Samsung SCC-B5310, SCC-B5311, SCC-B5315, SCC-B5313 User Manual

Specifications

Model

Camera Type 1/3" Day & Night Color Fixed Dome Camera
Image Device Super-HAD IT CCD

Scanning System
Minimum Scene Color 0.001Lux 0.002(Sens up 128X,15IRE)Lux
Illumination
Functions Day & Night Yes(Electric)

Horizontal Resolution 330TV Lines 540TV Lines
Video Output VBS 1.0Vp-p (75Ω, composite)
Lens Focal Length 3.8mm 3.0mm 8.0mm

Operating Temperature -10°C~50°C
Operating Humidity Within 90% RH
Power Requirement AC24V / DC12V compatible
Power Consumption 1.6W
Weight 190g
Dimensions 102(ø) x 78(H)mm
Body Color White SCC-B5310 SCC-B5311 SCC-B5313 SCC-B5315

SCC-B5310 is only available in NTSC.

*

Effective NTSC
Pixels PAL

B/W 0.001Lux 0.002(Sens up 128X,15IRE)Lux

Sens Up(LSS) Off, AUTO 128X
H/V Reverse Yes(On/Off)
DNR Yes(On/Off)

Viewing Horizontal 71° 92° 33.6°
Angle Vertical 53° 72° 25.3°
PAN / TILT 0°~340° / 0°~90°

Black SCC-B5310B SCC-B5311B SCC-B5313B SCC-B5315B

SCC-B5310

510(H) x 492(V)
500(H) x 582(V)
NTSC : 525 Line, 2:1 Interlace / PAL : 625 Line, 2:1 Interlace

SCC-B5311 SCC-B5313 SCC-B5315

768(H) x 494(V)
752(H) x 582(V)
