accounts.

•Google+

: Manage Google+ information for Google accounts.

•Ads

: Choose whether to personalize Google and AdMob

advertisements for Google accounts.

.

, touch

, the following options are available:

: Tailor

Location settings

: Choose whether Google apps can access

Google

Menu

. The

, then touch

Google

for Google

account

Managing accounts

1. From the Home screen, touch Menu
Settings ➔Accounts

2. Under

The related account type screen appears.

3. Under
Sync settings

(For more information, refer to “Controlling
Synchronization” on page 51.)

4. To enable or disable a synchronization setting, touch it.
When enabled, a check mark appears in the check box.

5. To invoke the enabled synchronization settings for the
selected account, touch

6. To remove the selected account from your phone,
touch
prompts you to confirm the removal.

To remove the selected account, touch

account

.

My accounts

Accounts

Remove account

.

, touch the desired account type.

, touch the desired account ID. The

screen for the selected account appears.

Sync now

.

. A

Delete account?

, then touch

pop-up

Remove

Contacts

DRAFT

FOR INTERNAL USE ONLY

To a ccess Con tacts:



From the Home screen, touch

Contact tips:

•

Swipe your finger left-to-right across a contact to make a call to
the contact.

•

Swipe right-to-left across a contact to create a message
addressed to the contact.

Contacts

.

2. Touch contact fields to select or enter information:

•

•

•

Adding Contacts

1. From the Home screen, touch
Add contact

•

If you have defined accounts (Google, Samsung, and so on),

Save contact to

the
account to receive the new Contact entry.

•

If you have not defined any accounts, the
up appears. The following options are available:

–

OK

: Saves your contacts in

–

Add new account

device will save your contacts. The
appears. (For more information, refer to

Accounts”

.

pop-up appears. Select

: Lets you define an account to which your

on page 50.)

Contacts

Phone

Save contact

“my device contacts”

Add new account

“Setting Up Your

➔

or the

.

•

•

pop-

•

screen

Tou c h
contact.

Tou c h
enter

Name suffix

Touch

Label
Work Fax, Home Fax, Pager, Other, Custom

add another number, touch .
Touch

Label
Custom

Touch
the
or

Touch next to
the

Anniversary, Other

Add photo ID

Name

to enter a name for the contact. Touch to

Name prefix, First name, Middle name, Last name,

.

Phone number

button to choose a label, from

Email address

button to choose a label, from

to create a new label. To add an address, touch .

Address

Label

button to choose a label, from

Custom

to create a new label. To add an address, touch

.

Label

button to choose a label, from

to choose a picture to identify the

to enter a phone number, then touch the

Mobile, Home, Work

, or

to enter an email address, then touch the

Home, Work, Other

to enter a street or postal address, then touch

Home, Work, Other

Events

to enter a special date, then touch

Birthday

, or

Custom

to create a new label.

Accounts and Contacts 53

Callback

,

or

,
. To

, or

,

•

DRAFT

FOR INTERNAL USE ONLY

Touch

Groups

to assign the contact to a group. For more

information about Groups, see

•

Touch

Ringtone

to choose a ringtone for the contact.

•

Touch

Message alert

you receive a message from this contact.

•

Touch

Vibration pattern

when you receive a call or message from this contact.

•

Touch

Add another field
Phonetic Name, Organization, IM, Notes, Nickname
Website

, or

Relationship

3. When you finish selecting and entering information,
Save

touch

.

“Groups”

on page 60.

to select the alert tone to be played when

to choose a vibration pattern to play

to add more fields, including

,

.

54

Creating Contacts from Recent calls

Save a phone number from a recent call to create a new
contact, or update an existing contact.

For more information, refer to “Creating or Updating Contacts
Using Recent calls” on page 68.

Creating Contacts from the Phone Keypad

Enter a phone number with the Phone Keypad, then save it.

1. From the Home screen, touch

2. Touch the digits of the phone number on the

3. Tou ch

4. Continue entering contact information. (For more

Tip:

Add to Contacts

the pop-up menu.

information, refer to “Adding Contacts” on page 53.)

While entering a phone number, you can add waits or
pauses. Enter the number up to the pause or wait, then
touch Menu

to select

, then select

Add 2 sec pause

Phone

.

Keypad

Create contact

or

Add wait

.

from

.

Updating Contacts

DRAFT

FOR INTERNAL USE ONLY

Make changes to update an existing contact.

Contacts

1. From the Home screen, touch

2. Touch a contact to view its information, then touch
Edit

.

– or –
Touch and hold a contact, then select
menu.

3. Continue entering contact information. (For more

information, refer to “Adding Contacts” on page 53.)

Updating Contacts from the Phone Keypad

Enter a phone number with the Phone Keypad, then save it.

1. From the Home screen, touch

2. Touch the digits of the phone number on the

3. Touch

4. Select a contact to update, then continue entering

Add to Contacts

the pop-up menu.

contact information. (For more information, refer to
“Adding Contacts” on page 53.)

, then select

.

Edit

from the

Phone

.

Keypad

Update existing

from

Updating Contacts from Recent calls

Save a phone number from a recent call to create a new
contact, or update an existing contact.

For more information, refer to “Creating or Updating Contacts
Using Recent calls” on page 68.

Choosing Contacts to Display

1. From the Home screen, touch

2. To uch

•

•

•

•

.

Contacts

.

Menu

, then touch

Choose

All contacts

Touch

Phone

to show only show contacts saved to the phone.
Choose an account to only display contacts from that account.
Choose

Customized list

account, or the phone.

Contacts to display

to show all contacts.

to select contact types for each

Accounts and Contacts 55

:

Contacts Settings

DRAFT

FOR INTERNAL USE ONLY

1. From the Home screen, touch
Menu

2. Touch

•

Select
least one stored phone number.

•

Touch

•

Touch

•

Touch
sending contacts namecards to other accounts or devices. (For
more information about sending contacts, see

Namecards”

, then touch

Only contacts with phones

List by

to sort contacts by first or last name.

Display contacts by
Contact sharing settings

on page 59.)

Settings

to show contacts with at

to list contacts by first or last name.

to set your preference for

56

Contacts

:

“Sending

.

Other Contacts Options

1. From the Home screen, touch

2. Touch a contact to display it, then touch

•History

•Edit

“Updating Contacts”

•Delete

•Join contact

as one. (For more information, refer to
page 57.)

• Mark as default

(such as IM or email address). Defaults are the contact method
used when creating a message or calling a contact. You can
also set a default by touching and holding on a contact field.

• Share namecard via

information, refer to

• Add to reject list

from the contact are rejected automatically. To remove a
contact from the reject list, touch and hold on the contact in the
main contacts screen, then choose

Contacts

.

Menu

:

: View calls and messages to and from this contact.

: Modify contact information. (For more information, refer to

on page 55.)

: Erase the contact record.

/

Separate contact

: Set a default phone number or other field

“Sending Namecards”

: Mark the contact so that calls or messages

: Manage multiple contacts

“Joining Contacts”

: Send the namecard. (For more

on page 59.)

Delete from reject list

on

.

• Print contact info

DRAFT

FOR INTERNAL USE ONLY

compatible Samsung Bluetooth-enabled printer.

• Add shortcut to Home

screen.

: Print the namecard via Bluetooth to a

: Add shortcut to this contact to Home

My Local Profile

My local profile is your own contact record, listed under ME
in Contacts. You can send My local profile as a vCard via
Bluetooth or as an attachment.

Creating My Local Profile

1. From the Home screen, touch
ME

touch

Menu

Set up profile

in the contact fields. (

, then touch

2. Under

3. Enter your information

information, refer to “Adding Contacts” on page 53.)

Sending My Local Profile

You can send your profile as a vCard via Bluetooth to other
Bluetooth devices, or as an attachment.

1. From the Home screen, touch

2. Touch your profile to display your contact information.

3. Touch

Contacts

.

.

For more

Contacts

.

Share namecard via

.

4. Choose a sending method or app from the
action using

the profile.

Joining Contacts

Your phone can synchronize with multiple accounts,
including Google, Corporate, and other providers, plus social
networking sites like Facebook. When you synchronize
contacts from these accounts with your phone, you may have
multiple contacts for one person.

Joining contact records allows you to see all the contact’s
numbers and addresses together. Joining also helps you
keep your contacts updated, because any changes to
information in the respective accounts is automatically
updated the next time you synchronize with the account.

Joining contacts

1. From the Home screen, touch

2. Touch a contact to display its information.

3. To uch

available contacts appears.

4. Select a contact to join to the displayed contact. The
joined contact appears.

Complete

pop-up, then follow the prompts to send

Contacts

.

Menu

, then touch

Join contact

Accounts and Contacts 57

. A list of

5. To join another contact, touch the

DRAFT

FOR INTERNAL USE ONLY

Joined contact screen appears.
Touch

Join another contact

appears.
Select a contact to join to the displayed contact. The

joined contact appears.

Separating contacts

1. From the Home screen, touch

2. Touch a contact to display its information.

3. Touch the

4. Touch to the right of a contact to remove it from

the selected joined contact.

Connection

field to display joined contacts.

Connection

. A list of available contacts

58

Contacts

field. The

.

Exporting and Importing Contacts

You can export your contact list to an installed memory card,
or import a list of contacts (previously exported) from a
memory card.

1. From the Home screen, touch

2. Tou ch

3. Select an option, then follow the prompts to complete

the operation:

• Import from USB storage

installed mass storage.

• Export to USB storage

storage.

• Import from SD card

installed memory card.

• Export to SD card

• Share namecard via

more information, refer to

59.)

Contacts

Menu

, then touch

: Copy contacts to an installed memory card.

Import/Export

: Copy contacts that are saved in

: Copy contacts to installed mass

: Copy contacts that are saved on an

: Share contacts as Namecards. (For

“Sending Namecards”

.

.

on page

Sending Namecards

DRAFT

FOR INTERNAL USE ONLY

You can send a contact entry as a namecard using a
Bluetooth connection to another device, or as an attachment
to a Gmail or Email message.

Important!

Not all Bluetooth devices will accept contacts, and
not all devices support transfers of multiple
contacts. Check the target device’s documentation.

Contacts

1. From the Home screen, touch
Menu

2. Touch

namecard via

3. Touch contacts to mark them for sending, or touch

Select all

the check box for marked contacts.

4. Touch

5. Choose a sending method or app from the

action using

the profile.

, then touch

.

to mark all contacts. A check mark appears in

Done

.

pop-up, then follow the prompts to send

Import/Export

.

➔

Share

Complete

Favorites

Mark contacts with a star to identify them as Favorites.
Favorites display on the

Contacts

indicated by the .

Creating Favorites

1. From the Home screen, touch

2. Touch and hold on a contact, then select
favorites

– or –
Touch a contact to display it, then touch at the top
right of the screen, it changes color to .

Favorites

tab in the

screens for fast dialing or messaging, and are

from the pop-up menu.

Accounts and Contacts 59

Phone

Contacts

Add to

and

.

Groups

DRAFT

FOR INTERNAL USE ONLY

Assign contacts to Groups to make searching for contacts
faster, or to quickly call or send messages to group
members. Your phone comes with pre-loaded groups you
can use to add your contacts.

Adding a New Group

1. From the Home screen, touch
Groups

.

Menu

➔

2. Touch

•

Touch

Group name

•

Touch

Group ringtone

members of this group.

•

Touch

Vibration pattern

from members of this group.

•

Touch

Add member

3. Touch

60

Save

Create

to enter a Group Name.

to choose a ringtone for calls from

to choose a vibration to play for calls

to select members from Contacts.

to save the new group.

Contacts

➔

, then enter information:

Editing a Group

1. From the Home screen, touch

2. Touch a Group to display it.

3. Tou ch

the group. For more information, see “Adding a New
Group” on page 60.

Deleting a Group

Tip:

You can only delete groups that you have created.

1. From the Home screen, touch

2. Tou ch

3. Touch a Group to mark it for deletion, or touch

to mark all groups. When selected, a check mark
appears in the check box. You cannot delete pre­loaded groups.

4. Tou ch
group members

Groups

Groups

Delete

.

Menu

➔

Edit

.

Menu

➔

Delete groups

, then choose

.

Contacts

➔

, then update information for

Contacts

➔

.

Select all

Group only

or

Group and

Adding Contacts to a Group

DRAFT

FOR INTERNAL USE ONLY

1. From the Home screen, touch
Groups

.

2. Touch a Group to display it, then touch .

3. Touch contact(s) to mark them for addition, or touch

Select all

to mark all contacts. When selected, a check

mark appears in the check box.

4. Touch

Removing Contacts from a Group

1. From the Home screen, touch

2. Touch a Group to display it.

3. Touch

4. Touch contact(s) to mark them for removal, or touch

5. Touch

Done

to add the selected contact(s).

Groups

.

Menu

➔

Remove member

Select all

to mark all contacts. When selected, a check

mark appears in the check box.

Done

to remove the selected contact(s).

Contacts

Contacts

.

➔

➔

Sending a Message to Group Members

Create a new text or email message, addressed to the
group’s members.

1. From the Home screen, touch

2. Touch and hold a Group, then touch
Send email

3. Touch contacts to mark them as recipients for the new

message, then touch

4. The new message opens, with the marked contacts as
recipients. Continue creating the message, as desired.
(For more information, refer to “Creating and Sending

Messages” on page 74, or “Composing and Sending
Email” on page 79.)

Contacts

➔

Groups

.

Send message

.

Done

.

Accounts and Contacts 61

or

Speed Dials

DRAFT

FOR INTERNAL USE ONLY

Speed dials are 1-, 2-, or 3-digit shortcuts (1 to 100) you
assign to contacts, to allow you to quickly call the contact.

For more information about calling using speed dials, see
“Making Calls using Speed Dials” on page 63.

Note:

Speed dial 1 is reserved for Voicemail, and cannot be
assigned.

Assigning Speed Dials

1. From the Home screen, touch
Menu

2. Touch

3. A list of speed dials displays.Touch a speed dial, then

touch a contact to assign the speed dial to the contact.

Removing or Reassigning a Speed Dial

1. From the Home screen, touch

2. Touch

3. Touch and hold an assigned Speed dial setting, the

following options pop-up:

• Replace

contact.

•Delete

62

, then touch

Menu

, then touch

: Touch a new speed dial location to assign it to the

: Un-assign the speed dial from the contact.

Contacts

.

Speed dial setting

Contacts

.

Speed dial setting

.

.

Section 4: Calling

DRAFT

FOR INTERNAL USE ONLY

Making Calls

Your phone offers multiple ways to make calls:

•

Use the touch screen
or speed dial.

•

Call a contact from

•

Call a contact from

•

Return a call, or call a recent caller, from

•

Voice dial using

Phone Keypad

Contacts
Favorites

Voice Dialer

to enter the phone number

.

.

Recent

.

.

Making Calls Using the Phone Keypad

1. From the Home screen, touch

2. Touch the digits of the telephone number on the
Keypad

3. Touch to place the call.

Making Calls using Speed Dials

Speed Dials are 1-, 2-, or 3-digit shortcuts (1 to 100) you
assign to contacts, to allow you to quickly call the contact.

(For more information about setting speed dials, see “Speed
Dials” on page 62.)

1. From the Home screen, touch

2. Touch the digits of the speed dial number on the
Keypad

Phone

.

.

Phone

.

, holding the last digit until the number dials.

Calling 63

Making Calls from Contacts

DRAFT

FOR INTERNAL USE ONLY

A contact is an entry that you have created to store the
name, numbers, and other information for people or groups
of interest.

(For more information, refer to “Contacts” on page 53.)

Contacts

1. From the Home screen, touch

2. Find the contact and touch it to open the Contact entry.

3. Swipe your finger from left to right across the contact

to dial their default number.
– or –

Touch a contact, then touch to dial the number.

.

Making Calls using S Voice

Place a call by speaking the name or number.

1. From the Home screen, touch

2. The first time you access S Voice, follow the prompts to

confirm the license agreement, and view information
about S Voice.

3. Follow the prompts to speak a command. You can say

commands such as:

• Call <Name >

• Dial <Phone number>

•Redial

64

S Voice

.

: Call an entry in your Contacts list.

: Repeat a recent call.

Phone

. then touch

: Call a spoken phone number.

Making Calls using Favorites

DRAFT

FOR INTERNAL USE ONLY

Favorites are contacts that you designate as favorites by
starring them. (For more information about creating favorites,
see “Favorites” on page 59.)

1. From the Home screen, touch
Favorites

2. Touch

3. Find the contact and touch it to open the Contact entry.

4. Swipe your finger from left to right across the contact

to dial their default number.
– or –

Touch a contact, then touch to dial the number.

Making Calls from Recent calls

Return a call, or call a number from a recent call stored in
Recent calls.

(For more information, refer to “Recent Calls” on page 67.)

to display favorites.

Phone

.

Multi-party Calling

Use multi-party call features to set up a call between multiple
callers, such as for a conference call.

1. Establish the first call, by answering an incoming call

or making a call.

2. To uch

3. Make the second call by touching the phone number

digits, then press .

4. Touch Merge to merge the calls into one conference

call.

5. To end the call touch

Add call

. The first call is placed on hold.

.

Calling 65

Answering Calls

DRAFT

FOR INTERNAL USE ONLY

You can answer incoming calls when the phone is locked or
unlocked.



Touch and drag the

Answer

icon to the right.

Tip:

To silence the ringtone for an incoming call, press the

Volume

key Up or Down.

66

Sending Calls to Voicemail

When your phone alerts you to an incoming call, you can
reject the call to send the caller to voice mail, or reject the
call and send a message to the caller.

Rejecting a call



Touch and drag the

Rejecting a call with a message



Touch and drag
middle of the screen, then select an existing message,
or

Note:

Answering Call-Waiting Calls

When you receive a call while on a call:

•

Touch and drag the
incoming call. The original call is placed on hold, and remains on
hold until you end the second call, or swap calls back to the
original call.

•

Tou ch

Swap

Reject

icon to the left.

Reject call with message

Create new message

For more information about creating reject
messages, see “Set reject messages” on
page 70.

to place a call on hold and return to the original call.

.

Answer

icon to the right to answer the

toward the

–

DRAFT

FOR INTERNAL USE ONLY

Options During a Call

While in a call, you can use these features:

•

Add call

: Display the Dialer to set

up a multi-party call.

•

Keypad

: Display a keypad to enter

numbers.

•

End call

: End the phone call.

•

Speaker

: Enable or disable

speakerphone.

•

Mute

: Mute or unmute your voice

on the call.

•

Headset

: Switch the call’s audio to

a Bluetooth headset.

•

Touc h

–
–
–

–

Menu

for options:

Contacts

: Launch Contacts.

Message

: Launch Messaging to view or create messages.

Memo

: Launch S Memo to take notes in text, or create a

drawing.

Noise reduction on/Noise reduction off

reduction, to improve call audio quality in noisy environments.

: Enable or disable noise

My call sound

cases where you might need the sound softer or clear, or
optimized for your right or left ear.

Ending a Call



Tou ch .

Recent Calls

When you place, answer, or miss a call, a record of the call is
saved in Recent calls.

Accessing Recent calls



From the Home screen, touch

Making Calls using Recent calls

1. From the Home screen, touch

2. Touc h

3. Swipe your finger from left to right across the call to

redial.
– or –

Touch a call, then touch to dial the number.

: Apply a sound equalizer to the call audio, in

Phone

Recent

to display recent calls.

Phone

Recent

to display recent calls.

Calling 67

➔

.

Sending Messages using Recent calls

DRAFT

FOR INTERNAL USE ONLY

1. From the Home screen, touch
Recent

.

2. Swipe your finger from right to left across the call.

– or –
For a contact call, touch the picture ID icon, then touch

to create a message to the number.

Phone

➔

Creating or Updating Contacts Using Recent calls

1. From the Home screen, touch
Recent

.

2. Touch and hold on a call, then select

from the pop-up menu.

3. Choose

4. Continue entering contact information. (For more

68

Create contact

information, see “Contacts” on page 53.)

or

Phone

Add to Contacts

Update existing

➔

.

Managing Recent calls

Deleting records

1. From the Home screen, touch

2. While viewing the calls, touch
Delete

3. Touch call records to mark them for deletion, or touch
Select all

4. Tou ch

Filtering records

1. From the Home screen, touch

2. While viewing the calls, touch
View by

3. Select a filter type, from
Missed calls, Dialed calls, Received calls, Rejected calls, All
messages

Phone

Recent

.

Menu

.

. A check indicates marked records.

Delete

to delete marked records.

Phone

Recent

.

Menu

.

All calls and messages, All calls

,

Sent messages

, or

Received messages

➔

, then touch

➔

, then touch

.

,

Viewing call durations

DRAFT

FOR INTERNAL USE ONLY

View the length of the Last call, all Dialed calls, all Received
calls, or All calls.

Phone

Menu

➔

, then touch

1. From the Home screen, touch
Recent

.

2. While viewing calls, touch

duration

.

Call

Call Settings

Configure settings for calling with your phone.



To access Call settings, from the Home screen, touch

Call rejection

Create and manage a list of phone numbers, to have your
phone automatically reject calls you receive from those
numbers.



From the
these options:

• Auto reject mode

• Auto reject list

Phone

➔

Menu

Call Settings

Auto reject On, or touch
Auto reject Off. When On, calls from numbers on the Auto
reject list will be rejected.

Auto reject mode is ON. Turn on
no caller ID. Touch
numbers to reject, or select them from Contacts. Touch

to set options for using the reject number list.

criteria

➔ Call Settings

screen, touch

: Touch

Auto reject mode

Auto reject mode

: Enter telephone numbers to be rejected when

Unavailable

Create

, then follow the prompts to enter

.

Call rejection

to turn

to turn

to reject calls with

Calling 69

for

Match

Set reject messages

DRAFT

FOR INTERNAL USE ONLY

Create and manage text messages to send to callers when
you select
screen.

Reject call with message

1. From the

2. Manage messages:

Call Settings

.

messages

•

To create new messages, touch
prompts.

•

To modify an existing message, touch the message, then edit
the text.

in the

screen, touch

Create

Incoming call

Set reject

, then follow the

70

Ringtones and keypad tones

Select incoming call ringtone and vibration, and enable or
disable call vibration and keypad tones.



From the

keypad tones

• Device ringtone

you of incoming calls.

• Device vibration

to alert you of incoming calls.

• Incoming call vibration

selected
appears in the check box.

•Keytones

when you enter numbers with the Phone keypad. When
enabled, a check mark appears in the check box.

Call Settings

Device vibration

: Touch to enable/disable playing of DTMF tones

screen, touch

. The following options are available:

: Select the ringtone your phone plays to alert

: Select the vibration pattern your phone uses

: Touch to enable/disable use of your

. When enabled, a check mark

Ringtones and

Call alerts

DRAFT

FOR INTERNAL USE ONLY

Set options for sounds and vibrations to occur during calls.



From the

Call Settings

following options are available:

• Call vibrations

have your phone vibrate when it connects to the network.
Enable on

Call-end vibration

the other caller ends the call.

•Call status tones

calls. Enable
when the other caller answers a call. Enable
have a tone play once per minute during a call. Enable

tone

to have the phone play a tone when the other caller ends

the call. Touch

• Alerts on call

messages play during phone calls. When disabled, these
notifications will be muted during a call.

screen, touch

: Enable

Vibrate on connection to network

: Choose options for sounds to play during

Call connect tone

OK

to save the settings.

: Enable to have notifications for alarms and new

Call alert

. The

to have the phone vibrate when

to have the phone play a tone

Minute minder

Call end

Call answering/ending

Manage settings for answering and ending calls.

1. From the
ending

to

to

• Answering key

• The power key ends calls

Auto screen off during calls

When enabled, the screen automatically turns off during
phone calls, and the proximity sensor on the front of the
phone is used to turn the screen back on when the phone is
moved or brought close to another surface, such as when
you move the phone to your ear.



From the

during calls

Call Settings

. The following options are available:

call by pressing

Power/Lock

Call Settings

to enable or disable the option.

screen, touch

: When enabled, you can answer an incoming

Home

.

: When enabled, pressing

ends a call.

screen, touch

Call answering/

Auto screen off

Calling 71

Accessory setting for call

DRAFT

FOR INTERNAL USE ONLY

Configure headset options for calls.



From the

Call Settings

. The following options are available:

for call

• Headset settings for incoming calls

–

Automatic answering

headset connected to the Headset Jack, incoming calls are
answered automatically after a delay, set at Automatic
answering timer.

–

Automatic answering timer

before automatically answering an incoming call when
Automatic answering is enabled and a headset is connected to
the phone.

• BT (Bluetooth) headset settings for outgoing calls

–

Outgoing call conditions

Bluetooth headset, you can choose to make calls even when the
phone is locked.

72

screen, touch

: When enabled, and you have a

: Choose a time period to delay

: When the phone is paired with a

Accessory settings

:

:

Use extra volume for calls

When enabled, the call screen displays a volume control, for
adjusting call volume during calls.



From the

calls

Increase volume in pocket

When enabled, the phone uses the proximity sensor to detect
when the phone is in a pocket or other close-fitting location
such as a purse or bag, and increases the volume for
incoming call ringtones.



From the

pocket

Noise reduction

When enabled, the phone uses both of its microphones to
detect background noise from your environment and
suppress it during calls.

1. From the

2. Tou ch

Call Settings

to enable or disable the option.

Call Settings

to enable or disable the option.

Call Settings

Noise reduction

screen, touch

screen, touch

screen, touch

to enable or disable the option.

Use extra vol. for

Increase volume in

Additional settings

.

Voicemail

DRAFT

FOR INTERNAL USE ONLY

Configure options for voicemail.



From the

Call Settings

following options are available:

• Voicemail service

service provider’s voicemail service. If you have another option
for voicemail installed, select it here.

• Voicemail settings

voicemail (speed dial 1) is set to your phone number. If you wish
to use another Voicemail service, touch
set a new one.

•Ringtone

: Choose sound to play for a voicemail notification.

•Vibrate

: Choose an option for vibration to play for a voicemail

notification.

screen, under

: By default, your phone uses your wireless

: By default, the speed dial for calling

Voicemail

, the

Voicemail number

Other call settings

to



From the
the following options are available:

•Auto retry

• TTY mode

•DTMF tones

• Voice privacy

Call Settings

: When enabled, the phone will automatically redial a

call if it receives a busy signal from the network.

: Choose a TTY mode to enable TTY mode, for use

with optional TTY equipment.

tones, which play when you use the keypad during a call, such
as when navigating phone menus.

improve the security of phone calls.

screen, under

: Set the length of Dual-tone Multi-frequency

: Enable or disable Enhanced voice privacy, to

Other call settings

Calling 73

,

Section 5: Messaging

DRAFT

FOR INTERNAL USE ONLY

This section describes how to send and receive messages,
and other features associated with messaging.

Types of Messages

Your phone supports these types of messages:

•

Text messages

text to other mobile phones or email addresses (also known as
SMS).

•

Multimedia messages

pictures, video, and/or sound to other mobile phones or email
addresses (also known as MMS).

•

Mobile IMs

popular messaging sites.

•

Email

including Corporate mail.

•

Gmail

•

Voicemail

•

Google Talk

74

: Send and receive simple messages containing

: Send and receive text messages with

: Exchange Instant Messages with other users of

: Send and receive email from your email accounts,

: Send and receive Gmail from your Google account.

: Retrieve voice messages from callers.

: Chat with other Google Talk users.

Text and Multimedia Messaging

Your phone can send and receive text and multimedia
messages.

Creating and Sending Messages

1. From the Home screen, touch

2. Tou ch

or email address, or touch to add recipients from
Contacts. As you enter text, matching contacts appear.
Touch a contact to add it to the list.

3. Tou ch

following options are available (which options are
available depends on whether you include an
attachment):

•

Touch Attach
files) or content (Memo text, Calendar events, Locations, Contacts)
to the message (converts the message to MMS).

New message

Enter recipient

Enter message

Messaging

.

and enter a name, phone number

, then enter the message text. The

to add media (images, pictures, videos, audio

➔

•

DRAFT

FOR INTERNAL USE ONLY

Touch Menu

–

Insert smiley

–

Add text

Contacts or Text templates to add.

–

Preview

–

Add to Contacts

save the info as a new contact, or update an existing contact.

–

Add slide

pictures or other media (adding a slide converts the message to
MMS).

–

Add subject

MMS.)

–

Duration (5sec)

displays.

–

Layout (bottom)

above (Text on top) of the attachment(s), or after (Text on
bottom).

–

Discard

4. Touch to send the message.

for options:

: Add a text emoticon to the message.

: Select text from S Memo, Calendar, Location,

: View the message and attachments before sending.

: If the recipients are not saved in Contacts,

/

Delete slide

: Add or remove a slide. Slides hold

: Add a subject field (converts the message to

: Set the length of time the media on the slide

: Choose whether the message text appears

: Erase this message.

Managing Messages

Messages you send and receive to the same contact, number
or address are grouped together as a “conversation”.
Threads allow you to see all the messages you exchanged
with a recipient in one place.

1. From the Home screen, touch

2. Message threads display by contact, number, or

address. While viewing message threads, you have
these options:

•

Touch and hold a thread to choose options, including:

–

View Contact

save the sender/recipient’s information.

–

Delete thread

–

Register number as spam

reject list. Messages from this number are automatically placed
in the Spam messages folder.

•

Tou c h

–

Search

–

Delete threads

erasure, or touch

Messaging

/

Add to Contacts

: Erase the entire message thread.

Menu

for options, including:

: Enter characters to search messages and recipients.

: Touch message threads to mark them for

Select all

: View the contact record, or

: Add this number to message

to mark all message threads.

Messaging 75

.

–

DRAFT

FOR INTERNAL USE ONLY

Draft messages

later reuse and/or to be sent to a recipient.

–

Locked messages

them from accidental deletion.

–

Spam messages

registered as spam senders.

–

Settings

76

: Messages you have composed and saved for

: Messages you have locked to protect

: Messages received from numbers you have

: Configure Messaging settings.

Message Settings

Configure settings for message storage, delivery, or alerts.

1. From the Home screen, touch

2. Tou ch

•Display

–

Bubble style

message thread. Touch a bubble style for each side of the
conversation, then touch

–

Background style

behind message threads. Touch a style, then touch

–

Use the volume key

of message text while viewing by pressing the Volume Key.

• General settings

–

Delete old messages

automatically erased when storage reaches default limits. When
disabled, the phone will prompt you to delete old messages to
make room.

–

Text message limit

conversation.

–

Multimedia message limit

messages per thread.

Menu

, then touch

:

: Choose the appearance of messages in a

:

Settings

Save

.

: Choose the appearance of the screen

: When enabled, you can change the size

: When enabled, messages are

: Set the number of SMS messages per

: Set the number of MMS

Messaging

for options:

.

Save

.

–

DRAFT

FOR INTERNAL USE ONLY

Text templates

to your messages. Use a pre-loaded text template, or create
your own.

• Text message (SMS) settings

–

Delivery reports

for text messages you send.

–

Auto combination

segment messages and shows them as a single message.

• Multimedia message (MMS) settings

–

Delivery reports

for multimedia messages you send.

–

Auto-retrieve

automatically. When disabled, the phone prompts for download.

–

Roaming auto-retrieve

download and display automatically when roaming. When
disabled, the phone prompts you to download new MMS
messages.

–

MMS alert

changes mode to MMS.

: Text templates are phrases that you can add

:

: When enabled, you receive a delivery report

: When enabled, re-assembles multi-

:

: When enabled, you receive a delivery report

: When enabled, MMS messages download

: When enabled, MMS messages

: When enabled, alerts you when a message

• Notification settings

–

Notifications

Status bar.

–

Select ringtone

–

Vibrate

: Configure vibration for message alerts.

–

Message alert repetition

repeat Once, Every 2 minutes, or Every 10 minutes.

–

Preview message

message appears in the Status bar.

• Emergency message settings

–

Emergency alerts

Emergency Alerts from the Commercial Mobile Alert Service
(CMAS), including Presidential Alerts, Imminent Alerts (Severe or
Extreme), and AMBER Alerts (missing persons). You may choose
not to receive Imminent and AMBER alerts, but Presidential
Alerts cannot be disabled. All alerts are enabled by default
(check mark shown). For more information about Emergency
Alerts see

“Emergency alerts”

–

Emergency notification preview

Emergency Alert tone (and vibration, if enabled). The Emergency
Alert tone plays at the same volume as your call ringtone.

:

: When enabled, message alerts display in the

: Choose a sound for message alerts.

: Choose to have message alert

: When enabled, a preview of a received

:

: This device is designed to receive Wireless

on page 78.

: Listen to an example of a

Messaging 77

–

DRAFT

FOR INTERNAL USE ONLY

Vibrate

: Configure vibration for Emergency Alerts.

–

Alert sound

alerts.

–

Alert reminder

phone plays a sound to notify you of a Emergency Alert after the
Emergency Alert tone has stopped.

• Signature settings

–

Add signature

end of your outgoing messages.

–

Signature text

outgoing messages.

• Spam message settings

–

Spam settings

are activated.

–

Register number as spam

messages are blocked automatically.

–

Register phrase as spam

will cause messages to be blocked automatically.

–

Block unknown senders

“Unknown” senders are blocked automatically.

78

: When enabled, a sound plays for emergency

: Choose whether, and at what interval, your

:

: When enabled, adds your signature text to the

: Enter text to be added to the end of your

:

: When enabled, the Spam message settings

: Enter sender numbers whose

: Enter message text phrases that

: When enabled, messages from

Emergency alerts

This device is designed to receive Wireless Emergency Alerts
from the Commercial Mobile Alert Service (CMAS).
Emergency Alerts are geographically-targeted, and alert
customers of imminent threats to their safety within their
area. There is no charge for receiving an Emergency Alert.

There are four types of Emergency Alerts:

•

Presidential

•

Extreme

•

Severe

•

AMBER Alerts (missing person alert)

You may choose not to receive Extreme Alerts, Sever Alerts,
and AMBER Alerts. Presidential Alerts, however, cannot be
disabled. To disable Extreme and Severe Threat Alerts and
AMBER Alerts, do the following:

1. From the Home screen, touch

2. Tou ch

3. All alerts are enabled by default (check mark showing).

To disable alerts, touch an alert to remove the check
mark.

Messaging

Menu ➔ Settings ➔ Emergency alerts

.

.

Email

DRAFT

FOR INTERNAL USE ONLY

Send and receive email using popular email services.

Configuring Email Accounts

You can configure Email for most accounts in just a few
steps.

Configuring the first email account

1. From the Home screen, select
Email

.

2. Select your email provider, then follow the prompts to

set up your email account.

Note:

For more information on setting up your email, contact
your Wireless Provider.

Apps

➔

Composing and Sending Email

1. From the Home screen, select
Email

➔

Compose

2. Touch fields to enter recipients and the email text.

3. While composing a message, touch

options.

Attach

4. Touc h

5. Touc h

to add a file to the message.

Send

to send the message.

Apps

➔

.

Menu

for

Configuring additional email accounts

1. From the Home screen, select
Email

.

2. Touch

3. Select your email provider, then follow the prompts to

set up your email account.

Menu

, then touch

Settings

Apps

.

➔

Messaging 79

Managing Emails

DRAFT

FOR INTERNAL USE ONLY

Refreshing Your Email Account

Refresh your account to update your phone from the servers.

1. From the Home screen, select
Email

.

Refresh

2. Touch

Email Account Settings

Use Account settings to configure handling of your email.

Note:

Available settings depend on the email provider.

1. From the Home screen, select
Email

2. Touch an account to view it, then touch

Settings

➔ General preferences

80

.

.

Apps

Apps

for options.

➔

➔

Menu

➔

Gmail

Send and receive emails via Gmail, Google’s web-based
email.



From the Home screen, select

Setting Up Your Gmail Account

The first time you launch Gmail, your phone will prompt you
to set up your Google account.

1. From the Home screen, select

2. Follow the prompts to sign in, or create a new account.

3. The phone communicates with the Google server to set

up your account and synchronize your email.

Note:

You can use more than one Google account on your
phone. To add another account, from within Gmail, touch

Menu

Gmail

Gmail

.

.

➔ Settings

➔ ADD ACCOUNT

Apps

Apps

option.

➔

➔

Refreshing Your Gmail Account

DRAFT

FOR INTERNAL USE ONLY

Refresh your account to update messages on your phone.

Apps

1. From the Home screen, touch
Gmail

.

Refresh

2. Touch

.

➔

Managing Your Gmail Account

Use menu options to manage your Gmail.

Apps

1. From the Home screen, touch
Gmail

.

Menu

2. Touch

for options.

➔

Composing and Sending Gmail

1. From the Home screen, touch
Gmail

➔

New message

2. Touch fields and to compose the message. While

composing, touch

3. When your message is complete, touch

Menu

Apps

.

for options.

➔

Send

.

Google Talk

Google Talk is a free Windows and web-based application for
instant messaging offered by Google. Conversation logs are
automatically saved to a Chats area in your Gmail account.
This allows you to search a chat log and store them in your
Gmail accounts.

1. Log on to your Google account if you have not already

done so. For more information, refer to “Your Google™
Account” on page 17.

2. From the Home screen, touch

3. Begin using Google Talk.

4. Press ➔

Google Talk.

Note:

The Network confirms your login and processes. This
could take up to 5 minutes to complete.

Apps ➔

Help

for more information on using

Messaging 81

Tal k

.

Messenger

DRAFT

FOR INTERNAL USE ONLY

Messenger allows you to bring groups of friends together into
a simple group conversation. When you get a new
conversation in Messenger, Google+ sends an update to your
phone.

1. Sign on to your Google account. For more information,

refer to “Your Google™ Account” on page 17

Apps

2. From the Home screen, touch
Messenger

– or –
From the Google+ application, select

3. Select the account you want to use to sign in to

Google+.
– or –

Touch

4. At the

message.

5. In the upper text field, enter a name, email address, or

circle.

6. In the bottom message field, enter a message then

touch .

82

.

Create a new account
Messenger

screen, touch to start a new

to create another account.

➔

Messenger

.

7. From the

detailed information.

Messenger

screen, touch

Learn more

for more

Section 6: Applications and Widgets

DRAFT

FOR INTERNAL USE ONLY

This section contains a description of each application and
widget that is available in the Apps and Widget menus, the
function, and how to navigate through that particular
application or widget. If the application or widget is already
described in another section of this user manual, then a
cross reference to that particular section is provided.

This section contains a description of each application
available in the Apps menu and how to launch it. For
applications provided by Samsung, this section also
describes functions and navigation.

If an application is described in another section of this user
manual, a cross reference to that particular section is
provided.

Note:

This manual only addresses applications that have been
loaded on your device as of the date of purchase.
Information concerning third party applications that you
may choose to download from the Google Play Store or
other sources should be obtained from the application
provider directly and not from Samsung.

Tip:

To open applications quickly, add the icons of frequently­used applications to one of the Home screens. (For
details, see “Customizing the Home Screen” on page 38.)

You can also add an application icon as a Primary
Shortcut that will display on all Home screens. If you add
an application as a primary shortcut, the application icon
will not be displayed in the Apps menu. (For more
information, refer to “Editing the Primary Shortcuts” on
page 39.)

Accessing Applications

1. Press
Apps

2. Sweep your finger right or left to scroll the Apps

screens.

3. To launch an application, touch the application’s icon.

tab. The

Home

, then touch

Apps

screen appears in the display.

Applications and Widgets 83

Apps

, and the

Customizing the Applications Screens

DRAFT

FOR INTERNAL USE ONLY

Choosing a view

By default, application icons appear in Customizable grid
view. You can change the view to Alphabetical grid view or
Alphabetical list view.

Apps

1. From the

The available options are:

• Customizable grid

prefer.

• Alphabetical grid

alphabetical order.

• Alphabetical list

alphabetical order.

screen, touch Menu ➔ View type

: Arrange application icons in the order you

: Application icons automatically arranged in

: Application icons automatically listed in

Moving Application icons

With the
arrange the application icons to suit yourself.

1. From the
Edit

.

Note:

The

View type

2. Touch and hold an application icon, then drag it to a

new location.

3. When you are finished, then touch

84

Apps

screen in Customizable grid view, you can

Apps

screen, touch Menu

.

Edit

option is not available with the

set to

Alphabetical list

.

Save

, then touch

Apps

screen

.

Filtering Application icons

DRAFT

FOR INTERNAL USE ONLY

You can select which icons appear in the



From the

Apps

screen, touch Menu

either of the following options:

• Downloaded applications

have downloaded and installed on your phone.

• Hide applications

appear on the
marks appear in their check boxes), then touch

Apps

Apps

screen appears without the hidden applications.

: Shows only those applications you

: Mark those applications you do not want to

screen by touching their icons (check

Apps

screen.

, then touch

Done

. The

Applications List

AllShare Play

AllShare Play™ wirelessly synchronizes your Samsung
device with your TV, streams content, and even keeps tabs
on who calls or sends text messages with real-time,
on-screen monitoring. Samsung’s AllShare makes staying
connected easy.

Using AllShare Play you can share your in-device media
content with other external DLNA certified™ (Digital Living
Network Alliance) Devices.

Tip:

Wi-Fi capability can be provided to TVs via a digital
multimedia streamer.

AllShare Definitions:

AllShare

This uses the traditional DLNA
technology for sharing multimedia
(photos, videos, or music) to your
Samsung Smart TV and other DLNA
devices.

Applications and Widgets 85

AllShare Play

DRAFT

FOR INTERNAL USE ONLY

AllShare Play/Group
Cast

AllShare Cast

Hub accessory)

86

This new feature builds on the previous
AllShare feature. It includes features
such as Web storage integration and
social networking integration. This is a
Web service that requires using a
Samsung account.

A subset feature of AllShare Play, this
allows you to mirror photos and
multimedia presentations with other
members of your current Wi-Fi group.
Users must be on the same Wi-Fi and
provide an access code to join the
group.

(with

This feature functions with an external
Wi-Fi AllShareCast Hub connected to a
TV. It allows you to fully mirror what is
currently displayed on your device to the
external TV.

Important!

Important!

Before launching AllShare Play, first connect both
of your communicating devices to the same Wi-Fi
and be using an active/registered Samsung
account. For more information, refer to “Wi-Fi

Settings” on page 143 and to “Creating a Samsung
Account” on page 18.

The Samsung account manages your access
information (username/password) to several
applications, such as AllShare Play, ChatON, and
Savanna Store.

1. From the
The AllShare Play screen appears.

2. Tou ch
have not already done so. (For more information, refer
to “Creating a Samsung Account” on page 18.)

3. Tou ch

Apps

screen, touch

Sign in

to sign into your Samsung account, if you

Start

and follow the on-screen prompts.

AllShare Play

.

The application contains two separate streaming media

DRAFT

FOR INTERNAL USE ONLY

options:

•Registered storage

stored externally (server, laptop, etc.) directly on your device by
allowing you to add a Web storage service for streaming
content.

• Registered devices

multimedia content from your device to DLNA compliant device
connected to the same Wireless Access Point.

Configuring AllShare Settings

Before using AllShare Play, you must configure it. That is,
set-up parameters such as connected Wi-Fi, Items to share,
source server address, and external device acceptance
rights.

1. From the

2. Touch

are available:

•Registered storage

Without a storage service/location added, you will not be able
to use AllShare Play.

• My device

: allows you to receive and playback media

: allows you to stream/share selected

Apps

screen, touch

Menu

➔

Settings

. The following options

: Lets you add a Web storage location.

: Lets you rename your device.

AllShare Play

.

•Save to

• Auto upload

• Video optimization

•Password lock

•My account

•Customer support

• About

: Lets you save your media to Internal memory (your

phone) or an SD card.

: Lets you set-up automatic upload of images from
your device to those storage locations specified within the Web
storage list.

: Lets you optimize the video quality for

streamed video content.

: Lets you restrict access to AllShare Play by
requiring a user enter the currently active and associated
Samsung account password.

: Lets you view information concerning your

Samsung account.

: Lets you contact the AllShare team via a

new email from an available email account.

: Displays application information.

Applications and Widgets 87

Sharing Media Using AllShare Play to a Target Device

2

DRAFT

FOR INTERNAL USE ONLY

Important!

Make sure all communicating devices are
connected to the same Wi-Fi.

1. Launch AllShare on the target device (such as an

Internet TV, Samsung Tablet, etc.).

2. From the

3. From the

4. Touch an available category tab (

5. Touch an available on-screen file, image, or video to

6. Touch

7. On a target device (ex: Internet TV) select the on-

88

Apps

screen, touch

Devices

list, touch your device name.

Movies, Files

•

Touch and hold to select multiple files.

•

A file with in the upper-left indicates it is stored remotely
on a web storage location. Selecting this media causes your
device to access the file currently stored on your services’
servers.

place a green check mark alongside it.

streaming the selected files.

screen Allow button to continue.

, or

Info

) and select a file.

Stream to connected devices

AllShare Play

Pictures, Music

to begin

Note:

At this stage your device is requesting access to share
media with the external source.

8. Confirm

the Notification area at the top of the device to indicate
you are using your device as the media source.

.

,

AllShare Play Screen Sharing Using Group Cast

Important!

Verify all of your recipients are connected to the
same Wi-Fi.

1. From the

2. Touch a picture or video.

3. Touch ➔

4. If prompted, read the on-screen notification and touch
OK

to continue and return to the main AllShare Play

screen.

5. Enter a security PIN and touch
makes sure only desired recipients can view your
shared image.

AllShare Controller enabled

Apps

screen, touch

Group Play

Gallery

.

Done

. This process

appears in

.

6. Re-enter you PIN and touch

DRAFT

FOR INTERNAL USE ONLY

waits for other connected recipients to accept the
connection and enter the PIN on their screens.

– or –
Touch

Start Group Play anyway

while your users connect.

You can now interact and draw with the on-screen image,
users will instantaneously see the same gestures and also be
able to interact.

Note:

The newly altered image (with markups and comments)
can not be saved, but you can take a screen shot of the
current image and save it to your Clipboard. (For more
information, refer to “Motions” on page 25.)

Calculator

Use your phone’s Calculator to perform arithmetical
calculations (addition, subtraction, multiplication, and
division).

Apps

1. From the

2. Enter the first number using the on-screen numeric

keys.

screen, touch

Done

. The device then

to continue the process

Calculator

.

3. Enter the operation for your calculation by touching the

corresponding on-screen arithmetic function key.

4. Enter the second number.

5. To view the result, touch equals (

6. To view calculator history, touch

the top of the calculator buttons. A history of your past
calculations is displayed. Touch
display the calculator keypad.

7. To clear the calculator history, touch
Clear history

8. To change the text size, touch

Tap Small, Medium, or Large.

9. Touc h
the display so that it is easier to use the calculator with
one hand.
Touc h
it off.

10. To display the scientific calculator, rotate your phone to
the landscape (horizontal) position.

=

.

Menu

➔

One-handed operation on

Menu

➔

One-handed operation off

Applications and Widgets 89

).

Menu

located at

again to

Menu

➔

Tex t size

to set

to turn

➔

.

Calendar

DRAFT

FOR INTERNAL USE ONLY

Record events and appointments to manage your schedule.

Tip:

A Calendar widget is available in Widgets. (For more
information about placing widgets on the Home screen,
see “Widgets” on page 40.)

Apps

1. From the

2. Touch a tab to choose a calendar view:

•Year

•Month

• Week

•Day

•List

•Task

3. Touch Menu

•Go to

•Delete

•Search

90

screen, touch

: Display the current year and scroll to other years.

: Display the current month and scroll to other months.

: Display the current week, and scroll to other weeks.

: Display today’s schedule, and scroll to other days.

: Display events and tasks in a chronological list.

: Display tasks in a chronological list.

: Display a specific date.

: Delete an event.

: Search for calendar events.

for these options:

Calendar

.

•Sync

calendars. (For more information, refer to

Accounts”

• Settings

Customizing the Calendar

1. From the

2. Tou ch

settings:

•View settings

–

–

–
–
–

–

: Synchronize your phones calendar with your account

“Setting Up Your

on page 50.)

: Customize the calendar.

Apps

screen, touch

Menu

➔

Settings

:

View styles

Calendar view +pop-up).

Week view

events.

First day of week
Hide declined events
Lock time zone

a specified time zone, so that times and dates will not change if
you move to another time zone.

Select time zone

time zone for all events.

: Choose Month view style (Calendar view + list,

: Choose Timeline or Analog view for a week’s

: Choose a day to begin each week.

: Enable or disable display of events.

: When enabled, sets event times and dates to

: When Lock time zone is enabled, specify the

Calendar

.

to configure these

–

DRAFT

FOR INTERNAL USE ONLY

Show week number

in a

W

column to the left of

–

Calendars

• Event notification

–

Set alerts & notifications

Status bar notification to display notifications in the Status bar, or
Off for no notifications or alerts.

–

Select Ringtone

then touch

–

Vibration

–

Default reminder time

Calendar events (default time is 15 minutes).

–

Notifications while screen is off

notifications on the full screen while the screen is blanked.

–

Quick responses

notifications to meeting attendees, guests, and so on.

•Gesture

:

–

Swipe with two fingers

to change the Calendar view with a simple swipe with two
fingers.

: Display the number of the week (1 – 52)

Sun

.

: Select calendars to display.

:

: Choose Alert to receive alerts,

: Choose a ringtone for event notifications,

OK

.

: Enable/disable vibration for event notifications.

: Choose a default reminder time for

: Enable/disable display of

: Pre-composed text to include with email

: Show animation demonstrating how

Sending Events

Send events as vCalendar files to other compatible devices.

1. From the

2. Touch an event to display its details.

3. To uch

4. Select the desired Sharing method from the

5. Follow the prompts to send a copy of a Calendar event

Apps

screen, touch

Menu ➔ Share via

pop-up.

to another device. (For more information, refer to
“Connections” on page 128.)

Calendar

.

.

Share via

Applications and Widgets 91

Camera

Viewfinder

Camera

Viewer

Mode

Effects

Battery
Charge

Change
Mode

Quick Settings

Front

(Gallery)

Video

Record

Tak e

Facing
Camera

Displays Front
Facing Camera

DRAFT

FOR INTERNAL USE ONLY

Use your 8.0 megapixel Camera feature to take photos and
save them in JPEG format. Your phone also functions as a
camcorder to record videos and save them in MPEG format.



From the

Apps

screen, touch

Important!

Do not take photos of people without their
permission.
Do not take photos in places where cameras are
not allowed.
Do not take photos in places where you may
interfere with another person’s privacy.

92

Camera

Taking Pictures

Note:

When taking a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.

.

1. From the

2. Using the display as a viewfinder, compose your

3. To take the picture, touch

4. After taking a picture, touch

Apps

screen, touch

picture by aiming the lens at the subject.

•

Touch the screen to focus on the area you touched.

•

“Pinch” the screen, or press the

•

To configure settings, see

picture. While viewing the picture, use these options:

•

“Pinch” the screen, or touch the zoom icons, to zoom in or out,
or double-touch to zoom all the way in or out.

•

Touch
screen.

•

Touch
Picasa, S Memo, Bluetooth, Wi-Fi Direct, Messaging, Dropbox,
Google+, Email, or Gmail.

Camera

Share

“Camera Options”

to return to the Camera viewfinder

to send the picture using Group Cast,

Camera

Volume

key, to zoom in or out.

Tak e

.

Image Viewer

.

on page 93.

to view the

•

DRAFT

FOR INTERNAL USE ONLY

Touch
slideshow.

•

Touch
screen in landscape mode).

•

Touch
clipboard, Rotate left, Rotate right, Crop, Set as (Contact photo,
Home and lock screens, Home/Lock screen wallpaper), Buddy
photo share, Print, Rename, Scan for nearby devices, or
Details.

Camera Options



While in Camera mode, touch the

• Self portrait

portraits.

• Flash

• Shooting mode

from:

–
–

–

Slideshow

to view all of your pictures as a

Delete

to erase the picture (only visible with the

Menu

to access added options: Face tag, Copy to

Options

tab:

: Switch to the front camera lens, for self-

: Choose Off, On, or Auto flash.

: Choose an automatic shooting mode,

Single shot
Best photo

select and save the best.

Best face

best photograph based on open eyes, smiles, sudden
movement, and so on.

: Take a single photo.

: Takes 8 photos in quick succession, then you

: Takes 5 photos in quick succession and selects the

–

Face detection

a picture of the subject’s face.

–

Panorama

and then adding additional images to itself. The guide box lets
you view the area where the second part of the panoramic
picture should fall within.

–

Share shot

with your friends.

–

HDR

increase image detail.

–

Buddy photo share

your contacts to send your friends or family pictures of
themselves.

–

Beauty

effect.

–

Smile shot

face. If a smile is detected, the picture is taken automatically.

–

Low light

: Touch the Camera button to focus on and take

: Takes a landscape photo by taking an initial photo

: Uses Wi-Fi Direct to share your pictures quickly

: Takes pictures in HDR (High Dynamic Range) mode to

: Uses face recognition from pictures in

: Adjust the contrast to create a smooth facial feature

: Touch the Camera button to focus on the subject’s

: Take better pictures when the light is low.

Applications and Widgets 93

• Color effects

DRAFT

FOR INTERNAL USE ONLY

effect (normal color), Cold vintage, Warm vintage, Posterize,
Solarize, Green point, Blue point, or Red-yellow point, Washed
out, Cartoonify, Black and white, Sepia, or Negative.

• Settings

–

Edit shortcuts

function menu.

–

Burst shot

pictures to create a panorama.

–

GPS Tag

–

Self-portrait

yourself.

–

Flash

–

Shooting mode

detection, Panorama, Share shot, HDR, Buddy photo share,
Beauty, Smile shot, Low light, or Cartoon.

–

Effects

–

Scene mode

–

Exposure value

the slider.

–

Focus mode

94

: Choose color theme for the picture: No

:

: Select which function shortcuts appear in the

: Detects action to automatically take multiple

: Add GPS location information to photo details.

: Set the front camera so you can take pictures of

: Choose Off, On, or Auto flash.

: Choose Single shot, Burst shot, Face

: Apply a color effect to pictures.

: Choose a mode to match conditions.

: Adjust the picture brightness level by moving

: Choose a type of automatic focus.

–

Timer

–

Resolution

–

White balance

–

ISO

: Choose a setting for imaging sensitivity.

–

Metering

–

Auto contrast

–

Guidelines

composition.

–

Auto share shot

share pictures with, then bring the devices back together (back­to-back) to connect them.

–

Anti-Shake

camera movement.

–

Contextual filename

the filename based on contextual information, such as your
current GPS location.

–

Image quality

–

Storage

an optional Memory card.

–

Reset

: Set a delay before taking a picture.

: Choose a size (in pixels) for the image.

: Choose a setting for the light source.

: Select a method for measuring light.

: Allow automatic light/dark adjustment.

: Enable or disable an on-screen grid to aid in photo

: Easily connect to the devices you want to

: Enable Anti-Shake to minimize the effect of

(requires GPS tagging): Lets you adjust

: Choose a quality setting for photos.

: Choose to store your pictures in Phone memory or on

: Set all Camera settings to the defaults.
