8. Exploded View and its Parts List
8-1 Cellular Phone Exploded View
8-2 Cellular Phone Parts List
8-3 Rapid Charger Exploded View
8-4 Rapid Charger Parts List
8-5 Hands-Free Kit Exploded View
8-6 Hands-Free Kit Parts List
8-7 Cradle Exploded View
8-8 Cradle Parts List
8-9 Main Packing Layout
8-10 Main Packing Parts List
8-11 Hands-Free Kit Packing Layout
8-12 Hands-Free Kit Packing Parts List
Page 2
Page 3
Exploded View and its Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 TAPE WINDOW BOHO 961 160150AA 1
2 PMO-WINDOW LCD GH72-40968A 1
3 TAPE WINDOW FOAM GH74-10544A 1
4 LOGO BADGE GA68-20508A 1
5 PMO-FLIP COVER GH72-40986A 1
6 MAGNETIC FLIP 937 312008AA 1
7 LABEL -FLIP GA68-30545A 1
8 PMO-REFLECTOR LED GH72-40971A 1
9 PMO-FRONT COVER GH72-41409A 1
10 STRIP FINGER (M) GH71-10549A 2
11 STRIP FINGER (S) GH71-10550A 3
12 BUZZER COVER GH72-10503A 1
13 VIBRATOR 3101-001003 1
14 SPEAKER -TAPE GH74-10546A 1
15 KNOB -VOLUME GH73-40534A 1
16 SPONGE -LCD GH74-10547A 1
17 COVER CONNECTOR GH73-40537A 1
18 HINGE -HOUSING GH72-40969A 2
19 SHAFT -HINGE GH72-40725A 2
20 CAM -HINGE GH72-40724A 2
21 SPRING -HINGE GH70-10524A 2
22 HOUSING -CAP GH72-40727A 2
23 HOLDER -MIC GH73-40536A 1
24 KEY -PAD GH73-40627A 1
25 MAIN KEY PAD ASS'Y GH59-10009A 1
26 HOLDER -BUZZER GH73-40568A 1
27 SHIELD COVER-R/F GH72-40970A 1
28 SPONGE MIC GH74-10526A 1
29 MAIN PBA GH92-00660A 1
30 STRIP -FINGER GH71-10551A 1
31 STRIP -FINGER (L) GH71-10548A 7
32 TAPE-FOAM GH74-10002A 1
33 MEMORY PBA GH92-01003A 1
34 HOLDER PLATE GH71-10009A 2
35 SPONGE MEMORY GH74-10554A 1
36 CONTACT PLATE GH71-10576A 1
37 ANT, WHIP-HELICAL, 824-894M GH42-10500A 1
38 CONTACT BRACKET-ANT GH71-10572A 1
39 LABEL QUALCOMM GH68-30799A 1
40 PMO-REAR COVER GH72-41349A 1
41 SPRING LOCKER -MAIN GH70-10516A 1
42 LOCKER -MAIN GH72-40715A 1
43 MAS, BH, STAR, M2, L8, CBLK 6001-000101 4
44 LABEL ID -MAIN GH68-31033A 1
45 CLOTH POLYESTER 0107-001004 1
46 STANDARD BATT PACK GH43-10104A 1
47 LONG BATT PACK GH43-10103A 1
8-2 Cellular Phone Parts List
Page 4
Page 5
Exploded View and its Parts List
8-4 Rapid Charger Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 CASE, TOP 1
2 HOUSING, BATTERY 1
3 HOOK, PLATE (LARGE) 1
4 HOOK (B) 2
5 WASHER 4
6 VH, M2.6, L6(2W), BLK 4
7 HOOK (A) 2
8 VH, M3, L8, BLK 3
9 ASS'Y, AC POWER CORD 1
10 ASS'Y, R/C BOARD 1
11 CASE, BOTTOM 1
12 BUMPON 4
13 VH, M2.6, L12(2W), BLK 4
14 LABEL, ID, R/C 1
Page 6
Exploded View and its Parts List
8-5 Hands-Free Kit Exploded View
Page 7
Exploded View and its Parts List
8-6 Hands-Free Kit Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 LABEL, LOGO, H/F GA68-30642A 1
2 HOUSING, UPPER, H/F GH97-00693A 1
3 FELT, SPEAKER, H/F GH74-10521A 1
4 AUDIO SPEAKER, C/D 3001-000186 1
5 TAPTITE, B, BH, +, M3, L6 6003-000115 4
6 PBA GH41-1056AA(100) 1
7 HEATSINK, H/F GH71-10559A 1
8 TAPTITE, B, BH, +, M2.6, L5 6003-000106 3
9 HOUSING, LOWER, H/F GH97-00694A 1
10 TAPTITE, B, BH, +, M3, L12 6003-000161 4
11 LABEL, ID, HFK GH68-30841A 1
Page 8
Exploded View and its Parts List
8-7 Cradle Exploded View
Page 9
Exploded View and its Parts List
8-8 Cradle Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 HOLDER, CRADLE GH72-40622A 1
2 TAPTITE, B, BH, +, M2, L6, C BLK 6002-000342 1
3 TAPTITE, B, BH, +, M2.6, L6, C BLK 6003-000107 6
4 FRAME GH72-40741A 1
5 HOUSING, UPPER GH72-40739A 1
6 SOCKET, PLATE GH70-10526A 1
7 LOCKER GH72-40742A 2
8 SPRING, TORTION GH70-10527A 2
9 EJECTOR GH72-40743A 1
10 SPRING, EJECTOR GH70-10520A 2
11 PBA, CRADLE GH41-10573A 1
12 HOUSING, LOWER GH72-40740A 1
13 MAS, B, BH, +, M3, L8 6001-000133 1
14 DATA CABLE GH81-10504A 1
15 CURL CORD GH39-60506A 1
16 LABEL, ID GH68-30832A 1
Page 10
Page 11
Exploded View and its Parts List
8-10 Main Packing Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 USERS MANUAL 1
2 RAPID CHARGER GH44-40034A 1
3 STANDARD BATT PACK GH43-10104A 1
4 LONG BATT PACK GH43-10103A 1
5 HANDSET GH90-01223A 1
6 CUSHION CASE GH69-20638A 1
7 GIFT BOX-MAIN GH69-11090A 1
Page 12
Exploded View and its Parts List
8-11 Hands-Free Kit Packing Layout
Page 13
Exploded View and its Parts List
8-12 Hands-Free Kit Packing Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 BOX, GIFT GH69-10842A 1
2 CUSHION, BASE GH69-20550A 1
3 ASS'Y, CABLE TIE 1
4 USER’S MANUAL, H/F GH68-60560A 1
5 ASS'Y, HANDS-FREE KIT GH90-00577A 1
6 CLAMSHELL, MOUNT 1
7 POWER CABLE GH39-10501A 1
8 ASS'Y, HANDS-FREE MICROPHONE 1
9 BRACKET, MOUNTING GH72-40628A 1
10 ASS'Y, SCREW 1
11 ASS'Y, CRADLE GH90-00578A 1
Page 14
Exploded View and its Parts List
