About the Gear VR

The Samsung Gear™ VR powered by Oculus™ allows you to enjoy
2D, 3D, and 360-degree content by connecting it with your mobile
device.

You can also view webpages and your own 360-degree images
or videos. Connect other devices, such as the included Gear VR
controller or other Bluetooth game controllers, with the mobile
device for a more immersive experience.

3

About the Gear VR

Samsung Electronics America (SEA), Inc.

Address:

85 Challenger Road

Ridgefield Park,

New Jersey 07660

Phone:

1-800-SAMSUNG (726-7864)

Internet Address:

samsung.com

©2017 Samsung Electronics America, Inc. Samsung is a registered
trademark of Samsung Electronics Co., Ltd. Do you have questions
about your Samsung Mobile Device? For 24 hour information and
assistance, we offer a new FAQ/ARS System (Automated Response
System) at

www.samsung.com/us/support

.

4

Table of Contents

Read me first

Health and safety
warnings

8 Wearing the Gear VR
26 Additional Notifications

Safety information

Getting started

34 Package contents
35 Device layout
42 Connecting straps
44 Installing the Mobile Device
59 Preparing the controller for

use

64 Installing the Gear VR app

(Oculus) and connecting the
controller

5

Table of Contents

Viewing content

88 Viewing content on the

Oculus Home screen

92 Viewing content on the

mobile device

95 Viewing online content

Basics

74 Using the Charger
76 Using the Gear VR's

touchpad
78 Using the controller
81 Moving the pointer or the

screen
82 Selecting items
82 Using the Universal menu
85 Downloading apps and

content
86 Viewing notifications

received on the mobile

device

6

Read me first

t

Please read this manual before using the Samsung Gear VR (also
referred to as Gear VR) to ensure safe and proper use.

t

To prevent injury or damage to your devices, read the health
and safety warnings and information before using the Gear VR.

t

Use the Gear VR for its intended purpose only. Using the Gear
VR for other purposes may result in injury.

t

The Gear VR cannot be operated by itself. To use the Gear VR,
connect a mobile device to it. Visit

www.samsung.com

to see a

list of compatible mobile devices.

t

To use a mobile device with the Gear VR, upgrade the mobile
device's software to the latest version.

t

Some languages or content may not be available depending on
the region or network.

t

To view the open source license for the Gear VR, refer to

opensource.samsung.com

.

7

Read me first

Instructional icons

Warning: situations that could cause injury to yourself or

others

Caution: situations that could cause damage to your device
or other equipment

Notice: notes, usage tips, or additional information

8

Health and safety warnings

Wearing the Gear VR

Although eyeglasses can be worn inside Gear VR, they
should be removed if the user experiences discomfort. If the
discomfort continues and these glasses are not removed,
this could cause facial injuries. If you have poor eyesight, we
recommended wearing contact lenses when using the Gear
VR.

The Gear VR can be affected by magnetic interference
created by items, such as computers, TVs, or electric cables.
Avoid using the Gear VR in areas affected by magnetic
interference.

Keep the lenses clean and protect them from getting
scratched. If the lenses get dirty or steam up, clean them
with a lens cleaning cloth.

9

Health and safety warnings

t

These health & safety warnings are periodically updated for
accuracy and completeness. Check both

www.samsung.com

and

oculus.com/warnings

for the latest updated content.

HEALTH & SAFETY WARNINGS: To reduce the risk of personal
injury, discomfort or property damage, please ensure that
all users of the Gear VR read the warnings below carefully
before using the Gear VR.

Before Using the Gear VR

t

Read and follow all setup and operating instructions provided
with the Gear VR.

t

Review the hardware and software recommendations for use of
the Gear VR. Risk of discomfort may increase if recommended
hardware and software is not used.

10

Health and safety warnings

t

Your Gear VR is not designed for use with any ineligible device,
accessory and/or software. Use of an ineligible device, accessory
and/or software may result in injury to you or others, and
may cause performance issues or damage to your system and
related services.

t

A comfortable virtual reality experience requires an unimpaired
sense of motion and balance. Do not use the Gear VR when
you are tired, need sleep, are under the influence of alcohol
or drugs, are hung-over, have digestive problems, are under
emotional stress or anxiety, or when suffering from cold, flu,
headaches, migraines, or earaches, as this can increase your
susceptibility to adverse symptoms.

t

We recommend seeing a doctor before using the Gear VR if
you are pregnant, elderly, have pre-existing binocular vision
abnormalities or psychiatric disorders, or suffer from a heart
condition or other serious medical condition.

11

Health and safety warnings

Seizures

Some people (about 1 in 4000) may have severe dizziness, seizures,
epileptic seizures or blackouts triggered by light flashes or patterns,
and this may occur while they are watching TV, playing video
games or experiencing virtual reality, even if they have never
had a seizure or blackout before or have no history of seizures or
epilepsy. Such seizures are more common in children and young
people under the age of 20. Anyone who has had a seizure, loss
of awareness, or other symptom linked to an epileptic condition
should see a doctor before using the Gear VR.

12

Health and safety warnings

Children

The Gear VR should not be used by children under the age of 13, as
young children are in a critical period in visual development. Adults
should monitor children (age 13 and older) who are using or have
used the Gear VR for any of the symptoms described below, and
should limit the time children spend using the Gear VR and ensure
they take breaks during use. Prolonged use should be avoided, as
this could negatively impact hand-eye coordination, balance, and
multi-tasking ability. Adults should monitor children closely during
and after use of the Gear VR for any decrease in these abilities.

13

Health and safety warnings

General Precautions

To reduce the risk of injury or discomfort you should always follow
these instructions and observe these precautions while using the
Gear VR.

t

Use Only In A Safe Environment: The Gear VR produces an
immersive virtual reality experience that distracts you from and
completely blocks your view of your actual surroundings.

−

Always be aware of your surroundings before beginning use
and while using the Gear VR. Use caution to avoid injury.

−

Use of the Gear VR may cause loss of balance.

−

Remember that the objects you see in the virtual
environment do not exist in the real environment, so don’t sit
or stand on them or use them for support.

−

For the safest experience, remain seated or stationary when
using the Gear VR.

−

Serious injuries can occur from tripping, running into or
striking walls, furniture or other objects, so clear an area for
safe use before using the Gear VR.

14

Health and safety warnings

−

Take special care to ensure that you are not near other
people, objects, stairs, balconies, open doorways, windows,
furniture, open flames, ceiling fans or light fixtures or other
items that you can bump into or knock down when using—
or immediately after using—the Gear VR.

−

Remove any tripping hazards from the area before using the
Gear VR.

−

Remember that while using the Gear VR you may be unaware
that people and pets may enter your immediate area.

−

Do not handle sharp or otherwise dangerous objects while
using the Gear VR.

−

Never wear the Gear VR in situations that require attention,
such as walking, bicycling, or driving.

−

The Gear VR can be affected by magnetic interference
created by items, such as computers, TVs, or electric cables.
Avoid using the Gear VR in areas affected by magnetic
interference.

t

Make sure the Gear VR is level and secured comfortably on your
head, and that you see a single, clear image. If you wear the
Gear VR tilted to one side, you may feel discomfort.

15

Health and safety warnings

t

A comfortable virtual reality experience requires an unimpaired
sense of motion and balance. Do not use the Gear VR when
you are tired, need sleep, are under the influence of alcohol
or drugs, are hung-over, have digestive problems, are under
emotional stress or anxiety, or when suffering from cold, flu,
headaches, migraines, or earaches, as this can increase your
susceptibility to adverse symptoms.

t

We recommend seeing a doctor before using the Gear VR if
you are pregnant, elderly, have pre-existing binocular vision
abnormalities or psychiatric disorders, or suffer from a heart
condition or other serious medical condition.

t

People who are prone to motion sickness in the real world also
have a heightened risk of experiencing discomfort while using
the Gear VR. Such individuals should take extra care to read and
follow these warnings carefully.

t

Do not use the Gear VR if you have symptoms of squint,
amblyopia, or anisometropia. Using the Gear VR may aggravate
these symptoms.

16

Health and safety warnings

t

Ease into the use of the Gear VR to allow your body to adjust;
use for only a few minutes at a time at first, and only increase
the amount of time using the Gear VR gradually as you grow
accustomed to virtual reality. Looking around and using
the input device when first entering virtual reality can help
you adjust to any small differences between your real-world
movements and the resulting virtual reality experience.

t

Do not use the Gear VR while in a moving vehicle such as a car,
bus, or train, as this can increase your susceptibility to adverse
symptoms.

t

Take at least a 10 to 15 minute break every 30 minutes, even
if you don’t think you need it. Each person is different, so take
more frequent and longer breaks if you feel discomfort. You
should decide what works best for you.

t

The Gear VR may be equipped with a “pass-through” feature
which permits you to temporarily see your surroundings for
brief real world interaction. You should always remove the Gear
VR for any situation that requires attention or coordination.

17

Health and safety warnings

t

Listening to sound at high volumes can cause irreparable
damage to your hearing. Background noise, as well as
continued exposure to high volume levels, can make sounds
seem quieter than they actually are. Due to the immersive
nature of the virtual reality experience, do not use the Gear
VR with the sound at a high volume so that you can maintain
awareness of your surroundings and reduce the risk of hearing
damage.

−

The Gear VR should be adjusted for each individual user, and
calibrated before starting a virtual reality experience. Failure
to follow this instruction may increase the risk of discomfort.

−

Do not use the Gear VR when the attached mobile device
is hot as this may cause burns. To prevent any injuries, take
frequent breaks when using the Gear VR.

−

Refer to your mobile device online support material for more
information.

18

Health and safety warnings

Discomfort

t

Immediately discontinue use if anyone using the Gear VR
experiences any of the following symptoms: seizures; loss of
awareness; eye strain; eye or muscle twitching; involuntary
movements; altered, blurred, or double vision or other visual
abnormalities; dizziness; disorientation; impaired balance;
impaired hand-eye coordination; excessive sweating; increased
salivation; nausea; lightheadedness; discomfort or pain in the
head or eyes; drowsiness; fatigue; or any symptoms similar to
motion sickness.

t

Just as with the symptoms people can experience after they
disembark a cruise ship, symptoms of virtual reality exposure
can persist and become more apparent hours after use. These
post-use symptoms can include the symptoms above, as well as
excessive drowsiness and decreased ability to multi-task. These
symptoms may put you at an increased risk of injury when
engaging in normal activities in the real world.

19

Health and safety warnings

t

Do not drive, operate machinery, or engage in other visually
or physically demanding activities that have potentially
serious consequences (i.e., activities in which experiencing any
symptoms could lead to death, personal injury, or damage to
property), or other activities that require unimpaired balance
and hand-eye coordination (such as playing sports or riding a
bicycle, etc.) until you have fully recovered from any symptoms.

t

Do not use the Gear VR until all symptoms have completely
subsided for several hours. Make sure you have properly
configured the Gear VR before resuming use.

t

Be mindful of the type of content that you were using prior to
the onset of any symptoms because you may be more prone to
symptoms based upon the content being used.

t

See a doctor if you have serious and/or persistent symptoms.

20

Health and safety warnings

Repetitive Stress Injury

Using the Gear VR can make your muscles, joints or skin hurt. If any
part of your body becomes tired or sore while using the Gear VR,
or if you feel symptoms such as tingling, numbness, burning or
stiffness, stop and rest for several hours before using the Gear VR
again. If you continue to have any of the above symptoms or other
discomfort during or after play, stop using the Gear VR and see a
doctor.

Interference with Medical Devices

The Gear VR contains magnets and can emit radio waves.
These can affect the operation of nearby electronics, including
cardiac pacemakers, hearing aids and defibrillators. If you have a
pacemaker or other implanted medical device, do not use the Gear
VR without first consulting your doctor or the manufacturer of your
medical device. Maintain a safe distance between the Gear VR and
your medical devices, and stop using the Gear VR if you observe a
persistent interference with your medical device.

21

Health and safety warnings

Controller

t

Your G ear VR may have co me w ith a th ird -p ar ty contr ol ler.

t

Consult the manufacturer for health and safety warnings for the
controller.

t

Always use included wrist straps with controllers to secure the
controller to your wrist when in use.

Batteries

t

CHOKING HAZARD. The controllers are not toys. They contain
batteries, which are small parts. Keep away from children
under 3.

t

DO NOT INGEST ANY BATTERY. CHEMICAL BURN HAZARD.

t

If a battery is swallowed, it can cause severe internal burns and
potential perforation of esophagus in just 2 hours and can lead
to death. Keep batteries out of reach of children.

t

If the battery compartment does not close securely, stop using
the product and keep it away from children.

22

Health and safety warnings

t

Risk of fire. Batteries could ignite, explode or leak if installed
backwards, disassembled, overcharged, punctured, crushed,
mixed with used or other battery types, or directly exposed to
fire or high temperature. Do not recharge disposable batteries.
Replace all batteries in a single device at the same time.

t

Keep in original package until ready to use. Properly dispose of
used batteries promptly.

t

Do not allow conductive materials to touch the battery
terminals on the devices. Keep batteries dry and avoid water
intrusion.

t

Do not disassemble, pierce, or attempt to modify batteries.

Electrical Shock

To red uce risk of e lectric sho ck:

t

Do not modify or open any of the components provided.

t

Do not use the product if any cable is damaged or any wires are
exposed.

23

Health and safety warnings

If a power adapter is provided:

t

Do not expose the power adapter to liquid or moisture.

t

Unplug the power adapter before cleaning, and clean only with
a dry cloth.

t

Keep the power adapter away from open flames and other heat
sources.

Use only charging devices and batteries approved by
Samsung. Samsung accessories are designed for your
device to maximize battery life. Using other accessories
may invalidate your warranty and may cause damage. Take
care not to stand up or move around while the Gear VR is
“plugged in”, as this may cause injury to the user or damage
the device.

The Gear VR does not come with a power adapter and
receives its power from the connected mobile device.

24

Health and safety warnings

Damaged or Broken Device

t

Do not use your device if any part is broken or damaged.

t

Do not attempt to repair any part of your device yourself.
Repairs should only be made by an authorized servicer.

Contagious Conditions

To avoid transferring contagious conditions (like pink eye), do
not share the Gear VR with persons with contagious conditions,
infections or diseases, particularly of the eyes, skin or scalp. The
Gear VR should be cleaned between each use with skin-friendly
antibacterial wipes (particularly the lenses) and dried with a
microfiber cloth.

25

Health and safety warnings

Skin Irritation

The Gear VR is worn next to your skin and scalp. Stop using the
Gear VR if you notice swelling, itchiness, or other irritation. If
symptoms persist, contact a doctor.

To avo id dam age t o t he Gear VR

t

Do not leave the Gear VR in direct sunlight. Exposure to direct
sunlight can damage the Gear VR.

t

Do not shine a laser or external light source through the lenses
as it may damage the screen.

t

Store components in their storage case when not in use to
minimize unintentional damage or environmental exposure.

26

Health and safety warnings

Additional Notifications

t

The connected mobile device may become hotter than normal
when used with the Gear VR, especially if you use the devices
to play games for an extended period. When the Gear VR
detects a high temperature, the quality of the application may
be degraded or VR applications may be terminated in order
to prevent overheating. This is normal and does not affect the
mobile device’s lifespan or performance.

t

When using apps that require a higher amount of power or
using these apps for an extended period, the mobile device
may feel hot to the touch. When the Gear VR detects high
temperature, a message appears on the screen warning you to
stop wearing the Gear VR and to wait until it cools down. Stop
using the Gear VR until the mobile device has cooled down,
then resume use. This is normal and should not affect the
mobile device’s lifespan or performance.

27

Health and safety warnings

t

The mobile device’s battery runtime may become shorter than
normal when it is used with the Gear VR since VR applications
use more of the device’s resources and may contribute to
battery drain.

−

You may experience slow loading speed or diminished
playback quality in some circumstances, such as after
extended use (to prevent the device from overheating) or if
your carrier or Wi-Fi network is slow or out of range.

−

The availability of VR-enabled content and applications and
language support may vary by region.

28

Safety information

To prevent injury to yourself and others or damage to your
device, read the safety information about your device
before using it.

Use the device for its intended purpose only.

Do not drop or cause an impact to the charger or the
device.

Do not use or store your device in areas with high
concentrations of dust or airborne materials.

Dust or foreign materials can cause your device to malfunction.

Do not allow the device’s connector to contact conductors,
such as liquid, dust, metal filings, and pencil leads.

Contact with conductors may cause a short circuit or corrosion at
the connector and result in explosion, fire, or damage to the device.

29

Safety information

The device includes detachable parts that may present a
choking hazard. Keep the device away from children and
animals.

Do not insert the device or supplied accessories into the
eyes, ears, or mouth.

Doing so may cause suffocation or serious injuries.

Do not expose the device to heavy smoke or fumes.

Doing so may damage the outside of the device or cause it to
malfunction.

Keep your device dry.

Humidity and liquids may damage the parts or electronic circuits in
your device.

30

Safety information

The device can be used in locations with an ambient
temperature of 0 °C to 35 °C. You can store the device at an
ambient temperature of -20 °C to 50 °C. Using or storing the
device outside of the recommended temperature ranges
may damage the device or reduce the battery’s lifespan.

Do not store your device in very hot areas such as inside a car in the
summertime. Doing so may cause the screen to malfunction, result
in damage to the device, or cause the battery to explode.

Do not look directly at bright light while you are wearing
the device without the mobile device inserted. Doing so
may damage your eyesight.

Do not use the device if errors occur. Continued use of
the device after errors occur may result in discomfort or
personal injury.

If you are allergic to the paint or metal parts on the device,
you may experience itching, eczema, or swelling of the
skin. If this happens, stop using the device and consult your
physician.

31

Safety information

Do not use your device in a hospital, on an aircraft, or in
any automobile that can be affected by radio frequencies.
Doing so may cause malfunctions of equipment and may
result in injury or damage to property.

When connecting the device to other devices via Bluetooth,
avoid using your device within 15 cm of pacemakers, if
possible, as your device can interfere with pacemakers.

Protect your hearing and ears when using a headset.

t

Excessive exposure to loud sounds can cause
hearing damage.

t

Always turn the volume down before plugging the
earphones into an audio source and use only the
minimum volume setting necessary to hear music.

t

Ensure the headset cable is not twisted around nearby objects.

Do not use the device if it is cracked or broken.

Broken glass or acrylic could cause injury to your hands and face.
Take the dev ice to a Samsung S er vice Center to have it repaired.

32

Safety information

Use manufacturer-approved batteries, chargers,
accessories, and supplies.

Samsung cannot be responsible for the user’s safety when using
accessories or supplies that are not approved by Samsung.

Do not disassemble, modify, or repair your device.

Any changes or modifications to your device can void your
manufacturer’s warranty. If your device needs servicing, take your
device to a Samsung Service Center.

When cleaning your device, mind the following.

t

Wipe the device and its lens with a clean soft cloth or a cotton
swab.

t

Do not use chemicals or detergents. Doing so may discolor or
corrode the outside the device.

t

Do not wash the foam cushioning. Doing so may cause the foam
cushioning to deteriorate.

33

Safety information

Handle and dispose of the device and charger with care.

t

Never place the battery or device on or in heating devices, such
as microwave ovens, stoves, or radiators.

t

Never crush or puncture the device.

Allow only qualified personnel to service your device.

Allowing unqualified personnel to service your device may result in
damage to your device and will void your manufacturer’s warranty.

34

Getting started

Package contents

Check the product box for the following items:

t

Gear VR, top strap, main strap, Micro USB device holder (for
replacement), controller, wrist strap, controller holder, two AAA
batteries, and user manual

t

The items supplied with the device and any available
accessories may vary depending on the region or service
provider.

t

The supplied items are designed only for this device and
may not be compatible with other devices.

t

Appearances and specifications are subject to change
without prior notice.

t

Use only Samsung-approved accessories. Using unapproved
accessories may cause performance problems and
malfunctions that are not covered by the warranty.

t

Availability of all accessories is subject to change depending
entirely on manufacturing companies. For more information
about available accessories, refer to the Samsung website.

35

Getting started

Device layout

Gear VR

Back key

Tou ch pad

Home key

Front cover

Focus

adjustment
wheel

36

Getting started

Touc hp ad and keys Function

Touc hp ad

t

Tap to select an item. You can move
to the next or previous item by
swiping forwards or backwards. For
more information, refer to Using
the Gear VR's touchpad. (p. 76)

Home

t

Press to return to the Oculus Home
screen.

Back

t

Press to return to the previous
screen.

t

Press and hold to open the
Universal menu. You can view the
status of the Gear VR and configure
settings.

Focus
adjustment
wheel

t

Rotate to focus by adjusting the
distance between the mobile
device and the Gear VR's lenses.

37

Getting started

Top s tra p l oo p

Main strap loop

Main strap loop

Multipurpose

jack (USB

Type-C)

Device holder
(right)

Device holder

(left)

Foam

cushioning

Proximity
sensor

Lenses

38

Getting started

Controller

You can connect the controller to a mobile device connected with
a Gear VR via Bluetooth. Control various Gear VR features with the
controller keys and touchpad.

Volume key

Trigger

Indicator light

Wrist strap
connection hole

Back key

Battery cover

Tou ch pad

Home key

39

Getting started

Touc hp ad and keys Function

Touc hp ad

t

Press to select an item. You can
move to the next or previous item
by swiping to the left or right. For
more information, refer to Using
the controller. (p. 78)

Home

When the controller is not
connected with a Gear VR:

t

Press to deactivate the controller’s
sleep mode.

t

Press and hold to enter Bluetooth
pairing mode.

When the controller is connected
with a Gear VR:

t

Press to return to the Oculus
Home screen.

t

Press and hold to reorient the
controller's pointer direction
when it is off-center.

40

Getting started

Touc hp ad and keys Function

Back

t

Press to return to the previous
screen.

t

Press and hold to open the
Universal menu. You can view
the status of the Gear VR and
configure settings.

Volume

t

Press to adjust the Gear VR
volume.

Trigger

t

Press to select an item or use it
as a trigger when playing certain
games. Its function may vary
depending on the launched apps.

41

Getting started

Indicator light

Color Status

Flashes red, green, and
blue

t

The controller is in Bluetooth
pairing mode.

Flashes blue three times

t

Bluetooth is connected.

Flashes blue one time

t

Sleep mode is deactivated.

42

Getting started

Connecting straps

Insert the ends of the straps through the strap loops on the Gear VR
and use the velcro to fasten each end.

43

Getting started

Removing straps

Remove the top strap by pulling its loop towards the foam
cushioning. Then, remove the main strap from the Gear VR.

44

Getting started

Installing the Mobile Device

This section outlines the process for removing the cover, replacing
the device holder, and then installing the desired device type.

Removing the Cover

Gently pull the right device holder outwards, then gently remove
the protective front cover.

2

1

45

Getting started

Replacing the device holder

The USB Type-C device holder is attached to the Gear VR when you
first open the packaging. If your mobile device's multipurpose jack
is USB Type-C, you can connect the mobile device to the Gear VR.
If your mobile device's multipurpose jack is Micro USB, replace the
device holder with the Micro USB device holder before connecting
your mobile device to the Gear VR.

Lock switch

Micro USB

device holder

USB Type-C

device holder

Locked Unlocked

46

Getting started

1

Slide the lock switch to the position and remove the device
holder from the Gear VR.

1 2

Lock switch

47

Getting started

2

Select another device holder. While the lock switch is in the
position, slide the device holder into the holder slot. Then, lock
the holder by sliding the lock switch to the

position.

1 2

48

Getting started

t

Do not slide the device holder into the holder slot while
the lock switch is in the

position. This may damage the

lock switch's latch.

t

The lock switch is for locking and unlocking the device
holder. It does not lock/unlock your mobile device when
plugging into/unplugging from Gear VR.

t

Unless you are changing the device holder, make sure the
lock switch is always in the

position.

49

Getting started

Connecting the mobile device

1

Device holder (left)

Device holder (right)

3

2

Position A: For larger devices.

Position B: For smaller devices.

1

Verify the device holder (right) is in the unlocked position by
pulling the device holder (right) to the right until it clicks (

1

).

50

Getting started

2

Verify the device holder (left) is in the correct position for your
device. If you need to adjust position, gently push down on
the device holder (left) (

2

) and slide it between Position A and

Position B as needed (

3

).

5

4

6

51

Getting started

3

Carefully insert the mobile device (face down) at an angle
into the port on device holder (left) (

4

), connecting it to your

mobile device's multipurpose jack.

Ensure that the connector is fully inserted into the mobile
device’s USB port. The device makes a sound when properly
connected, unless your mobile device is set to silent.

Do not forcefully insert the connector into the mobile device
as this may damage the connector. Improper installation can
scratch the mobile device.

4

Gently push the mobile device towards Gear VR until it locks
into place (

5

). The device holder (right) will lock into place,

securing the mobile device (

6

). The mobile device will emit a
sound when it is connected to the Gear VR properly, unless the
mobile device is set to silent.

52

Getting started

t

Ensure that you lock the device holder by sliding the lock
switch to the

position. If not, the mobile device and
device holder may accidentally separate from the Gear VR
and be damaged.

t

Do not twist or bend the Gear VR’s connector when you
connect or disconnect the mobile device. Doing so may
damage the connector.

5

Verify the orientation of the mobile device.

If you insert the mobile device tilted to one side, it may cause
discomfort. In this case, the mobile device screen will not be
aligned properly to the lenses.

53

Getting started

Alignment Tabs

Device Holder
(right)

Correctly Mounted

Verify that your device volume is not set to silent. If the
sound is not emitted when you insert the connector into
the mobile device, the Gear VR did not recognize the
connection. Carefully reconnect the mobile device until you
hear the sound.

Do not leave the Gear VR in direct sunlight. Exposure to
direct sunlight can damage the Gear VR and the connected
mobile device.

54

Getting started

Wearing the Gear VR

Place the Gear VR on your head and adjust the length of the top
strap and the main strap.

t

Do not walk or drive while wearing the Gear VR. Always
be aware of your surroundings while using the Gear VR to
avoid injuring yourself or others.

t

Do not look directly at bright light while you are wearing
the Gear VR without the mobile device inserted. Doing so
may damage your eyesight or cause blindness.

55

Getting started

Although eyeglasses can be worn inside Gear VR, they
should be removed if the user experiences discomfort. If the
discomfort continues and these glasses are not removed,
this could cause facial injuries. If you have poor eyesight, we
recommended wearing contact lenses when using the Gear
VR.

To avo id dam age t o t he Gear VR or mobil e dev ice

t

Do not leave the Gear VR in direct sunlight. Exposure to
direct sunlight can damage the Gear VR or mobile device.

t

Do not expose the lenses to external light sources
including sunlight and lasers, etc., which may cause the
damage on the device.

t

Store components in their storage case when not in use
to minimize unintentional damage or environmental
exposure.

56

Getting started

t

If factory lens protectors are pre-installed on the Gear VR,
remove the lens protectors before you use the Gear VR so
you can see clearly.

t

Keep the lenses clean and protect them from getting
scratched. If the lenses get dirty or steam up, clean them
with the lens cleaning cloth.

t

The foam cushioning may get dirty if your face is sweating
while wearing the Gear VR. Doing so may deteriorate the
quality of the foam cushioning. Ensure that you keep your
face clean and dry when wearing the Gear VR.

t

When you remove the Gear VR from your head, the mobile
device’s screen locks and the touch pad stops working.

t

When you are not wearing the Gear VR, do not place
objects on the Gear VR’s proximity sensor. Doing so may
cause the proximity sensor to stay on and drain the
battery.

t

Wear the Gear VR properly. If you wear the Gear VR tilted to
one side, it may cause discomfort.

57

Getting started

t

If the screen shifts to the left or right, check if the device
holder (left) is in the correct position. Reconnect your
mobile device after sliding the device holder (left) to
position A or B according to the size of your mobile
device's screen.

t

When the screen is tilted, adjust the Gear VR focus wheel
until the screen becomes clear.

t

To use an audio headset while using the Gear VR, connect
it to your mobile device before connecting the mobile
device to the Gear VR. Headsets are sold separately.

t

To control the Gear VR with your controller, connect the
controller to the mobile device you attached to the Gear
VR. (p. 69)

58

Getting started

Separating the devices

Separate the mobile device from the Gear VR when you finish using
it.

Carefully pull the device holder (right) outward (

1

), remove the

connected mobile device (

2

) by carefully sliding it outwards at an

angle.

2

1

Replace the front cover when you finish using the Gear VR.

59

Getting started

Preparing the controller for use

Connecting the wrist strap

When you connect the wrist strap to your controller, you can use
the controller safely without dropping it.

1

While pressing on the backside of the controller, slide the
battery cover in the direction shown below to open it.

Do not bend or twist the battery cover excessively. Doing so
may damage the battery cover.

60

Getting started

2

Insert the wrist strap loop into the wrist strap connection hole
and attach it to the hook to secure it.

2

1

Installing the batteries

1

Insert batteries with the positive and negative terminals
properly aligned with the + and - symbols on the controller.

61

Getting started

2

Place the battery cover on the controller and slide the battery
cover back until it clicks back into place.

t

If the indicator light flashes red while using the controller,
replace the batteries.

t

Do not recharge the provided batteries (AAA batteries).

62

Getting started

Using the controller holder

You can attach the controller holder to the Gear VR's main strap to
store your controller when not using it.

1

Thread the Gear VR's main strap through the controller holder.

63

Getting started

2

Put your controller in the controller holder to store it.

Insert the controller into the controller holder properly. If
it is not securely inserted, the controller may accidentally
separate from the controller holder and become damaged.

If you do not use the controller for an extended period, store
the controller after removing the batteries.

64

Getting started

Installing the Gear VR app (Oculus) and
connecting the controller

To use the Gear VR, you must manually install the Gear VR app
(Oculus). When you connect the mobile device to the Gear VR
for the first time, the Gear VR app (Oculus) installation will start
automatically.

t

Before installing the app, ensure that the mobile device is
connected to a Wi-Fi or mobile network.

t

You cannot download the Gear VR app (Oculus) from an
app store. You can install the Gear VR app (Oculus) only by
connecting your mobile device to the Gear VR.

t

The installation method or screens may differ depending
on the app version.

t

During the installation, you can connect the controller to
your mobile device to control the Gear VR.

1

Unlock your mobile device and turn up the volume.

65

Getting started

2

Carefully install the compatible mobile device into the Gear VR
compartment.

If the mobile device is not connected properly, you are not
prompted to continue with the set up process.

3

At the voice prompt, separate the mobile device from the Gear
VR.

4

On the Gear VR app (Oculus) installation screen, tap START.

5

Read and agree to the health and safety warnings, and the
terms and conditions in the End User License Agreement
(EULA), and then tap NEXT.

6

Tap INSTALL to install the default VR apps.

During this initial process, you might be prompted to install
additional software required to operate Gear VR or update
your mobile device firmware.

66

Getting started

7

To create an Oculus account using your Facebook account, tap
Continue with Facebook. If you continue with your Facebook
account, you can sync your Facebook friends, stream live videos
on Facebook, and more.

To cre ate an Oculus acc oun t, tap Create Account. If you
already have an Oculus account, tap Sign In and sign in to it.
Your Oculus account will be used when using apps and content
provided by Oculus.

8

Follow the on-screen prompts to configure your account.

9

Set a payment method for making payments when you
download paid VR apps or games from the Oculus Store.

10

Follow the on-screen instructions to connect the controller and
choose the hand you will use the controller with.

t

If the controller is not detected, press and hold the
controller's Home key to re-enter Bluetooth pairing mode.

t

The next time you connect the controller, you can connect
it to your mobile device on your mobile device's setting
screen or the Gear VR app (Oculus). (p. 68, p. 69)

67

Getting started

11

Reconnect your mobile device to the Gear VR and place the
Gear VR on your head.

When you sign in to your Oculus account, a tutorial will start.
After viewing the tutorial, the Oculus Home screen will appear.

Control the Gear VR with the controller's keys and touchpad.

t

A proximity sensor inside the Gear VR detects the position
of your face. When you wear the Gear VR, the screen
unlocks and you can use the touchpad or controller to
control your Gear VR environment.

t

The 3D viewing experience may vary depending on your
visual acuity.

t

Unlock your mobile device before using the Gear VR.

t

If the screen appears tilted or skewed while using the Gear
VR, take it off. Then, place the Gear VR on a flat surface
with the lenses facing forwards and the Focus adjustment
wheel at the top. Wait 5–7 seconds before using it again.

68

Getting started

Connecting the controller with the Gear VR app
(Oculus)

1

Press and hold the controller's Home key to enter Bluetooth
pairing mode.

The indicator light will flash red, green, and blue.

2

On your mobile device, launch the Gear VR app (Oculus),
tap

, and then select the controller menu to connect the

controller.

The indicator light will flash blue three times.

The process for connecting the controller is subject to
change depending on the Oculus service.

3

Reconnect your mobile device to the Gear VR and wear the
Gear VR.

Control the Gear VR with the controller's keys and touchpad.

69

Getting started

Connecting the controller via Bluetooth

You can connect the controller via Bluetooth only on mobile
devices running Android 6.0 or higher. If you cannot connect
the controller via Bluetooth, connect it with the Gear VR app
(Oculus).

1

Press and hold the controller's Home key to enter Bluetooth
pairing mode.

The indicator light will flash red, green, and blue.

70

Getting started

2

After activating your mobile device's Bluetooth feature, tap
Gear VR Controller(0000) on the list of available devices to
complete Bluetooth pairing.

The indicator light will flash blue three times.

The PIN for the controller is the four-digit number in
parenthesis displayed on the mobile device’s Bluetooth
settings screen. The number differs depending on the
controller.

3

Reconnect your mobile device to the Gear VR and place the
Gear VR on your head.

Control the Gear VR with the controller's keys and touchpad.

71

Getting started

Disconnecting and reconnecting the controller

If you remove the Gear VR from your head or the current
connection ends, the controller enters sleep mode. Press the
controller's trigger, touchpad, or any keys to deactivate sleep mode
and re-enter Bluetooth pairing mode.

The controller will be reconnected to the previous mobile device
automatically.

t

If the controller and the mobile device are not kept within
the Bluetooth connection range, the controller will be
disconnected.

t

If the batteries are removed from the controller or the
Bluetooth feature is deactivated in the mobile device, the
controller will be disconnected.

t

If the Bluetooth connection is lost due to a problem with
the connected mobile device, access the Bluetooth menu
on the mobile device to pair the devices again.

72

Getting started

Notices for using Bluetooth

Bluetooth is a wireless technology standard that uses a 2.4 GHz
frequency to connect to various devices over short distances. It can
connect and exchange data with other Bluetooth enabled devices,
such as mobile devices, computers, printers, and other digital home
appliances, without connecting via cables.

t

To avoid problems when connecting your controller to another
device, place the devices close to each other.

t

Ensure that your controller and the other Bluetooth device are
within the maximum Bluetooth range. The distance may vary
depending on the environment the devices are used in.

t

Ensure that there are no obstacles between the controller and
a connected device, including human bodies, walls, corners, or
fences.

t

Do not touch the Bluetooth antenna of a connected device.

t

Bluetooth uses the same frequency as some industrial, scientific,
medical, and low power products and interference may occur
when making connections near these types of products.

73

Getting started

t

Some devices, especially those that are not tested or approved
by the Bluetooth SIG, may be incompatible with your controller.

t

Do not use the Bluetooth feature for illegal purposes
(for example, pirating copies of files or illegally tapping
communications for commercial purposes).

74

Basics

Using the Charger

You can connect the charger to the multipurpose jack on the
bottom of the Gear VR.

t

Use only Samsung-approved USB cables and power
adapters.

t

Micro USB Connectors are sold separately.

Micro USB

charging cable

Micro USB
Connector

t

When connected to the charger, it is the connected mobile
device that is being charged and not the Gear VR.

75

Basics

t

If using the Gear VR while the charger is connected to the Gear
VR’s multipurpose jack:

−

It is powered by the charger and does not use the mobile
device’s battery. When you use content that has high power
demand (more than 1 A) while the charger is connected, the
Gear VR uses two power sources.

−

In high power demand situations, the Gear VR draws power
from both the charger and the mobile device’s battery at the
same time.

t

If the Gear VR is disconnected from the charger while it is being
used:

−

The image on the screen may be briefly inactive.

−

During this period, the screen recalibrates and the Gear VR
may not recognize your head movements.

t

If the Gear VR is not used while the charger is connected:

−

The mobile device’s battery will be charged.

t

If you reconnect the mobile device to the Gear VR while the
charger is connected, the Gear VR may not recognize the
mobile device. Remove the charger before you connect the
mobile device.

76

Basics

t

To save energy, unplug the charger when not in use. The
charger does not have a power switch, so you must unplug
the charger from the electric socket when not in use to avoid
wasting power.

t

The charger should remain close to the electric socket and
easily accessible while charging.

t

Replace the front cover once you have finished using the Gear
VR.

Using the Gear VR's touchpad

The touchpad is located under the Back key and the Home key. Use
the touchpad to select items or to control the Gear VR.

To avoid damaging the Gear VR's touchpad, do not tap it
with anything sharp.

t

A proximity sensor in the Gear VR detects the position of
your face and activates the touchpad. When you are not
wearing the Gear VR, the touchpad will not work.

t

The touchpad functions may vary by app.

77

Basics

Tappin g

t

Select an item.

t

While playing a video, show available
features.

Swiping forwards or backwards

t

Move to the next or previous item.

t

Scroll right or left on a list.

t

Reject an incoming call.

78

Basics

Swiping upwards or downwards

t

Scroll up or down on a webpage or list.

t

While viewing an image, enlarge or
reduce its size.

Some apps may not support upwards or downwards
swiping actions.

Using the controller

Control the Gear VR by moving your wrist in any direction to move
the pointer and use the touchpad to select items.

To avoid damaging the controller's touchpad, do not tap it
with anything sharp.

t

To use t he co ntroller, con nect it t o yo ur mobil e devic e.

t

The controller functions may vary by app.

79

Basics

Pressing

t

Select an item.

t

While playing a video, show available
features.

Moving

t

Move your wrist to move the pointer
left, right, up, and down on the screen.

Swiping to the left or right

t

Move to the next or previous item.

t

Scroll right or left on a list.

t

Reject an incoming call.

80

Basics

Swiping upwards or downwards

t

Scroll up or down on a webpage or list.

t

While viewing an image, enlarge or
reduce its size.

Some apps may not allow you to
use the swipe function.

Using the trigger

t

Press to select an item or use it as a
trigger when playing certain games. Its
function may vary depending on the
launched apps.

81

Basics

Moving the pointer or the screen

The Gear VR recognizes your head movements. Move your head in
any direction to move the pointer or the screen.

To control the Gear VR with your controller, move your wrist in any
direction to move the pointer.

t

The pointer is located in the center of the screen. Some
apps and content may not display the pointer at all times.

t

Depending on the app, there may be screen movement
restrictions.

82

Basics

Selecting items

You can select items by moving your head and then tapping the
Gear VR's touchpad. You can also select items by moving your
controller with your wrist and then pressing the touchpad.

Move the pointer to the item you want. When the border of
the item is highlighted, tap the Gear VR's touchpad or press the
controller's touchpad to select it.

Using the Universal menu

You can use the Universal menu to configure settings for the Gear
VR and to capture the Gear VR's screen. Also, you can view the
current time, remaining battery power, and more.

Press and hold the Gear VR's Back key or the controller's Back key
to open the Universal menu. To return to the previous screen, press
the Gear VR's Back key or the controller's Back key.

83

Basics

t

: Return to the Oculus Home screen.

t

: View your Oculus account profile.

t

: View your friends list and check the friend request. You can
invite your friends to the party room and play games and watch
videos together.

t

: View incoming call and message notifications.

t

: Display setting options.

−

: Adjust the volume.

−

: Adjust the brightness.

84

Basics

−

: Align the screen with the current direction you are

facing.

−

: Choose the hand you will use the controller with.

−

: Set the Gear VR to turn pop-up messages on or off for

incoming calls and notifications.

−

: Activate or deactivate the Bluetooth feature.

−

: Activate or deactivate the Wi-Fi feature.

t

: Display utility options.

−

: Capture the Gear VR's screen.

−

: Record the Gear VR's screen.

−

: Activate the mobile device's rear camera to see outside
the Gear VR. To deactivate the camera, select the Turn
Camera Off icon.

t

These features may not be available in some apps.

t

The Universal menu screen may appear differently
depending on the Oculus service.

85

Basics

Downloading apps and content

Launch the Oculus Store app and download various apps and
content, such as 360-degree videos or photos.

On the Oculus Home screen, select Store. Select the app or content
you want to download. Then, select Free or select the button that
shows the app’s price, then follow the on-screen instructions to
confirm the download.

Removing apps

To rem ove a dow nload ed ap p, se lect Library → next to the app
you want to delete. Select Uninstall.

86

Basics

Viewing notifications received on the
mobile device

Viewing caller information or rejecting calls

If you receive a call while you are using the Gear VR, a pop-up
message is displayed on the screen. You can view the caller
information or reject the call.

To answer a call, separate the mobile device from the Gear VR and
answer the call on the mobile device

To reject a call, swipe backwards or forwards on the Gear VR's
touchpad or swipe to the left or right on the controller's touchpad.

The mobile device may become hotter than normal when
it is used with the Gear VR. This situation occurs especially
if you use the device to watch video or play games for an
extended period. Removing your device from Gear VR and
answering a call when the mobile device is hot may cause
minor burns to your face or ear. To avoid burns, remove the
mobile device and wait for it to cool down. If you have to
answer calls while it is still hot, connect a headset or use the
speakerphone.

87

Basics

The Gear VR blocks pop-up messages for incoming calls
when you block pop-up messages for incoming calls or
other notifications. You can turn on pop-up messages in the
Universal menu. (p. 84)

Viewing notifications

While using the Gear VR, you can check general notifications,
such as events, messages, and alarms. When a notification comes
in, a pop-up message is displayed on the screen. To see more
notification details, check them on the mobile device after you
separate it from the Gear VR.

88

Viewing content

Viewing content on the Oculus Home
screen

Oculus Home screen

When you connect your mobile device to the Gear VR and wear
the Gear VR, you will see the Oculus Home screen. On the Oculus
Home screen, select an app or content to view various 2D, 3D, or
360-degree content. While using the Gear VR, press the Gear VR's
Home key or the controller's Home key to return to the Oculus
Home screen.

89

Viewing content

Tutorial

Oculus

Store

Recommendations

Friends list

Recent

apps

The Oculus Home screen may appear differently depending
on the Oculus service.

Library

View the content and apps you downloaded from the Oculus Store.

On the Oculus Home screen, select Library. Move to the content or
app you want to use and select it.

90

Viewing content

Oculus Video

Enjoy various videos and 3D movies in your own virtual movie
theatre.

You can also vie w 360- de gre e vi deos, a s we ll a s 2D or 3D videos,
saved in your mobile device.

If the video app is not installed as a default app, download it from
the Oculus Store.

1

On the Oculus Home screen, select Library → Oculus Video.

2

Select a category from the left of the page and select a video.

3

Move your head in any direction or use the controller to watch
the videos from various angles.

Swipe backwards or forwards on the Gear VR's touchpad or
swipe to the left or right on the controller's touchpad to rewind
or fast-forward.

While watching videos, tap the Gear VR's touchpad or press the
controller's touchpad to use the following features:

t

/ : Pause and resume playback.

t

: Return to the playlist.

91

Viewing content

Oculus 360 photos

View recommended 360-degree images, 3D art images, and other
various images.

You can also vie w 360- de gre e im ages save d in yo ur m obile de vice.

If the 360 photos app is not installed as a default app, download it
from the Oculus Store.

1

On the Oculus Home screen, select Library → Oculus 360
Photos.

2

Select a category from the left of the page and select an image.

3

Move your head in any direction to view the images from
various angles.

Swipe backwards or forwards on the Gear VR's touchpad or
swipe to the left or right on the controller's touchpad to view
the previous or next image.

92

Viewing content

While viewing the image, tap the Gear VR's touchpad or press the
controller's touchpad to use the following features:

t

/ : Pause and resume a slideshow.

t

/ : Move to the previous or next image.

t

: Return to the list.

Viewing content on the mobile device

View images and videos saved in your mobile device. You can also
enjoy 2D and 3D videos with subtitles and stereophonic sound, as
well as 360-degree content captured by 360 cameras, such as the
Gear 360.

If the Samsung Gallery app is not installed as a default app,
download it from the Oculus Store.

On the Oculus Home screen, select Library

→

Samsung Gallery.

Playing videos

Select a video and play it.

93

Viewing content

Swipe backwards or forwards on the Gear VR's touchpad or swipe
to the left or right on the controller's touchpad to rewind or fast­forward.

While watching videos, tap the Gear VR's touchpad or press the
controller's touchpad to use the following features:

t

/ : Pause and resume playback.

t

/ : Move to the previous or next video.

t

: Select a video from the video list.

t

: Select a view mode.

−

2D: View the video in 2D.

−

360°: View 360-degree videos.

−

180°: View 180-degree videos.

−

3D SBS/3D TB/360° 3D SBS/360° 3D TB/180° 3D SBS/180°
3D TB: View the 3D video in 3D.

t

: Select whether to display subtitles.

t

: Access additional options.

−

: Reposition the screen.

−

: Adjust the brightness of the background.

94

Viewing content

Viewing images

Select an image.

Swipe backwards or forwards on the Gear VR's touchpad or swipe
to the left or right on the controller's touchpad to view the previous
or next image.

To enlarge or reduce the size of the image, swipe upwards or
downwards on the Gear VR's touchpad or controller's touchpad.

To reorient the screen in the direction you are currently facing, tap
the Gear VR's touchpad or press the controller's touchpad. You
can also move the screen by moving your head while tapping or
pressing and holding the touchpad. Alternatively, press the Gear
VR's Back key twice.

While viewing images, tap the Gear VR's touchpad or press the
controller's touchpad to use the following features:

t

/ : View the next or previous image.

t

: View the images as a slide show.

95

Viewing content

t

: Select the view mode.

−

2D: View 2D images.

−

360: View 360-degree images.

−

Panorama: View panorama images.

t

: Access additional options.

−

: Reposition the screen.

−

: Adjust the brightness of the background.

−

: Rotate the image.

Viewing online content

Using the Samsung Internet app, you can view Internet content
and videos on webpages.

Download the Samsung Internet app from the Oculus Store and
launch the app to view online content.

Copyright

Copyright © 2017 Samsung Electronics

This manual is protected under international copyright laws.

No part of this manual may be reproduced, distributed, translated,
or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written
permission of Samsung Electronics.

Trademarks

t

SAMSUNG and the SAMSUNG logo are registered trademarks of
Samsung Electronics.

t

Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
worldwide.

t

All other trademarks and copyrights are the property of their
respective owners.
