Samsung SH37F, ML32E, ML55E, IF020H, IF025H Quick Reference Manual

Quick
Reference
Guide

Samsung SMART Signage Solutions

Mirror

ML Series

Model ML32E ML55E

Display

Screen Size 32" 55"

Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 300 nits 400 nits

Contrast Ratio (Typical) 4500:1 4500:1

Viewing Angle 178° / 178° 178° / 178°

Orientation

Landscape / Portrait Landscape / Portrait

Response Time 8ms 6ms

Connectivity

Input

DP1, HDMI1, Stereo Mini Jack,
DVI Audio (Common), USB 2.0 x 2

DP1, HDMI1, Stereo Mini Jack,
DVI Audio (Common), USB 2.0 x 2

Output Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45

External Sensor IR, Proximity Sensor IR, Proximity Sensor

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 55W / 77W 104W / 176W

Power Consumption (Standby) 0.33W (Sleep Mode) 0.32W (Off Mode) 0.34W (Sleep Mode) 0.31W (Off Mode)

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 1), WiFi Module Embedded

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 2), WiFi Module Embedded

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

SMART Signage Platform Compliant Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

VESA Standard Wall Mount Interface 200 x 200 mm 400 x 400 mm

24/7 Operation Yes Yes

Speaker Type Built in Speaker (10W x 1) Built in Speaker (10W x 1)

Dimensions

Product Dimension (Without Stand) 29.14" x 17.07" x 2.26" 49.18" x 28.35" x 2.26"

Packaging Dimension 32.17" x 19.80" x 5.75" 54.33" x 33.86" x 8.46"

Bezel Width 1 mm (Black Printing Line 20.4) 1 mm (Black Printing Line 49.3)

Weight

Product Weight 17.4 lbs 56.2 lbs

Shipping Weight 21.6 lbs 63.9 lbs

Service

Standard Warranty

3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Mount (Optional)

WMN4070SD WMN4270SD

Stand (Optional)

STN-L3240E STN-L4655E

Media Player (Optional)

SBB-DA SBB-DA

Green Management

Emission Standard Class A Class A

ENERGY STAR

®

5.0 Compliant

N/A N/A

RoHS Compliant Yes Yes

Packaging Recyclability Packing Materials Packing Materials

LED

IF Series

Model IF015H IF020H IF025H

Physical Paramaters

Pixel Pitch 1.5 mm 2.0 mm 2.5 mm

Pixel Configuration 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue

Pixel Density 444,444 m

2

/ 41,290 ft

2

250,000 m2 / 23,225 ft

2

160,000 m

Cabinet / Module Configuration (L x H) 320 x 360 Pixels 240 x 270 Pixels 192 x 216 Pixels

Diode Type Surface Mount Device (SMD) Surface Mount Device (SMD) Surface Mount Device (SMD)

Dimensions (L x H x D) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet)

Weight 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet)

Optical Parameters

Brightness 800 nits 1,200 nits 1,200 nits

Contrast Ratio 5,000:1 5,000:1 5,000:1

Viewing Angle - Horizontal / Vertical 160° / 140° 160° / 140° 160° / 140°

Number of Colors 11.2 Trillion Colors 11.2 Trillion Colors 11.2 Trillion Colors

Color Wavelength

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Color Temperature - Default / Adjustable 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K

Electrical Parameter

Video Rate 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

Input Power Range 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz

Power Consumption (Max) / (Typical)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

580 (W/2) / 150 (W/Cabinet)
190 (W/2) / 50 (W/Cabinet)

Refresh Rate 2,500 Hz, 4,000 Hz 3,700 Hz, 6,200 Hz 2,500 ~ 4,000 Hz

Operation Conditions

Working Temperature 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F)

IP Rating IP20 IP20 IP20

LED Lifetime 100,000 Hours 100,000 Hours 100,000 Hours

Bezel-free, cabinet-based format makes it simple to expand
screen size by adding LED signage cabinets. S-Box eliminates
need for video processor.

Model SNOW-1703U SNOW-1703F

Physical Parameters

Resolution UHD FHD
S/W Platform Tizen 2.4 Tizen 2.4
SoC Hawk Hawk
Log Function Supported Supported
Diagnostics Supported Supported
Ethernet Supported Supported
Input / Output Signal DP, HDMI, USB / DP, HDBT DP, HDMI, USB / DP, HDBT
Magic Info Solution Supported (CMS/Diagnostics) Supported (CMS/Diagnostics)
Bit-depth (bit) 10 bit (RGB 4:4:4) 10 bit (RGB 4:4:4)
Refresh Rate (Hz) 50 / 60Hz 50 / 60Hz
Power Consumption (Max) / (Typical) TBD / TBD TBD / TBD
Working Temperature 0°C~40°C (32°F to 104°F) 0°C~40°C (32°F to 104°F)
Operation Humidity 10% ~ 80% 10% ~ 80%
Image Quality Enhancing HDR, Dynamic Peaking HDR, Dynamic Peaking
Dimensions (W x D x H) 8.8" x 1.3" x 13.8" 8.8" x 1.3" x 13.8"
Weight (lbs) TBD TBD

Stretch

SH Series

Model SH37F

Display

Screen Size 37"

Panel Technology 60Hz D-LED BLU

Resolution 1920 x 540 (16:4.5)

Brightness 700 nits

Contrast Ratio (Typical) 4000:1

Viewing Angle 178° / 178°

Orientation Landscape / Portrait

Response Time 16ms

Connectivity

Input

DVI-I, DisplayPort 1.2, HDMI 1.4 (1), HDCP 2.2
Stereo Mini Jack, USB 2.0 x 1

Output DP1.2 (Loop-out), Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Mini Jack, RJ45

External Sensor IR

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 56W / 77W

Power Consumption (Standby) < 0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C

Operating Humidity 10 - 80%

Features

Special

Hardware

USB Plug and Play, Tilting and Portrait Install support,
Daisy Chains, Shock and Vibration certificated (IEC 61373)

Software

Magic Clone (to USB), RS232 MDC, Videowall, Smart
Scheduling, Auto Source Switching, Internal Media Player

SMART Signage Platform Compliant Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, Samsung Proprietary OS (VDLinux)

VESA Standard Wall Mount Interface 400 x 200 mm

Dimensions

Product Dimension (Without Stand) 36.0" x 11.0" x 1.5"

Packaging Dimension 43.3" x 14.5" x 4.8"

Bezel Width 5.7 mm (Side), 12 mm (Top / Bottom)

Weight

Product Weight 14.5 lbs

Shipping Weight 18.7 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

QSG, Warranty Card, Regulatory Guide, Power Cord,
Batteries, Remote Control, RS232C (IN) Adaptor, Screw,
External Remote Control Sensor, Cover-Jack

Mount (Optional) N/A

Stand (Optional) N/A

Media Player (Optional) SBB (Not Attachable)

Green Management

Emission Standard Class A

ENERGY STAR 5.0 Compliant

TBD

RoHS Compliant Ye s

Packaging Recyclability Packing Materials

LED

IF Series

Model IF015H IF020H IF025H

Physical Paramaters

Pixel Pitch 1.5 mm 2.0 mm 2.5 mm

Pixel Configuration 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue

Pixel Density 444,444 m

2

/ 41,290 ft

2

250,000 m2 / 23,225 ft

2

160,000 m2 / 14,864 ft

2

Cabinet / Module Configuration (L x H) 320 x 360 Pixels 240 x 270 Pixels 192 x 216 Pixels

Diode Type Surface Mount Device (SMD) Surface Mount Device (SMD) Surface Mount Device (SMD)

Dimensions (L x H x D) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet)

Weight 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet)

Optical Parameters

Brightness 800 nits 1,200 nits 1,200 nits

Contrast Ratio 5,000:1 5,000:1 5,000:1

Viewing Angle - Horizontal / Vertical 160° / 140° 160° / 140° 160° / 140°

Number of Colors 11.2 Trillion Colors 11.2 Trillion Colors 11.2 Trillion Colors

Color Wavelength

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Color Temperature - Default / Adjustable 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K

Electrical Parameter

Video Rate 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

Input Power Range 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz

Power Consumption (Max) / (Typical)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

580 (W/2) / 150 (W/Cabinet)
190 (W/2) / 50 (W/Cabinet)

Refresh Rate 2,500 Hz, 4,000 Hz 3,700 Hz, 6,200 Hz 2,500 ~ 4,000 Hz

Operation Conditions

Working Temperature 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F)

IP Rating IP20 IP20 IP20

LED Lifetime 100,000 Hours 100,000 Hours 100,000 Hours

Media
Players

PIM/SBB Series

Model PIM-PB28E PIM-PB32E SBB-DA SBB-B32D SBB-SSE SBB-SSF

Media Player

CPU

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

Cortex-A9 1GHz Quad Core CPU Cortex-A12 1GHz Quad Core CPU

GPU AMD R6 Graphics AMD R6 Graphics AMD R6 Graphics AMD R6 Graphics

2D & 3D Graphics Engine

- Up to 1920x1080. 32bpp

- Supports OpenGL ES

2D & 3D Graphics Engine

- Up to 3840x2160. 32bpp

- Supports OpenGL ES

FDM/HDD/SSD SSD 128GB SSD 32GB SSD 64GB SSD 32GB

8GB
(2.65GB Occupied by O/S,

5.35GB Available)

8GB
((3.75GB Occupied by O/S,

4.25GB Available)

Memory 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2)

1.5GB
48bit DDR3-933 (1866MHz)

2.5GB
96bit DDR3-933 (1866MHz)

Ethernet Gigabit Ethernet (RJ-45) Gigabit Ethernet (RJ-45) GbE Ethernet (RJ-45) GbE Ethernet (RJ-45) 10/100Mbps (MDC) 10/100Mbps (MDC)

Connectivity

USB

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2 USB 2.0 Port x 2

Output

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

1st: MagicInfo Out (Up-to
3840 x 2160 @ 30Hz)
2nd: DisplayPort Out (Up-to
3840 x 2160 @ 60Hz) Optimized
for FHD Play or 1 UHD Image

1st: MagicInfo Out (Up-to
3840 x 2160 @ 30Hz)
2nd: DisplayPort Out (Up-to
3840 x 2160 @ 60Hz) Optimized
for FHD Play or 1 UHD Image

DVI Out DP 1.2 (Up-to 3840 x 2160

@ 60Hz)
DVI (Up-to 1920 x 1080 @ 60Hz)

Others Mic In, Audio Out Mic In, Audio Out RJ-45, RS232 (D-SUB 9P) RJ-45, RS232 (D-SUB 9P)

RJ-45, RS232 In / Out (Stereo),
IR In, Audio In, HDMI1, HDMI2,
AV / Component

RJ-45, RS232 In / Out (Stereo),
IR In, Audio Out HDMI1, HDMI2

Operating System

Windows Embedded 8.1
Industrial Pro (64bit)

Windows Embedded
Standard 7 (32bit)

Windows Embedded Standard 7 Windows Embedded Standard 7

Samsung Proprietary OS
(VDLinux)

Samsung Proprietary Tizen2.4
OS (VDLinux)

Power

Type N/A (OPS Pass Through) N/A (OPS Pass Through) Internal Internal Adapter Adapter

Power Supply N/A N/A

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

Power Consumption 70W (Max) / 27W (Typical) 70W (Max) / 27W (Typical) 69W (Max) / 30W (Typical) 69W (Max) / 30W (Typical)

19W (Max) / 13W (Typical) /
17W (Rating)

TBD

Mechanical Spec

Dimension

Set 7.9" x 6.9" x 1.4" 7.9" x 6.9" x 1.4" 12.7" x 8.8" x 1.6" 12.7" x 8.8" x 1.6" 12.6" x 8.8" x 1.5" 12.6" x 8.8" x 1.5"

Package 16.9" x 9.8" x 2.2" 16.9" x 9.8" x 2.2" 17" x 10.6" x 3.7" 17" x 10.6" x 3.7" 17" x 10.5" x 3.7" 17" x 10.6 x 3.7

Weight

Set 2.6 lbs 2.6 lbs 4.0 lbs 4.0 lbs 2.8 lbs 2.8 lbs

Package 4.2 lbs 4.2 lbs 5.5 lbs 5.5 lbs 4.6 lbs 4.6 lbs

Operation

Operating Temperature 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C

Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Accessories

Included

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord, IR
sensor, RS-232 gender, DP
Cable (2m)

Bezel-free, cabinet-based format makes it simple to expand
screen size by adding LED signag e cabinets. S-Box eliminates
need for video proce ssor.

LED

Model SNOW-1703U SNOW-1703F

Physical Parameters

Resolution UHD FHD
S/W Platform Tizen 2.4 Tizen 2.4
SoC Hawk Hawk
Log Function Supported Supported
Diagnostics Supported Supported
Ethernet Supported Supported
Input / Output Signal DP, HDMI, USB / DP, HDBT DP, HDMI, USB / DP, HDBT
Magic Info Solution Supported (CMS/Diagnostics) Supported (CMS/Dia gnostics)
Bit-depth (bit) 10 bit (RGB 4:4:4) 10 bit (RGB 4:4:4)
Refresh Rate (Hz) 50 / 60Hz 50 / 60Hz
Power Consumption (Max) / (Typical) TBD / TBD TBD / TBD
Working Temperature 0°C~40°C (32°F to 104°F) 0°C~40°C (32°F to 104°F)
Operation Humidity 10% ~ 80% 10% ~ 80%
Image Quality Enhancing HDR, Dynamic Peaking HDR, Dynamic Peaking
Dimensions (W x D x H) 8.8" x 1.3" x 13.8" 8.8" x 1.3" x 13.8"
Weight (lbs) TBD TBD

Samsung large format displays can connect to
a variety of media players for complete flexibility.
Connect a Samsung Plug-In-Module (PIM), or a
Samsung Set Back Box (SBB). For even more
flexibility, connect a Windows PC or notebook,
or a third party med ia player.

Quick
Reference
Guide

Samsung SMART Signage Solutions

Mirror

ML Series

Model ML32E ML55E

Display

Screen Size 32" 55"

Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 300 nits 400 nits

Contrast Ratio (Typical) 4500:1 4500:1

Viewing Angle 178° / 178° 178° / 178°

Orientation

Landscape / Portrait Landscape / Portrait

Response Time 8ms 6ms

Connectivity

Input

DP1, HDMI1, Stereo Mini Jack,
DVI Audio (Common), USB 2.0 x 2

DP1, HDMI1, Stereo Mini Jack,
DVI Audio (Common), USB 2.0 x 2

Output Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45

External Sensor IR, Proximity Sensor IR, Proximity Sensor

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 55W / 77W 104W / 176W

Power Consumption (Standby) 0.33W (Sleep Mode) 0.32W (Off Mode) 0.34W (Sleep Mode) 0.31W (Off Mode)

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 1), WiFi Module Embedded

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 2), WiFi Module Embedded

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

SMART Signage Platform Compliant Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

VESA Standard Wall Mount Interface 200 x 200 mm 400 x 400 mm

24/7 Operation Yes Yes

Speaker Type Built in Speaker (10W x 1) Built in Speaker (10W x 1)

Dimensions

Product Dimension (Without Stand) 29.14" x 17.07" x 2.26" 49.18" x 28.35" x 2.26"

Packaging Dimension 32.17" x 19.80" x 5.75" 54.33" x 33.86" x 8.46"

Bezel Width 1 mm (Black Printing Line 20.4) 1 mm (Black Printing Line 49.3)

Weight

Product Weight 17.4 lbs 56.2 lbs

Shipping Weight 21.6 lbs 63.9 lbs

Service

Standard Warranty

3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Mount (Optional)

WMN4070SD WMN4270SD

Stand (Optional) STN-L3240E STN-L4655E

Media Player (Optional) SBB-DA SBB-DA

Green Management

Emission Standard Class A Class A

ENERGY STAR

®

5.0 Compliant N/A N/A

RoHS Compliant Yes Yes

Packaging Recyclability Packing Materials Packing Materials

Videowall

UD Series

Model UD46E-A UD55E-A UD46E-B UD55E-B UH46F5 UH55F-E

Display

Screen Size 46" 55" 46" 55" 46" 55"

Panel Technology D-LED DID D-LED DID D-LED DID D-LED DID D-LED DID D-LED DID

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness Max 700 nits Max 700 nits Max 500 nits Max 500 nits Max 700 nits Max 700 nits

Contrast Ratio (Typical) 3500:1 4000:1 3500:1 3500:1 4000:1 4000:1

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait

Response Time 8ms 8ms 8ms 8ms 8ms 8ms

Connectivity

Input

RGB Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2

VIDEO HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2

AUDIO Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

Output

RGB DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out)

AUDIO Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In/Out), RJ45 RS232C (In / Out), RJ45

External Sensor Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient)

Power

Type Internal Internal Internal Internal Internal Internal

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 128W / 187W 180W / 297W 87W / 143W 136W / 198W 120W / 132W 180W / 297W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 44%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 44%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Lamp Error Detection, Anti Retention (Haze
44%), Temperature Sensor, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Videowall (10 x 10), Pivot Display, Image Rotation,
Button Lock, DP 1.2 Digital Daisy Chain (Supporting 10 x 10 UHD
Resolution, HDCP Support), Smart F/W Update, Clock Battery
(80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Lamp Error Detection, Anti Retention (Haze
44%), Temperature Sensor, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Videowall (10 x 10), Pivot Display, Image Rotation,
Button Lock, DP 1.2 Digital Daisy Chain (Supporting 10x10 UHD
Resolution, HDCP Support), Smart F/W Update, Clock Battery
(80hrs Clock Keeping)

ACM Support(Advanced Color Management), Auto Source
Switching & Recovery, Haze 11%, Temperature Sensor,
RS232C/RJ45 MDC,Plug and Play (DDC2B), Videowall
(15 x 15(OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 25%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

SMART Signage Platform Compliant No No No No N/A No

Media Player N/A N/A N/A N/A N/A N/A

VESA Standard Wall Mount Interface 600 x 400 mm 600 x 400 mm 600 x 400 mm 600 x 400 mm 400 x 400 mm 600 x 400 mm

Dimensions

Product Dimension (Without Stand) 40.2" x 22.7" x 3.8" 47.7" x 26.9" x 3.8" 40.2" x 22.7" x 3.8" 47.8" x 26.9" x 3.8" 40.3" x 22.7" x 1.8" 47.6" x 26.8" x 3.7"

Packaging Dimension 45.6" x 28.1" x 11" 53.3" x 31.8" x 12.5" 45.7" x 28.1" x 11.0" 57.1" x 35.6" x 15.2" 46.1" x 28.8" x 10.9" 53.3" x 31.8" x 12.5"

Bezel Width 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 3.4 mm (U/L), 2.0 mm (R/B) 0.96 mm (U/L), 0.47 mm (R/B)

Weight

Product Weight 35.7 lbs 47.3 lbs 39.7 lbs 47.4 lbs 29.1 lbs 46.29 lbs

Shipping Weight 49.8 lbs 63.9 lbs 49.4 lbs 63.9 lbs 42.3 lbs 60.4 lbs

Service

Standard Warranty 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, DP Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, DP Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9
Cable, Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Mount (Optional) WMN-46VD WMN-55VD WMN-46VD WMN-55VD WMN-46VD WMN-55VD

Stand (Optional) MID-UD46DS MID-UD55DS MID-UD46DS MID-UD55DS N/A N/A

External Media Player SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA / SBB-SS08E SBB-DA, SBB-B32D (Slide-in)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC

RoHS Compliant Yes Yes Yes Yes Ye s Yes

Energy Star 6.0 Compliant ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) TBD ENERGY STAR 6.0 (USA)

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

LED

IF Series

Model IF015H IF020H IF025H

Physical Paramaters

Pixel Pitch 1.5 mm 2.0 mm 2.5 mm

Pixel Configuration 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue 1 Red, 1 Green, 1 Blue

Pixel Density 444,444 m

2

/ 41,290 ft

2

250,000 m2 / 23,225 ft

2

160,000 m2 / 14,864 ft

2

Cabinet / Module Configuration (L x H) 320 x 360 Pixels 240 x 270 Pixels 192 x 216 Pixels

Diode Type Surface Mount Device (SMD) Surface Mount Device (SMD) Surface Mount Device (SMD)

Dimensions (L x H x D) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet) 18.9" x 21.3" x 2.16" (Per Cabinet)

Weight 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet)

Optical Parameters

Brightness 800 nits 1,200 nits 1,200 nits

Contrast Ratio 5,000:1 5,000:1 5,000:1

Viewing Angle - Horizontal / Vertical 160° / 140° 160° / 140° 160° / 140°

Number of Colors 11.2 Trillion Colors 11.2 Trillion Colors 11.2 Trillion Colors

Color Wavelength

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Color Temperature - Default / Adjustable 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K

Electrical Parameter

Video Rate 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

Input Power Range 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz

Power Consumption (Max) / (Typical)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

580 (W/2) / 150 (W/Cabinet)
190 (W/2) / 50 (W/Cabinet)

Refresh Rate 2,500 Hz, 4,000 Hz 3,700 Hz, 6,200 Hz 2,500 ~ 4,000 Hz

Operation Conditions

Working Temperature 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F)

IP Rating IP20 IP20 IP20

LED Lifetime 100,000 Hours 100,000 Hours 100,000 Hours

Videowall

UED Series

Model UE46D UE55D

Display

Screen Size 46" 55"

Panel Technology 120Hz (E-LED BLU) 120Hz (E-LED BLU)

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 450 nits 450 nits

Contrast Ratio (Typical) 5000:1 5000:1

Viewing Angle 178°/178° 178°/178°

Orientation Landscape / Portrait Landscape / Portrait

Response Time 4ms 4ms

Connectivity

Input

Output Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 115W / 132W 103W / 154W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0˚C - 40˚C 0˚C - 40˚C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

Software

Internal Media Player

VESA Standard Wall Mount Interface 400 x 400mm 400 x 400mm

Dimensions

Product Dimension (Without Stand) 40.6" 23.0" x 1.2" 48.1" x 27.3" x 1.2"

Packaging Dimension 43.7" x 26.3" x 5.1" 52.8" x 31.5" x 5.7"

Bezel Width 5.5mm 5.5mm

Weight

Product Weight 25.6 lbs. 34 lbs.

Shipping Weight 34.1 lbs. 45.4 lbs.

Service

Standard Warranty 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Mount (Optional)

Stand (Optional) STN-L4055AD, STN-L4655E STN-L4055AD, STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard EMC EMC

ENERGY STAR 5.0 Compliant Yes Yes

RoHS Compliant Yes Yes

Packaging Recyclability Yes, Packing Materials Yes, Packing Materials

Bezel-free, cabinet-based format makes it simple to expand
screen size by adding LED signage cabinets. S-Box eliminates
need for video proce ssor.

Model SNOW-1703U SNOW-1703F

Physical Parameters

Resolution UHD FHD
S/W Platform Tizen 2.4 Tizen 2.4
SoC Hawk Hawk
Log Function Supported Supported
Diagnostics Supported Supported
Ethernet Supported Supported
Input / Output Signal DP, HDMI, USB / DP, HDBT DP, HDMI, USB / DP, HDBT
Magic Info Solution Supported (CMS/Diagnostics) Supported (CMS/Diagnostics)
Bit-depth (bit) 10 bit (RGB 4:4:4) 10 bit (RGB 4:4:4)
Refresh Rate (Hz) 50 / 60Hz 50 / 60Hz
Power Consumption (Max) / (Typical) TBD / TBD TBD / TBD
Working Temperature 0°C~40°C (32°F to 104°F) 0°C~40°C (32°F to 104°F)
Operation Humidity 10% ~ 80% 10% ~ 80%
Image Quality Enhancing HDR, Dynamic Peaking HDR, Dynamic Peaking
Dimensions (W x D x H) 8.8" x 1.3" x 13.8" 8.8" x 1.3" x 13.8"
Weight (lbs) TBD TBD

Stretch

SH Series

Model SH37F

Display

Screen Size 37"

Panel Technology 60Hz D-LED BLU

Resolution 1920 x 540 (16:4.5)

Brightness 700 nits

Contrast Ratio (Typical) 4000:1

Viewing Angle 178° / 178°

Orientation Landscape / Portrait

Response Time 16ms

Connectivity

Input

DVI-I, DisplayPort 1.2, HDMI 1.4 (1), HDCP 2.2
Stereo Mini Jack, USB 2.0 x 1

Output DP1.2 (Loop-out), Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Mini Jack, RJ45

External Sensor IR

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 56W / 77W

Power Consumption (Standby) < 0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C

Operating Humidity 10 - 80%

Features

Special

Hardware

USB Plug and Play, Tilting and Portrait Install support,
Daisy Chains, Shock and Vibration certificated (IEC 61373)

Software

Magic Clone (to USB), RS232 MDC, Videowall, Smart
Scheduling, Auto Source Switching, Internal Media Player

SMART Signage Platform Compliant Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, Samsung Proprietary OS (VDLinux)

VESA Standard Wall Mount Interface 400 x 200 mm

Dimensions

Product Dimension (Without Stand) 36.0" x 11.0" x 1.5"

Packaging Dimension 43.3" x 14.5" x 4.8"

Bezel Width 5.7 mm (Side), 12 mm (Top / Bottom)

Weight

Product Weight 14.5 lbs

Shipping Weight 18.7 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

QSG, Warranty Card, Regulatory Guide, Power Cord,
Batteries, Remote Control, RS232C (IN) Adaptor, Screw,
External Remote Control Sensor, Cover-Jack

Mount (Optional) N/A

Stand (Optional) N/A

Media Player (Optional) SBB (Not Attachable)

Green Management

Emission Standard Class A

ENERGY STAR 5.0 Compliant

TBD

RoHS Compliant Yes

Packaging Recyclability Packing Materials

160,000 m2 / 14,864 ft

2

Red: 630nm, Green: 530nm,
Blue: 468nm

580 (W/2) / 150 (W/Cabinet)
190 (W/2) / 50 (W/Cabinet)

Media
Players

PIM/SBB Series

Model PIM-PB28E PIM-PB32E SBB-DA SBB-B32D SBB-SSE SBB-SSF

Media Player

CPU

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

AMD Bald Eagle RX425BB
(2.5GHz Quad)

Cortex-A9 1GHz Quad Core CPU Cortex-A12 1GHz Quad Core CPU

GPU AMD R6 Graphics AMD R6 Graphics AMD R6 Graphics AMD R6 Graphics

2D & 3D Graphics Engine

- Up to 1920x1080. 32bpp

- Supports OpenGL ES

2D & 3D Graphics Engine

- Up to 3840x2160. 32bpp

- Supports OpenGL ES

FDM/HDD/SSD SSD 128GB SSD 32GB SSD 64GB SSD 32GB

8GB
(2.65GB Occupied by O/S,

5.35GB Available)

8GB
((3.75GB Occupied by O/S,

4.25GB Available)

Memory 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2)

1.5GB
48bit DDR3-933 (1866MHz)

2.5GB
96bit DDR3-933 (1866MHz)

Ethernet Gigabit Ethernet (RJ-45) Gigabit Ethernet (RJ-45) GbE Ethernet (RJ-45) GbE Ethernet (RJ-45) 10/100Mbps (MDC) 10/100Mbps (MDC)

Connectivity

USB

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2 USB 2.0 Port x 2

Output

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

1st: MagicInfo Out (Up-to
3840 x 2160 @ 30Hz)
2nd: DisplayPort Out (Up-to
3840 x 2160 @ 60Hz) Optimized
for FHD Play or 1 UHD Image

1st: MagicInfo Out (Up-to
3840 x 2160 @ 30Hz)
2nd: DisplayPort Out (Up-to
3840 x 2160 @ 60Hz) Optimized
for FHD Play or 1 UHD Image

DVI Out DP 1.2 (Up-to 3840 x 2160

@ 60Hz)
DVI (Up-to 1920 x 1080 @ 60Hz)

Others Mic In, Audio Out Mic In, Audio Out RJ-45, RS232 (D-SUB 9P) RJ-45, RS232 (D-SUB 9P)

RJ-45, RS232 In / Out (Stereo),
IR In, Audio In, HDMI1, HDMI2,
AV / Component

RJ-45, RS232 In / Out (Stereo),
IR In, Audio Out HDMI1, HDMI2

Operating System

Windows Embedded 8.1
Industrial Pro (64bit)

Windows Embedded
Standard 7 (32bit)

Windows Embedded Standard 7 Windows Embedded Standard 7

Samsung Proprietary OS
(VDLinux)

Samsung Proprietary Tizen2.4
OS (VDLinux)

Power

Type N/A (OPS Pass Through) N/A (OPS Pass Through) Internal Internal Adapter Adapter

Power Supply N/A N/A

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

Power Consumption 70W (Max) / 27W (Typical) 70W (Max) / 27W (Typical) 69W (Max) / 30W (Typical) 69W (Max) / 30W (Typical)

19W (Max) / 13W (Typical) /
17W (Rating)

TBD

Mechanical Spec

Dimension

Set 7.9" x 6.9" x 1.4" 7.9" x 6.9" x 1.4" 12.7" x 8.8" x 1.6" 12.7" x 8.8" x 1.6" 12.6" x 8.8" x 1.5" 12.6" x 8.8" x 1.5"

Package 16.9" x 9.8" x 2.2" 16.9" x 9.8" x 2.2" 17" x 10.6" x 3.7" 17" x 10.6" x 3.7" 17" x 10.5" x 3.7" 17" x 10.6 x 3.7

Weight

Set 2.6 lbs 2.6 lbs 4.0 lbs 4.0 lbs 2.8 lbs 2.8 lbs

Package 4.2 lbs 4.2 lbs 5.5 lbs 5.5 lbs 4.6 lbs 4.6 lbs

Operation

Operating Temperature 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C

Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Accessories

Included

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord, IR
sensor, RS-232 gender, DP
Cable (2m)

Videowall

UED Series

Model UE46D UE55D

Display

Screen Size 46" 55"

Panel Technology 120Hz (E-LED BLU) 120Hz (E-LED BLU)

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 450 nits 450 nits

Contrast Ratio (Typical) 5000:1 5000:1

Viewing Angle 178°/178° 178°/178°

Orientation Landscape / Portrait Landscape / Portrait

Response Time 4ms 4ms

Connectivity

Input

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack

Output Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 115W / 132W 103W / 154W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0˚C - 40˚C 0˚C - 40˚C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

WiFi Module Embedded, SD Card Slot, Super Clear
Coating, Temperature Sensor, Pivot Display, Clock Battery
(80hrs Clock Keeping), Built in Speaker (10W x 2ch)

WiFi Module Embedded, SD Card Slot, Super Clear
Coating, Temperature Sensor, Pivot Display, Clock Battery
(80hrs Clock Keeping), Built in Speaker (10W x 2ch)

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Ima ge Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution,
HDCP Support), Smart Scheduling, Smart F/W Update,
Built In MagicInfo Player S2, Videowall (15 x 15), Firmware
Update by Network, LFD New Home Screen, PC-less
Videowall, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Ima ge Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution,
HDCP Support), Smart Scheduling, Smart F/W Update,
Built In MagicInfo Player S2, Videowall (15 x 15), Firmware
Update by Network, LFD New Home Screen, PC-less
Videowall, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player

Internal Media Player

Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM,
USB 2.0, Linux OS

Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM,
USB 2.0, Linux OS

VESA Standard Wall Mount Interface 400 x 400mm 400 x 400mm

Dimensions

Product Dimension (Without Stand) 40.6" 23.0" x 1.2" 48.1" x 27.3" x 1.2"

Packaging Dimension 43.7" x 26.3" x 5.1" 52.8" x 31.5" x 5.7"

Bezel Width 5.5mm 5.5mm

Weight

Product Weight 25.6 lbs. 34 lbs.

Shipping Weight 34.1 lbs. 45.4 lbs.

Service

Standard Warranty 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, Application CD, D-Sub
Cable, Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, D-Sub
Cable, Power Cord, Remote Controller, Batteries

Mount (Optional)

WMN4270SD, WMN250MD, WMN4675MD
(for Videowall W/M)

WMN4270SD, WMN250MD, WMN4675MD
(for Videowall W/M)

Stand (Optional) STN-L4055AD, STN-L4655E STN-L4055AD, STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard EMC EMC

ENERGY STAR 5.0 Compliant Ye s Yes

RoHS Compliant Yes Yes

Packaging Recyclability Yes, Packing Materials Yes, Packing Materials

Interactive
Display

Model

DM65E-BR DM65E-BC DM75E-BR DM82E-BR PMF32F-BC PMF55F-BC

Display

Screen Size 65" 65" 75" 82" 32" 55"
Panel Technology 120Hz E-LED BLU 120Hz E-LED BLU 120Hz E-LED BLU 120Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness (Typical) 380 nits 380 nits (with touch glass) 380 nits 430 nits 300 nits (withs Touch Glass) 400 nits (with Touch Glass)
Contrast Ratio 5000:1 4000:1 5000:1 5000:1 5000:01 4000:01
Viewing Angle (H/V) 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Response Time 6ms 6ms 8ms 8ms 8ms 8ms

Connectivity

RGB In Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2

DVI-I (D-Sub Common), DisplayPort

1.2 (2), HDMI 2.0 (2), HDCP 2.2,
Stereo Mini Jack, RGB / DVI / HDMI,
USB 2.0 x 2 (1 Used for Touch)

DVI-I (D-Sub Common), DisplayPort

1.2 (2), HDMI 2.0 (2), HDCP 2.2, Stereo
Mini Jack, RGB /DVI / HDMI, USB 2.0 x
2 (1 Used for Touch)

Video In

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

Rear: HDMI1, HDMI2, Front Tray
Box: HDMI3

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

DP1.2 (Loop-out), Stereo Mini Jack Stereo Mini Jack

Audio In Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

RS232C (In / Out) thru Stereo
Jack, RJ45

RS232C (In / Out) thru Stereo
Jack, RJ45

Audio Out Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack N/A N/A

Power

Power Supply

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 ~ 240 V, 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 200W / 264W 200W / 264W 110W / 308W 329W / 495W 62W / 90W 125W / 187W
Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Mechanical Specifications

Product Dimensions (Without Stand) 60.4" x 35.84" x 30.0" 58.4" x 34.0" x 2.4" 69.1" x 40.7" x 2.9" (4.3"- Handle) 75.3" x 44.2" x 5.5" (7"- Handle) 29.3" x 17.3" x 2.4" 49.1" x 28.8" x 2.3"
Package Dimensions 65.6" x 40.9" x 9.84" 63.6" x 39.5" x 9.4" 74.6" x 44.2" x 11.85" 81.5" x 50.4" x 20.2" 33.2" x 21.3" x 5.8" 54.1" x 34.0" x 7.9"
Weight Set / Package 101.6 lbs / 119.3 lbs 89.2 lbs / 108.6 lbs 130.4 lbs / 152.1 lbs 172.4 lbs / 208.6 lbs 21.8 lbs / 25.5 lbs 58.2 lbs / 70.5 lbs
VESA Mount 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm 200 x 200 mm 400 x 400 mm
Stand Type None None None None TBD TBD

Bezel Width 39.9 mm (Even)

27.0 mm (U) / 27.8 mm (LR) / 32.4
mm (D)

39.9 mm (Even) 39.9 mm (Even) 21.9 mm (Even) 25.0 mm / 17.9 mm / 25.0 mm

Environmental Conditions

Operating Temperature 0˚C - 40˚C 0˚C - 40˚C 0˚C - 40˚C 0˚C - 40˚C 0°C - 40°C 0˚C - 40˚C
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

General

Special

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Super Clear Coating, Temperature Sensor,
Clock Battery (80hrs Clock Keeping),
Built in Speaker (10W x 2), WiFi Module
Embedded, Front
Tray Box

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Non Glare Touch Panel, Temperature
Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display,
Clock Battery (168hrs Clock Keeping),
Built in Speaker(10W x 2), WiFi Module
Embedded, Tuner (Only for NA), Center IR

Non Glare Touch Panel, Temperature
Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display,
Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 2), WiFi Module
Embedded, Tuner (Only for NA), Center IR

Speaker Built in Speaker (15W + 15W) Built in Speaker (10W x 2) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W)

Optional

Protection Glass Ye s Yes Yes Yes Yes Yes

Mount

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN8200SD WMN4070SD WMN4270SD

Stand STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L3240E STN-L4655E
Specialty All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch All-in-one Touch

Internal Player (MagicInfo)

Special

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built
In MagicInfo Player S3, MagicIWB
S+R58:S582, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C / RJ45
MDC, Plug and Play, PIP / PBP (Only for
NA), Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support),
Firmware Update by Network, New
Home Screen, PC-less Videowall, Multi
Channel, Mobile Control, Event Schedule,
Backup Player

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C / RJ45
MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy
Chain (HDCP Support), Firmware Update
by Network, New Home Screen, PC-less
Videowall (External Source Only), Multi
Channel, Mobile Control, Event Schedule,
Backup Player

SMART Signage Platform Compliant Yes Yes Yes Ye s Yes Ye s
Tuner Yes N/A Ye s Yes Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB
DDR3, 8GB FDM, USB 2.0, Samsung
Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A12 1.3GHz Quad Core, 2.5GB
DDR3, 8GB FDM, USB 2.0, Tizen 2.4
(VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB
DDR3, 8GB FDM, USB 2.0, Tizen 2.4
(VDLinux)

Certification and Compliance

Emission Standard EMC EMC EMC EMC EMC EMC
ROHS Compliant Ye s Yes Ye s Yes Ye s

Yes

Package Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Included

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Gender, Cover Jack, USB Cable

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Gender, Cover Jack, USB Cable

Optional

Mount

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN8200D WMN4070SD WMN4270SD

Stand STN-L7585F STN-L7585F STN-L7585F STN-L7585F STN-L3240E STN-L4655E

External Media Player

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable)

LED

Samsung large format displays can connect to
a variety of media players for complete flexibility.
Connect a Samsung Plug-In-Module (PIM), or a
Samsung Set Back Box (SBB). For even more
flexibility, connect a Windows PC or notebook,
or a third party me dia player.

Quick
Reference
Guide

Samsung SMART Signage Solutions

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 55W / 77W 104W / 176W

Power Consumption (Standby) 0.33W (Sleep Mode) 0.32W (Off Mode) 0.34W (Sleep Mode) 0.31W (Off Mode)

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 1), WiFi Module Embedded

Super Clear Coating, Temperature Sensor, Videowall (15 x 15),
Pivot Display, Clock Battery (168 hrs. Clock Keeping), Built in
Speaker (10W x 2), WiFi Module Embedded

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP
Support), Built In MagicInfo Player S3, Firmware Update
by Network, LFD New Home Screen, PC-less Videowall,
Predefined Template for Vertical Usage, Multi Channel,
Mobile Control, Event Schedule, Backup Player, PC-less
Touch, MagicPresenter

SMART Signage Platform Compliant Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, VDLinux

VESA Standard Wall Mount Interface 200 x 200 mm 400 x 400 mm

24/7 Operation Yes Yes

Speaker Type Built in Speaker (10W x 1) Built in Speaker (10W x 1)

Dimensions

Product Dimension (Without Stand) 29.14" x 17.07" x 2.26" 49.18" x 28.35" x 2.26"

Packaging Dimension 32.17" x 19.80" x 5.75" 54.33" x 33.86" x 8.46"

Bezel Width 1 mm (Black Printing Line 20.4) 1 mm (Black Printing Line 49.3)

Weight

Product Weight 17.4 lbs 56.2 lbs

Shipping Weight 21.6 lbs 63.9 lbs

Service

Standard Warranty

3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, Power
Cord, Remote Controller, Batteries, RS232C (IN) Adapter,
Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Mount (Optional)

WMN4070SD WMN4270SD

Stand (Optional) STN-L3240E STN-L4655E

Media Player (Optional) SBB-DA SBB-DA

Green Management

Emission Standard Class A Class A

ENERGY STAR

®

5.0 Compliant N/A N/A

RoHS Compliant Yes Ye s

Packaging Recyclability Packing Materials Packing Materials

High-Brightness
Outdoor

Model OH46F OH55F OH75F OH85F OM46D-W OM55D-W OM46D-K OM55D-K

Display

Screen Size 46" 55" 75" 85" 46" 55" 46" 55"
Panel Technology S-VA S-VA S-VA S-VA S-PVA, LED Backlit S-PVA, LED Backlit S-PVA, LED Backlit S-PVA, LED Backlit
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 3840 x 2160 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness 2,500 nits 2,500 nits 2,500 nits 2,500 nits 2,500 nits 2,500 nits 2,500 nits 2,500 nits
Contrast Ratio (Typical) 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01
Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait
Response Time 6ms 6ms 6ms 6ms 6ms 6ms 6ms 6ms

Connectivity

Input

HDMI 1.4 (2), HDBaseT (LAN Common), HDCP 2.2,
USB 2.0 x 1

HDMI 1.4 (2), HDBaseT (LAN Common), HDCP 2.2,
USB 2.0 x 1

HDMI 1.4 (2), HDBaseT (LAN Common), HDCP 2.2,
USB 2.0 x 1

DP 1.2 (2) @UHD 60Hz, HDMI 1.4 (2) @UHD 30Hz, HDBaseT,
HDCP 2.2, USB 2.0 (only for FW update)

Video: VGA (D-sub 15 pin), DVI-D, DisplayPort 1.2, HDMI
(2), Component/Composite, Stereo Mini Jack

Video: VGA (D-sub 15 pin), DVI-D, DisplayPort 1.2, HDMI
(2), Component/Composite, Stereo Mini Jack

Video: VGA (D-sub 15 pin), DVI-D, DisplayPort 1.2, HDMI
(2), Component/Composite, Stereo Mini Jack

Video: VGA (D-sub 15 pin), DVI-D, DisplayPort 1.2, HDMI

(2), Component/Composite, Stereo Mini Jack
Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack DisplayPort 1.2 (Loop-out), Stereo Mini Jack DisplayPort 1.2 (Loop-out), Stereo Mini Jack DisplayPort 1.2 (Loop-out), Stereo Mini Jack DisplayPort 1.2 (Loop-out), Stereo Mini Jack
External Control RS232C (In / Out), RJ45 (In / Out), HDBaseT (In) RS232C (In / Out), RJ45 (In / Out), HDBaseT (In) RS232C (In / Out), RJ45 (In / Out), HDBaseT (In) RS232C (In / Out), RJ45 (In / Out), HDBaseT (In) RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45
External Sensor N/A N/A N/A N/A Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient)

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical / Max) 440W / 468W 510W / 554W TBD 680W / 1800W 220W / 395W 300W / 495W 220W / 395W 300W / 495W
Power Consumption (Standby) < .5W < .5W TBD <1.0W < .5W < .5W < .5W < .5W

Environmental Conditions

Operating Temperature -30ºC - 50ºC -30ºC - 50ºC -30ºC - 50ºC -30ºC - 50ºC

0ºC - 30ºC (Direct Sunlight)
0ºC - 50ºC (w/o Direct Sunlight)

0ºC - 30ºC (Direct Sunlight)
0ºC - 50ºC (w/o Direct Sunlight)

0ºC - 30ºC (Direct Sunlight)
0ºC - 50ºC (w/o Direct Sunlight)

0ºC - 30ºC (Direct Sunlight)

0ºC - 50ºC (w/o Direct Sunlight)
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

IP56 Certified for Simple Enclosure Outdoor,
Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce),
Polarized Sun Glasses Viewable in any direction, HD Base
T for Long Distance Installalling, Portrait /Landscape
Installation Support, Lamp Error Detection, Auto Brightness
Control with Ambient Brightness Sensor, Temperature
Sensor, RJ45 MDC, Auto Source Switching & Recovery,
Clock Battery (80hrs Clock Keeping), Kensington Lock

IP56 Certified for Simple Enclosure Outdoor,
Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce),
Polarized Sun Glasses Viewable in any direction, HD Base
T for Long Distance Installalling, Portrait /Landscape
Installation Support, Lamp Error Detection, Auto Brightness
Control with Ambient Brightness Sensor, Temperature
Sensor, RJ45 MDC, Auto Source Switching & Recovery,
Clock Battery (80hrs Clock Keeping), Kensington Lock

IP56 Certified for Simple Enclosure Outdoor,
Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce),
Polarized Sun Glasses Viewable in any direction, HD Base
T for Long Distance Installalling, Portrait /Landscape
Installation Support, Lamp Error Detection, Auto Brightness
Control with Ambient Brightness Sensor, Temperature
Sensor, RJ45 MDC, Auto Source Switching & Recovery,
Clock Battery (80hrs Clock Keeping), Kensington Lock

IP56 Certified for Simple Enclosure Outdoor,
Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce),
Polarized Sun Glasses Viewable in any direction, HD Base
T for Long Distance Installalling, Portrait /Landscape
Installation Support, Lamp Error Detection, Auto Brightness
Control with Ambient Brightness Sensor, Temperature
Sensor, RJ45 MDC, FHD 4-PBP, Auto Source Switching &
Recovery, Clock Battery (80hrs Clock Keeping)

Temperature Sensor, Pivot Display, Button Lock, Built in
Speakers, Wi-Fi Embedded, Slide-in Media Player Option,
SD Card Slot, Polarized Sunglass Compatible, Plug and
Play, MagicInfo, Digital Daisy Chains, Lamp Error Detection,
Anti Image Retention, RS232C/RJ45 MDC, PIP/PBP,
Videowall (10x10), Smart Scheduling

Temperature Sensor, Pivot Display, Button Lock, Built in
Speakers, Wi-Fi Embedded, Slide-in Media Player Option,
SD Card Slot, Polarized Sunglass Compatible, Plug and
Play, MagicInfo, Digital Daisy Chains, Lamp Error Detection,
Anti Image Retention, RS232C/RJ45 MDC, PIP/PBP,
Videowall (10x10), Smart Scheduling

Temperature Sensor, Pivot Display, Button Lock, Wi-Fi
Embedded, Slide-in Media Player Option, SD Card Slot,
Polarized Sunglass Compatible, Plug and Play, MagicInfo,
Digital Daisy Chains, Lamp Error Detection, Anti Image
Retention, RS232C/RJ45 MDC, PIP/PBP, Videowall (10x10),
Smart Scheduling

Temperature Sensor, Pivot Display, Button Lock,

Wi-Fi Embedded, Slide-in Media Player Option,

SD Card Slot, Polarized Sunglass Compatible, Plug and

Play, MagicInfo, Digital Daisy Chains, Lamp Error Detection,

Anti Image Retention, RS232C/RJ45 MDC, PIP/PBP,

Videowall (10x10), Smart Scheduling

Software

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC, PIP /
PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC, PIP /
PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC, PIP /
PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC, PIP /
PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC,
PIP / PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC,
PIP / PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error
Detection, Anti Image Retention, RS232C / RJ45 MDC, PIP /
PBP, Videowall (10 x 10), Smart Scheduling

Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error

Detection, Anti Image Retention, RS232C / RJ45 MDC,

PIP / PBP, Videowall (10 x 10), Smart Scheduling
SMART Signage Platform Compliant Yes Ye s Yes Yes Yes Ye s Yes Yes
Tuner N/A N/A N/A N/A Yes Ye s Yes Yes

Internal Media Player

Cortex-A12 1.3GHz Quad Core CPU, 2.5GB DDR3, 8GB FDM,
USB 2.0, Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core CPU, 2.5GB DDR3, 8GB FDM,
USB 2.0, Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core CPU, 2.5GB DDR3, 8GB FDM,
USB 2.0, Tizen 2.4 (VDLinux)

N/A

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB FDM, USB

2.0, Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB FDM, USB

2.0, Linux OS)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB FDM, USB

2.0, Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB FDM, USB

2.0, Linux OS
VESA Standard Wall Mount Interface 1000 x 400 mm 1200 x 400 mm TBD TBD 600 x 400 mm 600 x 400 mm 600 x 400 mm 600 x 400 mm
24/7 Operation 24/7 24/7 24/7 24/7 24/7 24/7 N/A N/A
Speaker Type N/A N/A N/A N/A Built-in Speaker (10W + 10W) Built-in Speaker (10W + 10W) N/A N/A

Dimensions

Product Dimension (Without Stand) 42.0" x 24.5" x 3.3" 49.6" x 28.7" x 3.3" TBD 78.8" x 46.6" x 4.7" 40.8" x 23.2" x 5.5" 48.3" x 27.5" x 5.5" 40.8" x 23.2" x 5.5" 48.3" x 28.7" x 5.6"
Packaging Dimension 45.5" x 28.0" x 7.8" 53.4" x 33.2" x 9.0" TBD 86.6" x 59.1" x 32.0" 44.2" x 27" x 9.3" 52.6" x 31.8" x 10.4" 44.2" x 27" x 9.3" 52.6" x 31.8" x 10.4"
Bezel Width 24.9 mm (Even) 24.9 mm (Even) TBD 62 mm (Even) 9.3mm (Top) / 7.8mm (L/R) / 6.5mm (Bottom) 9.3mm (Top) / 7.8mm (L/R) / 6.5mm (Bottom) 9.3mm (Top) / 7.8mm (L/R) / 6.5mm (Bottom) 9.3mm (Top) / 7.8mm (L/R) / 6.5mm (Bottom)

Weight

Product Weight 89.3 lbs 115.9 lbs TBD 379.1 lbs 43.2 lbs 52.9 lbs 41.2 lbs 49.4 lbs
Shipping Weight 97.6 lbs 128.0 lbs TBD 489.4 lbs 55.3 lbs 66.1 lbs 53.4 lbs

62.6 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Regulatory Guide, Warranty Card,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Regulatory Guide, Warranty Card,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Regulatory Guide, Warranty Card,
Remote Controller, Batteries

External IR/Brightness Sensor, Quick Setup Guide,
Regulatory Guide, Warranty Card, D-Sub Cable, Power Cord,
Remote Controller, Batteries

External IR/Brightness Sensor, Quick Setup Guide,
Regulatory Guide, Warranty Card, D-Sub Cable, Power Cord,
Remote Controller, Batteries

External IR/Brightness Sensor, Quick Setup Guide,
Regulatory Guide, Warranty Card, D-Sub Cable, Power Cord,
Remote Controller, Batteries

External IR/Brightness Sensor, Quick Setup Guide,
Regulatory Guide, Warranty Card, D-Sub Cable, Power Cord,

Remote Controller, Batteries
Mount (Optional) N/A N/A N/A N/A N/A N/A N/A N/A
Stand (Optional) N/A N/A N/A N/A N/A N/A N/A N/A
Media Player (Optional) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard Class A Class A Class A Class A Class A Class A Class A Class A
ENERGY STAR

®

5.0 Compliant N/A N/A N/A N/A N/A N/A N/A N/A
RoHS Compliant Yes Yes Yes Ye s Yes Yes Ye s Yes
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Videowall

UD Series

Model UD46E-A UD55E-A UD46E-B UD55E-B UH46F5 UH55F-E

Display

Screen Size 46" 55" 46" 55" 46" 55"

Panel Technology D-LED DID D-LED DID D-LED DID D-LED DID D-LED DID D-LED DID

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness Max 700 nits Max 700 nits Max 500 nits Max 500 nits Max 700 nits Max 700 nits

Contrast Ratio (Typical) 3500:1 4000:1 3500:1 3500:1 4000:1 4000:1

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait

Response Time 8ms 8ms 8ms 8ms 8ms 8ms

Connectivity

Input

RGB Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2 DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2

VIDEO HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2 HDMI1, HDMI2

AUDIO Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

Output

RGB DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out) DP1.2 (Loop-out)

AUDIO Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In/Out), RJ45 RS232C (In / Out), RJ45

External Sensor Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient) Detachable Type (IR / Ambient)

Power

Type Internal Internal Internal Internal Internal Internal

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 128W / 187W 180W / 297W 87W / 143W 136W / 198W 120W / 132W 180W / 297W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 44%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 44%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Lamp Error Detection, Anti Retention (Haze
44%), Temperature Sensor, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Videowall (10 x 10), Pivot Display, Image Rotation,
Button Lock, DP 1.2 Digital Daisy Chain (Supporting 10 x 10 UHD
Resolution, HDCP Support), Smart F/W Update, Clock Battery
(80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Lamp Error Detection, Anti Retention (Haze
44%), Temperature Sensor, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Videowall (10 x 10), Pivot Display, Image Rotation,
Button Lock, DP 1.2 Digital Daisy Chain (Supporting 10x10 UHD
Resolution, HDCP Support), Smart F/W Update, Clock Battery
(80hrs Clock Keeping)

ACM Support(Advanced Color Management), Auto Source
Switching & Recovery, Haze 11%, Temperature Sensor,
RS232C/RJ45 MDC,Plug and Play (DDC2B), Videowall
(15 x 15(OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

ACM Support (Advanced Color Management), Auto Source
Switching & Recovery, Haze 25%, Temperature Sensor,
RS232C / RJ45 MDC, Plug and Play (DDC2B), Videowall
(15 x 15 (OSD)), Videowall Daisy Chain (10 x 10), Pivot Display,
Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain
(Supporting UHD Resolution, HDCP Support), Smart F/W Update,
Clock Battery (80hrs Clock Keeping)

SMART Signage Platform Compliant No No No No N/A No

Media Player N/A N/A N/A N/A N/A N/A

VESA Standard Wall Mount Interface 600 x 400 mm 600 x 400 mm 600 x 400 mm 600 x 400 mm 400 x 400 mm 600 x 400 mm

Dimensions

Product Dimension (Without Stand) 40.2" x 22.7" x 3.8" 47.7" x 26.9" x 3.8" 40.2" x 22.7" x 3.8" 47.8" x 26.9" x 3.8" 40.3" x 22.7" x 1.8" 47.6" x 26.8" x 3.7"

Packaging Dimension 45.6" x 28.1" x 11" 53.3" x 31.8" x 12.5" 45.7" x 28.1" x 11.0" 57.1" x 35.6" x 15.2" 46.1" x 28.8" x 10.9" 53.3" x 31.8" x 12.5"

Bezel Width 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 2.3 mm (U/L), 1.2 mm (R/B) 3.4 mm (U/L), 2.0 mm (R/B) 0.96 mm (U/L), 0.47 mm (R/B)

Weight

Product Weight 35.7 lbs 47.3 lbs 39.7 lbs 47.4 lbs 29.1 lbs 46.29 lbs

Shipping Weight 49.8 lbs 63.9 lbs 49.4 lbs 63.9 lbs 42.3 lbs 60.4 lbs

Service

Standard Warranty 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight) 3-Year On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, DP Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, DP Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9
Cable, Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Stereo to DB9 Cable,
Power Cord, Remote Controller, Batteries

Mount (Optional) WMN-46VD WMN-55VD WMN-46VD WMN-55VD WMN-46VD WMN-55VD

Stand (Optional) MID-UD46DS MID-UD55DS MID-UD46DS MID-UD55DS N/A N/A

External Media Player SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA, SBB-B32D (Slide-in) SBB-DA / SBB-SS08E SBB-DA, SBB-B32D (Slide-in)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC

RoHS Compliant Yes Yes Yes Yes Yes Yes

Energy Star 6.0 Compliant ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) ENERGY STAR 6.0 (USA) TBD ENERGY STAR 6.0 (USA)

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Weight 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet) 13.2 lbs. (Per Cabinet)

Optical Parameters

Brightness 800 nits 1,200 nits 1,200 nits

Contrast Ratio 5,000:1 5,000:1 5,000:1

Viewing Angle - Horizontal / Vertical 160° / 140° 160° / 140° 160° / 140°

Number of Colors 11.2 Trillion Colors 11.2 Trillion Colors 11.2 Trillion Colors

Color Wavelength

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Red: 630nm, Green: 530nm,
Blue: 468nm

Color Temperature - Default / Adjustable 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K 6,500K / 2,800 - 10,000K

Electrical Parameter

Video Rate 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

Input Power Range 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz 100~240 VAC, 50/60 Hz

Power Consumption (Max) / (Typical)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

810 (W/2) / 210 (W/Cabinet)
270 (W/2) / 70 (W/Cabinet)

580 (W/2) / 150 (W/Cabinet)
190 (W/2) / 50 (W/Cabinet)

Refresh Rate 2,500 Hz, 4,000 Hz 3,700 Hz, 6,200 Hz 2,500 ~ 4,000 Hz

Operation Conditions

Working Temperature 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F) 0°C - 40°C (32°F - 104°F)

IP Rating IP20 IP20 IP20

LED Lifetime 100,000 Hours 100,000 Hours 100,000 Hours

Memory 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2) 4GB (DDR3 SO-DIMM 2GB x 2)

Ethernet Gigabit Ethernet (RJ-45) Gigabit Ethernet (RJ-45) GbE Ethernet (RJ-45) GbE Ethernet (RJ-45) 10/100Mbps (MDC) 10/100Mbps (MDC)

Connectivity

USB

USB 2.0 Port x 2,
USB 3.0 Port x 2

USB 2.0 Port x 2,
USB 3.0 Port x 2

Output

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

80 pin OPS Port
DisplayPort Out (Up-to
3840 x 2160 @ 60Hz)

Others Mic In, Audio Out Mic In, Audio Out RJ-45, RS232 (D-SUB 9P) RJ-45, RS232 (D-SUB 9P)

Operating System

Windows Embedded 8.1
Industrial Pro (64bit)

Windows Embedded
Standard 7 (32bit)

Power

Type N/A (OPS Pass Through) N/A (OPS Pass Through) Internal Internal Adapter Adapter

Power Supply N/A N/A

Power Consumption 70W (Max) / 27W (Typical) 70W (Max) / 27W (Typical) 69W (Max) / 30W (Typical) 69W (Max) / 30W (Typical)

Mechanical Spec

Dimension

Set 7.9" x 6.9" x 1.4" 7.9" x 6.9" x 1.4" 12.7" x 8.8" x 1.6" 12.7" x 8.8" x 1.6" 12.6" x 8.8" x 1.5" 12.6" x 8.8" x 1.5"

Package 16.9" x 9.8" x 2.2" 16.9" x 9.8" x 2.2" 17" x 10.6" x 3.7" 17" x 10.6" x 3.7" 17" x 10.5" x 3.7" 17" x 10.6 x 3.7

Weight

Set 2.6 lbs 2.6 lbs 4.0 lbs 4.0 lbs 2.8 lbs 2.8 lbs

Package 4.2 lbs 4.2 lbs 5.5 lbs 5.5 lbs 4.6 lbs 4.6 lbs

Operation

Operating Temperature 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C 10˚C - 40˚C

Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Accessories

Included

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Ribbon Cable,
Mounting Bracket

Videowall

UED Series

Model UE46D UE55D

Display

Screen Size 46" 55"

Panel Technology 120Hz (E-LED BLU) 120Hz (E-LED BLU)

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 450 nits 450 nits

Contrast Ratio (Typical) 5000:1 5000:1

Viewing Angle 178°/178° 178°/178°

Orientation Landscape / Portrait Landscape / Portrait

Response Time 4ms 4ms

Connectivity

Input

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack

Output Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack Video: DP1.2 (Loop-out), Audio: Stereo Mini Jack

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 115W / 132W 103W / 154W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0˚C - 40˚C 0˚C - 40˚C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Hardware

WiFi Module Embedded, SD Card Slot, Super Clear
Coating, Temperature Sensor, Pivot Display, Clock Battery
(80hrs Clock Keeping), Built in Speaker (10W x 2ch)

WiFi Module Embedded, SD Card Slot, Super Clear
Coating, Temperature Sensor, Pivot Display, Clock Battery
(80hrs Clock Keeping), Built in Speaker (10W x 2ch)

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution,
HDCP Support), Smart Scheduling, Smart F/W Update,
Built In MagicInfo Player S2, Videowall (15 x 15), Firmware
Update by Network, LFD New Home Screen, PC-less
Videowall, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution,
HDCP Support), Smart Scheduling, Smart F/W Update,
Built In MagicInfo Player S2, Videowall (15 x 15), Firmware
Update by Network, LFD New Home Screen, PC-less
Videowall, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player

Internal Media Player

Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM,
USB 2.0, Linux OS

Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM,
USB 2.0, Linux OS

VESA Standard Wall Mount Interface 400 x 400mm 400 x 400mm

Dimensions

Product Dimension (Without Stand) 40.6" 23.0" x 1.2" 48.1" x 27.3" x 1.2"

Packaging Dimension 43.7" x 26.3" x 5.1" 52.8" x 31.5" x 5.7"

Bezel Width 5.5mm 5.5mm

Weight

Product Weight 25.6 lbs. 34 lbs.

Shipping Weight 34.1 lbs. 45.4 lbs.

Service

Standard Warranty 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, Application CD, D-Sub
Cable, Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, Application CD, D-Sub
Cable, Power Cord, Remote Controller, Batteries

Mount (Optional)

WMN4270SD, WMN250MD, WMN4675MD
(for Videowall W/M)

WMN4270SD, WMN250MD, WMN4675MD
(for Videowall W/M)

Stand (Optional) STN-L4055AD, STN-L4655E STN-L4055AD, STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard EMC EMC

ENERGY STAR 5.0 Compliant Yes Yes

RoHS Compliant Yes Yes

Packaging Recyclability Yes, Packing Materials Yes, Packing Materials

Small Signage

DB Series

Model DB10D DB10E-T (Touchscreen) DB10E-POE DB22D-P DB22D-T (Touchscreen) DB10E-TPOE (Touchscreen)

Display

Screen Size 10.1" 10.1" 10.1" 21.5" 21.5" 10.1"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 60Hz E-LED BLU

Resolution 1280 x 800 1280 x 800 1280 x 800 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1280 x 800

Brightness 450 nits 400 nits 450 nits 250 nits 250 nits 400 nits

Contrast Ratio (Typical) 900:01 900:01 900:01 1000:01 1000:01 900:01

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 30ms 30ms 30ms 5ms 5ms 30ms

Connectivity

Input HDMI, USB 2.0 x 1 HDMI, USB 2.0 x 2 (Up x 1, Down x 1) HDMI, USB 2.0

Output N/A Audio N/A Audio Audio N/A

External Control RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (External) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter)

Power Consumption (Typical / Max) 18W / 18.7W 19W / 20.9W 19W / 20.9W 40W / 44W 40W / 44W TBD

Power Consumption (Standby) < 0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80%, non-condensing 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Temperature Sensor, Portrait Installation Support,
Button Lock, Clock Battery (80hrs Clock Keeping),
Built in Speaker (5W x 1), WiFi Module Embedded,
SD Card Slot, Touch (5 Point, 2 Drawing)

Software

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Image Rotation, Built In MagicInfo Player
S3, Firmware Update by Network, LFD New Home
Screen, Predefined Templates for Vertical Usage,
Mobile Control, Event Schedule, Backup Player

SMART Signage Platform Compliant Yes Yes Yes No Yes Yes

Tuner No No No Yes Ye s No

Internal Media Player

Cortex-A9 1GHz Quad Core, 1.0GB DDR3, 4GB FDM,
USB 2.0, Linux OS

VESA Standard Wall Mount Interface 50 x 50 mm 75 x 75 mm 75 x 75 mm 100 x 100 mm 100 x 100 mm 75 x 75 mm

Dimensions

Product Dimension (Without Stand) 9.7" x 6.5" x .98" 9.7" x 6.5" x 1.1" 9.7" x 6.5" x 1.1" 20.0" x 12.3" x 2.27" 20.0" x 12.3" x 2.33" 9.7" x 6.5" x 1.1"

Packaging Dimension 11.8" x 8.1" x 3.1" 11.8" x 8.1" x 3.1" 11.8" x 8.1" x 3.1" 22.4" x 14.8" x 5.0" 22.4" x 14.8" x 5.0" 11.8" x 8.1" x 3.1"

Bezel Width 14.1 mm (Even) 14.1 mm (Even) 14.1 mm (Even) 17.5 mm (Top), 14.9 mm (Side), 24.5 mm (Bottom) 17.5 mm (Top), 14.9 mm (Side), 24.5 mm (Bottom) 14.1 mm (Even)

Weight

Product Weight 1.3 lbs 1.5 lbs 1.5 lbs 7.2 lbs 7.2 lbs 1.5 lbs

Shipping Weight 3.1 lbs 3.3 lbs 3.3 lbs 10.8 lbs 12.5 lbs 3.1 lbs

Accessories

Included

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC

RoHS Compliant Yes Ye s Yes Yes Yes Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Model SNOW-1703U SNOW-1703F

Physical Parameters

Resolution UHD FHD
S/W Platform Tizen 2.4 Tizen 2.4
SoC Hawk Hawk
Log Function Supported Supported
Diagnostics Supported Supported
Ethernet Supported Supported
Input / Output Signal DP, HDMI, USB / DP, HDBT DP, HDMI, USB / DP, HDBT
Magic Info Solution Supported (CMS/Diagnostics) Supported (CMS/Diagnostics)
Bit-depth (bit) 10 bit (RGB 4:4:4) 10 bit (RGB 4:4:4)
Refresh Rate (Hz) 50 / 60Hz 50 / 60Hz
Power Consumption (Max) / (Typical) TBD / TBD TBD / TBD
Working Temperature 0°C~40°C (32°F to 104°F) 0°C~40°C (32°F to 104°F)
Operation Humidity 10% ~ 80% 10% ~ 80%
Image Quality Enhancing HDR, Dynamic Peaking HDR, Dynamic Peaking
Dimensions (W x D x H) 8.8" x 1.3" x 13.8" 8.8" x 1.3" x 13.8"
Weight (lbs) TBD TBD

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 56W / 77W

Power Consumption (Standby) < 0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C

Operating Humidity 10 - 80%

Features

Special

Hardware

USB Plug and Play, Tilting and Portrait Install support,
Daisy Chains, Shock and Vibration certificated (IEC 61373)

Software

Magic Clone (to USB), RS232 MDC, Videowall, Smart
Scheduling, Auto Source Switching, Internal Media Player

SMART Signage Platform Compliant Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB FDM,
USB 2.0, Samsung Proprietary OS (VDLinux)

VESA Standard Wall Mount Interface 400 x 200 mm

Dimensions

Product Dimension (Without Stand) 36.0" x 11.0" x 1.5"

Packaging Dimension 43.3" x 14.5" x 4.8"

Bezel Width 5.7 mm (Side), 12 mm (Top / Bottom)

Weight

Product Weight 14.5 lbs

Shipping Weight 18.7 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

QSG, Warranty Card, Regulatory Guide, Power Cord,
Batteries, Remote Control, RS232C (IN) Adaptor, Screw,
External Remote Control Sensor, Cover-Jack

Mount (Optional) N/A

Stand (Optional) N/A

Media Player (Optional) SBB (Not Attachable)

Green Management

Emission Standard Class A

ENERGY STAR 5.0 Compliant TBD

RoHS Compliant Yes

Packaging Recyclability Packing Materials

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Ribbon Cable,
Mounting Bracket

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord DP to
DVI Cable (Short, Long)

User Manual, Power Cord, IR
sensor, RS-232 gender, DP
Cable (2m)

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack

WiFi Module Embedded, SD Card Slot, Super Clear
Coating, Temperature Sensor, Pivot Display, Clock Battery
(80hrs Clock Keeping), Built in Speaker (10W x 2ch)

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Ima ge Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution,
HDCP Support), Smart Scheduling, Smart F/W Update,
Built In MagicInfo Player S2, Videowall (15 x 15), Firmware
Update by Network, LFD New Home Screen, PC-less
Videowall, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player

Cortex-A9 1Ghz Quad Core, 1.5GB DDR3, 8GB FDM,
USB 2.0, Linux OS

Quick Setup Guide, Warranty Card, Application CD, D-Sub
Cable, Power Cord, Remote Controller, Batteries

WMN4270SD, WMN250MD, WMN4675MD
(for Videowall W/M)

Small Signage

DB Series

Model DB10D DB10E-T (Touchscreen) DB10E-POE DB22D-P DB22D-T (Touchscreen) DB10E-TPOE (Touchscreen)

Display

Screen Size 10.1" 10.1" 10.1" 21.5" 21.5" 10.1"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 60Hz E-LED BLU

Resolution 1280 x 800 1280 x 800 1280 x 800 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1280 x 800

Brightness 450 nits 400 nits 450 nits 250 nits 250 nits 400 nits

Contrast Ratio (Typical) 900:01 900:01 900:01 1000:01 1000:01 900:01

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 30ms 30ms 30ms 5ms 5ms 30ms

Connectivity

Input HDMI, USB 2.0 x 1 HDMI, USB 2.0 x 2 (Up x 1, Down x 1) HDMI, USB 2.0

GA (D-Sub 15 Pin), HDMI, Audio: Stereo Mini Jack,
USB 2.0 x 2

GA (D-Sub 15 Pin), HDMI, Audio: Stereo Mini Jack,
USB 2.0 x 3

HDMI, USB 2.0

Output N/A Audio N/A Audio Audio N/A

External Control RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (External) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter ) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz (Adapter)

Power Consumption (Typical / Max) 18W / 18.7W 19W / 20.9W 19W / 20.9W 40W / 44W 40W / 44W TBD

Power Consumption (Standby) < 0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80%, non-condensing 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Temperature Sensor, Portrait Installation Support,
Button Lock, Clock Battery (80hrs Clock Keeping),
Built in Speaker (5W x 1), WiFi Module Embedded,
SD Card Slot, Touch (5 Point, 2 Drawing)

Temperature Sensor, Portrait Installation Support,
Button Lock, Clock Battery (80hrs Clock Keeping),
Built in Speaker (5W x 1), WiFi Module Embedded,
SD Card Slot, Touch (5 Point, 2 Drawing)

Temperature Sensor, Portrait Installation Support,
Button Lock, Clock Battery (80hrs Clock Keeping),
Built in Speaker (5W x 1), WiFi Module Embedded,
SD Card Slot, Touch (5 Point, 2 Drawing)

Temperature Sensor, Pivot Display, Image
Rotation, Button Lock, Clock Battery (80hrs Clock
Keeping), Built in Speaker (1W x 2), WiFi Module
Embedded, Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C / RJ45 MDC, Plug and
Play (DDC2B), PIP / PBP, Smart Scheduling, Smart
F/W Update, Built In MagicInfo Player S2, Touch (10
Point, 2 Drawing), Temperature Sensor, Pivot Display,
Image Rotation, Button Lock, Clock Battery (80hrs
Clock Keeping), Built in Speaker (1W x 2),
WiFi Module Embedded

Temperature Sensor, Pivot Display, Image Rotation,
Button Lock, Clock Battery (80hrs Clock Keeping),
Built in Speaker (1W x 2), WiFi Module Embedded,
Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Smart Scheduling, Smart F/W
Update, Built In MagicInfo Player S2, Touch (10 Point,
2 Drawing), Temperature Sensor, Pivot Display, Image
Rotation, Button Lock, Clock Battery (80hrs Clock
Keeping), Built in Speaker (1W x 2),
WiFi Module Embedded

Temperature Sensor, Portrait Installation Support,
Button Lock, Clock Battery (80hrs Clock Keeping),
SD Card Slot, PoE+, Capacitive Touch (5 Point, 2
Drawing)

Software

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Image Rotation, Built In MagicInfo Player
S3, Firmware Update by Network, LFD New Home
Screen, Predefined Templates for Vertical Usage,
Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Image Rotation, Built In MagicInfo Player
S3, Firmware Update by Network, LFD New Home
Screen, Predefined Templates for Vertical Usage,
Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Image Rotation, Built In MagicInfo Player
S3, Firmware Update by Network, LFD New Home
Screen, Predefined Templates for Vertical Usage,
Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Smart Scheduling, Smart F/W
Update, Built In MagicInfo Player S2

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C/RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Smart Scheduling, Smart F/W
Update, Built In MagicInfo Player S2

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), Image Rotation, Built In MagicInfo Player
S3, Firmware Update by Network, LFD New Home
Screen, Predefined Templates for Vertical Usage,
Mobile Control, Event Schedule, Backup Player

SMART Signage Platform Compliant Yes Ye s Yes No Yes Yes

Tuner No No No Yes Yes No

Internal Media Player

Cortex-A9 1GHz Quad Core, 1.0GB DDR3, 4GB FDM,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 4GB FDM,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 4GB FDM,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB DDR3, 8GB,
USB 2.0, Linux OS

VESA Standard Wall Mount Interface 50 x 50 mm 75 x 75 mm 75 x 75 mm 100 x 100 mm 100 x 100 mm 75 x 75 mm

Dimensions

Product Dimension (Without Stand) 9.7" x 6.5" x .98" 9.7" x 6.5" x 1.1" 9.7" x 6.5" x 1.1" 20.0" x 12.3" x 2.27" 20.0" x 12.3" x 2.33" 9.7" x 6.5" x 1.1"

Packaging Dimension 11.8" x 8.1" x 3.1" 11.8" x 8.1" x 3.1" 11.8" x 8.1" x 3.1" 22.4" x 14.8" x 5.0" 22.4" x 14.8" x 5.0" 11.8" x 8.1" x 3.1"

Bezel Width 14.1 mm (Even) 14.1 mm (Even) 14.1 mm (Even) 17.5 mm (Top), 14.9 mm (Side), 24.5 mm (Bottom) 17.5 mm (Top), 14.9 mm (Side), 24.5 mm (Bottom) 14.1 mm (Even)

Weight

Product Weight 1.3 lbs 1.5 lbs 1.5 lbs 7.2 lbs 7.2 lbs 1.5 lbs

Shipping Weight 3.1 lbs 3.3 lbs 3.3 lbs 10.8 lbs 12.5 lbs 3.1 lbs

Accessories

Included

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Quick Setup Guide, Warranty Card, Regulatory Guide,
Power Cord, Adapter, Remote Controller, Batteries,
RS232C-Stereo Cable, Stand Bar

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC

RoHS Compliant Yes Yes Yes Yes Yes Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Interactive
Display

Model

DM65E-BR DM65E-BC DM75E-BR DM82E-BR PMF32F-BC PMF55F-BC

Display

Screen Size 65" 65" 75" 82" 32" 55"
Panel Technology 120Hz E-LED BLU 120Hz E-LED BLU 120Hz E-LED BLU 120Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness (Typical) 380 nits 380 nits (with touch glass) 380 nits 430 nits 300 nits (withs Touch Glass) 400 nits (with Touch Glass)
Contrast Ratio 5000:1 4000:1 5000:1 5000:1 5000:01 4000:01
Viewing Angle (H/V) 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Response Time 6ms 6ms 8ms 8ms 8ms 8ms

Connectivity

RGB In Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D Analog D-SUB, DVI-D, DisplayPort 1.2 Analog D-SUB, DVI-D, DisplayPort 1.2

DVI-I (D-Sub Common), DisplayPort

1.2 (2), HDMI 2.0 (2), HDCP 2.2,
Stereo Mini Jack, RGB / DVI / HDMI,
USB 2.0 x 2 (1 Used for Touch)

DVI-I (D-Sub Common), DisplayPort

1.2 (2), HDMI 2.0 (2), HDCP 2.2, Stereo
Mini Jack, RGB /DVI / HDMI, USB 2.0 x
2 (1 Used for Touch)

Video In

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

Rear: HDMI1, HDMI2, Front Tray
Box: HDMI3

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

Rear: HDMI1, HDMI2, Front
Connectivity Box: HDMI3 Component
(CVBS Common)

DP1.2 (Loop-out), Stereo Mini Jack Stereo Mini Jack

Audio In Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

RS232C (In / Out) thru Stereo
Jack, RJ45

RS232C (In / Out) thru Stereo
Jack, RJ45

Audio Out Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack N/A N/A

Power

Power Supply

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 - 240 V~ (+/- 10 %),
50/60 Hz

AC 100 ~ 240 V, 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 200W / 264W 200W / 264W 110W / 308W 329W / 495W 62W / 90W 125W / 187W
Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Mechanical Specifications

Product Dimensions (Without Stand) 60.4" x 35.84" x 30.0" 58.4" x 34.0" x 2.4" 69.1" x 40.7" x 2.9" (4.3"- Handle) 75.3" x 44.2" x 5.5" (7"- Handle) 29.3" x 17.3" x 2.4" 49.1" x 28.8" x 2.3"
Package Dimensions 65.6" x 40.9" x 9.84" 63.6" x 39.5" x 9.4" 74.6" x 44.2" x 11.85" 81.5" x 50.4" x 20.2" 33.2" x 21.3" x 5.8" 54.1" x 34.0" x 7.9"
Weight Set / Package 101.6 lbs / 119.3 lbs 89.2 lbs / 108.6 lbs 130.4 lbs / 152.1 lbs 172.4 lbs / 208.6 lbs 21.8 lbs / 25.5 lbs 58.2 lbs / 70.5 lbs
VESA Mount 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm 200 x 200 mm 400 x 400 mm
Stand Type None None None None TBD TBD

Bezel Width 39.9 mm (Even)

27.0 mm (U) / 27.8 mm (LR) / 32.4
mm (D)

39.9 mm (Even) 39.9 mm (Even) 21.9 mm (Even) 25.0 mm / 17.9 mm / 25.0 mm

Environmental Conditions

Operating Temperature 0˚C - 40˚C 0˚C - 40˚C 0˚C - 40˚C 0˚C - 40˚C 0°C - 40°C 0˚C - 40˚C
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

General

Special

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Super Clear Coating, Temperature Sensor,
Clock Battery (80hrs Clock Keeping),
Built in Speaker (10W x 2), WiFi Module
Embedded, Front
Tray Box

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Super Clear Coating, Temperature
Sensor, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi
Module Embedded, SD Card Slot, Front
Connectivity Box

Non Glare Touch Panel, Temperature
Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display,
Clock Battery (168hrs Clock Keeping),
Built in Speaker(10W x 2), WiFi Module
Embedded, Tuner (Only for NA), Center IR

Non Glare Touch Panel, Temperature
Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display,
Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 2), WiFi Module
Embedded, Tuner (Only for NA), Center IR

Speaker Built in Speaker (15W + 15W) Built in Speaker (10W x 2) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W) Built in Speaker (15W + 15W)

Optional

Protection Glass Yes Ye s Yes Yes Ye s Ye s

Mount

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN8200SD WMN4070SD WMN4270SD

Stand STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L7585F (New Stand) STN-L3240E STN-L4655E
Specialty All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch (Factory Assembly) All-in-one Touch All-in-one Touch

Internal Player (MagicInfo)

Special

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built
In MagicInfo Player S3, MagicIWB
S+R58:S582, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP,
Image Rotation, Button Lock, Built In
MagicInfo Player S3, MagicIWB S2,
Magic Presenter, USB Auto Switching,
Firmware Update by Network, LFD New
Home Screen, Predefined Template for
Vertical Usage, Multi Channel, Mobile
Control, Event Schedule, Backup Player,
MagicPresenter

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C / RJ45
MDC, Plug and Play, PIP / PBP (Only for
NA), Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support),
Firmware Update by Network, New
Home Screen, PC-less Videowall, Multi
Channel, Mobile Control, Event Schedule,
Backup Player

Magic Clone (to USB), Auto Source
Switching & Recovery, RS232C / RJ45
MDC, Plug and Play, PIP / PBP, Image
Rotation, Button Lock, DP 1.2 Digital Daisy
Chain (HDCP Support), Firmware Update
by Network, New Home Screen, PC-less
Videowall (External Source Only), Multi
Channel, Mobile Control, Event Schedule,
Backup Player

SMART Signage Platform Compliant Yes Yes Yes Yes Yes Yes
Tuner Yes N/A Yes Yes Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A9 1GHz Quad Core, 1.5GB
DDR3, 8GB FDM, USB 2.0, Samsung
Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A9 1GHz Quad Core CPU,

1.5GB, DDR3-933, 8GB, USB 2.0,
Linux OS

Cortex-A12 1.3GHz Quad Core, 2.5GB
DDR3, 8GB FDM, USB 2.0, Tizen 2.4
(VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB
DDR3, 8GB FDM, USB 2.0, Tizen 2.4
(VDLinux)

Certification and Compliance

Emission Standard EMC EMC EMC EMC EMC EMC
ROHS Compliant Yes Yes Yes Yes Yes

Yes

Package Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Included

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Adapter, Pen 1, Pen Tray

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Gender, Cover Jack, USB Cable

Quick Setup Guide, Regulatory Guide,
Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN)
Gender, Cover Jack, USB Cable

Optional

Mount

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN4675MD, WMN4277SD,
WMN6575SD

WMN8200D WMN4070SD WMN4270SD

Stand STN-L7585F STN-L7585F STN-L7585F STN-L7585F STN-L3240E STN-L4655E

External Media Player

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D, PIM-PB32E, PIM-
BF7P, PIM-PB28E, PIM-PB56E

SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable)

Standalone

DCE Series

Model DC32E DC40E DC49H DC55E

Display

Screen Size 32" 40" 49" 55"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 330 nits 350 nits 350 nits 350 nits

Contrast Ratio (Typical) 5000:1 5000:1 5000:1 5000:1

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 8ms 8ms 8ms 6ms

Connectivity

Input

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini Jack,
RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45

External Sensor IR IR N/A IR

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 28W / 77W 36W / 121W 45W / 99W 55W / 176W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 1)

Software

Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

SMART Signage Platform Compliant Yes Yes Yes Yes

Tuner Yes Yes Yes Yes

Internal Media Player

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 1.96" 35.7" x 20.7" x 1.96" 43.1" x 24.7" x 1.2" 48.4" x 27.8" x 1.96"

Packaging Dimension 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 47.7" x 28.3" x 6.1" 53.1" x 31.9" x 5.8"

Bezel Width 10.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 (mm Top / Side), 15.0 mm (Bottom) 9.0 (Top/Side), 11.0 (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom)

Weight

Product Weight 9.7 lbs 15.2 lbs 28.8 lbs 32.5 lbs

Shipping Weight 13.0 lbs 20.3 lbs 38.3 lbs 42.4 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D

Green Management

Emission Standard EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes

RoHS Compliant Yes Yes Yes Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

Standalone

P Series

Model PM32F PM43H PM49H PM55H PH43F-P PH49F-P PH55F-P

Display

Screen Size 32" 43" 49" 55" 43" 49" 55"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 400 nits 500 nits 500 nits 500 nits 700 nits 700 nits 700 nits

Contrast Ratio (Typical) 5000:01 3000:01 4000:01 4000:01 3000:01 4000:01 4000:01

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 8ms 8ms 8ms 8ms 8ms 8ms 8ms

Connectivity

Input

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I(D-Sub Common), DisplayPort 1.2 (2), HDMI (2), Stereo Mini
Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45

External Sensor N/A N/A N/A N/A N/A N/A N/A

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 42W / 88W 66W / 154W 47W / 165W 55W / 187W 108W / 154W 112W / 165W 134W / 187W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Temperature Sensor, Videowall (15 x 15 (OSD)), Videowall Daisy
Chain (16), Pivot Display, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 2), WiFi Module Embedded, Tuner, Center IR

Non Glare Panel, Temperature Sensor, Video Wall (15x15(OSD)), Video
Wall Daisy Chain(16), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, Tuner
(only for NA), IP5x, Center IR

Non Glare Panel, Temperature Sensor, Video Wall (15x15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, Tuner
(only for NA), IP5x, Center IR

Non Glare Panel, Temperature Sensor, Videowall (15x15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, Tuner
(only for NA), IP5x, Center IR

Non Glare Panel, Temperature Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Non Glare Panel, Temperature Sensor, Videowall (15 x 15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Non Glare Panel, Temperature Sensor, Videowall (15 x 15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Software

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/
RJ45 MDC,Plug and Play, PIP/PBP, Ima ge Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less VideoWall (external source only), Multi
Channel, Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/
RJ45 MDC,Plug and Play, PIP/PBP, Ima ge Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall (external source only), Multi
Channel, Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/
RJ45 MDC, Plug and Play, PIP/PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall (external source only), Multi
Channel, Mobile Control, Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

SMART Signage Platform Compliant Yes Yes Yes Yes Yes Yes Yes

Tuner Yes Yes Yes Yes No No No

Internal Media Player

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.3" x 16.3" x 1.1" 37.9" x 21.8" x 1.2" 43.1" x 24.7" x 1.2" 48.5" x 27.6" x 1.5" 37.7" x 21.6" x 1.1" 43.0" x 24.5" x 1.1" 48.3" x 27.6" x 1.1"

Packaging Dimension 31.3" x 19.0" x 5.1" 42.4" x 26" x 6" 47.7" x 28.3" x 6.1" 54.4" x 32.2" x 6.3" 40.8" x 24.7" x 5.1" 47.0" x 28.3" x 6.5" 52.5" x 31.9" x 7.1"

Bezel Width 8.9 mm (Even) 9mm (Top / Side), 11mm (Bottom) 9mm (Top / Side), 11mm (Bottom) 9mm (Top / Side), 11mm (Bottom) 6.9 mm (Top / Side), 8.9 mm (Bottom) 6.9 mm (Top / Side), 8.9 mm (Bottom) 6.9 mm (Top / Side), 8.9 mm (Bottom)

Weight

Product Weight 12.5 lbs 20.9 lbs 29.1 lbs 36.3 lbs 20.7 lbs 29.1 lbs 36.11 lbs

Shipping Weight 15.4 lbs 29.3 lbs 38.5 lbs 48.7 lbs 25.1 lbs 39.9 lbs 48.2 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years Onsite (Parts / Labor / Backlight) 3 Years Onsite (Parts / Labor / Backlight) 3 Years (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L3240E STN-L4655E STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, PIM SBB-DA, PIM SBB-DA, PIM

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC

ENERGY STAR 5.0 Compliant Ye s Yes Yes Yes Yes Yes Yes

RoHS Compliant Yes Yes Ye s Yes Yes Yes Yes

Packaging Recyclability

Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Standalone

DCE Series

Model DC32E DC40E DC49H DC55E

Display

Screen Size 32" 40" 49" 55"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 330 nits 350 nits 350 nits 350 nits

Contrast Ratio (Typical) 5000:1 5000:1 5000:1 5000:1

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 8ms 8ms 8ms 6ms

Connectivity

Input

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini Jack,
RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini Jack,
RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

DVI-I, HDMI 1.4 (2), Component (CVBS Common), Stereo Mini Jack, RGB/DVI/
HDMI/Component Audio (Common), USB 2.0 x 1

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini
Jack, RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45

External Sensor IR IR N/A IR

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 28W / 77W 36W / 121W 45W / 99W 55W / 176W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 1)

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 2)

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 2)

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 2)

Software

Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

Auto Source Switching & Recovery, RS232C / RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

Auto Source Switching & Recovery, RS232C / RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

Auto Source Switching & Recovery, RS232C / RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

SMART Signage Platform Compliant Yes Yes Yes Yes

Tuner Ye s Yes Yes Yes

Internal Media Player

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 1.96" 35.7" x 20.7" x 1.96" 43.1" x 24.7" x 1.2" 48.4" x 27.8" x 1.96"

Packaging Dimension 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 47.7" x 28.3" x 6.1" 53.1" x 31.9" x 5.8"

Bezel Width 10.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 (mm Top / Side), 15.0 mm (Bottom) 9.0 (Top/Side), 11.0 (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom)

Weight

Product Weight 9.7 lbs 15.2 lbs 28.8 lbs 32.5 lbs

Shipping Weight 13.0 lbs 20.3 lbs 38.3 lbs 42.4 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D

Green Management

Emission Standard EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes

RoHS Compliant Yes Ye s Yes Ye s

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

Standalone

DBE Series

Model DB32E DB40E DB48E DB55E

Display

Screen Size 32" 40" 48" 55"

Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 350 nits 350 nits 350 nits 350 nits

Contrast Ratio (Typical) 5000:01 5000:01 5000:01 5000:01

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 8ms 8ms 8ms 6ms

Runtime 16/7 16/7 16/7 16/7

Connectivity

Input

Analog D-SUB, DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack,
USB 2.0 x 1

Analog D-SUB, DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack,
USB 2.0 x 1

Analog D-SUB, DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D Input, Adapter not included),
Component / Composite, Stereo Mini Jack,
USB 2.0 x 1

Analog D-SUB, DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D input, Adapter not included),
Component / Composite, Stereo Mini Jack,
USB 2.0 x 1

Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45 RS232C (In / Out) Thru Stereo Jack, RJ45

External Sensor IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 30W / 77W 40W / 121W 44W / 132W 60W / 176W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0º C - 40º C 0º C - 40º C 0º C - 40º C 0º C - 40º C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 1), WiFi Module Embedded,
SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 1), WiFi Module Embedded,
SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 1), WiFi Module Embedded,
SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (168hrs Clock Keeping),
Built in Speaker (10W x 1), WiFi Module Embedded,
SD Card Slot

Software

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Built-in MagicInfo
S3, Firmware Update by Network, Predefined Template
for Vertical Usage, Multi Channel, Mobile Control, Event
Schedule, Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Built-in MagicInfo
S3, Firmware Update by Network, Predefined Template
for Vertical Usage, Multi Channel, Mobile Control, Event
Schedule, Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Built-in MagicInfo
S3, Firmware Update by Network, Predefined Template
for Vertical Usage, Multi Channel, Mobile Control, Event
Schedule, Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching &
Recovery, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Built-in MagicInfo
S3, Firmware Update by Network, Predefined Template
for Vertical Usage, Multi Channel, Mobile Control, Event
Schedule, Backup Player, PC-less Touch

SMART Signage Platform Compliant Yes Ye s Yes Yes

Tuner Yes Ye s Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB
Storage, USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB
Storage, USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB
Storage, USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB
Storage, USB 2.0, Samsung Proprietary OS (VDLinux)

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 2.0" 35.7" x 20.7" x 2.0" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0"
Packaging Dimension 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8"
Bezel Width 10.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom)

Weight

Product Weight 10.5 lbs 16.1 lbs 24.0 lbs 33.5 lbs
Shipping Weight 12.8 lbs 19.6 lbs 30.0 lbs 42.5 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Mount (Optional) WMN4070SD, WMN450MD WMN4070SD, WMN450MD WMN4070SD, WMN450MD WMN4070SD, WMN450MD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Touch Overlay (Optional) CML400D (Ceiling Mount) CML400D (Ceiling Mount) CML450D (Ceiling Mount) CML450D (Ceiling Mount)

Green Management

Emission Standard EMC EMC EMC EMC
ENERGY STAR

®

6.0 Compliant Yes Ye s Yes Yes
RoHS Compliant Yes Yes Yes Yes
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L3240E STN-L4655E STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, PIM SBB-DA, PIM SBB-DA, PIM

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC

ENERGY STAR 5.0 Compliant Yes Yes Yes Yes Ye s Ye s Ye s

RoHS Compliant Yes Yes Yes Ye s Ye s Ye s Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Standalone

DM Series

Model DM32E DM40E DM48E DM55E DM65E DM75E DM82D

Display

Screen Size 32" 40" 48" 55" 65" 75" 82"
Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 120Hz D-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness 400 nits 450 nits 450 nits 450 nits 450 nits 450 nits 500 nits
Contrast Ratio (Typical) 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01
Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Response Time 8ms 8ms 8ms 6ms 6.5ms 4ms 8ms

Connectivity

Input

Output

External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45
External Sensor IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical / Max) 30W / 77W 44W / 121W 50W / 132W 65W / 176W 110W / 265W 110W / 308W 138W / 363W
Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

SMART Signage Platform Compliant Yes Yes Ye s Ye s Ye s Ye s Ye s
Tuner Yes Yes Ye s Ye s Ye s Ye s Ye s

Internal Media Player

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 2.0" 35.7" x 20.7" x 2.0" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0" 57.8" x 33.4" x 2.2" 66.0" x 37.8" x 2.3" 73.0" x 41.9" x 1.9" (3.5" Handle)
Packaging Dimensions 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8" 63.0" x 38.6" x 11.3" 71.3" x 42.7" x 9.8" 78.8" x 48.7" x 18.6"
Bezel Width 10.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 18.0 mm (Top / Left), 23.5 mm (Right / Bottom) 12.0 mm (Top / Left), 17.3 mm (Right / Bottom) 20.2 mm (Even)

Weight

Product Weight 10.7 lbs 16.6 lbs 24.5 lbs 34.0 lbs 60.4 lbs 75.2 lbs 106.9 lbs
Shipping Weight 13.0 lbs 20.1 lbs 30.9 lbs 43.0 lbs 78.0 lbs 97.2 lbs 138.9 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Mount (Optional) WMN4070SD, WMN250MD WMN4070SD, WMN450MD, WMN250MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4675MD, WMN4277SD, WMN6575SD WMN4675MD, WMN4277SD, WMN6575SD WMN5770D
Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L6500E STN-L7585F (New Stand) STN-L7585F
Media Player (Optional) SBB-DA, SBB-B32D SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P
External Media Player SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC
ENERGY STAR
RoHS Compliant Yes Yes Ye s Ye s Ye s Ye s Ye s
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Standalone

DCE Series

Model DC32E DC40E DC49H DC55E

Display

Screen Size 32" 40" 49" 55"

Panel Technology 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU 60Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 330 nits 350 nits 350 nits 350 nits

Contrast Ratio (Typical) 5000:1 5000:1 5000:1 5000:1

Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Response Time 8ms 8ms 8ms 6ms

Connectivity

Input

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini Jack,
RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

D-SUB, DVI-D, HDMI1, HDMI2, Component (CVBS Common), Stereo Mini Jack,
RGB/DVI/HDMI/CVBS/Component Audio (Common), USB 2.0 x 1

Output Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45 RS232C (In) Thru Stereo Jack, RJ45

External Sensor IR IR N/A IR

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 28W / 77W 36W / 121W 45W / 99W 55W / 176W

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 1)

Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock
Battery (168hrs Clock Keeping), Built in Speaker (10W x 2)

Software

Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

Auto Source Switching & Recovery, RS232C / RJ45 MDC, Plug and Play (DDC2B),
Built In MagicInfo Lite, Firmware Update by Network

SMART Signage Platform Compliant

Yes Ye s Yes Yes

Tuner Ye s Yes Yes Yes

Internal Media Player

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

MIPS 24K, 128KB L2 Cache, 650MHz Processor, 512MB Main Memory
Interface, Samsung Proprietary OS (VD Linux),
179 MB Storage

VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 1.96" 35.7" x 20.7" x 1.96" 43.1" x 24.7" x 1.2" 48.4" x 27.8" x 1.96"

Packaging Dimension 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 47.7" x 28.3" x 6.1" 53.1" x 31.9" x 5.8"

Bezel Width 10.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 (mm Top / Side), 15.0 mm (Bottom) 9.0 (Top/Side), 11.0 (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom)

Weight

Product Weight 9.7 lbs 15.2 lbs 28.8 lbs 32.5 lbs

Shipping Weight 13.0 lbs 20.3 lbs 38.3 lbs 42.4 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D

Green Management

Emission Standard EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes

RoHS Compliant Yes Yes Yes Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

DVI-I(D-Sub Common), DisplayPort 1.2 (2), HDMI (2), Stereo Mini
Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

DVI-I (D-Sub Common), DisplayPort 1.2 (2),
HDMI (2), Stereo Mini Jack, USB 2.0 x 2

Non Glare Panel, Temperature Sensor, Videowall (15 x 15 (OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Non Glare Panel, Temperature Sensor, Videowall (15 x 15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Non Glare Panel, Temperature Sensor, Videowall (15 x 15(OSD)),
Videowall Daisy Chain (16), Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module Embedded, IP5x,
Center IR

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Magic Clone (to USB), Auto Source Switching & Recovery, RS232C /
RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP

1.2 Digital Daisy Chain (HDCP Support), Firmware Update by Network,
New Home Screen, PC-less Videowall, Multi Channel, Mobile Control,
Event Schedule, Backup Player

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

Cortex-A12 1.3GHz Quad Core, 2.5GB DDR3, 8GB FDM, USB 2.0,
Tizen 2.4 (VDLinux)

37.7" x 21.6" x 1.1" 43.0" x 24.5" x 1.1" 48.3" x 27.6" x 1.1"

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Essential

EDE Series

Model ED65E ED75E

Display

Screen Size 65" 75"

Panel Technology 60Hz E-LED BLU 120Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 400 nits 400 nits

Contrast Ratio (Typical) 4000:1 5000:1

Viewing Angle 178° / 178° 178° / 178°

Response Time 6ms 4ms

Connectivity

Input

Output Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) Thru Stereo Jack RS232C (In / Out) Thru Stereo Jack

External Sensor Yes Yes

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 180W / 253W 215W / 275W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

VESA Standard Wall Mount Interface 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 57.7" x 33.3" x 2.2" 65.9" x 37.7" x 3.4" (2.2" - Handle)

Packaging Dimension 62.9" x 38.5" x 11.2" 71.2" x 42.7" x 9.8"

Bezel Width 18.0 mm (Bottom 23.5 mm) 12 mm (Bottom 17.3 mm)

Weight

Product Weight 60.4 lbs 75.1 lbs

Shipping Weight 78.0 lbs 97.2 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Mount (Optional) WMN6575SD WMN6575SD

Stand (Optional) STN-L6500E STN-L7585F

Media Player (Optional) SBB-DA SBB-DA

Green Management

Emission Standard EMC EMC

ENERGY STAR

RoHS Compliant Yes Yes

Packaging Recyclability Packing Materials Packing Materials

Standalone

DM Series

Model DM32E DM40E DM48E DM55E DM65E DM75E DM82D

Display

Screen Size 32" 40" 48" 55" 65" 75" 82"
Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 120Hz D-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness 400 nits 450 nits 450 nits 450 nits 450 nits 450 nits 500 nits
Contrast Ratio (Typical) 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01
Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Response Time 8ms 8ms 8ms 6ms 6.5ms 4ms 8ms

Connectivity

Input

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort

1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort

1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D(HDMI Common), DisplayPort 1.2,
HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI,
DisplayPort 1.2, Component / Composite, USB,
Audio: Stereo Mini Jack, TV In

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack, TV In

Analog D-SUB, DVI-D, DisplayPort 1.2, HDMI1, HDMI2,
HDMI3, Component (CVBS Common)

Output

Audio: Stereo Mini Jack Video: DisplayPort 1.2 (Loop-out)

Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)

Audio: Stereo Mini Jack
External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45
External Sensor IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical / Max) 30W / 77W 44W / 121W 50W / 132W 65W / 176W 110W / 265W 110W / 308W 138W / 363W
Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in Ma gicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S2

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall
(15 x 15), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module
Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall
(15 x 15), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module
Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall

(15 x 15), Pivot Display, Clock Battery (80hrs Clock

Keeping), Built in Speaker (10W x 2), WiFi Module

Embedded, SD Card Slot

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP
Support), Smart Scheduling, Smart F/W Update, Built In
MagicInfo Player S2, Firmware Update by Network, LFD New
Home Screen, PC-less Videowall, Predefined Template for
Vertical Us age, Multi Channel, Mobile Control, Event Schedule,
Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP
Support), Smart Scheduling, Smart F/W Update, Built In
MagicInfo Player S2, Firmware Update by Network, LFD New
Home Screen, PC-less Videowall, Predefined Template for
Vertical Us age, Multi Channel, Mobile Control, Event Schedule,
Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,

RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image

Rotation, Button Lock, Built In MagicInfo Player S3,

MagicIWB S2, Magic Presenter, USB Auto Switching,

Firmware Update by Network, LFD New Home Screen, PC-

less Videowall, Predefined Template for Vertical Usage, Multi

Channel, Mobile Control, Event Schedule, Backup Player,

MagicPresenter

SMART Signage Platform Compliant Yes Yes Ye s Yes Yes Yes Ye s
Tuner Ye s Yes Yes Yes Ye s Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,

USB 2.0, Linux OS
VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 2.0" 35.7" x 20.7" x 2.0" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0" 57.8" x 33.4" x 2.2" 66.0" x 37.8" x 2.3" 73.0" x 41.9" x 1.9" (3.5" Handle)
Packaging Dimensions 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8" 63.0" x 38.6" x 11.3" 71.3" x 42.7" x 9.8" 78.8" x 48.7" x 18.6"
Bezel Width 10.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 18.0 mm (Top / Left), 23.5 mm (Right / Bottom) 12.0 mm (Top / Left), 17.3 mm (Right / Bottom) 20.2 mm (Even)

Weight

Product Weight 10.7 lbs 16.6 lbs 24.5 lbs 34.0 lbs 60.4 lbs 75.2 lbs 106.9 lbs
Shipping Weight 13.0 lbs 20.1 lbs 30.9 lbs 43.0 lbs 78.0 lbs 97.2 lbs 138.9 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN )
Adapter, Cover-Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN )
Adapter, Cover-Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub

Cable, Power Cord, Remote Controller, Batteries, RS232C (IN )

Adapter, Cover-Jack
Mount (Optional) WMN4070SD, WMN250MD WMN4070SD, WMN450MD, WMN250MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4675MD, WMN4277SD, WMN6575SD WMN4675MD, WMN4277SD, WMN6575SD WMN5770D
Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L6500E STN-L7585F (New Stand) STN-L7585F
Media Player (Optional) SBB-DA, SBB-B32D SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P
External Media Player SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC
ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes Yes Ye s Yes
RoHS Compliant Yes Yes Yes Yes Yes Ye s Yes
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Essential

EDE Series

Model ED65E ED75E

Display

Screen Size 65" 75"

Panel Technology 60Hz E-LED BLU 120Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 400 nits 400 nits

Contrast Ratio (Typical) 4000:1 5000:1

Viewing Angle 178° / 178° 178° / 178°

Response Time 6ms 4ms

Connectivity

Input

Analog D-SUB, DVI-D, CVBS, Component, HDMI, Stereo
Mini Jack, USB Player

Analog D-SUB, DVI-D, CVBS, Component, HDMI, Stereo
Mini Jack, USB Player

Output Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) Thru Stereo Jack RS232C (In / Out) Thru Stereo Jack

External Sensor Ye s Yes

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 180W / 253W 215W / 275W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Built in Speaker (10W + 10W), PIP / PBP, Narrow Bezel,
Light Weight, RS232 In / Out, 1 D-Sub &
1 HDMI, USB Player

Built in Speaker (10W + 10W), PIP / PBP, Narrow Bezel,
Light Weight, RS232 In / Out, 1 D-Sub &
1 HDMI, USB Player

VESA Standard Wall Mount Interface 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 57.7" x 33.3" x 2.2" 65.9" x 37.7" x 3.4" (2.2" - Handle)

Packaging Dimension 62.9" x 38.5" x 11.2" 71.2" x 42.7" x 9.8"

Bezel Width 18.0 mm (Bottom 23.5 mm) 12 mm (Bottom 17.3 mm)

Weight

Product Weight 60.4 lbs 75.1 lbs

Shipping Weight 78.0 lbs 97.2 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable, Power
Cord, Remote Controller, Batteries

Mount (Optional) WMN6575SD WMN6575SD

Stand (Optional) STN-L6500E STN-L7585F

Media Player (Optional) SBB-DA SBB-DA

Green Management

Emission Standard EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes

RoHS Compliant Yes Yes

Packaging Recyclability Packing Materials Packing Materials

Bezel Width 10.5 mm (Top / Side), 15.0 mm (Bottom) 9.5 (mm Top / Side), 15.0 mm (Bottom) 9.0 (Top/Side), 11.0 (Bottom) 9.5 mm (Top / Side), 15.0 mm (Bottom)

Weight

Product Weight 9.7 lbs 15.2 lbs 28.8 lbs 32.5 lbs

Shipping Weight 13.0 lbs 20.3 lbs 38.3 lbs 42.4 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter

Mount (Optional) WMN4070SD WMN4070SD WMN4270SD WMN4270SD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D SBB-DA, SBB-D32D

Green Management

Emission Standard EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes

RoHS Compliant Yes Ye s Yes Ye s

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote
Controller, Batteries, RS232C (IN) Adapter, Cover Jack

Essential

EDE Series

Model ED65E ED75E

Display

Screen Size 65" 75"

Panel Technology 60Hz E-LED BLU 120Hz E-LED BLU

Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9)

Brightness 400 nits 400 nits

Contrast Ratio (Typical) 4000:1 5000:1

Viewing Angle 178° / 178° 178° / 178°

Response Time 6ms 4ms

Connectivity

Input

Analog D-SUB, DVI-D, CVBS, Component, HDMI, Stereo
Mini Jack, USB Player

Output Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out) Thru Stereo Jack RS232C (In / Out) Thru Stereo Jack

External Sensor Yes Yes

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 180W / 253W 215W / 275W

Power Consumption (Standby) <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C

Operating Humidity 10 - 80% 10 - 80%

Features

Special

Built in Speaker (10W + 10W), PIP / PBP, Narrow Bezel,
Light Weight, RS232 In / Out, 1 D-Sub &
1 HDMI, USB Player

VESA Standard Wall Mount Interface 400 x 400 mm 400 x 400 mm

Dimensions

Product Dimension (Without Stand) 57.7" x 33.3" x 2.2" 65.9" x 37.7" x 3.4" (2.2" - Handle)

Packaging Dimension 62.9" x 38.5" x 11.2" 71.2" x 42.7" x 9.8"

Bezel Width 18.0 mm (Bottom 23.5 mm) 12 mm (Bottom 17.3 mm)

Weight

Product Weight 60.4 lbs 75.1 lbs

Shipping Weight 78.0 lbs 97.2 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable, Power
Cord, Remote Controller, Batteries

Mount (Optional) WMN6575SD WMN6575SD

Stand (Optional) STN-L6500E STN-L7585F

Media Player (Optional) SBB-DA SBB-DA

Green Management

Emission Standard EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes

RoHS Compliant Yes Yes

Packaging Recyclability Packing Materials Packing Materials

Doing Our Part

Samsung displays are engineered with efficiency in mind.
They meet EMC emission standards, are RoHS compliant
and are Energy Star certified (select models). The displays
themselves meet recyclability standards, and all packing
materials are recyclable.

Warranty

We offer a 3-year on-site parts and labor warranty
standard on LCD displays (2 years on hybrid models).
A Samsung extended warranty and hot-swap service
options are also available. Additionally, authorized
Samsung parts are available to your service department.

Product Support

We’re here when you need us. Our industry-leading
technical support is available on all Samsung displays.
Just call us at 1-800-SAMSUNG or 1-866-SAM4BIZ.

Reseller Support

Our Samsung Team of Empowered Partners (STEP)
program offers special pricing and promotions to
resellers who sign up. And it’s free. Learn more at
partnerportal.samsung.com

©2017 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung
Electronics Corp., Ltd. Specifications and designs are subject to change without notice.
Non-metric weights and measurements are approximate. All brand, product, service names
and logos are trademarks and/or registered trademarks of their respective manufacturers and
companies. Simulated screen images. Printed in USA on 50% recycled (30% post-consumer
waste) paper using soy inks. LFD-FAMILYQRG-MAY17T

Product support 1-866-SAM4BIZ
samsung.com/business insights.samsung.com
samsung.com/b2bdigitalsignage

Follow us

Standalone

DM Series

Model DM32E DM40E DM48E DM55E DM65E DM75E DM82D

Display

Screen Size 32" 40" 48" 55" 65" 75" 82"
Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 120Hz D-LED BLU
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness 400 nits 450 nits 450 nits 450 nits 450 nits 450 nits 500 nits
Contrast Ratio (Typical) 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01 5000:01
Viewing Angle 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Response Time 8ms 8ms 8ms 6ms 6.5ms 4ms 8ms

Connectivity

Input

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), HDMI1,
HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort

1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort

1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

VGA (D-Sub 15 Pin), DVI-D(HDMI Common), DisplayPort 1.2,
HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included),
Component / Composite, Stereo Mini Jack, USB 2.0 x 1

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI,
DisplayPort 1.2, Component / Composite, USB,
Audio: Stereo Mini Jack, TV In

Video: VGA (D-Sub 15 Pin), DVI-D, 2 HDMI, DisplayPort 1.2,
Component / Composite, USB, Audio: Stereo Mini Jack, TV In

Analog D-SUB, DVI-D, DisplayPort 1.2, HDMI1, HDMI2,
HDMI3, Component (CVBS Common)

Output

Audio: Stereo Mini Jack Video: DisplayPort 1.2 (Loop-out)

Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)
Audio: Stereo Mini Jack

Video: DisplayPort 1.2 (Loop-out)

Audio: Stereo Mini Jack
External Control RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45 RS232C (In / Out) thru Stereo Jack, RJ45
External Sensor IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light IR / Ambient Light

Power

Power Supply (Built-in) AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical / Max) 30W / 77W 44W / 121W 50W / 132W 65W / 176W 110W / 265W 110W / 308W 138W / 363W
Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Pla yer S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S3 Slim and Light LFD with Built-in MagicInfo Player S2

Hardware

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Pivot Display,
Button Lock, Clock Battery (80hrs Clock Keeping), Built in
Speaker (10W x 1), Wi-Fi Module Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall
(15 x 15), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module
Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall
(15 x 15), Pivot Display, Clock Battery (168hrs Clock
Keeping), Built in Speaker (10W x 2), WiFi Module
Embedded, SD Card Slot

Super Clear Coating, Temperature Sensor, Videowall

(15 x 15), Pivot Display, Clock Battery (80hrs Clock

Keeping), Built in Speaker (10W x 2), WiFi Module

Embedded, SD Card Slot

Software

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC, Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
RS232C / RJ45 MDC,Plug and Play (DDC2B), PIP / PBP,
Image Rotation, Built-in MagicInfo S3, Firmware Update
by Network, Predefined Template for Vertical Usage, Multi
Channel, Mobile Control, Event Schedule, Backup Player,
PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP
Support), Smart Scheduling, Smart F/W Update, Built In
MagicInfo Player S2, Firmware Update by Network, LFD New
Home Screen, PC-less Videowall, Predefined Template for
Vertical Usa ge, Multi Channel, Mobile Control, Event Schedule,
Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, RS232C / RJ45 MDC, Plug and Play
(DDC2B), PIP / PBP, Image Rotation, Button Lock, DP 1.2
Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP
Support), Smart Scheduling, Smart F/W Update, Built In
MagicInfo Player S2, Firmware Update by Network, LFD New
Home Screen, PC-less Videowall, Predefined Template for
Vertical Usa ge, Multi Channel, Mobile Control, Event Schedule,
Backup Player, PC-less Touch

Magic Clone (to USB), Auto Source Switching & Recovery,

RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image

Rotation, Button Lock, Built In MagicInfo Player S3,

MagicIWB S2, Magic Presenter, USB Auto Switching,

Firmware Update by Network, LFD New Home Screen, PC-

less Videowall, Predefined Template for Vertical Usage, Multi

Channel, Mobile Control, Event Schedule, Backup Player,

MagicPresenter

SMART Signage Platform Compliant Yes Yes Yes Ye s Yes Yes Ye s
Tuner Ye s Yes Yes Ye s Ye s Yes Yes

Internal Media Player

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage,
USB 2.0, Samsung Proprietary OS (VDLinux)

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,
USB 2.0, Linux OS

Cortex-A9 1GHz Quad Core CPU, 1.5GB, DDR3-933, 8GB,

USB 2.0, Linux OS
VESA Standard Wall Mount Interface 200 x 200 mm 200 x 200 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm

Dimensions

Product Dimension (Without Stand) 28.4" x 16.5" x 2.0" 35.7" x 20.7" x 2.0" 42.3" x 24.4" x 2.0" 48.4" x 27.8" x 2.0" 57.8" x 33.4" x 2.2" 66.0" x 37.8" x 2.3" 73.0" x 41.9" x 1.9" (3.5" Handle)
Packaging Dimensions 32.1" x 19.3" x 5.2" 39.8" x 23.8" x 5.4" 46.7" x 28.1" x 5.8" 53.1" x 31.9" x 5.8" 63.0" x 38.6" x 11.3" 71.3" x 42.7" x 9.8" 78.8" x 48.7" x 18.6"
Bezel Width 10.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 9.5 mm (Top / Left), 15.0 mm (Right / Bottom) 18.0 mm (Top / Left), 23.5 mm (Right / Bottom) 12.0 mm (Top / Left), 17.3 mm (Right / Bottom) 20.2 mm (Even)

Weight

Product Weight 10.7 lbs 16.6 lbs 24.5 lbs 34.0 lbs 60.4 lbs 75.2 lbs 106.9 lbs
Shipping Weight 13.0 lbs 20.1 lbs 30.9 lbs 43.0 lbs 78.0 lbs 97.2 lbs 138.9 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable, Power
Cord, Remote Controller, Batteries

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub
Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)
Adapter, Cover-Jack

Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub

Cable, Power Cord, Remote Controller, Batteries, RS232C (IN)

Adapter, Cover-Jack
Mount (Optional) WMN4070SD, WMN250MD WMN4070SD, WMN450MD, WMN250MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4675MD, WMN4277SD, WMN6575SD WMN4675MD, WMN4277SD, WMN6575SD WMN5770D
Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L6500E STN-L7585F (New Stand) STN-L7585F
Media Player (Optional) SBB-DA, SBB-B32D SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P
External Media Player SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC
ENERGY STAR

®

6.0 Compliant Yes Yes Ye s Ye s Yes Yes Ye s
RoHS Compliant Yes Yes Yes Yes Ye s Ye s Yes
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

UHD 4K

QM Series

Model QM49F QM55F QM65F QM75F QM98F QM85D QM85D-BR

Display

Screen Size 49" 55" 65" 75" 98" 85" 85"

Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 120Hz Slim Direct LED BLU 120Hz Slim Direct LED BLU

Resolution 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD

Brightness 500 nits 500 nits 500 nits 500 nits 500 nits 500 nits 430 nits (With Touch Glass)

Contrast Ratio 4700:1 4700:1 4700:1 4700:1 4700:1 5000:1 (Typical) 5000:1 (Typical)

Viewing Angle (Horizontal / Vertical) 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Orientation Landscape / Portrait Landsca pe / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait

Response Time (G-to-G) 8ms (Typical) 8ms (Typical) 8ms (Typical) 8ms (Typical) 8ms (Typical) 6ms (Typical) 6ms (Typical)

Connectivity

Input

RGB DVI-I (D-Sub Common), DisplayPort 1.2 (2) DVI-I (D-Sub Common), DisplayPort 1.2 (2) DVI-I (D-Sub Common), DisplayPort 1.2 (2) DVI-I (D-Sub Common), DisplayPort 1.2 (2) DVI-I (D-Sub Common), DisplayPort 1.2 (2) D-Sub, DVI-D, DisplayPort 1.2 (2), DisplayPort 1.1 (1) D-Sub, DVI-D, DisplayPort 1.2 (2), DisplayPort 1.1 (1)

Video HDMI (4) HDMI (4) HDMI (4) HDMI (4) HDMI (4) HDMI x 3 HDMI x 3

Audio Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

Output Audio Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45

External Sensor IR IR IR IR IR IR IR

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 100W / 154W 110W / 165W 138W / 198W TBD TBD 375 (Typical), 450 (Rating), 495 (Max) 375 (Typical), 450 (Rating), 495 (Max)

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

Hardware

Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W 2ch), IP5x

Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W 2ch), IP5x

Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W 2ch), IP5x

Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W 2ch)

Temperature Sensor, Pivot Display, Clock Battery (80hrs Clock
Keeping), Built in Speaker (10W 2ch)

Temperature Sensor, Clock Battery (80hrs Clock Keeping), Built in
Speaker (15W 2ch)

Temperature Sensor, Clock Battery (80hrs Clock Keeping), Built in
Speaker (15W 2ch)

Software

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Button Lock, DHCP with RJ45 MDC, Hot Key Option,
Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Button Lock, DHCP with RJ45 MDC, Hot Key Option,
Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Button Lock, DHCP with RJ45 MDC, Hot Key Option,
Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Button Lock, DHCP with RJ45 MDC, Hot Key Option,
Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Button Lock, DHCP with RJ45 MDC, Hot Key Option,
Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Remote F/W Update (MDC, MagicInfo Server) Button
Lock, DDC CI, DHCP with RJ45 MDC Urgent Message by MDC, Hot
Key Option, Plug&Play (Initial Setting)

FHD 4 PBP Support (2/3/4 PBP), Auto Source Switching & Recovery,
LFD Home UI, Remote F/W Update (MDC, MagicInfo Server) Button
Lock, DDC CI, DHCP with RJ45 MDC Urgent Message by MDC, Hot
Key Option, Plug&Play (Initial Setting)

VESA Standard Wall Mount Interface 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm 900 x 600 mm 600 x 400 mm 600 x 400 mm

Dimensions

Product Dimensions (Without Stand) 43.2" x 24.9" x 1.4" 48.6" x 27.9" x 1.4" 57.3" x 32.8" x 1.4" 66.1" x 37.8" x 2.4" 86.3" x 49.2" x 2.8" 74.9" x 42.9" x 4.1" 76.7" x 44.5" x 5.1"

Packaging Dimensions 47.0" x 28.3" x 6.9" 52.5" x 31.9" x 7.1" 61.8" x 37.3" x 8.3" TBD TBD 80.7" x 49.8" x 18.6" 82.5" x 51.7" x 20.6"

Bezel Width 11.0 mm (Top / Side), 12.0 mm (Bottom) 11.0 mm (Top / Side), 12.0 mm (Bottom) 12.0 mm (Top / Side), 12.0 mm (Bottom) 14.5 mm (Top / Side), 14.5 mm (Bottom) 15.2 mm (Top / Side), 15.2 mm (Bottom) 13.2 mm (Top / Side) / 19.3 mm (Bottom) 39.9 mm (Even)

Weight

Product Weight 29.5 lbs 36.1 lbs 50.9 lbs TBD TBD 122.4 lbs 179.0 lbs

Shipping Weight 39.4 lbs 49.3 lbs 69.0 lbs TBD TBD 157.4 lbs 218.3 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Quick Setup Guide, Warranty Card, Power Cord, Remote
Controller, Batteries

Quick Setup Guide, Warranty Card, Power Cord, Remote
Controller, Batteries

Quick Setup Guide, Warranty Card, Power Cord, Remote
Controller, Batteries

Quick Setup Guide, Warranty Card, Power Cord, Remote
Controller, Batteries

Quick Setup Guide, Warranty Card, Power Cord, Remote
Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Power Cord,
Remote Controller, Batteries

Quick Setup Guide, Warranty Card, DP Cable, Power Cord,
Remote Controller, Batteries

Mount (Optional) WMN4270SD WMN4270SD WMN6575SD WMN6575SD WMN9500SD WMN5770D WMN8200SD

Stand (Optional) STN-L4655E STN-L4655E STN-L6500E STN-L7585F - STN-L7585F STN-L7585F

Media Player (Optional) SBB-DA SBB-DA SBB-DA SBB-DA SBB-DA SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Yes Yes Yes Ye s Yes Yes

RoHS Compliant Yes Yes Yes Yes Yes Yes Yes

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Standard Warranty 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Quick Setup Guide, Warranty Card, D-Sub Cable,
Power Cord, Remote Controller, Batteries

Mount (Optional) WMN4070SD, WMN450MD WMN4070SD, WMN450MD WMN4070SD, WMN450MD WMN4070SD, WMN450MD

Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E

Media Player (Optional) SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Touch Overlay (Optional) CML400D (Ceiling Mount) CML400D (Ceiling Mount) CML450D (Ceiling Mount) CML450D (Ceiling Mount)

Green Management

Emission Standard EMC EMC EMC EMC

ENERGY STAR

®

6.0 Compliant Yes Ye s Yes Yes
RoHS Compliant Yes Yes Yes Yes
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials

Samsung SMART Signage Solutions

Samsung SMART Signage Solutions are engineered for maximum performance and reliability. The better your displays look, the
better you look. No matter what your application, there’s a Samsung display that’s perfect for you.

Standalone

P Series | PM32F, PM43H, PM49H, PM55H, PH43F-P,

PH49F-P, PH55F-P

Ultra-slim 24/7 reliable displays with full connectivity, built-in TV
tuner (PM models), embedded media player and signage software.

DCE Series | DC32E, DC40E, DC49H, DC55E

Entry 24/7 reliable displays with slim chassis, TV tuner, embedded
media player and signage software.

DBE Series | DB32E, DB40E, DB48E, DB55E

Affordable displays with full connectivity, built-in TV tuner,
embedded media player and signage software.

DM Series | DM32E, DM40E, DM48E, DM55E,

DM65E, DM75E, DM82D

Slim design with 24/7 reliability, built-in TV tuner, embedded
media player and signage software.

Essential

EDE Series | ED65E, ED75E

Budget-friendly displays with simple connectivity and
commercial reliability.

UHD 4K

QM Series | QM49 F, Q M 55F, QM 6 5 F, QM75 F,

QM98F, QM85D, QM85D-BR

Large size ultra-high resolution displays (4K) with quad screen
function and upscaling technology.

Small Signage

DB Series | DB10D, DB10E-T (Touchscreen), DB10E-POE,

DB22D-P, DB22D-T (Touchscreen),
DB10E-TPOE (Touchscreen)

Small form factor signage solution with a fully embedded media
player, high-resolution HD graphics and 16/7 commercial runtime.

Media Players

PIM Series | PIM-PB28E, PIM-PB32E

SBB Series | SBB-DA, SBB-B32D, SBB-SSE, SBB-SSF

Samsung displays can connect to a variety of media players,
including Samsung PIM and SBB, a Windows PC or notebook,
or a third party media player.

Videowall

UD Series | UD46E-A, UD55E-A, UD46E-B, UD55E-B,

UH46F5, UH55F-E

Ultra-narrow bezel videowall displays featuring 24/7 reliability and
embedded media player.

UED Series | UE46D, UE55D

Affordable videowall displays with narrow bezel, embedded media
player and signage software.

High-Brightness / Outdoor

OH Series | OH46F, OH55F, OH75F, OH85F

OM Series | OM46D-K, OM55D-K, OM46D-W, OM55D-W

Fully embedded digital signage solution designed for high ambient
light environments, 24/7 reliable displays, with embedded media
player and full connectivity.

LED

IF Series | IF015H, IF020H, IF025H, SNOW-1703U, SNOW-1703F

Direct-view LED, Bezel-free, cabinet-based format makes it simple
to expand screen size by adding LED signage cabinets.

Stretch

SH Series | SH37F

16:4.5 signage can be displayed portrait or landscape. The 700 nit
brightness and 24/7 operation make it an ideal signage solution.

Mirror

ML Series | ML32E, ML55E

The appearance of a regular mirror combined with the ability to
deliver content. Ideal for salons and fashion retail.

Interactive Display

DME Series | DM65E-BR, DM65E-BC, DM75E-BR, DM82E-BR

For the classroom or the boardroom, e-boards deliver interactive
content, allow on-screen notes, and foster greater learning
and teamwork.

PMF-BC Series | PM32F-BC, PM55F-BC

IP5X rated all-in-one capacitive touch signage solution ideal for
wayfinding, retail and other interactive needs.

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor) 3 Years On-Site (Parts / Labor)

Accessories

Included

Mount (Optional) WMN4070SD, WMN250MD WMN4070SD, WMN450MD, WMN250MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4270SD, WMN450MD, WMN250MD, WMN4675MD WMN4675MD, WMN4277SD, WMN6575SD WMN4675MD, WMN4277SD, WMN6575SD WMN5770D
Stand (Optional) STN-L3240E STN-L3240E STN-L4655E STN-L4655E STN-L6500E STN-L7585F (New Stand) STN-L7585F
Media Player (Optional) SBB-DA, SBB-B32D SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7 PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P PIM-BD7, PIM-BQ7P
External Media Player SBB-DA, SBB-B32D (Not Attachable) SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB-DA, SBB-B32D SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional) SBB (Optional), PIM (Optional)

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC
ENERGY STAR
RoHS Compliant Yes Yes Ye s Ye s Ye s Ye s Ye s
Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

UHD 4K

QM Series

Model QM49F QM55F QM65F QM75F QM98F QM85D QM85D-BR

Display

Screen Size 49" 55" 65" 75" 98" 85" 85"

Panel Technology 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 60Hz D-LED BLU 120Hz Slim Direct LED BLU 120Hz Slim Direct LED BLU

Resolution 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD 3840 x 2160 (16:9) 4K UHD

Brightness 500 nits 500 nits 500 nits 500 nits 500 nits 500 nits 430 nits (With Touch Glass)

Contrast Ratio 4700:1 4700:1 4700:1 4700:1 4700:1 5000:1 (Typical) 5000:1 (Typical)

Viewing Angle (Horizontal / Vertical) 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178° 178° / 178°

Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait Landscape / Portrait

Response Time (G-to-G) 8ms (Typical) 8ms (Typical) 8ms (Typical) 8ms (Typical) 8ms (Typical) 6ms (Typical) 6ms (Typical)

Connectivity

Input

Output Audio Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack

External Control RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45 RS232C (In / Out), RJ45

External Sensor IR IR IR IR IR IR IR

Power

Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical / Max) 100W / 154W 110W / 165W 138W / 198W TBD TBD 375 (Typical), 450 (Rating), 495 (Max) 375 (Typical), 450 (Rating), 495 (Max)

Power Consumption (Standby) <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W <0.5W

Environmental Conditions

Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C 0°C - 40°C

Humidity 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80% 10 - 80%

Features

Special

VESA Standard Wall Mount Interface 400 x 400 mm 400 x 400 mm 400 x 400 mm 600 x 400 mm 900 x 600 mm 600 x 400 mm 600 x 400 mm

Dimensions

Product Dimensions (Without Stand) 43.2" x 24.9" x 1.4" 48.6" x 27.9" x 1.4" 57.3" x 32.8" x 1.4" 66.1" x 37.8" x 2.4" 86.3" x 49.2" x 2.8" 74.9" x 42.9" x 4.1" 76.7" x 44.5" x 5.1"

Packaging Dimensions 47.0" x 28.3" x 6.9" 52.5" x 31.9" x 7.1" 61.8" x 37.3" x 8.3" TBD TBD 80.7" x 49.8" x 18.6" 82.5" x 51.7" x 20.6"

Bezel Width 11.0 mm (Top / Side), 12.0 mm (Bottom) 11.0 mm (Top / Side), 12.0 mm (Bottom) 12.0 mm (Top / Side), 12.0 mm (Bottom) 14.5 mm (Top / Side), 14.5 mm (Bottom) 15.2 mm (Top / Side), 15.2 mm (Bottom) 13.2 mm (Top / Side) / 19.3 mm (Bottom) 39.9 mm (Even)

Weight

Product Weight 29.5 lbs 36.1 lbs 50.9 lbs TBD TBD 122.4 lbs 179.0 lbs

Shipping Weight 39.4 lbs 49.3 lbs 69.0 lbs TBD TBD 157.4 lbs 218.3 lbs

Service

Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)

Accessories

Included

Mount (Optional) WMN4270SD WMN4270SD WMN6575SD WMN6575SD WMN9500SD WMN5770D WMN8200SD

Stand (Optional) STN-L4655E STN-L4655E STN-L6500E STN-L7585F - STN-L7585F STN-L7585F

Media Player (Optional) SBB-DA SBB-DA SBB-DA SBB-DA SBB-DA SBB-DA, SBB-B32D SBB-DA, SBB-B32D

Green Management

Emission Standard EMC EMC EMC EMC EMC EMC EMC

ENERGY STAR

®

RoHS Compliant Yes Yes Ye s Yes Yes Yes Ye s

Packaging Recyclability Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials Packing Materials

Doing Our Part

Samsung displays are engineered with efficiency in mind.
They meet EMC emission standards, are RoHS compliant
and are Energy Star certified (select models). The displays
themselves meet recyclability standards, and all packing
materials are recyclable.

Warranty

We offer a 3-year on-site parts and labor warranty
standard on LCD displays (2 years on hybrid models).
A Samsung extended warranty and hot-swap service
options are also available. Additionally, authorized
Samsung parts are available to your service department.

Product Support

We’re here when you need us. Our industry-leading
technical support is available on all Samsung displays.
Just call us at 1-800-SAMSUNG or 1-866-SAM4BIZ.

Reseller Support

Our Samsung Team of Empowered Partners (STEP)
program offers special pricing and promotions to
resellers who sign up. And it’s free. Learn more at
partnerportal.samsung.com

©2017 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung
Electronics Corp., Ltd. Specifications and designs are subject to change without notice.
Non-metric weights and measurements are approximate. All brand, product, service names
and logos are trademarks and/or registered trademarks of their respective manufacturers and
companies. Simulated screen images. Printed in USA on 50% recycled (30% post-consumer
waste) paper using soy inks. LFD-FAMILYQRG-MAY17T

Product support 1-866-SAM4BIZ
samsung.com/business insights.samsung.com 
samsung.com/b2bdigitalsignage

Follow us

@SamsungBizUSA

youtube.com/samsungbizusa
