SAMSUNG S3C6410X User Guide

USER'S MANUAL

S3C6410X

RISC Microprocessor

Feb 13, 2009

REV 1.20

Samsung Electronics Co., Ltd

Important Notice

The information in this publication has been carefully checked and is believed to be entirely accurate at the time of publication. Samsung assumes no responsibility, however, for possible errors or omissions, or for any consequences resulting from the use of the information contained herein.

Samsung reserves the right to make changes in its products or product specifications with the intent to improve function or design at any time and without notice and is not required to update this documentation to reflect such changes.

This publication does not convey to a purchaser of semiconductor devices described herein any license under the patent rights of Samsung or others.

Samsung makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does Samsung assume any liability arising out of the application or use of any product or circuit and specifically disclaims any and all liability, including without limitation any consequential or incidental damages.

S3C6410X RISC Microprocessor

User's Manual, Revision 1.20

"Typical" parameters can and do vary in different applications. All operating parameters, including "Typicals" must be validated for each customer application by the customer's technical experts.

Samsung products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, for other applications intended to support or sustain life, or for any other application in which the failure of the Samsung product could create a situation where personal injury or death may occur.

Should the Buyer purchase or use a Samsung product for any such unintended or unauthorized application, the Buyer shall indemnify and hold Samsung and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, expenses, and reasonable attorney fees arising out of, either directly or indirectly, any claim of personal injury or death that may be associated with such unintended or unauthorized use, even if such claim alleges that Samsung was negligent regarding the design or manufacture of said product.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electric or mechanical, by photocopying, recording, or otherwise, without the prior written consent of Samsung Electronics Co.,Ltd.

Samsung Electronics Co., Ltd.

San #24 Nongseo-Dong, Giheung-Gu Yongin-City Gyeonggi-Do, Korea 446-711

Home Page: http://www.samsungsemi.com/

E-Mail: mobilesol.cs@samsung.com

Printed in the Republic of Korea

Revision History

Revision No	Description of Change	Refer to	Author(s)		Date
1.00	- Public Release	-	W.J.Kim	July	18, 2008
1.10	Overview, System Controller, GPIO,	Errata Rev1.00	W.J.Kim	Aug	22, 2008
	CAMIF, IISBUSI/F, Key I/F, IIS Multi
	Audio I/F, Electrical Data has been
	modified
1.20	System Controller, DRAMC, OneNAND	Errata Rev1.10	C.G.Oh	Feb	13, 2009
	Controller, DMAC, TV Encoder, CAMIF,
	Modem Interface, USB2.0 HS OTG,
	SDMMC, SPI, PWM, IIS Bus Interface,
	PCM Audio Interface, Key Interface, IIS
	Multi Audio Interface, and Electrical
	DATA has been modified.

S3C6410X_USER’S MANUAL_REV 1.20

iii

Table of Contents

Chapter 1	Product Overview
1.1 Architectural Overview ............................................................................................................................		1-1
1.2 Features ..................................................................................................................................................		1-2
1.2.1 S3C6410X RISC Microprocessor Features Summary ....................................................................		1-3
1.2.2 Microprocessor ................................................................................................................................		1-4
1.2.3 Memory Subsystem .........................................................................................................................		1-5
1.2.3.1 SROM Memory Port configurable to support the following memory types: .............................		1-5
1.2.3.2 DRAM port configurable to support the following memory types: ............................................		1-6
1.2.4 Multimedia Acceleration...................................................................................................................		1-6
1.2.4.1 Camera Interface......................................................................................................................		1-6
1.2.4.2 Multi Format Codec (MFC) .......................................................................................................		1-7
1.2.4.3 JPEG Codec .............................................................................................................................		1-7
1.2.5 2D Graphics Accelerator..................................................................................................................		1-7
1.2.6 3D Graphics Accelerator..................................................................................................................		1-8
1.2.6 Image Rotator ..................................................................................................................................		1-8
1.2.7 Display Control.................................................................................................................................		1-9
1.2.7.1 TFT LCD Interface....................................................................................................................		1-9
1.2.7.2 Video Post Processor ...............................................................................................................		1-9
1.2.7.3 TV (NTSC/PAL) Video Encoder with Image Enhancer ............................................................		1-9
1.2.8 Audio Interface .................................................................................................................................		1-9
1.2.8.1 AC97 Controller ........................................................................................................................		1-9
1.2.8.2 PCM serial Audio Interface.......................................................................................................		1-9
1.2.8.3 IIS-Bus Interface .......................................................................................................................		1-10
1.2.9 USB Support	....................................................................................................................................	1-10
1.2.9.1 USB OTG 2.0 High Speed........................................................................................................		1-10
1.2.9.2 USB Host ..................................................................................................................................		1-10
1.2.10 IrDA v1.1 ........................................................................................................................................		1-10
1.2.11 Serial Communication....................................................................................................................		1-10
1.2.11.1 UART ......................................................................................................................................		1-10
1.2.11.2 IIC-Bus Interface.....................................................................................................................		1-11
1.2.11.3 SPI Interface ...........................................................................................................................		1-11
1.2.11.4 MIPI HSI .................................................................................................................................		1-11
1.2.12 Modem & HOST Interface..............................................................................................................		1-11
1.2.12.1 Parallel Modem Chip Interface ...............................................................................................		1-11
1.2.12.1 Host Interface .........................................................................................................................		1-11
1.2.13 GPIO (General Purpose I/O)..........................................................................................................		1-12
1.2.14 Input Devices .................................................................................................................................		1-12
1.2.14.1 Keypad Interface.....................................................................................................................		1-12
1.2.14.2 A/D Converter and Touch Screen Interface ...........................................................................		1-12

iv	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents

Chapter 1		Product Overview
1.2.15 Storage Devices ............................................................................................................................			1-12
	1.2.15.1 SD/MMC Host Controller........................................................................................................		1-12
1.2.16 System Peripherals........................................................................................................................			1-12
	1.2.16.1 DMA controller........................................................................................................................		1-12
	1.2.16.2 Vectored Interrupt Controller..................................................................................................		1-13
	1.2.16.3 TrustZone Protection Controller .............................................................................................		1-13
	1.2.16.4 Timer with PWM (Pulse Width Modulation) ...........................................................................		1-13
	1.2.16.5 16-bit Watchdog Timer...........................................................................................................		1-13
	1.2.16.6 RTC (Real Time Clock) ..........................................................................................................		1-13
1.2.17 security sub-system.......................................................................................................................			1-13
1.2.18 System Management.....................................................................................................................			1-14
1.2.19 System Operating Frequencies.....................................................................................................			1-14
1.3	Power Management................................................................................................................................		1-15
1.4	Electrical Characteristics.........................................................................................................................		1-15
1.5	Package ..................................................................................................................................................		1-15
1.6	Pin Assignments .....................................................................................................................................		1-16
1.7	Pin Description ........................................................................................................................................		1-36
1.7.1 External Memory Interface ..............................................................................................................			1-36
1.7.2 Serial Communication .....................................................................................................................			1-39
1.7.3 Parallel Communication...................................................................................................................			1-43
1.7.4 Modem Interface..............................................................................................................................			1-44
1.7.5 Image/Video Processing..................................................................................................................			1-46
1.7.6 Display Control ................................................................................................................................			1-47
1.7.7 Storage Devices ..............................................................................................................................			1-49
1.7.8 System Management.......................................................................................................................			1-51
1.8	Power-supply Groups .............................................................................................................................		1-53

Chapter 2		Memory Map
2.1	Memory System Block Diagram..............................................................................................................		2-1
2.2	Device Specific Address Space..............................................................................................................		2-3
Chapter 3		System Controller
3.1	Overview	.................................................................................................................................................	3-1
3.2	Features ..................................................................................................................................................		3-2
3.3	Functional .............................................................................................................................description		3-2
3.3.1 Hardware .....................................................................................................................architecture			3-2
3.3.2 Clock ............................................................................................................................Architecture			3-3
3.3.3 Clock .....................................................................................................................source selection			3-4

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 3	System Controller
3.3.4 Phase Locked Loop (PLL) ...............................................................................................................		3-4
3.3.4.1 Clock selection between PLLs and input reference clock........................................................		3-5
3.3.4.2 ARM and AXI/AHB/APB bus clock generation .........................................................................		3-6
3.3.4.3 MFC clock generation...............................................................................................................		3-7
3.3.4.4 Camera I/F clock generation ....................................................................................................		3-8
3.3.4.5 Clock generation for display (POST, LCD, and scaler)............................................................		3-8
3.3.4.6 Clock generation for audio (IIS and PCM)................................................................................		3-8
3.3.4.7 Clock generation for UART, SPI, and MMC .............................................................................		3-9
3.3.4.8 Clock generation for IrDA, USB host........................................................................................		3-9
3.3.4.9 Clock ON/OFF control ..............................................................................................................		3-10
3.3.4.10 Clock output............................................................................................................................		3-10
3.3.5 Low Power Mode Operation ............................................................................................................		3-10
3.3.5.1 Power domain in S3C6410X ....................................................................................................		3-11
3.3.5.2 NORMAL/IDLE mode ...............................................................................................................		3-11
3.3.5.3 STOP mode ..............................................................................................................................		3-12
3.3.5.4 DEEP-STOP mode ...................................................................................................................		3-13
3.3.5.5 SLEEP mode ............................................................................................................................		3-13
3.3.5.6 Wakeup.....................................................................................................................................		3-15
3.3.5.7 Reset ........................................................................................................................................		3-15
3.3.5.8 Hardware reset .........................................................................................................................		3-15
3.3.5.9 Watchdog reset.........................................................................................................................		3-16
3.3.5.10 Wakeup reset..........................................................................................................................		3-17
3.3.6 MISCELENEOUS.............................................................................................................................		3-17
3.4 REGISTER DESCRIPTION ....................................................................................................................		3-18
3.4.1 Memory map	....................................................................................................................................	3-18
3.4.2 INDIVIDUAL REGISTER DESCRIPTIONS .....................................................................................		3-20
3.4.2.1 PLL Control Registers ..............................................................................................................		3-20
3.4.2.2 Clock source control register....................................................................................................		3-24
3.4.2.3 Clock divider control register ....................................................................................................		3-26
3.4.2.4 Clock output configuration register...........................................................................................		3-28
3.4.2.5 Clock gating control register .....................................................................................................		3-29
3.4.2.6 AHB bus control register...........................................................................................................		3-33
3.4.2.7 Secure DMA control register ....................................................................................................		3-37
3.4.2.8 System ID register ....................................................................................................................		3-38
3.4.2.9 System Others register.............................................................................................................		3-38
3.4.2.10 Memory controller status register ...........................................................................................		3-39
3.4.2.11 Power mode control register...................................................................................................		3-43
3.4.2.12 System stabilization counter...................................................................................................		3-46
3.4.2.13 Cacheable bus transaction selection register ........................................................................		3-47
3.4.2.14 Others control register ............................................................................................................		3-48
3.4.2.15 Status register.........................................................................................................................		3-50
3.4.2.16 Information register.................................................................................................................		3-51

vi	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 4	Memory Sub-system
4.1. Overview.................................................................................................................................................		4-1
4.2. Introduction.............................................................................................................................................		4-1
4.3. Structure .................................................................................................................................................		4-2
4.4. AHB slave interface (SFR) .....................................................................................................................		4-2
4.5. AHB slave interface (SPINE)..................................................................................................................		4-3
4.6. EBI Multiplexing......................................................................................................................................		4-5
4.7. Configuration Options.............................................................................................................................		4-7
4.8. Use of wide address spaces for SROM Controller (Using dram 1 PORT) ............................................		4-8
4.9. Sharing Chip Select for memory port 0 ..................................................................................................		4-9
4.10.Remapping............................................................................................................................................		4-15
4.11.Address decoding .................................................................................................................................		4-16

Chapter 5	DRAM Controller
5.1 Overview	.................................................................................................................................................	5-1
5.2 Features ..................................................................................................................................................		5-2
5.3 SDRAM Memory ......................................................................................................................interface		5-3
5.4 SDRAM Initialization ..............................................................................................................Sequence		5-4
5.4.1 DRAM ........................................................................................Controller Initialization Sequence		5-4
5.4.2 SDR/mobile ..........................................................................SDR SDRAM Initialization Sequence		5-4
5.4.3 DDR/mobile .........................................................................DDR SDRAM Initialization Sequence		5-4
5.5 Register Description................................................................................................................................		5-5
5.5.1 DRAM ....................................................................................................Controller Status Register		5-5
5.5.2 DRAM .............................................................................................Controller Command Register		5-5
5.5.3 Direct ...............................................................................................................Command Register		5-6
5.5.4 Memory .......................................................................................................Configuration Register		5-7
5.5.5 Refresh ..................................................................................................................Period Register		5-8
5.5.6 CAS .....................................................................................................................Latency Register		5-8
5.5.7 T_DQSS ............................................................................................................................Register		5-9
5.5.8 T_MRD ..............................................................................................................................Register		5-9
5.5.9 T_RAS ...............................................................................................................................Register		5-9
5.5.10 T_RC ...............................................................................................................................Register		5-10
5.5.11 T_RCD ............................................................................................................................Register		5-10
5.5.12 T_RFC .............................................................................................................................Register		5-10
5.5.13 T_RP ...............................................................................................................................Register		5-10
5.5.14 T_RRD ............................................................................................................................Register		5-11
5.5.15 T_WR ..............................................................................................................................Register		5-11
5.5.16 T_WTR ............................................................................................................................Register		5-11
5.5.17 T_XP ...............................................................................................................................Register		5-12
5.5.18 T_XSR .............................................................................................................................Register		5-12
5.5.19 T_ESR .............................................................................................................................Register		5-12
5.5.20 Memory ....................................................................................................configuration 2 register		5-13
5.5.21 Memory ....................................................................................................configuration 3 register		5-14
5.5.22 ID_N ......................................................................................................................_CFG Register		5-14
5.5.23 CHIP ................................................................................................................._N_CFG Register		5-15
5.5.24 USER .............................................................................................................._STATUS Register		5-16
5.5.25 USER .............................................................................................................._CONFIG Register		5-16

S3C6410X_USER’S MANUAL_REV 1.20

vii

Table of Contents (Continued)

Chapter 6		SROM Controller
6.1	Overview..................................................................................................................................................		6-1
6.2	Feature ....................................................................................................................................................		6-1
6.3	Block Diagram .........................................................................................................................................		6-2
6.4	SROM Controller Function Description ...................................................................................................		6-2
6.4.1 nWAIT Pin Operation .......................................................................................................................			6-2
6.5	Programmable Access Cycle ..................................................................................................................		6-3
6.6	Special Function Registers......................................................................................................................		6-4
6.6.1 SROM Bus Width & Wait Contrl Register(SROM_BW)...................................................................			6-4
6.6.2 SROM Bank Control Register (SROM_BC : XrCSn0 ~ XrCSn2) ....................................................			6-6

Chapter 7 OneNAND Controller

7.1	Overview..................................................................................................................................................	7-1
7.2	Feature ....................................................................................................................................................	7-1
7.3	Block Diagram .........................................................................................................................................	7-2
7.4	Signal Description ...................................................................................................................................	7-3
7.4.1 External Memory Interface...............................................................................................................		7-3
7.5	Input Clocks.............................................................................................................................................	7-4
7.6	Memory Address Mapping ......................................................................................................................	7-5
7.7 Command Mapping .................................................................................................................................		7-5
7.7.1 "00" = Map 00 Commands...............................................................................................................		7-5
	7.7.2 "01" = MAP 01 COMMANDS.......................................................................................................	7-6
7.7.3 "10" = Map 10 Commands...............................................................................................................		7-7
	7.7.3.1 Erase Operation........................................................................................................................	7-7
	7.7.3.2 Lock, Unlock and Lock-Tight Operations .................................................................................	7-8
	7.7.3.3 Copy Back Operations..............................................................................................................	7-9
	7.7.3.4 OTP and Spare Area Access Operations.................................................................................	7-9
	7.7.3.5 Verify Read Operations ............................................................................................................	7-10
	7.7.3.6 Pipeline Read-Ahead or Write-Ahead Operations ...................................................................	7-10
	7.7.3.7 Read/Modify/Write Operations .................................................................................................	7-11
7.7.4 "11" = Map 11 Commands...............................................................................................................		7-11
7.8	Pipeline Read/Write Ahead Command ...................................................................................................	7-12
7.8.1 Set Up a Single Area for Pipelined Read-Ahead.............................................................................		7-12
7.8.2 Set Up Multiple Areas for Pipelined Read-Ahead............................................................................		7-13
7.9 controller Usage Exception .....................................................................................................................		7-14
7.10 Boot with OneNAND Controller.............................................................................................................		7-14
7.11 Register Description ..............................................................................................................................		7-15
7.11.1 Memory Map ..................................................................................................................................		7-15

viii	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 7	OneNAND Controller
7.12 Individual Register Descriptions ...........................................................................................................		7-18
7.12.1 Memory Device Configuration Register.........................................................................................		7-18
7.12.2 Burst Length Register....................................................................................................................		7-20
7.12.3 Memory Reset Register.................................................................................................................		7-20
7.12.4 Interrupt Error Status Register.......................................................................................................		7-21
7.12.5 Interrupt Error Mask Register ........................................................................................................		7-22
7.12.6 Interrupt Error Acknowledge Register ...........................................................................................		7-23
7.12.7 Ecc Error Status Register ..............................................................................................................		7-23
7.12.8 Manufacturer Id Register ...............................................................................................................		7-24
7.12.8 Device Id Register .........................................................................................................................		7-24
7.12.10 Data Buffer Size Register ............................................................................................................		7-25
7.12.11 Boot Buffer Size Register ............................................................................................................		7-25
7.12.12 Amount Of Buffer Register ..........................................................................................................		7-25
7.12.13 Technology Register....................................................................................................................		7-26
7.12.14 FBA Width Register .....................................................................................................................		7-26
7.12.15 FPA Width Register .....................................................................................................................		7-26
7.12.16 FSA Width Register .....................................................................................................................		7-27
7.12.17 Revision Register ........................................................................................................................		7-27
7.12.18 Dataram0 Code Register.............................................................................................................		7-27
7.12.19 Dataram1 Code Register.............................................................................................................		7-28
7.12.20 Synchronous Mode Register .......................................................................................................		7-28
7.12.21 Transfer Spare Register ..............................................................................................................		7-29
7.12.22 DBS-DFS Width Register ............................................................................................................		7-29
7.12.23 Page Count Register ...................................................................................................................		7-29
7.12.24 Error Page Address Register.......................................................................................................		7-30
7.12.25 Burst Read Latency Register.......................................................................................................		7-30
7.12.26 Interrupt Pin Enable Register ......................................................................................................		7-30
7.12.27 Interrupt Monitor Cycle Register..................................................................................................		7-31
7.12.28 Access Clock Register.................................................................................................................		7-31
7.12.29 Slow Read Path Register ............................................................................................................		7-32
7.12.30 Error Block Address Register ......................................................................................................		7-32
7.12.31 Flash Version Id Register ............................................................................................................		7-32
7.12.32 Flash Auxiliary Control Register ..................................................................................................		7-33
7.12.33 Flash Asynchronous Fifo Count Register....................................................................................		7-33

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 8		NAND Flash Controller
8.1	Overview..................................................................................................................................................		8-1
8.2	Features ..................................................................................................................................................		8-1
8.3	Block Diagram .........................................................................................................................................		8-2
8.4	Nand Flash Memory Timing ....................................................................................................................		8-3
8.5	NAND Flash access ................................................................................................................................		8-4
8.6	Data Register Configuration....................................................................................................................		8-4
8.7 STEPPINGSTONE (8KB SRAM) ............................................................................................................			8-4
8.8	1-bit / 4-bit / 8-BIT ECC (Error Correction Code) .................................................................................		8-5
8.8.1 ECC module features.......................................................................................................................			8-6
8.8.2 1-bit ECC Programming Encoding and decoding............................................................................			8-7
8.8.3 4-bit ECC Programming guide (Encoding) ......................................................................................			8-7
8.8.4 4-bit ECC Programming guide (DEcoding)......................................................................................			8-8
8.8.5 8-bit ECC Programming guide (ENcoding)......................................................................................			8-8
8.8.6 8-bit ECC Programming guide (DEcoding)......................................................................................			8-9
8.9	Memory mapping(NOR-flash boot) .......................................................................................................		8-11
8.10 Nand Flash Memory Configuration .......................................................................................................			8-12
8.11 Nand Flash Controller Special Registers ..............................................................................................			8-13
8.11.1 NAND Flash controller Register map.............................................................................................			8-13
8.11.2 Nand Flash configuration Register ................................................................................................			8-14
8.11.3 Control Register .............................................................................................................................			8-15
8.11.4 Command Register ........................................................................................................................			8-17
8.11.5 Address Register ...........................................................................................................................			8-17
8.11.6 Data Register .................................................................................................................................			8-17
8.11.7 Main data area ECC Register........................................................................................................			8-18
8.11.8 Spare area ECC Register .............................................................................................................			8-18
8.11.9 progrmmable block address Register............................................................................................			8-19
8.11.10 NFCon Status Register ................................................................................................................			8-21
8.11.11 ECC0/1 Error status Register ......................................................................................................			8-22
8.11.12 Main data area ECC0 status Register .........................................................................................			8-24
8.11.13 spare area ECC status Register ..................................................................................................			8-25
8.11.14 4-bit ECC Error patten Register...................................................................................................			8-25
8.11.15 ECC 0/1/2 FOR 8bit ECC STATUS Register...............................................................................			8-26
8.11.16 8-bit ECC MAIN DATA ECC 0/1/2/3 STATUS REGISTER .........................................................			8-28
8.11.17 8-bit ECC ERROR PATTERN REGISTER ..................................................................................			8-29

x	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 9	CF Controller
9.1 Overview .................................................................................................................................................		9-1
9.2 Features ..................................................................................................................................................		9-1
9.2.1 The CF controller features:..............................................................................................................		9-1
9.2.2 The PC card controller features:......................................................................................................		9-1
9.2.3 The ATA controller features:............................................................................................................		9-2
9.3 I/O description .........................................................................................................................................		9-3
9.4 Block Diagram.........................................................................................................................................		9-5
9.4.1 CF Controller Block Diagram..........................................................................................................		9-5
9.5 Timing Diagram.......................................................................................................................................		9-6
9.5.1 PC Card Mode .................................................................................................................................		9-6
9.5.2 True-IDE Mode ................................................................................................................................		9-7
9.5.3 UDMA Mode	....................................................................................................................................	9-8
9.6 Special Function Registers .....................................................................................................................		9-11
9.6.1 Memory Map	....................................................................................................................................	9-11
9.6.2 Register address Table ...................................................................................................................		9-12
9.6.3 Individual Register Descriptions ......................................................................................................		9-13
9.6.3.1 MUX_REG................................................................................................................................		9-13
9.6.3.2 PCCARD_CNFG&STATUS .....................................................................................................		9-14
9.6.3.3 PCCARD_INTMSK&SRC ........................................................................................................		9-15
9.6.3.3 PCCARD_INTMSK&SRC ........................................................................................................		9-15
9.6.3.4 PCCARD_ATTR.......................................................................................................................		9-16
9.6.3.5 PCCARD_I/O ...........................................................................................................................		9-16
9.6.3.6 PCCARD_COMM.....................................................................................................................		9-17
9.6.3.7 ATA_CONTROL.......................................................................................................................		9-18
9.6.3.7 ATA_CONTROL.......................................................................................................................		9-18
9.6.3.8 ATA_STATUS ..........................................................................................................................		9-18
9.6.3.9 ATA_COMMAND .....................................................................................................................		9-19
9.6.3.9 ATA_COMMAND .....................................................................................................................		9-19
9.6.3.10 ATA_SWRST .........................................................................................................................		9-20
9.6.3.11 ATA_IRQ ................................................................................................................................		9-20
9.6.3.12 ATA_IRQ_MASK....................................................................................................................		9-21
9.6.3.13 ATA_CFG...............................................................................................................................		9-22
9.6.3.13 ATA_CFG...............................................................................................................................		9-22
9.6.3.14 ATA_PIO_TIME......................................................................................................................		9-23
9.6.3.15 ATA_UDMA_TIME .................................................................................................................		9-24
9.6.3.16 ATA_XFR_NUM .....................................................................................................................		9-25
9.6.3.17 ATA_XFR_CNT......................................................................................................................		9-25
9.6.3.18 ATA_TBUF_START ...............................................................................................................		9-25
9.6.3.19 ATA_TBUF_SIZE ...................................................................................................................		9-26
9.6.3.20 ATA_SBUF_START ...............................................................................................................		9-26
9.6.3.21 ATA_SBUF_SIZE...................................................................................................................		9-26
9.6.3.22 ATA_CADDR_TBUR..............................................................................................................		9-27
9.6.3.23 ATA_CADDR_SBUF..............................................................................................................		9-27
9.6.3.24 ATA_PIO_DTR.......................................................................................................................		9-27
9.6.3.25 ATA_PIO_FED .......................................................................................................................		9-28

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 9	CF Controller
9.6.3.26 ATA_PIO_SCR .......................................................................................................................		9-28
9.6.3.27 ATA_PIO_LLR ........................................................................................................................		9-28
9.6.3.28 ATA_PIO_LMR .......................................................................................................................		9-29
9.6.3.29 ATA_PIO_LHR .......................................................................................................................		9-29
9.6.3.30 ATA_PIO_DVR .......................................................................................................................		9-29
9.6.3.31 ATA_PIO_CSD .......................................................................................................................		9-30
9.6.3.32 ATA_PIO_DAD .......................................................................................................................		9-30
9.6.3.33 ATA_PIO_RDATA ..................................................................................................................		9-30
9.6.3.34 BUS_FIFO_STATUS..............................................................................................................		9-31
9.6.3.35 ATA_FIFO_STATUS ..............................................................................................................		9-31

Chapter 10	GPIO
10.1 Overview................................................................................................................................................		10-1
10.2 Features ................................................................................................................................................		10-1
10.3 Description.............................................................................................................................................		10-2
10.4 Register Description ..............................................................................................................................		10-3
10.4.1 Memory Map ..................................................................................................................................		10-3
10.5 Individual Register Descriptions............................................................................................................		10-7
10.5.1 Port A Control Register ..................................................................................................................		10-7
10.5.2 Port B Control Register ..................................................................................................................		10-9
10.5.3 Port C Control Register..................................................................................................................		10-11
10.5.4 Port D Control Register..................................................................................................................		10-13
10.5.5 Port E Control Registers ................................................................................................................		10-15
10.5.6 Port F Control Registers ................................................................................................................		10-17
10.5.7 Port G Control Registers................................................................................................................		10-19
10.5.8 Port H Control Registers ................................................................................................................		10-21
10.5.9 Port I Control Registers..................................................................................................................		10-23
10.5.10 Port J Control Registers...............................................................................................................		10-25
10.5.11 Port K Control Registers ..............................................................................................................		10-27
10.5.12 Port L Control Registers...............................................................................................................		10-30
10.5.13 Port M Control Registers..............................................................................................................		10-33
10.5.14 Port N Control Registers ..............................................................................................................		10-34
10.5.15 Port O Control Registers..............................................................................................................		10-36
10.5.16 Port P Control Registers ..............................................................................................................		10-38
10.5.17 Port Q Control Registers..............................................................................................................		10-40
10.5.18 Special Port Control Register ......................................................................................................		10-42
10.5.19 Memory Interface Pin Configuration Register in Stop Mode .......................................................		10-46
10.5.20 Memory Interface Pin Configuration Register in Sleep Mode .....................................................		10-48
10.5.21 Memory Interface Drive Strength Control Register......................................................................		10-51
10.5.22 External Interrupt Control Registers ............................................................................................		10-53
10.6 Current Service REGISTER (SERVICE)...............................................................................................		10-73
10.6.1 Extern Pin Configuration Register in Sleep Mode ........................................................................		10-74

xii	S3C6410X_USER’S MANUAL_REV 1.20

	Table of Contents (Continued)
Chapter 11	DMA Controller
11.1 Overview ...............................................................................................................................................		11-1
11.2 Features ................................................................................................................................................		11-2
11.3 block diagram........................................................................................................................................		11-3
11.4 DMA sources.........................................................................................................................................		11-4
11.5 DMA interface .......................................................................................................................................		11-5
11.5.1 DMA request signals .....................................................................................................................		111-5
11.5.2 DMA response signals...................................................................................................................		11-5
11.5.3 Transfer types................................................................................................................................		11-5
11.5.3.1 Peripheral-to-memory transaction under DMA controller flow control ...................................		11-6
11.5.3.2 Memory-to- Peripheral transaction under DMA controller flow control ..................................		11-6
11.5.3.3 Memory-to-memory transaction under DMA controller flow control ......................................		11-6
11.5.3.4 Peripheral-to-peripheral transaction under DMA controller flow control................................		11-7
11.5.4 Signal timing ..................................................................................................................................		11-8
11.6 Functional timing diagram.....................................................................................................................		11-9
11.7 Programmer's model.............................................................................................................................		11-9
11.7.1 Programming the DMA controller ..................................................................................................		11-9
11.7.2 Enabling the DMA controller..........................................................................................................		11-9
11.7.3 Disabling the DMA controller .........................................................................................................		11-9
11.7.4 Enabling a DMA channel ...............................................................................................................		11-10
11.7.5 Disabling a DMA channel ..............................................................................................................		11-10
11.7.5.1 Disabling a DMA channel and losing data in the FIFO: .........................................................		11-10
11.7.5.2 Disabling a DMA channel without losing data in the FIFO:....................................................		11-10
11.7.6 Set up a new DMA transfer ...........................................................................................................		11-10
11.7.7 Halting a DMA channel..................................................................................................................		11-10
11.7.8 Programming a DMA channel .......................................................................................................		11-11
11.8 Register Description..............................................................................................................................		11-12
11.8.1 DMA register location ....................................................................................................................		11-12
11.8.2 Interrupt status register, DMACIntStatus.......................................................................................		11-15
11.8.3 Interrupt terminal count status register, DMACIntTCStatus ..........................................................		11-15
11.8.4 Interrupt terminal count clear register, DMACIntTCClear .............................................................		11-15
11.8.5 Interrupt error status register, DMACIntErrorStatus......................................................................		11-16
11.8.6 Interrupt error clear register, DMACIntErrClr.................................................................................		11-16
11.8.7 Raw interrupt terminal counter status register, DMACRawIntTCStatus .......................................		11-16
11.8.8 Raw error interrupt status register, DMACRawIntErrorStatus ......................................................		11-17
11.8.9 Enable channel register, DMACEnbldChns ..................................................................................		11-17
11.8.10 Software burst request register, DMACSoftBReq .......................................................................		11-17
11.8.11 Software single request register, DMACSoftSReq......................................................................		11-18
11.8.14 Configuration register, DMACConfiguration................................................................................		11-19
11.8.15 Synchronization register, DMACSync .........................................................................................		11-19
11.8.16 Channel source address register, DMACCxSrcAddr ..................................................................		11-20
11.8.17 Channel destination address register, DMACCxDestAddr .........................................................		11-20
11.8.18 Channel linked list item register, DMACCxLLI ............................................................................		11-21
11.8.19 Channel control register, DMACCxControl0................................................................................		11-21
11.8.20 Channel control register, DMACCxControl1................................................................................		11-24
11.8.21 Channel configuration register, DMACCxConfiguration..............................................................		11-25
11.8.22 Channel configuration expansion register, DMACCxConfigurationExp ......................................		11-27

S3C6410X_USER’S MANUAL_REV 1.20

xiii

		Table of Contents (Continued)
Chapter 12		Vectored Interrupt Controllers
12.1	Overview................................................................................................................................................		12-1
12.2	Features ................................................................................................................................................		12-1
12.3	Interrupt Sources...................................................................................................................................		12-2
12.4	Function.................................................................................................................................................		12-5
12.4.1 Block Diagram................................................................................................................................			12-5
12.5	Summary of VIC registers .....................................................................................................................		12-6
12.6	Register Descriptions ............................................................................................................................		12-9
12.6.1 IRQ Status Register, VICIRQSTATUS ..........................................................................................			12-9
12.6.2 FIQ Status Register, VICFIQSTATUS ...........................................................................................			12-9
12.6.3 Raw Interrupt Status Register, VICRAWINTR...............................................................................			12-10
12.6.4 Interrupt Select Register, VICINTSELECT ....................................................................................			12-10
12.6.5 Interrupt Enable Register, VICINTENABLE...................................................................................			12-11
12.6.6 Interrupt Enable Clear, VICINTENCLEAR.....................................................................................			12-11
12.6.7 Software Interrupt Register, VICSOFTINT ....................................................................................			12-12
12.6.8 Software Interrupt Clear Register, VICSOFTINTCLEAR...............................................................			12-12
12.6.9 Protection Enable Register, VICPROTECTION ............................................................................			12-13
12.6.10 Software Priority Mask Register, VICSWPRIORITYMASK .........................................................			12-13
12.6.11 Vector Priority Register for Daisy Chain ......................................................................................			12-14
12.6.12 Vector Address Regisgers, VICVECTADDR[0-31]......................................................................			12-15
12.6.13 Vector Priority Registers, VICVECTPRIORITY[0-31] ..................................................................			12-15
12.6.14 Vector Address Register, VICADDRESS ....................................................................................			12-16
Chapter 13		Security SUB-Systems
13.1	Overview................................................................................................................................................		13-1
13.2	Features ................................................................................................................................................		13-1
13.3	Programming Guide ..............................................................................................................................		13-3
13.3.1 AES ................................................................................................................................................			13-3
13.3.2 TDES..............................................................................................................................................			13-4
13.3.3 SHA-1 & PRNG..............................................................................................................................			13-5
13.4	Special Function Registers ...................................................................................................................		13-6
13.4.1 Security Sub-system Register Map ...............................................................................................			13-6
13.5	DMA & Interrupt control module............................................................................................................		13-11
13.5.1 Security sub-system DMA & interrupt register...............................................................................			13-11
13.6	Security sub-system RX FIFO module..................................................................................................		13-12
13.6.1 FIFO-RX Control Register..............................................................................................................			13-12
13.6.2 FIFO-RX Message Length Register ..............................................................................................			13-13
13.6.3 FIFO-RX Block Size Register ........................................................................................................			13-13
13.6.4 FIFO-RX Destination Address Register.........................................................................................			13-13
13.6.5 FIFO-RX Message Length Counter ...............................................................................................			13-14
13.6.6 FIFO-RX Write Buffer.....................................................................................................................			13-14

xiv	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 13	Security SUB-Systems
13.7 Security sub-system TX FIFO module..................................................................................................		13-15
13.7.1 FIFO-TX Control Register..............................................................................................................		13-15
13.7.2 FIFO-TX Message Length Register ..............................................................................................		13-16
13.7.3 FIFO-TX Block Size Register ........................................................................................................		13-16
13.7.4 FIFO-TX Source Address Register ...............................................................................................		13-16
13.7.5 FIFO-TX Message Length Counter ...............................................................................................		13-16
13.7.6 FIFO-TX Read Buffer.....................................................................................................................		13-17
13.8 Security sub-system AES module.........................................................................................................		13-18
13.8.1 AES_CTRL	....................................................................................................................................	13-18
13.8.2 AES_RX_DIN_01 ~ AES_RX_DIN_01..........................................................................................		13-19
13.8.3 AES_RX_DOUT_01 ~ AES_RX_DOUT_04 / AES_TX_DOUT_01 ~ AES_TX_DOUT_04..........		13-19
13.8.4 AES_RX_KEY_01 ~ AES_RX_KEY_08........................................................................................		13-20
13.8.5 AES_RX_IV_01 ~ AES_RX_IV_04 ...............................................................................................		13-20
13.8.6 AES_RX_CTR_01 ~ AES_RX_CTR_04 .......................................................................................		13-20
13.9 Security sub-system DES/3DEs module ..............................................................................................		13-21
13.9.1 TDES_RX_CTRL...........................................................................................................................		13-21
13.9.2 TDES_RX_KEY1_0.......................................................................................................................		13-22
13.9.3 TDES_RX_INPUT_0 / TDES_RX_INPUT_1.................................................................................		13-22
13.9.4 TDES_RX_IV_0 / TDES_RX_IV_1................................................................................................		13-23
13.10 Security sub-system SHA-1/PRNG module........................................................................................		13-24
13.10.1 HASH_CONTROL .......................................................................................................................		13-24
13.10.2 HASH_DATA ...............................................................................................................................		13-24
13.10.3 SEED_DATA_01 ~ SEED_DATA_10..........................................................................................		13-25
13.10.4 HASH_STATUS...........................................................................................................................		13-25
13.10.5 HASH_OUTPUT_01 (PRNG_OUTPUT_01) ~ HASH_OUTPUT_10 (PRNG_OUTPUT_10).....		13-26
13.10.6 HASH_MIDOUT_01 ~ HASH_MIDOUT_05................................................................................		13-27
13.10.7 PRE_MSG_LENGTH_01 / PRE_MSG_LENGTH_02.................................................................		13-28

Chapter 14		Display Controller
14.1	Overview ...............................................................................................................................................		14-1
14.2	Block Diagram.......................................................................................................................................		14-1
14.3	Features ................................................................................................................................................		14-2
14.4	Functional Description ..........................................................................................................................		14-3
14.4.1 Brief of the sub-block.....................................................................................................................			14-3
14.4.2 Data Flow.......................................................................................................................................			14-3
14.4.3 Interface.........................................................................................................................................			14-4
14.4.4 Overview of the Color Data ...........................................................................................................			14-5
	14.4.4.1 RGB Data format....................................................................................................................		14-5

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 14	Display Controller
14.4.5 Palette usage .................................................................................................................................		14-16
14.4.5.1 Palette Configuration and Format Control..............................................................................		14-16
14.4.6 Window Blending ...........................................................................................................................		14-18
14.4.6.1 Overview.................................................................................................................................		14-18
14.4.6.2 Blending Diagram/Details ...........................................................................................................		14-20
14.4.7 COLOR-KEY Function ...................................................................................................................		14-22
14.4.8 VTIME CONTROLLER OPERATION ............................................................................................		14-25
14.4.8.1 RGB Interface .........................................................................................................................		14-25
14.4.8.2 I80	Interface Controller ..........................................................................................................	14-26
14.4.9 LDI Command Control ...................................................................................................................		14-27
14.4.9.1 Auto Command.......................................................................................................................		14-27
14.4.9.2 Normal Command ..................................................................................................................		14-27
14.4.10 I80 CPU Interface Trigger ............................................................................................................		14-29
14.4.11 Interrupt........................................................................................................................................		14-29
14.4.12 Virtual Display ..............................................................................................................................		14-29
14.4.13 RGB Interface IO .........................................................................................................................		14-31
14.4.14 LCD I80 INTERFACE IO..............................................................................................................		14-32
14.4.14 ITU-R BT.601 INTERFACE IO.....................................................................................................		14-33
14.4.15 LCD DaTA PiN MAP ....................................................................................................................		14-34
14.4.16 LCD NORMAL/BY-PASS MODE SELECTION ...........................................................................		14-36
14.5 Programmer’s Model .............................................................................................................................		14-37
14.5.1 Overview ........................................................................................................................................		14-37
14.5.2 SFR Memory Map..........................................................................................................................		14-37
14.6 Individual Register Descriptions............................................................................................................		14-40
14.6.1 Video Main Control 0 Register.......................................................................................................		14-40
14.6.2 Video Main Control 1 Register.......................................................................................................		14-42
14.6.3 Video Main Control 2 Register.......................................................................................................		14-43
14.6.4 VIDEO Time Control 0 Register.....................................................................................................		14-43
14.6.5 Video Time Control 1 Register.......................................................................................................		14-44
14.6.6 VIDEO Time Control 2 Register.....................................................................................................		14-44
14.6.7 Window 0 Control Register ............................................................................................................		14-44
14.6.8 Window 1 Control Register ...........................................................................................................		14-46
14.6.9 Window 2 Control Register ............................................................................................................		14-48
14.6.10 Window 3 Control Register ..........................................................................................................		14-50
14.6.11 Window 4 Control Register ..........................................................................................................		14-51
14.6.12 Window 0 Position Control A Register.........................................................................................		14-52
14.6.13 Window 0 Position Control B Register.........................................................................................		14-52
14.6.14 Window 0 Position Control C Register.........................................................................................		14-52
14.6.15 Window 1 Position Control A Register.........................................................................................		14-53
14.6.16 Window 1 Position Control B Register.........................................................................................		14-53
14.6.17 Window 1 Position Control C Register........................................................................................		14-54
14.6.18 Window 1 Position Control D Register.........................................................................................		14-54
14.6.19 Window 2 Position Control A Register.........................................................................................		14-54

xvi	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 14	Display Controller
14.6.20 Window 2 Position Control B Register ........................................................................................		14-55
14.6.21 Window 2 Position Control C Register ........................................................................................		14-55
14.6.22 Window 2 Position Control D Register ........................................................................................		14-55
14.6.23 Window 3 Position Control A Register ........................................................................................		14-56
14.6.24 Window 3 Position Control B Register ........................................................................................		14-56
14.6.25 Window 3 Position Control C Register ........................................................................................		14-57
14.6.26 Window 4 Position Control a Register.........................................................................................		14-57
14.6.27 Window 4 Position Control B Register ........................................................................................		14-58
14.6.28 Window 4 Position Control C Register ........................................................................................		14-58
14.6.29 FRAME Buffer Address 0 Register..............................................................................................		14-59
14.6.30 FRAME Buffer Address 1 Register..............................................................................................		14-59
14.6.31 FRAME Buffer Address 2 Register..............................................................................................		14-60
14.6.32 VIDEO interrupt Control 0 Register .............................................................................................		14-60
14.6.33 VIDEO interrupt Control 1 Register .............................................................................................		14-61
14.6.34 Win1 Color Key 0 Register ..........................................................................................................		14-62
14.6.35 WIN 1 Color key 1 Register .........................................................................................................		14-62
14.6.36 Win2 Color Key 0 Register ..........................................................................................................		14-63
14.6.37 WIN2 Color key 1 Register ..........................................................................................................		14-63
14.6.38 Win3 Color Key 0 Register ..........................................................................................................		14-64
14.6.39 WIN3 Color key 1 Register ..........................................................................................................		14-64
14.6.40 Win4 Color Key 0 Register ..........................................................................................................		14-65
14.6.41 WIN4 Color key 1 Register ..........................................................................................................		14-66
14.6.42 Dithering Control 1 Register ........................................................................................................		14-67
14.6.43 WIN0 Color MAP .........................................................................................................................		14-67
14.6.44 WIN1 Color MAP .........................................................................................................................		14-68
14.6.44 WIN1 Color MAP .........................................................................................................................		14-68
14.6.45 WIN2 Color MAP .........................................................................................................................		14-68
14.6.46 WIN3 Color MAP .........................................................................................................................		14-68
14.6.47 WIN4 Color MAP .........................................................................................................................		14-69
14.6.48 Window Palette control Register .................................................................................................		14-69
14.6.49 I80 / RGB Trigger Control Register .............................................................................................		14-70
14.6.50 ITU 601 Interface control 0 ..........................................................................................................		14-70
14.6.51 LCD I80 Interface Control 0.........................................................................................................		14-71
14.6.52 LCD I80 Interface Control 1.........................................................................................................		14-72
14.6.53 LCD I80 Interface Command Control 0 .......................................................................................		14-72
14.6.54 LCD I80 Interface Command Control 1 .......................................................................................		14-74
14.6.55 I80 System Interface Manual Command Control 0 .....................................................................		14-74
14.6.56 I80 System Interface Manual Command Control 1 .....................................................................		14-75
14.6.57 I80 System Interface Manual Command Control 2 .....................................................................		14-75
14.6.58 LCD I80 Interface Command.......................................................................................................		14-76
14.6.59 Window 2’s Palette Data .............................................................................................................		14-76
14.6.60 Window 3’s Palette Data .............................................................................................................		14-77
14.6.61 Window 4’s Palette Data .............................................................................................................		14-77
14.6.62 WIN0 Palette Ram Access Address (not SFR) ...........................................................................		14-77
14.6.63 WIN1 Palette Ram Access Address (not SFR) ...........................................................................		14-78

S3C6410X_USER’S MANUAL_REV 1.20

xvii

Table of Contents (Continued)

Chapter 15		Post Processor
15.1	Overview	................................................................................................................................................	15-1
15.2	Features	................................................................................................................................................	15-2
15.3	A Source .....................................................................................and Destination Image Data Format		15-3
15.3.1 DMA ....................................................................................................................Mode Operation			15-4
15.3.2 FIFO ....................................................................................................................Mode Operation			15-7
15.4	Image Size ..................................................................................................................and Scale Ratio		15-7
15.5	DMA operation .................................................................................of Source and Destination Image		15-9
15.5.1 Start ..................................................................................................................................address			15-10
15.5.2 End address...................................................................................................................................			15-10
15.6	Frame Management ..............................................................................................of POST Processor		15-12
15.6.1 Per Frame ......................................................................................................Management Mode			15-12
15.6.2 Free ..............................................................................................................................Run Mode			15-12
15.7	Register File ..................................................................................................................................Lists		15-13
15.7.1 MODE .................................................................................................................Control Register			15-15
15.7.3 Pre-Scale ......................................................................................................Image Size Register			15-17
15.7.4 Source ..........................................................................................................Image Size Register			15-18
15.7.5 Horizontal ............................................................................................Main Scale Ratio Register			15-18
15.7.6 Vertical ................................................................................................Main Scale Ratio Register			15-18
15.7.7 Destination ...................................................................................................Image Size Register			15-19
15.7.8 Pre-Scale .....................................................................................................Shift Factor Register			15-19
15.7.9 DMA ..........................................................................................................Start Address Register			20
15.7.10 DMA .........................................................................................................End Address Register			15-21
15.7.11 Current .............................................Frame(Buffer0) and Next Frame(Buffer1) Offset Register			15-22
15.7.12 Next ....................................................................................Frame DMA Start Address Register			15-23
15.7.13 Next .....................................................................................Frame DMA End Address Register			15-24
15.7.14 DMA .....................................................................Start address Register for Output Cb and Cr			15-24
15.7.15 DMA ......................................................................End Address Register for Output Cb and Cr			15-25
15.7.16 Current ..........Frame(Buffer0) and Next Frame(Buffer1) Offset Register for Output Cb and Cr			15-25
15.7.17 15.26 .......................................Next Frame DMA Start Address Register for Output Cb and Cr			15-25
15.7.18 Next ..................................................Frame DMA End Address Register for Output Cb and Cr			15-26
15.7.19 POSTENVID ....................................................................Register to Enable Video Processing			15-26
15.7.20 MODE ............................................................................................................Control Register 2			15-27

xviii

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 16		TV Scaler
16.1	Overview	...............................................................................................................................................	16-1
16.2	Features ................................................................................................................................................		16-2
16.3	A Source .....................................................................................and Destination Image Data Format		16-3
16.3.1 DMA ....................................................................................................................Mode Operation			16-4
16.3.2 FIFO ....................................................................................................................Mode Operation			16-7
16.4	Image Size ..................................................................................................................and Scale Ratio		16-7
16.5	DMA operation ................................................................................of Source and Destination Image		16-9
16.5.1 Start .................................................................................................................................address			16-10
16.5.2 End address...................................................................................................................................			16-10
16.6	Frame Management .........................................................................................................of TV Scaler		16-12
16.6.1 Per Frame ......................................................................................................Management Mode			16-12
16.6.2 Free ..............................................................................................................................Run Mode			16-12
16.7	Register File .................................................................................................................................Lists		16-13
16.7.1 MODE .................................................................................................................Control Register			16-15
16.7.3 Pre-Scale .....................................................................................................Image Size Register			16-17
16.7.4 Source ..........................................................................................................Image Size Register			16-18
16.7.5 Horizontal ............................................................................................Main Scale Ratio Register			16-18
16.7.6 Vertical ................................................................................................Main Scale Ratio Register			16-18
16.7.7 Destination ...................................................................................................Image Size Register			16-19
16.7.8 Pre-Scale .....................................................................................................Shift Factor Register			16-19
16.7.9 DMA .........................................................................................................Start Address Register			16-20
16.7.10 DMA .........................................................................................................End Address Register			16-20
16.7.11 Current ...........................................Frame (Buffer0) and Next Frame (Buffer1) Offset Register			16-21
16.7.12 Next ...................................................................................Frame DMA Start Address Register			16-21
16.7.13 Next .....................................................................................Frame DMA End Address Register			16-22
16.7.14 DMA .....................................................................Start Address Register for Output Cb and Cr			16-22
16.7.15 DMA ......................................................................End Address Register for Output Cb and Cr			16-23
16.7.16 Current ........Frame (Buffer0) and Next Frame (Buffer1) Offset Register for Output Cb and Cr			16-23
16.7.17 Next .................................................Frame DMA Start Address Register for Output Cb and Cr			16-23
16.7.18 Next ..................................................Frame DMA End Address Register for Output Cb and Cr			16-24
16.7.19 POSTENVID ...................................................................Register for Enable Video Processing			16-24
16.7.20 MODE ............................................................................................................Control Register 2			16-25

S3C6410X_USER’S MANUAL_REV 1.20

xix

	Table of Contents (Continued)
Chapter 17	TV Encoder
17.1 Overview................................................................................................................................................		17-1
17.2 Feature ..................................................................................................................................................		17-1
17.3 Block Diagram .......................................................................................................................................		17-2
17.4 Functional Descriptions.........................................................................................................................		17-3
17.4.1 Composition Of Analog Composite Signal.....................................................................................		17-4
17.4.2 Common Ntsc System ...................................................................................................................		17-5
17.4.3 Common Pal System .....................................................................................................................		17-6
17.4.4 Composition Of Screen..................................................................................................................		17-7
17.4.5 Requested Horizontal Timing ........................................................................................................		17-8
17.4.6 Requested Vertical Timing.............................................................................................................		17-9
17.5 Dac Board Configure Guide ..................................................................................................................		17-10
17.6 Tv Encoder Register Summary .............................................................................................................		17-11
17.7 Individual Register Descriptions............................................................................................................		17-12
17.7.1 TVENCREG1 .................................................................................................................................		17-12
17.7.2 TVENCREG2 .................................................................................................................................		17-13
17.7.3 TVENCREG3 .................................................................................................................................		17-13
17.7.4 TVENCREG4 .................................................................................................................................		17-13
17.7.5 TVENCREG5 .................................................................................................................................		17-14
17.7.6 TVENCREG6 .................................................................................................................................		17-14
17.7.7 TVENCREG7 .................................................................................................................................		17-14
17.7.8 TVENCREG8 .................................................................................................................................		17-15
17.7.9 TVENCREG9 .................................................................................................................................		17-15
17.7.10 TVENCREG10 .............................................................................................................................		17-16
17.7.11 TVENCREG11 .............................................................................................................................		17-16
17.7.12 TVENCREG12 .............................................................................................................................		17-16
17.7.13 TVENCREG14 .............................................................................................................................		17-17
17.7.14 TVENCREG15 .............................................................................................................................		17-17
17.7.15 TVENCREG18 .............................................................................................................................		17-19
17.7.16 TVENCREG19 .............................................................................................................................		17-19
17.7.17 TVENCREG20 .............................................................................................................................		17-20
17.7.18 TVENCREG21 .............................................................................................................................		17-21
17.7.19 TVENCREG23 .............................................................................................................................		17-21
17.7.20 TVENCREG25 .............................................................................................................................		17-22
17.7.21 TVENCREG26 .............................................................................................................................		17-23
17.7.22 TVENCREG27 .............................................................................................................................		17-23
17.7.23 TVENCREG28 .............................................................................................................................		17-24
17.7.24 TVENCREG29 .............................................................................................................................		17-24
17.7.25 TVENCREG30 .............................................................................................................................		17-24
17.7.26 TVENCREG31 .............................................................................................................................		17-25
17.7.27 TVENCREG32 .............................................................................................................................		17-25
17.7.28 TVENCREG33 .............................................................................................................................		17-25

xx	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 18	GRAPHICS 2D
18.1 Overview ...............................................................................................................................................		18-1
18.1.1 Features.........................................................................................................................................		18-1
18.2 Color Format Conversion......................................................................................................................		18-2
18.3 Command Fifo.......................................................................................................................................		18-3
18.4 Rendering pipeline ................................................................................................................................		18-3
18.4.1 Primitive Drawing...........................................................................................................................		18-3
18.4.1.1Line/Point Drawing ..................................................................................................................		18-3
18.4.1.2 Bit Block Transfer ...................................................................................................................		18-4
18.4.1.3 Color Expansion (Font Drawing)............................................................................................		18-6
18.4.2 Rotation .........................................................................................................................................		18-7
18.4.3 Clipping..........................................................................................................................................		18-8
18.4.4 Stencil Test	....................................................................................................................................	18-9
18.4.5 Raster Operation ...........................................................................................................................		18-9
18.4.6 Alpha Blending...............................................................................................................................		18-10
18.5 REGISTER DESCRIPTION ..................................................................................................................		18-11
18.5.1 General Registers..........................................................................................................................		18-14
18.5.1.1 Control Register (CONTROL_REG) .....................................................................................		18-14
18.5.1.2 Interrupt Enable REGISTER (INTEN_REG) ..........................................................................		18-14
18.5.1.3 FIFO Interrupt Control REGISTER (FIFO_INTC_REG) ........................................................		18-15
18.5.1.4 Interrupt Pending REGISTER (INTC_PEND_REG) ..............................................................		18-15
18.5.1.5 FIFO status REGISTER (FIFO_STAT_REG) ........................................................................		18-16
18.5.2 Command Registers......................................................................................................................		18-17
18.5.2.1 Line Drawing REGISTER (CMD0_REG) ...............................................................................		18-17
18.5.2.2 BitBLT REGISTER (CMD1_REG)..........................................................................................		18-17
18.5.2.3 Host to Screen Start BitBLT REGISTER (CMD2_REG)........................................................		18-17
18.5.2.4 Host to Screen Continue BitBLT REGISTER (CMD3_REG) .................................................		18-18
18.5.2.5 Host to Screen Start Color Expansion REGISTER (CMD4_REG) ........................................		18-18
18.5.2.6 Host to Screen Continue Color Expansion REGISTER (CMD5_REG) .................................		18-18
18.5.2.7 Memory to Screen Color Expansion REGISTER (CMD7_REG) ...........................................		18-18
18.5.3 Parameter Setting Registers....................................................................................................		18-19
18.5.3.1 Source Image Resolution (SRC_RES_REG) ........................................................................		18-19
18.5.3.2 Source Image Horizontal Resolution (SRC_HORI_RES_REG)............................................		18-19
18.5.3.3 Source Image Vertical Resolution (SRC_VERT_RES_REG)................................................		18-19
18.5.3.4 Screen Resolution (SC_RES_REG) ......................................................................................		18-19
18.5.3.5 Screen Horizontal Resolution (SC_HORI_RES_REG)..........................................................		18-20
18.5.3.6 Screen Vertical Resolution (SC_VERI_RES_REG) ..............................................................		18-20
18.5.3.7 LeftTop Clipping Window (CW_LT_REG)..............................................................................		18-21
18.5.3.8 Left X Clipping Window (CW_LT_X_REG) ............................................................................		18-21
18.5.3.9 Top Y Clipping Window (CW_LT_Y_REG)............................................................................		18-21
18.5.3.10 RightBottom Clipping Window (CW_RB_REG) ...................................................................		18-21
18.5.3.11 Right X Clipping Window (CW_RB_X_REG)......................................................................		18-22
18.5.3.12 Bottom Y Clipping Window (CW_RB_Y_REG)...................................................................		18-22
18.5.3.13 Coordinate_0 REGISTER (COORD0_REG) .......................................................................		18-23

S3C6410X_USER’S MANUAL_REV 1.20

xxi

Table of Contents (Continued)

Chapter 18	GRAPHICS 2D
18.5.3.14 Coordinate_0 X REGISTER (COORD0_X_REG)................................................................		18-23
18.5.3.15 Coordinate_0 Y REGISTER (COORD0_Y_REG)................................................................		18-23
18.5.3.16 Coordinate_1 REGISTER (COORD1_ REG).......................................................................		18-23
18.5.3.17 Coordinate_1 X REGISTER (COORD1_X_REG)................................................................		18-24
18.5.3.18 Coordinate_1 Y REGISTER (COORD1_Y_REG)................................................................		18-24
18.5.3.19 Coordinate_2 REGISTER (COORD2_ REG).......................................................................		18-24
18.5.3.20 Coordinate_2 X REGISTER (COORD2_X_REG)................................................................		18-24
18.5.3.21 Coordinate_2 Y REGISTER (COORD2_Y_REG)................................................................		18-25
18.5.3.22 Common Resource Coordinate_3 REGISTER (COORD3_ REG) ......................................		18-25
18.5.3.23 Coordinate_3 X REGISTER (COORD3_X_REG)................................................................		18-25
18.5.3.24 Coordinate_3 Y REGISTER (COORD3_Y_REG)................................................................		18-25
18.5.3.25 Rotation Origin Coordinate (ROT_OC_REG) ......................................................................		18-26
18.5.3.26 Rotation Origin Coordinate X (ROT_OC_X_REG)...............................................................		18-26
18.5.3.27 Rotation Origin Coordinate Y (ROT_OC_Y_REG)...............................................................		18-26
18.5.3.28 Rotation REGISTER (ROTATE_REG).................................................................................		18-26
18.5.3.30 X Increment REGISTER (X_INCR_REG) ............................................................................		18-27
18.5.3.31 Y Increment REGISTER (Y_INCR_REG) ............................................................................		18-27
18.5.3.32 Raster Operation REGISTER (ROP_REG)..........................................................................		18-28
18.5.3.33 Alpha REGISTER (ALPHA_REG)........................................................................................		18-28
18.5.3.34 Foreground Color REGISTER (FG_COLOR_REG).............................................................		18-29
18.5.3.35 Background Color REGISTER (BG_COLOR_REG)............................................................		18-29
18.5.3.36 BlueScreen Color REGISTER (BS_COLOR_REG).............................................................		18-29
18.5.3.37 Source Image Color Mode (SRC_COLOR_MODE_REG)...................................................		18-29
18.5.3.38 Destination Image Color Mode (DEST_COLOR_MODE_REG) ..........................................		18-29
18.5.3.39 Pattern Offset REGISTER (PATOFF_REG) ........................................................................		18-30
18.5.3.40 Pattern Offset X REGISTER (PATOFF_X_REG).................................................................		18-30
18.5.3.41 Pattern Offset Y REGISTER (PATOFF_Y_REG).................................................................		18-30
18.5.3.42 Colorkey Control REGISTER (COLORKEY_CNTL_REG) ..................................................		18-31
18.5.3.43 Colorkey Decision Reference Minimum REGISTER (COLORKEY _DR_MIN_REG) .........		18-31
18.5.3.44 Colorkey Decision Reference Maximum REGISTER (COLORKEY _DR_MAX_REG) .......		18-31
18.5.3.45 Source Image Base Address REGISTER (SRC_BASE_ADDR_REG) ...............................		18-32
18.5.3.46 Destination Image Base Address REGISTER (DEST_BASE_ADDR_REG).......................		18-32

Chapter 19		Image Rotator
19.1	Overview................................................................................................................................................	19-1
19.2	Feature ..................................................................................................................................................	19-1
19.3	Block Diagram .......................................................................................................................................	19-1
19.4	Image Example......................................................................................................................................	19-2

xxii	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 19	Image Rotator
19.5 Register Description..............................................................................................................................		19-3
19.5.1 Memory Map..................................................................................................................................		19-3
19.5.2 Rotator Control Register................................................................................................................		19-3
19.5.3 Rotator Source Image Address Register 0 (RGB or Y component)..............................................		19-4
19.5.4 Rotator Source Image Address Register 1 (Cb Component)........................................................		19-4
19.5.5 Rotator Source Image Address Register 2 (Cr Component) ........................................................		19-4
19.5.6 Rotator Source Image Size Register.............................................................................................		19-4
19.5.7 Rotator Destination Image Address Register 0 (RGB or Y Component) ......................................		19-5
19.5.8 Rotator Destination Image Address Register 1 (CB Component).................................................		19-5
19.5.9 Rotator Destination Image Address Register 2 (CR Component) ................................................		19-5
19.5.10 Rotator Status Register ...............................................................................................................		19-5


Chapter 20			Camera Interface
20.1	Overview ...............................................................................................................................................			20-1
20.2	Features ................................................................................................................................................			20-1
20.3	External Interface..................................................................................................................................			20-3
20.4	Signal Description .................................................................................................................................			20-3
20.5	Timing Diagram.....................................................................................................................................			20-4
20.6	External/internal connection guide........................................................................................................			20-6
20.7	Camera Interface Operation .................................................................................................................			20-7
20.7.1 Four DMA Ports .............................................................................................................................				20-7
20.7.2 Clock Domain ................................................................................................................................				20-8
20.7.3 Frame Memory Hierarchy..............................................................................................................				20-9
20.7.4 Memory Storing method ................................................................................................................				20-10
20.7.5 Timing Diagram for Register Setting .............................................................................................				20-11
20.7.6 Timing diagram for Last IRQ (Camera capture mode)..................................................................				20-13
20.7.7 Timing diagram for IRQ (Memory data Scaling mode)..................................................................				20-14
20.7.8 MSDMA feature .............................................................................................................................				20-14
20.7.8 Camera interlace input support .....................................................................................................				20-15
20.7.8.1		progressive input ......................................................................................................................		20-15
20.7.8.1		interaced input ..........................................................................................................................		20-15
20.7.8.1		601 interface ..............................................................................................................................		20-16
20.7.8.1		656 interface ..............................................................................................................................		20-16
20.8	Software Interface (CAMERA INTERFACE IN S3C6410X SFR).........................................................			20-18
20.8.1 Camera Interface Special Function Registers...............................................................................				20-18
20.8.2 Camera Source Format Register ..................................................................................................				20-18
20.8.3 Window Offset Register.................................................................................................................				20-19
20.8.4 Global Control Register .................................................................................................................				20-20
20.8.5 Window Offset Register 2..............................................................................................................				20-22
20.8.6 Codec output Y1 start address register.........................................................................................				20-23
20.8.7 codec output Y2 start address register..........................................................................................				20-23
20.8.8 codec output Y3 start address register..........................................................................................				20-23

S3C6410X_USER’S MANUAL_REV 1.20

xxiii

Table of Contents (Continued)

Chapter 20	Camera Interface
20.8.9 codec output Y4 start address register ..........................................................................................		20-23
20.8.10 codec output CB1 start address register .....................................................................................		20-24
20.8.11 codec output Cb2 start address register......................................................................................		20-24
20.8.12 codec output CB3 start address register .....................................................................................		20-24
20.8.13 codec output CB4 start address register .....................................................................................		20-24
20.8.14 codec output Cr1 start address register ......................................................................................		20-25
20.8.15 codec output Cr2 start address register ......................................................................................		20-25
20.8.16 codec output Cr3 start address register ......................................................................................		20-25
20.8.17 codec output Cr4 start address register ......................................................................................		20-25
20.8.18 Codec target format register ........................................................................................................		20-26
20.8.19 Codec dma control register..........................................................................................................		20-27
20.8.20 register setting guide for Codec scaler and preview scaler.........................................................		20-29
20.8.21 Codec pre-scaler control register 1..............................................................................................		20-31
20.8.22 Codec pre-scaler control register 2..............................................................................................		20-31
20.8.23 Codec Main-scaler control register ..............................................................................................		20-32
20.8.24 codec dma target area register....................................................................................................		20-35
20.8.25 codec status register....................................................................................................................		20-35
20.8.26 Preview output Y1 start address register.....................................................................................		20-36
20.8.27 Preview output Y2 start address register.....................................................................................		20-36
20.8.28 Preview output Y3 start address register.....................................................................................		20-36
20.8.29 Preview output Y4 start address register.....................................................................................		20-36
20.8.30 preview output CB1 start address register ..................................................................................		20-37
20.8.31 preview output Cb2 start address register...................................................................................		20-37
20.8.32 preview output CB3 start address register ..................................................................................		20-37
20.8.33 PREVIEW output CB4 start address register ..............................................................................		20-37
20.8.34 PREVIEW output Cr1 start address register ...............................................................................		20-38
20.8.35 preview output Cr2 start address register....................................................................................		20-38
20.8.36 preview output Cr3 start address register....................................................................................		20-38
20.8.37 preview output Cr4 start address register....................................................................................		20-38
20.8.38 preview target format register ......................................................................................................		20-39
20.8.39 preview dma control register........................................................................................................		20-40
20.8.40 preview pre-scaler control register 1............................................................................................		20-42
20.8.41 preview pre-scaler control register 2............................................................................................		20-42
20.8.42 preview Main-scaler control register ............................................................................................		20-43
20.8.43 Preview dma target area register.................................................................................................		20-44
20.8.44 preview status register .................................................................................................................		20-44
20.8.45 Image Capture enable register ....................................................................................................		20-45
20.8.46 CAPTURE control SEQUENCE register......................................................................................		20-46
20.8.47 Image Effects register ..................................................................................................................		20-46
20.8.48 MSDMA for codec Y start ADDRESS register.............................................................................		20-48
20.8.49 MSDMA for codec Cb start ADDRESS register ..........................................................................		20-48
20.8.50 MSDMA for codec Cr start ADDRESS register ...........................................................................		20-48
20.5.51 MSDMA for codec Y end ADDRESS register..............................................................................		20-49
20.8.52 MSDMA for codec Cb end ADDRESS register ...........................................................................		20-49
20.8.53 MSDMA Cr end ADDRESS register ............................................................................................		20-49

xxiv	S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 20	Camera Interface
20.8.54 MSDMA for codec Y OFFSET register........................................................................................		20-50
20.8.55 MSDMA for codec Cb offset register...........................................................................................		20-50
20.8.56 MSDMA for codec Cr offset register............................................................................................		20-50
20.8.57 MSDMA for codec Source image width register .........................................................................		20-51
20.8.58 MSDMA for codec CONTROL register........................................................................................		20-52
20.8.59 MSDMA for preview Y0 start ADDRESS register........................................................................		20-55
20.8.60 MSDMA FOR PREVIEW Cb0 start ADDRESS register..............................................................		20-55
20.8.61 MSDMA FOR PREVIEW Cr0 start ADDRESS register ..............................................................		20-55
20.8.62 MSDMA FOR PREVIEW Y0 end ADDRESS register.................................................................		20-56
20.8.63 MSDMA FOR PREVIEW Cb0 end ADDRESS register...............................................................		20-56
20.8.64 MSDMA Cr0 end ADDRESS register..........................................................................................		20-56
20.8.65 MSDMA FOR PREVIEW Y OFFSET register .............................................................................		20-57
20.8.66 MSDMA FOR PREVIEW Cb offset register ................................................................................		20-57
20.8.67 MSDMA FOR PREVIEW Cr offset register .................................................................................		20-57
20.8.68 MSDMA FOR PREVIEW Source image width/height & autoload register..................................		20-58
20.8.69 MSDMA for preview CONTROL register.....................................................................................		20-59
20.8.70 Codec SCAN LINE Y OFFSET register ......................................................................................		20-60
20.8.71 Codec SCAN LINE cb OFFSET register .....................................................................................		20-61
20.8.72 Codec SCAN LINE cr OFFSET register......................................................................................		20-61
20.8.73 PREVIEW SCAN LINE Y OFFSET register ................................................................................		20-61
20.8.74 preview SCAN LINE cb OFFSET register ...................................................................................		20-62
20.8.75 preview SCAN LINE cr OFFSET register....................................................................................		20-62

Chapter 21		Multi-FORMAT Video Codec
21.1	Overview ...............................................................................................................................................		21-1
21.2	Features ................................................................................................................................................		21-2
21.3	The Bit Processor .................................................................................................................................		21-4
21.3.1 Hardware Acceleration ..................................................................................................................			21-5
21.3.2 Downloading the firmware .............................................................................................................			21-5
21.3.3 Running the codec.........................................................................................................................			21-7
21.3.4 Interrupt .........................................................................................................................................			21-8
21.4	Video codec hardware ..........................................................................................................................		21-9
21.4.1 Overview........................................................................................................................................			21-9
	21.4.1.1 H.264 encoder data flow ........................................................................................................		21-9
	21.4.1.2 MPEG-4 encoder data flow ....................................................................................................		21-10
	21.4.1.3 H.263 encoder data flow ........................................................................................................		21-10
	21.4.1.4 H.264 decoder data flow ........................................................................................................		21-11
	21.4.1.5 MPEG-4 decoder data flow ....................................................................................................		21-11
	21.4.1.6 H.263 decoder data flow ........................................................................................................		21-11
	21.4.1.7 VC-1 decoder data flow..........................................................................................................		21-11
	21.4.1.8 Full-duplex codec processing.................................................................................................		21-11
	21.4.1.9 Full-duplex codec bus-loading ...............................................................................................		21-11

S3C6410X_USER’S MANUAL_REV 1.20

xxv

Table of Contents (Continued)

Chapter 21	Multi-FORMAT Video Codec
21.4.2 Frame buffer...................................................................................................................................		21-12
21.4.3 Rotation/Mirroring ..........................................................................................................................		21-14
21.4.3.1 PrP rotator module..................................................................................................................		21-14
21.4.3.2 PP rotator module...................................................................................................................		21-15
21.4.3.3 Rotation/mirroring modes .......................................................................................................		21-15
21.4.4 Motion Estimation...........................................................................................................................		21-17
21.4.4.1 ME DMA block ........................................................................................................................		21-19
21.4.5 Inter-Prediction...............................................................................................................................		21-20
21.4.6 Intra-Prediction...............................................................................................................................		21-22
21.4.7 Transform/Quantization .................................................................................................................		21-24
21.4.7.1 Overview.................................................................................................................................		21-24
21.4.7.2 Block diagram.........................................................................................................................		21-24
21.4.7.3 MPEG-4/H.263 .......................................................................................................................		21-25
121.4.7.4 H.264	....................................................................................................................................	21-26
21.4.8 Overlap-smoothing/Deblocking Filter.............................................................................................		21-27
21.4.8.1 Overview.................................................................................................................................		21-27
21.4.8.2 Processing modes ..................................................................................................................		21-27
21.4.8.3 Block diagram.........................................................................................................................		21-29
21.4.8.4 H.264 Deblocking filter ...........................................................................................................		21-30
21.4.8.5 H.263 Annex J Deblocking filter .............................................................................................		21-30
21.4.8.6 VC-1 Overlap-smoothing filter ................................................................................................		21-30
21.4.8.7 VC-1 Deblocking filter .................................................................................................................		21-30
21.4.8.8 MPEG-4 Deblocking filter for post-processing .......................................................................		21-31
21.4.9 Coefficient Buffer Interface ............................................................................................................		21-31
21.4.9.1 Block diagram.........................................................................................................................		21-31
21.4.9.2 Reordering coefficients...........................................................................................................		21-32
21.4.9.3 Accessing the coefficient memory..........................................................................................		21-32
21.4.9.4 Encoder operation ..................................................................................................................		21-33
21.4.9.5 Decoder operation ..................................................................................................................		21-34
21.4.10 Macroblock Controller ..................................................................................................................		21-35
21.5 FIMV-MFC V1.0 Programming Model (Special Function Register ) .....................................................		21-36
21.5.1 BIT Processor operations ..............................................................................................................		21-37
21.5.1.1 Description of BIT Processor Registers .................................................................................		21-37
21.5.1.2 BIT Processor Code Download ..............................................................................................		21-37
21.5.1.3 Bit Stream Buffer management ..............................................................................................		21-38
21.5.1.4 Description of Run Commands ..............................................................................................		21-39
21.5.1.5 Parameter Buffer Management ..............................................................................................		21-43
21.5.1.6 Working Buffer Management..................................................................................................		21-44
21.5.1.7 Description of Run Process....................................................................................................		21-47
21.5.1.8 Description of Pre/Post Rotation ............................................................................................		21-47
21.5.1.9 Sample operation flows ..........................................................................................................		21-49
21.5.2 The host interface registers ...........................................................................................................		21-52
21.5.2.1 Summary of host interface registers.......................................................................................		21-53
21.5.2.2 Detailed Description of BIT Processor Registers ...................................................................		21-61

xxvi	S3C6410X_USER’S MANUAL_REV 1.20

	Table of Contents (Continued)
Chapter 22	JPEG Codec
22.1 Overview ...............................................................................................................................................		22-1
22.2 Feature..................................................................................................................................................		22-1
22.3 Block Diagram.......................................................................................................................................		22-2
22.4 Functional Descriptions.........................................................................................................................		22-2
22.4.1 Control Circuit & AHB interface .....................................................................................................		22-2
22.4.2 DCT/Quantization ..........................................................................................................................		22-2
22.4.3 Huffman Coder and Marker Process.............................................................................................		22-3
22.4.4 Quantization Table.........................................................................................................................		22-3
22.4.5 Huffman Table ...............................................................................................................................		22-3
22.4.6 Register Access.............................................................................................................................		22-3
22.4.7 Table Access .................................................................................................................................		22-3
22.4.8 Interrupt Signal ..............................................................................................................................		22-4
22.4.9 Interrupt Setting Register...............................................................................................................		22-4
22.4.10 Marker Process ...........................................................................................................................		22-4
22.4.1 Bitstream of Compressed File .......................................................................................................		22-4
22.5 Programmer’s Model.............................................................................................................................		22-5
22.6 JPEC CODEC PROGRAMMING GUIDE .............................................................................................		22-6
22.6.1 Basic JPEG encoding sequence ...................................................................................................		22-6
22.6.2 JPEG Decoding SEQUENCE........................................................................................................		22-7
22.7 JPEC CODEC SPECIAL REGISTERS.................................................................................................		22-8
22.7.1 JPGMOD .......................................................................................................................................		22-10
22.7.2 JPGSTS.........................................................................................................................................		22-10
22.7.3 JPGQHNO .....................................................................................................................................		22-11
22.7.4 JPGDRI..........................................................................................................................................		22-11
22.7.5 JPGY..............................................................................................................................................		22-12
22.7.6 JPGX..............................................................................................................................................		22-12
22.7.7 JPGCNT ........................................................................................................................................		22-12
22.7.8 JPGIRQS .......................................................................................................................................		22-13
22.7.9 JPGIRQ .........................................................................................................................................		22-13
22.7.10 QTBL0 .........................................................................................................................................		22-14
22.7.11 QTBL1 .........................................................................................................................................		22-14
22.7.12 QTBL2 .........................................................................................................................................		22-14
22.7.13 QTBL3 .........................................................................................................................................		22-15
22.7.14 HDCTBL0	....................................................................................................................................	22-15
22.7.15 HDCTBLG0..................................................................................................................................		22-15
22.7.16 HACTBL0.....................................................................................................................................		22-16
22.7.17 HACTBLG0..................................................................................................................................		22-16
22.7.18 HDCTBL1	....................................................................................................................................	22-16
22.7.19 HDCTBLG1..................................................................................................................................		22-17
22.7.20 HACTBL1.....................................................................................................................................		22-17

S3C6410X_USER’S MANUAL_REV 1.20

xxvii

	Table of Contents (Continued)
Chapter 22	JPEG Codec
22.7.21 HACTBLG1 ..................................................................................................................................		22-17
22.7.22 IMGADDR0 ..................................................................................................................................		22-18
22.7.23 IMGADDR1 ..................................................................................................................................		22-18
22.7.24 HUFADDR0..................................................................................................................................		22-18
22.7.25 HUFADDR1..................................................................................................................................		22-19
22.7.26 SW_JSTART................................................................................................................................		22-19
22.7.27 SW_JRSTART .............................................................................................................................		22-19
22.7.28 SW_RESET_CON .......................................................................................................................		22-20
22.7.29 OEF1............................................................................................................................................		22-20
22.7.30 COEF2 .........................................................................................................................................		22-20
22.7.31 COEF3 .........................................................................................................................................		22-21
22.7.32 MISC ............................................................................................................................................		22-21
Chapter 23	Modem Interface
23.1 Overview................................................................................................................................................		23-1
23.2 Features ................................................................................................................................................		23-2
23.3 External Interfaces ................................................................................................................................		23-2
23.4 Memory Map..........................................................................................................................................		23-2
23.5 Interrupt Ports........................................................................................................................................		23-3
23.6 AP Booting for Modem ..........................................................................................................................		23-4
23.7 address mapping...................................................................................................................................		23-6
23.8 timing diagram.......................................................................................................................................		23-8
23.9 software interface and registers ............................................................................................................		23-9
23.10 MODEM Interface Special Function Registers ...................................................................................		23-10
23.10.1 Interrupt Request to AP Register (INT2AP).................................................................................		23-10
23.10.2 Interrupt Request to Modem Register (INT2MODEM) ................................................................		23-10
23.10.3 Modem Interface Control Register (MIFCON) .............................................................................		23-11
23.10.4 Modem Interface Port Control Register (MIFPCON) ...................................................................		23-11
23.10.5 MODEM Interrupt Clear Register (MODEMINTCLR) ..................................................................		23-13
23.10.6 dma request tx address register (dmareq_tx_adr) ......................................................................		23-13
23.10.7 dma request rx address register (dmareq_rx_adr)......................................................................		23-14

xxviii

S3C6410X_USER’S MANUAL_REV 1.20

Table of Contents (Continued)

Chapter 24	Host Interface
24.1 Overview ...............................................................................................................................................		24-1
25.2 Features ................................................................................................................................................		24-4
24.3 Functional Description ..........................................................................................................................		24-4
24.3.1 Read and Write of a 16-bit Protocol Register................................................................................		24-5
24.3.2 Read and Write of Two 16-bit Protocol Registers in the Same Bank ...........................................		24-5
24.3.3 Single Write ...................................................................................................................................		24-5
24.3.4 Single Read ...................................................................................................................................		24-6
24.3.5 Burst Write .....................................................................................................................................		24-7
24.3.6 Burst Read.....................................................................................................................................		24-7
24.3.7 Repeated Burst Write to reduce the HOST (ex. Modem) overhead .............................................		24-8
24.3.8 MODEM Booting............................................................................................................................		24-9
24.3.9 Mailbox Interface ...........................................................................................................................		24-11
24.3.10 Mailbox basic operation...............................................................................................................		24-11
24.3.11 Mailbox operation with a bulk data ..............................................................................................		24-12
24.4 Programmer’s Model.............................................................................................................................		24-13
24.4.1 The registers of HOST Interface are classified into: .....................................................................		24-13
24.5 Register Descriptions (Protocol Registers)...........................................................................................		24-14
24.5.1 Protocol Register Matrix ................................................................................................................		24-15
24.5.2 Control Register (CTRL)...............................................................................................................		24-16
24.5.3 Interrupt Enable Register (INTE)...................................................................................................		24-16
24.5.4 Status Register (STAT) .................................................................................................................		24-17
24.5.5 Interrupt Enable1 Register (INTE1)...............................................................................................		24-18
24.5.6 Status1 Register (STAT1) .............................................................................................................		24-18
24.5.7 In-Mail Box Low Register (IMBL)...................................................................................................		24-18
24.5.8 In-Mail Box High Register (IMBH) .................................................................................................		24-18
24.5.9 Out-Mail Box Low Register (OMBL) ..............................................................................................		24-19
24.5.10 Out-Mail Box High Register (OMBH)...........................................................................................		24-19
24.5.11 Host Interface Data Low Register (hDATAL) ..............................................................................		24-19
24.5.12 Host Interface Data High Register (hDATAH).............................................................................		24-19
24.5.13 System Control Register (SYS_CTRL) .......................................................................................		24-19
24.5.14 Bank Selection Register (BSEL)..................................................................................................		24-20
24.6 Register Descriptions (Special Function Registers) .............................................................................		24-21
24.6.1 HOST I/F CONTROL REGISTER (HOSTIFC_CTRL) ..................................................................		24-22
24.6.2 HOST I/F Temporary Register (HOSTIFC_TMP)..........................................................................		24-22
24.6.3 HOST I/F IMB Register (HOSTIFC_IMB)......................................................................................		24-22
24.6.4 HOST I/F OMB Register (HOSTIFC_OMB) ..................................................................................		24-23
24.6.5 HOST I/F Status Mirrored Register (HOSTIFC_MR_STAT) .........................................................		24-23
24.6.6 HOST I/F Status1 Mirrored Register (HOSTIFC_MR_STAT1) .....................................................		24-23
24.6.7 HOST I/F Status2 Register (HOSTIFC_STAT2) ...........................................................................		24-24
24.6.8 HOSt I/F Interrupt Enable Mirrored Register (HOSTIFC_MR_INTE)............................................		24-24
24.6.9 HOSt I/F Interrupt Enable1 Mirrored Register (HOSTIFC_MR_INTE1)........................................		24-25
24.6.10 HOST I/F Interrupt Enable2 Register (HOSTIFC_INTE2)...........................................................		24-25

S3C6410X_USER’S MANUAL_REV 1.20

xxix

Table of Contents (Continued)

Chapter 25		USB HOST Controller
25.1	Overview................................................................................................................................................		25-1
25.2	Usb Host Controller Special Registers..................................................................................................		25-2
Chapter 26		USB2.0 HS OTG
26.1	Overview................................................................................................................................................		26-1
26.2	Feature ..................................................................................................................................................		26-1
26.3	Block Diagram .......................................................................................................................................		26-2
26.4	Modes Of Operation ..............................................................................................................................		26-3
26.4.1 DMA Mode .....................................................................................................................................			26-3
26.4.2 Slave Mode		....................................................................................................................................	26-3
26.5	System Controller Setting......................................................................................................................		26-3
26.5.1 Normal Mode..................................................................................................................................			26-3
26.5.2 Stop/Deep Stop/Sleep Mode .........................................................................................................			26-3
26.6	Register Map .........................................................................................................................................		26-4
26.6.1 Overview ........................................................................................................................................			26-4
26.6.2 OTG Link Csr Memory Map ...........................................................................................................			26-5
26.6.3 OTG Fifo Address Mapping ...........................................................................................................			26-6
26.6.4 Application Access To The Csrs....................................................................................................			26-8
26.7	HS OTG Controller Special Registers...................................................................................................		26-9
26.8	OTG PHY Control Registers .................................................................................................................		26-17
26.9	OTG LINK Core Registers.....................................................................................................................		26-20
26.9.1 OTG Global Registers....................................................................................................................			26-20
26.9.2 Host Mode Registers .....................................................................................................................			26-38
	26.9.2.1 Host Global Registers.............................................................................................................		26-38
	26.9.2.2 Host Port Control And Status Registers .................................................................................		26-43
	26.9.2.3 Host Channel-Specific Registers............................................................................................		26-45
26.9.3 Device Mode Registers..................................................................................................................			26-51
	26.9.3.1 Device Global Registers .........................................................................................................		26-51
	26.9.3.2 Device Logical Endpoint-Specific Registers...........................................................................		26-61
26.9.3 Power and clock Gating Register ..................................................................................................			26-74
Chapter 27		SD/MMC HOST Controller
27.1	Overview................................................................................................................................................		27-1
27.2	Features ................................................................................................................................................		27-1
27.3	Block Diagram .......................................................................................................................................		27-2
27.4	Sequence ..............................................................................................................................................		27-3
27.4.1 SD Card Detection Sequence........................................................................................................			27-3
27.4.2 SD Clock Supply Sequence...........................................................................................................			27-4
27.4.3 SD Clock Stop Sequence ..............................................................................................................			27-5
27.4.4 SD Clock Frequency Change Sequence.......................................................................................			27-5
27.4.5 SD Bus Power Control Sequence..................................................................................................			27-6
27.4.6 Change Bus Width Sequence........................................................................................................			27-7
27.4.7 Timeout Setting for DAT Line.........................................................................................................			27-8

xxx	S3C6410X_USER’S MANUAL_REV 1.20

+ 1341 hidden pages
