Page 1

SCH-E159 User’s Guide

Page 2

Important

safety

precautions

Failure to comply with the following precautions may be dangerous or illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.

Switch off the phone near all medical equipment

Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.

Page 3

Interference

All wireless phones may be subject to interference, which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.

Emergency calls

Key in the emergency number for your present location, then press

[]

Keep your phone away from small children

Keep the phone and all its parts, including accessories, out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.

• The phone could explode if the battery is replaced with an incorrect type.

• Dispose of the used batteries according to the manufacturer’s instructions.

Use of authorised software

Use only Samsung-authoriesed software. The use of any unauthoriesed software could damage your phone.

Qualified service

Only qualified service personnel may repair your phone.

For more detailed safety information, see "Health and safety information" on page 81.

Important safety precautions

Page 4

About this Guide

This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Getting started” and “Step outside the phone”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.



[ ] Indicates a key on the phone. For example,

< > Indicates a soft key, whose function is

Indicates that you can get more information on the referenced page.

→

Indicates that you need to press the Navigation keys to scroll to the specified option and then select it.

[]

displayed on the phone screen. For example,

• Camera and camcorder

Special

•Web browser

•Media player

Use the camera module on your phone to take a photo or record a video.

features of your phone

Access the wireless web to get upto-the-minute information and a wide variety of media content.

Play media files using your phone.

Page 5

• Get personal with photo caller ID

See who’s calling you by her or his very own photo.

• Remote controller

Control TVs or DVD players remotely with your phone.

Special features of your phone

•Name card

Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient name card.

•E-mail

Send and receive e-mails with images, sounds, name cards, and applications.

• Melody composer

Make your own melodies for your phone.

•Memory disk

Connect your phone to a computer to copy files directly to and from it.

• Organiser

Keep track of your daily, weekly, and monthly schedule.

• Voice recorder

Record voice memos or sounds.

Page 6

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ..................................... 7

Power on or off........................................................ 8

Keys and displays .................................................... 9

Access menu functions ............................................ 11

Customise your phone............................................. 13

Make/Answer calls .................................................. 14

Step outside the phone 15

Begin with your camera, music, web, and other special features

Use the camera ...................................................... 15

Play MP3 ............................................................... 16

Use melody composer ............................................. 17

Browse the web...................................................... 18

Use Phonebook ...................................................... 19

Send/View messages .............................................. 20

Use My Menu ......................................................... 21

Enter text 22

ABC, T9 Word, 123, and Symbol mode

Call functions 24

Advanced calling features

Menu functions 27

All menu options listed

Solve problems 78

Help and personal needs

Health and safety information 80

Page 7

Overview of menu functions

To access Menu mode, press <

1 Calls

1 Missed 2 Dialled 3 Received 4 Air time 5 Call forwarding 6 Call waiting 7 Call reject

2 Phonebook

1 Find 2 Add entry 3 Groups 4 Speed dial 5 Name card 6 My phone # 7 Memory status

3 Camera

1 Take photo 2 My album 3 Photo studio 4 Settings

> in Idle mode.



p.27

      



      



   

4 Display

p.27

1 Language

p.28

2 Image box

p.28

3 Banner

p.28

4 Menu style

p.29

5 Backlight

p.29

6 Set time

p.30

7 External clock 8 Dialing font

p.30

9 Quick menu indicator

p.30

5 Messages

p.31 p.32

1 Picture msg.

p.33

2 Text msg.

p.33

6 Sounds

p.34 p.34

1 Ring tones 2 Call volume

p.34

3 Msg. volume

p.34

4 Alarm volume

p.38

5 Schedule volume

p.40

6 Key tone

p.43

7 Alert



p.44

7 do mOre

p.44 p.44

p.44 p.44 p.44 p.45 p.45 p.45 p.46

p.46

p.46 p.49

p.53

p.53 p.53 p.53 p.54 p.54 p.54 p.54

1 3D game 2 MP3 3 VOD 4 Melody composer 5 TATA Zon e 6 Mobile Browser

8 Organiser

1 Today 2 Scheduler 3 Alarm clock 4 User memory 5 I.Beam 6 Voice memo 7 Task list 8 Calculator 9 World time 0 Countdown

Memo pad

 

      



 



      



p.55

9 Settings



p.55 p.56 p.58 p.60 p.62 p.63

p.65

p.65 p.65 p.66 p.67 p.68 p.71 p.72 p.72 p.72 p.73 p.73

1 Auto answer 2 Answer mode 3 Auto redial 4 Security 5 Entry method 6 Domains preset 7 Contents status 8 Rotation mode 9 Airplane mode

    



          



p.74



p.74



p.75



p.75



p.75



p.78



p.78



p.78



p.78



p.78

Page 8

Unpack

Make sure you have each item

Phone

Battery

You can obtain various accessories from your local Samsung dealer.

The items supplied with your phone and the accessories available at your Samsung dealer may vary, depending on your country or service provider.

Travel Adapter

User’s Guide

Your p ho ne

Buttons, features, and locations

Display

Navigation keys (Up/Down/Left/

Right)

Headset jack

Left soft key

Dial key

Volume ke ys

Alphanumeric

keys

Special

function keys

Earpiece

Web access key

Right soft key Power on/off/

Menu exit key

Cancel/ Correct key

Microphone

Infrared port Camera

lens

Camera/Voice memo key

MP3 key External

display

Page 9

Get started

First steps to operating your phone

UIM card information

When you subscribe to a cellular network, you receive a plug-in UIM (User Identification Module) card loaded with your subscription details, such as your PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the

phone is already on, first turn it off by holding [ ].

Insert the UIM card.

Make sure that the gold-coloured contacts on the card face down into the phone.

Install the battery.

Plug the travel adapter into the phone

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged (the

battery icon becomes still), unplug the adapter from the power outlet.

Page 10

Get started

Remove the adapter from the phone.

Power on or off

Power on

Do not turn on the phone when mobile phone use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

3. If necessary, enter the PIN and

the phone.

press <OK>.

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone automatically turns off. Recharge your battery.

Power off

1. Open the phone.

2. Press and hold [ ].

Page 11

Keys and displays

Keys

Perform the function indicated on the bottom line of the display.

In Idle mode, access the following menus directly.

• Up: My Menu Item

•Down:

•Left:

•Right: In Menu mode, scroll through menu options.

In Idle mode, access the menu.

Send or answer a call. In Idle mode, retrieve the recent

numbers dialled, missed, or received.

I.Beam

VOD

messages

TATA Zone

Delete characters from the display. In Menu mode, return to the previous

menu level.

End a call. Press and hold to switch the phone on

and off. In Menu mode, cancel input and return

the phone to Idle mode.

Enter numbers, letters, and some special characters.

In Idle mode, press and hold [0] to launch the web browser.

Enter special characters. In Idle mode, press and hold [] to

activate or deactivate Silent mode.

Get started

Page 12

Get started

Adjust the volume. In Idle mode, with the phone open,

adjust the keypad tone volume. With the phone closed, turn on the external display.

In Idle mode, access the

Camera

or turn on the camera when held down. In Camera mode, take a photo or start

recording a video. During a call, record your conversation

when held down.

In Idle mode, access the

MP3

menu. Play music files in the play list when held down.

During a call, activate or deactivate the noise cancellation feature.

Display

Layout

Icons

The display has three areas.

Icons

display various icon.

Text and graphics

display messages, instructions, and information you enter.

Menu Find

Received signal strength

Roaming

Call in progress

Out of your service area; you cannot send or receive calls

Restriction on

Lock mode

Soft key function indicators

show the current functions assigned to the two soft keys.

Page 13

Icons

(continued)

New e-mail in server

New e-mail in Inbox

Urgent SMS message

New SMS message

New voicemail

New web alert

Alarm set



Ringer type setting

•: Ringer only

•: Silent

• : 1 Beep

•: Vibration

•: Vib. & ringer

• : Vib. then ringer

• : Ringer then vib.

Silent mode

Battery power level



p. 53

p. 13

Access menu functions

Use the soft keys

The roles of the soft keys vary depending on the function you select. The bottom line of the display indicates their current role.

Menu Find

Press the left soft key to access Menu mode.

Press the right soft key to access

Find

Get started

Page 14

Get started

Select an option

1. Press the appropriate soft key.

2. Press the Navigation keys to move to the next or previous option.

3. Press <

4. To exit, choose either of the

Select

Save

function displayed or option highlighted.

following methods:

• Press [

level.

• Press [ ] to return to Idle

mode.

>, <OK>, or

> to confirm the

CLR

] to move up one

Use shortcuts

Use My Menu

Press the number key corresponding to the option you want.

You can set up a menu of your own using your favourite menu items, which can then be accessed by specific number keys. Once you have set up your favourites, you can easily and quickly access them.p. 21

Page 15

Customise your phone

Display language

Call ringer melody

1. In Idle mode, press < and select

Language

2. Select a language.

1. In Idle mode, press < and select

tones

2. Press [Down] and press [Left] or [Right] to scroll to a ringer category.

3. Press [Up] or [Down] to scroll to a ringer melody.

4. Press < melody.

5. When you find the melody you want, press <

Display →

Sounds → Ring

Play

> to listen to a

Save

Wallpaper for Idle mode

Menu style

Silent mode

You can set wallpaper for the idle screen using various pictures.

1. In Idle mode, press < and select

box → Wallpaper

2. Select an image category.

3. Select an image.

You can change the display style of the main menu screen.

1. In Idle mode, press < and select

style

2. Select the style you want.

You can switch the phone to Silent mode to avoid disturbing other people.

Press and hold [ ] in Idle mode.

Display → Image

Display →

Menu Menu

Get started

Page 16

Get started

Phone lock

You can protect the phone against unauthorised use with a phone password. The phone will require the password on power-up.

1. In Idle mode, press < and select

Security

2. Enter the default password,

00000000

3. Select

4. Enter a new 4- to 8-digit password and press <OK>.

5. Enter the new password again and press <OK>.

6. Select

7. Select On or

Settings →

, and press <OK>.

Change code

Lock mode

Once

Make/Answer calls

Make a call

Answer a call

Adjust the volume during a call

1. Enter an area code and phone number.

2. Press [ ].

3. To end the call, press [ ].

1. When the phone is ringing, open the phone or press [ ].

2. To end the call, press [ ] or close the phone.

Press [ / ].

Page 17

Step outside the phone

Begin with your camera, music, web, and other special features

Use the camera

Take a photo

1. In Idle mode, press and hold [ ] to turn on the camera.

Alternatively, rotate the display to view a wide image.

View a photo

3. Press the right soft key or [ ] to take a photo.

4. Press <

1. In Idle mode, press [ ] and

2. Press [Up] or [Down] to scroll

3. Press <

Save

select

My album

to a photo.

Expand

2. Adjust the image by rotating the camera lens and aiming it at the subject.

Record a video

1. In Idle mode, press and hold [ ] to turn on the camera.

2. Press <

3. Press < > to start recording.

4. Press < > to stop recording.

5. Press <

Video cam

Save

> and select

Page 18

Step outside the phone

Play a video

1. In Idle mode, press [ ] and select

My album

2. Press [Left] or [Right] to select

Vcam

3. Press [Up] or [Down] to scroll to a video clip.

4. Press <

Select

Play MP3

Copy MP3 files to the phone

Create the play list

Use these methods:

• Download from the wireless web.p. 63

• Copy directly from a computer.



p. 67

1. In Idle mode, press [ select

My files

2. Press <

3. Press <

4. Press <

5. Press <

to play list

Check

Add

Play

> to play music.

MP3

> and select

> to select files.

] and

Add

Page 19

Play MP3 music

1. In Idle mode, press and hold [

MP3

2. During playback, use the following keys:

• [ ]: pauses or resumes

playback.

• [Up]: changes the repeat

mode.

• [Down]: accesses the play

list.

• [Left]: moves back to the

previous file. Moves backward in a file when held down.

• [Right]: skips to the next

file. Moves forward in a file when held down.

• [ / ]: adjust the volume.

•<

list.

•<

A-B

file to play the section repeatedly.

Use melody composer

Create a melody

1. In Idle mode, press < and select

composer → Compose melody

2. Move the selection point up or down.

3. Press <

4. Select a note or rest.

>: opens the options

>: sets a section in a

do mOre → Melody

Input

Menu>

Step outside the phone

Page 20

Step outside the phone

Create a melody

(continued)

Play a melody

5. Repeat steps 2 to 4 to add more notes and rests.

6. Press <

7. Enter a melody name and press

1. In Idle mode, press <Menu

2. Scroll to the melody you want

Option

Save

<OK>.

and select do mOre → Melody

composer → My melodies

and press <

> and select

Play

Browse the web

Using a built-in web browser, you can get easy access to the wireless web to get a variety of up-to-date services and information and to enjoy downloads of web content.

Launch the web browser

Navigate the web

1. In Idle mode, press

• To scroll through browser items, press the Navigation keys.

• To select an item, press

• To return to the previous page, press [

CLR

• To return to the homepage, press and hold [

• To use browser options, press <

> and select

CLR

[]

Page 21

Use Phonebook

Add an entry

To the phone’s memory:

1. In Idle mode, enter a phone

2. Enter a name and press <OK>.

3. Press [Right] and select a

4. Specify entry information:

5. Press <Save> to save the

number and press <

number type.

Mobile, Home, Office, Pager, Fax, Image, E-Mail1, E-Mail2, URL, Group, Ringer, and ETC.

entry.

Save

Find an entry

To th e U I M ca r d :

1. In Idle mode, enter a phone number and press <

2. Enter a name and press <OK>.

3. Press <Save> to save the entry.

1. In Idle mode, press <

2. Select an entry.

3. Scroll to a number and press [] to dial, or < entry information.

Save

Find

> to edit

Step outside the phone

Page 22

Step outside the phone

Create and send a name card

1. In Idle mode, press < and select

Name card → card.vcf

2. Press <

Edit

3. Specify your entry information.

4. Press < name card.

Option

Save

Phonebook →

> to save the

My name

> and select

Send/View messages

Send a text message

1. In Idle mode, press < and select

msg. → Write

2. Enter the message text and press <OK>.

3. Press <

4. Enter destination numbers.

5. Press <OK> to send the message.

Messages → Text

Save

View a text message

When a notification appears:

Press <

Select

displays.

>. The message

Page 23

Access voice mails

From the Inbox:

1. In Idle mode, press < and select

msg. → Inbox

2. Select

3. Select a message.

When a notification appears:

1. Press [ ]. The phone access the voicemail center.

2. Follow the instructions from the system.

From the Inbox:

1. In Idle mode, press < and select

msg. → Voice mail

2. Follow the instructions from the system.

Messages → Text

Phone

Messages → Text

Card

Use My Menu

Set up My Menu item access

Access My Menu item

1. In Idle mode, press and hold <

2. Scroll to a location and press <

3. Select

4. Scroll to the menu you want

5. Scroll to an icon for the item

1. In Idle mode, press and hold

2. Select the item you want.

and press <

Regist

Save

Step outside the phone

Page 24

Enter text

ABC, T9 Word, 123, and Symbol mode

You can enter text for some features such as messaging, Phonebook, or Organiser, using ABC mode, T9 Word mode, 123 mode, and Symbol mode.

Changing the text input mode

Example

1. In the text entry screen, press <

2. Select the mode you want.

: Writing a text message

Tex t i n p ut

mode indicator

Mode

Using ABC mode

Press the appropriate key until the character you want appears on the screen.

Key

. @ - _ / : ~ ? , 1 ; ’ ( ) ! % & < > + = “ \ { } $ [ ]

A B C 2 a b c 2

D E F 3 d e f 3

G H I 4 g h i 4

J K L 5 j k l 5

M N O 6 m n o 6

P Q R S 7 p q r s 7

T U V 8 t u v 8

W X Y Z 9 w x y z 9

Characters in order displayed

Upper case Lower case

Page 25

Tips for using ABC mode

• To enter the same letter twice or to enter a different letter on the same key, wait for the cursor to move to the right automatically or press [Right]. Then, enter the next letter.

• Press [ ] to insert a space.

• Press [ ] to change case. Initial capital ( Lower case ( available.

• Press the Navigation keys to move the cursor.

•Press [ and hold [ side of the cursor.

abc

), and Capital lock (

CLR

] to delete characters one by one. Press

CLR

] to clear the characters on the left

ABC

Abc

) are

Using T9 Word mode

T9 is a predictive text input mode that allows you to key in any character using single keystrokes.

Entering a word in T9 Word mode

1. Press [2] to [9] to start entering a word. Press each key once for each letter.

Example

enter Hello. T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting the characters.

3. When the word displays correctly, go to step 4. Otherwise, press [0] to display alternative word choices for the keys that you have pressed.

For example, Of and Me use [6] and [3].

4. Press [ ] to insert a space and enter the next word.

: Press [4], [3], [5], [5], and [6] to

Tips for using T9 Word mode

• Press [1] to enter periods or apostrophes automatically.

• Press [ ] to change case. Initial capital (

Word

), Lower case (

(

T9 WORD

• Press the Navigation keys to move the cursor.

) are available.

T9 word

), and Capital lock

Enter text

Page 26

•Press [

CLR

and hold [ side of the cursor.

] to delete characters one by one. Press

CLR

] to clear the characters on the left

Using 123 mode

123 mode enables you to enter numbers. Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to enter symbols.

1. Press [Left] or [Right] to display more symbol sets.

2. Press the keys corresponding to the symbol you want.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone number.

2. Press [ ].

• Press [ hold [

• Press < numbers.

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of recent numbers.

2. Scroll to the number you want and press [ ].

Making a call from Phonebook

Once you have stored a number in Phonebook, you can dial the number by selecting it from Phonebook.p. 30

CLR

] to clear the last digit or press and

CLR

] to clear the whole display.

Pause

> to enter a pause between

Page 27

You can also use the speed dial feature to assign number keys to your most frequently called numbers.



p. 33

Ending a call

Close the phone, or press [ ].

Answering a call

When you receive an incoming call, the phone rings and displays the incoming call image.

Press [ ] to answer the call.

Tips for answering a call

• Depending on the setting in the menu, you can press any key, except for the soft keys, [ / ], and [ ], or just open the phone to answer a call.p. 75

•Press <

Reject

to reject a call.

Silent

> or [ ], or press and hold [ / ]

> or [ / ] to mute the ringer.

Answer mode

Viewing missed calls

If you have missed calls, the screen displays the number of the calls and the phone number of the last call.

Press [ ] to dial the displayed number.

Press the right soft key to access the missed call log list.

Using the headset

Use the headset to make or answer calls without holding the phone.

Connect the headset to the jack on the left side of the phone.

The button on the headset works as listed below:

To Press

redial the last call the button twice.

answer a call and hold the button.

end a call and hold the button.

Call functions

Page 28

Call functions

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to decrease the volume level.

Answering a second call

If you have subscribed to the call waiting service, you can answer another call during a call.

1. Press [ ] to answer a second call. The first caller is placed on hold and you are connected with the second caller.

2. Press [ ] again to switch between the calls.

Making a three-way call

If you have activated three-way calling service, you can have a conversation with two people simultaneously.

1. During a call, press [ ] and make another call. The first caller is placed on hold.

2. Press [ ] to begin the three-way call.

Recording your call conversation

You can record your conversation during a call. Press and hold [ ] to start recording.p. 71

Using In-call options

During a call, press < options:

•

Private loud speaker

feature or switch back to Normal mode.

•

Voice mute

that the other person on the phone cannot hear you.

•

Key mute

•

Voice memo

menu.p. 71

> to access the following

: turn on the speakerphone

: switch off the phone's microphone so

: switch the key tones off.

: access the

Voice memo

Page 29

•

Noise cancellation

cancellation feature, which removes noise from your surroundings so that the other person on the phone can hear you more clearly.

•

Calls

: access the

•

Phonebook:



p. 30

•

Text msg.

: access the

: activate the noise

Calls

menu.p. 27

access the

Phonebook

Text msg.

menu.

menu.p. 49

Menu functions

All menu options listed

Calls

(Menu 1)

Use the

Calls

duration of calls, and set options for call functions.

To access this menu, press < select

Missed

This menu displays the most recently received calls that you did not answer.

Accessing a call record

1. Select a call.

2. Press [ ] to dial the number or < access options.

menu to access call logs, view the

Calls

(Menu 1.1)

> in Idle mode and

> to

Page 30

Menu functions

Using call record options

While viewing call details, press < the following options:

•

Talk

: dial the currently selected number.

•

View phonebook

information.

•

Save

: save the number to Phonebook.

•

Edit

: edit the number to dial or save it.

•

Erase

: erase the call record.

•

Send msg.

number.

•

Send MMS

selected number.

While viewing the list of calls, press < access the following options:

•

Erase

: erase the call record.

•

Erase all

: erase all call records.

: display the saved Phonebook

: send a message to the selected

: send a picture message to the

> to access

> to

Dialled

This menu displays the most recent calls you have dialled.

Received

This menu displays the most recent calls you have received.

Air time

This menu displays the time log for voice calls you have made or received. You can also check the time log for data calls. Actual time invoiced by your service provider will vary.

•

(Menu 1.2)

(Menu 1.3)

(Menu 1.4)

This feature is not intended to be used for billing purposes.

Last call

data call.

Total

data calls and the total duration of the calls.

: display the air time of the last voice or

: display the number of all voice calls and

Page 31

•

Erase total

reset the air time counter.

•

Life time

of all calls since the phone was shipped from the factory.

Call forwarding

This network service allows incoming calls to be forwarded to another number.

Contact your service provider to check this service’s availability.

: erase the air time measurement and

: display the number and total duration

(Menu 1.5)

Settings the call forwarding feature

1. Select a type of call forwarding.

•

Immediate

when they are received.

•

When busy

busy.

•

No reply/Not reachable

if you don’t answer or when your phone is switched off.

: calls are forwarded immediately

: calls are forwarded if your line is

: calls are forwarded

•

Disable all

cancelled.

2. Select

3. Select

: all of the call forward settings are

To enable Voice mail

Other number

Changing the call forwarding code

1. Select a type of call forwarding.

2. Select

3. Select

4. Select

5. Press and hold [

6. Enter the code number you want and press

Call waiting

This network feature alerts you of incoming calls while you are on the phone.

Edit feature code To enable Voice mail

Save

To disable

Other number

CLR

] to clear the default code.

(Menu 1.6)

Setting the call waiting feature

1. On the Call waiting screen, scroll to

2. Press <

Select

To enable

Menu functions

Calls

(Menu 1)

Page 32

Menu functions

Changing the call waiting code

1. On the Call waiting screen, select

code

2. Select

3. Press and hold [

4. Enter the code number you want and press

Call reject

Use this menu to make a list of the phone numbers from which you want to reject calls.

Save

To enable

(Menu 1.7)

To disable

CLR

] to clear the default code.

Edit feature

Phonebook

You can store phone numbers and their corresponding names in your card and the phone’s memory. The card and phone’s memory, although physically separate, are used as if they were a single entity, called Phonebook.

To access this menu, press < select

Phonebook

Find

(Menu 2.1)

Use this menu to find an entry using a person’s name, speed dial location, group name, or memory location.

To quickly access this menu, press < mode.

(Menu 2)

> in Idle mode and

Find

> in Idle

Finding an entry

1. Press [Left] or [Right] to select a search method.

2. Enter the first few letters of the name you want, or select a memory location or a caller group.

3. Select an entry.

Page 33

4. Scroll to a number and press [ ] to dial, or press <

> to edit entry information.

Using Phonebook options

While viewing entry details, press < the following options:

•

Send msg

•

Send MMS

•

Talk

•

Copy

memory location.

•

Speed dial

to the currently selected number.

•

Edit

•

Erase

only the number is erased.

While viewing the Phonebook list, press < access the following options:

•

Edit

•

Erase

: send a text message.

: send a MMS message.

: dial the selected number

: copy the selected number to another

: assign a speed-dial location number

: change the selected item.

: erase the entry. If you select a number,

: edit entry information.

: erase the entry.

> to access

> to

•

Erase multiple

entries.

•

Add new

or on the card.

•

To name card

name card format.

Add entry

Use this menu to add a new entry to Phonebook.

In the phone’s memory, a name can contain up to 5 numbers in a different category; Mobile, Home, Office, Pager, and Fax. You can save only one number with a name on the card’s memory.

: erase the selected entries or all

: add a new entry to the phone’s memory

: save the selected number as a

(Menu 2.2)

Storing a number in the phone’s memory

1. Enter a name and press <OK>.

2. Select

3. Press [Down] and change the settings or enter

Phone

information about the entry:

•

Mobile/Home/Office/Pager/Fax

number for each category.

: add a

Menu functions

Phonebook

(Menu 2)

Page 34

Menu functions

•


: press < photos you have taken or the default icons as a caller ID image.

•

E-Mail1/E-Mail2

e-mail address.

•

URL

: press <

•

Group

: select one of the default relation

groups, where the entry is included.

•

Ringer

: press < the entry.

•

ETC

: press <

entry.

4. Press <

Save

Storing a number on the UIM card

1. Enter a name and press <OK>.

2. Press [Down] and enter a phone number.

3. Press <

Save

Edit

> and assign one of the

: press <

Edit

> and enter an URL address.

Edit

> and add a memo about the

> to save the entry.

Edit

> and select a ringtone for

> and enter an

Groups

Use this menu to set up a caller group list.

Adding a new group

1. When

2. Enter a name for the group and press <OK>.

3. Press [Down].

4. Press [Left] or [Right] to select a ringer category.

5. Press [Up] or [Down] to scroll to a ringer.

6. Press <

(Menu 2.3)

No group

To listen to the selected melody, press <

Save

highlights, press <

Add

Play

Managing a group

Press <

> to access the following options:

•

New

: add a new group.

•

Edit

: change the properties of the selected group.

•

Erase

: erase the selected group.

Page 35

Speed dial

Once you have stored phone numbers in Phonebook, you can set up to 95 (5~99) speed dial entries and then dial them easily by pressing the associated one or two number keys.

Numeber keys 1 to 4 are preset by your service provider to access the following services:

• [1]: Voicemail

• [2]: Voice station

• [3]: Customer care

• [4]: Directory assistance

(Menu 2.4)

Setting up speed dial entries

1. Press [Left] or [Right] to select

2. Enter the location number you want or scroll to the number.

Entering a number lists all of the location numbers containing the entered number.

3. Press <

4. Select a phone number from the Phonebook list.

Add

All

Empty

5. Select a number from the entry, if it has more than one number.

Editing speed dial entries

1. Press [Left] or [Right] to select

2. Enter the location number you want or scroll to the number.

3. Press <

•

Replace number

to the location.

•

Erase

: clear the speed dial setting for the

location.

•

Erase all

> to access the following options:

: assign a different number

: clear the settings for all keys.

All

Stored

Dialling speed dial entries

Press and hold the appropriate number key in Idle mode.

Name card

Use this menu to view and edit your name card.

1. Select

(Menu 2.5)

My name card.vcf.

Menu functions

Phonebook

(Menu 2)

Page 36

Menu functions

2. Press <

3. If necessary, press <

4. Press <

After saving the name card, press < access the following options:

•

My phone #

Use this menu to view and change your phone number.

To change the phone number, press < your phone number.

Memory status

Use this menu to check how many entries are stored in Phonebook, in both the card and the phone’s memory.

Option

> and select

contents of the name card.

Save

Edit

: edit the name card.

Add to phonebook

Phonebook entry.

Erase

: clear the name card.

(Menu 2.6)

Edit

> to save the name card.

: save the name card as a

(Menu 2.7)

Edit

> and change the

Option

> to

Edit

> and enter

Camera

Using the camera module built into your phone, you can take photos of people or events while on the move. You can also record a video by using your phone as a camcorder.

To access this menu, press < select

Take photo

Use this menu to take a photo in a still image or multi-shot or record a video. The camera produces JPEG photos and MP4 video clips.

(Menu 3)

Camera

• Do not take photos of people without their permission.

• Do not take photos in a place where cameras are not allowed.

• Do not take photos in a place where you may interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright conditions, shadows may appear on the photo.

, or press [ ] in Idle mode.

(Menu 3.1)

> in Idle mode and

Page 37

Taking a photo

1. Access the

Take photo

menu or press and hold [ ] in Idle mode. You can also rotate the display to view a wider image.

The camera turns on and the image to be captured displays.

2. When you use the camera first time, press [2] to change the preview screen until the icon appears.

3. Press [1] and select the camera mode you want:

• Single shot: take a photo.

• Serial shot: take a serial of action stills.

• Divided shot: take several stills and saves them

in one frame.

• Video cam: record a video.

• Picture msg.: take a photo for adding to a

picture message.

• Video msg.: record a video for adding to a

video mssage.

4. Adjust the image by rotating the camera lens and aiming it at the subject.

• You can use the following keys to customise the

image settings.

Key Function

Flips the image vertically.

Shows the mirror image.

Left/Right Zooms in or out.

Up/Down Adjusts the image brightness.

Changes the camera mode.

Switches the display between the full screen view, non-icon view, grid line view, and actual ratio view.

Sets the time delay.

Goes to the

My album

folder.

Menu functions

Camera

(Menu 3)

Page 38

Menu functions

• You can change settings by pressing <



next section

5. Press <

6. Press <

Using options in Capture mode

When you press < following options are available for the current shot:

•

Capture

When you are taking serial shot images, the camera takes photos successively.

Save

The phone saves the photo(s) in the folder and returns to Capture mode.

Mode

: use the following camera modes:

Single shot Serial shot

select the number of photos the camera will take.

Divided shot

one frame. You can select the layout.

Video cam

> or [ ] to take a photo.

> to save the photo.

My album

> in Capture mode, the

: take a photo in normal mode.

: take series of action stills. You can

: take several stills and save them in

: record a video clip.

Picture msg.

message.

Video msg.

mssage.

•

Size/Quality

quality.

•

White balance

photo. You can make your photo appear warmer or cooler.

•

Self timer

takes a photo.

•

Frame

•

Preview layout Icons

full screen with available option icons.

No icons

full screen without icons.

Guideline

the grid line.

•

Quick view

: take a photo for adding to a picture

: record a video for adding to a video

: select an image size or an image

: adjust the colour balance of the

: set a time delay before the phone

: add a decorative frame to the photo.

: select the default preview mode.

( ): the phone shows the image on the

( ): the phone shows the image in

: access the

My album

folder.

Page 39

Recording a video

1. Access the

2. Press [1] to select the icon.

3. Adjust the image by rotating the camera lens and aiming it at the subject.

• You can use the following keys to customise the

Take photo

image settings.

Key Function

Up/Down Adjusts the image brightness.

Left/Right Zooms in or out.

menu.

Flips the image vertically.

Shows the mirror image.

Changes the camera mode.

Switches the display between the full screen view, non-icon view, grid line view, and actual ratio view.

Key Function

• You can change settings by pressing <



next section

4. Press < > or [ ] to start recording. To pause recording, press < > and then press

<> to resume.

5. When you are finished, press < > or [ ].

6. Press < The phone saves the video in the

and returns to Record mode.

Using options in Record mode

When you press < following options are available for the current shot:

•

Mode

: use the following camera modes:

Single shot

Sets the time delay.

Goes to the

Save

> to save the video.

: take a photo in normal mode.

My album

> in Record mode, the

folder.

My album

folder

Menu functions

Camera

(Menu 3)

Page 40

Menu functions

Serial shot

select the number of photos the camera will take.

Divided shot

one frame. You can select the layout.

Video cam

Picture msg.

message.

Video msg.

mssage.

•

Size/Quality

quality.

•

White balance

video. You can make your video appear warmer or cooler.

•

Self timer

records a video.

•

Preview layout Icons

full screen with available option icons.

: take series of action stills. You can

: take several stills and save them in

: record a video clip.

: take a photo for adding to a picture

: record a video for adding to a video

: select an image size or an image

: adjust the colour balance of the

: set a time delay before the phone

: select the default preview mode.

( ): the phone shows the image on the

No icons

full screen without icons.

Guideline

the grid line.

•

Voice record

•

Quick view

My album

Use this menu to review the photos you have taken and the videos you have recorded.

( ): the phone shows the image on the

( ): the phone shows the image in

: turn on or off the audio.

: access the

(Menu 3.2)

Photos captured on other devices, such as digital cameras, may not display correctly.

My album

folder.

Viewing a photo

1. Select

2. Scroll to the photo you want.

3. Press <

4. Press <

screen.

Single

Multi

Expand

> to view the photo on the full

Multi

> to return to the thumbnail images.

Page 41

Using photo options

While viewing a photo, press <

Option

> to access the

following options:

•

Send picture msg.:

send the file as part of a

picture message.

•

Photo studio

•

Set wallpaper

: access the

Photo studio

: set the image as your wallpaper for the idle screen, or the opening or closing image.

•

Set phonebook

: set the image as a caller ID

image for a Phonebook entry.

•

Rename

: change the file name.

Do not use special characters, such as /, :, *, ?, <, >, or \.

•

File info Lock

: access the file properties.

: lock the file so that other people cannot

access it without your lock code.

•

Erase

: erase the file.

•

Erase all

: erase all files.

Viewing a video clip

menu.

1. Select

Vcam

2. Select the video clip you want.

During playback, you can use the following keys:

Key Function

Pauses or resumes playback.

Down Opens the video clip list.

Left Moves back to the previous file. Moves

backward in a file when held down.

Right Skips to the next file. Moves forward in

a file when held down.

/ Adjusts the volume.

On the video player screen, press <

> to access

the following options:

•

Send video Msg.

: send the file as part of a video

message.

•

Set wallpaper

: set the video clip as your

wallpaper for the idle screen.

•

File info

: access the file properties.

Menu functions

Camera

(Menu 3)

Page 42

Menu functions

Using video options

While viewing the video clip list, press < access the following options:

•

Send Video msg.:

message.

•

Set wallpaper

wallpaper for the idle screen.

•

Rename

•

File info

•

Lock

access it without your lock code.

•

Erase

•

Erase all

: change the file name.

Do not use special characters, such as /, :, *, ?, <, >, or \.

: access the file properties.

: lock the file so that other people cannot

: erase the file.

: erase all files.

Photo studio

Photo studio is a great tool for managing photos. Use this menu to edit photos by applying special effects and adding comments.

send the file as part of a video

: set the video clip as your

(Menu 3.3)

Option

> to

Wizard effect

You can apply a special effect to a photo.

1. Select

2. Select a photo or take a photo.

3. Press [Left] or [Right] to select an effect. You can compare the changed photo with the

original by pressing < <

Done

4. Press <

5. Enter a name for the photo and press <OK>.

Basic effect

You can change the colour tone of a new photo or saved photo.

1. Select

2. Select a photo or take a photo.

3. Press [Left] or [Right] to select a tone. You can compare the changed photo with the

original by pressing < <

Done

(Menu 3.3.1)

Saved photo

Save

(Menu 3.3.2)

Saved photo

New photo

Compare

New photo

Compare

> and press

Page 43

4. Press <

5. Enter a name for the photo and press <OK>.

Decoration

You can add a decorative frame, clip, or photo cut-out to a photo. You can also add text to the photo.

1. Select

2. Select a photo or take a photo.

3. Press <

Save

(Menu 3.3.3

Saved photo

Option

editing options:

•

Fun frame

[Left] or [Right].

•

Clip

: select an image. You can move it to the position you want by pressing the Navigation keys.

•

Photo sticker



p. 41.

•

Text

: enter text. After entering text, you can change the font size and colour, and the brightness of the font colour. You can move text to the position you want by pressing the Navigation keys.

)

New photo

> to access one of the following

: select a decorative frame using

: select a photo cut-out.

•

Pen

: add a drawing to the photo. Before drawing, change the thickness and colour of the draw line, and the brightness of the colour. You can move the pen by pressing the Navigation keys and draw using the number keys.

Press <

Help

and drawing a pen.

4. After adding decorations, press <

5. Enter a name for the photo and press <OK>.

Photo sticker

You can make a photo cut-out using a photo.

1. Select

2. Select a photo or take a photo.

3. Select a photo cut-out type using [Left] or [Right]

4. Press [Left] or [Right] to adjust the photo cut-out

5. Move the photo cut-out to the position you want

Saved photo

and press <

size and press <

using the Navigation keys and press <

> to view details about moving

(Menu 3.3.4)

New photo

Select

Save

Menu functions

Camera

(Menu 3)

Page 44

Menu functions

The part of the photo is saved as a photo cut-out.

Video capture

You can save a single video clip frame as a photo.

1. Select a video clip from the The selected video clip plays.

2. When the part of the video clip you want to capture appears, press <

The video clip frame displays.

3. Press <

4. Enter a name for the video clip frame and press <OK>.

Composition

You can make a new image by combining two photos.

1. Press <

2. Select

3. Select a photo or take a photo.

4. Press <

1. Select

(Menu 3.3.5)

My album

Capture

Save

(Menu 3.3.6)

Open

> when the

Saved photo

Open

> when the BG field highlights.

Saved photo

Main

New photo

folder.

field highlights.

2. Select a photo or take a photo.

3. Press <OK>.

4. Press [Left] or [Right] to adjust the image brightness and press <

5. Enter a name for the composition and press <OK>.

Revision

You can change the image properties of a photo, such as the contrast, brightness, saturation, or blur.

1. Select

2. Select a photo or take a photo.

3. Press <

(Menu 3.3.7)

Saved photo

Option

•

Sharpness

Increasing the sharpness makes the image appear more focus.

•

Brightness

image.

•

Hue

: change the colour tone of the image.

•

Blur

: adjust the clarity of the image.

Save

New photo

> to access the following options: : adjust the image sharpness.

: adjust the brightness of the

Page 45

4. After changing the properties, press <OK>. You can compare the changed photo with the

original by pressing < <

Done

5. Press <

Save

> to save the photo.

Compare

> and pressing

6. Enter a name for the photo and press <OK>.

Flip

(Menu 3.3.8)

You can change the orientation of a photo.

1. Select

Saved photo

New photo

2. Select a photo or take a photo.

3. Select a direction icon, or , by pressing [Left] or [Right].

4. Select an orientation for the photo using [Up] or [Down] and press <

Save

5. Enter a name for the adjusted photo and press <OK>.

Text composition

(Menu 3.3.9)

You can extract text from a photo and add it to another photo.

It may not be possible to extract text from a non-mono colour background photo.

1. Press <

2. Select

Open

> when the

Saved photo

Main

New photo

field highlights.

3. Select a photo or take a photo.

4. Press <

5. Select

Open

> when the

Saved photo

Text

New photo

field highlights.

6. Select a photo or take a photo.

7. Press <OK> and then <

Save

8. Enter a name for the photo and press <OK>.

Settings

(Menu 3.4)

Use this menu to change the default settings for the options when using the camera.

•

Sound

: select a sound to indicate a shutter release sound, the camera is ready for use, and a self timer sound.

•

Long camera key

•

Reset

: restore settings for the camera.

: select a default camera mode.

Menu functions

Camera

(Menu 3)

Page 46

Menu functions

•

Auto save

•

Album lock

other people cannot access it without your lock code.

Display

The

Display

settings for the display and the light.

To access this menu, press < select

Language

Use this menu to change the language of the display text.

Image box

Use this menu to change the background image to be displayed in Idle mode or when the phone is turned on or off.

: turn the auto saving feature on or off.

: lock the

(Menu 4)

menu enables you to change various

Display

(Menu 4.1)

(Menu 4.2)

My album

> in Idle mode and

folder so that

1. Select the item for which you want to change the image.

•

Opening

when the phone turns on.

•

Closing

the phone turns off.

•

Wallpaper

Idle mode.

2. Select the image category you want.

3. Select the image you want.

Banner

Use this menu to set a banner message to be displayed at the bottom of the display in Idle mode.

Menu style

Use this menu to select the menu display style.

Backlight

Use this menu to customise settings for backlight.

: select an image to be displayed

: select an image to be displayed when

: select an image to be displayed in

(Menu 4.3)

(Menu 4.4)

(Menu 4.5)

Page 47

•

Main LCD

remains on.

•

Sub LCD

external display.

•

Keypad Save mode

PM and 8:00 AM. Doing this saves the battery power.

Normal mode

any key.

Set time

Use this menu to set the current time and date or set up the time zones for the Dual Clock wallpaper.

Main clock

You can set the current time and date.

Enter the time in 24-hour format and the date in the order of year, month, and day.

: select the length of time the backlight

: turn on or off the backlight for the

: select the keypad backlight mode.

: use the backlight only between 5:00

: flash the backlight when you press

(Menu 4.6)

(Menu 4.6.1)

Dual clock

You can choose two time zones to be displayed when you select

1. Press [Left] or [Right] to select the time zone for the upper clock and press [Down].

2. Press [Left] or [Right] to select the time zone for the lower clock.

3. Press <

External clock

Use this menu to select a clock type to be displayed on the external display.

Dialing font

Use this menu to display numbers in colours when entering a phone number for dialling.

(Menu 4.6.2)

Dual clock

Save

You can apply the daylight savings time for each clock. When a clock highlights, press < and then <

for the wallpaper image.

Save

(Menu 4.7)

(Menu 4.8)

DST on

Menu functions

Camera

(Menu 3)

Page 48

Menu functions

Quick menu indicator

Use this menu to set whether or not the quick menu indicators are displayed on the dial screen.

While dialing numbers in Idle mode, you can press the appropriate Navigation keys to access the preset menu you want.

Messages

Use the messages. You can also use the quick SMS, voicemail, and web alert features.

To access this menu, press < select

Picture msg.

Multimedia Message Service (MMS) delivers messages containing a combination of text, image, and audio, from phone to phone or from phone to e-mail.

(Menu 5)

Messages

menu to send or receive text

(Menu 5.1)

(Menu 4.9)

> in Idle mode and

New MMS

Use this menu to create and send multimedia messages.

1. Enter a destination phone number or e-mail address and press [Down].

2. Enter a Cc number or e-mail address and press [Down].

3. Enter a Bcc number or e-mail address.

4. Press [Down] to move to the Subject field.

5. Enter a subject for your message.

6. Press [Down] to move to the Picture/Video field.

7. Press <

8. Press [Down] to move to the Message field.

9. Enter a message.

10. Press [Down] to move to the Sound field.

11. Press <

12. Press [Down] to move to the Setting field.

13. Press < the following settings:

(Menu 5.1.1)

> and add an image.

> and add a sound clip.

>, select

Send setting

and change

Page 49

•

Priority

•

Delivery report

: set the priority level of the message.

: request that the network informs you when your message has been delivered

•

Outbox msg

: set whether or not sent

messages are saved in the Outbox.

14. After adding media files, press <

> to access

the following options for editing the message.

•

Add

: add a new slide.

•

Delete

: delete the added slide.

•

Duration

: set how long one slide in your outgoing messages displays. After a specified time, the display automatically scrolls to the next slide.

15. When you have finished, press <

Select

> to send

the message.

Inbox

(Menu 5.1.2)

Use this menu to access the multimedia messages you have received.

The maximum size allowed for an MMS message is 200KB.

The following icons are available to show the message status:

• : Messages that you have opened.

• : Messages that you haven’t opened.

1. Select a message.

2. If necessary, press <

Receive

> to retrieve the

message from the MMS server.

3. Press [ ] to stop playing the sound attached in the message. To play the sound, press [ ] again.

While viewing a message, press <

> to access

the following options:

•

: send a reply message to the sender.

•

Forward

•

Reply all

: forward the message to other people.

: send a replay message to the sender

and other recipients.

•

Save phonebook

: extract the sender’s addresses

or phone numbers from the message text.

•

Save image

•

Save sound

•

Remove

: save the image of the message. : save the sound of the message.

: erase the currently selected message.

Menu functions

Messages

(Menu 5)

Page 50

Menu functions

While viewing the message list, press < access the following options:

•

Information

•

Remove

•

Remove all

Outbox

This folder stores messages that the phone has sent or has failed to send.

While viewing a message, press < the following options:

•

Resend

•

Forward

•

Remove

While viewing the message list, press < access the following options:

•

Information

•

Remove

•

Remove all

: access the message properties.

: remove the selected message.

: remove all messages.

(Menu 5.1.3)

: send the message again.

: forward the message to other people.

: erase the currently selected message.

: access the message properties.

: remove the selected message.

: remove all messages.

> to

> to access

> to

Draftbox

This folder stores messages you have saved to send at a later time.

When you select a message, it opens in Edit mode so that you can edit and send the message.

While viewing the message list, press < access the following options:

•

Manager

Use this menu to manage media items and change the settings for using the multimedia message feature.

•

(Menu 5.1.4)

Remove Remove all

Saved image

downloaded from the wireless web.

Saved video

downloaded from the wireless web.

Saved sound

downloaded from the wireless web.

: remove the selected message.

: remove all messages.

(Menu 5.1.5)

: access the images you have

: access the videos you have

: access the sound clips you have

> to

Page 51

•

Saved voice

: access the sound clips you have

saved.

•

My voice

: access the voice memos you have

recorded.

•

Settings

: change the settings for the multimedia

message feature:

Priority

: set the priority level of your messages.

Delivery report

: set the network to inform the

sender when a message has been delivered to you.

Outbox msg

: set whether or not sent messages

are saved in the Outbox.

Inbox msg

: set what happens if a new message is

received when the phone's memory is full.

Text msg.

(Menu 5.2)

Short Message Service (SMS) allows you to send or receive text messages.

Write

(Menu 5.2.1)

Use this menu to create text messages and send them to multiple mobile phones.

1. Enter the message text and press <OK>.

2. Change the following options:

•

Priority

: set the priority level of the message.

•

Ack

: activate or deactivate the delivery acknowledgement feature. When this feature is activated, the network informs you whether your message is delivered to the recipient or not.

3. When you have finished, press <

Save

4. Enter a phone number. To send the message to multiple destinations,

press [Down] and enter additional numbers.

5. Press <OK> to send the message.

Inbox

(Menu 5.2.2)

Use this menu to access messages you have received.

Viewing received text messages

When the phone receives a text message, the phone sounds a message alert and displays a text notification with the call back number appears. Press <

Select

> to

view the message immediately.

Menu functions

Messages

(Menu 5)

Page 52

Menu functions

When you access a list of the received message displays. Icons displayed on the list indicate the messages’ status:

• : Messages that you have opened.

• : Messages that you haven’t opened. A red icon means that the message is urgent.

means that the message is saved on the card.

Using message options

While viewing a message, press < the following options:

•

Erase

Inbox.

•

Forward

•

Call/Save

number or save the number to Phonebook.

•

Move to phone/Move to card

message to the phone’s memory or the card.

Phone

, or

Card

in the

Inbox

Option

> to access

: erase the selected message from your

: send a reply message to the sender.

: send the message to other people.

: make a call to the sender’s phone

: move the

menu,

•

Copy to phone/Copy to card

to the phone’s memory or the card.

While viewing the message list, press < access the following options:

•

Erase

: erase the currently selected message.

•

Erase multi

•

Erase all

Accessing Web alerts

When you select phone accesses your Alert Inbox on the wireless web, so that you can view a web message from your web server.

Outbox

Use this menu to access messages you have sent.

Viewing sent text messages

When you access menu, a list of sent messages appears. Icons displayed on the list indicate the messages’ status:

: erase the selected messages.

: erase all messages.

Web alert

(Menu 5.2.3)

Phone

, or

: copy the message

Option

in the

Inbox

Card

in the

> to

menu, the

Outbox

Page 53

• : Messages that have been successfully

delivered.

• : Messages that the phone has failed to send. A red icon means that the message is urgent.

means that the message is saved on the card.

Using message options

While viewing a message, press <

Option

> to access

the following options:

•

Erase

: erase the currently selected message.

•

Resend

: send the message to the recipient again.

•

Edit

: edit the message.

•

Call/Save

: make a call to the sender’s phone

number or save the number to Phonebook.

•

Move to phone/Move to card

: move the

message to the phone’s memory or the card.

•

Copy to phone/Copy to card

: copy the message

to the phone’s memory or the card.

While viewing the message list, press <

Option

> to

access the following options:

•

Erase

: erase the currently selected message.

•

Erase multi

•

Erase all

Templates

: erase the selected messages.

: erase all messages.

(Menu 5.2.4)

Use this menu to use preset templates and create new templates. You can also edit an existing template.

Voice mail

(Menu 5.2.5)

Use this menu to access your voicemails.

When you receive a voicemail, the new voicemail icon and a text notification display. Press [ ] to dial, and the phone dials the voicemail centre. Then follow the voice prompts from the system to listen to the voicemail.

Voice mail #

(Menu 5.2.6)

Use this menu to display the voicemail server number.

Settings

(Menu 5.2.7)

Use this menu to customise settings for receiving or sending messages.

Menu functions

Messages

(Menu 5)

Page 54

Menu functions

•

Auto scroll

phone scrolls to the next screen, 1 through 5 seconds.

When this option is set to scroll to the next screen using [Up] or [Down].

•

Msg reminder

you of new messages.

•

New messages

outgoing messages.

Save message

sent message to be saved in the Outbox.

•

Alert on call

informs you when you receive a new message during a call.

•

Msg wallpaper

displayed on the Message screen so that you can view messages with the image.

•

Auto delete

automatically erase the oldest message when the phone's memory is full and a new message is received.

: set the time interval in which the

Off

, you can manually

: set how often the phone reminds

: customise the settings for your

: set whether or not you want the

: set whether or not the phone

: select a background image to be

: set whether or not the phone will

Quick SMS

Quick SMS is a way of sending short, simple messages that are delivered immediately to other people by using preset template messages.

Creating the buddy list

1. On the Quick sms screen, select

2. Select an entry from the Phonebook list.

3. Press <OK>. The selected entry adds to the buddy list.

4. To add more entries, press < from step 2.

After saving entries, press < following options:

•

Erase

•

Erase all

Starting your messenger

1. On the Quick sms screen, select

2. In Idle mode, press [ The phone sends an SMS message using the preset

message to the recipient you have predefined.

(Menu 5.2.8)

View members

Add

> and repeat

Option

> to access the

: erase the entry from the buddy list.

: erase all entries from the buddy list.

Setting → On

CLR

] four times.

Page 55

Using the preset message

On the Quick sms screen, select

To edit the preset message, clear the default message, enter a new message, and press <OK>.

Memory status

This menu displays how many messages are stored on the card and in the phone’s memory.

Sounds

The

Sounds

sound settings.

To access this menu, press < select

Sounds

Ring tones

Use this menu to set the ringer for calls, messages, alarms, and schedule alarms separately.

(Menu 5.2.9)

(Menu 6)

menu allows you to customise various

(Menu 6.1)

Edit MSG

> in Idle mode and

Call volume

Use this menu to adjust the ringer volume and type for voice calls.

•

Level 1~5

•

Ringer only

selected in the

•

Silent

•

1 Beep

•

Vibration

•

Vib. & ringer

same time.

•

Vib. then ringer

rings.

•

Ringer then vib.

vibrates.

Msg. volume

Use this menu to adjust the ringer volume for incoming messages.

(Menu 6.2)

: select one of the volume levels.

: the phone sounds the ringtone

Ring tones

: the phone neither vibrates nor rings.

: the phone sounds a beep.

: the phone vibrates.

: the phone vibrates and rings at the

: the phone vibrates and then

: the phone rings and then

(Menu 6.3)

menu.

Menu functions

Sounds

(Menu 6)

Page 56

Menu functions

Alarm volume

Use this menu to adjust the ringer volume for alarms.

Schedule volume

Use this menu to adjust the ringer volume for an schedule alarm.

Key tone

Use this menu to select a type of tones that the keypad sounds each time you press a key.

You can adjust the key tone volume using [ / ] in Idle mode.

Alert

(Menu 6.7)

Use this menu to set up various alert sounds on your phone.

Function alert

Use this menu to set up audible alerts (beeps) at a specified time to inform you that certain things have happened.

(Menu 6.4)

(Menu 6.5)

(Menu 6.6)

(Menu 6.7.1)

•

Themes

•

Alert on/off Select/Saving

when you save your selection or change a menu function.

Cancel/Warning

when you cancel your selection or change when a confirmation message appears.

Folder

open or close the phone.

Connect

when an outgoing call is connected to the system.

Disconnect

tone when a call is disconnected by the other person.

Power on/off

when you turn on or off the phone.

Exit silent mode

when you exit Silent mode.

: select an alert tone.

: turn each alert on or off.

: set the phone to sound an alert

: set the phone to sound an alert when you

: set the phone to sound a connect tone

: set the phone to sound a disconnect

: set the phone to sound an alert

Page 57

Hour alert

You can set your phone to sound an alert every hour on the hour.

1. Select On and press [Down].

2. Enter the time period when the phone uses the hour alert.

3. Press <

do mOre

Using the to MP3 music, and watch VOD. You can also create your own melodies.

To access this menu, press < select

3D game

You can enjoy fun games on your phone.

(Menu 6.7.2)

Save

(Menu 7)

do mOre

Before accessing a game, you need to rotate the display first.

menu, you can play games, listen

(Menu 7.1)

> in Idle mode and

Starting a game

1. Select the game you want.

2. If necessary, press any key except for [ ].

3. If necessary, select a game mode. The phone displays the following options; options

vary depending on the selected game.

•

Start Race/NEW GAME

•

CONTINUE

played.

•

Score/RECORD

•

OPTION

•

ABOUT

•

HELP

the game.

•

Quit Game/EXIT

4. Select

For further information about games, refer to the help option.

Start race or NEW GAME

: continue the last game you

: check the high score table.

: change the game settings.

: access the game properties.

: give you information about how to play

: start a new game.

: exit the game.

Menu functions

do mOre

(Menu 7)

Page 58

Menu functions

MP3

(Menu 7.2)

Use this menu to enjoy MP3 music.

MP3 player

You can play MP3 music files. First, you need to save MP3 files in your phone’s memory.

Downloading MP3 files

To download MP3 files to the phone, use the following methods:

• Download from the wireless webp. 63

• Connect the phone to a computer and copy to the phonep. 67

Creating the play list

Before playing MP3 music files, you need to add them to the play list.

1. Access the The list of MP3 files stored in your phone displays.

2. Press <

3. Press <

4. Press <

(Menu 7.2.1)

My files

Menu Check Add

menu.

> and select

> to select the files you want.

Add to play list

5. To play music, press <

Playing MP3 music files

Accessing music files in the play list.

During playback, use the following keys:

Key Function

Up Changes the repeat mode.

Down Opens the file list.

Left Goes back to the previous file. Moves

Right Skips to the next file. Moves forward in a

MP3 player

Pauses or resumes playback.

• : repeats all files.

• : repeats the current file.

• : plays the files in random order.

• No icon: plays the selected file.

backward in a file when held down.

file when held down.

Play

menu begins playback MP3

Page 59

Key Function

/Adjusts the volume.

A - B

Repeats a section of your choice. Pressing this key begins a search for the starting point. To search for the end point, press <A → B>. To stop repeating, press <A ↔ B>.

Using MP3 player options

During playback, press <

> to access the

following options.

•

Go to file list

•

Timer

: access the file list.

: set the length of time the MP3 player stays on. The timer appears to show you the time remaining.

•

Set to ringer

: set the music file as a ringer melody for incoming calls, alarm sets, or scheduler alarms.

•

Visual effect

•

File info

: change the equaliser setting.

: access the file properties.

Using the play list

From the MP3 player screen, press [Down] to open the play list.

Press <

> to access the following options:

•

Add to play list

•

Remove

•

Visual effect

•

Go to file list

•

File info

My files

(Menu 7.2.2)

: add files to the play list.

: remove files from the play list.

: select an equaliser image.

: access the file list.

: access the file properties.

Use this menu to access MP3 files stored in the phone’s memory.

Press <

> to access the following options:

•

Open files

•

Add to play list

: access the music file list.

: add the MP3 files in the selected

folder or the selected MP3 file to the play list.

•

Rename

: change the file name.

Do not use special characters, such as /, :, *, ?, <, >, or \.

Menu functions

do mOre

(Menu 7)

Page 60

Menu functions

•

Sort

: change the sort order of the list.

•

File info

•

Set to ringer

melody for incoming calls, alarm sets, or scheduler alarms.

•

Erase

•

Erase all

MP3 settings

Use this menu to set the use of the backlight of the phone while playing MP3 files.

•

Backlight

playing an MP3 file.

Default

time set in the

Always on

VOD

In the VOD (video on demand) menu, you can download video files from the wireless web and play them.

: access the file properties.

: set the music file as a ringer

: erase the selected file.

: erase all files.

(Menu 7.2.3)

: change the backlight mode while

: the backlight turns off after the period of

Backlight

: the backlight does not turn off.

(Menu 7.3)

menu.

You can quickly access this menu by pressing [Left] in Idle mode.

VOD files

When you access this menu, the list of downloaded video files displays.

Playing video files

Scroll to a file and press <

You can access the following options during playback.

Key Function

Up Changes the repeat mode.

Down Opens the file list.

(Menu 7.3.1)

Play

Pauses or resumes playback.

• : repeats all files.

• : repeats the current file.

• : plays the files in random order.

• No icon: plays the selected file.

Page 61

Key Function

Left Goes back to the previous file. Moves

backward in a file when held down.

Right Skips to the next file. Moves forward in

a file when held down.

/ Adjusts the volume.

STOP

Stops playback.

Using video player options

From the video player screen, press <

> to

access the following options:

•

Set to wallpaper

: set the file as your wallpaper.

This option is available for video clips.

•

File info

: access the file properties.

Using file list options

While viewing the video file list, press <

> to

access the following options:

•

Open files

: open and play the selected files.

•

Rename

: change the file name.

Do not use special characters, such as /, :, *, ?, <, >, or \.

•

File info

•

Set to wallpaper

•

Erase

•

Erase all

Connect to server

: access the file properties.

: set the file as your wallpaper.

: erase the currently selected file.

: erase all files stored in your phone.

(Menu 7.3.2)

Use this menu to load the website preset by your service provider for viewing and downloading video files.

For further details, contact your service provider.

Settings

(Menu 7.3.3)

Use this menu to set the time increments by which each press of the Backward and Forward keys moves in a file.

The keypress speed is an approximately value.

Menu functions

do mOre

(Menu 7)

Page 62

Melody composer

(Menu 7.4)

Melody composer is a great tool that allows you to compose your own melodies using a variety of musical components.

Compose melody

(Menu 7.4.1)

When you access this menu, a stave screen displays with a selection point at the first note position.

Creating a melody

You can compose a melody of up to 10 pages and you can insert 12 notes or rests onto each page.

1. Move the selection point up or down.

2. When you have placed the selection point to your satisfaction, press <

Input

3. Select a note or rest. The note or rest is inserted onto the stave and the

selection point moves to the right on the same line.

4. Repeat steps 1 to 3 to add more notes and rests.

You can also add a background melody, change the tempo, or adjust the volume by using composer options.

5. When you have finished, press < select

Save

Option

> and

6. Enter a name for your melody and press <OK>.

Using composer options

While composing a melody, press <

Option

> to access

the following options:

•

New

: open a new composer screen.

•

Open

: open the list of the melodies you have

composed.

•

Play

: play back the current melody.

•

Save

: save the melody.

•

Save as

•

Instrument

: save the melody with a different name.

: change the musical instrument for

the melody.

•

BGM

: use a background melody.

•

Add note

: add notes to the melody.

Page 63

•

Tempo

: change the tempo.

•

Volume

: adjust the volume level of the main and

background melodies separately.

Editing a melody

While composing a melody or after opening a saved melody, you can edit it.

1. Select an entered note or rest by moving the selection cell.

The colour of the selected item changes to yellow to indicate that it is in Edit mode.

2. Change the position or type of the note or rest the same as you would when inserting it.

• Press [ ] or [ ] to move a note to the next

lower or higher position by semi-tone.

•Press <

Input

> to change the type of the

selected note or rest.

•Press <

Option

> to access the following

options:

Range

: select more than one note or rests.

Copy

: copy the selected notes and/or rests.

Cut

: delete the selected notes and/or rests.

Paste

: paste the copied notes and/or rests to the position next to the currently selected note or rest.

Change

: change the type of the currently

selected note or rest.

Erase

: delete the selected notes and/or rests.

Play

: play back the current melody.

3. After editing, press [Right] to move the selection cell to an input position.

4. Press <

Option

> and select

changes to the melody, or

Save

Save as

to save the

melody under a different name.

My melodies

(Menu 7.4.2)

Use this menu to play the melodies you have created.

Playing a melody

Scroll to the melody you want and press <

Play

Menu functions

do mOre

(Menu 7)

Page 64

Using melody options

While viewing the melody list, press < access the following options:

•

Set to ringer

for incoming calls, alarm sets, or scheduler alarms.

•

Rename

Do not u se speci al cha ra ct ers, s uch as /, :, * , ?, <, >, or \.

•

Erase

•

Erase all

•

View details

TATA Zone

This menu is supplied by your service provider. The contents available in each menu option may be different, depending on the service provider. For further details, contact your service provider.

To access this menu, press [ ] in Idle mode.

: set the melody as a ringer melody

: change the melody name.

: erase the selected melody.

: erase all melodies.

: access the melody properties.

(Menu 7.5)

> to

Start Brew

Use this menu to download applications and change the browser settings. You can also view help information.

Downloading an application

1. When the [].

•

2. Press [ ] when the You are sent to the associated website preset by your service provider and you can browse the available applications.

3. Select the application you want and follow the onscreen instructions to download it.

Changing the browser settings

1. Select the

MobileShop

Catalog Search

keyword.

Help MobileShop

: browse and purchase items.

: search for an application by entering a

: get help information for using the

Settings

icon is highlighted, press

menu.

Catalog

icon.

option is highlighted.

Page 65

2. Select a setting option.

•

Order Apps

: change the list order of the

downloaded applications.

•

Move Apps

: move an application to another

folder.

•

Manage Apps

: check the amount of memory

used for downloaded applications.

•

Main Menu View

: change the view mode of

the main menu screen.

•

Screen Savers

: activate the Screen Saver

application, if downloaded.

•

View Log

: show the records of your browsing.

Viewing help information

1. Select the

Help

icon.

2. Select a help item.

3. Press [Up] or [Down] to scroll through help information.

4. Press [ ] to go back to the main help screen.

Mobile Browser

(Menu 7.6)

Your phone comes equipped with a web (Wireless Application Protocol) browser which makes it possible for you to access the wireless web. Using the web browser, you can access up-to-date information and a wide variety of media content, such as wallpapers, ringtones, and music files.

Selecting the

Start Browser

menu launches the web browser and accesses the homepage of your service provider.

Navigating websites

To Press

scroll through browser items the Navigation keys.

scroll page by page [ / ].

select an item [ ].

return to the previous screen [

return to the homepage hold and [

CLR

Menu functions

do mOre

(Menu 7)

Page 66

Menu functions

Using browser menu options

While navigating websites, you can use various options. To access the Browser Menu list, press <

> and select

•

Home

: send you back at any time to your startup

homepage.

•

Forward

•

Bookmarks

•

Go To URL

web page.

•

Show URL

where you are currently connected.

•

History

: display the records of your connection to

the Wireless Web.

•

: use the Web Search features of your

service provider.

•

Reload

: refresh the current web page with

updated information.

•

Snapshots

page.

: return you to the previous web page.

: display the Bookmarks list.

: manually enter the URL address of a

: display the URL address of the site

: take a snapshot of the current web

•

Advanced... Restart Browser

without exiting it.

Delete Cookies

cookie is a record of a user’s information that is stored on the phone when you visit a website.

Multimedia

media objects, such as images or background sound on a web page.

Scroll Mode

scroll speed.

Send Referrer

referrer information to the web server each time the browser is launched.

Connection Timeout

remains connected to the current web page when you don’t use the web page for a specified period.

Key Press Timeout

waits after you have pressed a key in the text entry mode before moving the cursor to the right.

Security

: customise further options.

: restart the web browser

: delete all cookies and files. A

: enable or disable auto download of

: select a scroll mode, and/or set the

: set the browser to send HTTP

: set how long the phone

: set up all of security information.

Page 67

Organiser

The

Organiser

your schedule and tasks, set alarms, or use convenient features, such as a remote controller, calculator, voice recorder, counter, and memo pad.

To access this menu, press < select

Organiser

Today

Use this menu to schedule new events for the current date. Events scheduled for future dates automatically appear on your Today display for that particular day.

Schedule and access events as you would in the

Scheduler

Use this menu to view the current month, as well as the past or future months in the calendar format. You can be alerted by the Scheduler function before an event commences.

(Menu 8)

menu enables you to keep track of

(Menu 8.1)

(Menu 8.2)

> in Idle mode and

When you access this menu, today’s date is automatically selected and the date in lunar calendar displays on the bottom.

On the calendar, press < following options:

•

View

: access the events stored for the selected

day.

•

Add new

•

Erase events

individually.

•

Erase all

•

Jump to date

: add a new event to the selected day.

: erase all of the events in the calendar.

Option

> to access the

: erase scheduled events

: enter the date you want to access.

Scheduling an event

You can schedule up to 9 events for one day and 20 events total.

1. Select a day from the calendar.

To move to the next or previous month, press [/

Menu functions

Organiser

(Menu 8)

Page 68

Menu functions

2. Enter your event information and press <OK>.

3. Enter the time and press [Down].

4. Enter the date and press [Down].

5. Press [Left] or [Right] to select an alarm option.

6. Press <

Viewing your schedule

Days with scheduled events are indicated with the squares at the corners of the date cell.

1. Select one of days with scheduled events. The list

2. Select an event.

3. Press [Left] or [Right] to move to the previous or

While viewing an event, press < following options:

•

Save

> to save your event.

of events for that day displays.

next event.

Add new Edit Erase Erase all

: add a new event.

: edit the selected event.

: erase the selected event.

: erase all events.

> to access the

Alarm clock

Use this menu to set an alarm to ring at a specific time.

(Menu 8.3)

Setting an alarm

1. Select

2. Select an alarm frequency option and press

3. Enter the alarm time and press [Down].

4. Select a snooze option and press [Down].

5. Press <

6. Select a ringer category.

7. Select the ringer melody you want.

8. Press <

Alarm 1

[Down].

To listen to the highlighted melody, press <

, or

Alarm 2

Select

> to specify an alarm ringer.

Save

> to save the alarm set.

Play

Stopping an alarm

• To stop an alarm when it rings, press any key,

except <

• The alarm repeats at specified intervals. Press

End

> and [ ].

End

> to stop an alarm.

Page 69

Deactivating an alarm

1. On the Alarm list, select the alarm you want to deactivate.

2. Select

User memory

Off

from the Set field.

(Menu 8.4)

Use this menu to connect the phone to a PC, as you would use an external memory disk drive, and access the file folder of your phone’s memory.

Connect to PC

(Menu 8.4.1)

Use this menu to connect your phone to a computer.

1. Connect a USB cable to the jack on the left side of the phone and the USB port of the phone.

2. Access the

Connect to PC

menu.

3. Enter the password and press <OK>. Your phone switches to Memory Disk mode.

4. Open

My computer

on your Windows desktop and double-click the corresponding removable disk to open the phone’s file folder.

5. Copy files from the phone to the computer or vice versa.

6. When you have finished, close the disk.

7. Press <

8. Press <

Disconnect Yes

> to exit Memory Disk mode.

> to confirm the exiting.

• When the phone is in Memory Disk mode, all calls and messages are blocked.

• Use the Safely Remove Hardware programme from the Windows task bar for removing the USB cable from the computer; otherwise, the files may be corrupted and, thus, may not be played properly.

File manager

(Menu 8.4.2)

Use this menu to manage files stored on the phone’s memory. You can access the folders of your phone’s memory and manage media files.

You can also use each file option when you press <

> with a file highlighted in a folder.

•

Erase

: erase the file.

•

Move

: move the file to another folder.

Menu functions

Organiser

(Menu 8)

Page 70

Menu functions

•

Copy

: copy the file to another folder.

•

Rename

•

Create folder

•

Erase all

•

File info

•

Assign

idle screen, or the opening or closing image.

•

Set to ringer

•

Set wallpaper

scrren.

•

Copy to pbook

Memory status

Use this menu to view the memory status of each folder in the phone.

: change the file name.

Do not use special characters, such as /, :, *, ?, <, >, or \.

: create a new folder.

: erase all files.

: access the file properties.

: set the image as your wallpaper for the

: set the ring information.

: set your wallpaper for the idle

: copy the file to phonebook.

(Menu 8.4.3)

Format

Use this menu to format files saved in the

manager

I.Beam

Using the infrared port on the phone, you can use your phone as a remote controller, or send and receive data to and from other phones.

Remote control

You can set up and use the phone as a remote controller for your TV or DVD player.

Tips for using your phone as a remote controller

• The IrDA ports on both devices must be facing

• If your phone does not control the device properly,

• The remote control function may not work,

(Menu 8.4.4)

folder.

(Menu 8.5)

(Menu 8.5.1)

each other within 8 meter.

set up the remote control function again with a different number.

depending on the type or version of your device.

File

Page 71

• If a decide has multiple functions, e.g., a VCR/DVD combo, the remote controller may not control both device functions.

• Do not use your phone as a remote controller in pubic places where it can interface with others.

Setting up the phone as a remote controller

1. Align the IrDA port on the phone with a device.

2. Scroll to <

Set

ROOM, LIVING

, or

ETC

and press

You can designate the area in which the device the phone will control is located.

3. Select the device type,

DVD

4. Select a manufacturer of the device.

5. Scroll through the model numbers until you find the appropriate one.

When you select the correct model number for your device, the device turns on or off.

6. Press <

Select

Using the remote controller function

1. Align the IrDA port on the phone with the device.

2. Scroll to

ROOM, LIVING

, or

ETC

You can turn on or off all of the devices you have registered to be remotely controlled by the phone at one time. Select the area you want to control and press <

Power all

3. Press the number key corresponding to the device you are controlling.

4. Use the keys to control the device, referring to the image on the display.

Deactivating the remote controller

1. Align the IrDA port on the phone with the device.

2. Scroll to <

Set

ROOM, LIVING

, or

ETC

and press

3. Scroll to the device type for which you want to deactivate remote control and press <

4. Select one of the following options:

•

Erase

: deactivate control of the selected item.

Menu functions

Organiser

(Menu 8)

Page 72

Menu functions

•

Erase all

you have registered.

5. Press <

File transfer

Using this menu, you can send or receive various data, such as Phonebook entries, name cards, photos via the IrDA port.

• For optimal communication, the IrDA ports between the two phones should be within close range of each other.

• If the phones use conflicting IrDA protocol, the IrDA ports may not work properly.

• If you are interrupted by an incoming call while transferring data, the data transfer may be interrupted.

Receiving data

1. Select

2. Select the memory location to which received data will be saved.

: deactivate control of all of the items

Yes

(Menu 8.5.2)

Receive mode

3. Align

4. When you have finished, press <

Sending data

1. Select one of

2. To send all data, select

3. Press <

4. Press <

the IrDA ports between the phones, as shown. The IrDA port must be oriented within 15 degrees of each other.

The received data is automatically saved in the corresponding folder.

phonebook

To send the selected data, select file category. Continue to the next step.

Send name card, Send

, or

Send my album

All

. The data is sent.

Check

> to check the files you want.

Transmit

> or <

Transm

Select

Selection

or the

Page 73

Voice memo

You can record and review voice memos.

cording a voice memo

When there is no voice memo recorded, selecting the

Voice memo

1. Record a memo by speaking into the microphone. While you are recording, a timer displays to show

you the elapsed time. Press <

Continue

2. Press < provides you with the following choices:

•

Save

•

Re-record

record another one.

•

Review

displays the length of the memo.

3. When you are satisfied, select

4. Enter a title for the memo and press <OK>.

(Menu 8.6)

initiates recording.

Pause

> to pause recording and then press

> to resume.

Stop

> to end recording. The screen

: save the voice memo.

: discard the current memo and

: play the voice memo. The screen

Save

Playing a voice memo

Once you have recorded voice memos, the latest memo displays when you access the menu. Scroll to the voice memo you want and press <

Play

> to play the memo.

Voice memo

Using voice memo options

On the Voice memo screen, press < the following options:

•

New record

•

Play

•

Erase

•

Erase all

•

Rename

•

Speaker/Receiver

using the speakerphone feature.

: record a new voice memo.

: play the selected voice memo.

: erase the selected voice memo.

: erase all voice memos.

: change the file name.

: play the selected voice memo

> to access

Menu functions

Organiser

(Menu 8)

Page 74

Menu functions

Task list

Use this menu to enter up a list of tasks you need to do.

Creating a task

1. Enter the task content and press <OK>.

2. Enter the time by which your task needs to be

3. Enter the date by which your task needs to be

4. Select

5. Press <

Viewing a task

Select the task you want to view from the task list.

While viewing a task, press < following options:

•

(Menu 8.7)

done and press [Down].

!High

Low

priority.

Save

> to save the task.

Add new Edit Erase Erase all

: add a new task.

: edit the selected task.

: erase the selected task.

: erase all tasks.

> to access the

Calculator

Use this menu to use the phone as a calculator or a converter. The calculator provides the basic arithmetic functions: addition, subtraction, multiplication, and division.

1. Enter the first number.

2. Select the operation for your calculation by pressing the Navigation keys according to the illustration on the display.

3. Enter the second number.

4. Press <OK> to get the result.

You can reset the calculator by pressing <CE>.

World time

Use this menu to find out what time it is in another part of the world.

(Menu 8.8)

Use [ ] to enter a decimal point and [ ] to change the sign of a number to a negative (-).

(Menu 8.9)

Page 75

Viewing world time

Press the Navigation keys to scroll to the time zone you want to check.

Applying Daylight Savings Time (DST)

1. Scroll to the time zone to which you want to apply the DST, press <

2. Press <

Yes

Countdown

Use this menu to set a time and date for a future event and then check to see how many days, hours, and minutes remain before that event.

DST

(Menu 8.0)

Creating a countdown timer

1. Enter the event for your countdown timer and press <OK>.

2. Enter the time from which you want to count down and press [Down].

3. Enter the date from which you want to count down.

You can enter between 1981 and 2099 for the year.

4. Press <

Save

> to save the timer.

Viewing a countdown timer

Select a timer from the countdown timer list. The timer displays the specified date and time, and how many days and minutes remain until the event.

While viewing a timer, press < following options:

•

Add new

•

Edit

•

Erase

•

Erase all

Memo pad

Use this menu to make memos of important things you need to remember.

: create a new timer.

: edit the selected timer.

: erase the selected timer.

: erase all timers.

(Menu 8. )

> to access the

Writing a new memo

1. Enter what you need to remember.

2. Press <OK> to save the memo.

Menu functions

Organiser

(Menu 8)

Page 76

Menu functions

Viewing a memo

Select the memo you want to view from the memo list.

While viewing a memo, press < following options:

•

Add new

•

Edit

•

Erase

•

Erase all

Settings

Many different features of your phone can be customised to suit your preferences.

To access this menu, press < select

Auto answer

This feature works only when the phone is connected to the headset. With this menu activated, the phone automatically answers calls after a specified time.

: add a new memo.

: edit the selected memo.

: erase the selected memo.

: erase all memos.

(Menu 9)

Settings

(Menu 9.1)

> to access the

> in Idle mode and

To activate this feature, set how long the phone waits before answering an incoming call.

Answer mode

Use this menu to select how to answer an incoming call.

•

By send key

press [ ], if necessary, open the phone.

•

By folder open

open the phone. If the phone is already open, press [ ].

•

By any key

any key, except for the soft keys, [ / ] ,and [ ], if necessary, open the phone.

Auto redial

Use this menu to set the phone to automatically redial the number when a connection fails.

(Menu 9.2)

: the phone answers only when you

: the phone answers when you

: the phone answers when you press

(Menu 9.3)

Page 77

Security

(Menu 9.4)

Use this menu to protect your phone against unautorised use by managing the several access codes of your phone and the card.

To access the

Security

menu, you must enter the 8-

digit lock code and press <OK>. It is preset to

00000000

Lock mode

at the factory.

(Menu 9.4.1)

Use this menu to lock your phone.

•

Off

: deactivate Lock mode.

•

Once

: lock the phone just one time. Once the lock

code is entered, the phone unlocks.

•

: lock the phone. Each time turning on the phone, you need to enter the lock code to use the phone.

In Lock mode, you cannot use phone’s menu function and dial numbers, except for making an emergency call.

To unlock the phone, press one of the soft keys, [ / ], Navigation keys, [ ], [ ],[

MP3

] and [ ],

enter the 8-digit lock code and press <OK>.

Change code

(Menu 9.4.2)

Use this menu to change your current lock code to a new one. The lock code is preset to

00000000

at the

factory.

1. Enter a new 4- to 8-digit lock code and press <OK>.

2. Enter the code once again and press <OK>.

Restriction

(Menu 9.4.3)

Use this menu to restrict the use of your phone.

•

Dialled

: restrict outgoing calls from your phone, except emergency calls by standard emergency numbers, such as 100, 101 and 102 , or 3 programmed numbers in

•

Received

•

Phonebook

: restrict incoming calls.

: restrict use of Phonebook.

Emergency numbers

Menu functions

Settings

(Menu 9)

Page 78

Menu functions

Emergency numbers

Your phone provides the option of storing three emergency numbers. All of these numbers can be manually dialled at any time, even if your phone is locked, all outgoing calls are restricted, or the UIM card is not inserted.

Storing an emergency number

1. Select a location.

2. Press and hold [

3. Enter a number and press < number.

• 100, 101, and 102 will remain as emergency numbers, even if you change them on the emergency number list.

• When the UIM card is not inserted, press < to dial the default emergency number, 100. The other numbers can be dialled manually.

Making an emergency call in Lock mode

Enter one of the programmed emergency numbers and press [ ].

(Menu 9.4.4)

CLR

] to clear the existing number.

Save

> to save the

SOS

Voice privacy

Used only in digital networks, Voice Privacy encrypts the voice channel so that people cannot eavesdrop on your conversation. Use this menu to enable or disable Voice privacy.

•

Standard

calls.

•

Enhanced

an encrypted high security line.

This feature may not be available in all areas. Contact your service provider for details and its availability.

Clear memory

Use this menu to erase Phonebook entries or

messages stored on the UIM card and in phone’s memory.

1. Select

2. Select the memory location you want to clear.

3. Press <

(Menu 9.4.5)

: the phone uses a standard line for

: the phone makes and receives calls on

(Menu 9.4.6)

Phonebook

Yes

Messages

> to confirm the clearing.

Page 79

Reset phone

(Menu 9.4.7)

Use this menu to restore the default settings of all of user-selectable options or clear informations in the phone’s memory.

1. Select a reset option.

•

Functions only

: restore the default settings of

all user-selectable options.

•

All

: clear information stored in the phone’s memory and restore the default settings of the options.

When you reset your phone using the

all

option, information stored on the UIM

card, items stored in the

File manager

Reset

folder, and files stored in the My album folder does not reset.

2. Press <

Yes

> to confirm the reset. The phone reboots, turning itself off and then back on, and returns to Idle mode.

Card setup

(Menu 9.4.8)

Use this menu to access the security options for the card.

•

PIN check

: activate the PIN check feature. You must enter the PIN assigned to your card each time you switch on the phone.

•

Change PIN

: change the PIN of your card to a new one, provided that the PIN check feature is enabled.

•

UIM lock

: set your phone to work with the current

card only.

Entry method

(Menu 9.5)

Use this menu to select the default text input mode.

Domains preset

(Menu 9.6)

Your phone has domain name extensions that you can retrieve when composing a message. Use this menu to change default domain name extensions and add new domain name extensions, if necessary.

Menu functions

Settings

(Menu 9)

Page 80

Contents status

Use this menu to check the amount of the memory currently being used or memory remaining for media contents, such as applications, melodies, and images.

Rotation mode

Use this menu to specify a feature to open automatically when you rotate the phone display. When you rotate the display, you can get a wide screen view, making the phone’s entertainment features, such as camera, game, MP3 music, and VOD, that mush more enjoyable.

Airplane mode

In an airplane, all calls are restricted for safety and you must turn off the phone. However, if you need to use your phone, except call functions, use Airplane mode which disables all call functions of your phone.

(Menu 9.7)

(Menu 9.8)

(Menu 9.9)

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service call, perform the simple checks in this section before contacting a service professional.

When you switch on your phone, the following messages may appear:

“Card is empty. Insert card”

• Be sure that the card is correctly installed.

“PIN code”

• You are using your phone for the first time. You must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time you make a call, the PIN has to be entered. To disable this feature, use the

“No service,” “Network failure,” or “Not done” displays

• The network connection has been lost. You may be in a weak signal area. Move and try again.

PIN check

menu.

Page 81

• You are trying to access an option for which you have no subscription with your service provider. Contact the service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right cellular network.

• Be sure that you have not restricted outgoing calls.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ] pressed for more than one second.)

• Be sure that you are accessing the correct cellular network.

• Be sure that you have not restricted incoming calls.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the microphone.

• Be sure that you are holding the phone close enough to your mouth. The microphone is located at the bottom of the phone.

The phone starts beeping and “Low battery warning!” flashes on the display

• Your battery is insufficiently charged. Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display ( ). The number of bars indicates the signal strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a window if you are in a building.

No number is dialled when you re-call a Phonebook entry

•Use the

• Re-store the number, if necessary.

Find

stored correctly.

menu to ensure the number has been

Solve problems

Page 82

The battery doesn’t charge properly or the phone sometimes turns itself off

• Wipe the charging contacts both on the phone and on the battery with a clean soft cloth.

If the above guidelines do not help you to solve the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

• Then contact your local dealer or Samsung aftersales service.

Health and safety information

Exposure to Radio Frequency (RF) Signals

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on the safety standards that were developed by independent scientific organizations through periodic and through evaluation of scientific studies.

The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless phones employs a unit of measurement known as Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6W/kg*.

Page 83

SAR tests are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the phone.

* In the U.S. and Canada, the SAR limit for mobile phones used

by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

Before a new model phone is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID printed in the label on the phone.

Health and safety information

Page 84

Health and safety information

For Body Operation

For body worn operation, this model phone has been tested and meets the FCC RF exposure guidelines when used with a Samsung-supplied or approved accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum from the body.

• The minimum distance from the body for this model phone is written in the FCC certification information.

• Non compliance with the above conditions may violate FCC RF exposure guidelines.

• For more Information concerning exposure to radio frequency signals, see the following websites:

• Federal Communications Commission (FCC) http://www.fcc.gov/oet/rfsafety

• Cellular Telecommunications Industry Association (CTIA): http://www.wow-com.com

• U.S.Food and Drug Administration (FDA) http://www.fda.gov/cdrh/consumer

• World Health Organization (WHO) http://www.who.int/peh-emf/en

Precautions When Using Batteries

• Never use any charger or battery that is damaged in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base station, it uses less power; talk and standby time are greatly affected by the signal strength on the cellular network and the parameters set by the network operator.

• Battery charging time depends on the remaining battery charge and the type of battery and charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time, including talk time and standby time, is noticeably shorter than normal, it is time to buy a new battery.

• If left unused, a fully charged battery will discharge itself over time.

Page 85

• Use only Samsung-approved batteries and recharge your battery only with Samsungapproved chargers. When a charger is not in use, disconnect it from the power source. Do not leave the battery connected to a charger for more than a week, since overcharging may shorten its life.

• Extreme temperatures will affect the charging capacity of your battery: it may require cooling or warming first.

• Do not leave the battery in hot or cold places, such as in a car in summer or winter conditions, as you will reduce the capacity and life-time of the battery. Always try to keep the battery at room temperature. A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged. Li-ion batteries are particularly affected by temperatures below 0 °C (32 °F).

• Do not short-circuit the battery. Accidental short circuiting can occur when a metallic object (coin, clip or pen) causes a direct connection between the + and – terminals of the battery (metal strips on the battery), for example when you carry a spare battery in a pocket or bag. Short-circuiting the terminals may damage the battery or the object causing the short-circuit.

• Dispose of used batteries in accordance with local regulations. Always recycle. Do not dispose of batteries in a fire.

Road Safety

Your wireless phone gives you the powerful ability to communicate by voice, almost anywhere, anytime. But an important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When driving a car, driving is your first responsibility. When using your wireless phone behind the wheel of a car, make sure that you are following the special regulations in a given area or country.

Health and safety information

Page 86

Health and safety information

Operating Environment

Remember to follow any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

When connecting the phone or any accessory to another device, read its user’s guide for detailed safety instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position (held to your ear with the antenna pointing over your shoulder).

Electronic Devices

Most modern electronic equipment are shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Consult the manufacturer of the device to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a minimum distance of 15 cm (6 inches) be maintained between a wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research.

Persons with pacemakers:

• should always keep the phone more than 15 cm (6 inches) from their pacemaker when the phone is switched on;

• should not carry the phone in a breast pocket;

• should use the ear opposite the pacemaker to minimise potential interference.

• If you have any reason to suspect that interference is taking place, switch off your phone immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may wish to consult your hearing aid manufacturer to discuss alternatives.

Page 87

Other Medical Devices

If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information. Switch off your phone in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle.

You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Switch off your phone in any facility where posted notices require you to do so.

Potentially Explosive Atmosphere

Switch off your phone when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Users are advised to switch off the phone while at a refuelling point (service station). Users are reminded of the need to observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants or where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include below deck on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas (such as propane or butane), areas where the air contains chemicals or particles, such as grain, dust or metal powders, and any other area where you would normally be advised to turn off your vehicle engine.

Health and safety information

Page 88

Health and safety information

Emergency Calls

This phone, like any wireless phone, operates using radio signals, wireless and landline networks as well as user-programmed functions, which cannot guarantee connection in all conditions. Therefore, you should never rely solely on any wireless phone for essential communications (medical emergencies, for example).

Remember, to make or receive any calls the phone must be switched on and in a service area with adequate signal strength. Emergency calls may not be possible on all wireless phone networks or when certain network services and/or phone features are in use. Check with local service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present location. Emergency numbers vary by location.

3. Press [ ].

When making an emergency call, remember to give all the necessary information as accurately as possible. Remember that your phone may be the only means of communication at the scene of an accident; do not cut off the call until given permission to do so.

Other Important Safety Information

• Only qualified personnel should service the phone or install the phone in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty applicable to the device.

• Check regularly that all wireless phone equipment in your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases or explosive materials in the same compartment as the phone, its parts or accessories.

• For vehicles equipped with an air bag, remember that an air bag inflates with great force. Do not place objects, including both installed or portable wireless equipment in the area over the air bag or in the air bag deployment area. If wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Page 89

• Switch off your phone before boarding an aircraft. The use of wireless phones in aircraft may be dangerous to the operation of the aircraft, and is illegal.

• Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both.

Care and Maintenance

Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill any warranty obligations and allow you to enjoy this product for many years.

• Keep your phone and all its parts and accessories out of the reach of small children and pets. They may accidentally damage these things or choke on small parts.

• Keep the phone dry. Precipitation, humidity, and liquids contain minerals that corrode electronic circuits.

• Do not use the phone with a wet hand. Doing so may cause an electric shock to you or damage to the phone.

• Do not use or store the phone in dusty, dirty areas, as its moving parts may be damaged.

• Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the phone in cold areas. When the phone warms up to its normal operating temperature, moisture can form inside the phone, which may damage the phone’s electronic circuit boards.

• Do not drop, knock, or shake the phone. Rough handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone. Wipe it with a soft cloth slightly dampened in a mild soap-andwater solution.

Health and safety information

Page 90

Health and safety information

• Do not paint the phone. Paint can clog the device’s moving parts and prevent proper operation.

• Do not put the phone in or on heating devices, such as a microwave oven, stove, or radiator. The phone may explode when overheated.

• When the phone or battery gets wet, the label indicating water damage inside the phone changes colour. In this case, phone repairs are no longer guaranteed by the manufacturer's warranty, even if the warranty for your phone has not expired.

• If your phone has a flash or light, do not use it too close to the eyes of people or animals. This may cause damage to their eyes.

• Use only the supplied or an approved replacement antenna. Unauthorised antennas or modified accessories may damage the phone and violate regulations governing radio devices.

• If the phone, battery, charger, or any accessory is not working properly, take it to your nearest qualified service facility. The personnel there will assist you, and if necessary, arrange for service.

Page 91

Licensed by QUALCOMM Incorporated under one or more of the following Patents.

U.S Patent No. 4,901,307 5,056,109 5,099,204

5,101,501 5,103,459 5,107,225

5,109,390

Page 92

Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

World Wide Web http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-08685A

English. 11/2005. Rev 1.0.
